2Preparing Materials
Materials
Configured with
the Equipment
Fuse
, connect plate 1, connect plate 2, combined hexagon head bolts M12x90,
OT
ground terminal of the power cable to the indoor unit
, and single cord end terminal
of the power cable to the indoor unit
Engineering
Procurement
Automatic
drainpipe
•
Rigid pipe: BSPT 1/2-inch rigid pipe connector with external
threads, and rigid pipe (PP-R or C-PVC)
•
Hose: BSPT 1/2-inch pagoda connector with external threads,
hose clamp, and hose (inner diameter of 3/4 inch, made of
EPDM)
Humidifier
water inlet
pipe
•
Rigid pipe: G 1/2-
inch rigid pipe connector with external threads,
and rigid pipe (PP-R or C-PVC)
•
Hose: G 1/2-
inch pagoda connector with external threads, hose
clamp, and hose (inner diameter of 3/4 inch, made of EPDM)
(1) Electric control
box
(2) PSU
(3) Main control
board
(4) Differential
pressure switch
(5) Temperature and
humidity sensor
(6) Wet film
humidifier
(7) Water outlet
pipe
(8) Chilled water valve
(9) Humidifier
pump
(10) Automatic
drainpipe
(11) Condensate pump
(If condensate water
needs to be drained by
using a water pump,
you can customize a
condensate pump)
(12) Water inlet
pipe
Model NetCol5000-C065 NetCol5000-C080
Cooling Capacity
(kW) 65 80
Net Weight (kg)
(full configuration)
202 240
Dimension (mm)
(H x W x D) 2000 x 600 x 1200 2500 x 600 x 1200
Issue: 05
Date: 2019-06-24
NetCol5000-C(065, 080) In-row Chilled
Water Smart Cooling Product
Quick Guide

Model
Specifications
(As the smart cooling product uses dual power supplies, the
power cable specifications for the two routes should be the same.)
NetCol5000
-C
2
Engineering
Procurement
Chilled water
inlet and
outlet pipes
Seamless steel pipe with a G 1
–1/2 in. external threaded
connector or Aluminum plastic pipe with an inner diameter of 41
mm
Cables
Power cable (as shown in the following table), teamwork
networking and monitoring cables, and equipotential cable (≥ 16
mm²)
Others
Indoor unit base, thermal insulation foam, and thermal insulation
foam glue
3×6.0 mm2
Main power to the
indoor unit Power to the equipment room
1. Shock absorption bars (EPDM rubber, 5 mm
thick) need to be installed between the ground
and the base.
2. The base should be at least 300 mm in height.
3. You are advised to use angle steel, square steel
or channel steel. Width of 50 mm and thickness
of 3 mm to 5 mm is recommended.
4. When the width of angle steel is more than 50
mm, it is interfering with the cable routing holes.
Cut out the part on the angle steel to avoid
interfering. If the width is less than or equal to 50
mm, skip this step.
NOTE
(Optional) Preparing an Indoor Unit Base
2.1 (Optional) Making
Holes on the Floor
2.2
Unit: mm

3
3Installing the Equipment
1. Read the related user manual or instructions before installing the NetCol5000-C.
2. The unit in this document is a fully configured NetCol5000-C. If some components are not
configured, skip the corresponding steps.
3. You are recommended to use tools that are fully insulated when installing devices.
4. Only engineers from the manufacturer or engineers certified by the agent are allowed to install,
commission, and maintain smart cooling products. Otherwise, personal injuries and device
damage may be caused, which is beyond the smart cooling product warranty range.
There are two air filters for NetCol5000-C065
kW and three for NetCol5000-C080 kW. The
following figure uses the NetCol5000-C065
model as an example.
NOTE
1. The equipment has been injected with
0.3–0.5 MPa of nitrogen before delivery. If
no nitrogen is discharged, contact Huawei
technical support.
2. You can open or close the exhaust valve
using a flat-head screwdriver.
Slowly open the exhaust valve to release
nitrogen and close the valve afterwards.
Removing Air Filters
3.1 Discharging Nitrogen 3.2

4
Removing the Pallet
3.3 Leveling the Cabinet 3.4
Level
The connectors are secured to the equipment
with M6 screws and secured to the pallet with
M12 screws.
NOTE
Securing the Equipment
3.6
Installing Cabinets Side by Side
3.5
Front door
Rear door

Unit: mm
5
4Installing Pipes
1. A 1:100 tilt should be reserved for the main drainpipe.
2. Keep a clearance of at least 25 mm between pipes. Secure the pipes to supports every a certain distance.
3. Clean the water inlet engineering pipes to avoid impurities entering into the humidifier.
4. A reducing valve must be installed if the inlet water pressure exceeds 0.7 MPa.
5. Pipes should be wrapped with thermal insulation foam along the route.
6. Condensate water can be drained from the top or bottom. Determinethe appropriate pipe connection
based on site requirements.
Pipe Layout
4.1
Connecting the Drainpipe
4.2
Hose
Hose clamp
Reserved port
for the automatic
drainpipe
Adapter
Rigid pipe
Pagoda
connector
Hose clamp
Hose
Reserved port for
the water pump
Automatic drainpipe 1 Automatic drainpipe 2 Water pump drainpipe (optional)
Reserved port
for the
automatic
drainpipe
Scenario
Pipes Must Be
Connected
Bottom
drainage
Auto
-drainpipe
and
water
pump drainpipe
After installing the condensate pump drainpipe (optional) and automatic drainpipe, connect them to
the main pipe and bind them with a cable tie according to step 1 in the figure. Then wrap the pipes
with tape or use other materials to secure them, as shown by step 2 in the figure.
Automatic drainpipe Water pump drainpipe (Optional)
The automatic drainpipe can be connected in
two modes. The following figure illustrates
one mode.

Connecting the Chilled Water Inlet and Outlet Pipes
4.4
6
Connecting the Humidifier Water Inlet Pipe
4.3
Connection method
(1) Reserved connector
(4) Pagoda connector
(2) Rigid pipe adapter
(5) Hose clamp
(3) Rigid pipe
(6) Hose
Aluminum plastic pipe
(1)
Reserved device port
(2) Direct connection of
external teeth
(3) Sealing ring
(4) Nut
(5) Aluminum plastic pipe
with an inner diameter of
41 mm
Connecting the seamless steel pipe
(1) Reserved device
port
(2) Seamless steel pipe
(Optional) Leakage Test with Nitrogen
4.5
•If the pressure has fallen, apply soapy water on the pipes, especiallypipejoints, to check for leakages.
Rectify the leakages if any.
•If the pressure is stable, wrap all pipes and connectors with thermal insulation foam.
•Install a reducing valve on the outlet of the nitrogen cylinder. Its outlet pressure must not exceed 0.8 MPa.
•In addition to the leakage test with nitrogen, there is the leakage test with water. You can choose one test
based on site requirements.

7
Injecting Water to Expel Nitrogen
4.6
1. Open the general water supply valve.
2. Press the button on the side of the actuator and
manually rotate the valve handle to the maximum
in the specified direction. Check that the chilled
water valve is in the open state (100%).
3. Slowly open the exhaust valve to let out gas.
4. Adjust the gas releasing speed until no gas flows
out of the valve. Then close the exhaust valve.
5. Manually close the chilled water valve.
1. Rotate the chilled water valve to the
maximum (100%).
2. Check that the needle and exhaust valves
on the pipeline are closed.
3. Connect a reducing valve and a nitrogen
cylinder at the needle valve position shown
in the figure, charge 0.8 MPa of nitrogen
(when the pressure is stable), and leave
them for 24 hours.
4. Check for pressure change after 24 hours.
(Optional) Leakage Test with Water
4.7
Manually open the chilled water valve. Inject water to 0.8 MPa, and preserve the pressure for 24
hours. Then connect a pressure gauge to a needle valve on the pipeline to measure the pressure. If
the reading remains unchanged, the pipe is not leaking. You can perform the following operations.
Clean the main pipe beforehand to avoid
blockage of the heat exchanger due to foreign
construction matter. Close the isolation valve on
the water inlet and outlet pipes before the
cleaning.
If the leakage test has been done with nitrogen, skip the test with water.
5Installing Cables
Connecting the Equipotential Ground Cable and Power Cable
5.1
1. When routing the cables, wrap the section of all signal cables inside the smart cooling product
with the corrugated pipes and route them out of the corresponding cable holes so that the
strong- and weak-current cables are separated.
2. Route the power cable along the rear door post, and use cable ties to secure the cable to the
post every 150–200 mm.

8
(Optional) Installing a
Differential Pressure Sensor
5.2
1. Connect the equipotential cable. 2. Connect the power cable.
Connect a pressure inlet tube to the +mark and route it to the aisle through the hole on the
top of the cabinet. Ensure that the pressure inlet faces downwards. Connect another pressure
inlet tube to the –mark and route it to the cabinet top through the hole atop.
Hot aisle
Cold aisle
Connect the cable
terminal of the micro
differential
pressure
sensor to
the DPT
terminal.
Connect a pressure inlet tube to the +mark and route it to the cabinet top through the hole
atop. Connect another pressure inlet tube to the –mark and route it to the aisle through the
hole on the top of the cabinet. Ensure that the pressure inlet faces downwards.
Connecting the Water
Sensor
5.3

1. Connect the temperature and humidity (T/H) sensor cable (W12).
2. Set the DIP switches on the T/H sensors.
9
(Optional) Installing T/H Sensors Outside Cabinets
5.4
(Optional) Connecting the Teamwork Network Cable
5.5
Connecting an FE teamwork network cable
The smart cooling product supports both FE teamwork networking and CAN teamwork
networking (hand-in-hand).
•All smart cooling products in a
teamwork group must be of the
same model.
•Do not directly connect the first and
the last smart cooling products to
form a ring network.
•A maximum of 32 smart cooling
products can be networked in one
group. The teamwork cable between
two adjacent smart cooling products
must not exceed 10 m.
•If CAN networking is required onsite,
set Enable teamwork CAN resistor
for the first and last smart cooling
products to Yes on the screen.
The T/H sensors inside the cabinet are
secured at the return air side and their IN
ports are connected to the main control
board. When connecting the T/H sensors
outside the cabinet, connect the OUT port
of one T/H sensor inside the cabinet to the
IN port of the next T/H sensor outside the
cabinet. Connect all T/H sensors in series
in this way.
T/H sensors in the aisle should be installed
at the door frame inside the server cabinet
and 1.5 m above the ground (33 U). After
they are secured, set the sensor positions
based on their location and the table.
Name Address DIP Switch ID
1 2 3 4 5 6
Return air 2 temp/humid 1 ON OFF OFF OFF OFF OFF
Cold aisle 1 temp/humid 11 ON ON OFF ON OFF OFF
Cold aisle 2 temp/humid 12 OFF OFF ON ON OFF OFF
Cold aisle 3 temp/humid 13 ON OFF ON ON OFF OFF
Cold aisle 4 temp/humid 14 OFF ON ON ON OFF OFF
Cold aisle 5 temp/humid 15 ON ON ON ON OFF OFF
Hot aisle 1 temp/humid 21 ON OFF ON OFF ON OFF
Hot aisle 2 temp/humid 22 OFF ON ON OFF ON OFF
Hot aisle 3 temp/humid 23 ON ON ON OFF ON OFF
Hot aisle 4 temp/humid 24 OFF OFF OFF ON ON OFF
Hot aisle 5 temp/humid 25 ON OFF OFF ON ON OFF
NOTE

Connecting the FE monitoring cable (SNMP/Modbus-TCP protocol)
10
(Optional) Connecting the Monitoring Network Cable
5.6
Connecting the RS485 monitoring network cable (Modbus-RTU protocol)
The smart cooling product supports both RS485 monitoring and FE monitoring.
The FE monitoring and FE teamwork use the same network cable. Connect the FE monitoring
cable in the same process of connecting the FE teamwork network cable.
CAN teamwork network cable
•If there is no teamwork networking, connect the COM-IN port on each smart cooling
product to the customer's monitoring system.
•If CAN teamwork networking has been implemented, connect the RS485 monitoring
cables, as shown in the following figure.

6Verifying the Installation
11
No.
Check Item
Check Result
1
All water pipes are properly and securely installed, and free from leakage,
blockage, and sharp turns.
□
Passed □
Failed
2
The liquid level detector is level. The water pan is free from foreign matter
such as cable remains and thermal insulation foam. Cables are securely
bound and not in the water pan.
□
Passed □
Failed
3
The distance between two chilled water pipes outside the cabinet is
sufficient (recommended distance: longer than 25 mm), the hose is tightly
wrapped with insulation foam, and joints are secured using glue.
□
Passed □
Failed
4
The pipeline system has passed the pressure preservation and air
tightness tests.
□
Passed □
Failed
5
The needle valve plugs are secured (torque of
0.45±0.05 N•m), and
screw caps are tightened.
□
Passed □
Failed
6
The cabinet is reliably grounded.
□
Passed □
Failed
7
The power cables and signal cables are correctly connected and properly
separated. Strong
-current and weak-current cables are separately bound.
□
Passed □
Failed
8
The chilled water valve and its actuator are securely installed.
The chilled
water connector joints have been wrapped with thermal insulation foam,
and no metal or hose is exposed. Cables are securely connected to the
chilled water valve actuator. The actuator manual button is reset (ejected
state).
□
Passed □
Failed
7System Power-On
1. Turn on the smart cooling product switch in the power distribution cabinet and the AC1 and AC2
switches on the smart cooling product.
2. After the device is powered on for the first time, the LCD displays the Quick Settings screen. Log
in as the admin user, and set parameters as instructed, such as language, date format, date, time,
and time zone. If the device is not powered on for the first time, the home screen is displayed.
Temperature and Humidity Settings
7.4
Set Temperature and humidity control type, Control point temperature setpoint, and Control
point humidity setpoint as required on site. Path: Settings > System Settings > Common
Settings or Settings > System Settings > T/H Sensor.
•Users are classified into admin and operator. The preset password is 000001 for both types of users.
•After powering on, the smart cooling product is in shutdown mode.
NOTE
Power-On
7.1
If a T/H sensor outside the cabinet is installed, enable it. Path: Settings > System Settings >
Common Settings or Settings > System Settings > T/H Sensor
(Optional) Enabling the T/H Sensor Outside the Cabinet
7.3
(Optional) Setting the T/H Control Type
7.2
Application Scenario
Recommended T/H
Control Type
Remarks
Cold aisle containment Cold aisle control If cold aisle T/H sensors are not configured,
you can also choose the supply air control.
Hot aisle containment Cold aisle control
Non-aisle containment Return air control If cold aisle T/H sensors are configured, you
can also choose the cold aisle control.
Path: Settings > System Settings > Common Settings or Settings > System Settings > T/H Sensor.

12
1. Teamwork group no.: One teamwork networking can contain four groups at most. They must have
the same teamwork control number and can be assigned 1–4 respectively.
2. Smart cooling product address: In a teamwork control group, each smart cooling product address
(1-32) must be unique, and the smart cooling product with minimum address is the master smart
cooling product.
3. Networking mode: The networking mode set on the screen must be consistent with the actual
networking mode. CAN network indicates teamwork control over a CAN bus, MAC_CAN network
teamwork control over an FE port.
4. Enable teamwork CAN resistor: In CAN networking, set this parameter for the first and last smart
cooling products to Yes.
5. Number of smart cooling products in this group: Indicates the number of precision smart cooling
products in a group. The value is an integer ranging from 1 to 32.
6. Number of running smart cooling products in this group: Specifies the number of running
NetCol5000-Cs in a group. The value ranges from 1 to the number of NetCol5000-Cs in the group.
7. Rotation function: Enable the active and standby smart cooling products to work alternately. This
function is recommended when the heat load is even.
8. When Requirement control is set to Anti-competitive running, the master smart cooling product
synchronizes operating data (parameters such as the T/H control type, temp set point, humid set
point for the master smart cooling product) to the slave smart cooling product, and all the precision
smart cooling products in the group refer to the mode delivered by the master smart cooling
product. When Requirement control is set to Disable, all the smart cooling products operate
based on their own requirements. When the requirement control is Indoor fan unified control or
Central load distribution, all smart cooling product fans in the group rotate at the same speed.
(Optional) Teamwork Settings
7.6
The table uses 8 smart cooling products in CAN teamwork as an example.
No.
1
2
3
...
7
8
Item
Teamwork group no.
1
1
1
...
1
1
Air conditioner
address
1
2
3
...
7
8
Enable teamwork CAN
resistor
Yes
No
No
...
No
Yes
Teamwork function
Enable
Enable
Enable
...
Enable
Enable
Networking mode
CAN
CAN
CAN
CAN
CAN
CAN
Number of air
conditioners in this
group
8
/
/
...
/
/
Number of running air
conditioners in this
group
6
(2
standby)
/
/
...
/
/
Rotation function
Enable
/
/
...
/
/
Requirement control
Enable
/
/
...
/
/
(Optional) Setting the Indoor Fan Control Type
7.5
If a micro differential pressure sensor is installed and the pressure difference control is required, set
Air-side difference pressure sensor type to 0–50 Pa, and set the Indoor fan control type to
Pressure diff ctrl. It is recommended that the Indoor fan pressure difference setpoint retain the
default value. If there are hot spots onsite, you can increase the value. Path: Settings > System
Settings > Indoor fan

1. First startup flowchart
13
8Startup and Wizard Startup
•Download the Service Expert app from Huawei app store and runs on Android. Apply for
permission after downloading the app.
•Except that the indoor fan item is mandatory, you can clear other commissioning items that are
not required.
•If this is not the first startup, choose Maint > Wizard Startup to enter wizard startup.
•If no humidifier or water pump is configured, their commissioning items are not displayed.
Open the Service Expert app.
Tap Startup > Offline Activation on
app.
After tapping Yes, the barcode and
the verification code are shown on the
screen.
Tap Start on the home screen.
Enter Bar code and Verification
code, and tap Generate PWD.
Enter the generated startup password
on the screen of smart cooling
product.
Tap No on Wizard Startup screen to exit
wizard startup.
Tap Enter. The screen turns to
Wizard Startup.
Tap Yes on Wizard Startup screen to enter
wizard startup.
Start

14
9Checking the Commissioning
Check Item
Result
The controller exits diagnostic mode.
□
Passed □Failed
The temperature and humidity are correctly set.
□
Passed □Failed
Check that the chilled water valve is closed.
□
Passed □Failed
10 Power-Off
1. Tap Shutdown on the LCD home screen.
2. Turn off all switches on the smart cooling product.
3. If the smart cooling product will not be used over a long time, drain the water in the heat
exchanger or take antifreeze measures to avoid frost cracks.
11 Routine Maintenance
Component
Item
Troubleshooting
Frequency
Air filter
Check that the air filter is clean and
not blocked.
Clean the air filter with water.
Monthly
Check that the air filter is not
damaged or distorted.
Replace the air filter.
Monthly
Appendix: Precautions Against Adding Glycol
To prevent glycol solution from corroding pipes and the heat exchanging coil, corrosion inhibitor
should be mixed into the glycol solution. For details about the mixing schemes, consult glycol experts.
2. Wizard startup
flowchart
For routine maintenance, see NetCol5000-C(065, 080) In-row Chilled Water Smart Cooling
Product User Manual.
Fail
Chilled water valve commissioning
Humidifier commissioning
(Optional) Condensate pump commissioning
Indoor fan commissioning
Commissioning
interrupted
(Handle the fault
by referring to the
tips displayed on
the home screen.
Perform wizard
startup after the
handling.)
Start
Success
Success
Success
Success
End
Precautions
Yes
No
No
Fail
Fail
Identify notes and check items
Success Fail
Huawei Technologies Co., Ltd.
Huawei Industrial Base, Bantian, Longgang
Shenzhen 518129 People's Republic of China
www.huawei.com
