Infoprint Color 1454 & 146 4
Setup Guide
S510-4059-00


Infoprint Color 1454 & 146 4
Setup Guide
S510-4059-00


Edition: June 2004
Lexmark and MarkNet are trademarks of Lexmark International, Inc., registered in the
United States and/or other countries.
ImageQuick is a trademark of Lexmark International, Inc.
PostScript® is a registered trademark of Adobe Systems Incorporated. PostScript 3 is
Adobe Systems’ designation of a set of printer commands (language) and functions
included in its software products. This printer is intended to be compatible with the
PostScript 3 language. This means the printer recognizes PostScript 3 commands
used in various application programs, and the printer emulates the functions
corresponding to the commands.
Other trademarks are the property of their respective owners.
© 2004 Lexmark International, Inc.
All rights reserved.
UNITED STATES GOVERNMENT RIGHTS
This software and any accompanying documentation provided under this agreement
are commercial computer software and documentation developed exclusively at
private expense.
Federal Communications Commission (FCC) compliance
information statement
This printer complies with the limits for a Class B digital device (without a network
cable or high-capacity output finisher installed) and for a Class A digital device (with a
network cable or high-capacity output finisher installed), pursuant to Part 15 of the
FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Any questions on this statement should be directed to:
Director of Lexmark Technology & Services
Lexmark International, Inc.
740 West New Circle Road
Lexington, KY 40550
[phone]
Refer to the online documentation for additional compliance information.
Safety information
•If your product is not marked with this symbol , it must be connected to
an electrical outlet that is properly grounded.
CAUTION: Do not set up this product or make any electrical or cabling
connections, such as the power cord or telephone, during a lightning storm.
•The power cord must be connected to an electrical outlet that is near the
product and easily accessible.
•Refer service or repairs, other than those described in the operating
instructions, to a professional service person.
•This product is designed, tested, and approved to meet strict global safety
standards with the use of specific Lexmark components. The safety features
of some parts may not always be obvious. Lexmark is not responsible for the
use of other replacement parts.
•Your product uses a laser.
CAUTION: Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation
exposure.
•Your product uses a printing process that heats the print media, and the heat
may cause the media to release emissions. You must understand the section
in your operating instructions that discusses the guidelines for selecting print
media to avoid the possibility of harmful emissions.
Conventions
Note: A note identifies something that could help you.
CAUTION: A caution identifies something that could cause you harm.
Warning: A warning identifies something that could damage your product hardware
or software.
Static sensitivity notice
Warning: This symbol identifies static-sensitive parts. Do not touch
in the areas near these symbols without first touching the metal
frame of the printer.

5
Contents
Contents
Step 1: Choose your setup (local or network printer) . . . . . . . . . . . . . . . . . . . . . . . . 7
Local printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Network printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 2: Install drivers for local printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
UNIX/Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Step 3: Unpack the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting up a multifunction printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Step 4: Set up the printer and paper handling options . . . . . . . . . . . . . . . . . . . . . . 10
Printer models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Printer setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installing a 2000-sheet drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installing a 500-sheet drawer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing a duplex unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Positioning the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installing an output expander . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing a 5-bin mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Step 5: Set up the print supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting up the print cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Attaching an operator panel overlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Step 6: Install memory, firmware, or option cards . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Removing the system board access cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installing a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Installing a firmware card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installing a hard disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installing an option card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Replacing the system board access cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Applying the Option Added label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Step 7: Load paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Loading the 500-sheet trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Loading the 2000-sheet tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Loading the multipurpose feeder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Step 8: Attach cables and power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cable types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Attaching cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Step 9: Verify printer setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Printing a menu settings page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Printing a network setup page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Printing Help Menu pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Step 10: Configure for TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Assigning a printer IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Verifying the IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Configuring for Pull Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Step 11: Install drivers for network printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
UNIX/Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
NetWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6
Contents
Step 12: Other sources of information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Viewing and using the publications CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7
Choose your setup (local or network printer)
Step 1: Choose your setup (local or network printer)
Local printer A local printer is a printer attached to your computer using a USB or parallel cable. The
local printer is intended to be used by the computer to which it is attached. If you are
attaching a local printer, you must install the printer driver on your computer before
setting up your printer.
Continue with Step 2: “Install drivers for local printing”on page 7.
Network printer A network printer is a printer attached to a network either by a network cable (such as
Ethernet) or through the use of a server. If you are attaching a network printer, you must
set up your printer on the network first, and then install the printer driver.
Continue with Step 3: “Unpack the printer”on page 9.
Step 2: Install drivers for local printing
The printer driver is software that lets your computer communicate with your printer.
The procedure to install drivers depends on the operating system you are using. Use
the following table to find driver installation instructions for your particular operating
system. If you need additional help, refer to the documentation that shipped with your
computer and your software.
Windows Some Windows operating systems may already include a printer driver that is
compatible with your printer. This may mean that installation will seem automatic in later
versions of Windows. System printer drivers work well for simple printing, but they
contain less functionality than our enhanced custom printer driver.
Note: Installing a custom driver will not
replace the system driver. A separate
printer object will be created and appear
in the Printers folder.
Use the drivers CD that shipped with your printer to install the custom printer driver and
obtain all the enhanced printer features and functionality.
Using Windows Server 2003,
Windows 2000, Windows XP,
Windows98SE,WindowsMe,
and Windows NT
1Insert the drivers CD.
If the CD does not auto launch, click Start àRun, and then type
D:\Setup.exe in the Run dialog box.
Note: USB support is not available for
Windows NT operating systems.
2Click Install Software.
Operating system Go to page...
Windows
Windows Server 2003, Windows 2000, Windows XP,
Windows 98 SE, Windows Me, Windows NT 4.x 7
Windows 95 and Windows 98 (first edition) 8
Serial printing 8
Macintosh 8
UNIX/Linux 9

8
Install drivers for local printing
Note: Some Windows operating
systems require that you have
administrative access to install printer
drivers on your computer.
3Click Printer and Software.
4Click Agree to accept the license agreement.
5Select Suggested, and then click Next.
The Suggested option is the default installation for local and network-attached
setup. If you need to install utilities, change settings, or customize device drivers,
select Custom, and follow the instructions on your screen.
6Select Local Attached, and then click Finish.
It may take some time for the drivers to load.
7Close the drivers CD.
8Go to “Unpack the printer”on page 9.
Using Windows 95 and Windows
98 (first edition) Refer to the User’s Guide on the publications CD for information to install Windows 95
and Windows 98 (first edition) drivers.
Serial printing For information about serial printing, refer to the User’s Guide on the publications CD.
Macintosh Refer to the User’s Guide on the publications CD for information to install Macintosh
drivers and to create a desktop printer icon for Macintosh 8.6–9.x.
Creating a queue in Print Center
(Macintosh OS X) 1Install a printer PostScript Printer Description (PPD) file on your computer.
aInsert the drivers CD.
bDouble-click the installer package for your printer.
Note: A PPD file provides detailed
information about the capabilities of a
printer to your Macintosh computer.
cClick Continue on the Welcome screen and again after you view the
Readme file.
dClick Continue after you view the license agreement, and then click Agree
to accept the terms of the agreement.
eSelect a Destination, and then click Continue.
fEnter your password, and then click OK.
gOn the Easy Install screen, click Install. All the necessary software is
installed on your computer.
hClick Close when installation is complete.
2Open Finder, click Applications, and then click Utilities.
3Double-click Print Center or Printer Setup Utility.
4Do one of the following:
If your USB-attached printer appears in the Printer List, you can quit Print Center
or Printer Setup Utility. A queue has been created for your printer.
If your USB-attached printer does not appear in the Printer List, make sure the
USB cable is properly connected and the printer is turned on. After the printer
appears in the Printer List, you can quit Print Center or Printer Setup Utility.
5After you have installed the drivers on your computer, you are ready to set up
the printer. Go to “Unpack the printer”on page 9.

9
Unpack the printer
UNIX/Linux Local printing is supported on many UNIX and Linux platforms, such as Sun Solaris and
Red Hat.
Note: If your drivers CD does not
contain any UNIX/Linux printer driver
packages, contact the place you
purchased your printer to see if your
printer is supported.
Some printer driver packages are available on the drivers CD. The User’s Guide in each
package gives detailed instructions for installing and using printers in UNIX and Linux
environments.
All the printer driver packages support local printing using a parallel connection. The
driver package for Sun Solaris supports USB connections to Sun Ray appliances and
Sun workstations.
After you have installed the drivers on your computer, you are ready to set up the printer.
Go to “Unpack the printer”on page 9.
Step 3: Unpack the printer
Setting up a
multifunction printer If you purchased a multifunction printer (MFP) that copies, faxes, and scans, refer to the
documentation that came with the device to see if furniture or other hardware needs to
be set up first.
Unpacking
CAUTION: The printer weighs 47.7 kg
(105 lb) and requires at least two people
to lift it safely.
1Select a location for your printer:
•Leave enough room to open the printer trays, covers, and doors; access
options; and allow for proper ventilation.
•Provide the proper environment:
–A firm, level surface
–Away from the direct airflow of air conditioners, heaters, or ventilators
–Free of temperature, sunlight, or humidity extremes or fluctuations
–Clean, dry, and free of dust
38 cm
(15 in.)
30 cm
(12 in.)
61 cm
(24 in.)
51 cm
(20 in.)
160 cm
(63 in.)

10
Set up the printer and paper handling options
Note: Leave the printer in the box until
you are ready to install it, then have
someone help you lift it using the
handholds (see “Positioning the printer”
on page 13).
2Remove all items except the printer from the box.
Make sure you have the following items:
(1) Printer with one 500-sheet tray
(2) Four print cartridges (preinstalled)
(3) Setup Guide with a publications CD
(4) Drivers CD
(5) Power cord
If any items are missing or damaged, contact the place you purchased your printer for
assistance.
Save the carton and packing materials in case you need to repack the printer.
Step 4: Set up the printer and paper handling options
Printer models You can purchase several different options for your printer. Not all options are available
for all printers. Refer to the publications CD for more information.
If you purchased a multifunction printer (MFP) that copies, faxes, and scans, refer to the
documentation that came with the device to see if furniture or other hardware needs to
be set up first.If you purchased a finisher to go with your printer, refer to the
documentation that came with the finisher for information about setting it up with the
printer.
4
2
5
1
3
Output
expander
(see page 14)
5-bin
mailbox
(see page 15)
Printer
(see page 13)
Duplex unit
(see page 13)
2000-sheet
drawer
(see page 11)
or
500-sheet
drawer
(see page 12)

11
Set up the printer and paper handling options
Printer setup If you only purchased a base printer with no options, follow the directions under
“Positioning the printer”on page 13.
Note: Be sure to set up the items in the
order listed in the table.
Use the following table to locate the instructions you need to set up your printer and any
paper handling options you may have purchased.
Installing a 2000-sheet
drawer Your printer supports one optional 2000-sheet drawer.
Warning: If you have an optional
duplex unit and a 2000-sheet drawer, you
must install a 500-sheet drawer between
the duplex unit and the 2000-sheet
drawer.
1Unpack the 2000-sheet drawer and remove any packing material.
2Place the drawer in the location you have chosen for your printer.
3If you are installing a 500-sheet drawer on top of the 2000-sheet drawer, attach
the stabilizing bars:
aPlace the two stabilizing bars on the ground, narrow side up.
bLower the 2000-sheet drawer onto the bars, making sure you align the holes
in the drawer with the holes in the bars.
cScrew the bars into place using four screws (two screws for each bar).
4Adjust the four leveling feet on the bottom of the drawer, if necessary.
Note: You will install the power cord for
the 2000-sheet drawer later.
5Continue with “Installing a 500-sheet drawer”on page 12 or “Positioning the
printer”on page 13.
Topic Go to page...
Installing a 2000-sheet drawer 11
Installing a 500-sheet drawer 12
Installing a duplex unit 13
Positioning the printer 13
Installing an output expander 14
Installing a 5-bin mailbox 15
Leveling feet

12
Set up the printer and paper handling options
Installing a 500-sheet
drawer Your printer supports up to three additional 500-sheet drawers. However, if you install a
2000-sheet drawer, you can only add one additional 500-sheet drawer.
Warning: If you have an optional
duplex unit and a 2000-sheet drawer, you
must install a 500-sheet drawer between
the duplex unit and the 2000-sheet
drawer.
1Unpack the 500-sheet drawer and remove any packing material.
2Place the drawer in the location you have chosen for your printer or install it on
another drawer:
aAlign the holes in the 500-sheet drawer with the positioning posts on the
lower drawer.
bLower the 500-sheet drawer into place. Make sure it is seated securely on
the other drawer.
3If you are installing a 500-sheet drawer on top of a 2000-sheet drawer, secure
them with stabilizing screws.
aInsert the screws through the holes next to the positioning posts on the
500-sheet drawer.
bHand-tighten the screws.
Even when fully inserted, the screws allow some space between the
drawers.
4Install another 500-sheet drawer, or continue with “Installing a duplex unit”on
page 13 or “Positioning the printer”on page 13.

13
Set up the printer and paper handling options
Installing a duplex unit Your printer supports an optional duplex unit that lets you print on both sides of a sheet
of paper.
Warning: If you have an optional
duplex unit and a 2000-sheet drawer, you
must install a 500-sheet drawer between
the duplex unit and the 2000-sheet
drawer.
1Unpack the duplex unit and remove any packing material.
2Place the duplex unit in the location you have chosen for your printer or install it
on a 500-sheet drawer:
aAlign the positioning posts on the drawer with the holes in the duplex unit.
bLower the duplex unit into place. Make sure it is seated securely on the
drawer.
3Continue with “Positioning the printer”on page 13.
Positioning the printer Once you have selected a location and set up any optional drawers or a duplex unit, you
are ready to position the printer.
CAUTION: The printer weighs 47.7 kg
(105 lb) and requires at least two people
to lift it safely.
1Have someone help you lift the printer out of the box.
Use the handholds on the front and rear of the printer.

14
Set up the printer and paper handling options
2Have someone help you place the printer in the location you have chosen.
If you are installing the printer on an optional drawer or a duplex unit, align the
positioning posts on the option with the holes in the printer. Make sure the printer
is seated securely on the option.
3Remove any tape or packing material from the outside of the printer.
4If you purchased an output expander or mailbox, continue with this chapter.
Otherwise, skip to Step 5: “Set up the print supplies”on page 16.
Installing an output
expander Your printer supports an optional output expander that lets you stack up to 650 sheets
of paper in one bin.
Note: After you unpack the output
expander, install it immediately.
Otherwise, the edges of the mounting
brackets could damage tabletops or
fabrics.
1Unpack the output expander and remove any packing material.
2Remove the printer top cover.
Warning: The output expander tray is
designed to hold the weight of print
material only. Do not use it as a shelf;
excess weight may cause it to disengage
from the output expander.
3Align the mounting brackets on the bottom of the output expander with the slots
in the top of the printer.
4Lower the output expander into place.

15
Set up the printer and paper handling options
5Attach the printer top cover to the output expander.
6Attach the output expander paper bail to the top cover.
7Go to Step 5: “Set up the print supplies”on page 16.
Installing a 5-bin mailbox Your printer supports a 5-bin mailbox that lets you collate and stack up to 500 sheets of
paper.
Note: After you unpack the mailbox,
install it immediately. Otherwise, the
edges of the mounting brackets could
damage tabletops or fabrics.
1Unpack the mailbox and remove any packing material.
2Remove the printer top cover.
Warning: The mailbox is designed to
hold the weight of print material only. Do
not use it as a shelf; excess weight may
damage it.
3Align the mounting brackets on the bottom of the mailbox with the slots in the top
of the printer.
4Lower the mailbox into place.

16
Set up the print supplies
5Attach the printer top cover to the mailbox.
6Attach the mailbox paper bail to the top cover.
Step 5: Set up the print supplies
Warning: Be sure to remove all
packing materials or the printer may be
damaged.
This step describes how to prepare the print cartridges and remove the packing
materials inside the printer.
Setting up the print
cartridges 1Open the printer front cover.
2Remove the packing material on top of the cartridges.

17
Set up the print supplies
3Remove the print cartridges. For each cartridge:
aPull up on the handhold.
bPull the cartridge straight out and use the handle to lift it off the guides.
cSet the cartridge on a firm, flat, clean surface in the upright position.
Warning: Do not touch the image
transfer unit belt with your fingers.
4Remove the packing material from the image transfer unit belt:
aGrasp the detensioner located on the right side on the inside of the machine.
bGently but firmly pull up on the detensioner and the attached sheet, then
remove both items from the printer.
5Reinstall the print cartridges. For each cartridge:
aTurn the cartridge over so the handle is on the bottom.
bRemove the red plastic packing material from the photoconductor drum.
Discard the packing material.
b
a
c
1
2
1
Detensioner
a
b

18
Set up the print supplies
Warning: Failure to remove the
packing material from the print cartridges
damages the printer.
cTurn the cartridge so the handle is on the top.
dRotate the cartridge in all directions to distribute the toner.
Warning: Do not touch the
photoconductor drum on the bottom of
the print cartridge.
eHolding the cartridge by the handle, rest the spokes on the cartridge as
shown.
Be sure to match the cartridge color with the colored label in the printer.
fSlide the cartridge in as far as it will go.
The cartridge lowers into place.
Warning: If the front cover does not
close completely, reopen the cover and
press in firmly on the cartridges to make
sure they are fully seated.
6Close the front cover.
e
c
d

19
Install memory, firmware, or option cards
Attaching an operator
panel overlay If English is not your preferred language and your printer shipped with an adhesive
operator panel overlay, attach the overlay that has the appropriately translated button
names:
1Locate the overlay packaged with your printer.
2Peel the protective backing off the overlay.
3Align the holes in the overlay with the buttons on the operator panel, and then
press it into place.
4Peel the protective covering away from the overlay.
Refer to the User’s Guide on the publications CD for instructions on changing the
language of the text displayed on the operator panel.
Step 6: Install memory, firmware, or option cards
If you do not have any memory, firmware, or option cards to install, skip this step and
go to Step 7: “Load paper”on page 26.
You can customize your printer memory capacity and connectivity by adding optional
cards.
Warning: If you are installing memory
or option cards sometime after setting up
the printer, turn the printer off and unplug
the power cord before continuing.
The instructions in this section help you install any of the following:
•Memory cards
–Printer memory
•Firmware cards
–Additional functionality
–Internet capabilities
Note: You need a small Phillips
screwdriver to remove the system board
access cover and to install some of the
cards.
–Flash memory
•Option cards
–Hard disk with adapter card
–MarkNet™internal print servers (also called internal network adapters or
INAs)
–Serial Interface Card
–Parallel 1284-B Interface Card
1 Menu 2 Select 3 Return 4
Go 5 Stop 6
t 3 Retu
Stop 6
What do I do next?
Task Go to page…
Install memory, firmware, or option cards 19
Load paper 26

20
Install memory, firmware, or option cards
Removing the system
board access cover 1Locate the access cover on the back of the printer.
2Remove the four access cover screws (two at top, two at bottom).
3Remove the access cover.
4Use the illustration to locate the connector for the card you want to install.
5Use the following table to locate the instructions you need.
Hard disk
connector
Option card
connector
Firmware and
flash memory
card connectors
Memory card
connector
To install a... Go to page...
Memory card 21
Firmware card 22
Hard disk 23
Option card 24
