Huawei Ascend G300 User manual

Phone at a Glance
All the pictures in this guide are for your reference only. Your
phone’s actual display features may be different to those
described here, depending on its software version.
Key Functions at Your Fingertips
• Press and hold to power on your mobile phone.
• When your mobile phone is powered on, press and
hold the button to display the options menu from
where you can power the mobile phone off or
perform some shortcut operations.
• Press to lock the screen when your mobile phone is
active.
Touch to open the menu on an active screen.
Earphone Loudspeaker
Camera
Flashlight
Headset jack
Microphone
Microphone
Volume
Keys
micro USB
charging port

Installing the SIM Card
There are two steps to install the SIM card:
1. Remove the battery cover.
2. Insert the SIM card.
Installing the microSD Card
Your mobile phone is already equipped with a large-volume built-in
embedded MultiMediaCard (eMMC). If you want to expand your
phone memory, you can also insert a microSD card.
1. Remove the battery cover.
2. Insert the microSD card into the card slot as shown in the
diagram.
• Touch to return to the Home screen.
• Touch and hold to display recently used applications.
• Touch to return to the previous screen or exit the
application you are running.
• Touch to hide the keyboard.
12
1 2

Installing the Battery
1. Angle the edge labeled a (with the contacts) into the bottom end
of the battery compartment.
2. Push the edge labeled b into the compartment until the battery
clicks firmly into place.
Charging the Battery
Before charging the battery, ensure that it has been properly installed
on your phone.
1. Connect the USB cable that came with your mobile phone to
the charger.
2. Connect the other end of the USB cable to your mobile phone.
Then, to start charging, plug the charger into an electrical outlet.
If you charge your mobile phone while it is powered on, the battery
icon on the notification bar indicates the charging status. When the
battery icon changes to , your mobile phone is fully charged.

Status Indicator
The color of the status indicator tells you the status of your mobile
phone’s battery.
Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains information
about how to use the device safely. Read this information carefully
before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not use the
device when using the device causes danger or interference with
electronic devices.
Medical Device
• Follow rules and regulations set forth by hospitalsand health
care facilities. Do not use your device when using the device is
prohibited.
• Pacemaker manufacturersrecommend that a minimum
distance of 15 cm be maintainedbetween a device and a
pacemaker to prevent potential interference with the pacemaker.
If you are using a pacemaker, use the device on the opposite
Status Indicator
Green: Fully charged (when connected to charger).
Orange: Charging in progress (when connected to charger).
Red: Battery low.

side of the pacemaker and do not carry the device inyour front
pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas that
may have potentially explosive atmospheres include the areas
where you would normally be advised to turn off your vehicle engine.
Triggering of sparks in such areas could cause an explosion or a fire,
resulting in bodily injuries or even deaths. Do not power on your
device at refueling points such as service stations. Comply with
restrictions on the use of radio equipment in fuel depots, storage, and
distribution areas, and chemical plants. In addition, adhere to
restrictions in areas where blasting operations are in progress.
Before using the device, watch out for areas that have potentially
explosive atmospheres that are often, but not always, clearly
marked. Such locations include areas below the deck on boats,
chemical transfer or storage facilities, and areas where the air
contains chemicals or particles such as grain, dust, or metal
powders. Ask the manufacturers of vehicles using liquefied
petroleum gas (such as propane or butane) whether this device can
be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with the
following guidelines:
• Concentrate on driving. Your first responsibility is to drive safely.
• Do not talk on the device while driving. Use hands-free
accessories.
• When you have to make oranswer a call, park the vehicle at the
road side before using your device.
• RF signals may affect electronic systems of motor vehicles. For
more information, consultthe vehicle manufacturer.

• In a motor vehicle, do not place the device over the air bag or in
the air bag deployment area. Otherwise, the device may hurt you
owing to the strong force when the air bag inflates.
• Do not use your device while flying in an aircraft. Power off your
device before boardingan aircraft. Using wireless devices in an
aircraft may causedanger to the operation of the aircraft and
disrupt the wirelesstelephone network. It may also be
considered illegal.
Operating Environment
• Do not use or charge the device in dusty, damp, and dirty places
or places with magnetic fields. Otherwise, it may result in a
malfunction of the circuit.
• The device complies with the RF specifications when the device
is used near your ear or at a distance of 1.5 cm from your body.
Ensure that the device accessories such as a device case and a
device holster are notcomposed of metal components. Keep
your device 1.5 cm away from your body to meet the
requirement earlier mentioned.
• On a stormy day with thunder, do not use your device when it is
being charged,to prevent any dangercaused by lightning.
• When you are on a call, do not touch the antenna. Touchingthe
antenna affects thecall quality and results in increase in power
consumption. As a result, the talk time and the standby time are
reduced.
• While using the device, observe the local laws and regulations,
and respect others' privacy and legal rights.
• Keep the ambient temperature between -10°C and 45°C while
the device is being charged. Keep the ambient temperature
between -10°C to 55°C forusing the device powered by a
battery.

Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset volume to a
safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety. Letting
the child play with your device or its accessories, which may include
parts that can be detached from the device, may be dangerous, as it
may present a choking hazard. Ensure that small children are kept
away from the device and accessories.
Accessories
Choose only batteries, chargers, and accessories approved for use
with this model by the device manufacturer. The use of any other
type of battery, charger, or accessory may invalidate any warranty for
the device, may be in violation of local rules or laws, and may be
dangerous. Please contact your dealer for information about the
availability of approved batteries, chargers, and accessories in your
area.
Use only the following listed AC Adapters/Power Supplies:
HUAWEI: HW-050100E1W, HW-050100A1W, HW-050100B1W,
HW-050100U1W.
Battery and Charger
• Unplug the charger from the electrical plug and the device when
not in use.
• The battery can be charged and dischargedhundreds of times
before it eventually wears out. When the standbytime and the
talk time are shorterthan the normal time, replace the battery.
• Use the AC power supplydefined in the specifications of the
charger. An improperpower voltage may cause a fire or a
malfunction of the charger.
• Do not connect two poles of the battery with conductors, such as
metal materials, keys, or jewelries. Otherwise, the battery may

be short-circuited and may cause injuries and burns on your
body.
• If battery electrolyte leaks out, ensure that the electrolyte does
not touch your skin and eyes. When the electrolyte touches your
skin or splashes into your eyes, wash youreyes with clean water
immediately and consult a doctor.
• If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery, remove
the battery immediately andstop using it. Otherwise, it may lead
to battery leakage, overheating, explosion, or fire.
• If the power cable is damaged (for example, the cord is exposed
or broken), or the plug loosens, stop using the cable at once.
Otherwise, it may lead to an electric shock, a short circuit of the
charger, or a fire.
• Do not dispose of batteries in fire as they may explode. Batteries
may also explode if damaged.
• Do not modify or remanufacture, attempt to insert foreign objects
into the battery, immerse or expose to water or other liquids,
expose to fire, explosion or other hazard.
• Avoid dropping thedevice or battery. If thedevice or battery is
dropped, especially on a hard surface, and the user suspects
damage, take it to a qualified service center for inspection.
• Improper battery use may result in a fire, explosion or other
hazard.
• Promptly dispose of used batteries in accordance with local
regulations.
• The device should onlybe connected to products that bear the
USB-IF logo or have completed the USB-IF compliance
program.
Cleaning and Maintenance
• The device, battery, and charger are not water-resistant.Keep
them dry. Protect the device, battery, and charger from water or

vapor. Do not touch the device or the charger with a wet hand.
Otherwise, it may lead to a short circuit, a malfunction of the
device, and an electric shock to the user.
• Do not place your device, battery, and charger in places where
they can get damaged because of collision. Otherwise, it may
lead to battery leakage, device malfunction, overheating, fire, or
explosion.
• Do not place magnetic storage media such as magnetic cards
and floppy disks near the device. Radiation from the device may
erase the information stored on them.
• Do not leave your device, battery, and charger in a place with an
extreme high or low temperature. Otherwise, they may not
function properly andmay lead to a fire or an explosion. When
the temperature is lower than 0°C, performance of the battery is
affected.
• Do not place sharp metal objects such as pins near the earpiece.
The earpiece may attract these objects and hurt you when you
are using the device.
• Before you clean or maintain the device, power off the device
and disconnect it from the charger.
• Do not use any chemical detergent, powder, or other chemical
agents (such as alcohol and benzene) to clean the device and
the charger. Otherwise, parts of the device may be damaged or
a fire can be caused. You can clean the device and the charger
with a piece of damp and soft antistatic cloth.
• Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
• If the device screen is broken by colliding with hard objects, do
not touch or try to remove the broken part. In this case, stop using
the device immediately, and then contact an authorized service
center in time.

Emergency Call
You can use your device for emergency calls in the service area. The
connection, however, cannot be guaranteed in all conditions. You
should not rely solely on the device for essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is designed not
to exceed the limits for exposure to radio waves. These guidelines
were developed by the independent scientific organization
International Commission on Non-Ionizing Radiation Protection
(ICNIRP) and include safety measuresdesigned to ensure safety for
all users, regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of measurement for
the amount of radio frequency energy absorbed by the body when
using a device. The SAR value is determined at the highest certified
power level in laboratory conditions, but the actual SAR level of the
device when being operated can be well below the value. This is
because the device is designed to use the minimum power required
to reach the network.
The SAR limit adopted by USA and Canada is 1.6 watts/kilogram
(W/kg) averaged over one gram of tissue. The Highest SAR value
reported to the FCC and IC for this device type when tested for use
at the ear is 0.233 W/kg, when properly worn on body is 0.988 W/kg,
and when using Wi-Fi hotspot function is 0.988 W/Kg.
The SAR limit also adopted by Europe is2.0 W/kg averaged over 10
grams of tissue. The highest SAR value for this device type when
tested at the ear is 0.691 W/kg, and when properly worn on the body
is 0.871 W/kg.
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interferenceto radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Caution
Changes or modifications made to this device not expressly
approved by Huawei Technologies Co., Ltd. may void the
FCC authorization to operate this device.
Disposal and Recycling Information
This symbol (or without a solid bar) on the device, and/or on its
packaging, and on its batteries where included, indicates that the
device including its electrical accessories (e.g. headset, adapter,
cable) and the batteries should not be disposed of as normal
household garbage. These items should not be disposed as
unsorted municipal waste and should be handed over to a certified
collection point for recycling or proper disposal at the end of their life.

For more detailed information about the recycling of the device or
batteries, please contact your local city office, the household waste
disposal service, or the retail store where you purchased it/them.
Disposal of the device and batteries if included is subject to WEEE
Directive Recast (Directive 2012/19/EU) and Battery Directive
(Directive 2006/66/EC). The purpose for separating WEEE and
batteries from other waste is to minimize the potential environmental
impacts on human health of any hazardous substancesthat may be
present.
Reduction of Hazardous Substances
This device is compliant with the REACH Regulation [Regulation
(EC) No 1907/2006] and RoHS Directive Recast (Directive
2011/65/EU). Batteries where included are compliant with Battery
Directive (Directive 2006/66/EC). For more information about the
REACH and RoHS compliance of the device, please visit the Web
site
www.huaweidevice.com/certification . You are
recommended to visit the Web site regularly for up-to-date
information.
EU Regulatory Conformance
Hereby, Huawei Technologies Co., Ltd. declares that this device is in
compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the Web site
www.huaweidevice.com/certification .
Observe the national local regulations in the location where the
device is to be used. This device may be restricted for use in
some or all member states of the European Union (EU).
This device may be operated in all member states of the EU.

Norway : This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund.
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
Legal Notice
Copyright © Huawei Technologies Co., Ltd. 2013. All rights
reserved.
No part of this manual maybe reproduced or transmitted in any form
or by any means without prior written consent of Huawei
Technologies Co., Ltd. and its affiliates (“Huawei”).
The product described in this manual may include copyrighted
software of Huawei and possible licensors. Customers shall not in
any manner reproduce, distribute, modify, decompile, disassemble,
decrypt, extract, reverse engineer, lease, assign, or sublicense the
said software, unless such restrictions are prohibited by applicable
laws or such actions are approved by respective copyright holders.
Trademarks and Permissions
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Android™ is a trademark of Google Inc.
The Bluetooth
®
word mark and logos are registered trademarks
owned by Bluetooth SIG,Inc. and any use of such marks by Huawei
Technologies Co., Ltd. is under license.
Other trademarks, product, service and company names mentioned
may be the property of their respective owners.

Notice
Some features of the product and its accessories described herein
rely on the software installed, capacities and settings of local
network, and therefore may not be activated or may be limited by
local network operators or network service providers.
Thus, the descriptions herein may not exactly match the product or
its accessories which you purchase.
Huawei reserves the right to change or modify any information or
specifications contained in this manual without prior notice and
without any liability.
Third-Party Software Statement
Huawei does not own the intellectual property of the third-party
software and applications that are delivered with this product.
Therefore, Huawei will not provide any warranty of any kind for third
party software and applications. Neither will Huawei provide support
to customers who use third-party software and applications, nor be
responsible or liable for the functions or performance of third-party
software and applications.
Third-party software and applications services may be interrupted or
terminated at any time, and Huawei does not guarantee the
availability of any content or service. Third-party service providers
provide content and services through network or transmission tools
outside of the control of Huawei. To the greatest extent permitted by
applicable law, it is explicitly stated that Huawei shall not compensate
or be liable for services provided by third-party service providers, or
the interruption or termination of third-party contents or services.
Huawei shall not be responsible for the legality, quality, or any other
aspects of any software installed on this product, or for any uploaded
or downloaded third-party works in any form, including but not limited
texts, images, videos, or software etc. Customers shall bear the risk
for any and all effects, including incompatibility between the software
and this product, which result from installing software or uploading or
downloading the third-party works.
This product is based on the open-source Android™ platform.
Huawei has made necessary changes to the platform. Therefore,

this product may not support all the functions that are supported by
the standard Android platform or may be incompatible with third-
party software. Huawei does not provide any warranty and
representation in connect with any such compatability and expressly
excludes all liability in connection with such matters.
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE,
DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS
REGARDLESS OF WHETHER SUCH LOSSES ARE
FORSEEABLE OR NOT.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT
APPLY TO LIABILITY FOR PERSONAL INJURY TO THE
EXTENT APPLICABLE LAW PROHIBITS SUCH A LIMITATION)
OF HUAWEI ARISING FROM THE USE OF THE PRODUCT
DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE
AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF
THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and be responsible to obtain all necessary governmental
permits and licenses in order to export, re-export or import the
product mentioned in this manual including the software and
technical data therein.

Privacy Policy
Please refer to our privacy policy on our websites for the information
about how we protect your personal information.
Getting More
• Please visit www.huaweidevice.com/worldwide for user
guide.
• Please visit
www.huaweidevice.com/worldwide/support/hotline
for recently updated hotline and email address in your country or
region.

Snabbtitt på telefonen
Bilderna i den här handboken tillhandahålls endast som
referens. Beroende på telefonens programversion kan
displayfunktionerna skilja sig från dem som beskrivs här.
Viktiga lättåtkomliga funktioner
• Håll knappen intryckt för att starta mobiltelefonen.
• När mobiltelefonen är påslagen, tryck på knappen
och håll den intryckt för att öppna alternativmenyn.
Därefter kan du välja mellan att stänga av telefonen
eller använda genvägar.
• Tryck på knappen för att låsa skärmen när
mobiltelefonen är aktiv.
Peka för att öppna menyn på en aktiv skärm.
Hörlur Högtalare
Kamera
Blixt
Headsetuttag
Mikrofon
Mikrofon
Volymknapp
Laddnings-/dataport

Installera SIM-kortet
Det är två steg i installationen av SIM-kortet:
1. Ta bort batterilocket.
2. Sätt i SIM-kortet.
Installera microSD-kortet
Din mobiltelefon är redan utrustad med ett inbyggt multimediakort
(eMMC) som har gott om utrymme. Om du vill utöka minnet i din
telefon kan du även sätta i ett microSD-kort.
1. Ta bort batteriluckan.
2. Sätt i microSD-kortet på kortplatsen (se bilden).
• Peka för att återgå till startskärmen.
• Peka och håll kvar för att visa program som nyligen
använts.
• Peka för att återvända till föregående skärm eller
avsluta programmet som körs.
• Peka för att dölja tangentbordet.
12
1 2

Sätta i batteriet
1. Passa in sidan markerad med a (med kontakterna) mot botten
av batterifacket.
2. Tryck in kanten märkt b i facket tills det hörs ett klickljud.
Ladda batteriet
Innan du laddar batteriet, kontrollera att det är korrekt installerat i
telefonen.
1. Anslut USB-kabeln som följer med mobiltelefonen till laddaren.
2. Anslut USB-kabelns andra ände till mobiltelefonen. Anslut
sedan laddaren till ett eluttag för att börja ladda.
Om du laddar mobiltelefonen medan den är påslagen visas
laddningsstatus med batteriikonen i meddelandefältet. När
batteriikonen ändras till är mobiltelefonen fulladdad.

Statusindikator
Statusindikatorns färg anger mobiltelefonens batteristatus.
Varningar och säkerhetsåtgärder
Användningsmiljö
• Telefonen uppfyller RF-specifikationernanär den används nära
örat eller på ett avstånd av 1,5cm från kroppen. Se till att tillbehör
till telefonen som väskor och hölster inte innehåller
metallkomponenter . Håll telefonen 1,5 cm från kroppen för att
uppfylla det tidigare nämnda kravet.
• Håll omgivningstemperaturenmellan -10 °C och 45 °C under
tiden som enheten laddas. Omgivningstemperaturen ska vara
mellan -10 °C och 55 °C när enheten används med ett batteri.
Certifieringsinformation (SAR)
Telefonen uppfyller kraven i riktlinjerna för exponering för radiovågor.
Enheten är en radiosändare och mottagare med låg effekt. Enheten
är konstruerad för att inte överskrida gränserna för exponering av
radiovågor, enligt rekommendationer i internationella riktlinjer. Dessa
riktlinjer har utvecklats av den oberoende vetenskapliga
organisationen ICNIRP och inbegriper säkerhetsgränser som är
Status indikator
Grön: Fullt laddad (när den är ansluten till laddare).
Orange: Laddning pågår (när den är ansluten till laddare).
Röd: Lågt batteri.
