Hunt Electronic HVRM-T1600M User manual

HVRM-T1600M / T800M / T400M,
T1600Q / T800Q
Install & User’s Guide
(v 1.0)
HVRM-T1600M, HVRM-T800M, HVRM-T400M,
HVRM-T1600Q, HVRM-T800Q
Digital Video Recorder
Installation/User Manual
English

Install&User Manual
1
Introduction
Thank you for purchasing a Hunt digital video recorder.
This manual is for HVRM-T1600Q, HVRM-T800Q, HVRM-T1600M, HVRM-T800M, HVRM-
T400M. Before product installation and operation, please become thoroughly familiar with this
user manual and other manuals referenced by this manual.
This user manual and the software and hardware described here are protected by copyright law.
With the exception of copying for general use within fair use, copying and reprinting the user
manual, either partially or in entirety, or translating it into another language without the consent
of Hunt Inc. is strictly prohibited.
This specification may change without prior notice for improvement of product performance.
Product Warranty and Limits of Responsibility
The manufacturer does not assume any responsibility concerning the sale of this product and
does not delegate any right to any third party to take any responsibility on its behalf. The
product warranty does not cover cases of accidents, negligence, alteration, misuse or abuse.
No warranty is offered for any attachments or parts not supplied by the manufacturer.
Malfunctions due to negligence by the user
Deliberate disassembly and replacement by the user
Connection of a power source other than a properly rated power source
Malfunctions caused by natural disasters (fire, flood, tidal wave, etc.)
Replacement of expendable parts (HDD, FAN, etc.)
※The warranty period for the HDD and Fan is one year after purchase.
This product is not for exclusive use of crime prevention but for assistance in cases as
fire or theft. We take no responsibility for damage from any incident.

Install&User Manual
2
Caution
As this equipment undergone EMC registration and suitable for business purpose, distributors
and users are aware of this point.
FCC Compliance Statement
Caution : Any changes or modifications in construction of this device which are not expressly
approved the party responsible for compliance could void the user's authority to operate the
equipment.
NOTE : This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications, Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Warning
This is a class Aproduct. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures
Warning
1. In case of changing built-in lithum battery, it should be replaced as same or kindred one to
prevent a danger of explosion. Since old batteries could be a factor of environment
contamination, be cautios to treat them.
2. Do not throw the batteries to fire or heating. Neither short circuiut or disassembly is
prohibited.
3. Do not charge the batteries provided with Remote Controller

Install&User Manual
3
Important Notice
1. Do not place heavy objects on the top of the product.
2. Product is for indoor use. It is not weatherproof. Use product with referring to its
environmental specifications (Temperature & Humidity). To clean the product, gently wipe the
outside with a clean dry cloth.
3. Product uses AC power of 110V ~ 240V. Be cautious not to cause electric damages to
product.
4. Be careful not to drop the product. Physical shocks may harm the product including internal
HDD. In addition, be sure the product is secured after installation.
5. Product is made of metal. Therefore you can hurt human beings if you throw it to them or hit
on them. When installing product, be cautious to locate on safe places where children are
unreachable.
6. If Product does not operate properly, please contact the closest HUNT distributor for after
sales service. Tampering or disassembling the product will void the warranty.
7. Security surveillance laws may differ for each country. Therefore, please contact the local
region first to avoid any surveillance law violations.
Experience and technical skills are needed for the installation of this product as an improper
installation may cause fire, electric shocks, or defects. Any installation job should be performed
by the vendor you purchased this product from.
The content of this manual can differ according to firmware or Software upgrading, and the
standard and appearance of products may be changed for the improvement of quality without
an advance notice.

Install&User Manual
4
Contents
INTRODUCTION............................................................................. 1
KEY FEATURES............................................................................. 9
INSTALL MANUAL....................................................................... 12
1. FEATURE.................................................................................. 12
1.1 Supplied Accessories .......................................................................................................12
1.1.1. T1600M/T800M/T400M Series ...................................Error! Bookmark not defined.
1.1.2. T1600Q/T800Q Series................................................Error! Bookmark not defined.
1.2. Description & Function..................................................................................................14
1.2.1. Front..........................................................................................................................14
1.2.2. Rear...........................................................................................................................18
1.2.3. REMOTE CONTROLLER .........................................................................................21
2. INSTALLATION......................................................................２３
2.1 Installation and Connection...........................................................................................２３
2.1.1 Connecting & Running ...........................................................................................２３
2.2 Running OSD menu ......................................................................................................２５
2.2.1 OSD menu configuration........................................................................................２５
2.2.2Setting remote controller........................................................................................２６
2.2.3 Install examples......................................................................................................２７
2.2.4 Basic Setting ..........................................................................................................２９
2.3 Connecting and configuring DIO ports..........................................................................３３
2.3.4 HDD........................................................................................................................４４
2.3.5 Remote monitor and control...................................................................................４５
USER MANUAL.........................................................................４７

Install&User Manual
5
3MENU USE ...........................................................................４７
3.1 Menu Structure..............................................................................................................４７
3.2 Function Menu...............................................................................................................４７
3.3 Factory Reset ................................................................................................................４８
4MONITORING.......................................................................５４
4.1 Basic Screen .................................................................................................................５４
4.2 Single Fll Screen Mode .................................................................................................５４
4.3 Multi Screen Mode.........................................................................................................５４
4.4 Screen Description ........................................................................................................５５
4.5 Auto Switch Mode..........................................................................................................５５
4.5.1 System Standard Mode..........................................................................................５５
4.5.2 User Sequence Mode.............................................................................................５６
4.6 Event Screen.................................................................................................................５７
4.7 Zoom Screen Mode.......................................................................................................５８
4.8 Pause Live Screen ........................................................................................................５８
4.9 PTZ Control ...................................................................................................................５９
4.9.1 Pan/Tilt.........................................................................................................................６０
4.9.2 Zoom/Focus.................................................................................................................６０
4.9.3 Load Preset .................................................................................................................６０
4.9.4 Save Preset .................................................................................................................６０
4.9.5 Auxiliary On..................................................................................................................６０
4.9.6 Auxiliary Off..................................................................................................................６１
4.9.7 Menu............................................................................................................................６１
5PLAYBACK...........................................................................６２

Install&User Manual
6
5.1 Playback Mode..............................................................................................................６２
5.1.1 Playback on Standard monitor (16 / 9 / 4 division) ................................................６２
5.1.2 Playback function...................................................................................................６２
5.2 SEARCH MODE............................................................................................................６３
5.2.1 Time Search...........................................................................................................６３
5.2.2 Schedule Search....................................................................................................６３
5.2.3 Event Search..........................................................................................................６４
5.2.4 Thumbnail Search..................................................................................................６５
5.3 Copy ..............................................................................................................................６６
5.3.1 CD/DVD..................................................................................................................６６
5.3.2 RE4.........................................................................................................................６７
5.3.3 AVI..........................................................................................................................６８
6. CONFIGURATION..................................................................６９
6.1 Recording Structure.......................................................................................................６９
6.2 System Setup ................................................................................................................６９
6.2.1 Date/Time...............................................................................................................６９
6.2.2 Disk.........................................................................................................................７２
6.2.3 User Setup .............................................................................................................７４
6.2.4 Utility.......................................................................................................................７６
6.3 Network..........................................................................................................................７８
6.3.1 xDSL.......................................................................................................................８０
6.3.2 WRS.......................................................................................................................８０
6.4 Device Setup .................................................................................................................８１
6.4.1 Camera Setup ........................................................................................................８２
6.4.2 Monitor Setup.........................................................................................................８３
6.4.3 Audio Setup............................................................................................................８４
6.4.4 Text Setup ..............................................................................................................８５
6.4.5 Serial Setup............................................................................................................８６
6.5 Event Setup...................................................................................................................８７
6.5.1 Event Check...........................................................................................................８８

Install&User Manual
7
6.5.2 Sync Event.............................................................................................................８９
6.5.3 Motion Detection ....................................................................................................９１
6.5.4 Sensor....................................................................................................................９２
6.5.5 Preset.....................................................................................................................９２
6.6 Recording setup ............................................................................................................９４
6.6.1 Program setup........................................................................................................９４
6.6.2 Manual/Schedule recording setup..........................................................................９６
7. WEB VIEWER .................................................................１００
7.1 System requriement .................................................................................................. １００
7.2 Login.......................................................................................................................... １００
7.3 User Setup................................................................................................................. １０１
7.4 Browser available ...................................................................................................... １０１
7.5 Monitor....................................................................................................................... １０２
7.5.1 Screen division and changing video position..................................................... １０２
7.5.2 Move to Playback............................................................................................... １０３
7.5.3 Channel On/Off .................................................................................................. １０４
7.5.4 Sensor Indication................................................................................................ １０４
7.5.5 Relay opeartion .................................................................................................. １０４
7.5.6 Using microphone .............................................................................................. １０４
7.5.7 Event data .......................................................................................................... １０５
1.2.1. Video Recording & Save saving......................................................................... １０５
7.5.8 UsingPTZ ........................................................................................................... １０６
7.5.9 Using Audio ........................................................................................................ １０７
7.5.10 Closing Video Channel....................................................................................... １０７
7.6 Playback.................................................................................................................... １０８
1.2.2. Video Division & Changing Channel .................................................................. １０８
7.6.1 Image recording ................................................................................................. １０８
7.6.2 Printing ............................................................................................................... １０９
7.6.3 Backup ............................................................................................................... １０９
7.6.4 Web Monitor....................................................................................................... １１０

Install&User Manual
8
7.6.5 Channel On/Off .................................................................................................. １１０
7.6.6 Saving time & Checking Rec. Capacity.............................................................. １１０
7.6.7 Searching Calander................................................................................................. １１０
7.6.8. Functional function at the buttom of monitor...................................................... １１１
8. USER MANUAL FOR MOBILE VIEWER ........................１１２
8.1 Log-In page ............................................................................................................... １１２
8.2 Monitoring page......................................................................................................... １１２
TROUBLE SHOOTING...........................................................１１４
AVAILABLE HDD....................................................................１１６
COMPATITABLE CD/DVD LIST..............................................１１７
SPECIFICATION.....................................................................１１７
HVRM-T1600M, HVRM-T800M, HVRM-T400M.................................................................. １１７
HVRM-T1600Q, EH800L...................................................................................................... １２０
PRODUCT SIZE......................................................................１２３

Install&User Manual
9
KEY FEATURES
Monitoring Screen
Supprots real live video with high resolution per each channel and variable display mode.
Real H.264 Video
Varianble display mode
HVRM-T1600M : 1/4/9/10/16 channel mode
HVRM-T800M : 1/4/9 channel mode
HVRM-T400M : 1/4 channel mode
HVRM-T1600Q : 1/4/9/10/16 channel mode
HVRM-T800Q : 1/4/9 channel mode
Auto Switching
HVRM-T1600M : Composite x 2, DVI x 1
HVRM-T800M : Composite x 2, DVI x 1
HVRM-T400M : Composite x 2, DVI x 1
HVRM-T1600Q : Composite x 2, VGA x 1
HVRM-T800Q : Composite x 2, VGA x 1
Audio Recording
Supprots real-time audio input and recording
Simultaneous 4ch audio input & recording available
Input : 4Ch, Output : 1ch (Rear)
Simultaneous audio recording and playback available

Install&User Manual
10
Recording
It supports max. 480ips/HVRM-T1600M, 240ips/HVRM-T800M, HVRM-T1600Q,
120ips/HVRM-T800Q, HVRM-T400M
recording at High-Resolution (H.264) and available to record max. 5
seconds before triggering an event. Also, convert function is available protecing privacy.
H.264 Video recording with High-Quality
HVRM-T1600M : CIF(360x240) 480ips
HVRM-T800M : 2CIF(704x240) 240ips
HVRM-T400M : D1 (704x480) 120ips
HVRM-T1600Q : CIF(360x240) 240ips
HVRM-T800Q : CIF(360x240) 240ips
Supprots manual & schedule recording
Video loss detection
Supprots archiving event list(Sensor, Video Loss,
Motion detection, Text)
Available record Max 5 seconds before triggering an event per
each channel
Search/ Playback
It supports variable and convenient functions for search & playback
Play back by time, date, Channel
Easy and convenient search using mouse
Pre/post search from a freeze frame
Play back by Event (Sensor, Video Loss, Motion Detection, Text)
Easy & convenient search using Remote Controller & Jog/
Shuttle (except HVRM-T1600Q, HVRM-T800Q)

Install&User Manual
11
Back up device
It is available to backup to DVD-R, CD-R, USB memory by user‟s choice.
(HVRM-T1600Q, HVRM-T800Q is available as an option.)
Supprots various back up device : DVD-R, CD-R, USB memory
Extention HDD Storage (External extention Storage device)
Network
It supports variable network like LAN, XDSL and easily control from remote site using PC
cliet viewer.
E-mail notification thru. TCP/IP, DHCP in case of triggering an
event
Live monitoring form remote site (Whole screen or available to
select quad screen)
Available to playback, recording, search and DVR management
thru. network viewer in PC
Available to record, search & playback by time from remote site.
Supprots 10/100Mbps Ethernet/xDSL
Multiple DVR connection
Etc.
Supports User friendly GUI and mouse function
Easy and simple firmware upgrade thru. USB memory
Recorded data back up thru. USB port
PTZ Control (SPEED DOME), PRESET fucntion
Available to control up to 16 DVRs with one remote controller

Install&User Manual
12
Install Manual
1. Feature
1.1 Supplied Accessories
Unpack and check all the items as below
1.1.1. T1600M/T800M/T400M Series
AC Cord, Remocon, Setup CD, SATA Cable, HDD Fixing Screw, Quick Guide

Install&User Manual
13
1.1.2. T1600Q/T800Q Series
AC Cord, Remocon, Setup CD, SATA Cable, HDD Fixing Screw, Quick Guide

Install&User Manual
14
1.2. Description & Function
1.2.1. Front
1.2.1.1. T1600M/T800M/T400M Series Front
1
2 9 12 15 3 20 4
22 6 7 8 10
11
13 16 18 17 19 5
14 21
Item
Description
1
DVD-Multi (For
Back up)
Back up use for recorded data by DVD/CD media
2
Channel Button
To select video input channel
3
REC LED
Displays recording status
COPY LED
Displays copy status
HDD LED
Displays HDD running.
NETWORK LED
Displays network connection
EVENT LED
Displays event detection
4
Power
Turn on/ off power
5
USB port
Use connecting USB memory or Mouse
6
REC
To start or stop manual recording
7
Multi
To change DVISION in live or playback mode
8
SEQ
To run or stop user sequence
9
Copy
To enter copy mode
10
Search
To enter search mode
11
PTZ
To start PTZ function or stop
12
Func
To enter function mode
13
Relay
Manual On/Off button for relay

Install&User Manual
15
14
Mon
To change Monitor/ Stop
15
Menu
To enter menu
16
ESC
To escape from menu or close pop-up window
17
Enter/Play
To enter playback mode or select menu
18
◀/REW
To move or select in menu and change replay speed to
reverse direction in playback mode
19
▶/FWD
To move or select in menu and change replay speed to
forward direction in playback mode
20
▲/Pause
To move or select in menu and pause live/ replay video
21
▼/Stop
To stop replay in playback mode
22
Jog/ Shuttle
STEP function control, Playback direction change,
Playback speed control

Install&User Manual
16
1.2.1.2. T1600Q/T800Q Series Front
1
2 9 12 15 3 20 4
6 7 8 10
11
13 16 18 17 19 5
14 21
Item
Description
1
DVD-Multi (For
Back up)
Back up use for recorded data by DVD/CD media
2
Channel Button
To select video input channel
3
REC LED
Displays recording status
COPY LED
Displays copy status
HDD LED
Displays HDD running.
NETWORK LED
Displays network connection
EVENT LED
Displays event detection
4
Power
Turn on/ off power
5
USB port
Use connecting USB memory or Mouse
6
REC
To start or stop manual recording
7
Multi
To change DVISION in live or playback mode
8
SEQ
To run or stop user sequence
9
Copy
To enter copy mode
10
Search
To enter search mode
11
PTZ
To start PTZ function or stop
12
Func
To enter function mode
13
Relay
Manual On/Off button for relay
14
Mon
To change Monitor/ Stop
15
Menu
To enter menu
16
ESC
To escape from menu or close pop-up window
17
Enter/Play
To enter playback mode or select menu

Install&User Manual
17
18
◀/REW
To move or select in menu and change replay speed to
reverse direction in playback mode
19
▶/FWD
To move or select in menu and change replay speed to
forward direction in playback mode
20
▲/Pause
To move or select in menu and pause live/ replay video
21
▼/Stop
To stop replay in playback mode

Install&User Manual
18
1.2.2. Rear
1.2.2.1. T1600M/T800M/T400M Series REAR
15
21
14
3
13 12 10 9 7
4 5 6
11 9
Com1/
RS-232
번호
Input/ Output name
Descrtiption
1
Ground
Ground between DVR & external device
2
CH1~16
BNC input for camera connection
HVRM-T1600M : 16EA, HVRM-T800M : 8EA, HVRM-
T400M : 4EA
3
Loop out
BNC output(Loop) for camera connection
4
Monitor/ Spot
BNC connection for monitor output
5
Audio Input(RCA)
RCA connection for Audio input
6
Audio Output
Speaker output terminal
7
Ethernet
For network connection (RJ-45)
8
eSATA
eSATA external storage connection
9
DVI OUTPUT
Output for DVI monitor connection
10
RS-232C D-Sub
Text equipment, Keyboard connection
11
Termination Ohm
Termination Ohm for Com2, Com3
12
Relay/Serial
Connection for Relay and Serial(RS-485)
13
Sensor IN
Input for external sensor
14
FAN
Cooling system against over heating

Install&User Manual
19
번호
Input/ Output name
Descrtiption
1
Ground
Ground between DVR & external device
15
Power connector
Socket for AC100V~AC240V power cord
