HUAWEI Vision User Guide

i
Smartphone at a Glance ......................... 1
Installing the SIM Card ............................ 2
Installing the microSD Card..................... 3
Installing the Battery................................ 3
Charging the Battery ............................... 4
Touchscreen Actions............................... 5
Home Screen .......................................... 6
Importing Contacts from a SIM Card....... 7
Adding a Contact..................................... 7
Making a Call with the Phone Application 8
Creating and Sending a Multimedia
Message.................................................. 8
Connecting to the Internet ....................... 9
Turning Off the Data Service................... 10
Google Play Store ................................... 10
Uninstalling an Application ...................... 11
Using the Camera ................................... 11
Using the microSD Card as a USB Mass
Storage.................................................... 12
Playing Music .......................................... 13
FAQs ....................................................... 13
Safety Information ................................... 15
Personal Information and Data Security.. 28
Contents

ii
Legal Notice ............................................ 29
Warranty Information............................... 33
Support.................................................... 34

1
Smartphone at a Glance
All the pictures in this guide are for reference
only. The smartphone's actual display features
may be different to those described here,
depending on its software version.
Key Functions at Your Fingertips
• Press and hold to power on the
smartphone.
• When the smartphone is powered on,
press and hold this button to display the
options menu. You can then choose to
power off the smartphone or perform
shortcut operations.
• Press to lock the screen when the
smartphone is active.
Volume
key
Earpiece
Charger/
Data port
Speaker
Power key Headset jack
Back
Home
Menu
Microphone
Camera

2
Installing the SIM Card
There are two steps to install the SIM card:
1. Remove the battery cover.
2. Insert the SIM card.
Touch to open the menu on an active
screen.
• Touch to return to the Home screen.
• Touch and hold to display recently used
applications.
• Touch to return to the previous screen or
exit the application you are running.
• Touch to hide the keyboard.
12

3
Installing the microSD Card
The smartphone is already equipped with a large-
volume built-in embedded MultiMediaCard (eMMC).
If you want to expand the smartphone's memory, you
can also insert a microSD card.
1. Remove the battery cover.
2. Insert the microSD card into the card slot as
shown in the diagram.
Installing the Battery
1. Angle the edge labeled a (with the contacts) into
the bottom end of the battery compartment.
2. Push the edge labeled b into the compartment
until the battery clicks firmly into place.
12
a
b

4
Charging the Battery
Before charging the battery, ensure that it has been
properly installed in the smartphone.
1. Connect the USB cable that came with the
smartphone to the charger.
2. Connect the other end of the USB cable to the
smartphone. Then, to start charging, plug the
charger into an electrical outlet.
If you charge the smartphone while it is powered on,
the battery icon on the notification bar indicates the
charging status. When the battery icon changes to
, the smartphone is fully charged.

5
Status Indicator
The color of the status indicator tells you the status of
the smartphone's battery.
Touchscreen Actions
Using your finger on the touchscreen, you can
conveniently operate the smartphone.
Status Indicator
Green: Fully charged (when connected to charger).
Orange: Charging in progress (when connected to charger).
Red: Battery low.
Drag
TouchTouch & hold Double touch
Rotate Flick

6
Home Screen
You can set up the Home screen according to your
own preferences, for example by adding a shortcut
or a widget to your Home screen, changing the
wallpaper, or setting the number of Home screen
extensions.
To return to the Home screen from any of its
extensions, press .
When a new notification icon appears on the
notification bar, place your finger on the notification
bar and flick down to open the notification panel.
Adding a New Home Screen Item
1. On the Home screen, touch to display the
application list.
2. Press and hold an application icon, and then
drag the icon to a blank area on the Home
screen.
Flick your finger left or right
across the Home screen.
10:23
10:23
+
Touch to view thumbnails
of the Home screen and its
extensions. Touch a thumbnail
to open the screen.

7
Removing an Icon from the Home
Screen
1. Touch and hold an item on the Home screen that
you want to remove, until the smartphone
vibrates.
2. Without lifting your finger, drag the item to the
trash can. Wait until the item and the trash can
turn red.
3. Release the item.
Importing Contacts from a SIM
Card
1. In the contacts list, touch > Manage
contacts .
2. Touch Copy from SIM card .
3. Wait for the SIM card contents to be loaded.
Touch one contact to import that contact
individually to the smartphone, or touch
SELECT
ALL
to import all contacts to the smartphone.
4. Touch COPY .
5. If you have more than one account on the
smartphone, touch the account into which you
want to import the contacts.
Adding a Contact
1. In the contact list, touch .
2. From the screen displayed, create a contact in
the smartphone, SIM card or your account. Add a
new account if you do not have one.

8
3. Enter the contact's name, and then add detailed
information such as phone numbers and
address.
4. Touch DONE to save the contact information.
To save a contact from your call log, touch and
hold the desired phone number to display the
options menu, and then touch
Add to contacts .
Making a Call with the Phone
Application
1. On the Home screen, touch > Phone . If the
dialer is not displayed, touch .
2. Enter the phone number.
3. Touch to initiate the call.
Creating and Sending a
Multimedia Message
You can use multimedia messages to make
everyday communications very special. You can
record a message and send it as an audio file, for
example, sing "Happy Birthday" and send it to a
friend, or send a slideshow of photographs of a
special event. The possibilities are enormous.
1. Touch > Messaging , then .
2. Enter a phone number in the To field, or touch
to select a contact from People .
3. Touch the composition text box to start
composing your message.

9
4. Touch to attach a picture, an audio file, or a
video clip to the message.
5. When you are ready to send the message, touch
Send MMS .
Connecting to the Internet
Get online using the smartphone's Wi-Fi to save your
money.
Turning On Wi-Fi
1. Touch > Settings .
2. Under WIRELESS & NETWORKS , touch the
button next to
Wi-Fi .
Basic Operations
Touch > Browser to open the home page.
When known or open Wi-Fi networks and mobile
data networks are available at the same time, the
smartphone will preferably select a Wi-Fi
network for Internet access.
Touch on the upper section of the screen, and all
web pages currently open are displayed. You can:
• Touch one page to enlarge it.
• Touch the cross sign (×) to close that page.
• Touch (+) to open a new browser window.
Opening a Webpage
1. In a browser window, touch the URL field at the
top of the screen.

10
2. Use the keyboard to enter a webpage address.
You can touch to enter the web page address
by voice.
3. As you enter the address, matching webpage
addresses will appear on the screen. If you see
the address you want, touch it and go directly to
that webpage or finish entering your desired
webpage.
Turning Off the Data Service
When you are not using your data service, to
eliminate unwanted data traffic, you can turn it off
quickly.
1. Open the notification bar.
2. Touch at the top of the screen to switch data
services on or off.
Google Play Store
Google Play Store provides direct access to
applications and games which you can download
and install on the smartphone.
Opening Play Store
1. On the Home screen, touch > Play Store .
2. When you open Play Store for the first time, the
Google Play Terms of Service window will
appear. Touch
Accept to continue.
Installing an Application
1. In the Play Store , select a category, and then
touch the application you want to download.

11
2. Follow the onscreen instructions to download
and install the application.
After the application has been downloaded and
installed on the smartphone, the content download
icon appears in the notification bar.
If you want to install a non-Play Store application,
touch
> Settings > Security , and then select
the Unknown sources check box to allow
installation of the non-Play Store application.
Uninstalling an Application
You cannot uninstall the applications that are
pre-installed on the system.
1. On the Settings screen, touch Apps .
2. Touch an application, and then touch Uninstall .
Using the Camera
You can take and share photos using the camera.
Your camera supports multiple capture modes and
photo effects. After taking a picture, access the
Gallery to view it. For information on how to share
photos and videos, see the full manual at:
www.ConsumerCellular/Support/
VideosandManuals
.

12
Capture Screen
Using the microSD Card as a
USB Mass Storage
1. Connect the smartphone to your PC with the
USB cable provided. Your PC will detect the
microSD card as a removable storage device.
2. Open the notification bar, and then touch USB
connected
.
3. Touch Turn on USB storage in the dialog box
that opens to confirm that you want to transfer
files.
You can now transfer files from your PC to the
smartphone's microSD card.
Thumbnail of last
photo. Touch to
preview the photos
or videos.
Touch to take a
photo.
Touch to customize the camera settings.
Drag up to take
photos, drag down
to record videos.
AutoAuto

13
Playing Music
You can listen to music that you have stored on your
microSD card using the music player . The music
player will automatically search for any music on the
microSD card sort it into albums and playlists.
FAQs
How Can I Use a microSD Card to Import
Contacts to My Smartphone from Another
Smartphone?
The smartphone supports contact files in the .vcf
format only.
1. Save the contacts you want to import to the
smartphone to a microSD as a .vcf file.
2. Insert the microSD card into the smartphone and
find the .vcf file using
File Manager .
3. Touch the .vcf file. The smartphone displays a
message asking whether you want to import the
contacts.
4. Touch OK to import the contacts.
Back Search music
Music player
controls
Progress bar

14
Compatibility problems may occur with .vcf files
created by different smartphone, and certain
contact information may be lost when contacts
are imported.
How Do I Disable Automatic Change of
Screen Orientation When Rotating My
Smartphone?
On the Home screen, touch > Settings >
Display , and then clear the Auto-rotate screen
check box to disable this function.
How Do I Set an Unlock Pattern?
On the Home screen, touch > Settings >
Security > Screen lock > Pattern .
How Do I Stop the Song Playing in the
Background?
Flick the notification bar downwards to open the
notifications panel, touch the music playing
notification to go to the music playing screen, and
then stop playing the song.
How Do I Return to the Call Screen?
If you switched to another screen during a call, flick
the notification bar downwards to open the
notifications panel, and then touch the current call
notification to return to the call screen.
How Do I Create an Application Shortcut
on the Home Screen?
Touch and hold an application icon on the
application screen until the Home screen is

15
displayed. Then drag the icon to where you want to
place it and release your finger.
How Do I Hide the Keyboard?
Touch to hide the keyboard.
How Do I Forward a Message?
On the message viewing screen, touch and hold a
message, and then select
Forward from the
displayed menu.
Why Am I Unable to Use Navigation?
Navigation is unavailable in some countries or
regions.
Safety Information
This section contains important information about
the operation of your device. It also contains
information about how to use the device safely. Read
this information carefully before using your device.
Electronic device
Do not use your device if using the device is
prohibited. Do not use the device if doing so causes
danger or interference with other electronic devices.
Interference with medical equipment
• Follow rules and regulations set forth by hospitals
and health care facilities. Do not use your device
where prohibited.
• Some wireless devices may affect the
performance of hearing aids or pacemakers.
Consult your service provider for more
information.

16
• Pacemaker manufacturers recommend that a
minimum distance of 15 cm be maintained
between a device and a pacemaker to prevent
potential interference with the pacemaker. If using
a pacemaker, hold the device on the side opposite
the pacemaker and do not carry the device in your
front pocket.
Protecting your hearing when using a
headset
• Using a headset at high volumes may damage
your hearing. To reduce this risk, lower the
headset volume to a safe and comfortable level.
• Exposure to high volumes while driving may
cause distraction and increase your risk of an
accident.
Areas with flammables and explosives
• Do not use the device where flammables or
explosives are stored (in a gas station, oil depot,
or chemical plant, for example). Using your device
in these environments increases the risk of
explosion or fire. In addition, follow the
instructions indicated in text or symbols.
• Do not store or transport the device in containers
with flammable liquids, gases, or explosives.
Traffic security
• Observe local laws and regulations while using
the device. To reduce the risk of accidents, do not
use your wireless device while driving.

17
• Concentrate on driving. Your first responsibility is
to drive safely.
• Do not hold the device while driving. Use hands-
free accessories.
• When you must make or answer a call, pull of the
road safely and park the vehicle first.
• RF signals may affect the electronic systems of
motor vehicles. For more information, consult the
vehicle manufacturer.
• Do not place the device over the air bag or in the
air bag deployment area in a motor vehicle. Doing
so may hurt you because of the strong force when
the air bag inflates.
• Do not use your device while flying in an aircraft or
immediately before boarding. Using wireless
devices in an aircraft may disrupt wireless
networks, present a hazard to aircraft operation,
or be illegal.
Operating environment
• Avoid dusty, damp, or dirty environments. Avoid
magnetic fields. Using the device in these
environments may result in circuit malfunctions.
• Do not use your device during thunderstorms to
protect your device against any danger caused by
lightning.
• Ideal operating temperatures are -10 ℃ to 45 ℃ .
( Keep the ambient temperature between 0°C and
45°C while the device is being charged. Keep the
ambient temperature between -10°C to 45°C for
using the device powered by a battery.) Ideal
