Hydrotechnik MultiSystem 5060 User manual

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 1
Universal
Measuring
Instrument
MultiSystem 5060
Operating Manual
Version E1.1/061107
Back

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 2
Contents
1Safety................................................................................................................4
1.1 General Safety Advice and Warning Hints ........................................................4
1.2 Hinweise zum Umgang mit dem MultiSystem ...................................................4
1.3 Hints for the use of sensors and cables ............................................................5
1.4 Hints for the use of batteries .............................................................................5
1.5 Hints for the connection of printers....................................................................5
2Introduction .....................................................................................................6
2.1 Range of validity................................................................................................6
2.2 Copyright ...........................................................................................................6
2.3 Limitation of liability ...........................................................................................6
2.4 Use as agreed ...................................................................................................7
2.5 Warranty regulations .........................................................................................7
2.6 Obligations to the customer...............................................................................8
2.7 Authorized staff .................................................................................................8
3Description of the measuring instrument .....................................................9
3.1 Qualities of the MultiSystem 5060.....................................................................9
3.2 Connectors ......................................................................................................10
3.3 Display.............................................................................................................16
3.4 Keyboard .........................................................................................................17
3.5 Evaluation software .........................................................................................18
3.6 Technical data .................................................................................................18
4Startup............................................................................................................19
4.1 Check delivery.................................................................................................19
4.2 Range of delivery ............................................................................................19
4.3 Charge batteries..............................................................................................20
5Operation .......................................................................................................21
5.1 Switch the instrument on and off .....................................................................22
5.2 Select operation language...............................................................................23
5.3 Set date and time ............................................................................................24
5.4 Connect sensors .............................................................................................25
5.5 Enter sensor parameters.................................................................................25

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 3
5.6 Collect measuring data....................................................................................31
5.7 Connect PC and transfer measurement data..................................................33
5.8 Delete measurement data ...............................................................................34
5.9 Print measurement data ..................................................................................35
5.10 Reset instrument .............................................................................................36
6Operation software........................................................................................37
6.1 Display of the measured values ......................................................................37
6.2 Main menu.......................................................................................................38
6.3 Channel menu .................................................................................................39
6.4 Display menu...................................................................................................42
6.5 Memory menu .................................................................................................44
6.6 Device menu ...................................................................................................47
6.7 Project menu ...................................................................................................54
6.8 PASS menu.....................................................................................................55
6.9 Show menu (function key bar).........................................................................57
6.10 Delete menu ....................................................................................................62
7Special functions...........................................................................................63
7.1 Linearisation table ...........................................................................................63
7.2 Define CAN channel........................................................................................64
7.3 Graphic presentation in display menu .............................................................65
8Cleaning and maintenance...........................................................................66
8.1 Cleaning ..........................................................................................................66
8.2 Maintenance....................................................................................................67
8.3 Repair..............................................................................................................67

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 4
1 Safety
1.1 General Safety Advice and Warning Hints
• Never cut, damage or modify the connection cables of the power pack and do not
place things on it.
• Never touch the power pack with wet or moist hands.
• Only connect the power pack to power supplies for which it is suited (see technical
data).
• Unplug the mains cable during a thunderstorm.
• Unplug the mains cable if you determine smoke or smell, or if the mains cable is
damaged.
• Assure sufficient grounding of your installations. Inadequate grounding may lead to
measuring peaks.
1.2 Hinweise zum Umgang mit dem MultiSystem
• Never expose the instrument to excessive heat or moisture; obtain the technical
data.
• Do not store the instrument in humid or dusty locations or at temperatures below
freezing point.
• Never dip the instrument into water or other liquids. Never let liquids come into the
instrument.
• Never open the instrument.
• Do not use the instrument after it fell down or the housing is damaged.
• Avoid strong magnetic fields. Keep distance of electric motors or other instruments
that generate electro-magnetic fields. Strong magnetic fields may cause malfunc-
tions and influence measuring values.
• Avoid the formation of condensed water. If condensed water has formated you
should let the instrument acclimate before you switch it on. Otherwise it could be
damaged.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 5
1.3 Hints for the use of sensors and cables
• Protect the sensors from exceeding the allowed power range, mechnical overload
and wrong pin assignment.
• Assure to enter the sensor parameters correctly when using sensors without ISDS
(Intelligent Sensor Detection System).
• The measuring cables MK 01 and MKS may not be lengthened. Otherwise the
shielding will be interrupted.
• The data of an ISDS sensor are read into the measuring instrument during switch-
on procedure. If you connect new sensors, you will have to switch the instrument
off and on.
1.4 Hints for the use of batteries
• Keep batteries away from heat sources and open fire.
• Never dip batteries into water.
• Never short-circuit the contacts of batteries.
• Never dismount, repair or modify batteries.
• Use only batteries that are mounted or delivered by Hydrotechnik.
• Load only the battery while it is mounted in the instrument.
• Dispose used batteries as special waste. Cover the contacts with insulation tape.
1.5 Hints for the connection of printers
The measuring instrument supports printers with USB interface. Because of the great
variets of printers in the market, it is not possible to support all of them. Additionally,
the basic USB specifications are not fuliflled and maintained completely by all manu-
facturers.
This is why Hydrotechnik guarantees the full support of the printer "PIXMA iP 4200" of
Canon Inc., only. Please ask our customer service, whether your printer is supported.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 6
2 Introduction
2.1 Range of validity
The manual on hand is valid for measuring instruments named "MultiSystem 5060". It
adresses to the operator of this instrument, that means the person, who works with the
instrument.
The manual is not a technical manual. Please contact our service staff for questions,
that exceed the contents of this manual.
2.2 Copyright
The measuring instrument and this manual are protected on copyright. Manufacture
without license will be prosecuted by law. All rights reserved on this manual, even the
reproduction and/or duplication in any thinkable form, e.g. by photocopying, printing,
on any data recording media or translated. Reproduction of this manual is only permit-
ted with a written approval of Hydrotechnik GmbH.
The technical state by the time of delivery of instrument and manual is decisive, if no
other information is given. Technical changes without special announcements are re-
served. Earlier manuals are no longer valid.
The general conditions of sale and delivery of Hydrotechnik GmbH are valid.
2.3 Limitation of liability
We guarantee the faultless functioning of our product in accordance with our advertis-
ing, the product information edited by Hydrotechnik GmbH and this manual. Further
product features are not guaranteed. We take no liability for the economy and faultless
function if the product is used for a different purpose than that, described in the chap-
ter „Use as agreed“.
Compensation claims are generally impossible, except if intention or culpable negli-
gence by Hydrotechnik GmbH is proved, or if assured product features are not pro-
vided. If the product is used in environments, for which it is not suited or which do not
represent the technical standard, we are not responsible for the consequences.
Important hint
The information contained in this section
is important. If you neglect them, you
might loose possible guarantee de-
mands.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 7
We are not responsible for damages at installations and systems in the surroundings
of the product, which are caused by a fault of the product or an error in this manual.
We are not responsible for the violation of patents and/or other rights of third persons
outside the Federal Republic of Germany.
We are not liable for damages, which result from improper operation according to this
manual. We are not liable for missed profit and for consecuting damages due to non
regardance of safety advice and warning hints. We don’t accept liability for damages
which result from the use of accessoires which are not delivered and/or approved by
Hydrotechnik GmbH.
The products of Hydrotechnik GmbH are designed for a long life. They represent the
standard of technique and science and were checked on all functions individually be-
fore delivery. The electrical and mechanical construction corresponds to the current
norms and regulations. Hydrotechnik GmbH is doing product and market research for
the further development and permanent improvement of their products.
In case of faults and/or technical trouble please contact the Hydrotechnik GmbH ser-
vice staff. We assure that suitable measures will be taken immediately. Hydrotechnik
GmbH guarantee regulations are valid, which we will send to you on demand.
2.4 Use as agreed
The measuring instrument "MultiSystem 5060" is a mobile, hand-held instrument for
the recording, storage and evaluation of measurement data, collected by sensors con-
nected to the instrument.
You can connect a large variety of different sensors to the instrument, but they have to
meet the requirements defined in the section "Technical data".
Any other use of the measuring instrument is considered as not agreed.
If you have any question or want to use the measuring instrument for a different pur-
pose, please do not hesitate to contact our service staff. We are pleased to help you.
2.5 Warranty regulations
In accordance to our warranty regulations we guarantee the condition without defects
for this measuring instrument for a duration of six months. Wearing parts and storage

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 8
batteries are excepted from this warranty. The warranty is spoiled if repair work or in-
terventions are executed by unauthorized persons.
Within the warranty period we repair damage or defects which are caused by a manu-
facturing fault. We only accept warranty claims if they are reported to us immediately
after their discovery, but latest six months after delivery. The warranty benefit is by our
choice through repair of defective parts or replacement by intact parts.
Send your instrument with an invoice copy or delivery note copy to Hydrotechnik. The
adress is mentioned at the end of this manual.
2.6 Obligations to the customer
The operating authority of this product has to assure, that only persons who
• know the regulations on working safety and accident prevention
• have been instructed in the operation of this product
• have read and understood this manual
can operate this product. Persons who operate this instrument are obliged to
• obey all regulations on working safety and accident prevention
• read this manual completely, especially the safety instructions in the first chapter.
2.7 Authorized staff
Persons are authorized if they have a professional education, technical experience,
knowledge of the important norms and regulations and if they are able to estimate their
duties and recognize possible danger at an early time.
Operator of the instrument
Persons are authorized if they are trained in the operation of the instrument and have
read and understood this manual completely.
Personell for installation and maintenance
Persons are authorized if they are trained in all aspects of the instrument and have
read and understood this manual completely.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 9
3 Description of the measuring instrument
3.1 Qualities of the MultiSystem 5060
The MultiSystem 5060 is a practice-oriented, user-friendly hand-held measuring in-
strument supporting the user in the daily measuring functions.
When using ISDS sensors, the MultiSystem automatically detects the connected sen-
sors during initialisation and stores all parameters: measuring range, physical meas-
urand, measuring unit, signal output and characetristic curve (linearisation). A confu-
sion of the sensor and the entry of specific sensor data are things of the past.
You can connect sensors without ISDS designation to the MultiSystem 5060. The en-
try of the sensor parameters is then done in clear operation menus.
All measurements can be comfortably transferred to a PC using an USB cable. The
software HYDROcomsys/Win32 is delivered for free with the instrument and offers
comprehensive support with functions for the evaluation, presentation and printing of
the measured values.
You can connect up to eight sensors and store all measured values. Calculations from
the measured values as difference, sum and performance, and a first differentiation
(e.g. speed from distance) are available as additional special channels for display and
storage.
The buffering of extreme values of the minimum and maximum measurands is always
active and can be displayed by a few key pressures.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 10
3.2 Connectors
1 Input Ch1 – analog input highspeed 8 Input Ch8 – frequency input
2 Input Ch2 – analog input highspeed 9 USB – host interface
3 Input Ch3 – analog input 10 USB – device interface
4 Input Ch4 – analog input 11 Combi-jack CAN/Bootloader
5 Input Ch5 – analog input 12 Power supply – power pack
6 Input Ch6 – analog input 13 Digital input and output
7 Input Ch7 – frequency input
9 1
2
3
4
5
6
7
8
10 11
12
13

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 11
3.2.1 Characteristics of highspeed analog inputs
Number 2 (Ch1, Ch2)
Signal input switchable 0 – 20 mA / 4 – 20 mA / 0 – 10 V / ± 10 V / 0,5 – 4,5 V
Resolution 13-bit analog/digital converter (12-bit + sign)
Meas. rate 0.1 ms = 10 kHz
Filter function input filter 50 kHz (dynamic mode)
Hardware filter switchable: 5 kHz (standard mode) / 50 Hz (damped mode)
Software filter adjustable: mean value filter 1... 16 ms
Connector 6 pol. device plug
Prot. type IP40
Pin assignment
Pin Function Ri. Ci. Limitation Protection type
1 Signal I [mA] 110 Ω2 nF 5.6 V DC Transil diode
2 Mass
3 Ub* 100 mA Current limiting
4 Signal U [V] 22 kΩ2 nF ± 20 V DC Transil diode
5 Shield
6 ISDS
Ub*: power supply during mains operation 24 V

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 12
3.2.2 Characteristics of analog inputs
Number 4 (Ch3, Ch4, Ch5, Ch6)
Signal input switchable 0 – 20 mA / 4 – 20 mA / 0 – 10 V / ± 10 V / 0,5 – 4,5 V
Resolution 13-bit analog/digital converter (12-bit + sign)
Meas. rate 10 kHz
Filter function input filter 5 kHz (standard mode)
Hardware filter switchable: 50 Hz (damped mode)
Software filter adjustable: mean value filter 1... 16 ms
Connector 6 pol. device plug
Prot. type IP40
Pin assignment
Pin Function Ri. Ci. Limitation Protection type
1 Signal I [mA] 110 Ω2 nF 5.6 V DC Transil diode
2 Mass
3 Ub* 100 mA Current limiting
4 Signal U [V] 22 kΩ2 nF ± 20 V DC Transil diode
5 Shield
6 ISDS
Ub*: power supply during mains operation 24 V
3.2.3 Characteristics of frequency inputs
Number 2 (Ch7, Ch8) frequency/counter inputs with switchable direction detec-
tion
Signal input 5 – 30 VDC, 0.25Hz – 10 kHz
Filter function adjustable period measurement for averaging
Connector 6 pol. device plug
Prot. type IP40

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 13
Pin assignment
Pin Function Ri. Ci. Limitation Protection type
1 Frequency signal 4.75 kΩ1 nF 33 V DC VDR Transil diode
2 Mass
3 Ub* 100 mA PTC
4 Direction signal 4.75 kΩ1 nF 33 V DC VDR Transil diode
5 Shield
6 ISDS
Ub*: power supply during mains operation 24 V
3.2.4 Characteristics of digital trigger input
Pins of the digital input/output; the trigger input is isolated.
Pin assignment
Pin Function Ri. Ci. Limitation Protection type
3 Signal 4.75 kΩ1 nF 33 V DC VDR Transil diode
4 Mass
Attention
Damage to the instrument possible!
This input may not be connected directly to inductive loads (e.g. coil of a magnetic
valve). Otherwise the instrument may be damaged.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 14
3.2.5 Characteristics digital signal output
Jacks of the digital input/output.
Pin assignment
Pin Function Limitation Protection type
1 Signal Ub*/10 mA VDR Transil diode
2 Mass
3.2.6 Characteristics combi-jack CAN/Bootloader
8-pin Mini-DIN
Pin assignment
Pin Function
1 Mass
2 Ub* (power supply CAN sensor), max. 100 mA at mains operation
3 not used
4 CAN_H
5 TXD for Bootloader
6 RTS for Bootloader
7 CAN_L
8 RXD for Bootloader
Ub*: power supply during mains operation 24 V

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 15
3.2.7 Characteristics USB interfaces
USB type A: host interface
Function Designation Remarks
Signal D+ green twisted cable
Signal D– white twisted cable
(VCC) red not supported by MS 5060
Mass black –
USB type B: device interface
Function Designation Remarks
Signal D+ green twisted cable
Signal D– white twisted cable
VCC red delivers max. 500 mA from host for terminal
equipment power supply (not used by MS 5060)
Mass black –

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 16
3.3 Display
Das Messgerät verfügt über ein Farbdisplay, auf dem alle Informationen und Messwer-
te angezeigt werden. Grafikdarstellungen sind indivduell konfigurierbar.
In der untersten Zeile des Display können verschiedene Informationen als Icons ange-
zeigt werden:
Storage indicator indicates a running storage
red indicator pretrigger storage
green indicator trigger event not happened yet
yellow indicator storage
Timer timer triggering; the remaining time until the
trigger event is displayed beside the icon
Drucker printer detected at USB interface (host)
Highspeed hardware filter set for peak pressure measure-
ments to 10 kHz (highspeed mode)
USB instrument is connected to a PC via the USB
interface (device)
Battery
loading state of the battery; when the icon turns
red and start flashing, the batteries should be
charged immediately
Power pack instrument power supply with external power
pack; batteries are charged
In normal operation, either the battery or power pack icon is displayed. If the battery
icon flashes during mains operation, the batteries are either missing, defective or
deep-cycled. Possibly the battery cable isn't plugged correctly.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 17
3.4 Keyboard
The MS 5060 is equipped with a valuable membrane keyboard that is insensitive to
humidity and dirt. The 26 keys are occupied as follows:
Function key 1 Input 3 or DEF
Function key 2 Input 4 or GHI
Function key 3 Input 5 or JKL
Function key 4 Input 6 or MNO
Function key 5 Input 7 or PQRS
Switch instrument on Input 8 or TUV
Switch instrument off Input 9 or WXYZ
Highlight upward Input 0 or space*
Cursor / page to the left Input hyphen or point
Cursor / page to the right Open main menu
Highlight downward Cancel input without storing
Input 1 Store input
Input 2 or ABC Delete single digit
*: use the key "0" to enter special digits, e.g. ( ) * / @ ° …

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 18
3.5 Evaluation software
The evaluation software "HYDROcomsys/Win32" is part of the delivery. After trans-
missing the measuring data to a PC, you can use this software to evaluate, process
and present the data graphically.
3.6 Technical data
Casing ABS plastic
Weight 1.1 kg
Protection type IP40
CE-conformity EN 50 081-1 and EN 50082-1 – RoHS
Internal power supply NiMh-batteries, 14.4V / 2,150 mAh
External power supply 24 V DC / 630 mA
Dimensions 270 x 137 x 67 mm (L x W x H)
Interfaces USB 2.0, CAN
Ambient temperature -10 °C – 50 °C
Relative humidity 0 – 85% (not condensing)
Storage temperature -20 °C – 60 °C
Measured value display 5-digit
Trigger 2 channels as start/stop, or with the connections AND or
OR; time trigger
Scan rate selectable between 100 µsec and 10 min
Measuring rate Analog inputs 0.1 ms (10 kHz)
Frequency inputs 0.25 Hz to 10 kHz
Measuring value memory SD-card 128 MB
max. 200 series of measurements
max. 8MB per series of measurements (2 million values)
Error limits analog ± 0.15% of final value
digital ± 0.02 % of measured value (resolution 20 ns)

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 19
4 Startup
4.1 Check delivery
The measuring instrument is delivered by Hydrotechnik and transported by suited
shipping companies. At the time of delivery you should check:
• Does the number of delivered items corresponds with the Hydrotechnik delivery
note?
• Is the packing free of visible damage?
• Are measuring instrument and accessories free of visible damage?
• Are there any indications of rough treatment during transportation (e.g. burn
marks, scratches, color)?
To maintain all demands against the shipping company you should document all pos-
sible transportation damage (e.g. by taking photos and signing a written protocol), be-
fore you put the instrument into operation.
Hydrotechnik is not responsible for transportation damage and will take no liability.
4.2 Range of delivery
Carefully remove the transportation packing. Please obtain all rules and regulations for
the disposal of packing materials. After unpacking you should find the following parts:
• Measuring instrument MultiSystem 5060 3160-00-70.00
• CD with software HydroComsys Win32 8874-16-00.01
• Power pack, 230 VAC / 24 VDC, 625 mAh 8812-20-02.00
• USB data transmission cable 8824-F8-01.50
Check the range of delivery in accordance to the delivery note and the order docu-
ments. Report differences instantly to Hydrotechnik. Later claims on incomplete deliv-
ery cannot be accepted.

MultiSystem 5060
© Hydrotechnik GmbH • All rights reserved • VE1.1/061107 20
4.3 Charge batteries
Attention
Battery performance endangered!
Charge the instrument batteries for 14 to 16 hours before you put the instrument into
operation. Otherwise there is the danger of excessive discharge, which would influ-
ence the battery performance negatively.
Note
The battery integrated in the measuring instrument will be charged, as soon as the
instrument is supplied by a Hydrotechnik power pack.
The instrument is equipped with an internal battery. This is pre-charged by Hydrotech-
nik and must be charged for at least 14 to 16 hours, before the instrument can be
used.
Hints for the treatment of the batteries
The life cycle of NiMH cells can be very long, but it depends on the conditions of use.
Avoid a complete discharge, continuous charging and immediate re-charging after
every use. This triggers the memory effect with a minimization of the battery capacity
and possible remanent damage. You can regenerate the battery by several discharge
and charge cycles.
In case of low battery power a hint "Load batteries" will be displayed. In this case you
should maintain a 16 hour charging time. In case of longer periods without use you
should discharge and charge the batteries monthly.
