A2C-LAN INSTALLATION GUIDE
LAN Module for Hunter ACC2 Controllers
INSTALLATION
1. Turn o the controller power.
2. Tilt the facepack. Then remove the facepack from the larger
panel to access the bottom area of the facepack.
3. Remove cover (or prior module) from the controller
facepack. Press the spring-loaded button and pull
downward to remove.
4. Slide the new A2C-LAN module in until the lock clicks.
LAN ETHERNET CONNECTION
1. Insert the network cable into the enclosure. Route the cable
through the cable channel on the back of the facepack.
2. Connect the network jack (RJ-45 or 8P8C) into the receiver
on the A2C-LAN module. Route the LAN cable through the
cable channel on the back of the facepack. Leave enough
slack in the network cable to allow the door to open and
close without pinching the cable.
3. Turn on the controller power. Aer the controller
reboots, the networking icon should appear on the
bottom of the Home screen.
NETWORKING
Once the LAN cable is connected to the network and the
networking icon appears with a green light on the Home
screen, proceed directly to the Soware Setup section.
Push up
SOFTWARE SETUP
1. From the Main Menu icon in the
soware, select Add Controller.
2. Follow the on-screen instructions to
add your controller. Aer entering the
required information, the soware
will send a Controller Verication
Code for security purposes.
3. Go to the controller menu for Settings. Select Controller
Verication.
4. Enter the code number that appears at the Controller
Verication screen into the soware setup screen.
5. If the Verication Code is correct, the controller will be
added to the soware and the map.
6. The networking icon on the Home screen of the controller
should now have a green status icon.
TROUBLESHOOTING
Network Test
The Network Test function will check all connections from the
controller, through the router, to the server. If the controller is
not communicating, this will indicate which functions are not
performing.
Note: Sometimes, turning the controller power o and back on
can restore or x network connections.
STATIC IP
We don’t recommend assigning a static IP address to a LAN
module, but some networks may require this. Consult with the
host network information service administrator for the exact
settings to enter, if this is required.
Network Connection
Green
Status Icon

COMPLIANCE AND APPROVALS
Hunter Industries hereby declares that this product is in
compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU (Radio Equipment
Directive). Contact Hunter Industries for complete
compliance information.
FCC Notice
This equipment has been tested and found to comply with
the limits for a Class B digital device pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment o and on, you are encouraged to try to
correct the interference by taking one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that of which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
This device complies with part 15 of FCC rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modications not expressly approved by Hunter
Industries could void the user’s authority to operate this device.
If necessary, consult a representative of Hunter Industries Inc.
or an experienced radio/television technician for additional
suggestions.
To satisfy FCC RF Exposure requirements for mobile and base
station transmission devices, a separation distance of 20 cm
or more should be maintained between the antenna of this
device and persons during operation. To ensure compliance,
operation at closer than this distance is not recommended. The
antenna(s) used for this transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Innovation, Science and Economic Development Canada
(ISED) Compliance Notice
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage, et
2. L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
Certicate of Conformity to European Directives
Hunter Industries declares that the irrigation
controller complies with the standards of
the European Directives of “electromagnetic
compatibility” (2014/30/EU), “low voltage” (2014/35/EU) and
“radio equipment” (2014/53/EU).
This symbol means the product must not be discarded
as household waste and should be delivered to an
appropriate collection facility for recycling. Proper
disposal and recycling help protect natural resources, human
health, and the environment. For more information on disposal
and recycling of this product, contact your local municipality,
disposal service, or the shop where you bought this product.
RC004IGA2CLAN 10/19
RESIDENTIAL & COMMERCIAL IRRIGATION |Built on Innovation®
Learn more. Visit hunterindustries.com
For complete setup information, scan the QR code or visit hunterindustries.com.
