HULALA HOME SCCL0878 User manual

HULALA
H O M E
01/15
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
ITEM NO.SCCL0878

MAINTAINANCE AND WARNING
1.Keep furniture away from heat sources.
2.Do not clean furniture with harsh cleaner or polishes.Do not use
detergents,solvents,abrasives,spray packs or leather cleaner.
Use non-color mild soa with warm water to clean spills(Mix 1:10
soap to water).
3.Do not place furniture under direct sunlight,material will possibly
fade over time.
4.Do not use on site dry cleaning machine.Children should not climb
or jump on the furniture.
5.Do not write on furniture that is not protectedby a padded barrier.
6.Not for commercial use,only for residential use.
Weight Limitation
110 LBS
02/15

EXPLOSIVE VIEW
2PERSONEN
03/15
A
B
B
C
C

PARTS LIST
A B C x2x2x1
04/15

HARDWARE LIST
HARDWARE SPARE LIST
#1 x4
Ø6*35mm
#2 #4 #5x4 x8 x2
#1 #4 #5 #6
#6
#7 #8 #9
TOOL LIST
#10
x1 x1 x1 x1
x1
x2
x2 x1 x2
M3.5*15mm M4*35mm
05/15
Ø15*11mm
Ø6*35mm M3.5*15mm M4*35mm
M4*40mm
M4*40mm
#3 x4

ASSEMBLY INSTRUCTIONS
STEP-1
Insert screw bolt #1 into the corresponding hole of leg (C), tighten bolt
#1 with screwdriver #10.
#1 x4 #10 x1
06/15
#1
#1
#1
#1x4
#10
C
C
C
Ø6*35mm

ASSEMBLY INSTRUCTIONS
STEP-2
Insert leg (C) into the panel (B),and then insert cam bolt #2 into the
panel (B)tighten cam bolt #2 with screwdriver #10.
#2 x4 #10 x1
07/15
#2
#2
#2
B
B
C
C
B
C
BC
#2x4 #10
Ø15*11mm

ASSEMBLY INSTRUCTIONS
STEP-3
Insert preassemble step 2 into panel (A) and make sure all the holes
are aligned.
08/15
A
C
C
B
B
C
B
A

ASSEMBLY INSTRUCTIONS
STEP-4
In preassemble step 3，make sure all holes aligned and then use bolt
#4 to attach them，tighten bolt #4 with screwdriver #10.
#4 x8 #10 x1
09/15
#4
#4
#4
A
CC
B
B
#10
C
M4*40mm

ASSEMBLY INSTRUCTIONS
STEP-5
As shown in the figure,remove the #3 back protective layer
and attach the felt mat #3 to the leg (C).
10/15
A
C
B
B
#3 x4
#3
#3
C
x4

A
#10
ASSEMBLY INSTRUCTIONS
STEP-6
Remove the screw using #10 screwdriver, place the handle in front of
drawer panel, connect the handle with a screw and lock the screw with
a screwdriver#10.
11/15
#10 x1
#10

#9 x1
ASSEMBLY INSTRUCTIONS
STEP-7
Use screw #5 to plastic bracket #9 to panel (A),tighten screw #5 with
screwdriver #10.
#5 x2
12/15
#5
#5x2
A
A
#10 x1
#9
#9
#10
M3.5*15mm

ASSEMBLY INSTRUCTIONS
STEP-8:
13/15
WALL
1.
2.
WALL
WALL
#7x2
NOT PROVIDED
#9x1
#6x2
#10
#7 x2 #9 x1 #10 x1
#6 x2
1. Mark the position on the wall, that corresponds to the location of
bracket on the top panel (A); Drill and insert the expandable
screw by hammer.
2. Assemble the bracket to the wall. Align the hole in the
bracket with the expandable screw , use screw to attach
it,tighten screw with screwdriver .
#6
M4*35mm

ASSEMBLY INSTRUCTIONS
STEP-9:
3.Let the plastic belt #8 pass through bracket #9 and pull tightly.
#8 x1
14/15
#8×1
#9
#9
WALL
#8
