IBM R/S6000 7012 300 Series Manual

RS/6000
7012 Models 300 Series
Operator Guide
SA38–0544–00

First Edition (October 1997)
This edition notice applies to the R/S6000 7012 Models 300 Series Operator Guide. This edition obsoletes
all previous editions.
The following paragraph does not apply to the United Kingdom or any country where such
provisions are inconsistent with local law: THIS PUBLICATION IS PRINTED “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some
states do not allow disclaimer of express or implied warranties in certain transactions; therefore, this
statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made
to the information herein; these changes will be incorporated in new editions of the publication.
It is possible that this publication may contain reference to, or information about, products (machines and
programs), programming, or services that are not announced in your country. Such references or
information must not be construed to mean that such products, programming, or services will be offered in
your country. Any reference to a licensed program in this publication is not intended to state or imply that
you can use only the licensed program indicated. You can use any functionally equivalent program instead.
AIX is a registered trademark of International Business Machines Corporation.
Medeco is a trademark of the Medeco Company.
Copyright International Business Machines Corporation, 1990, 1997. All rights reserved.
Note to US Government Users – Documentation and programs related to restricted rights – Use,
duplication, or disclosure is subject to the restrictions set forth in the GSA ADP Schedule Contract.

Preface iii
Table of Contents
Communications Statements vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Notices xi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
About This Book xiii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1. System Unit Description 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical Workstation Arrangement 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Unit 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Unit Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Illustration for Early Models 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Illustration for Models 380, 390, 39H, and 397 1-4. . . . . . . . . . . . . . . . . . . . .
Base Positioning 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disk Drives 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Cover Removal and Replacement 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
External Device Connectors 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location Codes 1-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location Code Format for 7135, and 9334 1-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location Code Format for Non-SCSI Devices 1-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location Code Format for SCSI Devices 1-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location Code Table 1-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2. Using the System Unit 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the Key Mode Switch 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the System Unit 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stopping the System Unit 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating with Multiple Attached Systems 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ordering Keys 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Reorder Form 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reading the Three-Digit Display 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Reset Button 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Keyboards 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Three-Button Mouse 2-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handling the Mouse Correctly 2-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Care of the Mouse 2-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the Mouse 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the 3.5-Inch Diskette Drive 2-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handling Your Diskettes 2-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of 3.5-Inch Diskettes 2-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Write-Protecting 3.5-Inch Diskettes 2-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading and Unloading the 3.5-Inch Diskette 2-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the CD-ROM Drive 2-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type B Bezel (CD-ROM and CD-ROM2) CD-ROM Drive 2-17. . . . . . . . . . . . . . . . . . .
Loading the CD-ROM Disc Caddy 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unloading the CD-ROM Disc Caddy 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the CD-ROM Drive 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iv Operator Guide
Type C Bezel CD-ROM Drive 2-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading the CD-ROM Drive 2-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unloading the CD-ROM Drive 2-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency Eject 2-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the CD-ROM Drive 2-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4. Using the Standalone and Online Diagnostics 3-23. . . . . . . . . . . . . . . . . .
Sources for the Diagnostic Programs 3-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standalone and Online Diagnostics Operating Considerations 3-23. . . . . . . . . . . . . . . . .
Diagnostics on a System Unit Attached to Another System 3-24. . . . . . . . . . . . . . . . . .
Selecting a Console Display 3-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identifying the Terminal Type to the Diagnostic Programs 3-24. . . . . . . . . . . . . . . . . . .
Undefined Terminal Types 3-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Resetting the Terminal 3-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running Diagnostic Programs From Tape Drives 3-24. . . . . . . . . . . . . . . . . . . . . . . . . .
Running Diagnostic Programs from CD–ROM 3-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the Diagnostic Programs from Diskettes 3-25. . . . . . . . . . . . . . . . . . . . . . . . . .
Running the Diskette Diagnostics From a Non–RS232 Terminal 3-26. . . . . . . . . . . . .
Subsystem Diagnostic Diskette Package Version 3.0 3-27. . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Diskette Contents and Descriptions 3-28. . . . . . . . . . . . . . . . . . . . . . . . . .
Running the Diagnostic Programs from Disk or From a Server 3-30. . . . . . . . . . . . . . .
Running the Diagnostic Programs from the Network 3-31. . . . . . . . . . . . . . . . . . . . . . .
Running the Diagnostic Programs with a 5080 Attached 3-31. . . . . . . . . . . . . . . . . . . .
Running the Diagnostic Programs from a TTY Terminal 3-32. . . . . . . . . . . . . . . . . . . . .
Online Diagnostics Mode of Operation 3-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Mode 3-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the Online Diagnostics in Service Mode 3-32. . . . . . . . . . . . . . . . . . . . . . . . . .
Concurrent Mode 3-33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the Online Diagnostics in Concurrent Mode 3-34. . . . . . . . . . . . . . . . . . . . . . .
Maintenance Mode 3-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the Online Diagnostics in Maintenance Mode 3-34. . . . . . . . . . . . . . . . . . . . .
Standalone Diagnostic Operation 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the Standalone Diagnostics 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Exerciser 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the System Exerciser 3-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display Screens 3-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stopping the System Exerciser 3-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the System Exerciser to Check Out Repairs and Intermittent Problems 3-36
General Information About Multiple Systems 3-37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Determining System Architecture 3-37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Block Multiplexer Channel Adapter 3-38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting or Stopping Communications With the Host System 3-38. . . . . . . . . . . . . . . .
Stopping Communications 3-38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Communications 3-38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the System Diagnostics 3-39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Error Log Entries 3-39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Solving System–to–Host System Communication Problems 3-39. . . . . . . . . . . . . . . . .
Cabling the System Unit to the Host System 3-39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preface v
Enterprise System Connection (ESCON) Adapter 3-40. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting or Stopping Communications With the Host System 3-40. . . . . . . . . . . . . . . .
Stopping Communications 3-40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Communications 3-40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the System Diagnostics 3-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Error Log Entries 3-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Solving System to Host System Communication Problems 3-41. . . . . . . . . . . . . . . . . .
Cabling the System Unit to the Host System 3-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Enterprise System Connection (ESCON) Channel Emulator 3-42. . . . . . . . . . . . . . . . . . .
Starting or Stopping Communications With the Tape Control Unit 3-42. . . . . . . . . . . .
Stopping Communications 3-42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Communications 3-42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the System Diagnostics 3-43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Error Log Entries 3-43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Solving System to Tape Control Unit Communication Problems 3-43. . . . . . . . . . . . . .
Cabling the System Unit to the Host System 3-43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fiber Distributed Data Interface (FDDI) Adapter 3-44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FDDI Single Ring Adapter Service Considerations 3-44. . . . . . . . . . . . . . . . . . . . . . . . .
FDDI Dual Ring Adapter Service Considerations 3-44. . . . . . . . . . . . . . . . . . . . . . . . . .
FDDI Cabling 3-44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High–Availability SCSI 3-45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High–Availability Cabling 3-45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Summary 3-45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Memory and Processor Testing 3-45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IPL Control Block Analysis 3-45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checkstops 3-45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Crashes 3-45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Error Log Analysis 3-46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Modes 3-46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Changes 3-47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
diag Command Line Options: 3-48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 5. Introduction to Tasks and Service Aids 4-49. . . . . . . . . . . . . . . . . . . . . . . .
Tasks 4-49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AIX Shell Prompt Service Aid 4-50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Backup/Restore Media Service Aid 4-50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Create Customized Diagnostic Configuration Diskette 4-50. . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Package Utility Service Aid 4-50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dials and LPFK Configuration Service Aid 4-51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dials and LPFKs Configuration Service Aid Before Version 4.2 4-51. . . . . . . . . . . . . .
Configure Dials and LPFKs Task Version 4.2+ 4-51. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disk Based Diagnostic Update Service Aid and Update Disk Based Diagnostic Task 4-51
Disk Based Diagnostic Update Service Aid Before Version 4.2 4-51. . . . . . . . . . . . . .
Update Disk Based Diagnostic Task Version 4.2 4-51. . . . . . . . . . . . . . . . . . . . . . . . . . .
Disk Maintenance Service Aid 4-52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disk to Disk Copy Service Aid 4-52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display/Alter Sector Service Aid 4-52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display or Change BUMP Configuration Task 4-53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display or Change Diagnostic Run Time Options Task 4-53. . . . . . . . . . . . . . . . . . . . . . . .
Disk Media Service Aids 4-54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Certify Media 4-54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vi Operator Guide
Format Media 4-54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Format and Certify 4-54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Erase Disk 4-54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Spare Sectors Service Aid for Optical Disk 4-55. . . . . . . . . . . . . . . . . . . . . . . . .
Diskette Media Service Aid 4-56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display/Alter Bootlist Service Aid 4-56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display or Change Configuration or Vital Product Data (VPD) Service Aid 4-56. . . . . . .
Display Hardware Vital Product Data Task 4-56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display Software Product Data pre version 4.2 4-56. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display Software Product Data beginning with version 4.2 4-57. . . . . . . . . . . . . . . . . .
Display Configuration and Resource List Task 4-57. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Hardware Vital Product Data Task 4-57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Add Resource to Resource List Task 4-57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delete Resource from Resource List Task 4-57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Configuration Service Aid and Add or Delete Drawer Configuration Task 4-57
Add or Delete Drawer Configuration Task 4-57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Add or Delete Drawer Configuration Task 4-57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Add or Delete Drawer Configuration Task 4-58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display and Change Diagnostic Test List Service Aid 4-58. . . . . . . . . . . . . . . . . . . . . . . . .
Display Hardware Error Report Service Aid 4-58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display or Change Key Modes (Display or Change Electronic Mode Switch Task) 4-59
Display Previous Diagnostic Results Service Aid 4-59. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display Resource Attributes 4-59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display Test Patterns for the Multimedia Video Capture Adapter Service Aid 4-59. . . . .
Display Test Patterns Service Aid 4-59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ESCON Bit Error Rate Service Aid 4-59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Generic Microcode Download Service Aid 4-60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Local Area Network Service Aid and Local Area Network Analyzer Task 4-60. . . . . . . . .
Microcode Download Service Aid 4-60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Multi–processor Service Aid (Display or Change Multi–processor Configuration Task) 4-60
Periodic Diagnostics Service Aid 4-61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Process Supplemental Media Task 4-61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Topology Service Aid 4-61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Run Diagnostics Task 4-61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Run Error Log Analysis Task 4-62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCSI Bus Service Aid and SCSI Bus Analyzer Task 4-62. . . . . . . . . . . . . . . . . . . . . . . . . .
SCSI Device Identification and Removal Service Aid 4-63. . . . . . . . . . . . . . . . . . . . . . . . .
SCSI Tape Utilities Service Aid 4-63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Aids for use with Ethernet 4-64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Hints Service Aid 4-64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SSA Service Aids 4-64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trace Service Aid 4-64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7135 RAIDiant Array Service Aid 4-64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7318 Serial Communications Network Server Service Aid 4-65. . . . . . . . . . . . . . . . . . . . .
Chapter 6. Using the System Verification Procedure 5-1. . . . . . . . . . . . . . . . . . . . . . .
Step 1. Considerations before Running This Procedure 5-1. . . . . . . . . . . . . . . . . .
Step 2. Loading the Diagnostic Programs 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 3. Running System Verification 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 4. Additional System Verification 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 5. Stopping the Diagnostics 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preface vii
Chapter 7. Hardware Problem Determination 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hardware Problem Determination Procedure 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 8. Changing the System Unit Position 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the System Unit Base 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the Logo Position 7-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the Three-Digit Display Position 7-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 9. Moving the System Unit 8-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moving the System Unit 8-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 10. Diskless/Dataless Workstation Configuration 9-1. . . . . . . . . . . . . . . . .
Diskless/Dataless Workstation Configuration 9-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 1. Planning 9-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 2. Starting the System 9-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 3. Setting Up Network Configuration 9-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 4. Waiting for Client Registration on the Diskless/Dataless Server 9-6. . . . . . .
Step 5. Booting the Diskless/Dataless Client 9-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix A. Supplies A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix B. Three-Digit Display Numbers B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Built-In Self-Test (BIST) Indicators B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power-On Self-Test (POST) Indicators B-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration Program Indicators B-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Load Progress Indicators B-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Debugger Progress Indicators B-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flashing 888 Message Descriptions B-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type 102 Message B-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Crash Codes B-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dump Progress Indicators B-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type 103 and 105 Messages B-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Index X-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

viii Operator Guide

Preface ix
Communications Statements
The following statement applies to this product. The statement for other products intended
for use with this product will appear in their accompanying manuals.
Federal Communications Commission (FCC) Statement
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
Properly shielded and grounded cables and connectors must be used in order to meet FCC
emission limits. Neither the provider nor the manufacturer are responsible for any radio or
television interference caused by using other than recommended cables and connectors or
by unauthorized changes or modifications to this equipment. Unauthorized changes or
modifications could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
European Union (EU) Statement
This product is in conformity with the protection requirements of EU Council Directive
89/336/EEC on the approximation of the laws of the Member States relating to
electromagnetic compatibility. The manufacturer cannot accept responsibility for any failure
to satisfy the protection requirements resulting from a non–recommended modification of
the product, including the fitting of option cards supplied by third parties. Consult with your
dealer or sales representative for details on your specific hardware.
This product has been tested and found to comply with the limits for Class A Information
Technology Equipment according to CISPR 22 / European Standard EN 55022. The limits
for Class A equipment were derived for commercial and industrial environments to provide
reasonable protection against interference with licensed communication equipment.
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
International Electrotechnical Commission (IEC) Statement
This product has been designed and built to comply with IEC Standard 950.

xOperator Guide
United Kingdom Telecommunications Safety Requirements
This equipment is manufactured to the International Safety Standard EN60950 and as such
is approved in the UK under the General Approval Number NS/G/1234/J/100003 for indirect
connection to the public telecommunication network.
The network adapter interfaces housed within this equipment are approved separately, each
one having its own independent approval number. These interface adapters, supplied by the
manufacturer, do not use or contain excessive voltages. An excessive voltage is one which
exceeds 70.7 V peak ac or 120 V dc. They interface with this equipment using Safe Extra
Low Voltages only. In order to maintain the separate (independent) approval of the
manufacturer’s adapters, it is essential that other optional cards, not supplied by the
manufacturer, do not use main voltages or any other excessive voltages. Seek advice from
a competent engineer before installing other adapters not supplied by the manufacturer.
Avis de conformité aux normes du ministère des Communications du
Canada Cet appareil numérique de la classe A respecte toutes les exigences du Réglement sur le
matériel brouilleur du Canada.
Canadian Department of Communications Compliance Statement
This Class A digital apparatus meets the requirements of the Canadian
Interference-Causing Equipment Regulations.
VCCI Statement
The following is a summary of the VCCI Japanese statement in the box above.
This equipment is in the Class 1 category (information equipment to be used in
commercialand/orindustrialareas)andconformstothestandardssetbytheVol-
untaryControl Council ForInterferencebyDataProcessingEquipment and Elec-
tronic Office Machines aimed at preventing radio interference in commercial and/
or industrial areas.
Consequently,whenusedinaresidentialareaorinanadjacentareathereto,radio
interference may be caused to radios and TV receivers, etc.
Read the instructions for correct handling. VCCI–1.

Preface xi
Electromagnetic Interference (EMI) Statement – Taiwan
The following is a summary of the EMI Taiwan statement above.
Warning: This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user will be required to take adequate measures.
Radio Protection for Germany
Dieses Gerät ist berechtigt in Übereinstimmung mit dem deutschen EMVG vom 9.Nov.92
das EG-Konformitätszeichen zu führen.
Der Aussteller der Konformitätserklärung ist die IBM Germany.
Dieses Gerät erfüllt die Bedingungen der EN 55022 Klasse A. Für diese Klasse von
Geräten gilt folgende Bestimmung nach dem EMVG:
Geräte dürfen an Orten, für die sie nicht ausreichend entstört sind, nur mit besonderer
Genehmigung des Bundesministers für Post und Telekommunikation oder des
Bundesamtes für Post und Telekommunikation betrieben werden. Die Genehmigung wird
erteilt, wenn keine elektromagnetischen Störungen zu erwarten sind.
(Auszug aus dem EMVG vom 9.Nov.92, Para.3, Abs.4)
Hinweis:
Dieses Genehmigungsverfahren ist von der Deutschen Bundespost noch nicht veröffentlicht
worden.

xii Operator Guide

Preface xiii
Safety Notices
Note: For a translation of these notices, see System Unit Safety Information .
Definitions of Safety Notices
A danger notice indicates the presence of a hazard that has the potential of causing death
or serious personal injury.
Danger notices appear on the following pages:
8-1
A
caution notice indicates the presence of a hazard that has the potential of causing
moderate or minor personal injury.
Caution notices appear on the following pages:
xiii
8-1
Observe the following safety instructions any time you are connecting or disconnecting
devices attached to the system unit.
Safety Notices for Installing, Relocating, or Servicing
For safety checks when relocating, refer to Chapter 8 “Moving the System Unit.”
Lithium Battery
CAUTION:
A lithium battery can cause fire, explosion, or a severe burn. Do not recharge,
disassemble, heat above 100°C (212°F), solder directly to cell, incinerate, or expose
cell contents to water. Keep away from children. Replace only with the part number
specified for your system. Use of another battery may present a risk of fire or
explosion.
The battery connector is polarized; do not attempt to reverse the polarity.
Dispose of the battery according to local regulations.

xiv Operator Guide
Power Cables
1234
567
8
9
10 11
Note: If you should
need a different
power cable,
use this figure
and the following
table to assist
you when
ordering.
Index Part
Number Country
1 1838574 Bahamas, Barbados, Bolivia, Brazil, Canada, Costa Rica, Dominican
Republic, El Salvador, Ecuador, Guatemala, Guyana, Haiti, Honduras,
Jamaica, Japan, Netherlands Antilles, Panama, Peru, Philippines, Taiwan,
Thailand, Trinidad, Tobago, U.S.A. (except Chicago), Venezuela
2 6952300 Bahamas, Barbados, Bermuda, Bolivia, Brazil, Canada, Cayman Islands,
Colombia, Costa Rica, Dominican Republic, Ecuador, El Salvador,
Guatemala, Guyana, Haiti, Honduras, Jamaica, Japan, Korea (South),
Mexico, Netherlands Antilles, Nicaragua, Panama, Peru, Philippines,
Puerto Rico, Saudi Arabia, Suriname, Trinidad, Taiwan, U.S.A. (except
Chicago), Venezuela
2 62X1045 Chicago, U.S.A.
3 6952311 Argentina, Australia, New Zealand
4 13F9979 Abu Dhabi, Austria, Belgium, Bulgaria, Botswana, Egypt, Finland, France,
Germany, Greece, Iceland, Indonesia, Korea (South), Lebanon,
Luxembourg, Macau, Netherlands, Norway, Portugal, Saudi Arabia, Spain,
Sudan, Sweden, Turkey, Yugoslavia
5 13F9997 Denmark
6 14F0015 Bangladesh, Burma, Pakistan, South Africa, Sri Lanka
7 14F0033 Bahrain, Bermuda, Brunei, Channel Islands, Cyprus, Ghana, Hong Kong,
India, Iraq, Ireland, Jordan, Kenya, Kuwait, Malawi, Malaysia, Nigeria,
Oman, People’s Republic of China, Qatar, Sierra Leone, Singapore,
Tanzania, Uganda, United Arab Emirates (Dubai), United Kingdom, Zambia
8 14F0051 Liechtenstein, Switzerland
9 14F0069 Chile, Ethiopia, Italy
10 14F0087 Israel
11 6952291 Paraguay, Colombia, Uruguay

Preface xv
About This Book
This book uses three-digit model numbers. You may have other documentation that uses
four-digit model numbers. For example, the model 32H in this book may be referred to as a
model 320H in other documentation. They are the same system units.
This book provides information about the operator controls and the devices installed in the
7012 system unit.
Chapter 6 contains the hardware problem determination guide.
All information in this book pertaining to 7012 Model 397 also applies to 7030 Model 397.
Related Information
The AIX Version 4 Problem Solving Guide and Reference, Order Number SC23-2606, is
the first book you should use when you have a problem with the system unit. It contains the
procedure for determining if the problem is hardware or software related.
If the problem is software related, use the
AIX Version 4 Problem Solving Guide and
Reference.
The Site and Hardware Planning Information publication, Order Number SA38-0508 and the
Adapters, Devices, and Cable Information , Order Number SA23-2764, contains information
about various hardware and software offerings.
System Unit Safety Information , Order Number SA23-2652, contains translated versions of
the danger and caution notices.
The
Diskless Workstation Management Guide , Order Number SC23-2433, contains
information about diskless workstations.

System Unit Description 1-1
Chapter 1. System Unit Description
This chapter contains information to help you become familiar with the 7012 system unit.
Typical Workstation Arrangement
Your system unit may have a display, keyboard, and mouse attached to it, plus a wide range
of other available options such as a tape drive, printers, data communications, terminals,
and plotters.
An illustration of a typical system unit office arrangement follows:
3-Button Mouse
Keyboard
Display
Tape Drive
System Unit
System Unit
The system unit processes data (input) from the keyboard, mouse, tablet, disk drives,
diskettes, tape drives, and communications connections. It contains a 32-bit processor,
input/output (I/O) adapters, memory, and media storage devices. The hardware is controlled
by the operating system program.
Each model of the system unit has a standard memory size, but each can be configured with
additional memory cards. See
Adapters, Devices, and Cable Information, Order Number,
SA23-2764 for details.
The system unit provides slots for the installation of Micro Channel adapters. Internal
hardware controls the 3.5-inch diskette drive, speaker, two serial ports, one parallel port,
mouse, keyboard, tablet, and disk drives.

1-2 Operator Guide
Depending on the particular model, additional features could be present. For example:
•SCSI, Ethernet ports, or SCSI-2 SE port
•16-bit SCSI cable instead of an 8-bit SCSI Bus Extender card
•Metal covers with a plastic front bezel
•No rear cover
•Capable of supporting two removable media bays
•Front cover with an operator-accessible front panel
System Unit Features
Logo Is located on the front and rear covers. These logos can be rotated in
place when the base position is changed.
Key Mode Switch Is a key-controlled mode switch with three positions labeled:
•Normal ( OK )
•Secure ( )
•Service ( )
Attention: Pressing the Reset button with the key mode switch in the
Normal or Service position and the operating system running can
result in damaged or lost data.
3-Digit Display Displays up to three 7-segment characters. The display has a hinged
lens through which the characters can be seen. The hinged lens
allows access to the character holder, which can be turned 90 degrees
for correct viewing when the system unit is in the horizontal or vertical
position.
Diskette Drive Contains a standard 1.44M-byte 3.5-inch diskette drive that has an
in-use light and a diskette-eject button.
Power Switch Has the international symbols (l) for On and (O)for Off. The Power
switch also has a power-on light.
Base Is removable and can be attached to the left side or the bottom for
vertical or horizontal positioning of the system unit. See Chapter 7 for
instructions.
Serial Number Is located on the top cover (left-front corner) for easy access. It also is
located on the rear bar code label.
Rear Cover Is removable and provides access to the system unit connectors.
Top Cover Can be removed by a service technician.
Front Cover Can be removed by a service technician.
Rear Fan Provides cooling for the electronics located inside the system unit.
Cable Guides Provide a means to orderly arrange the cables between the system
unit and external devices and power outlet.
Power Supply Fan Provides cooling for the power supply. It is located inside the power
supply.
Reset Button Is located next to the 3-digit display and is labeled Reset.
Media Bays The two media bays are optional.

System Unit Description 1-3
System Illustration for Early Models
Logo
KeyMode
Switch Reset Button 3-Digit Display Diskette Drive Power
Switch
Front Cover
Base
Diskette Eject
Button
Logo
Power
Supply
Fan
Rear Cover
Base
Cable
Guides Rear
Fan

1-4 Operator Guide
System Illustration for Models 380, 390, 39H, and 397
Logo
KeyMode
Switch Reset Button 3-Digit Display Diskette
Drive
Power
Button
Front Cover
Base
Serial Number
Diskette Eject
Button
Media Bays
Optional
S 1 S2 P
Power Adapter Positions
Serial 1
Serial 2 SCSI-2 Port Parallel Port Tablet
Keyboard Mouse
Ethernet
Power On LED Diskette LED
1234

System Unit Description 1-5
Base Positioning
In the typical workstation arrangement shown on page 1-1, the system unit is in the
horizontal position. You can use the system unit in either the horizontal or vertical position as
shown in this illustration. The unit has a removable base for stabilizing when the unit is in the
vertical position. The base is attached to the bottom of the system unit when the system unit
is in the horizontal position. See Chapter 7 for instructions on changing the base position.
Base
Vertical Position
Horizontal Position
Attention: Do not operate the system unit when it is on the side that does not have base
screw mounting holes. This may result in damaged or lost data.
Disk Drives
The system unit has disk drive positions inside the system unit.There are no operator
controls on these internal disk drives.
The disk is a permanent part of the drive and is sometimes called a
fixed-disk .
Sometimes data is lost because of user action, accident, or equipment trouble, so you
should back up disk data at regular intervals. See your operating system documentation for
information about using diskettes or tape drives to back up files.
Disk Drive
Positions
