Hunt Electronic HVRM-T1600L Operation manual

Installaction & User Manual
0
HVRM-T1600L
Install & User’s Guide
(v 1.0)
Installation/User Manual
HVRM-T1600M, HVRM-T800M, HVRM-T400M,
HVRM-T1600Q, HVRM-T800Q
Digital Video Recorder
Installation/User Manual
English

Installaction & User Manual
1
Introduction
Thank you for purchasing a Hunt digital video recorder.
This manual is for . Before product installation and operation, please become thoroughly familiar
with this user manual and other manuals referenced by this manual.
This user manual and the software and hardware described here are protected by copyright law.
With the exception of copying for general use within fair use, copying and reprinting the user
manual, either partially or in entirety, or translating it into another language without the consent
of Hunt Inc. is strictly prohibited.
This specification may change without prior notice for improvement of product performance.
Product Warranty and Limits of Responsibility
The manufacturer does not assume any responsibility concerning the sale of this product and
does not delegate any right to any third party to take any responsibility on its behalf. The
product warranty does not cover cases of accidents, negligence, alteration, misuse or abuse.
No warranty is offered for any attachments or parts not supplied by the manufacturer.
Malfunctions due to negligence by the user
Deliberate disassembly and replacement by the user
Connection of a power source other than a properly rated power source
Malfunctions caused by natural disasters (fire, flood, tidal wave, etc.)
Replacement of expendable parts (HDD, FAN, etc.)
※The warranty period for the HDD and Fan is one year after purchase.
This product is not for exclusive use of crime prevention but for assistance in cases as
fire or theft. We take no responsibility for damage from any incident.

Installaction & User Manual
2
Caution
As this equipment undergone EMC registration and suitable for business purpose, distributors
and users are aware of this point.
FCC Compliance Statement
Caution : Any changes or modifications in construction of this device which are not expressly
approved the party responsible for compliance could void the user's authority to operate the
equipment.
NOTE : This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications, Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Warning
This is a class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures
Warning
1. In case of changing built-in lithum battery, it should be replaced as same or kindred one to
prevent a danger of explosion. Since old batteries could be a factor of environment
contamination, be cautios to treat them.
2. Do not throw the batteries to fire or heating. Neither short circuiut or disassembly is
prohibited.
3. Do not charge the batteries provided with Remote Controller

Installaction & User Manual
3
Important Notice
1. Do not place heavy objects on the top of the product.
2. Product is for indoor use. It is not weatherproof. Use product with referring to its
environmental specifications (Temperature & Humidity). To clean the product, gently wipe the
outside with a clean dry cloth.
3. Product uses AC power of 110V ~ 240V. Be cautious not to cause electric damages to
product.
4. Be careful not to drop the product. Physical shocks may harm the product including internal
HDD. In addition, be sure the product is secured after installation.
5. Product is made of metal. Therefore you can hurt human beings if you throw it to them or hit
on them. When installing product, be cautious to locate on safe places where children are
unreachable.
6. If Product does not operate properly, please contact the closest HUNT distributor for after
sales service. Tampering or disassembling the product will void the warranty.
7. Security surveillance laws may differ for each country. Therefore, please contact the local
region first to avoid any surveillance law violations.
Experience and technical skills are needed for the installation of this product as an improper
installation may cause fire, electric shocks, or defects.Any installation job should be performed
by the vendor you purchased this product from.
The content of this manual can differ according to firmware or Software upgrading, and the
standard and appearance of products may be changed for the improvement of quality without
an advance notice.

Installaction & User Manual
4
Contents
INTRODUCTION............................................................................. 1
KEY FEATURES............................................................................. 9
INSTALL MANUAL....................................................................... 12
1. FEATURE.............................................................................. 12
1.1 Supplied Accessories .......................................................................................................12
1.2 Description & Function .....................................................................................................13
1.2.1 Front..........................................................................................................................13
1.2.2 Rear...........................................................................................................................15
1.2.3 REMOTE CONTROLLER .........................................................................................16
2. INSTALLATION......................................................................... 18
2.1 Installation and Connection..............................................................................................18
2.1.1 Connecting & Running ..............................................................................................18
2.2 Running OSD menu .........................................................................................................19
2.2.1 OSD menu configuration...........................................................................................19
2.2.2 Setting remote controller...........................................................................................21
2.2.3 Installation examples.................................................................................................22
2.2.4 Basic Setting .............................................................................................................23
2.3 Connecting and configuring DIO ports .............................................................................27
2.3.4 HDD...........................................................................................................................37
2.3.5 Remote monitor and control......................................................................................38
2.3.6 External device connection .......................................................................................39
2.3.7 NVS04 connection.....................................................................................................41
USER MANUAL............................................................................ 43
3. MENU USE............................................................................ 43

Installaction & User Manual
5
3.1 Menu Structure .................................................................................................................43
3.2 Function Menu..................................................................................................................43
3.3 Factory Reset ...................................................................................................................44
4. MONITORING........................................................................ 49
4.1 Basic Screen ....................................................................................................................49
4.2 Single Fll Screen Mode ....................................................................................................49
4.3 Multi Screen Mode............................................................................................................49
4.4 Screen Description ...........................................................................................................49
4.5 Auto Switch Mode.............................................................................................................50
4.5.1 System Standard Mode.............................................................................................50
4.5.2 User Sequence Mode................................................................................................50
4.6 Event Screen....................................................................................................................51
4.7 Zoom Screen Mode..........................................................................................................52
4.8 Pause Live Screen ...........................................................................................................52
4.9 PTZ Control ......................................................................................................................53
4.9.1 Pan/Tilt............................................................................................................................54
4.9.2 Zoom/Focus....................................................................................................................54
4.9.3 Load Preset ....................................................................................................................54
4.9.4 Save Preset ....................................................................................................................54
4.9.5 Auxiliary On.....................................................................................................................54
4.9.6 Auxiliary Off.....................................................................................................................55
4.9.7 Menu...............................................................................................................................55
5.PLAYBACK................................................................................ 56
5.1 Playback Mode.................................................................................................................56
5.1.1 Playback on Standard monitor (16 / 9 division).........................................................56
5.1.2 Playback function......................................................................................................56

Installaction & User Manual
6
5.2 SEARCH MODE...............................................................................................................56
5.2.1 Time Search..............................................................................................................57
5.2.2 Schedule Search.......................................................................................................57
5.2.3 Event Search.............................................................................................................58
5.2.4 Thumbnail Search.....................................................................................................58
5.3 Copy .................................................................................................................................59
5.3.1 CD/DVD.....................................................................................................................59
5.3.2 RE4............................................................................................................................61
5.3.3 AVI.............................................................................................................................61
6.CONFIGURATION ..................................................................... 63
6.1 Recording Structure..........................................................................................................63
6.2 System Setup ...................................................................................................................63
6.2.1 Date/Time..................................................................................................................63
6.2.2 Disk............................................................................................................................66
6.2.3 User Setup ................................................................................................................68
6.2.4 Utility..........................................................................................................................70
6.3 Network.............................................................................................................................73
6.3.2 xDSL..........................................................................................................................75
6.3.3 WRS..........................................................................................................................75
6.4 Device Setup ....................................................................................................................76
6.4.2 Camera Setup ...........................................................................................................76
6.4.3 Monitor Setup............................................................................................................77
6.4.4 Audio Setup...............................................................................................................79
6.4.5 Text Setup .................................................................................................................80
6.4.6 Serial Setup...............................................................................................................81
6.5 Event Setup......................................................................................................................82
6.5.2Event Check..............................................................................................................83
6.5.3 Sync Event................................................................................................................84
6.5.4 Motion Detection .......................................................................................................85
6.5.5 Sensor.......................................................................................................................87
6.5.6 Preset........................................................................................................................87

Installaction & User Manual
7
6.6 Recording setup ...............................................................................................................88
6.6.2 Program setup...........................................................................................................88
6.6.3 Manual/Schedule recording setup.............................................................................89
7. WEB VIEWER........................................................................... 95
7.1 System requirement .........................................................................................................95
7.2 Login.................................................................................................................................95
7.3 User Setup........................................................................................................................96
7.4 Browser available .............................................................................................................97
7.5 Monitor..............................................................................................................................97
7.5.1 Screen division and changing video position............................................................97
7.5.2 Move to Playback......................................................................................................98
7.5.3 Channel On/Off .........................................................................................................99
7.5.4 Sensor Indication.......................................................................................................99
7.5.5 Relay operation.........................................................................................................99
7.5.6 Using Microphone .....................................................................................................99
7.5.7 Event Data...............................................................................................................100
7.5.8 Video Recording & Save Saving.............................................................................100
7.5.9 Using PTZ ...............................................................................................................101
7.5.10 Using Audio .............................................................................................................102
7.5.11 Closing Video Channel............................................................................................102
7.6 Playback.........................................................................................................................103
7.6.1 Video Division & Changing Channel .......................................................................103
7.6.2 Image recording ......................................................................................................103
7.6.3 Print.........................................................................................................................104
7.6.4 Backup ....................................................................................................................104
7.6.5 Web Monitor............................................................................................................105
7.6.6 Channel On/Off .......................................................................................................105
7.6.7 Saving time & Checking Rec, Capacity...................................................................105
7.6.8 Searching Calander.................................................................................................105
7.6.9 Functional function at the buttom of monitor...........................................................106
8. USER MANUAL FOR MOBILE VIEWER ............................ 107

Installaction & User Manual
8
8.1 Log-In page.....................................................................................................................107
8.2 Monitoring page..............................................................................................................107
TROUBLE SHOOTING............................................................... 109
THE WAY TO CHECK THE MANUFACTURING DATE ...............111
AVAILABLE HDD.........................................................................112
COMPATITABLE CD/DVD LIST...................................................112
SPECIFICATION..........................................................................112
PRODUCT DIMENTION...............................................................115

Installaction & User Manual
9
KEY FEATURES
Monitoring Screen
Supprots real live video with high resolution per each channel and variable display mode.
Real H.264 Video
Various monitoring
Single, 4ch, 9ch, 10ch, 16ch
Auto Switching(AUTO)
Composite 4 ea, DVI 2ea
Audio Recording
Supprots real-time audio input and recording
Simultaneous 16ch audio input & recording available
Input : 4ch RCA, 12ch D-SUB, Output : 1ch(Rear)
Simultaneous audio recording and playback available
Recording
It supports 480ips recording at H.264 High-Resolution (4CIF) and available to record max.
5 seconds before triggering an event. Also, convert function is available protecing
privacy(Covert func.).
H.264 Video recording with High-Quality
D1(720x480) 480ips
Supports manual & schedule recording
Video loss detection
Supports archiving event list (Sensor, Video loss, Motion detection, Text)
Available record Max 5 seconds before triggering an event per each channel
