IBM S824L Instruction Manual

Power Systems
Installing the IBM Power System
S824L (8247-42L)
GI11-9911-02
IBM

Power Systems
Installing the IBM Power System
S824L (8247-42L)
GI11-9911-02
IBM

Note
Before using this information and the product it supports, read the information in “Safety notices” on page v, “Notices” on
page 27, the IBM Systems Safety Notices manual, G229-9054, and the IBM Environmental Notices and User Guide, Z125–5823.
This edition applies to IBM Power Systems™servers that contain the POWER8 processor and to all associated
models.
© Copyright IBM Corporation 2014, 2015.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety notices ................................. v
Installing the IBM Power System S824L (8247-42L) ................. 1
Installing the IBM Power System S824L (8247-42L)....................... 1
Determining your server type ............................ 1
Installing a rack-based server ............................. 1
Prerequisite for installing the rack-mounted server..................... 1
Completing inventory for your server ......................... 2
Determining and marking the location in the rack ..................... 2
Attaching the 8247-42L mounting hardware to the rack ................... 4
Installing the server into a rack ........................... 6
Installing the cable-management arm ......................... 8
Cabling the server with an ASCII terminal ....................... 12
Cabling the server ............................... 13
Completing server setup ............................. 14
Setting up a preinstalled server............................ 14
Prerequisite for installing the preinstalled server ..................... 14
Completing inventory for your preinstalled server .................... 15
Removing the shipping bracket and connecting power cords and power distribution unit (PDU) for your
preinstalled server ............................... 15
Cabling the server with an ASCII terminal ....................... 17
Routing cables through the cable-management arm and connecting expansion units ......... 18
Completing server setup ............................. 18
Common information for installing servers .................... 21
Common system attention LEDs and system reference codes ................... 21
Best practices for integrating cable and system placement .................... 22
Supporting information for setting up consoles ....................... 24
Accessing the ASMI by using a web browser ....................... 24
Setting the IP address on your PC or notebook ...................... 25
Windows Vista ................................ 26
Windows 7 ................................. 26
Correcting an IP address .............................. 26
Notices ................................... 27
Trademarks ................................... 28
Electronic emission notices .............................. 29
Class A Notices ................................. 29
Class B Notices ................................. 32
Terms and conditions ................................ 35
© Copyright IBM Corp. 2014, 2015 iii

iv Power Systems: Installing the IBM Power System S824L (8247-42L)

Safety notices
Safety notices may be printed throughout this guide:
vDANGER notices call attention to a situation that is potentially lethal or extremely hazardous to
people.
vCAUTION notices call attention to a situation that is potentially hazardous to people because of some
existing condition.
vAttention notices call attention to the possibility of damage to a program, device, system, or data.
World Trade safety information
Several countries require the safety information contained in product publications to be presented in their
national languages. If this requirement applies to your country, safety information documentation is
included in the publications package (such as in printed documentation, on DVD, or as part of the
product) shipped with the product. The documentation contains the safety information in your national
language with references to the U.S. English source. Before using a U.S. English publication to install,
operate, or service this product, you must first become familiar with the related safety information
documentation. You should also refer to the safety information documentation any time you do not
clearly understand any safety information in the U.S. English publications.
Replacement or additional copies of safety information documentation can be obtained by calling the IBM
Hotline at 1-800-300-8751.
German safety information
Das Produkt ist nicht für den Einsatz an Bildschirmarbeitsplätzen im Sinne § 2 der
Bildschirmarbeitsverordnung geeignet.
Laser safety information
IBM®servers can use I/O cards or features that are fiber-optic based and that utilize lasers or LEDs.
Laser compliance
IBM servers may be installed inside or outside of an IT equipment rack.
© Copyright IBM Corp. 2014, 2015 v

DANGER
When working on or around the system, observe the following precautions:
Electrical voltage and current from power, telephone, and communication cables are hazardous. To
avoid a shock hazard:
vIf IBM supplied the power cord(s), connect power to this unit only with the IBM provided power
cord. Do not use the IBM provided power cord for any other product.
vDo not open or service any power supply assembly.
vDo not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm.
vThe product might be equipped with multiple power cords. To remove all hazardous voltages,
disconnect all power cords.
vConnect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet
supplies proper voltage and phase rotation according to the system rating plate.
vConnect any equipment that will be attached to this product to properly wired outlets.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or structural damage.
vDo not attempt to switch on power to the machine until all possible unsafe conditions are
corrected.
vAssume that an electrical safety hazard is present. Perform all continuity, grounding, and power
checks specified during the subsystem installation procedures to ensure that the machine meets
safety requirements.
vDo not continue with the inspection if any unsafe conditions are present.
vDisconnect the attached power cords, telecommunications systems, networks, and modems before
you open the device covers, unless instructed otherwise in the installation and configuration
procedures.
vConnect and disconnect cables as described in the following procedures when installing, moving,
or opening covers on this product or attached devices.
To Disconnect:
1. Turn off everything (unless instructed otherwise).
2. Remove the power cords from the outlets.
3. Remove the signal cables from the connectors.
4. Remove all cables from the devices.
To Connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. Attach the power cords to the outlets.
5. Turn on the devices.
Sharp edges, corners and joints may be present in and around the system. Use care when
handling equipment to avoid cuts, scrapes and pinching.
(D005)
DANGER
vi Power Systems: Installing the IBM Power System S824L (8247-42L)

Observe the following precautions when working on or around your IT rack system:
vHeavy equipment–personal injury or equipment damage might result if mishandled.
vAlways lower the leveling pads on the rack cabinet.
vAlways install stabilizer brackets on the rack cabinet.
vTo avoid hazardous conditions due to uneven mechanical loading, always install the heaviest
devices in the bottom of the rack cabinet. Always install servers and optional devices starting
from the bottom of the rack cabinet.
vRack-mounted devices are not to be used as shelves or work spaces. Do not place objects on top
of rack-mounted devices.
vEach rack cabinet might have more than one power cord. Be sure to disconnect all power cords in
the rack cabinet when directed to disconnect power during servicing.
vConnect all devices installed in a rack cabinet to power devices installed in the same rack
cabinet. Do not plug a power cord from a device installed in one rack cabinet into a power
device installed in a different rack cabinet.
vAn electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of
the system or the devices that attach to the system. It is the responsibility of the customer to
ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
CAUTION
vDo not install a unit in a rack where the internal rack ambient temperatures will exceed the
manufacturer's recommended ambient temperature for all your rack-mounted devices.
vDo not install a unit in a rack where the air flow is compromised. Ensure that air flow is not
blocked or reduced on any side, front, or back of a unit used for air flow through the unit.
vConsideration should be given to the connection of the equipment to the supply circuit so that
overloading of the circuits does not compromise the supply wiring or overcurrent protection. To
provide the correct power connection to a rack, refer to the rating labels located on the
equipment in the rack to determine the total power requirement of the supply circuit.
v(For sliding drawers.) Do not pull out or install any drawer or feature if the rack stabilizer brackets
are not attached to the rack. Do not pull out more than one drawer at a time. The rack might
become unstable if you pull out more than one drawer at a time.
v(For fixed drawers.) This drawer is a fixed drawer and must not be moved for servicing unless
specified by the manufacturer. Attempting to move the drawer partially or completely out of the
rack might cause the rack to become unstable or cause the drawer to fall out of the rack.
(R001)
Safety notices vii

CAUTION:
Removing components from the upper positions in the rack cabinet improves rack stability during
relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a
room or building.
vReduce the weight of the rack cabinet by removing equipment starting at the top of the rack
cabinet. When possible, restore the rack cabinet to the configuration of the rack cabinet as you
received it. If this configuration is not known, you must observe the following precautions:
– Remove all devices in the 32U position (compliance ID RACK-001 or 22U (compliance ID RR001)
and above.
– Ensure that the heaviest devices are installed in the bottom of the rack cabinet.
– Ensure that there are little-to-no empty U-levels between devices installed in the rack cabinet
below the 32U (compliance ID RACK-001 or 22U (compliance ID RR001) level, unless the
received configuration specifically allowed it.
vIf the rack cabinet you are relocating is part of a suite of rack cabinets, detach the rack cabinet from
the suite.
vIf the rack cabinet you are relocating was supplied with removable outriggers they must be
reinstalled before the cabinet is relocated.
vInspect the route that you plan to take to eliminate potential hazards.
vVerify that the route that you choose can support the weight of the loaded rack cabinet. Refer to the
documentation that comes with your rack cabinet for the weight of a loaded rack cabinet.
vVerify that all door openings are at least 760 x 230 mm (30 x 80 in.).
vEnsure that all devices, shelves, drawers, doors, and cables are secure.
vEnsure that the four leveling pads are raised to their highest position.
vEnsure that there is no stabilizer bracket installed on the rack cabinet during movement.
vDo not use a ramp inclined at more than 10 degrees.
vWhen the rack cabinet is in the new location, complete the following steps:
– Lower the four leveling pads.
– Install stabilizer brackets on the rack cabinet.
– If you removed any devices from the rack cabinet, repopulate the rack cabinet from the lowest
position to the highest position.
vIf a long-distance relocation is required, restore the rack cabinet to the configuration of the rack
cabinet as you received it. Pack the rack cabinet in the original packaging material, or equivalent.
Also lower the leveling pads to raise the casters off of the pallet and bolt the rack cabinet to the
pallet.
(R002)
(L001)
DANGER: Hazardous voltage, current, or energy levels are present inside any component that has this
label attached. Do not open any cover or barrier that contains this label. (L001)
(L002)
viii Power Systems: Installing the IBM Power System S824L (8247-42L)

DANGER: Rack-mounted devices are not to be used as shelves or work spaces. (L002)
(L003)
or
or
1 2
34
or
Safety notices ix

1234
DANGER: Multiple power cords. The product might be equipped with multiple power cords. To remove
all hazardous voltages, disconnect all power cords. (L003)
(L007)
CAUTION: A hot surface nearby. (L007)
(L008)
CAUTION: Hazardous moving parts nearby. (L008)
All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class
1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser
product. Consult the label on each part for laser certification numbers and approval information.
xPower Systems: Installing the IBM Power System S824L (8247-42L)

CAUTION:
This product might contain one or more of the following devices: CD-ROM drive, DVD-ROM drive,
DVD-RAM drive, or laser module, which are Class 1 laser products. Note the following information:
vDo not remove the covers. Removing the covers of the laser product could result in exposure to
hazardous laser radiation. There are no serviceable parts inside the device.
vUse of the controls or adjustments or performance of procedures other than those specified herein
might result in hazardous radiation exposure.
(C026)
CAUTION:
Data processing environments can contain equipment transmitting on system links with laser modules
that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical
fiber cable or open receptacle. Although shining light into one end and looking into the other end of
a disconnected optical fiber to verify the continuity of optic fibers many not injure the eye, this
procedure is potentially dangerous. Therefore, verifying the continuity of optical fibers by shining
light into one end and looking at the other end is not recommended. To verify continuity of a fiber
optic cable, use an optical light source and power meter. (C027)
CAUTION:
This product contains a Class 1M laser. Do not view directly with optical instruments. (C028)
CAUTION:
Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the following
information: laser radiation when open. Do not stare into the beam, do not view directly with optical
instruments, and avoid direct exposure to the beam. (C030)
CAUTION:
The battery contains lithium. To avoid possible explosion, do not burn or charge the battery.
Do Not:
v___ Throw or immerse into water
v___ Heat to more than 100°C (212°F)
v___ Repair or disassemble
Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local
regulations. In the United States, IBM has a process for the collection of this battery. For information,
call 1-800-426-4333. Have the IBM part number for the battery unit available when you call. (C003)
(C048)
CAUTION regarding IBM provided VENDOR LIFT TOOL:
vOperation of LIFT TOOL by authorized personnel only.
vLIFT TOOL intended for use to assist, lift, install, remove units (load) up into rack elevations. It is
not to be used loaded transporting over major ramps nor as a replacement for such designated tools
like pallet jacks, walkies, fork trucks and such related relocation practices. When this is not
practicable, specially trained persons or services must be used (for instance, riggers or movers).
vRead and completely understand the contents of LIFT TOOL operator's manual before using.
Failure to read, understand, obey safety rules, and follow instructions may result in property
damage and/or personal injury. If there are questions, contact the vendor's service and support.
Local paper manual must remain with machine in provided storage sleeve area. Latest revision
manual available on vendor's web site.
vTest verify stabilizer brake function before each use. Do not over-force moving or rolling the LIFT
TOOL with stabilizer brake engaged.
vDo not move LIFT TOOL while platform is raised, except for minor positioning.
Safety notices xi

vDo not exceed rated load capacity. See LOAD CAPACITY CHART regarding maximum loads at
center versus edge of extended platform.
vOnly raise load if properly centered on platform. Do not place more than 200 lb (91 kg) on edge of
sliding platform shelf also considering the load's center of mass/gravity (CoG).
vDo not corner load the platform tilt riser accessory option. Secure platform riser tilt option to main
shelf in all four (4x) locations with provided hardware only, prior to use. Load objects are designed
to slide on/off smooth platforms without appreciable force, so take care not to push or lean. Keep
riser tilt option flat at all times except for final minor adjustment when needed.
vDo not stand under overhanging load.
vDo not use on uneven surface, incline or decline (major ramps).
vDo not stack loads.
vDo not operate while under the influence of drugs or alcohol.
vDo not support ladder against LIFT TOOL.
vTipping hazard. Do not push or lean against load with raised platform.
vDo not use as a personnel lifting platform or step. No riders.
vDo not stand on any part of lift. Not a step.
vDo not climb on mast.
vDo not operate a damaged or malfunctioning LIFT TOOL machine.
vCrush and pinch point hazard below platform. Only lower load in areas clear of personnel and
obstructions. Keep hands and feet clear during operation.
vNo Forks. Never lift or move bare LIFT TOOL MACHINE with pallet truck, jack or fork lift.
vMast extends higher than platform. Be aware of ceiling height, cable trays, sprinklers, lights, and
other overhead objects.
vDo not leave LIFT TOOL machine unattended with an elevated load.
vWatch and keep hands, fingers, and clothing clear when equipment is in motion.
vTurn Winch with hand power only. If winch handle cannot be cranked easily with one hand, it is
probably over-loaded. Do not continue to turn winch past top or bottom of platform travel.
Excessive unwinding will detach handle and damage cable. Always hold handle when lowering,
unwinding. Always assure self that winch is holding load before releasing winch handle.
vA winch accident could cause serious injury. Not for moving humans. Make certain clicking sound
is heard as the equipment is being raised. Be sure winch is locked in position before releasing
handle. Read instruction page before operating this winch. Never allow winch to unwind freely.
Freewheeling will cause uneven cable wrapping around winch drum, damage cable, and may cause
serious injury. (C048)
Power and cabling information for NEBS (Network Equipment-Building System)
GR-1089-CORE
The following comments apply to the IBM servers that have been designated as conforming to NEBS
(Network Equipment-Building System) GR-1089-CORE:
The equipment is suitable for installation in the following:
vNetwork telecommunications facilities
vLocations where the NEC (National Electrical Code) applies
The intrabuilding ports of this equipment are suitable for connection to intrabuilding or unexposed
wiring or cabling only. The intrabuilding ports of this equipment must not be metallically connected to the
interfaces that connect to the OSP (outside plant) or its wiring. These interfaces are designed for use as
intrabuilding interfaces only (Type 2 or Type 4 ports as described in GR-1089-CORE) and require isolation
from the exposed OSP cabling. The addition of primary protectors is not sufficient protection to connect
these interfaces metallically to OSP wiring.
xii Power Systems: Installing the IBM Power System S824L (8247-42L)

Note: All Ethernet cables must be shielded and grounded at both ends.
The ac-powered system does not require the use of an external surge protection device (SPD).
The dc-powered system employs an isolated DC return (DC-I) design. The DC battery return terminal
shall not be connected to the chassis or frame ground.
The dc-powered system is intended to be installed in a common bonding network (CBN) as described in
GR-1089-CORE.
Safety notices xiii

xiv Power Systems: Installing the IBM Power System S824L (8247-42L)

Installing the IBM Power System S824L (8247-42L)
These instructions will help you install, cable, and set up your IBM Power®System S824L (8247-42L)
server.
Installing the IBM Power System S824L (8247-42L)
Use this information to learn about installing the IBM Power System S824L (8247-42L).
You might need to read the following documents before you begin to install the server:
vThe latest version of this document is maintained online. See Installing the IBM PowerLinux 8R2
(8247-42L) (http://publib.boulder.ibm.com/infocenter/systems/scope/hw/topic/p8egk/
p8egk_kickoff.htm).
vTo plan your server installation, see Planning for the system (http://publib.boulder.ibm.com/
infocenter/systems/scope/hw/topic/p8had/p8had_8xx_kickoff.htm).
Determining your server type
Determine whether you are installing a rack-mounted server, a server that arrived preinstalled in a rack,
or a stand-alone server.
Determine which type of server you are installing. For more information, see the following table.
Table 1. Determine the type of server you are installing and follow the instructions to find related information.
Server type Description Where to find related information
Rack-mounted Your system arrived without a rack,
and you need to install the system
into an existing rack.
“Installing a rack-based server”
Preinstalled Your system arrived preinstalled in a
rack.
“Setting up a preinstalled server” on
page 14
Installing a rack-based server
Use this information to learn about installing a rack-based server.
Prerequisite for installing the rack-mounted server
Use the information to understand the prerequisites that are required for installing the server.
You might need to read the following documents before you begin to install the server:
vThe latest version of this document is maintained online. See Installing the IBM Power System S824L
(8247-42L) (http://www.ibm.com/support/knowledgecenter/POWER8/p8egk/p8egk_kickoff.htm).
vTo plan your server installation, see Planning for the system (http://www.ibm.com/support/
knowledgecenter/POWER8/p8had/p8had_8xx_kickoff.htm).
Ensure that you have the following items before you start your installation:
vPhillips screwdriver
vFlat-head screwdriver
vRack with four units of space
Note: If you do not have a rack that is installed, install the rack. For instructions, see Racks and rack
features (http://www.ibm.com/support/knowledgecenter/POWER8/p8hbf/p8hbf_8xx_kickoff.htm).
© Copyright IBM Corp. 2014, 2015 1

Completing inventory for your server
Use this information to complete inventory for your server.
To complete the inventory, complete the following steps:
1. Verify that you received all the boxes you ordered.
2. Unpack the server components as needed.
3. Complete a parts inventory before you install each server component by following these steps:
a. Locate the inventory list for your server.
b. Ensure that you received all the parts that you ordered.
Note: Your order information is included with your product. You can also obtain order
information from your marketing representative or the IBM Business Partner.
If you have incorrect, missing, or damaged parts, consult any of the following resources:
vYour IBM reseller.
vIBM Rochester manufacturing automated information line at 1-800-300-8751 (United States only).
vThe Directory of worldwide contacts website http://www.ibm.com/planetwide. Select your
location to view the service and support contact information.
Determining and marking the location in the rack
Learn how to determine where to install the PCIe Gen3 I/O expansion drawer (PCIe3 expansion drawer)
into the rack.
If you received a mounting template, you can use the template to mark the locations. If you did not
receive a mounting template, continue with the following steps.
To determine where to install the drawer into a rack, complete the following steps:
1. Read the Rack safety notices (http://www.ibm.com/support/knowledgecenter/POWER8/p8hbf/
racksafety.htm).
2. Determine where in the rack to place the drawer in relation to other system hardware. As you plan
for installing the drawer in a rack, keep in mind the following information:
vOrganize larger and heavier units into the lower part of the rack.
vPlan to install units into the lower part of the rack first.
vRecord the Electronic Industries Alliance (EIA) locations in your plan.
3. If necessary, remove the filler panels to allow access to the inside of the rack enclosure where you
plan to place the drawer.
2Power Systems: Installing the IBM Power System S824L (8247-42L)

4. Face the front of the rack and work from the left side to complete the following steps:
Remember: If you received a mounting template, you can use the template to mark the locations
instead of using the manual method.
a. Make a note of both the lowest and highest EIA units to be used for the drawer.
b. Use tape, a marker, or a pencil to mark the top mounting hole (A) of the third EIA unit. Insert a
nut clip at this location.
c. Mark the top mounting hole on the lowest EIA unit.
Note: Mark the rack so that these marks can also be seen from the rear of the rack.
d. Count up two holes and place another mark (B) beside that mounting hole. You now have two (B)
marks on the rack, with one mounting hole between the marks.
Figure 1. Removing the filler panels
Installing the IBM Power System S824L (8247-42L) 3

5. Repeat these steps to place three marks on the corresponding mounting holes on the front-right side
of the rack. Insert a nut clip in the (A) mark.
6. Go to the rear of the rack and work from the left side to complete the following steps:
a. Find the EIA unit that corresponds to the lowest EIA unit marked on the front of the rack.
b. Use tape, a marker, or a pencil to mark the top mounting hole of this EIA unit.
c. Count up two holes and place another mark (C) beside that mounting hole. You now have two (C)
marks on the rack, with one mounting hole between the marks.
d. Count up three mounting holes from where you placed your last mark, and place another mark
next to that mounting hole.
e. Count up three holes and place another mark (D) beside that mounting hole. You now have two
(D) marks on the rack. Insert nut clips in these two locations.
Note: During this procedure, put nut clips in the (D) marks. Then, during the procedure to attach the
mounting hardware to the rack, put rail pins in the (C) marks.
7. Repeat these steps to place four marks on the corresponding mounting holes on the rear-right side of
the rack. Insert nut clips in the (D) marks.
Attaching the 8247-42L mounting hardware to the rack
You might need to attach the mounting hardware to the rack. Use the procedure in this section to
perform this task. This section also includes illustrations of the related hardware components and shows
how these components relate to each other.
Figure 2. Marking the front installation locations
Figure 3. Marking the rear installation locations
4Power Systems: Installing the IBM Power System S824L (8247-42L)
