Huawei Band B3 Reference guide

HUAWEI Band B3
Online Help
Issue
01
Date
2016-05-18
HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
1
1 Getting started
About This Chapter
1.1 Using your HUAWEI TalkBand B3
1.2 Charging your HUAWEI TalkBand B3
1.3 Connecting your HUAWEI TalkBand B3 to your phone
1.4 Managing screens
1.5 Getting to know the icons
1.1 Using your HUAWEI TalkBand B3
You can use your HUAWEI TalkBand B3 for fitness monitoring, sleep monitoring, Bluetooth
calling, and smart notifications.
Fitness monitoring: Your HUAWEI TalkBand B3 is able to smartly recognize whether you
are walking, running, or climbing.
Sleep monitoring: Your HUAWEI TalkBand B3 is able to identify whether you are sleeping
deeply or lightly and monitor your sleep data.
Bluetooth calling: Your HUAWEI TalkBand B3 comes with a Bluetooth headset that allows
you to make Bluetooth calls.
Smart reminders: Your HUAWEI TalkBand B3 supports smart alarms, activity reminders,
and event alarms to make your life more convenient.
1.2 Charging your HUAWEI TalkBand B3
Charge your HUAWEI TalkBand B3 in a place with good ventilation. Make sure the charging port
is clean and dry before charging.
Your HUAWEI TalkBand B3 does not come with a charger. Supported charging specifications
include 5 V 0.5A, 5 V 1A, 5 V 1.5 A, and 5 V 2A.

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
2
To charge your HUAWEI TalkBand B3: Connect your HUAWEI TalkBand B3 to the
charging port on the charger with the charging cable and connect the charger to a power
supply. that is being filled up upward indicates your HUAWEI TalkBand B3 is
charging.
Charging time: It takes about 2 hours to fully charge your HUAWEI TalkBand B3. When
your HUAWEI TalkBand B3 is fully charged, the battery icon becomes static and is
displayed.
To view the battery level: Check the battery icon on the home screen or the
battery icon in the Huawei Wear app.

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
3
Low battery alerts: When the battery icon blinks or appears, this indicates
your HUAWEI TalkBand B3 has low power. Please charge your HUAWEI TalkBand B3 as
soon as possible.
1.3 Connecting your HUAWEI TalkBand B3 to your phone
When you are connecting your HUAWEI TalkBand B3 to your phone for the first time,
download the Huawei Wear app.After data has been synced between your HUAWEI
TalkBand B3 and phone, you can check the time and fitness data on your HUAWEI TalkBand
B3.
1. Search for the Huawei Wear app in the Huawei HiApp or Apple's App Store to
download the app.
2. Press and hold the side button to power on your HUAWEI TalkBand B3. When
blinks, this indicates that your HUAWEI TalkBand B3 is in pairing mode.
After a fixed time interval, your HUAWEI TalkBand B3 automatically exits pairing mode. Turn on the
screen to enter pairing mode again.
3. Open the Huawei Wear app and select TalkBand B3.

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
4
4. Turn on Bluetooth on your phone, search for and touch the Bluetooth name of your
HUAWEI TalkBand B3 “HUAWEI B3-XXX”.
5. Open the Huawei Wear app and follow the onscreen instructions to connect your
HUAWEI TalkBand B3 and phone.
6. Enter the home screen of the Huawei Wear app, and data will be automatically synced.
The data sync is successful if the time of your phone is displayed on your HUAWEI
TalkBand B3. Now you can start using your HUAWEI TalkBand B3.
Your HUAWEI TalkBand B3 supports phones running Android 4.3 or later and iOS 7.0 or later.
When your HUAWEI TalkBand B3 is disconnected from your phone for a while, your HUAWEI
TalkBand B3 will automatically reconnect. If you do not want to wait for your HUAWEI TalkBand
B3 to automatically reconnect, you can also press the side button to reconnect immediately.
1.4 Managing screens
To turn on the screen: Press the side button or raise your wrist.

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
5
To switch between different screens: Swipe up or down on the screen or rotate your wrist.
When rotating your HUAWEI TalkBand B3, please keep your wrist level.
To turn off the screen: Press the side button or lower your wrist. The screen will also turns
off if it has been idle for a long time.

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
6
When you are on the home screen, pressing the side button will turn off the screen. On other screens,
pressing the side button will bring you back to the home screen.
1.5 Getting to know the icons
The following icons are applicable to version 1.3.1. We will continue to offer version optimizations to
provide you with a better user experience.
Swipe and touch on the screen of your HUAWEI TalkBand B3 to get to know the screens and
icons.
Home screen
Steps
Calories
Sleep
Contacts
Fitness

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
7
Walking
Running
Cycling
CLimbing
More features
Change screen
Phone finder
Bluetooth connection
Factory data reset
About screens
Status screen
The walking, running, cycling, and climbing icons only appear on the fitness screen.
After changing the home screen, you can touch the screen to access the status screen where you can
check the battery, Bluetooth connection, and other information.
Screens and icons for calling

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
8
Incoming call
Missed call
Make a Call
End a call
Screens and icons for reminders
Activity reminder
Goal achieved
Low battery alert
Battery almost empty alert
Alarm
Snooze
Updating
Smart reminder

HUAWEI Band B3
Online Help
1 Getting started
Issue 01(2016-05-18)
9
Open the camera application on your phone and press and hold the side button of your
HUAWEI TalkBand B3. The remote photo shooting notification will appear.
Remote photo shooting
