Huawei BTS3900E GSM User manual

BTS3900E GSM
V300R008&V600R009
User Guide
Issue 01
Date 2010-01-15
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. For any
assistance, please contact our local office or company headquarters.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [email protected]
Copyright © Huawei Technologies Co., Ltd. 2010. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are the property of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or representations
of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.

Contents
About This Document.....................................................................................................................1
1 Changes in the BTS3900E GSM User Guide........................................................................1-1
2 Typical Installation Scenarios of the BTS3900E (Indoor Coverage)................................2-1
2.1 Scenario 1: AC Power Input............................................................................................................................2-3
2.2 Scenario 2: -48 V DC Power Input.................................................................................................................2-4
3 Typical Installation Scenarios of the BTS3900E (Outdoor Coverage).............................3-1
3.1 Scenario 1: AC Power Input (No Backup Power Required)...........................................................................3-2
3.2 Scenario 2: -48 V DC Power Input (No Backup Power Required).................................................................3-3
3.3 Scenario 3: AC Power Input (Backup Power Required).................................................................................3-5
4 Monitoring Scheme of the BTS3900E.....................................................................................4-1
5 BTS3900E Hardware..................................................................................................................5-1
5.1 BTS3900E Equipment.....................................................................................................................................5-2
5.1.1 BTS3900E Appearance..........................................................................................................................5-2
5.1.2 Panels of the BTS3900E........................................................................................................................5-3
5.1.3 LEDs on the BTS3900E.........................................................................................................................5-5
5.1.4 DIP Switch on the BTS3900E................................................................................................................5-7
5.2 BTS3900E Cables...........................................................................................................................................5-8
5.2.1 List of the BTS3900E Cables.................................................................................................................5-9
5.2.2 PGND Cable of the BTS3900E............................................................................................................5-11
5.2.3 Power Cable of the BTS3900E............................................................................................................5-12
5.2.4 Transmission Cable of the BTS3900E.................................................................................................5-15
5.2.5 Alarm Cable of the BTS3900E............................................................................................................5-19
5.2.6 RF Cable of the BTS3900E..................................................................................................................5-21
5.3 Auxiliary Devices of the BTS3900E.............................................................................................................5-26
5.3.1 Integrated Antennas of the BTS3900E.................................................................................................5-26
5.3.2 Structure of SLPU................................................................................................................................5-29
5.3.3 AC Surge Protection Box.....................................................................................................................5-31
6 BTS3900E Maintenance.............................................................................................................6-1
6.1 Maintenance Items for the BTS3900E............................................................................................................6-2
6.2 Powering On and Powering Off the BTS3900E.............................................................................................6-2
6.2.1 Powering On the BTS3900E..................................................................................................................6-2
BTS3900E GSM
User Guide Contents
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i

6.2.2 Powering Off the BTS3900E.................................................................................................................6-3
6.3 Replacing the BTS3900E................................................................................................................................6-4
6.4 Replacing an Optical Module..........................................................................................................................6-6
Contents
BTS3900E GSM
User Guide
ii Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-01-15)

Figures
Figure 2-1 Mapping between the cables and their colors.....................................................................................2-1
Figure 2-2 Installation of one AC-powered BTS3900E in omni-directional configuration................................2-3
Figure 2-3 Installation of two AC-powered BTS3900Es in omni-directional configuration...............................2-4
Figure 2-4 Installation of one DC-powered BTS3900E in omni-directional configuration................................2-4
Figure 2-5 Installation of two DC-powered BTS3900Es in omni-directional configuration...............................2-5
Figure 3-1 Mapping between the cables and their colors.....................................................................................3-1
Figure 3-2 Installation of one AC-powered BTS3900E in omni-directional configuration................................3-2
Figure 3-3 Installation of AC-powered BTS3900E in three-sector configuration...............................................3-3
Figure 3-4 Installation of one AC-powered BTS3900E in omni-directional configuration................................3-4
Figure 3-5 Installation of DC-powered BTS3900E in three-sector configuration...............................................3-4
Figure 3-6 Installation of one AC-powered BTS3900E in omni-directional configuration................................3-5
Figure 3-7 Installation of DC-powered BTS3900E in three-sector configuration...............................................3-6
Figure 4-1 Monitoring system..............................................................................................................................4-1
Figure 5-1 Dimensions of the AC-powered BTS3900E and the DC-powered BTS3900E.................................5-2
Figure 5-2 Positions of the BTS3900E panels.....................................................................................................5-3
Figure 5-3 Panels of the DC-powered BTS3900E...............................................................................................5-4
Figure 5-4 Panels of the AC-powered BTS3900E...............................................................................................5-4
Figure 5-5 Position of the BTS3900E DIP switch...............................................................................................5-7
Figure 5-6 PGND cable......................................................................................................................................5-11
Figure 5-7 DC power cable of the BTS3900E (North American standard).......................................................5-12
Figure 5-8 Power cable between the BTS3900E and the AC surge protection box...........................................5-13
Figure 5-9 Power cable between the BTS3900E and the power supply device.................................................5-14
Figure 5-10 Power cable between the AC surge protection box and the power supply device.........................5-14
Figure 5-11 Ethernet cable.................................................................................................................................5-16
Figure 5-12 75-ohm E1 cable.............................................................................................................................5-17
Figure 5-13 120-ohm E1 cable...........................................................................................................................5-17
Figure 5-14 Appearance of the SFP high-speed cable.......................................................................................5-19
Figure 5-15 Appearance of the multi-mode optical cable..................................................................................5-19
Figure 5-16 Alarm cable.....................................................................................................................................5-20
Figure 5-17 RF jumper.......................................................................................................................................5-21
Figure 5-18 Mapping between the RF cables and their colors...........................................................................5-21
Figure 5-19 RF cable connections (1)................................................................................................................5-22
Figure 5-20 RF cable connections (2)................................................................................................................5-23
BTS3900E GSM
User Guide Figures
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii

Figure 5-21 RF cable connections (3)................................................................................................................5-24
Figure 5-22 RF cable connections (4)................................................................................................................5-25
Figure 5-23 RF cable connections (5)................................................................................................................5-26
Figure 5-24 Appearance of omni-directional antennas......................................................................................5-27
Figure 5-25 Appearance of directional antennas................................................................................................5-28
Figure 5-26 Structure of SLPU..........................................................................................................................5-29
Figure 5-27 Panel of the USLP2........................................................................................................................5-29
Figure 5-28 DIP switches on the USLP2...........................................................................................................5-30
Figure 5-29 AC surge protection box.................................................................................................................5-31
Figure 6-1 Removing the BTS3900E...................................................................................................................6-5
Figures
BTS3900E GSM
User Guide
iv Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-01-15)

Tables
Table 4-1 Functions of the monitoring system.....................................................................................................4-2
Table 5-1 Dimensions of the AC-powered BTS3900E and the DC-powered BTS3900E...................................5-3
Table 5-2 Panels of the BTS3900E......................................................................................................................5-4
Table 5-3 LEDs on the BTS3900E.......................................................................................................................5-6
Table 5-4 Default settings of the 4-bit DIP switch...............................................................................................5-7
Table 5-5 Settings of the 4-bit DIP switch (1)......................................................................................................5-8
Table 5-6 Settings of the 4-bit DIP switch (2)......................................................................................................5-8
Table 5-7 List of the BTS3900E cables................................................................................................................5-9
Table 5-8 Pin assignment for the wires of the DC power cable of the BTS3900E (North American standard)
.............................................................................................................................................................................5-13
Table 5-9 Pin assignment for the wires of the DC power cable of the BTS3900E (European standard)...........5-13
Table 5-10 Pin assignment for the wires of the power cable between the BTS3900E and the AC surge protection
box.......................................................................................................................................................................5-14
Table 5-11 Pin assignment for the wires of the power cable between the BTS3900E and the power supply device
.............................................................................................................................................................................5-15
Table 5-12 Pin assignment for the wires of the power cable between the AC surge protection box and the power
supply device.......................................................................................................................................................5-15
Table 5-13 Pin assignment for the wires of the Ethernet cable..........................................................................5-16
Table 5-14 Installation position of the Ethernet cable........................................................................................5-16
Table 5-15 Pin assignment for the wires of the 75-ohm E1 coaxial cable.........................................................5-18
Table 5-16 Pin assignment for the wires of the 120-ohm E1 twisted pair cable................................................5-18
Table 5-17 Application scenarios of the inter-BTS3900E signal cable.............................................................5-19
Table 5-18 Pin assignment for the wires of the alarm cable...............................................................................5-20
Table 5-19 RF cable connections of the BTS3900E..........................................................................................5-22
Table 5-20 Specifications of the integrated antennas of the BTS3900E............................................................5-28
Table 5-21 Ports on the panels of the USLP2....................................................................................................5-30
Table 5-22 DIP switches on the USLP2.............................................................................................................5-30
Table 5-23 Specifications of the AC surge protection box................................................................................5-31
Table 5-24 Wiring terminals and wiring posts on the AC surge protection box................................................5-32
Table 6-1 Maintenance items for the BTS3900E.................................................................................................6-2
BTS3900E GSM
User Guide Tables
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
v

About This Document
Purpose
This document provides a reference for you to plan and deploy the BTS3900E. It describes the
ports and functions of the BTS3900E, categories of the cables, and specifications and installation
positions of the connectors. The methods for maintaining the BTS3900E are also provided.
Product Version
The following table lists the product version related to this document.
Product Name Product Version
BTS3900E GSM (hereinafter referred to as
BTS3900E)
V300R008
V600R009
Intended Audience
This document is intended for:
lBTS3900E installers
lSite maintainers
lField engineers
Organization
1 Changes in the BTS3900E GSM User Guide
This describes the changes in the BTS3900E GSM User Guide.
2 Typical Installation Scenarios of the BTS3900E (Indoor Coverage)
This describes the typical installation scenarios of the BTS3900E for indoor coverage.
3 Typical Installation Scenarios of the BTS3900E (Outdoor Coverage)
This describes the typical installation scenarios of the BTS3900E for outdoor coverage.
BTS3900E GSM
User Guide About This Document
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1

4 Monitoring Scheme of the BTS3900E
This describes the monitoring scheme of the BTS3900E.
5 BTS3900E Hardware
This describes the equipment, cables, and auxiliary devices of the BTS3900E.
6 BTS3900E Maintenance
This describes the items to be regularly maintained after the BTS3900E is put into use in order
to ensure its proper operation. The power-on and power-off operations and the method of
replacing the BTS3900E and optical modules are also provided.
Conventions
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates a hazard with a high level of risk, which if not
avoided,will result in death or serious injury.
Indicates a hazard with a medium or low level of risk, which
if not avoided, could result in minor or moderate injury.
Indicates a potentially hazardous situation, which if not
avoided,could result in equipment damage, data loss,
performance degradation, or unexpected results.
Indicates a tip that may help you solve a problem or save
time.
Provides additional information to emphasize or supplement
important points of the main text.
General Conventions
The general conventions that may be found in this document are defined as follows.
Convention Description
Times New Roman Normal paragraphs are in Times New Roman.
Boldface Names of files, directories, folders, and users are in
boldface. For example, log in as user root.
Italic Book titles are in italics.
Courier New Examples of information displayed on the screen are in
Courier New.
Organization
BTS3900E GSM
User Guide
2 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-01-15)

Command Conventions
The command conventions that may be found in this document are defined as follows.
Convention Description
Boldface The keywords of a command line are in boldface.
Italic Command arguments are in italics.
[ ] Items (keywords or arguments) in brackets [ ] are optional.
{ x | y | ... } Optional items are grouped in braces and separated by
vertical bars. One item is selected.
[ x | y | ... ] Optional items are grouped in brackets and separated by
vertical bars. One item is selected or no item is selected.
{ x | y | ... }*Optional items are grouped in braces and separated by
vertical bars. A minimum of one item or a maximum of all
items can be selected.
[ x | y | ... ]*Optional items are grouped in brackets and separated by
vertical bars. Several items or no item can be selected.
GUI Conventions
The GUI conventions that may be found in this document are defined as follows.
Convention Description
Boldface Buttons, menus, parameters, tabs, window, and dialog titles
are in boldface. For example, click OK.
>Multi-level menus are in boldface and separated by the ">"
signs. For example, choose File > Create > Folder.
Keyboard Operations
The keyboard operations that may be found in this document are defined as follows.
Format Description
Key Press the key. For example, press Enter and press Tab.
Key 1+Key 2 Press the keys concurrently. For example, pressing Ctrl+Alt
+A means the three keys should be pressed concurrently.
Key 1, Key 2 Press the keys in turn. For example, pressing Alt, A means
the two keys should be pressed in turn.
Mouse Operations
BTS3900E GSM
User Guide Organization
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

The mouse operations that may be found in this document are defined as follows.
Action Description
Click Select and release the primary mouse button without moving
the pointer.
Double-click Press the primary mouse button twice continuously and
quickly without moving the pointer.
Drag Press and hold the primary mouse button and move the
pointer to a certain position.
Organization
BTS3900E GSM
User Guide
4 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-01-15)

1 Changes in the BTS3900E GSM User Guide
This describes the changes in the BTS3900E GSM User Guide.
01 (2010-01-15)
This is the first commercial release.
BTS3900E GSM
User Guide 1 Changes in the BTS3900E GSM User Guide
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1-1

2 Typical Installation Scenarios of the
BTS3900E (Indoor Coverage)
About This Chapter
This describes the typical installation scenarios of the BTS3900E for indoor coverage.
In the typical installation scenarios, different cables are identified by different colors. Figure
2-1 shows the mapping between the RF cables and their colors.
Figure 2-1 Mapping between the cables and their colors
Power cable
Inter-BTS3900E cable
RF jumper of the BTS3900E
NOTE
lThe longest remote distance of the DC power cable for a single BTS3900E is 100 m. The longest
remote distance of the DC power cables for cascaded BTS3900Es is 50 m.
lA maximum of three DC BTS3900Es can be cascaded in chain topology.
lIn indoor application scenario, the BTS3900E supports distributed installation of combined cabinets.
The distance between the combined cabinets is shorter than or equal to 10 km.
The full names of common cabinet names whose abbreviations are used in this document are
listed as follows:
lBBC: Battery Cabinet
lAPM: Advance Power Module
lAPM30H: Advance Power Module(with Heat-exchanger Cooling)
2.1 Scenario 1: AC Power Input
This describes the installation scenarios of the BTS3900E in the case that AC power is available
on site and no transmission space is required.
2.2 Scenario 2: -48 V DC Power Input
BTS3900E GSM
User Guide
2 Typical Installation Scenarios of the BTS3900E (Indoor
Coverage)
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2-1

This describes the installation scenarios of the BTS3900E in the case that -48 V DC power is
available on site but no transmission space is provided.
2 Typical Installation Scenarios of the BTS3900E (Indoor
Coverage)
BTS3900E GSM
User Guide
2-2 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-01-15)

2.1 Scenario 1: AC Power Input
This describes the installation scenarios of the BTS3900E in the case that AC power is available
on site and no transmission space is required.
Configuration of Omni-Directional Site (One BTS3900E)
Figure 2-2 shows the installation of the one AC-powered BTS3900E in omni-directional
configuration.
Figure 2-2 Installation of one AC-powered BTS3900E in omni-directional configuration
BTS3900E
AC
AC INPUT
Antenna
This installation scenario has the following features:
lRequirements for the external power input system:
–110 V AC single-phase: 4 A to 6 A
–220 V AC single-phase: 4 A to 6 A
lThe BTS3900E can be mounted on the wall or H-shaped stand.
lConsidering the capacity expansion requirements, the space for mounting one BTS3900E
can be left on the wall. In addition, a maximum of two BTS3900Es can be mounted on the
H-shaped stand.
Configuration of Omni-Directional Site (Two BTS3900Es)
Figure 2-3 shows the installation of the two AC-powered BTS3900Es in omni-directional
configuration.
BTS3900E GSM
User Guide
2 Typical Installation Scenarios of the BTS3900E (Indoor
Coverage)
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2-3

Figure 2-3 Installation of two AC-powered BTS3900Es in omni-directional configuration
AC INPUT
BTS3900E
AC
BTS3900E
AC
Antenna
This installation scenario has the following features:
lRequirements for the external power input system:
–110 V AC single-phase: 4 A to 6 A
–220 V AC single-phase: 4 A to 6 A
lThe BTS3900E can be mounted on the wall or H-shaped stand.
lThe two AC-powered BTS3900Es are interconnected through the SFP ports.
2.2 Scenario 2: -48 V DC Power Input
This describes the installation scenarios of the BTS3900E in the case that -48 V DC power is
available on site but no transmission space is provided.
Configuration of Omni-Directional Site (One BTS3900E)
Figure 2-4 shows the installation of one DC-powered BTS3900E in omni-directional
configuration.
Figure 2-4 Installation of one DC-powered BTS3900E in omni-directional configuration
-48V DC
Antenna
BTS3900E
DC
2 Typical Installation Scenarios of the BTS3900E (Indoor
Coverage)
BTS3900E GSM
User Guide
2-4 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2010-01-15)

This installation scenario has the following features:
lThe BTS3900E can be mounted on the wall or H-shaped stand.
lThe capacity of the external power input system should range from 5 A to 8 A.
lConsidering the capacity expansion requirements in later phase, the space for mounting
one BTS3900E can be left on the wall. In addition, a maximum of two BTS3900Es can be
mounted on the H-shaped stand.
Configuration of Omni-Directional Site (Two BTS3900Es)
Figure 2-5 shows the installation of two DC-powered BTS3900Es in omni-directional
configuration.
Figure 2-5 Installation of two DC-powered BTS3900Es in omni-directional configuration
-48V DC
BTS3900E
DC
BTS3900E
DC
Antenna
This installation scenario has the following features:
lThe BTS3900E can be mounted on the wall or H-shaped stand.
lRequirements for the external power input system:
–If power supply for the BTS3900Es are independent from each other, the capacity of
the external power input system should range from 5 A to 8 A.
–If two BTS3900Es are cascaded, the capacity of the external power input system should
range from 10 A to 12 A.
lA maximum of two BTS3900Es can be mounted on the H-shaped stand, which facilitates
capacity expansion.
lThe two DC-powered BTS3900Es are interconnected through the SFP ports.
BTS3900E GSM
User Guide
2 Typical Installation Scenarios of the BTS3900E (Indoor
Coverage)
Issue 01 (2010-01-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2-5
