IBM 689912U - IntelliStation Z - Pro 6899 Owner's manual

This Manual Supports:
300 Series, Type
700 Series, Type
IntelliStation, Type
6272
6275
68XX
6888
6889
6893
6898
6899
6282
6284
6285
6561
6588
6591
65XX
6862
6892
S83G-7789-16
IBM Personal Computer
300 Series
700 Series
IntelliStation
Hardware
Maintenance
Manual
June 1998
We Want Your Comments!
(Please see page 449)

S83G-7789-16
IBM Personal Computer
300 Series
700 Series
IntelliStation
Hardware
Maintenance
Manual
June 1998
We Want Your Comments!
(Please see page 449)
IBM

Note
Before using this information and the product it
supports, be sure to read the general information
under “Notices” on page 458.
Seventeenth Edition (June 1998)
The following paragraph does not apply to the United
Kingdom or any country where such provisions are
inconsistent with local law: INTERNATIONAL
BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. Some states do not allow disclaimer of
express or implied warranties in certain transactions,
therefore, this statement may not apply to you.
This publication could include technical inaccuracies or
typographical errors. Changes are periodically made to
the information herein; these changes will be incorporated
in new editions of the publication. IBM may make
improvements and/or changes in the product(s) and/or the
program(s) described in this publication at any time.
It is possible that this publication may contain reference to,
or information about, IBM products (machines and
programs), programming, or services that are not
announced in your country. Such references or
information must not be construed to mean that IBM
intends to announce such IBM products, programming, or
services in your country.
Requests for technical information about IBM products
should be made to your IBM reseller or IBM marketing
representative.
 Copyright International Business Machines
Corporation 1996, 1997, 1998. All rights reserved.
Note to U.S. Government users–Documentation related to
Restricted rights–Use, duplication, or disclosure is subject
to restrictions set forth in GSA ADP Schedule Contract
with IBM Corp.
ii IBM PC 300/700, IntelliStation Series HMM

About This Manual
This manual contains service and reference information for
IBM Personal Computer 300 Series, 700 Series, and the
Professional Workstation IntelliStation products.
The manual is divided into two sections as follows:
The service section includes procedures for isolating
problems to a FRU, a Symptom-to-FRU Index, related
service procedures, and an illustrated parts catalog.
The reference section includes safety information,
product descriptions, and general information about
system functions, and the advanced diagnostic tests.
This manual should be used along with the advanced
diagnostic tests to troubleshoot problems effectively.
Important
This manual is intended for trained servicers who are
familiar with IBM Personal Computer products. Use
this manual along with advanced diagnostic tests to
troubleshoot problems effectively.
Before servicing an IBM product, be sure to review the
“Safety Notices (Multi-lingual Translations)” on
page 156 and “Safety Information” on page 160.
iii

Related Publications
The following publications are available for IBM products.
For more information, contact IBM or an IBM Authorized
Dealer.
For Information About See Publication
PS/2 Computers IBM Personal System/2
Hardware Maintenance
Manual (S52G-9971)
PS/ValuePoint Computers IBM PS/ValuePoint
Hardware Maintenance
Service and Reference
(S61G-1423)
Laptop, Notebook, Portable,
and ThinkPad Computers
(L40, CL57, N45, N51,
P70/P75, ThinkPad 300,
350, 500, 510, 710T,
Expansion Unit, Dock I,
Dock II)
IBM Mobile Systems
Hardware Maintenance
Manual Volume 1
(S82G-1501)
ThinkPad Computers
(ThinkPad 340, 355, 360,
370, 700, 701, 720, 750,
755)
IBM Mobile Systems
Hardware Maintenance
Manual Volume 2
(S82G-1502)
ThinkPad Computers
(ThinkPad 365, 560, 760,
SelectaDock)
IBM Mobile Systems
Hardware Maintenance
Manual Volume 3
(S82G-1503)
Monitors (Displays)
(February 1993) IBM PS/2 Display HMM Volume 1 (SA38-0053)
Monitors
(December 1993) IBM Color Monitor HMM Volume 2 (S71G-4197)
IBM Monitors (P/G Series)
(June 1996) IBM Monitor HMM Volume 3 (S52H-3679)
IBM 2248 Monitor
(February 1996) IBM Monitor HMM Volume 4 (S52H-3739)
Disk Array technology
overview and using the IBM
RAID Configuration Program
Configuring Your Disk Array
booklet (S82G-1506)
Installation Planning for
Personal System/2
computers
Personal System/2
Installation Planning and
Beyond (G41G-2927)
Installation Planning for
Advanced Personal
System/2 Servers
Advanced PS/2 Servers
Planning and Selection
Guide (GG24-3927)
iv IBM PC 300/700, IntelliStation Series HMM

Contents
About This Manual ................ iii
Related Publications . . . . . . . . . . . . . . . iv
Service Information . . . . . . . . . . . . . . . 1
General Checkout (Type 62XX, 65XX, 68XX) .... 2
General Checkout (Type 6272 Models 88X, 89X, 90X,
91X) . . . . . . . . . . . . . . . . . . . . . . 5
General Checkout (Type 6275, 6285, 6561, 6591,
6862, 6889, 6892, 6893) ............. 14
General Checkout (Type 6876, 6886) ....... 17
Module Test Menu and Hardware Configuration Report 26
Keyboard . . . . . . . . . . . . . . . . . . . . . 27
Printer . . . . . . . . . . . . . . . . . . . . . . 27
Power Supply . . . . . . . . . . . . . . . . . . . 28
Display . . . . . . . . . . . . . . . . . . . . . . 31
Symptom-to-FRU Index . . . . . . . . . . . . . . 32
Undetermined Problem . . . . . . . . . . . . . . 81
Replacing a Processor .............. 81
Replacing a Video Cache Module ......... 82
Replacing a System Board ............ 83
Type 6272 Parts ................. 86
Type 6275 Parts ................. 89
Type 6282, 6284 Parts .............. 91
Type 6285 Parts ................. 94
Type 6X7X Parts ................. 96
Type 6X8X Parts ................. 97
Type 6560 Parts ................ 107
Type 6561 Parts ................ 110
Type 6562 Parts ................ 112
Type 6588, 6888 Parts ............. 114
Type 6591 Parts ................ 117
Type 6592 Parts ................ 119
Type 6598 Parts ................ 121
Type 6862 Parts ................ 123
Type 6888 Parts ................ 125
Type 6889 Parts ................ 126
Type 6892 Parts ................ 128
Type 6893 Parts ................ 131
Type 6898 Parts ................ 133
Type 6899 Parts ................ 136
Common Parts . . . . . . . . . . . . . . . . . 138
Special Tools . . . . . . . . . . . . . . . . . . 146
Reference Information . . . . . . . . . . . . . 147
Safety Notices (Multi-lingual Translations) .... 156
Safety Information . . . . . . . . . . . . . . . 160
Laser Compliance Statement .......... 165
Product Description . . . . . . . . . . . . . . . 167
Specifications Type 6272 ............ 169
Specifications Type 6275 ............ 170
Specifications Type 6282, 6284 ......... 171
 Copyright IBM Corp. 1996, 1997, 1998 v

Specifications Type 6285 ............ 172
Specifications Type 6X7X ............ 173
Specifications Type 6X8X ............ 174
Specifications Type 6560 ............ 175
Specifications Type 6561 ............ 176
Specifications Type 6562 ............ 177
Specifications Type 6588 ............ 178
Specifications Type 6589 ............ 179
Specifications Type 6591 ............ 180
Specifications Type 6592 ............ 181
Specifications Type 6598 ............ 182
Specifications Type 6862 ............ 183
Specifications Type 6888 ............ 184
Specifications Type 6889 ............ 185
Specifications Type 6892 ............ 186
Specifications Type 6893 ............ 187
Specifications Type 6898 ............ 188
Specifications Type 6899 ............ 189
Security Features . . . . . . . . . . . . . . . . 190
Hard Disk Drive Jumper Settings ......... 195
CD-ROM, PD/CD-ROM Drive Jumper Settings . . 199
BIOS Levels . . . . . . . . . . . . . . . . . . 200
Flash (BIOS/VPD) Update Procedure ...... 201
Diagnostics and Test Information ........ 203
Using the Test Programs ............ 215
Setup Utility Program .............. 220
Power Management . . . . . . . . . . . . . . . 226
Network Settings . . . . . . . . . . . . . . . . 229
Recovering from Software Problems (Type 68X7) . 231
Creating Utility Diskettes ............ 231
IBM Wireless LAN ............... 239
System Board Memory ............. 248
Computer Exploded View (Type 6272) ...... 261
Computer Exploded View (Type 6275) ...... 262
Computer Exploded View (Type 6282, 6284) . . . 265
Computer Exploded View (Type 6285) ...... 266
Computer Exploded View (Type 6X7X) ...... 271
Computer Exploded View (Type 6X8X) ...... 272
Computer Exploded View (Type 6560) ...... 273
Computer Exploded View (Type 6561) ...... 274
Computer Exploded View (Type 6562) ...... 279
Computer Exploded View (Type 6588, 6888) . . . 283
Computer Exploded View (Type 6591) ...... 288
Computer Exploded View (Type 6592) ...... 294
Computer Exploded View (Type 6598) ...... 297
Computer Exploded View (Type 6862) ...... 299
Computer Exploded View (Type 6889) ...... 302
Computer Exploded View (Type 6892) ...... 307
Computer Exploded View (Type 6893) ...... 312
Computer Exploded View (Type 6898) ...... 315
Computer Exploded View (Type 6899) ...... 319
Keylock Assembly Exploded View (Desktop Models) 321
System Board Layouts ............. 322
Riser Card Layouts ............... 388
vi IBM PC 300/700, IntelliStation Series HMM

Type/Model Number Conversion ......... 399
Country/Language Model Configuration ...... 406
Miscellaneous Information . . . . . . . . . . . . 447
Send Us Your Comments! ............ 449
Do You Need Technical References? ...... 450
Problem Determination Tips ........... 451
Notices . . . . . . . . . . . . . . . . . . . . . 458
Contents vii

viii IBM PC 300/700, IntelliStation Series HMM

Service Information
This section contains the general checkout procedures,
related service procedures, Symptom-to-FRU indexes, and
parts listings for IBM Personal Computer 300/700 Series
(Type 62XX, 65XX, and 68XX) and the IntelliStation (Type
6888, 6889, 6893, 6898, and 6899) computers.
Note
This manual and the diagnostic tests are intended to
test
only IBM products. Non-IBM products of any kind
including adapter cards, accelerator boards, options,
or non-IBM devices, can give false errors and invalid
computer responses. If you remove a non-IBM device
and the symptom goes away, the problem is with the
device you removed.
 Copyright IBM Corp. 1996, 1997, 1998 1

General Checkout (Type 62XX, 65XX,
68XX)
This general checkout procedure is for Type 62XX, 65XX,
and 68XX computers.
If you are servicing a Type 6272 Model 88X, 89X, 90X,
91X, computer, see “General Checkout (Type 6272
Models 88X, 89X, 90X, 91X)” on page 5.
If you are servicing a Type 6275, 6285, 6561, 6591,
6862, 6889, 6892, or 6893 computer, see General
Checkout on page 14
If you are servicing a Type 6876 or Type 6886 Micro
Channel computer, see “General Checkout (Type 6876,
6886)” on page 17.
Attention
The drives in the computer you are servicing might
have been rearranged or the drive startup sequence
changed. Be extremely careful during write operations
such as copying, saving, or formatting. Data or
programs can be overwritten if you select an incorrect
drive.
Diagnostic error messages appear when a test program
finds a problem with a hardware option. For the test
programs to properly determine if a test Passed , Failed , or
Aborted , the test programs check the error-return code at
test completion. See “Return Codes” on page 214.
General error messages appear if a problem or conflict is
found by an application program, the operating system, or
both. For an explanation of these messages, refer to the
information supplied with that software package.
Notes
1. Before replacing any FRUs, ensure the latest
level of BIOS is installed on the system. A
down-level BIOS might cause false errors and
unnecessary replacement of the system board.
For more information on how to determine and
obtain the latest level BIOS, see “BIOS Levels”
on page 200.
2. If multiple error codes are displayed, diagnose
the first error code displayed.
3. If the computer hangs with a POST error, go to
“Symptom-to-FRU Index” on page 32.
4. If the computer hangs and no error is displayed,
go to “Undetermined Problem” on page 81.
5. If an installed device is not recognized by the
diagnostics program, that device might be
defective.
2IBM PC 300/700, IntelliStation Series HMM

001
– Power-off the computer and all external devices.
– Check all cables and power cords.
– Set all display controls to the middle position.
– Insert the Diagnostics diskette into drive A.
– Power-on all external devices.
– Power-on the computer.
– Check for the following response:
1. Readable instructions or the Main Menu.
DID YOU RECEIVE THE CORRECT RESPONSE?
Yes No
002
If Rapid Resume is displayed, do the following:
1. Disable Rapid Resume, see “Running Rapid
Resume Manager” on page 228.
2. Run the diagnostics tests.
3. Enable Rapid Resume after service is
complete.
– or –
If the computer hangs during Rapid Resume, do the
following:
1. Power-off; then, power-on the computer.
2. When the hard-disk drive activity light comes
on, press Ctrl+Alt+Del to exit Rapid Resume
and restart the computer. (Rapid Resume is
now turned off.)
– or –
Go to the “Symptom-to-FRU Index” on page 32.
003
ARE ALL INSTALLED DEVICES IN THE COMPUTER
HIGHLIGHTED ON THE MODULE TEST MENU OR
HARDWARE CONFIGURATION REPORT?
Yes No
004
Go to “Module Test Menu and Hardware
Configuration Report” on page 26.
005
Run the Advanced Diagnostics test. If necessary, refer to
“Diagnostics and Test Information” on page 203.
If you receive an error, go to “Symptom-to-FRU
Index” on page 32.
If the test stops and you cannot continue, replace the
last device tested.
(Step 005 continues)
Service Information 3

(CONTINUED)
005 (continued)
If the computer has incorrect keyboard responses, go
to “Keyboard” on page 27.
If the printer has incorrect responses, go to “Printer”
on page 27.
If the display has problems such as jittering, rolling,
shifting, or being out of focus, go to “Display” on
page 31.
4IBM PC 300/700, IntelliStation Series HMM

General Checkout (Type 6272 Models
88X, 89X, 90X, 91X)
This general checkout and diagnostic procedure is for the
Type 6272, Models 88X, 89X, 90X, 91X only. These
models come without a diskette drive (disketteless) and
without a CD-ROM.
Depending on the operating system and network
configuration, the method of running diagnostics varies.
It is the customer's responsibility to make the IBM PC
Enhanced Diagnostics accessible from either:
The local hard disk
-- or --
The server
If the computer you are servicing is set up to start
remotely, this general checkout procedure assumes that
the server providing services to the computer and the
network are functioning correctly.
Note
Run the IBM PC Enhanced Diagnostics under the
DOS operating system. Windows 95 and Windows
NT diagnostics should be run only if the DOS version
is not available.
For more information about the IBM PC Enhanced
Diagnostics, see “Diagnostics Test Programs” on
page 205.
001
– Power-off the computer and all external devices.
– Check all cables and power cords.
– Make sure the computer is connected to a functioning
network.
– Set all display controls to the middle position.
– Power-on all external devices.
– Power-on the computer.
– Check for the following response:
1. One beep
2. Operating system or diagnostics loaded
Note
If the operating system loader screen appears,
select an operating system.
DID YOU RECEIVE THE CORRECT RESPONSE?
Yes No
002
Check the following for the response you received
and perform the action:
(Step 002 continues)
Service Information 5

(CONTINUED)
002 (continued)
No beep - See “Beep Symptoms” on page 33.
One beep; Operating system did not load - Go
to Step 006.
Two or more beeps - Go to the
“Symptom-to-FRU Index” on page 32.
003
OBSERVE THE GREEN LED ON THE TOKEN-RING
ADAPTER OR THE LNK LED ON THE ETHERNET
ADAPTER FOR 30 SECONDS. IS THE LED ON SOLID
FOR THE ENTIRE 30 SECONDS?
Yes No
004
The computer might not be connected to an active
network or there might be a problem with the
network adapter card. See “Network Adapter LED
Status” on page 11.
005
Start the PC Enhanced Diagnostics tests. If necessary,
refer to “Starting IBM PC Enhanced Diagnostics” on
page 9 and “Diagnostics and Test Information” on
page 203.
If diagnostic programs are not installed on the computer
you are servicing, contact the system administrator and
ask if the diagnostic programs can be made available over
the LAN. If the diagnostics can not be made available
over the LAN, use the “Symptom-to-FRU Index” on
page 32.
006
IS THERE A READABLE SCREEN WITH NO FLASHING,
JITTERING, OR OTHER DISPLAY PROBLEMS?
Yes No
007
Go to “Display” on page 31.
008
OBSERVE THE GREEN LED ON THE TOKEN-RING
ADAPTER OR THE LNK LED ON THE ETHERNET
ADAPTER FOR 30 SECONDS. IS THE LED ON SOLID
FOR THE ENTIRE 30 SECONDS?
Yes No
009
(Step 009 continues)
6IBM PC 300/700, IntelliStation Series HMM

009 (continued)
The computer might not be connected to an active
network or there might be a problem with the
network adapter card. See “Network Adapter LED
Status” on page 11.
010
IS THE COMPUTER STOPPED AT THE RPL SCREEN?
Yes No
011
– The RPL (Remote Program Load) screen displays
a title line at the top of screen such as “IBM PCI
Token-Ring Adapter RPL.”
– Go to Step 026 on page 8.
012
CONTACT THE SYSTEM ADMINISTRATOR AND
PROVIDE THE MAC ADDRESS OF THE COMPUTER
YOU ARE SERVICING. ASK THE SYSTEM
ADMINISTRATOR: SHOULD THE COMPUTER BE
ENABLED FOR RPL?
Yes No
013
Change Startup sequence to remove network as
startup device. (See “Setup Utility Program” on
page 220). Go to Step 001 on page 5.
014
ASK THE SYSTEM ADMINISTRATOR: IS AN RPL
IMAGE ASSIGNED TO THE COMPUTER?
Yes No
015
– If a Token-Ring adapter is installed in the
computer, make note of the current startup
sequence, then change startup sequence to
temporarily remove network as a startup device
and make the hard disk the first startup device.
Restart the computer. Go to Step 017.
– If an Ethernet adapter is installed in the computer,
go to Step 020 on page 8.
016
Provide the new MAC address to the system administrator.
017
(Step 017 continues)
Service Information 7

(CONTINUED)
017 (continued)
DID THE OPERATING SYSTEM LOAD?
Yes No
018
– Restore the startup sequence.
– Go to Step 023.
019
Go to Step 005 on page 6 to run diagnostics, then restore
startup sequence after determining the problem.
020
PRESS THE HOME KEY. DID THE OPERATING
SYSTEM LOAD?
Yes No
021
Go to Step 023.
022
Go to Step 005 on page 6 to run diagnostics.
023
CONTACT THE SYSTEM ADMINISTRATOR AND ASK:
CAN DIAGNOSTICS BE ASSIGNED FROM THE
SERVER?
Yes No
024
– If you were provided with or have observed any
obvious symptoms, Go to “Symptom-to-FRU
Index” on page 32.
– Notify system administrator that you have no
symptoms diagnosed and diagnostics can not be
run on the computer you are servicing.
025
Restart the computer and run diagnostics. See “Starting
IBM PC Enhanced Diagnostics” on page 9.
026
AFTER CHECKING THE STARTUP SEQUENCE, IS
NETWORK THE FIRST DEVICE LISTED IN THE
STARTUP SEQUENCE?
Yes No
027
(Step 027 continues)
8IBM PC 300/700, IntelliStation Series HMM

027 (continued)
– Go to Step 029.
028
– Replace the network adapter card.
– Contact the system administrator and provide the new
MAC address.
029
IS THE HARD DISK DRIVE THE FIRST DEVICE LISTED
IN THE STARTUP SEQUENCE?
Yes No
030
– If a device other than the hard disk is listed as the
first device, change the startup sequence so the
hard disk is the first device, then return to Step
001 on page 5. (See “Setup Utility Program” on
page 220).
031
SHOULD THE COMPUTER BE ENABLED FOR RPL?
Yes No
032
– Ask the system administrator to reinstall the
operating system, then return to Step 001 on
page 5. If the operating system cannot be
installed, replace the hard disk drive.
033
– Change the startup sequence so the network is the first
startup device and the hard disk drive is the second
startup device.
– Return to Step 001 on page 5.
Starting IBM PC Enhanced Diagnostics
These steps show how to start the DOS based IBM PC
Enhanced Diagnostics from Windows 95, Windows NT,
and Windows 3.X.
1. Shut down Windows 95 or Windows NT and re-start
in DOS mode. If Windows 3.X is running, close
Windows.
2. At the command prompt type: CD IBMDIAG, then
press the Enter key.
Note
If an invalid directory message appears, IBM PC
Enhanced Diagnostics are not installed. Restart
the computer and go to Step 001 on page 5.
Service Information 9

3. Type: PCDR, then press the Enter key.
4. Follow the instructions on the screen to run the
diagnostics.
Note
Do not start the diagnostics in the DOS session
of Windows 95 or from a command prompt under
Windows NT. The system must be shut down
and restarted in DOS.
Starting diagnostics under Windows 95 and
Window NT: Use the Windows diagnostics version
only if you cannot run the IBM PC Enhanced Diagnostics
under DOS.
1. Select Start
2. Select Programs
3. Select PC-Doctor
4. Select PC-Doctor for Windows
Diagnostics on the RTC CD
The IBM PC Enhanced Diagnostics are shipped on the
RTC (Ready To Configure) CD. For Type 6272
Disketteless models, the customer has the responsibility to
make the diagnostics available either locally on the PC
hard disk or remotely through a server.
Remote Diagnostics
Some computers might not have diagnostics loaded onto
the local hard drive. If the computer you are servicing is
connected to a server and the server has the diagnostic
image, remote diagnostics can be run. (To use the
diagnostics from the RTC CD, a diskette must be made
from the diskette factory, then the diskette files are loaded
on the server). See the customer's System Administrator
for more information about remote diagnostics.
Remote diagnostics require:
Access to the network
System Administrator to download the diagnostics or
to execute remote diagnostics to the client computer.
10 IBM PC 300/700, IntelliStation Series HMM
