IBM BladeCenter JS12 User manual

BladeCenter JS12 Type 7998
Problem Determination and Service Guide


BladeCenter JS12 Type 7998
Problem Determination and Service Guide


Note
Before using this information and the product it supports, read the general information in
Appendix B, “Notices,” on page 289 and the Warranty and Support Information document for your
blade server type on the Documentation CD.
Second Edition (November 2009)
© Copyright International Business Machines Corporation 2008, 2009.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety ...............v
Guidelines for trained service technicians ....vi
Inspecting for unsafe conditions ......vi
Guidelines for servicing electrical equipment . . vii
Safety statements ............viii
Chapter 1. Introduction ........1
Related documentation ...........1
Notices and statements in this documentation . . . 2
Features and specifications..........2
Supported DIMMs ............4
Blade server control panel buttons and LEDs . . . 5
Turning on the blade server .........7
Turning off the blade server .........8
System-board layouts ...........9
System-board connectors .........9
System-board LEDs ...........9
Chapter 2. Diagnostics ........11
Diagnostic tools .............12
Collecting dump data ...........13
Location codes .............14
Reference codes .............15
System reference codes (SRCs) .......16
1xxxyyyy SRCs ...........17
6xxxyyyy SRCs ...........22
A1xxyyyy service processor SRCs .....24
AA00E1A8 to AA260005 Partition firmware
attention codes ...........25
Bxxxxxxx Service processor early termination
SRCs ..............28
B200xxxx Logical partition SRCs .....29
B700xxxx Licensed internal code SRCs . . . 39
BA000010 to BA400002 Partition firmware
SRCs ..............48
POST progress codes (checkpoints) .....88
C1001F00 to C1645300 Service processor
checkpoints ............89
C2001000 to C20082FF Virtual service
processor checkpoints .........99
IPL status progress codes .......109
C700xxxx Server firmware IPL status
checkpoints ...........109
CA000000 to CA2799FF Partition firmware
checkpoints ............110
D1001xxx to D1xx3FFF Service processor
dump codes ............131
D1xx3y01 to D1xx3yF2 Service processor
dump codes ...........138
D1xx900C to D1xxC003 Service processor
power-off checkpoints ........140
Service request numbers (SRNs) ......141
Using the SRN tables .........142
101-711 through FFC-725 SRNs .....142
A00-FF0 through A24-xxx SRNs .....159
ssss-102 through ssss-640 SRNs for SCSI
devices .............180
Failing function codes 151 through 2D02 . . 184
Error logs ..............186
Checkout procedure ...........186
About the checkout procedure.......186
Performing the checkout procedure .....187
Verifying the partition configuration......189
Running the diagnostics program ......189
Starting AIX concurrent diagnostics .....189
Starting stand-alone diagnostics from a CD . . 190
Starting stand-alone diagnostics from a NIM
server ...............191
Using the diagnostics program ......192
Boot problem resolution ..........193
Troubleshooting tables ..........194
General problems ...........195
Hard disk drive problems ........195
Intermittent problems .........196
Keyboard problems ..........196
Management module service processor
problems ..............197
Memory problems ...........197
Microprocessor problems ........198
Monitor or video problems ........198
Network connection problems .......200
PCI expansion card (PIOCARD) problem
isolation procedure ..........200
Optional device problems ........201
Power problems ...........202
POWER Hypervisor (PHYP) problems ....203
Service processor problems ........205
Software problems...........217
Universal Serial Bus (USB) port problems . . . 217
Light path diagnostics ..........218
Viewing the light path diagnostic LEDs . . . 218
Light path diagnostics LEDs .......219
Isolating firmware problems ........222
Recovering the system firmware .......222
Starting the PERM image ........222
Starting the TEMP image ........223
Recovering the TEMP image from the PERM
image ...............223
Verifying the system firmware levels ....224
Committing the TEMP system firmware image 224
Solving shared BladeCenter resource problems . . 225
Solving shared keyboard problems .....226
Solving shared media tray problems.....226
Solving shared network connection problems 228
Solving shared power problems ......229
Solving shared video problems ......230
Solving undetermined problems .......231
Calling IBM for service ..........232
Chapter 3. Parts listing, Type 7998 235
© Copyright IBM Corp. 2008, 2009 iii

Chapter 4. Removing and replacing
blade server components ......239
Installation guidelines ..........239
System reliability guidelines .......240
Handling static-sensitive devices ......240
Returning a device or component .....241
Removing the blade server from a BladeCenter
unit ................241
Installing the blade server in a BladeCenter unit 242
Removing and replacing Tier 1 CRUs .....244
Removing the blade server cover ......244
Installing and closing the blade server cover . . 245
Removing the bezel assembly .......246
Installing the bezel assembly .......247
Removing a SAS hard disk drive ......248
Installing a SAS hard disk drive ......249
Removing a memory module .......251
Installing a memory module .......251
Removing the management card ......253
Installing the management card ......254
Entering vital product data ........256
Obtaining a PowerVM Virtualization Engine
system technologies activation code .....257
Removing and installing an I/O expansion card 260
Removing a small-form-factor expansion card 260
Installing a small-form-factor expansion card 261
Removing a standard-form-factor expansion
card..............263
Installing a standard-form-factor expansion
card..............264
Removing a combination-form-factor
expansion card ...........265
Installing a combination-form-factor
expansion card ...........266
Removing the battery .........267
Installing the battery ..........268
Removing the hard disk drive tray .....270
Installing the hard disk drive tray .....271
Removing the expansion bracket ......272
Installing the expansion bracket ......273
Replacing the Tier 2 system-board and chassis
assembly ...............274
Chapter 5. Configuring .......277
Updating the firmware ..........277
Configuring the blade server ........278
Using the SMS utility...........279
Starting the SMS utility .........279
SMS utility menu choices ........280
Creating a CE login ...........280
Configuring the Gigabit Ethernet controllers . . . 281
Blade server Ethernet controller enumeration. . . 282
MAC addresses for host Ethernet adapters . . . 282
Updating IBM Director ..........283
Appendix A. Getting help and
technical assistance ........285
Before you call .............286
Using the documentation .........286
Getting help and information from the Web . . . 287
Software service and support ........287
Hardware service and support .......287
IBM Taiwan product service ........287
Appendix B. Notices ........289
Trademarks ..............290
Important notes ............291
Product recycling and disposal .......291
Battery return program ..........293
Electronic emission notices .........295
Federal Communications Commission (FCC)
statement..............295
Industry Canada Class A emission compliance
statement..............295
Avis de conformité à la réglementation
d’Industrie Canada ..........296
Australia and New Zealand Class A statement 296
United Kingdom telecommunications safety
requirement .............296
European Union EMC Directive conformance
statement..............296
Taiwanese Class A warning statement ....297
Chinese Class A warning statement .....297
Japanese Voluntary Control Council for
Interference (VCCI) statement .......297
Index ...............299
iv JS12 Type 7998: Problem Determination and Service Guide

Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
© Copyright IBM Corp. 2008, 2009 v

Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Guidelines for trained service technicians
Inspect the equipment for unsafe conditions and observe the servicing guidelines.
Inspecting for unsafe conditions
Identify potential unsafe conditions in an IBM®product that you are working on.
Each IBM product, as it was designed and manufactured, has required safety items
to protect users and service technicians from injury. This information addresses
only those items. Use good judgment to identify potential unsafe conditions that
might be caused by non-IBM alterations or attachment of non-IBM features or
options that are not addressed in this information. If you identify an unsafe
condition, you must determine how serious the hazard is and whether you must
correct the problem before you work on the product.
Consider the following conditions and the safety hazards that they present:
vElectrical hazards, especially primary power. Primary voltage on the frame can
cause serious or fatal electrical shock.
vExplosive hazards, such as a damaged CRT face or a bulging capacitor.
vMechanical hazards, such as loose or missing hardware.
To inspect the product for potential unsafe conditions, complete the following
steps:
1. Make sure that the power is off and the power cords are disconnected.
2. Make sure that the exterior cover is not damaged, loose, or broken, and observe
any sharp edges.
3. Check the power cords:
vMake sure that the third-wire ground connector is in good condition. Use a
meter to measure third-wire ground continuity for 0.1 ohm or less between
the external ground pin and the frame ground.
vMake sure that the power cords are the correct type.
vMake sure that the insulation is not frayed or worn.
4. Remove the cover.
5. Check for any obvious non-IBM alterations. Use good judgment as to the safety
of any non-IBM alterations.
6. Check inside the computer for any obvious unsafe conditions, such as metal
filings, contamination, water or other liquid, or signs of fire or smoke damage.
7. Check for worn, frayed, or pinched cables.
8. Make sure that the power-supply cover fasteners (screws or rivets) have not
been removed or tampered with.
vi JS12 Type 7998: Problem Determination and Service Guide

Guidelines for servicing electrical equipment
Observe the guidelines for servicing electrical equipment.
vCheck the area for electrical hazards such as moist floors, nongrounded power
extension cords, and missing safety grounds.
vUse only approved tools and test equipment. Some hand tools have handles that
are covered with a soft material that does not provide insulation from live
electrical current.
vRegularly inspect and maintain your electrical hand tools for safe operational
condition. Do not use worn or broken tools or testers.
vDo not touch the reflective surface of a dental mirror to a live electrical circuit.
The surface is conductive and can cause personal injury or equipment damage if
it touches a live electrical circuit.
vSome rubber floor mats contain small conductive fibers to decrease electrostatic
discharge. Do not use this type of mat to protect yourself from electrical shock.
vDo not work alone under hazardous conditions or near equipment that has
hazardous voltages.
vLocate the emergency power-off (EPO) switch, disconnecting switch, or electrical
outlet so that you can turn off the power quickly in the event of an electrical
accident.
vDisconnect all power before you perform a mechanical inspection, work near
power supplies, or remove or install main units.
vBefore you work on the equipment, disconnect the power cord. If you cannot
disconnect the power cord, have the customer power-off the wall box that
supplies power to the equipment and lock the wall box in the off position.
vNever assume that power has been disconnected from a circuit. Check it to
make sure that it has been disconnected.
vIf you have to work on equipment that has exposed electrical circuits, observe
the following precautions:
– Make sure that another person who is familiar with the power-off controls is
near you and is available to turn off the power if necessary.
– When you are working with powered-on electrical equipment, use only one
hand. Keep the other hand in your pocket or behind your back to avoid
creating a complete circuit that could cause an electrical shock.
– When using a tester, set the controls correctly and use the approved probe
leads and accessories for that tester.
– Stand on a suitable rubber mat to insulate you from grounds such as metal
floor strips and equipment frames.
vUse extreme care when measuring high voltages.
vTo ensure proper grounding of components such as power supplies, pumps,
blowers, fans, and motor generators, do not service these components outside of
their normal operating locations.
vIf an electrical accident occurs, use caution, turn off the power, and send another
person to get medical aid.
Safety vii

Safety statements
Important: Each caution and danger statement in this documentation is labeled
with a number. This number is used to cross reference an English-language caution
or danger statement with translated versions of the caution or danger statement in
the Safety Information document.
For example, if a caution statement is labeled, ″Statement 1,″translations for that
caution statement are in the Safety Information document under ″Statement 1.″Be
sure to read all caution and danger statements in this documentation before you
perform the procedures. Read any additional safety information that comes with
your blade server or optional device before you install the device.
Statement 1
DANGER
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid a shock hazard:
vDo not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical storm.
vConnect all power cords to a properly wired and grounded electrical outlet.
vConnect to properly wired outlets any equipment that will be attached to
this product.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or
structural damage.
vDisconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
vConnect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached devices.
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
viii JS12 Type 7998: Problem Determination and Service Guide

Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 16G8095 or an
equivalent type battery recommended by the manufacturer. If your system has a
module containing a lithium battery, replace it only with the same module type
made by the same manufacturer. The battery contains lithium and can explode if
not properly used, handled, or disposed of.
Do not:
vThrow or immerse into water
vHeat to more than 100°C (212°F)
vRepair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
vDo not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable parts
inside the device.
vUse of controls or adjustments or performance of procedures other than those
specified herein might result in hazardous radiation exposure.
DANGER
Some laser products contain an embedded Class 3A or Class 3B laser diode.
Note the following.
Laser radiation when open. Do not stare into the beam, do not view directly
with optical instruments, and avoid direct exposure to the beam.
Safety ix

Statement 4
≥18 kg (39.7 lb) ≥32 kg (70.5 lb) ≥55 kg (121.2 lb)
CAUTION:
Use safe practices when lifting.
Statement 5
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current from
the device, ensure that all power cords are disconnected from the power source.
1 2
Statement 8
xJS12 Type 7998: Problem Determination and Service Guide

CAUTION:
Never remove the cover on a power supply or any part that has the following
label attached.
Hazardous voltage, current, and energy levels are present inside any component
that has this label attached. There are no serviceable parts inside these
components. If you suspect a problem with one of these parts, contact a service
technician.
Statement 10
CAUTION:
Do not place any object on top of rack-mounted devices.
Safety xi

xii JS12 Type 7998: Problem Determination and Service Guide

Chapter 1. Introduction
This problem determination and service information helps you solve problems that
might occur in your IBM BladeCenter®JS12 Type 7998 blade server. The
information describes the diagnostic tools that come with the blade server, error
codes and suggested actions, and instructions for replacing failing components.
Replaceable components are of three types:
vTier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged
for the installation.
vTier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your blade server.
vField replaceable unit (FRU): FRUs must be installed only by trained service
technicians.
For information about the terms of the warranty and getting service and assistance,
see the Warranty and Support Information document.
Related documentation
Documentation for the JS12 blade server includes documents in Portable Document
Format (PDF) on the IBM BladeCenter Documentation CD and the online information
center.
The most recent version of all BladeCenter documentation is in the BladeCenter
information center.
The online BladeCenter information center is available in the IBM Systems
Information Center.
You can find the following documents in PDF on the IBM BladeCenter
Documentation CD and in the online information center:
vInstallation and User’s Guide
This document contains general information about the blade server, including
how to install supported options and how to configure the blade server.
vSafety Information
This document contains translated caution and danger statements. Each caution
and danger statement that appears in the documentation has a number that you
can use to locate the corresponding statement in your language in the Safety
Information document.
vWarranty and Support Information
This document contains information about the terms of the warranty and about
getting service and assistance.
© Copyright IBM Corp. 2008, 2009 1

Additional documents might be included in the online information center and on
the IBM BladeCenter Documentation CD.
The blade server might have features that are not described in the documentation
that comes with the blade server. The documentation might be updated
occasionally to include information about those features, or technical updates
might be available to provide additional information that is not included in the
documentation that comes with the blade server.
Review the online information or the Planning Guide and the Installation Guide for
your IBM BladeCenter unit. The information can help you prepare for system
installation and configuration. The most current version of each document is
available in the BladeCenter information center.
Notices and statements in this documentation
The caution and danger statements in this document are also in the multilingual
Safety Information. Each statement is numbered for reference to the corresponding
statement in your language in the Safety Information document.
The following notices and statements are used in this document:
vNote: These notices provide important tips, guidance, or advice.
vImportant: These notices provide information or advice that might help you
avoid inconvenient or problem situations.
vAttention: These notices indicate potential damage to programs, devices, or data.
An attention notice is placed just before the instruction or situation in which
damage might occur.
vCaution: These statements indicate situations that can be potentially hazardous
to you. A caution statement is placed just before the description of a potentially
hazardous procedure step or situation.
vDanger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
Features and specifications
Features and specifications of the IBM BladeCenter JS12 Type 7998 blade server are
summarized in this overview.
2JS12 Type 7998: Problem Determination and Service Guide

The JS12 blade server is used in one of the following IBM BladeCenter units:
BladeCenter E (8677), BladeCenter H (8852), BladeCenter HT (8740 and 8750),
BladeCenter S (8886), and BladeCenter T (8720 and 8730) units.
Notes:
vPower, cooling, removable-media drives, external ports, and advanced system
management are provided by the BladeCenter unit.
vThe operating system in the blade server must provide support for the Universal
Serial Bus (USB), to enable the blade server to recognize and communicate
internally with the removable-media drives and front-panel USB ports.
Microprocessor:
Support for one dual-core, 64-bit
POWER6®microprocessor; 3.8 GHz
Support for Energy Scale thermal
management for power
management/oversubscription
(throttling) and environmental
sensing
Memory:
vDual-channel (DDR2) with 8 slots
for very low profile (18.3 mm)
DIMMs
vSupports 1 GB, 2 GB, 4 GB, and 8
GB DDR2 DIMMs for a maximum
of 64 GB
vSupports 2-way interleaved, DDR2,
PC2-4200 or PC2-5300, ECC
SDRAM registered x4, memory
scrubbing, Chipkill, and bit steering
DIMMs
Virtualization:
PowerVM Standard Edition hardware
feature supports Integrated
Virtualization Manager and Virtual
I/O Server
Integrated functions:
vTwo 1 Gigabit Ethernet controllers
vExpansion card interface
vThe baseboard management
controller (BMC) is a flexible
service processor with Intelligent
Platform Management Interface
(IPMI) firmware and SOL support
vATI RN 50 ES1000 video controller
vSAS RAID controller
vLight path diagnostics
vRS-485 interface for
communication with the
management module
vAutomatic server restart (ASR)
vSerial over LAN (SOL)
vSupport for local keyboard and
video
vFour Universal Serial Bus (USB)
buses for communication with
keyboard and removable-media
drives
vTransferable Anchor function
(Renesas Technology HD651330
microcontroller) in the
management card
Storage:
Support for two internal
small-form-factor (SFF) Serial
Attached SCSI (SAS) drives
Predictive Failure Analysis (PFA)
alerts:
vMicroprocessor
vMemory
Electrical input: 12Vdc
Environment:
vAir temperature:
– Blade server on: 10° to 35°C (50°
to 95°F). Altitude: 0 to 914 m
(3000 ft)
– Blade server on: 10° to 32°C (50°
to 90°F). Altitude: 914 m to 2133
m (3000 ft to 7000 ft)
– Blade server off: -40° to 60°C (-40°
to 140°F)
vHumidity:
– Blade server on: 8% to 80%
– Blade server off: 8% to 80%
Size:
vHeight: 24.5 cm (9.7 inches)
vDepth: 44.6 cm (17.6 inches)
vWidth: 2.9 cm (1.14 inches)
vMaximum weight: 5.0 kg (11 lb)
See the ServerProven Web site for information about supported operating-system
versions and all JS12 blade server optional devices.
Chapter 1. Introduction 3

Supported DIMMs
The BladeCenter JS12 Type 7998 blade server contains eight memory connectors for
industry-standard registered, dual-inline-memory modules (RDIMMs). The DIMMS
are very low profile, which means that each DIMM has a height of 18.3 millimeters
(mm). Total memory can range from a minimum of 2 gigabytes (GB) to a
maximum of 64 GB.
See Chapter 3, “Parts listing, Type 7998,” on page 235 for memory modules that
you can order from IBM.
Memory module rules:
vInstall DIMMs in pairs in the following connectors to have a supported (tested)
configuration:
Table 1. Supported use of DIMMs
DIMM
Connectors
Number of DIMMs in Use
Two Four Six Eight
Pair 1 (DIMM 1
and DIMM 3) Yes Yes Yes Yes
Pair 2 (DIMM 6
and DIMM 8) No Yes Yes Yes
Pair 3 (DIMM 2
and DIMM 4) No No Yes Yes
Pair 4 (DIMM 5
and DIMM 7) No No No Yes
See “System-board connectors” on page 9 for DIMM connector locations.
vBoth DIMMs in a pair must be the same size, speed, type, technology, and
physical design. You can mix compatible DIMMs from different manufacturers.
Each DIMM in each of the following sets of four connectors must be the same
size:
Size 1 DIMM 1 and DIMM 3 (pair 1) and DIMM 2 and DIMM 4 (pair 3) when
using 6 or 8 DIMMs
Size 2 DIMM 5 and DIMM 7 (pair 4) and DIMM 6 and DIMM 8 (pair 2) when
using 8 DIMMs
vWhen using 4 DIMMs in DIMM 1 and DIMM 3 (pair 1) and DIMM 6 and
DIMM 8 (pair 2), DIMMs in the second pair can differ in size and speed from
the first pair.
vWhen using 8 GB DIMMs, all of the DIMMS used must be 8 GB.
vInstall only supported DIMMs, as described on the ServerProven®Web site. See
http://www.ibm.com/servers/eserver/serverproven/compat/us/.
vInstalling or removing DIMMs changes the configuration of the blade server.
After you install or remove a DIMM, the blade server is automatically
reconfigured, and the new configuration information is stored.
4JS12 Type 7998: Problem Determination and Service Guide

Blade server control panel buttons and LEDs
Blade server control panel buttons and LEDs provide operational controls and
status indicators.
Note: Figure 1 shows the control-panel door in the closed (normal) position. To
access the power-control button, you must open the control-panel door.
Keyboard/video select button: When you use an operating system that supports a
local console and keyboard, press this button to associate the shared BladeCenter
unit keyboard and video ports with the blade server.
Notes:
vThe operating system in the blade server must provide USB support for the
blade server to recognize and use the keyboard, even if the keyboard has a
PS/2-style connector.
vThe keyboard and video are available after partition firmware loads and is
running. Power-on self-test (POST) codes and diagnostics are not supported
using the keyboard and video. Use the management module to view
checkpoints.
The LED on this button flashes while the request is being processed, then is lit
when the ownership of the keyboard and video has been transferred to the blade
server. It can take approximately 20 seconds to switch control of the keyboard and
video to the blade server.
Using a keyboard that is directly attached to the management module, you can
press keys in the following sequence to switch keyboard and video control
between blade servers:
NumLock NumLock blade_server_number Enter
MT
Keyboard/video select button Media-tray select button
Information LED
Blade-error LED
Power-control button
NMI reset
Activity LED
Location LED
Power-on LED
Sleep (not used on
blade server)
Figure 1. Blade server control panel buttons and LEDs
Chapter 1. Introduction 5

Where blade_server_number is the two-digit number for the blade bay in which
the blade server is installed. When you use some keyboards, such as the
28L3644 (37L0888) keyboard, hold down the Shift key while you enter this key
sequence.
If there is no response when you press the keyboard/video select button, you can
use the Web interface of the management module to determine whether local
control has been disabled on the blade server.
Media-tray select button: Press this button to associate the shared BladeCenter
unit media tray (removable-media drives and front-panel USB ports) with the
blade server. The LED on the button flashes while the request is being processed,
then is lit when the ownership of the media tray has been transferred to the blade
server. It can take approximately 20 seconds for the operating system in the blade
server to recognize the media tray.
If there is no response when you press the media-tray select button, use the
management module to determine whether local control has been disabled on the
blade server.
Note: The operating system in the blade server must provide USB support for the
blade server to recognize and use the removable-media drives and USB ports.
Information LED: When this amber LED is lit, it indicates that information about a
system error for the blade server has been placed in the management-module
event log. The information LED can be turned off through the Web interface of the
management module or through IBM Director Console.
Blade-error LED: When this amber LED is lit, it indicates that a system error has
occurred in the blade server. The blade-error LED will turn off after one of the
following events:
vCorrecting the error
vReseating the blade server in the BladeCenter unit
vCycling the BladeCenter unit power
Power-control button: This button is behind the control panel door. Press this
button to turn on or turn off the blade server.
The power-control button has effect only if local power control is enabled for the
blade server. Local power control is enabled and disabled through the Web
interface of the management module.
Press the power button for 5 seconds to begin powering down the blade server.
6JS12 Type 7998: Problem Determination and Service Guide
