HPE LSWM124XG2Q User manual

1
HPE LSWM124XG2Q (JH181A) &
LSWM124XG2QL (JH180A) Interface
Modules User Guide
Part number: 5998-7150t
▌Introduction
Product code HPE description Alias
JH181A
HPE 5930 24-port SFP+ and
2-port QSFP+ with MACsec
Module
LSWM124XG2Q
JH180A HPE 5930 24-port SFP+ and
2-port QSFP+ Module LSWM124XG2QL
Overview
The LSWM124XG2Q and LSWM124XG2QL interface modules are
similar in appearance. Each interface module provides 24 SFP+ ports
and two QSFP+ ports. The SFP+ ports on the LSWM124XG2Q
interface module support MACsec.

2
Figure 1 LSWM124XG2Q interface module front panel
(1) SFP+ port LED (2) QSFP+ port LED
(3) QSFP+ port (4) SFP+ port
SFP+ ports
The SFP+ ports on the LSWM124XG2Q and LSWM124XG2QL
interface modules support the following transceiver modules and
cables:
•SFP transceiver modules in Table 1 and Table 2.
•SFP+ transceiver modules in Table 3 and Table 4.
•SFP+ cables in Table 5.
Table 1 1000 Mbps SFP transceiver modules available for the
SFP+ ports (1)
Product
code HPE description Central wavelength (nm) Connector
JD089B HPE X120 1G SFP
RJ45 T Transceiver N/A RJ-45
JD118B HPE X120 1G SFP
LC SX Transceiver 850 LC
JD119B HPE X120 1G SFP
LC LX Transceiver 1310 LC

3
Product
code HPE description Central wavelength (nm) Connector
JD061A
HPE X125 1G SFP
LC LH40 1310nm
Transceiver
1310 LC
JD062A
HPE X120 1G SFP
LC LH40 1550nm
Transceiver
1550 LC
JD063B HPE X125 1G SFP
LC LH70 Transceiver 1550 LC
Table 2 1000 Mbps SFP transceiver modules available for the
SFP+ ports (2)
Product
code
Cable/fiber
diameter (µm)
Modal
bandwidth
(MHz × km)
Max transmission
distance
JD089B Category-5 twisted
pair N/A 100 m (328.08 ft)
JD118B
Multi-mode, 50/125
500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
Multi-mode,
62.5/125
200 275 m (902.23 ft)
160 220 m (721.78 ft)
JD119B
Single-mode, 9/125 N/A 10 km (6.21 miles)
Multi-mode, 50/125 500 or 400 550 m (1804.46 ft)
Multi-mode,
62.5/125 500 550 m (1804.46 ft)
JD061A Single-mode, 9/125 N/A 40 km (24.86
miles)
JD062A Single-mode, 9/125 N/A 40 km (24.86
miles)

4
Product
code
Cable/fiber
diameter (µm)
Modal
bandwidth
(MHz × km)
Max transmission
distance
JD063B Single-mode, 9/125 N/A 80 km (49.71
miles)
Table 3 10G SFP+ transceiver modules available for the SFP+
ports (1)
Product
code HPE description
Central
waveleng
th (nm)
Connector
JD092B HPE X130 10G SFP+ LC
SR Transceiver 850 LC
JD094B HPE k X130 10G SFP+
LC LR Transceiver 1310 LC
Table 4 10G SFP+ transceiver modules available for the SFP+
ports (2)
Product
code
Fiber diameter
(µm)
Modal
bandwidth
(MHz × km)
Max transmission
distance
JD092B
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125
200 33 m (108.27 ft)
160 26 m (85.30 ft)
JD094B Single-mode,
9/125 N/A 10 km (6.21 miles)

5
Table 5 SFP+ cables available for the SFP+ ports
Product
code HPE description Cable length Data rate
JD095B HPE X240 10G SFP+
SFP+ 0.65m DA Cable 0.65 m (2.13 ft) 10.31 Gbps
JD096B HPE X240 10G SFP+
SFP+ 1.2m DA Cable 1.2 m (3.94 ft) 10.31 Gbps
JD097B HPE X240 10G SFP+
SFP+ 3m DA Cable 3 m (9.84 ft) 10.31 Gbps
JG081C HPE X240 10G SFP+
SFP+ 5m DAC Cable 5 m (16.40 ft) 10.31 Gbps
NOTE:
A
s a best practice, use HPE transceiver modules and cables for
the SFP+ ports. The available transceiver modules and cables
might change over time. For the most recent list of available
transceiver modules and cables, contact Hewlett Packard
Enterprise Support or marketing staff.
For more information about HPE SFP transceiver modules, SFP+
transceiver modules, and SFP+ cables, see HPE Comware-Based
Devices Transceiver Modules User Guide.
QSFP+ ports
The QSFP+ ports on the LSWM124XG2Q and LSWM124XG2QL
interface modules support the following transceiver modules and
cables:
•QSFP+ transceiver modules in Table 6 andTable 7.
•QSFP+ cables in Tabl e 8.
•QSFP+ to SFP+ cables in Table 9.

6
Table 6 40G QSFP+ transceiver modules available for the QSFP+
ports (1)
Product
code HPE description Central wavelength (nm)
Conne
ctor
JG325B HPE X140 40G QSFP+
MPO SR4 Transceiver 850 MPO
JG709A
HPE X140 40G QSFP+
MPO MM 850nm CSR4
300m Transceiver
850 MPO
JG661A HPE X140 40G QSFP+ LC LR4 SM 10km
1310nm Transceiver
Four lanes:
•1271
•1291
•1311
•1331
LC
Table 7 40G QSFP+ transceiver modules available for the QSFP+
ports (2)
Product
code
Cable/fiber
diameter (µm)
Modal
bandwidth
(MHz × km)
Max transmission
distance
JG325B Multi-mode, 50/125
2000 100 m (328.08 ft)
4700 150 m (492.13 ft)
JG709A Multi-mode, 50/125
2000 300 m (984.25 ft)
4700 400 m (1312.34 ft)
JG661A Single-mode, 9/125 N/A 10 km (6.21 miles)

7
Table 8 40G QSFP+ cables available for the QSFP+ ports
Product
code HPE description Cable length Data rate
JG326A
HPE X240 40G QSFP+
QSFP+ 1m Direct Attach
Copper Cable
1 m (3.28 ft) 40 Gbps
JG327A
HPE X240 40G QSFP+
QSFP+ 3m Direct Attach
Copper Cable
3 m (9.84 ft) 40 Gbps
JG328A
HPE X240 40G QSFP+
QSFP+ 5m Direct Attach
Copper Cable
5 m (16.40 ft) 40 Gbps
Table 9 40G QSFP+ to SFP+ cables available for the QSFP+
ports
Product
code HPE description Cable length Data rate
JG329A
HPE X240 40G QSFP+ to
4x10G SFP+ 1m Direct
Attach Copper Splitter Cable
1 m (3.28 ft) 40 Gbps
JG330A
HPE X240 40G QSFP+ to
4x10G SFP+ 3m Direct
Attach Copper Splitter Cable
3 m (9.84 ft) 40 Gbps
JG331A
HPE X240 40G QSFP+ to
4x10G SFP+ 5m Direct
Attach Copper Splitter Cable
5 m (16.40 ft) 40 Gbps

8
NOTE:
•When you install the interface modules on the HPE FlexFabric
5930 4-Slot Switch (JH179A), HPE FlexFabric 5930 4-Slot
TAA Switch (JH188A), and HPE FlexFabric 5940 4-Slot
Switch (JH398A) the 40-GE QSFP+ ports on the interface
modules cannot be split into four 10-GE SFP+ ports.
•As a best practice, use HPE transceiver modules and cables
for the QSFP+ ports. The available transceiver modules and
cables might change over time. For the most recent list of
available transceiver modules and cables, contact Hewlett
Packard Enterprise Support or marketing staff.
For more information about QSFP+ transceiver modules, QSFP+
cables, and QSFP+ to SFP+ cables, see HPE Comware-Based
Devices Transceiver Modules User Guide.
LEDs
Table 10 describes SFP+ port LEDs. Table 11 describes QSFP+ port
LEDs.
Table 10 SFP+ port LED description
LED status Description
Steady green
A transceiver module or cable has been correctly
installed. The port has a link and is operating at 10
Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow
A transceiver module or cable has been correctly
installed. The port has a link and is operating at 1
Gbps.
Flashing
yellow
The port is sending or receiving data at 2 Gbps or
4 Gbps.
Off No transceiver module or cable has been installed
or no link is present on the port.

9
Table 11 QSFP+ port LED description
LED status Description
Steady green
A transceiver module or cable has been correctly
installed. The port has a link and is operating at 40
Gbps.
Flashing green The port is sending or receiving data at 40 Gbps.
Steady yellow
A transceiver module or cable has been correctly
installed. The port has a link and is operating at 10
Gbps.
Flashing
yellow The port is sending or receiving data at 10 Gbps.
Off No transceiver module or cable has been installed
or no link is present on the port.
NOTE:
The SFP+ port LEDs and QSFP+ port LEDs are not affected by
the port mode switching button on your switch. For more
information about the port mode switching button, see the
installation guide of the switch.
▌Installing and removing the interface module
CAUTION:
•Before you install or remove the interface module, wear an
ESD wrist strap and make sure the strap makes good skin
contact and is reliably grounded.
•To avoid device damage, do not use excessive force when you
install or remove the interface module.
The installation and removal procedures are the same for the
LSWM124XG2Q and LSWM124XG2QL interface modules. This
section uses the LSWM124XG2Q interface module as an example.
Installing the interface module
Before you install the interface module, remove the filler panel (if any)
from the target slot. Keep the removed filler panel for future use.

10
To install the interface module:
1. Unpack the interface module.
Figure 2 LSWM124XG2Q interface module
(1) Ejector lever (2) Latch
2. Press the latch on the interface module to release the ejector
lever.
3. Insert the interface module slowly into the slot along the guide
rails, as shown by callout 1 in Figure 3.
4. Rotate inward the ejector lever until the latch locks the ejector
lever in place, as shown by callout 2 in Figure 3.
Figure 3 Installing the interface module

11
Removing the interface module
CAUTION:
•Before you remove the interface module, remove the cable
from it to avoid cable damage.
•If you are not to install a new interface module, install a filler
panel in the slot to prevent dust and ensure good ventilation in
the device.
To remove the interface module:
1. Prepare an anti-static bag.
2. Press the latch to release the ejector lever.
3. Rotate outward the ejector lever, as shown by callout 1 in Figure
4.
4. Pull the interface module slowly out of the interface module slot,
as shown by callout 2 in Figure 4.
5. Place the removed interface module in the anti-static bag.
Figure 4 Removing the interface module
Installing and removing SFP, SFP+, and QSFP+
transceiver modules and cables
For information about installing and removing SFP/SFP+ transceiver
modules and SFP+ cables, see Pluggable SFP/SFP+/XFP
Transceiver Modules Installation Guide.
For information about installing and removing QSFP+ transceiver
modules and cables, see QSFP+ Transceiver Modules/Cables
Installation Guide.

12
Verifying the installation
After the installation is complete, identify whether the interface module
is operating correctly.
If the interface module fails to operate correctly, perform the following
steps:
1. Reinstall it following the installation procedures described in this
document.
2. If the problem persists, contact Hewlett Packard Enterprise
Support.
▌Documentation
To access documentation and support services, go to the Hewlett
Packard Enterprise Support Center website:
www.hpe.com/support/hpesc
The information in this document is subject to change without notice.
© Copyright 2016 Hewlett Packard Enterprise Development LP
BOM: 3101A0JA
Version: 6PW103
5998-7150t
