Huntleigh Smartsigns Compact SC750 User manual

SC750
Smartsigns®
Compact

2
Table of Contents
Contents
1. Quality, Reliability & Safety ........................................ 5
1.1 Cautions.................................................................................. 5
2. Introduction ................................................................ 7
2.1 Contents ................................................................................. 7
2.2 Front Panel Controls and Indicators ...................................... 9
2.3 Rear Panel Features ............................................................... 10
2.4 Patient Inputs.......................................................................... 11
2.5 Display .................................................................................... 11
2.6 Touch Screen .......................................................................... 14
3. Preliminary Checks .................................................... 15
3.1 Installation .............................................................................. 15
3.2 Line Power Operation.............................................................. 15
3.3 Battery Operation and Low Battery Alarm.............................. 15
3.4 Fuses ...................................................................................... 15
4. Specifications ............................................................ 16
4.1 Equipment Classification ....................................................... 16
4.2 General ................................................................................... 16
4.3 Environmental ......................................................................... 17
4.4 Monitoring Functions.............................................................. 17
4.5 Accessories ........................................................................... 19
4.6 System Connectors ................................................................ 20
4.7 Equipment Markings .............................................................. 21
5. Operation.................................................................... 22
5.1 General ................................................................................... 22
5.1.1 Switch On.......................................................................................... 22
5.1.2 The Initial Display .............................................................................. 22
5.1.3 SETUP ............................................................................................... 24
5.1.3.1 SYSTEM...........................................................................................24
5.1.3.1.1 Lang – Set Language..............................................................25
5.1.3.1.2 Set Time and Date..................................................................25
5.1.3.1.3 Suspend – Set Alarm Suspend Period....................................25
5.1.3.1.4 Brilliance .................................................................................25
5.1.3.1.5 QRS Volume ...........................................................................25
5.1.3.1.6 Alarm Volume ......................................................................25
5.1.3.1.7 Demo Mode............................................................................25
5.1.3.1.8 Exiting the System Screen .....................................................26
5.1.3.2 PATIENT ...........................................................................................26
5.1.3.3 RECORDER .....................................................................................27
5.1.3.4 Parameter Setup .............................................................................27
5.1.3.5 Trace Speed ....................................................................................27
5.1.3.6 TRENDS...........................................................................................28
5.1.3.7 ALARM SETUP.................................................................................28
5.1.3.8 Tick
√ Button....................................................................................28

3
Table of Contents
5.1.4 SUSPEND.......................................................................................... 29
5.1.5 TRENDS ............................................................................................ 29
5.1.5.1 Trend Period Selection ....................................................................30
5.1.5.2 Trend Display Mode ........................................................................30
5.1.6 SPOT Mode....................................................................................... 31
5.1.7 Freeze Trace ..................................................................................... 32
5.1.8 RECORD GO/STOP ........................................................................... 32
5.1.9 Time/Date Display & Battery Indicator.............................................. 32
5.1.10 Touch screen Enable / Disable ........................................................ 32
5.1.10 Switching Off ................................................................................... 32
5.2 ECG Monitoring....................................................................... 33
5.2.1 Electrode Application for ECG Monitoring ........................................ 33
5.2.2 ECG SETUP....................................................................................... 34
5.2.2.1 Lead ................................................................................................34
5.2.2.2 Gain .................................................................................................35
5.2.2.3 Mode ...............................................................................................35
5.2.2.4 Filter.................................................................................................35
5.2.2.5 QRS Beep........................................................................................35
5.2.2.6 1mV .................................................................................................35
5.2.2.7 DUAL ...............................................................................................35
5.2.2.8 HR ALARM SETUP – Heart Rate Alarm Setup .................................35
5.2.2.8.1 High and Low Alarm Settings and Suspend ............................36
5.2.2.8.2 Auto Limit .................................................................................36
5.2.2.8.3 Use Defaults.............................................................................36
5.2.2.8.4 Tick √Button ............................................................................36
5.2.2.9 Exiting..............................................................................................36
5.3 SpO2 Monitoring..................................................................... 37
5.3.1 Attaching and Removing Sensor ...................................................... 37
5.3.2 SpO2 Readout .................................................................................. 37
5.3.3 Interference....................................................................................... 38
5.3.4 SpO2 SETUP ..................................................................................... 38
5.3.4.1 Parameter........................................................................................39
5.3.4.2 Pulse Beep ......................................................................................39
5.3.4.3 O2 ALARM SETUP and PR ALARM SETUP .....................................39
5.3.4.3.1 High and Low Alarm Settings and Suspend ............................39
5.3.4.3.2 Auto Limit .................................................................................39
5.3.4.3.3 Use Defaults.............................................................................40
5.3.4.3.4 Tick √Button ............................................................................40
5.3.4.4 Exiting..............................................................................................40
5.4 Respiration Monitoring ........................................................... 41
5.4.1 Electrode Application for RESP Monitoring....................................... 41
5.4.2 RESP SETUP ..................................................................................... 42
5.4.2.1 Parameter........................................................................................42
5.4.2.2 Sens ................................................................................................43
5.4.2.3 BR ALARM SETUP ...........................................................................43
5.4.2.3.1 High and Low Alarm Settings and Suspend ............................43
5.4.2.3.3 Use Defaults.............................................................................43
5.4.2.3.4 Tick √Button ............................................................................44
5.4.2.4 Exiting..............................................................................................44

4
Table of Contents
5.5 Temperature Monitoring ......................................................... 44
5.5.1 TEMP SETUP..................................................................................... 45
5.5.1.1 T1 ALARM SETUP and T2 ALARM SETUP.......................................45
5.5.1.1.1 High and Low Alarm Settings and Suspend ............................46
5.5.1.1.2 Auto Limit .................................................................................46
5.5.1.1.3 Use Defaults.............................................................................46
5.5.1.1.4 Tick √Button ............................................................................46
5.5.1.2 Exiting..............................................................................................46
5.6 Non-invasive Blood Pressure (NIBP) Monitoring ................... 47
5.6.1 Connecting the Cuff to the SC750.................................................... 48
5.6.2 NIBP SETUP ...................................................................................... 48
5.6.2.1 Mode ...............................................................................................49
5.6.2.2 Cycle................................................................................................49
5.6.2.3 Start Pressure..................................................................................49
5.6.2.4 ENABLE CALIBRATION MODE ........................................................49
5.6.2.5 SYS ALARM SETUP .........................................................................50
5.6.2.6 DIA ALARM SETUP ..........................................................................50
5.6.2.7 MAP ALARM SETUP ........................................................................51
5.6.3 Operational Error Messages ............................................................. 51
5.7 Alarms .................................................................................... 52
5.7.1 Altering & Viewing Alarms ................................................................ 52
5.7.2 Alarm Activation................................................................................ 52
5.7.3 Alarm Sounds and Indications.......................................................... 52
5.7.4 Factory Alarm Priority Settings ......................................................... 53
5.7.5 Technical Alarms............................................................................... 53
5.7.6 Alarm Ranges & Default Settings ..................................................... 54
5.8 The Printer/Recorder ............................................................... 55
5.8.1 Paper Loading................................................................................... 55
5.8.2 Recording Procedure........................................................................ 56
5.8.3 Recorder Set Up ............................................................................... 56
5.8.4 Recorder Reset................................................................................. 56
6. Trouble Shooting ........................................................ 57
7. Maintenance............................................................... 58
7.1 Care of your Equipment.......................................................... 58
7.2 Cleaning and Disinfecting ...................................................... 58
7.3 Further Maintenance .............................................................. 60
8. Warranty & Service..................................................... 61

5
1. Quality, Reliability & Safety
Before using this equipment, please study this manual
carefully and familiarise yourself with the controls, display
features and operating techniques. Ensure each user fully
understands the safety and operation of the unit, as mis-use
may cause damage to the unit or injury to the user or the
patient.
This equipment has been manufactured using quality
components and designed to operate safely and reliably.
If the integrity of the protective earth conductor is in doubt, the
equipment should be operated from its internal electrical power
source.
All modifications and repairs to the equipment must carried out
by qualified service engineers, agents or hospital technicians
authorised by Huntleigh Healthcare.
CE MARKING
This equipment carries a CE mark but this is only fully valid if it is used
in conjunction with cables and other accessories approved by Huntleigh
Healthcare Ltd.
1.1 Cautions
Note The following are descriptions of general hazards and
unsafe practices that could result in death, severe injury
or product damage. Specific warnings and cautions not
appearing in this section are found throughout the manual.
Possible
Fire or
Explosion
A possible explosion hazard exists if used in the presence
of flammable anaesthetics. Explosion or fire can result.
Possible
Safety
Hazard
Do not mount the equipment directly above the patient.
Place the equipment in a location where it cannot harm the
patient should it fall from its shelf or other mount.
Possible
Electrical
Hazard
Do not operate the equipment using damaged cables and
wires, or loose snap fittings, which may cause interference
or loss of signal.
Perform frequent electrical and visual inspections on cables
and wires.
Possible
Shock or
Fire Hazard
Do not immerse any portion of the instrument in water.
Fluid spills may damage the instrument’s electrical
components.
Possible
Equipment
Damage
Do not sterilise this product. Sterilisation environments can
cause severe damage.
Do not autoclave or gas sterilise accessories unless
manufacturer instructions clearly approve it.
Quality, Reliability & Safety

6
Possible
Safety Risk
Do not substitute accessories. Use only recommended
accessories listed in this manual. Substitution may cause
the instrument to work improperly. The correct accessories
are shielded to prevent conductive parts of the electrodes
contacting other conductive parts or earth. No action
should be taken which permits this to happen.
Warning All interconnecting equipment must meet their relevant
safety standards i.e. EN60959 in the case of computers,
network terminals and display monitors. When several
pieces of equipment of various origins are interconnected,
the summation of leakage currents may constitute a
hazard.
Warning The accuracy of the readings obtained from this equipment
may be affected by the presence of a pacemaker or by
cardiac arrhythmia
Warning If it is thought that interference is occurring from or with
other equipment, such as that used for Diathermy, then
either shut-off, or move, the offending devices, increase the
separation or reduce lead lengths.
Warning If the integrity of the protective earth conductor arrangement
is in doubt, the equipment should be operated from its
internal electrical power source only while connected to a
patient. Use the mains supply only to re-charge the battery
while not connected to a patient
Caution Electromagnetic Compatibility (EMC). This product
complies with the requirements of applicable EMC
Standards. The use of accessories not specified by the
manufacturer may result in increased emissions by,
or decreased immunity of, the equipment, affecting its
performance.
Quality, Reliability & Safety
This product contains sensitive electronics; strong radio
frequency fields could interfere with the operation of the
system. In the event where this occurs, we suggest that the
source of interference is identified and the equipment is used
‘out of range’.
Do not use this equipment in the presence of flammable gases.
Do not immerse any part of the equipment in any liquids.
Do not use solvent cleaner on any part of the system.
Do not use high temperature sterilising or E-beam / gamma sterilisation
processes.
If any doubt exists concerning the use of this equipment, an
alternative method should be used.

7
Introduction
2. Introduction
The SC750 is a compact multi-parameter patient monitor which provides the
following monitoring capabilities:
• ECG (3 or 5 lead) • Respiration
• SpO2• Non Invasive Blood Pressure
• Temperature
A factory fit chart recorder can also be supplied.
The monitor is of fully moulded construction in a tough flame retardant ABS
material.
The TFT liquid crystal display (LCD), with touch screen, provides an easy to
operate monitor with clear presentation of patient information.
All controls, with the exception of the front panel ON/OFF switch, are software-
controlled.
The SC750 series weighs 3.3kg with battery, and may be powered from an
AC mains supply, from the integral rechargeable battery pack.
An optional mounting plate can be fitted to the underside of the SC750 to
enable the monitor to be mounted on a wall bracket or stand.
2.1 Contents
CHG
1 x SC750
1 x Instructions for Use CD
1 x Power Cord

8
Introduction
1 x Adult Finger Sensor
1 x SpO2Interface Cable
1 x ECG / RESP Patient Cable
Temperature Probes (optional)
1 x Surface
1 x Rectal
1 x Central
ECG / RESP
1 x NIBP Hose 1 x NIBP Standard Adult Cuff
NIBP

9
2.2 Front Panel Controls and Indicators
Fig. 1 Front panel indicators
1~
Green “~ “ ON Indicates mains power connected.
2 CHG Amber “CHG” ON Indicates that the internal battery is charging.
3Amber above the “On” / Off” button indicates the unit is
switched on.
CHG
Introduction
1
2
3
Recorder
1 x Chart Paper

10
2.3 Rear Panel Features
Fig. 2
1Mains Input Socket
2
I/O Sockets (from the top) :
• Ethernet Socket
• Serial Port
• Keyboard Socket
• External Monitor Socket
• Equipotential Earth Connector
3Integral Battery Access Cover
4Rating and Serial Number Label
o
I
Use only with a 250V fuse
Employer uniquement avec
un fusible de 250V
Use only with a 250V fuse
Employer uniquement avec
un fusible de 250V
Use only 250V fuses
Use only 250V fuses
1
2
3
4
Introduction

11
2.4 Patient Inputs
All patient inputs are fully isolated from electrical earth. ECG and respiration
rates are obtained via conventional electrodes and either a 3 or 5 way patient
cable. Temperature measurements are obtained via thermistor based
temperature sensors. Non-invasive Blood Pressure readings are gained
using a plethysmographic cuff technique with cuff inflation provided by an
internal pump. A pulse oximetry sensor is used to obtain SpO2 and pulse rate
readings.
Fig. 3
The side panel of the SC750 has the patient input connectors. These are:-
1SpO2 Pulse Oximeter input connector
2ECG 3/5 lead ECG connector (ECG & RESP)
3T1 Socket for Temperature probe (channel 1)
4T2 Socket for Temperature probe (channel 2)
5NIBP Connection to NIBP cuff
1
2
5
3
4
2.5 Display
The SC750 monitor display comprises a waveform area with numerical
readout boxes on the right-hand side and a set of touch buttons below. The
waveform area has an ECG trace at the top of the screen with a second ECG
trace line that can be enabled to cascade the top trace (with a 3 lead ECG
cable) or to show Lead II. The SpO2 trace comes next with the Respiration
trace below that. NIBP and temperature readings are at the bottom of the
display. The readouts, as shown in Fig.4, are clearly identified by caption and
colour.
Introduction

12
Fig. 4
The readouts are displayed as follows:
Lifesign Trace Description
ECG This is the top trace on the SC750 and may be displayed
as one or two traces. The beats per minute are presented
as a numeric display on the right of the top trace line.
Also displayed is selected lead, display gain and alarm
status.
SpO2 With the SpO2 probe plugged into the SC750 the SpO2
waveform is displayed as the next trace on the screen.
Summary digital values of SpO2% and pulse-oximeter
determined heart rate are continuously updated in
the patient summary on the right side of the screen.
Additionally, a horizontal bar graph above the digital
display indicates signal strength.
Respiration Respiration rate is determined by a thoracic impedance
method via the ECG electrodes. This cardiorespirogram
appears as a trace below SpO2.
Blood Pressure
NIBP
NIBP measurement uses the oscillometric method via a
cuff which is inflated and deflated through the monitor.
A bar graph is used to show the cuff pressure during
measurement and the blood pressure results are shown
numerically.
Temperature With two temperature sensors plugged into the SC750
both temperatures (T1 and T2) and the difference between
them (∆T) are continuously updated and displayed. If only
one sensor is connected the single temperature is shown.
Table 1
15
br/m
18 : 05
85%
40.0
50
11
°C
30.0
40.0
30.0
T1
T2
37.9
38.1
0.2
60
mmHg
AUTO 5
11 Apr 2005
160
50
MAP
DIA
SYS
SETUP SUSPEND TRENDS SPOT RECORD
GO/STOP
N
I
B
P
REC : OK (MANUAL)
ADULT
SOMEBODY
PATIENT REF
I
N
F
O
T
E
M
P
1 /cm
R
E
S
P
97
%bpm
100
92
90
30
S
P
O
2
Lead i (CASC)
E
C
G
60
Lead I bpm
x1
90
30
E
C
G
Introduction

13
The alarms in Table 2 below can be adjusted from within the appropriate
set-up screen. Individual alarms or all alarms may be muted for the preset
suspend period. When all alarms are muted the ‘INFO’ box displays the
message ‘SUSPEND’ and the remaining suspend time is indicated by a bar
graph or ‘∞’ if continuous muting is selected.The readouts are displayed as
follows:
Alarm Description HIGH LIMIT LOW LIMIT
MAX MIN MAX MIN
HEART
RATE
(ECG and
SpO2
Pulse
Rate)
High and low limits are
programmable in 1bpm steps. A
minimum separation of 5bpm is
maintained between the High and
Low values. Other ECG alarm
conditions are ASYSTOLE, LEAD
OFF, V LEAD OFF and INOP (out of
range signal).
250 35 245 30
%O2 High and low limits for Oxygen
saturation are programmable in steps
of 1%. The minimum separation
between the High and Low values is
5%.
100 55 90 50
T1 and
T2
The 2 temperature channels have
high & low limits programmable
in steps of 0.1°C. The minimum
separation between the High and
Low values is 0.5°C.
45.0 21 44.5 20.5
NIBP
Systolic
Diastolic
MAP
High & low limits are programmable
in steps of 1mmHg for Systolic,
Diastolic and Mean Average Pressure
(MAP). The minimum separation
between the High and Low values is
5mmHg.
250 10 245 5
RESP High and low limits are
programmable in steps of one unit.
The minimum separation between
the High and Low values is 5br/m.
An alarm condition occurs when
APNEA is detected or if there is a
poor connection.
125 9 120 4
Table 2
Introduction

14
Patient Information
Patient information, Name, Bed and Ref. No., which is displayed in the ‘INFO’
box, can be changed from the patient set-up screen.
All information, including alarm settings, are automatically retained when the
monitor is switched off. At switch on, patient information is displayed with
the options CHANGE DETAILS or CONTINUE. Selecting CHANGE DETAILS
produces a screen where the patient’s name and other information can be
altered (see section 4.1.3.2). If NEW PATIENT is selected from the PATIENT
screen all existing stored patient information is erased and the alarm limits are
set to the default values. Pressing the CONTINUE button will retain, not only
the patient information, but also current alarm settings.
Other Features
Lead select Leads I, II or III of the ECG 3 way patient cable may be
selected. With the five lead ECG option display of aVR,
aVL, aVF and V can also be chosen.
QRS indication A heart symbol is displayed on screen as part of the ECG
display and, if enabled, an audible tone is emitted.
Filtering A line frequency notch filter can be selected for the ECG
trace as well as Monitor or Diagnostic mode filtering.
Gain selection For ECG there are 4 gain settings and for Respiration 2
gain settings.
Trace freeze May be selected to examine the traces.
Digital displays Heart Rate, Temperatures, Respiration rate, SpO2, and
Blood Pressure are all displayed in digital form, as well as
their alarm limits
2.6 Touch Screen
Light finger pressure is all that is needed to operate any of the touch screen
buttons. Touching the numeric display boxes to the right of the traces will
bring up the appropriate SETUP screen. Touching an Alarm section to the
right of the numeric display box will disable/enable the specific alarm for the
SUSPEND period. It is possible to turn off the touch screen facility by pressing
the padlock icon at the bottom right hand corner of the screen. To re-activate
the touch screen press the padlock icon once more. If an alarm is triggered
the touch screen will be re-enabled automatically.
REC : OK (MANUAL)
ADULT
SOMEBODY
PATIENT REF
I
N
F
O
Introduction

15
3. Preliminary Checks
Preliminary Checks
Delivery Inspection
Huntleigh Healthcare Ltd takes every precaution to ensure that their goods
reach you in perfect condition. However, accidental damage can occur in
transit and storage. For this reason we recommend that a thorough visual
inspection is made immediately the unit is received. Should any damage be
evident or any parts missing, ensure that Huntleigh Healthcare Ltd is informed
at once.
Storage
Should the unit not be required for immediate use, it should be re-sealed in
its original packing, after carrying out the initial delivery inspection, and stored
under covered conditions at a temperature between -10 and 50 °C, and
relative humidity of 0-99% (non-condensing)
3.1 Installation
SC750 monitors are supplied with a plug-in mains lead, fitted with a 3 pin
mains plug. The cores use the European colour code :
BROWN LIVE
BLUE NEUTRAL
GREEN/YELLOW EARTH
If it becomes necessary to fit a new mains plug take care that the wires have
correct lengths, so that in the event of extreme strain, the earth wire will be the
last to break. Make sure that the cable clamp secures the outer sheathing so
that there is no direct strain on any individual wires at the terminals.
Where the plug is fused, a 5A fuse should be fitted.
3.2 Line Power Operation
No alterations are required to change between 100 and 240 Volt operation.
Connect the equipotential earth terminal to a potential equalisation conductor
where provided or mandatory. Connect the power cable to the line power
socket. If a good, reliable earth is not available operate the SC750 from its
internal battery pack while monitoring a patient.
3.3 Battery Operation and Low Battery Alarm
The battery, when fully charged will provide approximately 3 hours continuous
use. An on-screen battery indicator shows the state of charge at all times.
Battery charging takes place whenever the monitor is connected to the mains.
When the battery is discharging two flashing arrows >> point away from the
battery symbol. When the battery is charging two flashing arrows << point
towards the symbol. If the battery charge drops below 16% the indicator will
change colour from yellow to red and an alarm will sound.
3.4 Fuses
Fuses are fitted in both the power live and neutral lines. Correctly rated fuses
must be fitted as below:-
T1A 250VAC Littelfuse 0213001
Note: To isolate the SC750 from the mains or line supply, disconnect the
power cable from the mains inlet at the rear of the unit.

16
4. Specifications
Type of protection against
electric shock.
Class 1 and Internally powered equipment
Degree of protection
against electric shock
Type CF - equipment with an applied part, intended
for direct electrical connection to the heart. The
equipment is defibrillation discharge protected. The
SpO2 and non-invasive blood pressure defibrillation
discharge protection is provided by the applied
parts themselves and intrinsically by the probe and
blood pressure cuff.
The ECG module is designed with spark gaps to
minimise problems associated with stray currents
generated by defibrillation, diathermy etc.
Mode of operation. Continuous
Degree of protection
against harmful ingress of
water.
IPX1
Degree of safety of
application in the presence
of a flammable anaesthetic
Equipment not suitable for use in the presence
of a FLAMMABLE ANAESTHETIC MIXTURE
WITH AIR, OXYGEN OR NITROUS OXIDE
Electrosurgery Surgical
Equipment
This unit does not provide protection against HF
burning from other surgical equipment.
4.1 Equipment Classification
Supply voltage 100 to 240V 50/60Hz.
Fuse Type T2AH 250VAC (SCHURTER 0001-2707)
Power input 90 VA
Screen 8.4 inch diagonal high brightness TFT SVGA flat panel display
Trace speed 50, 25, 12.5 and 6.25mm per second for ECG and SpO2
waveforms. The Respiration waveform trace speed is 6.25mm per
second.
Trace freeze On all traces.
Battery 12V NiMH type with smart charger and fuel gauge type indication
of battery status. Approximately 3 hours of continuous monitoring
is available from a fully charged battery.
Size 240mm wide, 223mm high (including feet), 160mm deep
(including equipotential earth connector
Weight 3.3kg
Outputs 10/100 Ethernet socket (RJ45) for connection to Smartsigns Central
View, Serial port (9 pin ‘D’) for software upgrade for connection to
Huntleigh Healthcare BD4000, 6 way mini DIN for external keyboard
and a VGA socket for a slave monitor.
4.2 General
Specifications

17
4.3 Environmental
Operating Storage
10°C to 40°C Temperature range -10°C to 50°C
30% to 90% (non condensing) Relative Humidity 0% to 99% (non condensing)
860mb to 1060mb Pressure 860mb to 1060mb
ECG
Heart Rate range 15 – 300 BPM
Selectable leads I, II, or III with the standard 3 lead option.
I, II, III, aVR, aVL, aVF and V with the 5 lead option.
Selectable display
gain
0.5, 1, 2 or 4 times.
Lead fault detection Displays LEAD OFF warning for any of the 3/5 leads.
QRS indication Flashing heart symbol. Audible tone with volume control
/ off
Pacemaker indication ‘P’ symbol appears by the QRS ‘Heart’ and the trace
displays a positive 2cm pulse.
Esis/defibrillator
protection
Yes
Bandwidth 0.5 – 30 Hz (monitor mode), 0.05 – 100Hz (diagnostic
mode)
Filter 50Hz and 60Hz notch
Input impedance > 20MΩat 10Hz
Trend 1, 8 or 24 hour trend of ECG heart rate
Alarms High and Low heart rate, Asystole. Visual and audible
warning with optional latching.
SpO2
Range 0 – 99%
Resolution 1%
Accuracy Adult 70 - 99% ±2% Less than 70% undefined
Neonate 70 - 99% ±3% Less than 70% undefined
Averaging 8 beat average
Pulse rate range 30 – 254bpm, ±2bpm or ±2%
Patient input leakage < 10 μA
Trends 1, 8 or 24hour trend of SpO2%, and Pulse Rate.
Alarms SpO2 saturation, High (55 - 100%), and Low (50-95%).
Pulse Rate, High (250 - 25 BPM), and Low rate (245 - 20
BPM)
4.4 Monitoring Functions
Specifications

18
Respiration
Method Impedance measurement via the ECG chest electrodes.
Accuracy ±2% ±1 digit
Sensitivity 1Ω/cm; 3Ω/cm selectable.
Range 4 – 150 Resp/min.
Trends 1, 8 or 24 hour trend of respiration rate
Alarms Apnea, high and low rate.
Non-Invasive Blood Pressure
Range 30 to 280mmHg. Cuff over-pressure 300mmHg
Accuracy ±5mmHg with a standard deviation no greater than ±8mmHg
Display Systolic/diastolic and mean numerical display; graphical
manometer display during cuff inflation/deflation also graphical
bar display, with mean, on trend screen.
Automatic
repeat interval
In ‘Turbo’ mode continuous measurements are taken for a
period of five minutes. In ‘Automatic’ mode measurements
can be programmed to start at intervals of 2, 3, 4, 5, 10, 15,
30, 60 or 90 minutes.
Trends Graphical and tabular display of last 24 systolic, diastolic and
MAP readings.
Alarms Systolic, diastolic, MAP, High, and Low pressure with visual
and audible warning.
Temperature
Method Thermistor (YSI 400 series compatible)
Accuracy ±0.1°C ±1 digit
Display T1, T2 or T1, T2 & ∆T
Range 13°C – 47°C
Trends 1, 8 or 24 hour trend of T1 and T2
Alarms High and Low temperature on T1 and T2.
Recorder
Type Thermal array up to 24 dots/mm horizontally, 8 dots/mm vertically
Paper 50mm width x 30m long thermal roll
Speed 50, 25, 12.5, 6.25mm/s
Waveform Up to 4 as selected in the menu function.
Alarms Recorder will record on alarm if required
Specifications

19
4.5 Accessories
ECG / Respiration
Item Part No.
3 Way Trunk ACC-VSM-01
3 Way Combined ECG / RESP Patient Cable ACC-VSM-05
3 Way Fly Leadset RED, GREEN, YELLOW (Zero) ACC-VSM-06
5 Way Trunk ACC-VSM-146
5 Way Combined ECG / RESP Patient Cable ACC-VSM-147
5 Way Fly Leadset ACC-VSM-148
SpO2 Sensors
Item Part No.
Reusable Adult finger sensor ACC-VSM-171
Reusable Pediatric finger sensor ACC-VSM-170
Reusable Universal Y sensor ACC-VSM-169
Reusable Ear Sensor ACC-VSM-162
Reusable Infant Wrap sensor ACC-VSM-167
Reusable Neonate Wrap sensor ACC-VSM-168
Disposable Adult finger sensor ACC-VSM-163 (box 10)
Disposable Pediatric finger sensor ACC-VSM-164 (box 10)
Disposable Neonate finger sensor ACC-VSM-165 (box 10)
Disposable Infant finger sensor ACC-VSM-166 (box 10)
3 metre Extension cable ACC-VSM-188
NIBP
Item Part No.
Reusable Infant Cuff 8-13cm ACC-VSM-195
Reusable Child Cuff 12-19cm ACC-VSM-196
Reusable Small Adult Cuff 17-25cm ACC-VSM-197
Reusable Adult Cuff 23-33cm ACC-VSM-198
Reusable Large Adult Cuff 31-40cm ACC-VSM-199
Reusable Thigh Cuff 38-50cm ACC-VSM-200
Neonatal Hose 3.5M ACC-VSM-184
Adult Hose 3.5M ACC-VSM-185
Specifications

20
Temperature Sensors
Item Part No.
Central - Adult ACC-VSM-11
Central - Infant ACC-VSM-12
Central - Neonate ACC-VSM-13
Surface - Adult ACC-VSM-14
Surface - Infant ACC-VSM-15
Surface - Neonate ACC-VSM-16
Rectal - Adult (flange) ACC-VSM-17
Rectal - Infant (flange) ACC-VSM-18
Rectal - Neonate ACC-VSM-19
Adhesive Strap (pack 240) ACC-179
Recorder
Item Part No.
Chart Paper (10) ACC-VSM-39
Chart Paper (100) ACC-VSM-40
Hardware
Item Part No.
GCX Roll Stand ACC-VSM-153
Roll Stand & Wall Mount Fixing Kit ACC-VSM-152
GCX Wall Mount ACC-VSM-154
4.6 System Connectors
The SC750 may be connected to the Smartsigns® Central View Central
Station via the LAN socket situated on the rear panel. Contact Huntleigh
Healthcare for details prior to attempting this connection.
A set of normally open contacts across pins 2 & 6 on the keyboard socket can
be utilised for a “Nurse Call” or other facility in the event of an alarm.
Specifications
