Huawei Telecom Power TP48200A-DT19C1 User manual

TP48200A-DT19C1 & DT19C2 & HT19C1 &
HT19C2
V100R005
Installation Guide
Issue
03
Date
2014-02-23
HUAWEI TECHNOLOGIES CO., LTD.

Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2014. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://enterprise.huawei.com

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
About This Document
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Purpose
This document describes how to install and commission the power system.
The cabinet figures in this document are for reference only.
Intended Audience
This document is intended for:
Installation and commissioning engineers
Technical support engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.
Calls attention to important information, best practices and tips.
NOTE is used to address information not related to personal
injury, equipment damage, and environment deterioration.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
About This Document
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 03 (2014-02-23)
Optimized the content of the document.
Issue 02 (2013-11-06)
Optimized the content of the document, including standardizing the terminology and
improving the accuracy of the description.
Issue 01 (2013-08-06)
This issue is the first official release.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
Contents
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 Safety ...............................................................................................................................................1
1.1 Health and Safety..........................................................................................................................................................1
1.1.1 Overview ...................................................................................................................................................................1
1.1.2 Electrical Safety.........................................................................................................................................................3
1.1.3 Inflammable Environment.........................................................................................................................................4
1.1.4 Battery .......................................................................................................................................................................4
1.1.5 Working at Heights....................................................................................................................................................6
1.1.6 Mechanical Safety .....................................................................................................................................................8
1.1.7 Bundling Signal Cables .............................................................................................................................................9
1.2 Equipment Safety..........................................................................................................................................................9
1.2.1 Electricity Safety .......................................................................................................................................................9
1.2.2 Electrostatic Discharge ............................................................................................................................................10
1.2.3 Laying Out Cables...................................................................................................................................................10
1.2.4 Rectifier...................................................................................................................................................................10
2 Installation Preparations ...........................................................................................................11
2.1 Required Tools............................................................................................................................................................ 11
2.2 Technical Specifications .............................................................................................................................................12
2.3 Installation Dimensions ..............................................................................................................................................13
2.4 Requirements for Cable Routing ................................................................................................................................13
3 Components .................................................................................................................................16
3.1 Interior........................................................................................................................................................................16
3.2 Rectifier......................................................................................................................................................................22
3.3 SMU02B.....................................................................................................................................................................23
3.4 UIM02C......................................................................................................................................................................27
3.5 Sensor .........................................................................................................................................................................30
3.5.1 (Optional) Smoke Sensor.........................................................................................................................................33
3.5.2 (Optional) Temperature and Humidity Sensor.........................................................................................................34
3.5.3 (Optional) Water Sensor ..........................................................................................................................................35
3.5.4 Battery Temperature Sensor.....................................................................................................................................35
3.5.5 Temperature Sensor in the Equipment Compartment ..............................................................................................35
3.6 (Optional) Intelligent Electric Meter ..........................................................................................................................35

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
Contents
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
v
3.7 (Optional) Bluetooth Door Lock.................................................................................................................................37
3.7.1 (Optional) Electric Door Lock.................................................................................................................................37
3.7.2 (Optional) Bluetooth Controller...............................................................................................................................38
3.8 (Optional) Battery.......................................................................................................................................................39
4 Installing Cabinets......................................................................................................................40
4.1 Unpacking and Acceptance.........................................................................................................................................40
4.2 Removing a Cabinet from a Pallet..............................................................................................................................40
4.3 Marking Hole Positions..............................................................................................................................................41
4.4 Drilling Holes and Installing Expansion Sleeves........................................................................................................42
4.5 Hoisting and Installing the Cabinet.............................................................................................................................43
4.6 Securing a Cabinet......................................................................................................................................................46
4.7 Open the Cabinet Door...............................................................................................................................................46
5 Installing a Ground Cable.........................................................................................................49
6 Installing Components...............................................................................................................51
6.1 Installing a Rectifier ...................................................................................................................................................51
6.2 (Optional) Installing a Smoke Sensor.........................................................................................................................52
6.3 (Optional) Installing a Water Sensor...........................................................................................................................54
6.4 (Optional) Installing anAmbient Temperature and Humidity Sensor.........................................................................55
7 Installing Cables .........................................................................................................................58
7.1 (Optional) Installing Dry Contact Signal Cables........................................................................................................58
7.2 Installing the Communications Cables .......................................................................................................................59
7.2.1 WebUI Management................................................................................................................................................59
7.2.2 NetEco Management ...............................................................................................................................................59
7.2.3 Third-Party NMS Management (over SNMP).........................................................................................................60
7.2.4 Connecting to Huawei BBU (over Dry Contacts, M2000 Management) ................................................................61
7.3 Installing DC Output Power Cables............................................................................................................................63
7.4 InstallingAC Input Power Cables ..............................................................................................................................64
7.4.1 Installing AC Input Power Cables for the TP48200A-DT19C1 or TP48200A-HT19C1.........................................65
7.4.2 Installing AC Input Power Cables for the TP48200A-DT19C2 and TP48200A-HT19C2......................................69
8 (Optional) Installing Batteries..................................................................................................75
8.1 Installing Battery Strings............................................................................................................................................76
8.2 Installing Copper Bars Between Batteries..................................................................................................................77
8.3 Installing Battery Cables.............................................................................................................................................78
9 Verifying the Installation..........................................................................................................80
9.1 Checking Hardware Installation .................................................................................................................................80
9.2 Checking Electrical Connections................................................................................................................................80
9.3 Checking Cable Installation........................................................................................................................................80
10 Commissioning .........................................................................................................................81
10.1 Connecting theAC Power Supply............................................................................................................................81

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
Contents
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vi
10.2 Setting the Display Language...................................................................................................................................82
10.3 Setting the Date and Time.........................................................................................................................................82
10.4 Setting theAC Input System.....................................................................................................................................82
10.5 Setting Battery Parameters........................................................................................................................................83
10.6 Setting Sensor Parameters ........................................................................................................................................84
10.7 (Optional) Setting Hibernation Parameters...............................................................................................................85
10.8 Setting Communications Parameters........................................................................................................................85
10.8.1 Setting Parameters Before Using WebUI Management.........................................................................................85
10.8.2 (Optional) Setting Parameters Before Using the NetEco Management.................................................................86
10.8.3 Setting Parameters Before Using the SNMP Management....................................................................................87
10.9 Connecting the Battery Supply.................................................................................................................................90
10.10 Subsequent Operations ...........................................................................................................................................91
A Associations Between Alarms and Dry Contacts on the UIM ..........................................92
B Acronyms and Abbreviations ..................................................................................................93

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Safety
1.1 Health and Safety
1.1.1 Overview
Introduction
This section describes the safety precautions you must take before installing or maintaining
Huawei equipment.
To ensure safety of humans and the equipment, pay attention to the safety symbols on the
equipment and all the safety instructions in this document.
The "NOTICE", "CAUTION", "WARNING", and "DANGER" statements in this
document do not represent all the safety instructions. They are only supplements to the
safety instructions.
Installation and maintenance personnel must understand basic safety precautions to avoid
hazards.
When operating Huawei equipment, in addition to following the general precautions in
this document, follow the specific safety instructions given by Huawei.
Only trained and qualified personnel are allowed to install, operate, and maintain Huawei
equipment.
This product should be used in the environment that meets design specifications.
Otherwise, the product may be damaged, and the resulting product exceptions or
component damage are beyond the warranty scope.
Local Safety Regulations
When operating Huawei equipment, you must follow the local laws and regulations. The
safety instructions in this document are only supplements to the local laws and regulations.
General Requirements
To minimize risk of personal injury and damage to equipment, read and follow all the
precautions in this document before performing any installation or maintenance.
Ensure that the instructions provided in this document are followed completely. This section
also provides guidelines for selecting the measuring and testing devices.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Installation
The device (or system) must be installed in an access-controlled location.
The device can be mounted only on concrete or non-combustible surfaces.
The device must be fixed securely on the floor or to other immovable objects such as
walls and mounting racks before operation.
When installing the unit, always make the ground connection first and disconnect it at
the end.
Do not block the ventilation while the device is operating. Keep a minimum distance of 5
cm between the device and the wall or other objects that may block the ventilation.
Tighten the thumbscrews by using a tool after initial installation and subsequent access
to the panel.
Ground
Do not damage the ground conductor or operate the device in the absence of a properly
installed ground conductor. Conduct the electrical inspection carefully.
The device (or system) must be connected permanently to the protection ground before
an operation. The cross-sectional area of the protective ground conductor must be at least
10 mm2.
Power Supply
For AC-supplied models: The device applies to TN, TT, or IT power system.
For DC-supplied models: Reinforced insulation or double insulation must be provided to
isolate the DC source from the AC mains supply.
For DC-supplied model: The device applies to DC power source that complies with the
Safety Extra-Low Voltage (SELV) requirements in IEC 60950-1 based safety standards.
Prepared conductors are connected to the terminal block, and only the appropriate
AWG/Type of wire is secured with the lug terminals.
Human Safety
Do not operate the device or cables during lightning strikes.
Remove the AC power connector when there is lightning. Do not use fixed terminals or
touch terminals or antenna connectors when there is lightning.
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to
telecommunication network voltage (TNV) circuits.
Move or lift the chassis by holding its lower edge. Do not hold the handles on certain
modules such as power supply, fans, and boards because they cannot support the weight
of the device.
At least two persons are required to lift the chassis. When lifting it, keep your back
straight and move stably.
Do not wear jewelry or watches when you operate the device.
Operator
Only qualified professional personnel are allowed to install, configure, operate, and
disassemble the device.
Only the personnel authenticated or authorized by Huawei are allowed to replace or
change the device of the parts of the device (including the software).

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
Any fault or error that might cause safety problems must be reported immediately to a
supervisor.
Only qualified personnel are allowed to remove or disable the safety facilities and to
troubleshoot and maintain the device.
1.1.2 Electrical Safety
High Voltage
The high voltage power supply provides power for the device operation. Direct or indirect
contact (through damp objects) with high voltage and AC mains supply may result in serious
injuries.
During the installation of the AC power supply facility, follow the local safety
regulations. The personnel who install the AC facility must be qualified to perform high
voltage and AC operations.
Do not wear conductive articles, such as watches, hand chains, bracelets, and rings
during the operation.
When water is found in the rack or the rack is damp, switch off the power supply
immediately.
When the operation is performed in a damp environment, make sure that the device is
dry.
Non-standard and improper high voltage operations may result in fire and electric shock.
Therefore, you must abide by the local rules and regulations when bridging and wiringAC
cables. Only qualified personnel are allowed to perform high voltage andAC operations.
Before powering on a device, ground the device. Otherwise, personal injury or device damage
may be caused by high leakage current.
Tools

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
Dedicated tools must be used during high voltage and AC operations. Avoid using ordinary
tools.
High Electrical Leakage
Ground the device before powering it on. Otherwise, personal injury or device damage may
be caused by high leakage current.
If the "high electrical leakage" tag is present on the power terminal of the device, you must
ground the device before powering it on.
1.1.3 Inflammable Environment
Operating the electrical device in an inflammable environment can be fatal.
Do not place the device in an environment that has inflammable and explosive air or gas. Do
not perform any operation in this environment.
1.1.4 Battery
Storage Battery
Before operating storage batteries, carefully read the safety precautions for battery handling
and connection.
Improper handling of storage batteries causes hazards.
When operating storage batteries, avoid short circuit and overflow or leakage of the
electrolyte. Electrolyte overflow may damage the device. It will corrode metal parts and
circuit boards, and ultimately damage the device and cause short circuit of circuit boards.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
If the power system is not powered on and does not supply power to any load for more than
two weeks, turn off all battery loops.
Basic Precautions
Before installing and maintaining the battery, note the following:
Do not wear metal articles such as wristwatch, hand chain, bracelet, and ring.
Use special insulated tools.
Take care to protect your eyes when operating the device.
Wear rubber gloves and a protective coat in case of electrolyte overflow.
When handling a storage battery, ensure that its electrodes are upward. Leaning or
reversing the storage battery is prohibited.
Do not wear metal articles such as wristwatch, hand chain, bracelet, and ring.
Short Circuit
Battery short circuit may cause human injuries. Although the voltage of ordinary batteries is
low, the instantaneous high current caused by the short circuit releases a great deal of energy.
There is danger of explosion if the battery is incorrectly replaced. Therefore, replace the
battery only with the same or equivalent type recommended by the manufacturer.
Keep away metal objects, which may cause battery short circuit, from batteries. If metal
objects must be used, first disconnect the batteries in use before performing any other
operations.
Hazardous Gas

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
Do not use unsealed lead acid storage batteries. Lead acid storage batteries must be placed
horizontally and stably to prevent the batteries from releasing flammable gas, which may
cause fire or erode the device.
Lead acid storage batteries in use emit flammable gas. Therefore, ventilation and
fireproofing measures must be taken at the sites where lead acid storage batteries are used.
Battery Temperature
If a battery overheats, the battery may be deformed or damaged, and the electrolyte may
overflow.
When the temperature of the battery is higher than 60°C, check the battery for electrolyte
overflow. If the electrolyte overflows, absorb and counteract the electrolyte immediately.
Battery Leakage
If the electrolyte overflows, absorb and counteract the electrolyte immediately.
When moving or handling a battery whose electrolyte leaks, note that the leaking electrolyte
may hurt human bodies. When you find the electrolyte leaks, use the following substances to
counteract and absorb the leaking electrolyte:
Sodium bicarbonate (baking soda): NaHCO3
Sodium carbonate (soda): Na2CO3
Select a substance to counteract and absorb the leaking electrolyte according to the
instructions of the battery manufacturer.
1.1.5 Working at Heights
Avoid object falling when you work at heights.
When working at heights, fulfill the following requirements:
Only trained personnel can work at heights.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Prevent the devices and tools that you carry from falling down.
Take safety and protection measures, for example, wear a helm and safety belt.
Wear warm clothes when working at heights in a cold region.
Before working at heights, check that all the lifting facilities are in good condition.
Hoisting Heavy Objects
Do not walk below the cantilever or hoisted objects when heavy objects are being hoisted.
Only trained and qualified personnel can perform hoisting operations.
Before hoisting heavy objects, check that the hoisting tools are complete and in good
condition.
Before hoisting heavy objects, ensure that the hoisting tools are fixed to a secure object
or wall with good weight capacity.
Issue orders with short and explicit words to avoid misoperations.
Ensure that the angle formed by two cables is not larger than 90 degrees. See Figure 1-1.
Figure 1-1 Hoisting heavy objects

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
Using Ladders
Checking a Ladder
Before using a ladder, check whether the ladder is damaged. Only the ladder in good
condition can be used.
Before using a ladder, you should know the maximum weight capacity of the ladder.
Avoid overweighting the ladder.
Placing a Ladder
The recommended gradient of ladders is 75 degrees. You can measure the gradient of the
ladder with a right angle or your arms. When using a ladder, ensure that the wider feet of the
ladder are downward, or take protection measures for the ladder feet to prevent the ladder
from sliding. Ensure that the ladder is placed securely.
Climbing Up a Ladder
When climbing up a ladder, note the following:
Ensure that the center of gravity of your body does not deviate from the edges of the two
long sides.
To minimize the risk of falling, hold your balance on the ladder before any operation.
Do not climb higher than the fourth rung of the ladder (counted from up to down).
If you want to climb up a roof, ensure that the ladder top is at least one meter higher than
the roof.
1.1.6 Mechanical Safety
Drilling Holes
Do not drill the cabinet at will. Drilling holes without complying with the requirements affects
the electromagnetic shielding performance of the cabinet and damages the cables inside the
cabinet. In addition, if the scraps caused by drilling enter the cabinet, the printed circuit
boards (PCBs) may be short circuited.
Before you drill a hole in the cabinet, wear insulated gloves and remove the internal
cables from the cabinet.
Wear an eye protector when drilling holes. This is to prevent your eyes from being
injured by the splashing metal scraps.
Ensure that the scraps caused by drilling do not enter the cabinet.
Drilling holes without complying with the requirements affects the electromagnetic
shielding performance of the cabinet.
After drilling, clean the metal scraps immediately.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
Sharp Objects
Before you hold or carry a device, wear protective gloves to avoid getting injured by sharp
edges of the device.
Handling Fans
When handling fans, note the following:
When replacing a component, place the component, screws, and tools in a safe place.
Otherwise, if any of them fall into the operating fans, the fans may be damaged.
When replacing a component near fans, do not insert your fingers or boards into the
operating fans until the fans are switched off and stops running.
Lifting Heavy Objects
When heavy objects are being lifted, do not stand or walk under the cantilever or the lifted
object.
1.1.7 Bundling Signal Cables
Do not bundle signal cables with high current cables or high voltage cables.
Maintain a minimum space of 150 mm between adjacent ties.
1.2 Equipment Safety
1.2.1 Electricity Safety
High Electrical Leakage

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
1 Safety
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
If the "high electrical leakage" tag is present on the power terminal of the device, you must
ground the device before powering it on.
1.2.2 Electrostatic Discharge
The static electricity generated by human bodies may damage the electrostatic-sensitive
components on boards, for example, the large-scale integrated (LSI) circuits.
Human body movement, friction between human bodies and clothes, friction between shoes
and floors, or handling of plastic articles causes static electromagnetic fields on human bodies.
These static electromagnetic fields cannot be eliminated until the static is discharged.
To prevent electrostatic-sensitive components from being damaged by the static on human
bodies, you must wear a well-grounded electrostatic discharge (ESD) wrist strap when
touching the device or handling boards or application-specific integrated circuits (ASICs).
1.2.3 Laying Out Cables
When the temperature is very low, violent strike or vibration may damage the cable sheathing.
To ensure safety, comply with the following requirements:
Cables can be laid or installed only when the temperature is higher than 0°C.
Before laying out cables which have been stored in a temperature lower than 0°C, move
the cables to an environment of the ambient temperature and store them at the ambient
temperature for at least 24 hours.
Handle cables with caution, especially at a low temperature. Do not drop the cables
directly from the vehicle.
1.2.4 Rectifier
When a rectifier is running, the temperature around the air exhaust vent at the rear is
high. Do not touch the vent or cover the vent with cables or other objects.
To prevent electric shocks, do not put your hands into rectifier slots.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
2 Installation Preparations
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
2 Installation Preparations
2.1 Required Tools
Figure 2-1 lists the tools that are required for the installation.
Use tools with insulated handles.

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
2 Installation Preparations
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
Figure 2-1 Installation tools
2.2 Technical Specifications
Table 2-1 Technical specifications
Model
Dimensions (H x W x D)
Weight
Cabinet
TP48200A-
DT19C1
2030 mm x 820 mm x 760 mm
(including the 150 mm high base
and excluding the protruding part
of the door)
< 200 kg (excluding
rectifiers and batteries)
TP48200A-
DT19C2
TP48200A-
HT19C1
TP48200A-
HT19C2

TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2
Installation Guide
2 Installation Preparations
Issue 03 (2014-02-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
Model
Dimensions (H x W x D)
Weight
Rectifier
R4850G2
40.8 mm x 105 mm x 281 mm
≤ 2 kg
R4830G2
≤ 1.8 kg
2.3 Installation Dimensions
Figure 2-2 shows the installation dimensions.
Figure 2-2 Installation dimensions
2.4 Requirements for Cable Routing
Cables should be more than 20 mm away from heat source components or area,
preventing direct damage (melting) to the insulation layer or functional degradation
(aging or broken).
The bending radius of cables should be greater than or equal to five times the diameter of
the cables.
Cables of the same type should be bound together. Cables of different types should keep
a minimum distance of 30 mm from each other to avoid tangles.
Cables that are bound together should be close to each other, neat, and free of damage.
The protection ground cables must not be bound to or tangled with the signal cables.An
appropriate distance should be left between them to minimize interruption.
AC power cables, DC power cables, signal cables, and communications cables must be
bound separately.
