Hunter I-40 User manual

ARC ADJUSTMENTS
(N O N -OPPO S I N G N OZZL E M O DE L)
All I-40 group adjustable heads are preset to approximately 180°.
Sprinklers may be adjusted with water on or o. It is recommended
that initial adjustment be made before installation.
1. Using the palm of your hand, rotate the nozzle turret counter -
clockwise to left stop to complete any interrupted rotation cycle
(Fig. 1).
2.
side of the arc.The nozzle turret must be held in this position
for all arc adjustments.
To I ncrease Arc
1. Insert the key end of the Hunter wrench into the adjustment
socket (Figs. 2 & 3).
2. While holding the nozzle turret at the right stop, turn the
wrench clockwise. Each 360° turn of the wrench increases the
arc 45°.
3. Adjust to any arc between 50° and 360°.
4. Wrench will stop turning, or there will be a ratcheting noise,
when the maximum arc (360°) is reached.
5. When set to 360°, the sprinkler will rotate continually
counterclockwise.
To Decrease Arc
1. Insert the key end of the Hunter wrench into the adjustment
socket (Figs. 2 & 3).
2. While holding the nozzle turret at the right stop, turn the
wrench counterclockwise. Each 360° turn of the wrench
decreases the arc 45°.
3. Adjust to any arc between 50° and 360°.
4. Wrench will stop turning, or there will be a ratcheting noise,
when the minimum arc (50°) is reached.
Radius Adjustment
Insert the hex end of the Hunter wrench into the nozzle-retainer/
range-adjustment screw (Figs. 2 & 3).Turn the screw clockwise
into the stream of water to decrease the radius, or counterclockwise
to increase the radius.
P recipitation Rate Adjustment
Where excessively wet or dry areas are a problem, the
precipitation rate may be adjusted. Simply replace the existing
nozzle with a larger one to increase or a smaller one to decrease
the rate of precipitation.
Nozzle I nstallation
1. Insert the key end of the Hunter wrench into the lifting socket
of a pop-up sprinkler. Pull the riser up to gain access to the
nozzle socket.
2. Using the Hunter wrench, loosen the nozzle-retainer/range-
adjustment screw. If a nozzle is already installed in the
the water.
3. Discard nozzle if removed with pliers. Slip the desired nozzle
into the nozzle socket. Note that the socket is angled up 25°
(see Fig. 4).Tighten the nozzle-retainer/range-adjustment screw.
Institutional Series ™
I -40
Gear-Driven Sprinklers
Fig. 1
®
Fig. 2
Nozzle
Retainer/
Range
Adjustment
Scre w
Arc Adjustment
So cke t
Fig. 3
Lift Up
So cke t
Recess
for Nozzl e
ID Button
SS
43
I40
Arc Adjustment
Direction
®
I-40
ADS
Fig. 4
Water
ow
NO N-S TR IPPABLE BACKDR IVE
This sprinkler is designed with an internal device that prevents
damage to the internal gear drive if it should be turned by
vandals.This important feature works when the nozzle turret
is turning in either direction.This makes the sprinkler very
durable in all applications.
AUTO ARC RETUR N
This sprinkler is designed with an internal device that re-aligns
the arc if it is turned by vandals.This important feature works
when the nozzle turret is turning in either direction.When
forced outside of the originally set arc, the sprinkler takes the
shortest path back to the pattern without going completely
around.This saves the non-irrigated areas from getting wet!
Always a good thing!

C ORRECT I NS TALLAT ION
Each nozzle can be identif ied by
the number of raised r idges on th e
inside surf ace of the nozzle .
Ex ample: 2 r idges = # 42 nozzle
IDE NTIFY ING NOZZLE NUMBER S
I-40 = 3 minut es (appr ox.)
I-40 High Speed = 1 minut e (appr ox.)
F ULL CI RCLE R OTAT ION SPEED
I-40
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
40
40
50
60
45'
46'
46'
7.0
8.0
8.5
0.67
0.73
0.77
0.77
0.84
0.89
41
50
60
70
80
50'
51'
52'
53'
10.2
11.1
12.1
13.0
0.79
0.82
0.86
0.89
0.91
0.95
0.99
1.03
42
50
60
70
80
51'
53'
55'
56'
11.0
12.3
13.1
13.9
0.81
0.84
0.83
0.85
0.94
0.97
0.96
0.99
43
50
60
70
80
56'
57'
59'
61'
13.5
15.1
16.1
17.5
0.83
0.89
0.89
0.91
0.96
1.03
1.03
1.05
44
60
70
80
90
63'
65'
66'
67'
20.0
21.8
23.4
24.9
0.97
0.99
1.03
1.07
1.12
1.15
1.19
1.23
45
60
70
80
90
66'
68'
69'
70'
22.7
24.7
26.4
28.2
1.00
1.03
1.07
1.11
1.16
1.19
1.23
1.28
I-40 High Speed
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
40
40
50
60
41'
42'
42'
7.0
8.0
8.5
0.80
0.87
0.93
0.93
1.01
1.07
41
50
60
70
80
44'
44'
45'
46'
10.2
11.1
12.1
13.0
1.01
1.10
1.15
1.18
1.17
1.27
1.33
1.37
42
50
60
70
80
46'
47'
49'
50'
11.0
12.3
13.1
13.9
1.00
1.07
1.05
1.07
1.16
1.24
1.21
1.24
43
50
60
70
80
51'
52'
52'
53'
13.5
15.1
16.1
17.5
1.00
1.07
1.15
1.20
1.15
1.24
1.32
1.38
44
60
70
80
90
58'
58'
60'
60'
20.0
21.8
23.4
24.9
1.14
1.25
1.25
1.33
1.32
1.44
1.44
1.54
45
60
70
80
90
60'
62'
64'
65'
22.7
24.7
26.4
28.2
1.21
1.24
1.24
1.28
1.40
1.43
1.43
1.48
I-40 Dual Opposing
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
15
Gray
50
60
70
80
52'
54'
56'
57'
13.0
13.2
14.4
15.5
0.46
0.44
0.44
0.46
0.53
0.50
0.51
0.53
18
Red
50
60
70
80
58'
59'
60'
62'
13.7
15.2
16.6
17.8
0.39
0.42
0.44
0.45
0.45
0.49
0.51
0.51
20
Dk. Brown
60
70
80
90
63'
64'
66'
66'
19.1
20.9
22.3
23.9
0.46
0.49
0.49
0.53
0.53
0.57
0.57
0.61
23
Dk. Green
60
70
80
90
65'
66'
67'
68'
20.4
22.3
24.0
25.6
0.46
0.49
0.51
0.53
0.54
0.57
0.59
0.62
25
Dk. Blue*
60
70
80
90
66'
68'
69'
70'
22.0
24.0
25.9
27.2
0.49
0.50
0.52
0.53
0.56
0.58
0.60
0.62
28
Black
70
80
90
100
70'
72'
74'
76'
28.9
30.9
32.9
33.7
0.57
0.57
0.58
0.56
0.66
0.66
0.67
0.65
Institutional Series ™
I -40
Gear-Driven Sprinklers
I-40
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
40
2.5
3.0
3.5
4.0
4.5
5.0
248
303
352
400
448
496
13.4
13.7
14.0
14.0
14.0
14.3
1.52
1.68
1.80
1.92
2.03
2.13
25.4
28.0
30.0
32.0
33.8
35.5
17
18
18
20
21
21
20
21
21
23
24
24
41
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
14.9
15.2
15.5
15.5
15.8
16.2
2.16
2.33
2.49
2.64
2.79
2.95
36.0
38.9
41.5
44.1
46.5
49.1
19
20
21
22
22
23
22
23
24
25
26
26
42
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
15.2
15.5
16.2
16.5
16.8
17.1
2.37
2.54
2.71
2.87
3.01
3.17
39.4
42.4
45.2
47.8
50.2
52.9
20
21
21
21
21
22
24
24
24
24
25
25
43
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
16.8
17.1
17.4
17.7
18.0
18.6
2.87
3.11
3.33
3.55
3.75
3.97
47.9
51.8
55.6
59.1
62.4
66.1
20
21
22
23
23
23
24
25
26
26
27
26
44
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
19.2
19.5
19.8
20.1
20.1
20.4
4.47
4.75
5.02
5.31
5.56
5.80
74.4
79.1
83.6
88.5
92.6
96.6
24
25
26
26
27
28
28
29
30
30
32
32
45
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
20.1
20.4
20.7
21.0
21.3
21.6
5.07
5.38
5.68
6.01
6.28
6.55
84.4
89.7
94.7
100.2
104.7
109.1
25
26
26
27
28
28
29
30
31
31
32
32
I-40 High Speed
Nozzle Performance Data – Metric
Pressure Radius Flow
Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
40
2.5
3.0
3.5
4.0
4.5
5.0
248
303
352
400
448
496
13.4
13.7
14.0
14.0
14.0
14.3
1.52
1.68
1.80
1.92
2.03
2.13
25.4
28.0
30.0
32.0
33.8
35.5
17
18
18
20
21
21
20
21
21
23
24
24
41
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
13.1
13.4
13.4
13.4
13.7
14.0
2.16
2.33
2.49
2.64
2.79
2.95
36.0
38.9
41.5
44.1
46.5
49.1
25
26
28
29
30
30
29
30
32
34
34
35
42
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
13.7
14.0
14.3
14.6
14.9
15.2
2.37
2.54
2.71
2.87
3.01
3.17
39.4
42.4
45.2
47.8
50.2
52.9
25
26
26
27
27
27
29
30
30
31
31
32
43
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
14.9
15.5
15.8
15.8
15.8
16.2
2.87
3.11
3.33
3.55
3.75
3.97
47.9
51.8
55.6
59.1
62.4
66.1
26
26
27
28
30
30
30
30
31
33
34
35
44
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
17.7
17.7
17.7
18.3
18.3
18.3
4.47
4.75
5.02
5.31
5.56
5.80
74.4
79.1
83.6
88.5
92.6
96.6
29
30
32
32
33
35
33
35
37
37
38
40
45
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
18.3
18.6
18.9
19.5
19.8
19.8
5.07
5.38
5.68
6.01
6.28
6.55
84.4
89.7
94.7
100.2
104.7
109.1
30
31
32
32
32
33
35
36
37
36
37
39
I-40 Dual Opposing
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
15
Gray
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
15.2
15.8
16.2
16.8
17.1
17.4
2.75
2.91
3.06
3.20
3.32
3.46
45.8
48.5
51.0
53.3
55.4
57.7
12
12
12
11
11
11
14
13
14
13
13
13
18
Red
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
17.4
17.7
18.0
18.0
18.3
18.9
2.90
3.15
3.38
3.61
3.82
4.05
48.3
52.5
56.4
60.1
63.7
67.5
10
10
10
11
11
11
11
12
12
13
13
13
20
Dk. Brown
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
18.9
19.2
19.5
20.1
19.8
20.1
4.26
4.54
4.80
5.08
5.32
5.55
71.1
75.6
80.0
84.7
88.7
92.5
12
12
13
13
14
14
14
14
15
15
16
16
23
Dk. Green
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
19.5
19.8
20.1
20.4
20.7
20.7
4.55
4.85
5.14
5.45
5.71
5.96
75.8
80.8
85.6
90.8
95.1
99.4
12
12
13
13
13
14
14
14
15
15
15
16
25
Dk. Blue*
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
20.1
20.4
20.7
21.0
21.3
21.3
4.92
5.23
5.52
5.84
6.10
6.36
82.1
87.2
92.0
97.3
101.7
106.0
12
13
13
13
13
14
14
14
15
15
15
16
28
Black
4.5
5.0
5.5
6.0
6.5
7.0
448
496
552
600
648
696
21.0
21.3
21.9
22.3
22.6
23.2
6.38
6.68
7.00
7.27
7.52
7.76
106.4
111.3
116.7
121.1
125.3
129.4
14
15
15
15
15
14
17
17
17
17
17
17
* Factory-installed nozzle
eerged081rofdetaluclacerasetarnoitatipicerpllA:etoN
operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
This manual suits for next models
1
Other Hunter Control Unit manuals

Hunter
Hunter A2C-LTE User manual

Hunter
Hunter Hydrawise WAND User manual

Hunter
Hunter ACC-COM-LTE User manual

Hunter
Hunter CELL-KIT User manual

Hunter
Hunter PCM-1600 User manual

Hunter
Hunter Hydrawise WAND User manual

Hunter
Hunter HYDRAWISE X2 User manual

Hunter
Hunter WVOM User manual

Hunter
Hunter 99120 User manual

Hunter
Hunter DUAL 48M Operating instructions
