IBM DDS Gen 5 User manual

DDSGen5TapeDrive
User’s Guide
Important: Please review the maintenance information in Chapter 3, “Using the tape
drive”, on page 15 as periodic maintenance (cleaning, firmware updates, etc.) is not
covered by the IBM warranty. Repairs or exchanges resulting from improper
maintenance may result in billable service charges.


DDSGen5TapeDrive
User’s Guide


First Edition (August 2003)
Note: Before using this information and the product it supports, be sure to read teh information under Appendix C,
“IBM Statement of Limited Warranty - Z125-4753-07 - 11/2002”, on page 31 and Appendix C, “IBM Statement of
Limited Warranty - Z125-4753-07 - 11/2002”, on page 31.
© Copyright International Business Machines Corporation 2003. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Safety: Read first
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Pred inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy.
Antes de instalar este producto lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
© Copyright IBM Corp. 2003 iii

iv DDS Gen 5 Tape Drive: User’s Guide

Contents
Safety: Read first ..........iii
About this book ...........vii
Chapter 1. Introduction ........1
Product description ............1
Chapter 2. Installation .........3
Unpacking ...............3
Pre-installation requirements .........3
Avoiding electrostatic damage .......3
Reviewing drive default settings.......4
SCSI ID settings ............5
Parity checking ............5
Terminating power ...........5
Data compression............6
Power-on self test............6
Host operating system ..........6
Vendor ID ..............7
Tape Drive Components .........8
Opening the computer ...........8
Installing the drive ............9
Installing the drive in IBM servers ......9
General installation instructions .......9
Completing your installation ........13
Chapter 3. Using the tape drive ....15
Using the appropriate media ........15
Handling cartridges ...........15
Loading a cartridge............15
Initializing a blank cartridge.........16
Unloading a cartridge ...........16
Write-protecting a DDS cartridge .......17
Cleaning the tape heads ..........18
Updating firmware ............18
Chapter 4. Understanding the drive
LEDs ...............19
Front panel LEDs ............19
LED summary .............19
Clean LED...............20
Media LED ..............20
Drive LED...............21
Chapter 5. Troubleshooting ......23
SCSI ID problems ............23
SCSI termination problems .........23
Mounting hardware problems ........23
Drive does not work ...........23
Power-On Self-Test fails ..........23
Computer does not boot ..........23
Computer does not recognize drive ......24
Backup program does not recognize drive ....24
Write error ..............24
Hardware error .............24
Appendix A. Specifications ......25
Data capacities .............25
Size and weight .............25
Power specifications ...........26
Drive performance specifications .......27
Environmental requirements.........28
Reliability ...............28
Appendix B. Service and Support . . . 29
Online technical support ..........29
Telephone technical support .........29
Appendix C. IBM Statement of Limited
Warranty - Z125-4753-07 - 11/2002 . . . 31
Part 2 - Country-unique Terms........34
Part3-Warranty Information ........
45
Appendix D. Notices .........49
Federal Communications Commission (FCC)
statement ...............50
Trademarks ..............53
© Copyright IBM Corp. 2003 v

vi DDS Gen 5 Tape Drive: User’s Guide

About this book
This manual contains instructions for installing, configuring, and troubleshooting
the IBM DDS Gen 5 Drive. The manual is divided into the following sections:
vInstallation and user’s guide
This guide contains the product description and installation instructions in the
following languages:
– English
– French
– German
– Italian
– Japanese
– Korean
– Simplified Chinese
– Spanish
– Traditional Chinese
vAppendixes
The appendixes contain device-driver special configuration settings and help and
service information. They also contain the product warranties and notices.
Note: The illustrations in this manual might be slightly different from your
hardware.
© Copyright IBM Corp. 2003 vii

viii DDS Gen 5 Tape Drive: User’s Guide

Chapter 1. Introduction
Designed for computer environments that require high-performance, high-capacity
data storage, the DDS Gen 5 drive is the latest offering in the popular DDS
technology roadmap.
This SCSI tape drive is capable of storing up to 36 GB per data cartridge and
transferring data at a sustained rate of up to 3.5 MB per second. Both capacity and
transfer rate are further enhanced by its onboard data compression feature.
In addition to this User’s Guide, provided on the User’s Guide and Software CD, the
option package contains:
vIBM DDS Gen 5 Internal Tape Drive
vmounting screws
vcleaning cartridge
v3.5″drive bezel
vQuick Start Guide
vSCSI cable
vdevice drivers (in Drivers folder on User’s Guide CD)
Contact your place of purchase if an item is missing or damaged. Be sure to retain
your proof of purchase. It might be required to receive warranty service. See
Appendix C, “IBM Statement of Limited Warranty - Z125-4753-07 - 11/2002”, on
page 31 for warranty information.
Product description
This section provides information on the product features.
Features
vSupports DDS-3, DDS-4, and DDS 5th Generation recording formats.
vLVD / Ultra Wide SCSI connection
v3.5-inch half-height drive factory-installed with 5.25-inch mounting rails and
bezel for installation in a 5.25-inch half-height space
vSupport for various native data-storage capacities
vHigh-speed transfer rates for fast backups
vAdvanced onboard DDS-DC hardware using Lempel-Ziv (DCLZ)
data-compression, doubling the drive’s uncompressed capacity (e.g., a 36 GB
uncompressed drive can be up to 72 GB with compression).
vHigh-performance SCSI burst transfer rates
vThree levels of error-correction code (ECC) and four-head design for
read-after-write (RAW) error detection and correction (uncorrectable error rate of
less than 1 in 1015 bits)
v“Flying” preamplifier for greater signal-to-noise ratio
vFlash memory to store setup parameters and enable field firmware upgrades
vAutomatic power-on self-test
vState-of-the-art sealed drive mechanism and tape handling components for
improved immunity to airborne contaminants and extended media life
© Copyright IBM Corp. 2003 1

2DDS Gen 5 Tape Drive: User’s Guide

Chapter 2. Installation
This chapter describes how to install the internal DDS Gen 5 drive.
Unpacking
Before you unpack the contents of your drive package, inspect the shipping
containers for damage. If you spot damage to the container, notify your carrier
immediately.
When you unpack the package, compare the items received with those on the
packing list. If any item is missing or damaged, please contact your place of
purchase immediately.
Pre-installation requirements
In addition to the contents included with your internal tape drive, you need the
following items to install your internal tape drive.
vA SCSI host bus adapter that is properly installed and configured in a host
computer
vA 3.5-inch or 5.25-inch half-height bay
vBackup application software that supports the internal tape drive.
vPhillips screwdriver
vFlatblade screwdriver, if your computer uses flathead screws
vTorx screwdriver, if your computer uses torx screws
Avoiding electrostatic damage
Your internal tape drive has very sensitive components that are prone to damage
from electrostatic discharge (ESD). Use extreme care when handling the drive, as it
can be damaged by ESD.
Before handling the drive, read these ESD instructions to prevent damage to the
drive.
vWear an ESD-preventive grounding wrist strap or observe similar ESD
precautions when working with the drive. Be sure the wrist strap makes good
skin contact. Do not remove the wrist strap until you finish working with the
drive.
vAvoid contact between the drive, other equipment, and clothing. The wrist strap
only protects the equipment from ESD voltages on the body; ESD voltages on
clothing can still cause damage.
vWhen the drive is not being used, keep it in its antistatic bag.
vBefore you remove the drive from the antistatic bag, touch a metal or grounded
surface to discharge any static electricity buildup from your body.
vHold the drive by its edges only. Avoid touching any exposed parts on the
printed circuit board.
vAlways place the drive on top of or inside the antistatic bag to reduce the
chance of ESD damage.
© Copyright IBM Corp. 2003 3

Reviewing drive default settings
Your internal tape drive comes with various default settings. These settings are
configured using jumpers and switches.
vThe jumpers are located on the back of the drive, between the SCSI interface and
power connectors (refer to the diagram in“General installation instructions” on
page 9).
vThe switches are located on the underside of the drive. If you change a switch
setting, you must turn the drive off and then on to have the new setting take
effect (see Figure below).
You may need to change these settings to suit your requirements. Review the
default settings shown below to determine whether they suit your requirements or
need to be changed.
Parameters Default Settings
Jumper
Pins/Switches See...
SCSI ID 6 Jumper pins 1–2, 3–4,
5–6, 7–8
“SCSI ID settings” on
page 5
Parity checking enabled Jumper pins 9–10 “Parity checking” on
page 5
Terminator powered disabled Jumper pins 11-12 “Terminating power”
on page 5
Data compression enabled Switches 1 and 2 “Data compression”
on page 6
Power-On Self-Test
diagnostic
enabled Switch 4 “Power-on self test”
on page 6
Host operating
system
Microsoft Windows
98/NT/2000/2003
Server
Switches 5-8 “Host operating
system” on page 6
Vendor ID IBM DDS Gen5 Switch 10 “Vendor ID” on
page 7
Front of drive
Default settings shown
Switch Default setting
1 Data compression (DC)
2 SCSI DC control
4DDS Gen 5 Tape Drive: User’s Guide

Switch Default setting
3 Media recognition
4 Self test
5 Operating-system configuration switches
6
7
8
9 Wide/narrow SCSI
10 Inquiry string support
SCSI ID settings
Jumper Pins: 1-2, 3-4, 5-6, 7-8
Default Settings: SCSI ID 6
Each SCSI device on the bus must have its own unique ID. Your internal tape
drive is shipped with a default SCSI ID of 6. If another SCSI device in the SCSI
chain is already using this ID, use jumper pins 1–2, 3–4, 5–6, and 7–8 to change the
drive’s SCSI ID.
Note: If you change the drive’s default SCSI ID, avoid using SCSI IDs 0 and 1
(which typically are assigned to a boot drive) and SCSI ID 7 (which typically is
assigned to SCSI controllers or host bus adapters).
Parity checking
Jumper Pins 9-10: Pins 9-10 shunted: Enable parity checking
(default)
Pins 9-10 open: Disable parity checking
By default, parity checking is enabled on the internal tape drive. To disable parity
checking, remove the jumper from pins 9 and 10.
Note: If you disable parity checking, the drive still generates a parity bit.
Terminating power
Jumper Pins 11-12: Pins 11-12 shunted: Enable terminator
power
Pins 11-12 open: Disable terminator power
(default)
By default, terminator power is disabled on the internal tape drive. To enable
terminator power, place a jumper across pins 11 and 12.
Note: If you enable terminator power, be careful not to short the TERMPWR signal
to ground (for example, by attaching the SCSI cable upside down). If a short
Chapter 2. Installation 5

occurs, terminator power to the bus is interrupted. After the short is removed, a
fuse in the drive is automatically reset, restoring terminator power.
Data compression
Settings: Switch 1 ON = Enable hardware data
compression (default)
Switch 1 OFF = Disable hardware data
compression
Switch 2 OFF = Recognize SCSI data
compression commands (default)
Switch 2 ON = Ignore SCSI data
compression commands
The internal tape drive provides two switches for controlling data compression.
Switch 1 determines whether hardware data compression is enable or disabled. By
default, switch 1 is set to ON, enabling hardware data compression. To disable
hardware data compression, set switch 1 to the OFF position.
Switch 2 controls whether SCSI commands are recognized for enabling or disabling
hardware data compression. By default, switch 2 is set to ON, allowing SCSI
commands to be used to enable or disable hardware data compression. To prevent
SCSI commands from enabling or disabling hardware data compression, set switch
2 to the OFF position.
When data compression is enabled, the drive compresses all data written to tape
and decompresses all compressed data read from tape. The degree of compression
varies due to the type of data being processed.
vData with a high degree of redundancy, such as structured database files or
graphics files, are compressed most efficiently, often at a ratio of 2:1 or more.
vData with little redundancy, such as executable programs, are compressed the
least.
Power-on self test
Settings: Switch 4 ON = Drive performs Power-On
Self Test (default)
Switch 4 OFF = Drive does not perform
Power-On Self Test
Switch 4 enables or disables the Power-On Self-Test diagnostics that the drive
performs when powered on. By default, the drive responds to SCSI commands
only after it successfully completes the Power-On Self-Test (about 5 seconds). To
prevent the drive from performing the Power-On Self-Test when powered-up, set
switch 4 to the OFF position.
Host operating system
Switches: 5,6,7,8
Default Settings: Microsoft Windows
6DDS Gen 5 Tape Drive: User’s Guide

Switches 5 through 8 configure the internal tape drive for a host operating system.
By default, these switches are all ON. This setting configures the drive for a
Microsoft
®
Windows
®
operating system.
To use the internal tape drive with a different operating system, set switches 5
through 8 to select the appropriate settings.
The following table shows the supported operating systems and their
corresponding settings.
Host
Operating
Systems Driver
Switches
SW5 SW6 SW7 SW8 SW10
Windows IBMDAT5 ON ON ON ON ON
Windows 4MMDAT ON ON ON ON OFF
Novell 5.x NWTAPE
(pre
11/03/99)
OFF ON ON OFF ---
Novell 5.x NWTAPE
(post
11/03/99)
ON ON ON ON ---
DEC UNIX -- OFF ON ON ON ---
Sun Unix -- ON OFF ON ON ---
SGI -- ON ON ON ON ---
HP-UX -- ON ON OFF ON ---
IBM AIX -- ON OFF ON OFF ---
Linux -- ON ON ON ON ---
SCO -- OFF ON ON OFF ---
SCO
UnixWare
7.x
-- ON ON ON ON ---
Vendor ID
Settings: Switch 10 ON = Vendor ID is ″IBM DDS
Gen5″(default)
Switch 10 OFF = Vendor ID is ″Archive
PYTHON″
Switch 10 determines the vendor ID that the internal tape drive returns when it
receives a SCSI “Inquiry” command. By default, the drive returns ″IBM DDS
Gen5″.
Setting switch 10 to the OFF position configures the drive to return ″Archive
Python″.
Chapter 2. Installation 7

Tape Drive Components
The following describes the major components of the tape drives.
1 Clean LED (green)
2 Media LED (green)
3 (Drive LED (amber)
4 Eject button
For more information on LEDs, see“Front panel LEDs” on page 19.
Opening the computer
To open the computer:
1. Shut down the computer as you would normally. Then turn off the computer
and all peripherals connected to it.
2. Remove the computer’s power cord from the computer connector.
3. Remove the computer cover. For more information, refer to the documentation
that came with your computer.
Note: If you have to disconnect cables to gain access to the mounting bay, note
which cables were removed. You can then refer to this information when you
reconnect the cables at the end of this procedure.
4. Select an available 3.5-inch or 5.25-inch mounting bay, depending the internal
tape drive you want to install.
Note: The internal tape drive can be mounted horizontally or vertically (on its
side).
5. If the mounting bay has a “filler panel,” remove it according to the instructions
in your computer’s documentation. Place the screws aside, You will need them
to secure the drive in the bay.
6. If the computer does not have a SCSI host adapter, install one.
8DDS Gen 5 Tape Drive: User’s Guide

Installing the drive
This section contains information on installing the tape drive in IBM servers and
other computers.
Installing the drive in IBM servers
The IBM DDS Gen 5 Tape Drive can be installed in several IBM xSeries servers.
The most current list of supported servers can be found at
www/pc/ibm.com/us/compat/storage/matrix.html. Refer to the documentation
that comes with the server for instructions on installing the tape drive or follow
the general instructions below.
General installation instructions
Follow these steps to install the tape drive.
Step 1. Selecting a SCSI ID
Each device on a SCSI bus must have a unique SCSI ID. Select a SCSI ID from 0 to
15 for the tape drive. The SCSI ID must be supported by your SCSI adapter. Refer
to your SCSI adapter documentation for the range and relative priority of the IDs
supported. The tape drive is shipped with the SCSI ID preset to 6.
Follow these guidelines to select a SCSI ID:
vAssign the tape drive to one of the higher priority IDs available (0–6).
vAssign the lower priority ID numbers (8-15) to those devices that are most often
used or are faster than other devices in the chain.
vDo not assign an ID of 7, because this is usually used as the SCSI adapter ID.
Depending on your computer, there are several ways to view your current SCSI ID
settings:
vFor many IBM computers, press F1 during the startup after the memory check
completes. Other adapters show SCSI settings when you press Ctrl A. Check the
documentation that comes with your computer or SCSI adapter for information
on how to view configuration information.
vUse SCSI adapter utility programs, if available.
vInspect the installed SCSI devices to see how the jumpers that determine the IDs
are set.
Step 2. Setting the SCSI ID
Chapter 2. Installation 9

Refer to the following diagram when setting the SCSI ID.
SCSI ID=0
SCSI ID=1
SCSI ID=2
SCSI ID=3
SCSI ID=4
SCSI ID=5
SCSI ID=6
SCSI ID=7
SCSI ID=8
SCSI ID=9
SCSI ID=10
SCSI ID=11
SCSI ID=12
SCSI ID=13
SCSI ID=14
SCSI ID=15
Parity enable
Term. power
Default jumper settings shown
(SCSI ID 6, parity checking enabled,
and termination power disabled)
Pins: Function:
1-2 SCSI ID bit 0
3-4 SCSI ID bit 1
5-6 SCSI ID bit 2
7-8 SCSI ID bit 3
9-10 Parity checking
11-12 Termination Power
Note: When setting the SCSI ID, use the jumpers that come with the tape drive. If
your enclosure uses a remote SCSI ID switch, remove the jumpers from the jumper
pins on the tape drive and connect the remote switch.
1. Find the jumper pin setting that corresponds to the SCSI ID number you
choose; then place jumper pins on the SCSI ID blocks as shown. You can use a
pair of flat-nose pliers to place the jumpers on the jumper pins.
Step 3. Mounting the drive
Mount the tape drive; then attach the SCSI and power cables to it. If there is
insufficient working space to attach the connectors after mounting the drive, attach
the cables first. To mount the drive, follow these steps:
10 DDS Gen 5 Tape Drive: User’s Guide
