Huawei FusionDC1000A User manual

FusionDC1000A Prefabricated All-in-One Data
Center
Quick Guide (2020, Nigeria, River)
Issue 01
Date 2020-11-30
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2020. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees
or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every eort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: https://e.huawei.com
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. i

About This Document
Purpose
This document describes the initial conguration parameters of the data center, as
well as the installation precautions, processes, parameters, and drawings. It helps
customers quickly get familiar with product congurations, and provides
installation guidance and technical support for onsite installation personnel and
technical support engineers.
Intended Audience
This document is intended for:
● Maintenance engineers
● Technical support engineers
● System engineers
● Commissioning engineers
● Data conguration engineers
Symbol Conventions
The symbols that may be found in this document are dened as follows.
Symbol Description
Indicates a hazard with a high level of risk which,
if not avoided, will result in death or serious
injury.
Indicates a hazard with a medium level of risk
which, if not avoided, could result in death or
serious injury.
Indicates a hazard with a low level of risk which,
if not avoided, could result in minor or moderate
injury.
FusionDC1000A Prefabricated All-in-One Data
Center
Quick Guide (2020, Nigeria, River) About This Document
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. ii

Symbol Description
Indicates a potentially hazardous situation which,
if not avoided, could result in equipment damage,
data loss, performance deterioration, or
unanticipated results.
NOTICE is used to address practices not related to
personal injury.
Supplements the important information in the
main text.
NOTE is used to address information not related
to personal injury, equipment damage, and
environment deterioration.
Change History
Changes between document issues are cumulative. The latest document issue
contains all the changes made in earlier issues.
Issue 01 (2020-11-30)
This issue is the rst ocial release.
FusionDC1000A Prefabricated All-in-One Data
Center
Quick Guide (2020, Nigeria, River) About This Document
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. iii

Contents
About This Document................................................................................................................ ii
1 Quick Guide Usage.................................................................................................................. 1
2 Installation Drawings............................................................................................................. 3
3 Removing Transport Protection Materials........................................................................ 4
4 Initial Conguration Parameters.........................................................................................6
A Common Torque Selection Table.........................................................................................7
FusionDC1000A Prefabricated All-in-One Data
Center
Quick Guide (2020, Nigeria, River) Contents
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. iv

1 Quick Guide Usage
This chapter describes the notes for using the quick guide.
● Before the installation, check whether the materials are intact according to
the packing list. If there is any problem, contact Huawei technical support.
● This document provides only the initial conguration parameters required for
data center commissioning and O&M as well as the drawings and parameters
required for onsite installation.
● Before using this document, read through and keep in mind the safety
precautions and the cautions and notes for operations.
● Precautions provided in this document are only supplementary to the local
laws and regulations governing the data center.
● The system conguration parameters are essential to reliable running of the
system. Improper modications of parameters may easily cause abnormal
running status, or even damage to the system. You are not allowed to modify
conguration parameters without permission when using the data center. If a
modication is necessary, contact Huawei technical support. Huawei shall not
be responsible for any loss caused by unauthorized conguration
modication.
● You can modify initial congurations under the guidance of Huawei
engineers. Huawei assumes no liability for any loss caused by unauthorized
changes to the initial congurations.
● Some parameters mentioned in this document should be provided and
congured by onsite technical support engineers based on the actual
application of the data center.
● If parameters need to be modied during the running of systems, the
operator should be a professional in this eld and familiar with each system
and its working principles.
● Before performing an operation, ensure that the prerequisites are met.
Otherwise, the expected result may not be achieved. More seriously,
equipment damage and personal injury may occur.
● Put on necessary protective equipment such as the safety helmet and gloves
before entering the site.
● A data center can be powered on for commissioning only after it has been
installed and passed the installation check.
FusionDC1000A Prefabricated All-in-One Data
Center
Quick Guide (2020, Nigeria, River) 1 Quick Guide Usage
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. 1

● The gures provided in this document illustrate only installation and
connection methods. The actual product appearance prevails.
● Unless otherwise specied, the unit for the dimensions in the gures provided
in this document is mm by default.
● Before using this document, understand the actual product congurations,
solution conguration for the data center in use, type of power grid used by
the customer, and internal conguration of each pre-fab. module.
● When performing operations (such as installing an awning or outdoor unit)
over the top of a pre-fab. module, take measures to protect the top of the
pre-fab. module against damage. Do not perform operations such as arc
welding, drilling, and cutting on the top of a pre-fab. module.
Table 1-1 Reference Documentation
Item Document Name
FusionModu
le
FusionDC1000A Prefabricated All-in-One Data Center
V100R021C00 Installation Guide (CT)
FusionDC1000A Prefabricated All-in-One Data Center
V100R021C00 Commissioning Guide (CT)
FusionDC1000A Prefabricated All-in-One Data Center
V100R021C00 Maintenance Guide (CT)
UPS UPS5000-E-(25 kVA-75 kVA)-BF Quick Guide
ECC ECC800 Data Center Controller V100R003C00 User Manual (for
ECC800-Pro)
FusionDC1000A Prefabricated All-in-One Data
Center
Quick Guide (2020, Nigeria, River) 1 Quick Guide Usage
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. 2

2 Installation Drawings
FusionDC1000A Prefabricated All-in-One Data
Center
Quick Guide (2020, Nigeria, River) 2 Installation Drawings
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. 3

Installation Sequence Subcategory Item Diagram ID Diagram Name
Installing Pre-fab. Module Bases
Removing the Pre-fab. Module Cover
Hoisting and Securing Pre-fab. Modules
Grounding Pre-fab. Modules Grounding Pre-fab. Modules NO.S003
Pre-fab. Module Grounding Position
Diagram
Installing the Drainage Sheet Metal
Component for the Intelligent Heat
Exchanger
Installing the Drainage Sheet Metal Component for the
Intelligent Heat Exchanger
NO.S007
(Optional) Installation Position Of The
Drainage Sheet Metal Component For The
Intelligent Heat Exchanger
Installing Awnings Installing Awnings NO.S008
(Optional) Awning Installation Position
Diagram
Installing Air Conditioner
Drainpipes
Installing Air Conditioner Drainpipes Installing a dehumidifier drainpipe NO.S004 (Optional) Humidifier Pipe Layout Diagram
Installing Power Modules No.P017 Power module installation position diagram
Installing Lithium Batteries No.P018
Lithium battery installation position
diagram
Installing a ground cable No.P011 Grounding System Wiring Diagram
Installing a Light No.P012 Light Power Cable Wiring Diagram
Installing the socket No.P013
Socket And Light Switch Power Cable
Wiring Diagram
No.M004
Monitoring Device Installation Position
Diagram
No.S021
(Optional) RF_Z Antenna Installation
Position Diagram
Installing Fire Extinguishing Devices Installing CE-Certified Fire Extinguishing Devices No.F004
Fire Extinguishing Device Installation
Position Diagram (CE)
Connecting External Cables Installing External Input Power Cables Installing External Input Power Cables No.P009
Wiring Diagram From The Mains to The
Power PDF
Checklist of Devices Installed Onsite
Installing a Pre-fab. Module
Installing Pre-fab. Modules (Base Solution)
NO.S002
Installing Monitoring Devices
Installing Devices Inside the
Pre-fab. Module
Installing Power Supply and Distribution
Devices
Installing Monitoring Devices
Site Space And Pre-fab. Module Installation
Position Diagram (Single-capacity Base
Scenario)
Installing External
Accessories for the Pre-fab.
Module

Note:
1. The concrete platform must support a maximum weight of 15000 kg. The recommended seismic acceleration is 3 g.
The concrete platform strength is calculated based on the contact area (see the contact area of a single base 1720
cm2/ on the ground). For details, consider the engineering margin.
2. Each base has eight mounting holes. Only four holes need to be installed. The four holes outside the base are
preferred. If the external holes meet the reinforcement of the foundation, use the internal holes.
3. Ensure that the direction of the single base is consistent with that in the drawing.
200
Ground
Single-capacity base
370
340
260
290 430
400
Single-capacity base
8-
∅
24
Concrete platform
1000
2900
Name Drawing No. Qty Unit
Single-capacity
base DKBA40703508 4 PCS
T-shaped bolt DKBA80473086 4 PCS
Expansion bolt DKBA04802828_M16×150_S 16 PCS
>=6,438
>=10,058
加湿补排水口
54.3
底部进线口
63
281
875
600
213
1,000
1,000
1,351
550
1,768
105
2,690
6,254
7,354
混凝土支撑平台
2,900
No.S002 Site Space and Pre-fab. Module Installation Position Diagram
(Single-capacity Base Scenario)
Concrete platform

A
A
Container ground point
500
Grounding point
Note:
1. Install two ground points on the front wall and the rear wall of the container. The ground points are shown
in the preceding figure. Before grounding, remove the aluminum foil from the ground points. Use M12x30
stainless steel hexagon-head bolts to tighten the ground bolts to 60 N·m.
80
No.S003 Site Space and Pre-fab. Module Installation Position Diagram
(Single-capacity Base Scenario)
Name No. Qty Unit
Screw GB5783-2000_M12×30_S_ZNAL 2 PCS

Note:
The number of air conditioner drain kits is the same as the number of air conditioners.
The torque is 1.2 N·m.
1. Remove the transport protective cover from the air conditioner.
Transport protective cover
2. Install the drainage sheet metal.
No.S007 (Optional) Installation position of the drainage sheet metal
component for the intelligent heat exchanger
Name Drawing No. Qty Unit
Screw GB819-85_M4×14_S 6 PCS
Drainage
sheet metal GB819-85_M4×14_S 6 PCS

Note:
1. The rain and snow cover is secured to the pre-fab. module using three
GB9074_17-88_M10X40_S_ZNAL screws to a torque of 40 N·m. The preceding figure shows the
positions for securing the cover .
GB9074_17-88_M10X40_S_ZNAL
GB9074_17-88_M10X40_S_ZNAL
1. Remove the four GB9074_17-88_M10X40_S_ZNAL screws if
there is are eaves for the delivered pre-fab. module. Remove the
eaves and install the cover after cleaning eaves.
Rubber strip
GB9074_17-88_M10X40_S_ZNAL
2. Secure cover component 2 to the pre-fab. module using three
GB9074_17-88_M10X40_S_ZNAL screws, and then assemble cover components 1
and 2 using two GB9074_17-88_M10X40_S_ZNAL screws to a torque of 40 N·m.
Rain and snow cover component 1
No.S008 (Optional) Rain And Snow Cover Installation Position Diagram
Name Drawing No. Qty Unit
Screw GB5783-2000_M12×30_S_ZNAL 5PCS
Rain and snow cover DKBA61545321 1PCS
Rain and snow
cover component 1 DKBA61568040 1 PCS
Rain and snow
cover component 2 DKBA61545321 1 PCS
Apply sealant on the top of the rain and snow cover after it is installed.
Rain and snow cover component 2

Humidifier refill and drain port
108.6
1,200
426
No.S004 (Optional) Humidifier pipe layout diagram
Note: (Optional) Secure the humidifier drainpipe using a clamp.

No.P017 Power module installation position diagram
1. Find the UPS power module （02311NXM*2pcs） from
the packaged materials.
2. The power module is installed in the position shown
in the following figure.
Note： The position marked 2 is the power module
installation position.

No.P018 Lithium battery installation position diagram
1. Find the UPS battery module （02311PCW*8pcs）
from the packaged materials.
2. Removing the filler panel from the UPS.
3. Remove the protective cover from the rear of the
battery
3. Push the battery module whose positioning lock is in
unlocked state into the cabinet, and turn the
positioning lock to the locked state.
4. Install battery modules one by one from the bottom
layer to the top layer in the preceding way.
Installation positions of lithium batteries

Air outlet window
EL
Rack1 Rack2
Rack4 Rack3
Air Conditioner-1
( EC50 )
Air Conditioner-2
( EC50 )
Air Conditioner-3
( EC50 )
Air Conditioner-4
( EC50 )
Air Conditioner-5
( EC50 )
Air Conditioner-6
( EC50 )
Fan-1
Fan-2
Humidifier-1(Up Option)
Main PDF
UPS5000E-B
(25kVA*2)
Battery
(12V/9Ah*2 组)
集装箱内部接地点
No.P011 Grounding System Wiring Diagram
Note: This is the cable connection diagram. For details about the cable routing, routing, and binding, see the structure Process document.

Air outlet window
EL
Rack1 Rack2
Rack4 Rack3
Air Conditioner-1
( EC50 )
Air Conditioner-2
( EC50 )
Air Conditioner-3
( EC50 )
Air Conditioner-4
( EC50 )
Air Conditioner-5
( EC50 )
Air Conditioner-6
( EC50 )
Fan-1
Fan-2
Humidifier-1(Up Option)
Main PDF
Lighting-2 Lighting-1Lighting-5 Lighting-4 Lighting-3
Lighting-10
Lighting-7
Lighting-6
UPS5000E-B
(25kVA*2)
Battery
(12V/9Ah*2 组)
Lighting-9 Lighting-8
Socket-1
WY-10A
Socket-2
WY-10A
Light-1
Cable Relation Table Terminal Relation Table
Cable No. INPUT OUTPUT Breaker Power System Huawei Part Description Terminal Spec From Part 1 Terminal Spec From Part 2
Container From Device Container To Device
1
/
Lighting Switch
/
Lighting-1~10
16A/1P
L
25030386
Electronic power cable -300V/500V-60227
IEC 53(RVV)-3x2.5mm^2- black (3 cores:
Brown, blue, yellow/green) -27A-outdoor
cable -CCC,CE
14170215
Tube 2.5mm^2
14170215
Tube 2.5mm^2
/ / / N14170215
Tube 2.5mm^2
14170215
Tube 2.5mm^2
/ / / PE
14170008
OT2.5-M6
14170008
OT2.5-M6
No.P012 Lighting Power Cable Wiring Diagram
Note: This is the cable connection diagram. For details about the cable routing, routing, and binding, see the structure Process document.

Air outlet window
EL
Rack1 Rack2
Rack4 Rack3
Air Conditioner-1
( EC50 )
Air Conditioner-2
( EC50 )
Air Conditioner-3
( EC50 )
Air Conditioner-4
( EC50 )
Air Conditioner-5
( EC50 )
Air Conditioner-6
( EC50 )
Fan-1
Fan-2
Humidifier-1(Up Option)
Main PDF
Lighting-2 Lighting-1Lighting-5 Lighting-4 Lighting-3
Lighting-10
Lighting-7
Lighting-6
UPS5000E-B
(25kVA*2)
Battery
(12V/9Ah*2 组)
Lighting-9 Lighting-8
Socket-1
WY-10A
Socket-2
WY-10A
Light-1
Cable Relation Table Terminal Relation Table
Cable No. INPUT OUTPUT Breaker Power System Huawei Part Description Terminal Spec From Part 1 Terminal Spec From Part 2
Container From Device Container To Device
1
/
Main PDF QF16
/
Lighting Switch
16A/1P
L
25030386
Electronic power cable -300V/500V-60227
IEC 53(RVV)-3x2.5mm^2- black (3 cores:
Brown, blue, yellow/green) -27A-outdoor
cable -CCC,CE
14170215
Tube 2.5mm^2
14170215
Tube 2.5mm^2
2Main PDF QF18 Socket-1~2 N14170008
OT2.5-M6
14170215
Tube 2.5mm^2
/ / / PE
14170008
OT2.5-M6
14170215
Tube 2.5mm^2
No.P013 Socket And Light Switch Power Cable Wiring Diagram
Note: This is the cable connection diagram. For details about the cable routing, routing, and binding, see the structure Process document.

Air outlet window
Air inlet window
Magnetic Lock-1
EL
Emergency Door Release-1
Exit Button-1 Reader-1
IP Camera-1
Main PDF
T/H
T&H-1
Rack1 Rack2
Rack4 Rack3
ECC800(1U)
UPS5000E-B
(25kVA*2)
Battery
(12V/9Ah*2)
DOOR
EXIT
Air Conditioner-1
(EC50 )
Air Conditioner-2
(EC50 )
Air Conditioner-3
(EC50 )
Air Conditioner-4
(EC50 )
Air Conditioner-5
(EC50 )
Air Conditioner-6
(EC50 )
ECCE
ECCE-1
Collector_ECC800-1
WATER
Water Sensor-1
Fan-1
Fan-2
Humidifier-1(Up Option)
No.M004 Monitoring Device Installation Position Diagram
Connect the ECC800 antenna and bind it to
the mounting bar of the cabinet.
Installing the ECC800 antenna on the top of Rack 1
Access Actuator-1
AI/DI_2 WG_1 WG_2AI/DI_1
LOCK GND GATE GND
COM1 COM2POE
1 2 3 4
ADDRESS
PGND -48V RTN
Smart ETH Gateway-1/2/3
UT-H6902
POE
PGND -48V RTN
COM1 COM2
POE_2POE_3POE_4 POE_148V_OUT148V_OUT2
PWR_IN
FE_1FE_2
PWR_OUT
UT-H606 UT-H6902
POE
PGND -48V RTN
COM1 COM2
UT-H6902
POE
PGND -48V RTN
COM1 COM2
UT-H6902
POE
PGND -48V RTN
COM1 COM2
ETH Converter-1/2/3/4/5/6/7/8
POE_2POE_3POE_4 POE_148V_OUT148V_OUT2
PWR_IN
FE_1FE_2
PWR_OUT
UT-H606
POE_2POE_3POE_4 POE_148V_OUT148V_OUT2
PWR_IN
FE_1FE_2
PWR_OUT
UT-H606 UT-H6902
POE
PGND -48V RTN
COM1 COM2
UT-H6902
POE
PGND -48V RTN
COM1 COM2
UT-H6902
POE
PGND -48V RTN
COM1 COM2
UT-H6902
POE
PGND -48V RTN
COM1 COM2
