ICA CS Series User manual

UNINTERRUPTIBLE
POWER
SUPPLY
ICA
481-11C0030-151
Rev. 03

I. INTRODUCTION / PENDAHULUAN
UPS (Uninterruptible Power Supplies)
dapat melindungi peralatan anda yang rentan
terhadap gangguan kelistrikan seperti: komputer,
instrument terkomputerisasi, PABX, faksimili,
cash register dan peralatan elektronik lainnya.
UPS ini terdiri atas inverter, baterai,
pengisi baterai, rangkaian pengendali,
stabilisator, saklar-pengalih dan indikator. Saat
listrik jala-jala normal, UPS menyaring listrik
masukan dan menyalurkannya pada keluaran
UPS, pada saat yang sama baterai diisi oleh
pengisi baterai. Manakala terjadi gangguan
listrik (padam, tegangan terlalu rendah/tinggi),
inverter seketika bekerja dengan waktu alih 4
ms sehingga pasokan listrik pada beban tidak
terganggu/terputus. Dan bila listrik jala-jala pulih
maka otomatis beban mendapat daya listrik jala-
jala kembali.
UPS ini dilengkapi interface untuk
berkomunikasi dengan komputer, dengan sistem
operasi Windows 95, 98, ME, Unix/Linux
maupun Windows NT4/2000. Informasi yang
diberikan kepada komputer adalah
dan .
<
listrik
padam baterai hampir habis
UPS (Uninterruptible Power Supplies) can
provide full protection against all of power
problem for your sensitive equipment ranging
from computer, computerized instrument, PABX,
facsimile, cash register to all electronic
equipment.
This UPS consists of inverter, batteries,
battery charger, control circuit, stabilizer,
transfer switch and indicator. When line power is
normal, the UPS filters line power input and by
pass to output UPS and at the same time the
batteries is being charged by battery charger.
And when line power fails (off, voltage too
low/high), inverter will supply regulated AC
power to the load within 4 ms transfer time so
that the power supplied to the load is
uninterrupted. And when line power is normal
automatically load gets from line power again.
This UPS is also completed by interface for
communication with computer, with operating
system Windows 95, 98, ME, Unix / Linux and
Windows NT4/2000. Information from UPS to
Computer is and .
<
power fail battery low
AC INPUT
TO COMPUTER
UPS OUTPUT
TRANSFER
SWITCH
INVERTERCHARGER
BATTERY
STABILIZER
&
INDICATOR
CONTROL CIRCUIT

II. TECHNICAL SPECIFICATION / SPESIFIKASI
TEKNIK
MODEL
ITEM
CAPACITY
Voltage
Current
Frequency
Protection
Internal Battery
Wave Form
Voltage
Frequency
Efficiency
Type
Voltage
Current
Transfer Time
Back Up Time
Indicator
Operation Temperature
Dimension
Gross Weight
UNIT
VA/W
V
A
Hz
A
V
Hz
%
V
A
ms
min
0C
mm
Kg
SPECIFICATION
CS638 CS1238
600/300 1200/600
165 ~ 250
1.6 2.9
50 ± 3
3 5
Synthesized Sinewave (Step Wave)
220 ± 5%
50
> 80
Constant Voltage
13.5 27.0
1.5
10
Led & Buzzer
0 ~ 40
345x95x158 390x145x195
6
7
12.6
14
1 x 12V, 7AH 2 x 12V, 7AH
REMARKS
Maximum
Max. Load &
Charger
Fuse
Sealed Lead Acid
Battery
PWM
Maximum
Nominal Load
Refer to Table of
Status Indicator
D xW x H
Netto
Gross
< 4
Notes :
The UPS battery should charge for at least 10 hours to ensure sufficient runtime. The unit is being
charged whenever it is connected to utility power and UPS must be turn ON.
------------------------------------------------------------------------------------------------------------------------
Catatan :
Battery UPS harus di isi sekurangnya 10 jam untuk memastikan UPS beroperasi dengan memadai.
Unit akan mengisi bilamana dihubungkan dengan sumber listrik dan UPS harus dihidupkan.

III. FRONT PANEL & REAR PANEL VIEW / TAMPAK
PANEL DEPAN & PANEL BELAKANG
1. Main Switch / : To turn on and turn off the UPS /
2. Green Led / : Indicate output UPS from line power /
3. Yellow Led / : Indicate output UPS from inverter /
.
4. Red Led / : Indicate battery low /
5. USB Port / Port USB : For communication between UPS and computer /
.
6. Modem Protector Port : Internet modem protection /
7. Outlet /
8. AC Cord Input / Kabel AC input
9. Input Fuse /
Tombol Daya
Untuk menghidupkan dan mematikan UPS
Led Hijau
Menunjukkan keluaran UPS dari listrik jala-jala.
Led Kuning
Menunjukkan keluaran UPS dari inverter
Led Merah
Menunjukkan keadaan battery hampir habis.
Untuk komunikasi antara UPS dengan komputer
Perlindungan modem
Internet
Stopkontak Keluaran
Fuse Input
*
*
* Notice :
Please disconnect all communication connectors before disconnecting main power cord from
receptacle.
Putuskan semua konektor komunikasi sebelum mencabut kabel daya utama dari stopkontak.
ICA
INPUT
OUTPUT
USB TELEPHONE/MODEM
PROTECTOR
OUTPUT
USB
service centre / technical support :
http://www.icaups.co.id/support.php
TELEPHONE/MODEM
PROTECTOR
INPUT
FRONT PANEL VIEW
UPS CS638, CS1238
REAR PANEL VIEW
UPS CS638
REAR PANEL VIEW
UPS CS1238
1
2
3
4
5 6
7
9
6
9
8
8
5
7

Keselamatan ListrikElectrical Safety
IV. SAFETY NOTES / CATATAN KESELAMATAN
!
!
!
!
!
Do not work alone under hazardous
conditions.
High current through conductive materials
could cause severe burns.
Check that the power cord(s), plug(s), and
socket are in good condition.
When grounding cannot be verified,
disconnect the equipment from the utility
power outlet before installing or connecting
to other equipment. Reconnect the power
cord only after all connections are made.
Connect the equipment to a three wire
utility outlet (two pole plus ground). The
receptacle must be connected to appropriate
branch circuit/ mains protection (fuse or
circuit breaker). Connection to any other
type of receptacle may result in risk of
electrical shock.
!
!
!
!
!
Jangan bekerja sendiri dalam situasi
berbahaya.
Tegangan tinggi melalui bahan konduktif
dapat menyebabkan luka bakar.
Periksa agar kabel listrik, fiting, dan soket
berada dalam kondisi baik.
Bila grounding tak dapat diverifikasi,
putuskan hubungan peralatan listrik dengan
keluaran listrik AC sebelum memasang atau
menghubungkannya dengan peralatan lain.
Hubungkan kembali dengan kabel listrik
hanya jika seluruhnya selesai dihubungkan.
Hubungkan peralatan ke keluaran listrik AC
tiga kabel (dua kutub dan ground). Soket
penerima harus terhubung secara benar
melalui sirkuit cabang/ pelindung utama
(sekring atau pemutus arus). Hubungan ke
soket penerima dalam bentuk lainnya dapat
menyebabkan bahaya sengatan listrik.
!
!
If the UPS has an internal energy source
(battery), the output may be energized when
the unit is not connected to a utility power
outlet.
To deenergize a pluggable UPS, press the
OFF button or switch to shut the equipment
off. Unplug the UPS from the utility power
outlet. Disconnect the external batteries
where applicable and disconnect the internal
battery. Push the ON button to deenergize
the capacitors.
!
!
Jika alat memiliki sumber energi internal
(batterai), output mungkin masih
mengandung arus listrik walaupun unit tidak
terhubung dengan tegangan listrik AC.
Untuk membuang arus listrik dari UPS yang
terhubung, tekan tombol OFF untuk
mematikan alat. Putuskan alat dari outlet
listrik AC. Lepaskan batterai dan putuskan
batterai internal. Tekan tombol ON untuk
membuang listrik di dalam kapasitor.
!
!
!
!
Repair are to be performed only by qualified
personnel.
Do not dispose of batteries in a fire. The
batteries may explode.
Do not open or mutilate batteries. They
contain an electrolyte that is toxic and
harmful to the skin and eyes.
Replace batteries with the same number and
type of batteries as originally installed in the
equipment.
!
!
!
!
Perbaikan hanya dilakukan oleh seorang
teknisi yang memiliki kualifikasi.
Jangan buang batterai ke dalam api, dapat
meledak.
Jangan membongkar batterai. Batterai
mengandung elektrolit yang beracun dan
dapat merusak kulit dan mata.
Ganti batterai dengan nomor dan jenis yang
sama seperti aslinya terpasang dalam alat.
Battery Safety Keselamatan Batterai
Deenergizing Safety Keselamatan Saat Membuang Arus Listrik

V. UPS INSTALLATION / PEMASANGAN UPS
1. Unpacking and Inspection.
Unpack the packaging and check the package
contents. The contains of package ; user
manual, warranty card, input power cable.
Inspect the appearance of the UPS to see if
there is any damage during transportation. Do
not on the unit and notify the carrier and
dealer immediately if there is any damage or
lacking of some parts.
2. UPS Installation.
This UPS should be located in protected place.
This UPS must be connected to a power
receptacle with earth ground.
a. Make sure main switch on the off position.
b. Connect the UPS to the available outlet.
3. UPS management software.
If communication software is needed from
UPS to PC, please contact the nearest agent/
service center in your city.
1. Buka kemasan dan Pemeriksaan.
Buka kemasan dan periksa isinya. Isi dari
kemasan ; buku petunjuk, kartu garansi, kabel
daya input.
Periksa penampilan UPS untuk mengetahui
apakah terdapat kerusakan akibat pengiriman.
Jangan menghidupkan unit dan langsung
beritahukan kepada agen jika ditemukan
kerusakan ataupun kekurangan.
2. Instalasi UPS.
Letakkan UPS di tempat terlindung.
UPS harus dipasang pada stopkontak yang
mempunyai hubungan ke bumi (arde).
a. Pastikan main switch pada posisi off.
b. Hubungkan UPS dengan stopkontak yang
tersedia.
3. Perangkat lunak pengelolaan UPS.
Jika dibutuhkan perangkat lunak komunikasi
dari UPS ke PC, harap menghubungi agen/
pusat layanan terdekat di kota anda.
1. Turn on procedure.
a. Press on main switch at the front panel.
b. Turn on the load connected to the outlet.
2. When the line power is interrupted.
In case of line power is interrupted (off or
voltage is too low/ high), inverter converts the
battery power to AC power automatically with
transfer time 4 ms. Buzzer will sound at
interval 4 seconds if the line power off or
< 165V or > 250V. When the battery is near
the end of its capacity, buzzer will sound
continuously. At this time data should be
stored and all load shutdown.
3. Turn off procedure.
a. Turn off all the load connected to the outlet.
b. Press on power button at the front panel.
<
1. Cara Menghidupkan.
a. Tekan tombol daya pada panel depan.
b. Hidupkan beban yang terpasang pada
stopkontak keluaran.
2. Saat listrik jala-jala terganggu (padam atau
tegangannya terlalu rendah / tinggi), inverter
langsung bekerja dengan waktu alih 4 ms
mengubah daya baterai menjadi arus listrik
AC. Buzzer akan berbunyi putus - putus
selang 4 detik, jika listrik jala-jala mati atau
< 165V atau > 250V. Saat baterai hampir habis
buzzer akan berbunyi sinambung. Pada saat ini
data harus sudah tersimpan dan semua semua
beban harus sudah dimatikan.
3. Cara mematikan.
a. Matikan semua beban yang terpasang pada
UPS.
b. Tekan tombol daya pada panel depan.
<
VI. OPERATION PROCEDURE / CARA PENGOPERASIAN

VIII. TABLE OF STATUS INDICATOR / TABEL
STATUS INDIKATOR
BUZZER LED
NTPL NTPC L1 L2 L3
RECOMMENDED
SOLUTION
MAIN
SWITCH
STATUS
CONDITION
Normal
No line voltage
Line voltage too
low
Line voltage too
high
Inverter is on at
low battery voltage
1. Line power is
normal.
2. Low battery.
Check the line power, make sure
between 165-250 Vac.
Check the line power, < 250 Vac.
Save your work now, the inverter
will be cut off.
1
1
1
1
1
1 0 0 1 0 1 -
0 0
01
1 0
01
0 1 0
0
0
0
1
1
1
1
1
0
1
0
0
0
0
-
-
Remark :
L1 : Green Led (Line On) NTPL : Audible alarm sound every 4 seconds.
L2 : Yellow Led (Inverter) NTPC : Audible alarm sound every 1 second.
L3 : Red Led (Battery Low)
VII. START UP UPS / MENGHIDUPKAN UPS
1. Pastikan tombol pada posisi “off” dan tidak
ada beban yang terpasang pada stopkontak
keluaran.
2. Hubungkan steker kabel daya ke stopkontak
jala-jala yang mempunyai arde.
3. Hidupkan UPS dengan menekan tombol daya.
Led merah TEGANGAN BATERAI RENDAH
akan menyala sekitar 2 detik dan padam
kembali bila kondisi baterai baik. Bersamaan
dengan itu led hijau LISTRIK JALA-JALA
menyala (bila tegangannya > 165V dan
< 250V) yang menunjukkan keluaran UPS
berasal dari listrik jala-jala.
4. Cabut steker kabel daya dari stopkontak jala-
jala maka led hijau LISTRIK JALA-JALA
padam sedangkan led kuning INVERTER akan
menyala dan buzzer akan berbunyi setiap 4
detik.
5. Pasang kembali steker maka sekitar 2 detik
kemudian led kuning INVERTER padam
sedangkan led hijau akan menyala.
6. Sekarang UPS siap menjalankan fungsinya.
Hubungkan peralatan yang akan diberi pasokan
daya pada stopkontak keluaran UPS.
1. Make sure main switch on the “off” position
and no load is connected to the outlet.
2. Connect inlet with power cord to a power
receptacle with earth ground.
3. Turn on the UPS by pressing power button.
The red led of BATTERY LOW lights for
about 2 seconds and will go out when the
battery is in good condition At the same time
the green led of LINE ON light (if line
voltage > 165V and < 250V) which indicates
UPS output is from line power.
4. Disconnect inlet from line power, the green
led of LINE ON will go out while the yellow
led of INVERTER will light on and audible
alarm will sound every 4 seconds.
5. Connect inlet to line power again and then
after about 2 seconds the yellow led of
INVERTER will go out while the green led of
line on will light on.
6. Now your UPS is ready for operation.
Connect the equipment that is going to be
supplied by the UPS into the UPS.
.

IX. TROUBLE SHOOTING / PETUNJUK
KETIDAK NORMALAN
SYSTEM PROBLEM CAUSE RECOMMENDED
SOLUTION
“Green Led” indicator not
light.
Main voltage >165 Vac, turn
on main switch, red led light
on, after ± 5 seconds go out,
but inverter does not work.
When AC main failure and
inverter does not work.
Communication from UPS
to computer fail.
1. Main voltage < 165 Vac or
> 250 Vac.
2. Problem in transfer switch
control.
Battery voltage low.
Problem in inverter circuit.
1. Interface cable not connected.
2. Software has not been installed
or configure properly.
3. Interface cable or monitor card
is broken.
1. Install the interface cable.
2. Install software (setting
software)
3. If the problem still occur, call
for service.
1. Check your mains voltage.
2. If main voltage > 165 Vac and
< 250 Vac, call for service.
1. Check battery voltage.
2. Charger battery ± 10 hour by
kept the main switch in on
position when AC mains
normal.
3. Call for service.
Call for service.
SERVICE CENTRE
ICA
Jln. Pinangsia Raya I No: 22BB
Jakarta - 11120
Phone : [phone] (Hunting)
Notes :
For service information other cities, please visit “www.icaups.co.id” go to support menu.
------------------------------------------------------------------------------------------------------------------------
: Catatan
Untuk informasi servis kota-kota lain, silahkan kunjungi “www.icaups.co.id” cari menu support
