HULALA HOME TVSBSD0454 User manual

NOTE:
ITEM NO. TVSBSD0454
This brochure contains IMPORTANT safty info. Please read and keep for
future reference.
1/20

MAINTAINANCE
AND WARNING
Keep furniture away from heat.
Do not clean furniture with harsh cleansers
or polish. Do not use detergents, Solvents,
abrasives, spray packs or leather cleaner. Use
non-color mild soap with warm water clean
spills(Mix 1:10 soap to water)
Do not place furniture under direct sunlight,
material will possibly fade over time.
Do not use on site dry Cleaning machine.
Children should not climb or jump on the
furniture.
Do not write on furniture without a padded
barrier to protect the surface.
Not for commercial use, For residential use
only.
Weight Limitation
80LBS
20

PARTS
LIST
20

Explosive View
20

HARDWARE
LIST
Be sure to check all packing material carefully for
small parts, which may have come loose inside the
carton during shipment.
20
SPARE
78
X

6 20
ASSEMBLY
IN STRUCTIONS
A*8
D*8
4
Preparation for middle leg and doors
1) Assemble the middle leg. Align the hole in part 16 and the screw hole in part 15,
screw in and tighten the screw K by allenkey P.
2) Attach the part U to the part 11. Align the hole in part U to the part 11, then screw
in and tighten the screw E by screwdriver X.
3) Attach the part G to the part 11. Align the hole in part G to the part 11, then screw
in and tighten the screw H by screwdriver X.
4) Attach the part N to the part 11. Align the hole in part N to the part 11, then screw
in and tighten the screw E by screwdriver X.
PREPARE THE PART 1.
1) Align the hole in part 1, insert the wooden dowel D into t
he hole by hand; screw in and tighten the cam bolt A by
screwdriver X.
2) Align the hole in part U to the hole in part 1, screw
in and tighten the screw E by screwdriver X.

20
7
A*4 A*4
D*4 D*4
B*4
O*4
3
Attach the part 3 and 4 to the part 1.
1）Insert the nut B into the hole in part 3 and 4
as the picture show.
2）Align the hole in part 3 and 4, insert the wooden dowel D
and cam bolt A in part 1 into the part 3 and 4, then tighten
the nut B by screwdriver X.
3）Cover the nut by part O.
Prepare the part 5 and 6. Align the hole in part 5
and 6, insert the wooden dowel D by hand , screw
in and tighten the cam bolt A into part 5 and 6 by
screwdriver X.

20
A
D
D*8
B*4
O*4
AD
Connect the part 5 and 6 to the part 8.
1) Insert the nut B into the hole in part 8 as the picture show.
2) Align the hole in the part 8, insert the wooden dowel D and
cam bolt A in part 5 and 6 into the part 8, then tighten the
nut B by screwdriver X.
3) Cover the nut B by part O.
Connect the part 5 and 6 to the part 1.
1) Insert the nut B into the hole in part 5, 6
as the picture show.
2) Align the hole in the part 5 and 6, insert
the wooden dowel D and cam bolt A in
part 1 into the part 5 and 6, then tighten
the nut B by screwdriver X.
3) Cover the nut B by part O.
4)Align the hole in part 3,4,5 and 6,
insert the wooden dowel D into the hole
in part 3,4,5 and 6 by hand.

9 20
Attach part 9 and 10 to finished part in step 6.
1) Insert the part W into the part 9 and 10 bu hand.
2) Slide the part 9 and 10 into the groove in part 1, 3,4,5 and 6.
4
6

20
8
C*8
Attach the part 2 to the finished part in step 7.
1) Align the hole in part 2, insert the wooden dowel B in the part 3,4,5 and 6 into the part 2
2) Align the hole in part 2 to the hole in part 3,4,5 and 6, Screw in and tighten the screw C
by Allenkey P as the picture show.

11 20
9
J*12
10
Attach the leg frame.
Align the hole in part 12 and 13 to the
hole in part 2, screw in and tighten the
screw J by allenkey P. DO NOT FULLY TIGHTEN!
Attach the middle leg to the leg frame.
Align the hole in part 16 to the hole in part 12,
screw in and tighten the screw I by allenkey
P. DO NOT FULLY TIGHTEN!
12

12 20
11
Assemble the part V to the leg frame.
1) Insert the edge of part V into the space in part 12 and 13
2) Align the hole in part V to the hole in part 12 and 13, screw in and tighten the screw E
by screwdriver X. DO NOT FULLY TIGHTEN!

13 20
12
V
Assemble the legs.
1）Align the hole in part 14 to the hole in part V, screw in and tighten
the screw L by allenkey P.
2）After check the all screw in right position, fully tighten the
screws I, J E in sequence.

13
14 20
22
2
Assemble the part F and part hook of anti-collapse R as the picture show.
1）Insert the part F into the space between the part 1,2, 3, 4,5,6, screw in screw E
and tighten by screwdriver X.
2）Align the hole in part R to the part 1, screw in and tighten the screw E by screwdriver X.

15/20
14
Insert the part Q into the hole in part 3, 4,5,6 by hand as the picture show.
U*2
E*4
Align the hole in part U ,screw in and tighten the screw E by screwdriver X

15
16/20
Install the part N on the part 3 and 4 as the picture show.
Align the hole in part N to the hole in part 3 and 4, screw in and tighten the screw E
by screwdriver X.
N

Q
Q
16
17/20
Insert the part 7 into the position above the part Q.

Use the adjustable nail to keep the cabinet level in case the
cabinet is wabbling.
Now your cabinet is ready to use.
17
18/20

19
Install the anti-collapse device.
1. Mark the position on the wall, this should be same as the position of R
where are on the back of panel 1; Drilled and insert the expandable screw
T by hammer;
2.Assemble the part R on the wall. Align the hole in the part R to the
expandable screw T, screw in and tighten by screwdriver;
3.let the plastic belt S go through the both R and pull to tighten.
M
M
T
T
M
18
20

Are you having
with assembly? Missing
send email with your order
For return, Please check the return policy
the retailer or MarketPlace you bought
Appreciated your purchasing from us.
Pop up your life by our furniture
20/20
We strive to offer high-quality products, and we also try our
best to satisfy each and every customer that orders from us
with product or service as needed. We provide 30 days
warranty starting from the time you receive the item. Each
customer must provide a record of their order such as the
order number, or item receipt for any items that are out of
the warranty period you may also still receive replacement
parts by purchasing them with our company if they are
available.
