IBM System Storage N7000 Manual

N7000 Series Gateway
Installation and Setup Instructions
IBM System Storage

Hostname:
Network Configuration Information e0a e0b e0c e0d e0e e0f
IP addresses: First 3 #s
______.______.______
Netmask:
Media type/speed (100tx-fd, 100tx,
auto [100/1000])
Flow control (none, receive, send,
full):
Enable jumbo frames?
IP address or name of default gateway:
IP address or name of administration host:
(Leave blank for root access to /etc from
any NFS client)
Where is the NAS system located?
(Text string)
Do you want to run DNS resolver?
Do you want to run NIS client?
Would you like to configure the RLM LAN
interface [y]?
RLM IP Address
RLM Netmask
RLM Gateway IP Address
Would you like to enable DHCP on the
RLM LAN interface [y]?
Enter the name or IP address of the
mail host:
Below is a copy of the system setup worksheet. If a worksheet has not yet
been completed for this setup, remove this sheet and fill in the following
information that is needed for the setup before unpacking the system unit.

Customer-supplied items needed for setup:
!
!
!
!
!
!
!
Ethernet LAN cables
Fibre Channel cables
Console (for example, a PC or laptop)
#2 Phillips screwdriver and slotted screwdriver
ESD wrist strap
Pointed tool for setting termination switches
7-mm nut driver
1
This document provides installation and setup instructions for the IBM System
Storage N7700 and N7900 gateway systems. Additional information about
these products can be found in the
TM
IBM System Storage N7000 Series Hardware
and Service Guide.
®
Need help?
If you encounter any difficulties while setting up your system, contact IBM service
and support for assistance. Information can also be found at the following Web
site:
www.ibm.com/storage/support/nas/
Read the safety notices:
Before continuing, make sure that you have reviewed the safety notices on the
documentation CD that came with this system. Do not plug any cables into the
system, adapters, or any electrical outlets until you have reviewed the safety
information and followed the procedures in this document.
IMPORTANT
Installation of gateway systems is intended to be performed by IBM-trained
service personnel.

1Unpacking the N7000 series gateway
2
Note: The contents of the box will differ based
on the model you purchased. See Step 1.1 for a
list of contents for specific models.
Note: Lift box from crate. The
contents will remain in place.
Note: Eight Small Form Factor Pluggable (SFP)
modules will either be in the accessory box or
will be installed on the fiber ports of the gateway
system.
Accessory kit:
- IBM rail kit
- Power cable
- DB-9 to RJ-45
console adapter
- Cable
management tray
- Serial null modem
cable
N7700/N7900
(gateway system)

1.1 Verify that the shipping packages include the following items:
N7700 (2866-A11) / N7900 (2867-A11)
1 N7700/N7900
1 Console adapter, RJ-45 to DB-9
1 IBM rail kit
1 Serial null modem cable
1 Cable management tray
1 ESD wrist strap
2 Power cords
1 Publications
There will also be at least one envelope with the software EULA and
license keys.
2 N7700/N7900
1 Console adapter, RJ-45 to DB-9
2 IBM rail kit
1 Serial null modem cable
2 Cable management tray
2 ESD wrist strap
4 Power cords
1 Publications
There will also be at least one envelope with the software EULA and
license keys.
N7700 (2866-A21) / N7900 (2867-A21)
32 kg (70.5 lb)
3
Caution: The weight of this part or unit is between 32 and 55 kg (70.5
and 121.2 lb). It takes three persons to safely lift this part or unit.
(C010)

Installing the rails in an IBM 19-inch rack
2
4
Note: Read this document in its entirety before proceeding.
Gateway 1 N7700/N7900
(A11)
Note: It is recommended that the N7700/N7900 be placed in the lowest
position available in a rack. For example:
Gateway 2
Gateway 1
N7700/N7900
N7700/N7900
(A21)
(A21)
Model A11 Model A21
Expansion Unit 2
.
.
.
Expansion Unit 1
Filer 2, Loop 1
Filer 2, Loop 1
Expansion Unit 2
Expansion Unit 1
Filer 1, Loop 1
Filer 1, Loop 1
.
.
.
Expansion Unit 4
Expansion Unit 3
Expansion Unit 2
Expansion Unit 1

5
2.1 Loosen (but do not remove) the four rai-adjustment screws on each rail.
Right rail
Left rail
Front of rack
Rear of rack
Rail adjustment
screws
2.2 Use the figure on the next page for reference. At the front of the rack,
position the right-hand rail into the rack at the appropriate EIA location
(make sure that the two locating pins seat properly). The bottom of the
rail should line up with the bottom EIA boundary.
When installed, each N7700/N7900 unit will occupy a 6U space.
Using two silver pan-head M5 screws, attach the rail to the front of the
rack using holes H2 and H8. Tighten the screws with a screwdriver.
Note:
2.3 At the rear of the rack, position the rail at the same EIA location used in
step 2.2 (make sure that the locating pins seat properly). Using two silver
pan-head M5 screws,
Tighten these screws with a screwdriver.
attach the rail to the rack using holes H2 and H8.
2.4 Tighten the four rail-adjustment screws on the installed rail.
Locating pins

6
2.5 Repeat steps 2.2 through 2.4 for the left-hand rail.
2.6 Repeat steps 2.1 through 2.5 if you are installing a second N7700/N7900.
Section of rack EIA rail
H2
H1
H3
H4
H5
H6
H7
H8
H9
Locating pins
Bottom rail screws
REAR
Left and Right
Rails
Chassis attach screw
H2
H1
H3
H4
H5
H6
H7
H8
H9
FRONT
Left and Right
Rails
Top rail screws
Locating pins
Chassis attach screw
1 EIA unit (1U)

3Installing the N7000 series gateway in the rack
7
32 kg (70.5 lb)
3.1 Remove the foam hardware protectors and the plastic surrounding the
system unit.
2 Power
supplies
5 Fan
modules
Bezel
2
3.2 Carefully remove the front bezel of the N7700/N7900 gateway by pulling
out on the semi-circular openings on either side of the bezel.
Caution: The weight of this part or unit is between 32 and 55 kg (70.5
and 121.2 lb). It takes three persons to safely lift this part or unit.
(C010)

Thumbscrew
Release tab
3.3 Remove the five fan modules from the front of the system unit by performing
the following steps:
1. Loosen the thumbscrew on the fan module handle.
2. Press the release tab of the fan module handle, and then pull
the handle toward you to remove the fan from the chassis. Make
sure that you support the fan with your free hand. After removing
each fan place it on a table or other safe place.
3.4 Remove the two power supplies from the rear of the system unit by
performing the following steps:
1. Loosen the two thumbscrews on the power supply.
2. Lower the cam handle and slide the power supply out of the
chassis. Make sure that you support the power supply with
your free hand. After removing each power supply place it on a
table or other safe place.
Thumbscrews
Cam handle
Cam handle
8

3.6 At the front of the rack, using four black hex-head M5 screws in the H3
and H7 holes, secure the system unit to the rack by threading the screws
through the system unit bracket and the rack frame rail into the threaded
rail nuts. Tighten the screws using the 7mm nut driver. Refer to the figure
below step 2.6 on page 6.
3.9 Replace the front bezel of the N7700/N7900 gateway by snapping it
back onto the system unit chassis.
3.5 The system unit is installed from the front of the rack. Position the pallet
near the front of the rack. Lift the system unit using the handles on the
chassis and place the system unit onto the rails. Then slide it into the rack
until the front mounting bracket of the system unit is flush with the frame
rails of the rack.
3.7 Replace the two power supplies at the rear of the gateway system unit by
performing the following steps:
1. Align the edges of the power supply with the opening in the
system chassis and gently push the power supply into the
chassis until the cam handle begins to rise.
2. Push the cam handle to the closed position.
3. Tighten the two thumbscrews on the power supply.
Replace the five fan modules at the front of the system unit by performing
the following steps:
1. Align the fan with the fan opening in the chassis, and gently
slide it into the chassis as far as it can go.
The fan modules are keyed and can only be installed one
way. If the fan module does not fit properly, flip the module 180
degrees and reinstall it.
2. Finish seating the fan by pushing firmly on the edges of the
fan housing. When properly seated, the locking tab engages
the handle.
3. Tighten the thumbscrew on the handle.
Note:
The upper two fan modules are installed
with the handles at the bottom, and the lower three fan modules
are installed rotated 180 degrees, with the handles at the top.
3.8
9

10
3.10 From the rear of the rack, attach the rear tie down bracket in the
orientation shown to the rails using four M5 flat-head screws. The tie
down bracket should be over the rear of the system unit.
Tie down bracket
M5 flat head screws

4Installing the cabling hardware
4.1 Verify that SFPs are installed and firmly seated in Fibre Channel ports 0a
through 0h.
4.3 If you are installing a model A11, go to step 6 on page 13.
If you are installing a model A21, go to step 5 on page 12.
4.2
4.2
I0I0
0a 0b 0c 0d 0e 0f 0g 0h
RLM
e0e e0f
e0a e0b e0c e0d
11
4.4
4.1
4.2
Install your cable management tray by inserting one arm into the chassis
as shown. Then press the other arm towards the center of the chassis
and insert it in the slot so that it locks into place.
11

5.1 To cable the cluster adapters, complete the following steps, using the
diagram for reference. NVRAM6 adapters, which also function as the
cluster interconnect adapters, must be installed in slot 1 of each gateway
node.
Cluster cables can be either fiber or copper. If you are using fiber
cables, a copper-fiber converter must be plugged into the NVRAM6
adapter before attaching a fiber cluster cable.
The cable management arm must be used to support the cluster
cables. If left unsupported, the adapter connectors can be damaged by
the cable weight.
5.1.1 Plug one end of the cluster cable into one of gateway 1's
cluster adapter ports. Then plug the other end into gateway 2's
corresponding cluster adapter port.
You must not cross-cable the cluster-interconnect
adapter. Cable the gateway1 ports only to the identical ports on
the gateway 2 node.
5.1.2 Repeat step 5.1.1 for the remaining port on the cluster adapter.
5.1.3 Gently pull on the cable ends to ensure that they are properly
seated.
5.1.4 Go to Step 6 on page 13.
Note:
Note:
Attention:
5Cluster cabling (model A21 only)
12
Cluster cable
Gateway 2
Gateway 1
Slot 1
123456789
123456789
Note: Refer to the
for more information on clustering.
Data ONTAP Active-Active Configuration Guide for
your version of Data ONTAP

Installing the power cables
6
6.1 Make sure all power supply switches on the N7700/N7900(s) and any
attached expansion units(s) are in the Off position.
Connect the power cords to all
power receptacles for all storage systems that are being installed
using power cord retainer clips as shown below.
power supply 1 and power supply 2
6.2 Connect the power cords to the power sources, making sure that the
This ensures
redundant power.
power supplies on the left and right sides of the system are connected
to separate and independent AC power sources.
Caution: Do not power on the system at this time.
6.3 Give all documentation (including this document) and all hardware to the
customer.
6.1
Note: Refer the customer to the next two pages for additional
planning and setup information.
13

Planning tasks for the N7700/N7900 gateway
Reviewing site planning information
Reviewing the compatibility information for
the following items:
Storage subsystems supported
Storage subsystem microcode
versions required
Switch support and firmware
Planning which storage units (LUNs) on the
storage subsystem are to be allocated for
gateways (Your storage subsystem vendor
might refer to a unit of data storage by a
different name.)
Planning setup of LUN access by
gateways.
Determining how to use Data ONTAP
features to manage your storage (for
example, setting LUN sizes).
Reviewing the configuration rules for setting
up the storage subsystem.
Determining whether to use SyncMirror
for additional RAID-level data protection.
Creating a document that shows the
desired logical configuration between the
gateways and storage subsystems
!
!
!
®
- Introduction and Planning Guide
Planning task: Refer to the following:
- Interoperability Matrix
-
- Gateway Implementation Guide
Configuration diagrams for the storage
subsystems and a topology diagram of the
network
for your
storage subsystem type
-Storage subsystem configuration diagrams
that you might already have
- Gateway Planning Guide
- Gateway Planning Guide
- Gateway Implementation Guide for your
storage subsystem type
- Gateway Implementation Guide
Gateway Software Setup, Installation, and
Management Guide
for your
storage subsystem type
-
14

Setup overview for the N7700/N7900 gateway
Prepare for connectivity between gateways
and storage subsystems, including the
following tasks:
Creating LUNs on the storage subsystem
Setting LUN security, as appropriate
Exporting (mapping) the LUNs to the
targeted ports for the gateways
Installing the gateway in a rack
Connecting your gateway to a storage
subsystem
Connecting your gateway to create a cluster
failover pair
Connecting your gateway to a network,
ASCII terminal, and any third-party tape
backup devices, and then powering on and
booting in regular mode
Performing basic setup and configuration of
the gateway software, including:
Specifying the LUNs on the storage
subsystem that the gateway can access
Providing system information for the
gateway, such as IP address and media
type
Installing an NFS or a CFS license
Installing the Data ONTAP software
Configuring Data ONTAP features that you
want to use with your gateway
!
!
!
!
!
!
!
Setup task: Refer to the following:
- Gateway Implementation Guide for your
storage subsystem type
- Gateway Implementation Guide for your
storage subsystem type
- Gateway Implementation Guide for your
storage subsystem type
-Gateway Software Setup, Installation, and
Management Guide
-This document
-
- Gateway Implementation Guide
Storage subsystem documentation
for your
storage subsystem type
-
Data ONTAP documentation library
Gateway Software Setup, Installation, and
Management Guide
-
15
For a complete list of all Data ONTAP gateway publications, see Appendix I, “IBM System
Storage N series documentation,” in the
, GA32-0543
IBM System Storage N series Introduction and
Planning Guide Introduction and Planning Guide. The latest version of the and
other N series documentation is available at the following Web site:
www. ibm.com/storage/support/nas

International Business Machines Corporation 2006, 2009
Printed in USA
All Rights Reserved
Mail comments to:
IBM Corporation
Attention Department GZW
9000 South Rita Road
Tucson, AZ 85744-0001
Internet URL: www.ibm.com/storage/support/nas
GC26-7956-03
45E6980
NA 210-04405+A0
References in this publication to IBM products or
services do not imply that IBM intends to make
them available in every country or region.
IBM, the IBM logo, and System Storage are
trademarks or registered trademarks of International
Business Machines Corporation.
Data ONTAP, SyncMirror, NetApp, and Network
Appliance are trademarks and/or registered
trademarks of Network Appliance, Inc in the United
States and other countries.
Other company, product, and service names may
be trademarks or service marks of others.
