NOTE: Use these amended pages as one addendum set.
Do not mix them up with the previous master pages.
SERVICE MANUAL
ADDENDUM
October 2016
iR9500
CONTENTS
AMENDED PAGES:
PARTS LIST ………………………………………………………………………… 1
MECHANICAL PARTS LIST ……………………………………………………… 61
BOARD LAYOUTS ………………………………………………………………… 69
SCHEMATIC DIAGRAMS ………………………………………………………… 73

SECTION §PARTS LIST
1
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[DISPLAY UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[DISPLAY UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
IC1 1130011880 S.IC CD4051BPWR T 104.0/86.2
IC2 1130011880 S.IC CD4051BPWR T 121.0/86.2
IC3 1130011880 S.IC CD4051BPWR T 30.1/77.6
IC6 1140015180 S.IC M30622M6P-535GP T 48.2/27.8
IC201 1110006400 S.IC M62343GP D65J T 68.4/58.2
IC203 1130007431 S.IC TC7S14FU (TE85RF)
Except [#06] T 82.4/39.9
IC204 1110006670 S.IC NJM2730F-TE1-#ZZZB
Except [#06] T 76.3/56.3
IC210 1180000421 S.IC TA78L05F (TE12RF) T 102.1/63.7
IC601 1130011551 S.IC RX-4581NB-F T 39.0/45.9
IC651 1110005822 S.IC R3112N281A-TR-FE T 50.2/68.9
Q200 1560001260 S.FET 2SK3018 T106 T 53.6/70.4
Q201 1550000330 S.FET FDC610PZ Other than [#06] T 113.0/37.6
1530003301 S.TRA 2SC3647S-TD-E [#06]
Q202 1590004750 S.TRA LMUN5213T1G Other than [#02] T 109.8/41.5
1530003301 S.TRA 2SC3647S-TD-E [#06]
Q203 1590004750 S.TRA LMUN5213T1G Other than [#06] T 84.2/36.9
1530002060 S.TRA 2SC4081 T106 R [#06]
Q204 1590004750 S.TRA LMUN5213T1G Other than [#06] T 93.7/38.8
1520000651 S.TRA 2SB1201S-TL-E [#06]
Q205 1590004750 S.TRA LMUN5213T1G Other than [#06] T 97.6/38.2
1590003940 S.TRA RN1105 (TE85LF) [#06]
Q207 1590004750 S.TRA LMUN5213T1G Except [#06] T 93.4/46.2
Q209 1520000651 S.TRA 2SB1201S-TL-E T 113.6/59.9
Q210 1530002060 S.TRA 2SC4081 T106 R T 106.4/54.9
Q350 1590003940 S.TRA RN1105 (TE85LF) T 29.5/85.8
Q351 1590003940 S.TRA RN1105 (TE85LF) T 28.0/83.0
Q352 1590003940 S.TRA RN1105 (TE85LF) T 26.5/85.8
Q370 1590003940 S.TRA RN1105 (TE85LF) T 6.3/80.8
Q371 1590003940 S.TRA RN1105 (TE85LF) T 11.8/74.0
Q375 1590003940 S.TRA RN1105 (TE85LF) T 6.3/78.8
Q420 1590003940 S.TRA RN1105 (TE85LF) T 40.5/85.3
Q421 1590003940 S.TRA RN1105 (TE85LF) T 40.5/82.7
Q601 1510000771 S.TRA 2SA1586-GR (TE85LF) T 56.5/71.6
Q610 1550000090 S.FET RSQ035P03TR T 20.6/60.7
Q611 1550000090 S.FET RSQ035P03TR T 20.8/54.0
Q612 1590003940 S.TRA RN1105 (TE85LF) T 26.3/61.0
Q613 1590003940 S.TRA RN1105 (TE85LF) T 27.7/54.6
D12 1730002511 S.ZEN MAZ8027GHL T 108.2/57.2
D201 1750002170 S.DIO DB2S31400L Except [#06] T 78.4/41.9
D202 1750002170 S.DIO DB2S31400L Except [#06] T 91.0/40.3
D601 1750002020 S.DIO DA2S10100L T 57.6/75.5
D602 1750002020 S.DIO DA2S10100L T 56.4/69.7
D603 1750002020 S.DIO DA2S10100L T 56.4/73.5
D610 1750001350 S.DIO CLS02 (TE16LQ) T 13.9/59.1
D611 1750001350 S.DIO CLS02 (TE16LQ) T 13.9/54.4
X1 6050009870 S.XTA CR-567 (9.8304 MHz) T 49.7/44.6
L201 6200001831 S.COI NLV32T-100J-PF T 43.9/84.4
L602 6200001831 S.COI NLV32T-100J-PF T 59.5/72.4
R2 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/57.1
R3 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/60.0
R4 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/58.3
R5 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/61.2
R6 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/59.5
R7 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/62.4
R8 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/60.7
R9 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/63.6
R10 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/61.9
R11 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/64.8
R12 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/63.1
R13 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/66.0
R14 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/64.3
R15 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/67.2
R16 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/65.5
R17 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/68.4
R18 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/66.7
R19 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/70.8
R20 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/69.1
R21 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 127.3/72.0
R22 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 123.1/71.5
R23 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 127.3/69.6
R24 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 123.1/67.9
R25 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 123.1/70.3
R26 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 127.3/73.2
R200 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
Other than [#06] T 109.3/37.5
7030003440 S.RES ERJ3GEYJ 102 V (1 k) [#06]
R201 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
Other than [#06] T 112.0/40.7
7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) [#06]
R202 7030003250 S.RES ERJ3GEYJ 270 V (27)
Other than [#06] T 76.9/42.0
7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) [#06]
R203 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 49.7/41.3
R204 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 38.2/33.3
R205 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 70.7/54.2
(Amended page)
October 2016
R206 7030003250 S.RES ERJ3GEYJ 270 V (27)
Except [#06] T 89.5/40.3
R207 7030003570 S.RES ERJ3GEYJ 123 V (12 k)
Except [#06] T 90.2/38.3
R208 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
Other than [#06] T 93.6/40.9
7030003360 S.RES ERJ3GEYJ 221 V (220) [#06]
R209 7030003860 S.RES ERJ3GE JPW V T 13.0/24.7
R210 7030003860 S.RES ERJ3GE JPW V T 13.0/23.4
R212 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k)
Other than [#06] T 80.4/58.9
7030003660 S.RES ERJ3GEYJ 683 V (68 k) [#06]
R213 7030003410 S.RES ERJ3GEYJ 561 V (560)
Other than [#06] T 80.4/55.3
7030003580 S.RES ERJ3GEYJ 153 V (15 k) [#06]
R214 7030003690 S.RES ERJ3GEYJ 124 V (120 k)
Except [#02] T 77.7/39.9
R215 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
Except [#06] T 86.0/39.9
R235 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 50.3/13.1
R239 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 37.0/85.4
R240 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 35.8/85.4
R241 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 38.2/85.4
R242 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 34.6/85.4
R246 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 59.6/13.3
R247 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 58.3/13.3
R248 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 57.0/13.3
R249 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 55.7/13.3
R250 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 54.4/13.3
R251 7030003320 S.RES ERJ3GEYJ 101 V (100) T 52.7/13.1
R254 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 48.4/13.3
R304 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 58.5/40.0
R306 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 58.8/29.0
R308 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
Except [#06] T 97.7/40.9
R309 7030003860 S.RES ERJ3GE JPW V Except [#06] T 117.6/36.4
R310 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 25.0/42.4
R311 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 25.0/43.6
R326 7030003360 S.RES ERJ3GEYJ 221 V (220) T 108.3/54.0
R327 7030003580 S.RES ERJ3GEYJ 153 V (15 k) T 104.5/54.8
R328 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 102.6/55.2
R339 7070000261 RES ERG2SJ 220 (22) Only [#06]
R340 7070000261 RES ERG2SJ 220 (22) Only [#06]
R369 7030003860 S.RES ERJ3GE JPW V T 56.1/37.2
R370 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.2/86.8
R371 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/91.4
R372 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/85.6
R373 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/90.2
R374 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/84.4
R375 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/89.0
R376 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/83.2
R377 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/87.8
R378 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/82.0
R379 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/86.6
R380 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/80.8
R381 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/85.4
R382 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/79.6
R383 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/84.2
R384 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/78.4
R385 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/83.0
R386 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/81.5
R387 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/77.2
R388 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/80.3
R389 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.7/73.5
R390 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/76.7
R391 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 22.4/73.5
R392 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/75.0
R393 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 14.6/77.9
R394 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 19.4/74.8
R395 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 14.6/79.1
R396 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 19.4/76.0
R503 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 36.2/32.5
R532 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 51.5/13.1
R560 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 18.2/14.0
R561 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.4/14.0
R562 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 20.6/14.0
R563 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 21.8/14.0
R564 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 23.0/14.0
R565 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 24.2/14.0
R566 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 25.4/14.0
R567 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 26.6/14.0
R568 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 27.8/14.0
R569 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 29.0/14.0
R570 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 30.2/14.0
R571 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 31.4/14.0
R572 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 32.6/14.0
R573 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 33.8/14.0
R574 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 35.0/14.0
R575 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 36.2/14.0
R576 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 37.4/14.0
R577 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 38.6/14.0
R578 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 39.8/14.0
R579 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 41.0/14.0
R580 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 42.2/14.0
R581 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 43.4/14.0
R601 7030003860 S.RES ERJ3GE JPW V T 53.5/68.5
R602 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 53.6/72.3

2
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[DISPLAY UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[SW-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R603 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 32.4/45.4
R604 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 32.4/46.9
R610 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 23.8/61.1
R611 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 25.2/54.6
R612 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 23.0/59.3
R613 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 23.2/55.8
R614 7030003860 S.RES ERJ3GE JPW V T 9.4/71.2
R615 7030003860 S.RES ERJ3GE JPW V T 9.4/70.0
R616 7030003860 S.RES ERJ3GE JPW V T 9.4/67.6
R617 7030003720 S.RES ERJ3GEYJ 224 V (220 k) T 9.6/73.0
R618 7030003720 S.RES ERJ3GEYJ 224 V (220 k) T 9.4/68.8
R619 7030003720 S.RES ERJ3GEYJ 224 V (220 k) T 9.4/66.4
R651 7030003650 S.RES ERJ3GEYJ 563 V (56 k) T 50.6/73.7
R652 7030003620 S.RES ERJ3GEYJ 333 V (33 k) T 50.6/72.5
R653 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 53.5/66.6
C1 4030011600 S.CER C1608 JB 1E 104K-T T 25.7/57.6
C8 4030011600 S.CER C1608 JB 1E 104K-T T 131.4/74.7
C200 4030011600 S.CER C1608 JB 1E 104K-T T 106.2/58.6
C202 4510008800 S.ELE EEE1EA100SR Other than [#06] T 78.2/35.1
4030019160 S.CER C4520 CH 3F 100FT [#06]
C203 4030007020 S.CER C1608 CH 1H 120J-T T 50.5/40.0
C204 4030007020 S.CER C1608 CH 1H 120J-T T 47.9/40.0
C205 4550007370 S.TAN F931V225MBABMA T 107.1/64.0
C206 4030011600 S.CER C1608 JB 1E 104K-T T 71.0/60.0
C207 4030011600 S.CER C1608 JB 1E 104K-T T 32.5/81.1
C208 4030011600 S.CER C1608 JB 1E 104K-T T 120.8/89.6
C209 4030011600 S.CER C1608 JB 1E 104K-T T 104.2/89.6
C210 4030011600 S.CER C1608 JB 1E 104K-T T 98.4/64.6
C211 4030011600 S.CER C1608 JB 1E 104K-T T 65.9/60.4
C212 4030011600 S.CER C1608 JB 1E 104K-T T 80.4/56.5
C213 4510008800 S.ELE EEE1EA100SR Other than [#06] T 90.7/33.4
4510009150 S.ELE EEE1EA470WP [#06]
C215 4030011600 S.CER C1608 JB 1E 104K-T T 99.8/55.2
C216 4030011600 S.CER C1608 JB 1E 104K-T T 62.4/11.2
C217 4030011600 S.CER C1608 JB 1E 104K-T T 38.9/79.8
C218 4510009150 S.ELE EEE1EA470WP T 44.3/77.9
C219 4030006860 S.CER C1608 JB 1H 102K-T T 40.1/79.8
C220 4550007510 S.TAN F931C106MBABMA T 102.0/59.4
C221 4030011600 S.CER C1608 JB 1E 104K-T T 102.6/54.0
C222 4030011600 S.CER C1608 JB 1E 104K-T
Other than [#06] T 84.5/40.7
4340000330 S.MYL ECHU1H103J [#06]
C223 4030011600 S.CER C1608 JB 1E 104K-T
Other than [#06] T 76.7/58.9
4340000330 S.MYL ECHU1H103J [#06]
C224 4030011600 S.CER C1608 JB 1E 104K-T T 48.2/38.2
C231 4030011600 S.CER C1608 JB 1E 104K-T T 47.6/17.4
C232 4030011600 S.CER C1608 JB 1E 104K-T T 58.0/31.2
C235 4030011600 S.CER C1608 JB 1E 104K-T T 50.3/81.1
C241 4030011600 S.CER C1608 JB 1E 104K-T T 105.5/75.6
C242 4030011600 S.CER C1608 JB 1E 104K-T T 106.7/75.6
C243 4030011600 S.CER C1608 JB 1E 104K-T T 104.3/75.6
C244 4030011600 S.CER C1608 JB 1E 104K-T T 103.1/75.6
C245 4030011600 S.CER C1608 JB 1E 104K-T T 110.1/87.8
C246 4030011600 S.CER C1608 JB 1E 104K-T T 110.1/86.6
C247 4030011600 S.CER C1608 JB 1E 104K-T T 110.1/85.4
C248 4030011600 S.CER C1608 JB 1E 104K-T T 110.1/84.2
C253 4030011600 S.CER C1608 JB 1E 104K-T T 127.1/84.6
C254 4030011600 S.CER C1608 JB 1E 104K-T T 127.1/85.8
C255 4030011600 S.CER C1608 JB 1E 104K-T T 127.1/87.0
C256 4030011600 S.CER C1608 JB 1E 104K-T T 127.1/88.2
C501 4030008890 S.CER C1608 JB 1H 273K-T T 50.7/66.5
C601 4510008800 S.ELE EEE1EA100SR T 53.7/77.3
C602 4030011600 S.CER C1608 JB 1E 104K-T T 39.2/41.9
C610 4030006900 S.CER C1608 JB 1H 103K-T T 8.5/58.0
C611 4030006900 S.CER C1608 JB 1H 103K-T T 8.5/54.9
C613 4030011600 S.CER C1608 JB 1E 104K-T T 133.2/55.8
C614 4030006860 S.CER C1608 JB 1H 102K-T T 28.9/61.2
C615 4030006860 S.CER C1608 JB 1H 102K-T T 30.2/54.2
C616 4030011600 S.CER C1608 JB 1E 104K-T T 8.4/74.2
C652 4030011600 S.CER C1608 JB 1E 104K-T T 50.6/71.3
J1 6510021722 S.CON 30FLT-SM2-TB T 10.7/86.3
J3 6510021722 S.CON 30FLT-SM2-TB T 131.6/65.3
J4 6510021561 S.CON 52808-2470 T 30.8/8.8
J5 6510019971 S.CON 52808-1071 T 25.0/90.2
J7 6510019971 S.CON 52808-1071 T 55.5/8.8
J201 6510022472 S.CON 40FLT-SM2-TB T 6.2/28.7
J202 6510022472 S.CON 40FLT-SM2-TB T 11.9/48.5
J203 6510020081 S.CON 52808-2071 T 44.0/90.1
J301 6510018971 S.CON B4B-PH-SM4-TB
Other than [#06] T 130.3/38.9
6510021181 S.CON SM2(8.0)B-BHS1TB [#06]
J601 6510021861 CON BH-800.4GG
J610 6510022191 S.CON B3B-PH-SM4-TB T 2.5/56.7
J611 6510 022311 S.CON B5B -PH- SM 4 -TB T 2. 5 / 70.9
T201 5910001050 TRA 3319-T106-LF Only [#06]
BT601 3020000110 LIT CR-2032L/BK
EP203 6910014730 S.BEA MPZ2012S331A-T T 49.4/84.5
EP205 6910014730 S.BEA MPZ2012S331A-T T 60.9/34.9
EP208 6910014730 S.BEA MPZ2012S331A-T T 47.6/84.5
IC1 1130011510 S.IC BU2099FV-E2 B 91.4/47.7
R1 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 8.5/88.3
R2 7030003380 S.RES ERJ3GEYJ 331 V (330) B 8.6/87.0
R3 7030003380 S.RES ERJ3GEYJ 331 V (330) B 8.5/41.5
R4 7030003380 S.RES ERJ3GEYJ 331 V (330) B 8.5/56.5
R6 7030003400 S.RES ERJ3GEYJ 471 V (470) B 26.5/37.1
R7 7030003400 S.RES ERJ3GEYJ 471 V (470) B 38.3/38.0
R8 7030003400 S.RES ERJ3GEYJ 471 V (470) B 53.9/37.5
R9 7030003400 S.RES ERJ3GEYJ 471 V (470) B 58.0/37.5
R10 7030003400 S.RES ERJ3GEYJ 471 V (470) B 73.7/36.7
R11 7030003400 S.RES ERJ3GEYJ 471 V (470) B 86.3/38.4
R12 7030003400 S.RES ERJ3GEYJ 471 V (470) B 56.3/81.9
R13 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 9.5/38.4
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 49.9/77.9
R15 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 31.4/37.1
R16 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 47.1/37.1
R17 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 66.4/35.8
R18 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 80.2/38.4
R19 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 89.1/60.7
R20 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 99.3/62.5
R21 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 89.1/64.3
R22 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 101.4/68.9
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 101.6/56.8
R24 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 98.5/32.7
R25 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 100.5/20.8
R26 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 100.5/8.6
R27 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 99.3/61.3
R28 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 89.1/59.5
R29 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 54.1/57.2
R30 7030003400 S.RES ERJ3GEYJ 471 V (470) B 50.0/56.3
R31 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 86.9/50.1
C1 4030011600 S.CER C1608 JB 1E 104K-T B 89.1/63.1
C2 4030011600 S.CER C1608 JB 1E 104K-T B 99.3/63.7
C3 4030011600 S.CER C1608 JB 1E 104K-T B 89.1/61.9
C4 4030011600 S.CER C1608 JB 1E 104K-T B 99.3/60.1
C5 4030011600 S.CER C1608 JB 1E 104K-T B 89.1/58.3
C6 4030011600 S.CER C1608 JB 1E 104K-T B 52.7/75.2
C7 4030011600 S.CER C1608 JB 1E 104K-T B 89.8/75.2
C8 4030011600 S.CER C1608 JB 1E 104K-T B 94.8/70.6
C9 4030011600 S.CER C1608 JB 1E 104K-T B 94.6/51.9
C10 4030011600 S.CER C1608 JB 1E 104K-T B 40.6/26.5
C11 4030011600 S.CER C1608 JB 1E 104K-T B 63.2/28.3
C12 4030011600 S.CER C1608 JB 1E 104K-T B 90.4/51.9
J1 6510020091 S.CON 52808-0871 B 46.7/70.7
J2 6510020091 S.CON 52808-0871 B 83.7/70.7
J3 6510021722 S.CON 30FLT-SM2-TB B 94.4/61.2
J4 6510020091 S.CON 52808-0871 B 56.1/27.6
J5 6510020091 S.CON 52808-0871 B 34.2/27.6
DS5 5040002980 S.LED SML-512DW-T86 T 8.5/87.7
DS6 5040002930 S.LED SML-512MW T86 T 8.5/86.4
DS7 5040002930 S.LED SML-512MW T86 T 8.5/41.5
DS8 5040002930 S.LED SML-512MW T86 T 26.3/38.2
DS9 5040002930 S.LED SML-512MW T86 T 37.8/38.2
DS10 5040002930 S.LED SML-512MW T86 T 49.3/38.2
DS11 5040002930 S.LED SML-512MW T86 T 63.3/38.2
DS12 5040002930 S.LED SML-512MW T86 T 56.3/81.9
DS13 5040002930 S.LED SML-512MW T86 T 74.8/38.2
DS14 5040002930 S.LED SML-512MW T86 T 86.3/38.2
DS16 5040002930 S.LED SML-512MW T86 T 8.5/56.5
DS17 5040002930 S.LED SML-512MW T86 T 56.3/53.9
S1 2260002740 S.SWI LS8J2M-T T 9.8/77.2
S2 2260002740 S.SWI LS8J2M-T T 8.3/62.5
S3 2260002740 S.SWI LS8J2M-T T 8.3/48.8
S4 2260002740 S.SWI LS8J2M-T T 8.3/35.1
S5 2260002740 S.SWI LS8J2M-T T 37.6/33.1
S6 2260002740 S.SWI LS8J2M-T T 26.1/33.1
S7 2260002740 S.SWI LS8J2M-T T 49.1/33.1
S8 2260002740 S.SWI LS8J2M-T T 63.1/33.1
S11 2260002740 S.SWI LS8J2M-T T 56.1/75.5
S12 2260002740 S.SWI LS8J2M-T T 74.6/33.1
S13 2260002740 S.SWI LS8J2M-T T 86.1/33.1
S14 2260002740 S.SWI LS8J2M-T T 100.8/82.7
S15 2260002740 S.SWI LS8J2M-T T 100.8/70.7
S16 2260002740 S.SWI LS8J2M-T T 100.8/58.7
S17 2260002740 S.SWI LS8J2M-T T 100.8/46.7
S18 2260002740 S.SWI LS8J2M-T T 100.8/34.7
S19 2260002740 S.SWI LS8J2M-T T 100.8/22.7
S20 2260002740 S.SWI LS8J2M-T T 100.8/10.7
S21 2260002740 S.SWI LS8J2M-T T 56.1/47.5
(Amended page)
October 2016

3
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[SW-B UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[SW-C UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
J2 6510021561 S.CON 52808-2470 B 118.7/19.8
S1 2260002740 S.SWI LS8J2M-T T 23.5/24.8
S2 2260002740 S.SWI LS8J2M-T T 45.5/24.8
S3 2260002740 S.SWI LS8J2M-T T 67.5/24.8
S4 2260002740 S.SWI LS8J2M-T T 89.5/24.8
S5 2260002740 S.SWI LS8J2M-T T 111.5/24.8
S6 2260002740 S.SWI LS8J2M-T T 133.5/24.8
S7 2260002740 S.SWI LS8J2M-T T 155.5/24.8
S8 2260002740 S.SWI LS8J2M-T T 23.5/15.4
S9 2260002740 S.SWI LS8J2M-T T 45.5/15.4
S10 2260002740 S.SWI LS8J2M-T T 67.5/15.4
S11 2260002740 S.SWI LS8J2M-T T 89.5/15.4
S12 2260002740 S.SWI LS8J2M-T T 111.5/15.4
S13 2260002740 S.SWI LS8J2M-T T 133.5/15.4
S14 2260002740 S.SWI LS8J2M-T T 155.5/15.4
S15 2260002740 S.SWI LS8J2M-T T 14.2/2.7
S16 2260002740 S.SWI LS8J2M-T T 35.7/2.7
S17 2260002740 S.SWI LS8J2M-T T 57.2/2.7
S18 2260002740 S.SWI LS8J2M-T T 78.7/2.7
S19 2260002740 S.SWI LS8J2M-T T 100.2/2.7
S20 2260002740 S.SWI LS8J2M-T T 123.8/2.7
S21 2260002740 S.SWI LS8J2M-T T 147.8/2.7
S22 2260002740 S.SWI LS8J2M-T T 168.1/2.7
R3 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 4.7/17.9
R13 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 4.7/50.2
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 4.7/44.5
R18 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 32.8/38.7
R19 7030003400 S.RES ERJ3GEYJ 471 V (470) B 30.6/40.9
R20 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 51.1/38.7
R21 7030003400 S.RES ERJ3GEYJ 471 V (470) B 48.5/40.5
R22 7030003400 S.RES ERJ3GEYJ 471 V (470) B 68.8/40.2
R31 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 5.4/40.7
R32 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 5.4/38.1
C5 4030011600 S.CER C1608 JB 1E 104K-T B 14.3/39.2
C31 4030011600 S.CER C1608 JB 1E 104K-T B 6.2/46.3
C32 4030011600 S.CER C1608 JB 1E 104K-T B 6.5/35.5
J3 6510021561 S.CON 52808-2470 B 10.4/50.5
J5 6510020091 S.CON 52808-0871 B 27.2/34.2
J6 6510020091 S.CON 52808-0871 B 67.2/34.2
DS1 5040002930 S.LED SML-512MW T86 T 30.8/42.4
DS2 5040002930 S.LED SML-512MW T86 T 51.8/42.4
DS3 5040002930 S.LED SML-512MW T86 T 72.8/42.4
S23 2260002740 S.SWI LS8J2M-T T 10.6/59.9
S24 2260002740 S.SWI LS8J2M-T T 10.6/49.7
S25 2260002740 S.SWI LS8J2M-T T 10.6/34.9
S26 2260002740 S.SWI LS8J2M-T T 8.4/2.2
S27 2260002740 S.SWI LS8J2M-T T 28.3/59.9
S28 2260002740 S.SWI LS8J2M-T T 28.3/49.7
S29 2260002740 S.SWI LS8J2M-T T 30.5/34.9
S30 2260002740 S.SWI LS8J2M-T T 43.8/59.9
S31 2260002740 S.SWI LS8J2M-T T 43.8/49.7
S32 2260002740 S.SWI LS8J2M-T T 51.5/34.9
S33 2260002740 S.SWI LS8J2M-T T 59.3/59.9
S34 2260002740 S.SWI LS8J2M-T T 59.3/49.7
S35 2260002740 S.SWI LS8J2M-T T 72.5/34.9
S36 2260002740 S.SWI LS8J2M-T T 74.8/59.9
S37 2260002740 S.SWI LS8J2M-T T 74.8/49.7
(Amended page)
October 2016

4
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[TENKEY UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[JACK UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
R1 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 16.4/36.6
R3 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 14.7/28.8
R4 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 13.8/67.9
R5 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 13.8/60.1
R6 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 13.8/54.1
R8 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 15.8/67.3
R9 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 18.5/37.2
R10 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 15.3/25.4
R11 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 31.3/69.8
R12 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 31.3/60.1
R13 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 31.3/50.5
R14 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 29.2/71.8
R15 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 43.6/36.4
R16 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 43.6/26.9
R17 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 48.8/69.8
R18 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 48.8/59.7
R19 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 48.8/50.1
R20 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 46.7/71.8
C1 4030011600 S.CER C1608 JB 1E 104K-T B 18.2/70.8
C2 4030011600 S.CER C1608 JB 1E 104K-T B 47.8/17.6
C3 4030011600 S.CER C1608 JB 1E 104K-T B 18.5/35.9
C4 4030011600 S.CER C1608 JB 1E 104K-T B 15.3/24.1
C5 4030011600 S.CER C1608 JB 1E 104K-T B 19.2/14.9
C6 4030011600 S.CER C1608 JB 1E 104K-T B 15.8/68.6
C7 4030011600 S.CER C1608 JB 1E 104K-T B 29.2/70.5
C8 4030011600 S.CER C1608 JB 1E 104K-T B 46.7/70.5
J1 6510021722 S.CON 30FLT-SM2-TB B 21.6/63.6
J3 6510021561 S.CON 52808-2470 B 46.2/11.8
S1 2260002740 S.SWI LS8J2M-T T 16.2/74.2
S2 2260002740 S.SWI LS8J2M-T T 16.2/64.7
S3 2260002740 S.SWI LS8J2M-T T 16.2/55.2
S4 2260002740 S.SWI LS8J2M-T T 16.2/45.7
S5 2260002740 S.SWI LS8J2M-T T 16.2/32.5
S6 2260002740 S.SWI LS8J2M-T T 16.2/23.0
S7 2260002740 S.SWI LS8J2M-T T 21.2/12.1
S8 2260002740 S.SWI LS8J2M-T T 33.7/74.2
S9 2260002740 S.SWI LS8J2M-T T 33.7/64.7
S10 2260002740 S.SWI LS8J2M-T T 33.7/55.2
S11 2260002740 S.SWI LS8J2M-T T 33.7/45.7
S12 2260002740 S.SWI LS8J2M-T T 33.7/32.5
S13 2260002740 S.SWI LS8J2M-T T 33.7/23.0
S14 2260002740 S.SWI LS8J2M-T T 51.2/74.2
S15 2260002740 S.SWI LS8J2M-T T 51.2/64.7
S16 2260002740 S.SWI LS8J2M-T T 51.2/55.2
S17 2260002740 S.SWI LS8J2M-T T 51.2/45.7
S18 2260002740 S.SWI LS8J2M-T T 51.2/32.5
S19 2260002740 S.SWI LS8J2M-T T 51.2/23.0
S20 2260002740 S.SWI LS8J2M-T T 46.2/12.1
R1 7030006060 S.RES ERJ12YJ100U (10) B 16.0/9.5
R2 7030006060 S.RES ERJ12YJ100U (10) B 16.0/13.3
C1 4030006860 S.CER C1608 JB 1H 102K-T B 11.9/39.3
C2 4030006860 S.CER C1608 JB 1H 102K-T B 13.0/34.0
C3 4030006860 S.CER C1608 JB 1H 102K-T B 13.0/32.0
C4 4030006860 S.CER C1608 JB 1H 102K-T B 11.5/43.4
C5 4030006860 S.CER C1608 JB 1H 102K-T B 13.0/36.0
C6 4030006860 S.CER C1608 JB 1H 102K-T B 13.0/30.0
C7 4030006860 S.CER C1608 JB 1H 102K-T B 13.0/28.0
J4 6510023590 CON HSJ2000-01-010
J5 6450001440 CON HSJ1403-01-010
J6 6450001440 CON HSJ1403-01-010
J7 6510023761 S.CON S10B-PH-SM4-TB B 3.8/33.0
J8 6510021601 S.CON S2B-PH-SM4-TB B 3.8/53.3
EP2 6910014730 S.BEA MPZ2012S331A-T B 16.3/52.6
EP3 6910014730 S.BEA MPZ2012S331A-T B 16.3/50.8
EP4 6910014730 S.BEA MPZ2012S331A-T B 16.3/40.8
EP5 6910014730 S.BEA MPZ2012S331A-T B 16.3/38.6
EP6 6910014730 S.BEA MPZ2012S331A-T B 17.5/21.2
EP7 6910014730 S.BEA MPZ2012S331A-T B 14.5/21.2
(Amended page)
October 2016

5
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[LED UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[SENSOR UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
R4 7030003390 S.RES ERJ3GEYJ 391 V (390) T 79.1/14.8
R7 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) T 139.3/13.9
R8 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) T 147.3/14.0
J1 6 510 02 0711 S .C O N 52 79 3 -107 0 T 111. 3/ 2. 9
DS4 5040002961 S.LED SML-A12MT T86J T 75.0/17.0
DS5 5040002961 S.LED SML-A12MT T86J T 77.6/17.0
DS7 5040003011 S.LED SML-A12WT T86J T 135.3/16.0
DS8 5040003011 S.LED SML-A12WT T86J T 147.3/16.0
IC1 1170000360 S.PHO CPI250-T T 11.4/6.4
IC2 1170000410 S.PHO CPI-210-T T 11.4/14.8
IC3 1130018320 S.IC SN74LVC3G14DCTR B 12.3/18.3
R1 7030003380 S.RES ERJ3GEYJ 331 V (330) B 8.5/9.2
R2 7030003380 S.RES ERJ3GEYJ 331 V (330) B 8.5/11.8
R3 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 11.7/6.0
R4 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 16.5/14.0
R5 7310004610 S.TRI EVM-2WSX80 B15 (104) B 11.1/8.0
R6 7310004610 S.TRI EVM-2WSX80 B15 (104) B 13.9/13.9
R7 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 15.8/6.0
R8 7310004610 S.TRI EVM-2WSX80 B15 (104) B 15.2/8.0
R9 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 10.7/14.8
R10 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 11.5/11.9
R11 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 15.3/17.4
C1 4030011600 S.CER C1608 JB 1E 104K-T B 14.6/20.1
W1 8900015710 CAB OPC-1604
(Amended page)
October 2016

6
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[VR-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[VR-B UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R2 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 14.9/22.3
R4 7210003170 VAR RV-318 (RK09L1120CON)
C1 4030006860 S.CER C1608 JB 1H 102K-T T 14.9/25.8
C2 4030006860 S.CER C1608 JB 1H 102K-T T 6.4/22.5
C3 4030006860 S.CER C1608 JB 1H 102K-T T 13.6/22.3
J1 6510020091 S.CON 52808-0871 T 10.0/22.5
S1 2250000440 ENC TP90N00E20-22.5F-2494
R2 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 14.9/22.3
R4 7210003170 VAR RV-318 (RK09L1120CON)
C1 4030006860 S.CER C1608 JB 1H 102K-T T 14.9/25.8
C2 4030006860 S.CER C1608 JB 1H 102K-T T 6.4/22.5
C3 4030006860 S.CER C1608 JB 1H 102K-T T 13.6/22.3
J1 6510020091 S.CON 52808-0871 T 10.0/22.5
S1 2250000440 ENC TP90N00E20-22.5F-2494
(Amended page)
October 2016

7
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[VR-C UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[VR-D UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R1 7210002970 VAR RV-314
(RK0972210 10KB/10KB)
R2 7210002970 VAR RV-314
(RK0972210 10KB/10KB)
R3 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 10.1/35.0
R4 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 10.1/32.4
R5 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 10.1/27.1
R6 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 10.1/25.8
C1 4030006860 S.CER C1608 JB 1H 102K-T T 10.1/33.7
C2 4030006860 S.CER C1608 JB 1H 102K-T T 10.1/31.1
C3 4030006860 S.CER C1608 JB 1H 102K-T T 10.1/28.4
C4 4030006860 S.CER C1608 JB 1H 102K-T T 10.1/24.5
J2 6510020091 S.CON 52808-0871 T 15.3/46.4
R1 7210002970 VAR RV-314
(RK0972210 10KB/10KB)
R2 7210002970 VAR RV-314
(RK0972210 10KB/10KB)
R3 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 12.9/16.8
R4 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 12.9/15.5
R5 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 10.1/24.7
R6 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 10.1/28.0
C1 4030006860 S.CER C1608 JB 1H 102K-T T 12.9/18.1
C2 4030006860 S.CER C1608 JB 1H 102K-T T 12.9/14.2
C3 4030006860 S.CER C1608 JB 1H 102K-T T 10.1/26.0
C4 4030006860 S.CER C1608 JB 1H 102K-T T 10.1/29.3
J2 6510020091 S.CON 52808-0871 T 14.8/24.5
(Amended page)
October 2016

8
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[VR-E UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[VR-F UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C1 4030006860 S.CER C1608 JB 1H 102K-T T 4.8/2.9
C2 4030006860 S.CER C1608 JB 1H 102K-T T 2.3/14.2
C3 4030006860 S.CER C1608 JB 1H 102K-T T 9.8/2.9
C4 4030006860 S.CER C1608 JB 1H 102K-T T 16.0/14.9
J1 6510020091 S.CON 52808-0871 T 14.9/8.5
S1 2250000410 ENC TP90D96E20-30F-2178-1
R1 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 12.8/2.1
R2 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 12.8/14.9
R3 7210002970 VAR RV-314
(RK0972210 10KB/10KB)
C1 4030006860 S.CER C1608 JB 1H 102K-T T 15.5/14.9
C2 4030006860 S.CER C1608 JB 1H 102K-T T 15.5/2.1
J1 6510020091 S.CON 52808-0871 T 15.0/8.5
(Amended page)
October 2016

9
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
IC101 1180000720 S.IC AN79L05M-(E1) B 73.8/9.8
IC201 1130013370 S.IC HD74LV2GT34AUSE-E T 56.5/48.0
IC202 1130006891 S.IC TC7S04FU (TE85RF) T 51.6/46.0
IC203 1140007881 S.IC TC190G08EFG0046JDZ T 59.1/34.4
IC1002 1130012610 S.IC SN74AHC1GU04DCKR T 92.9/59.5
IC1004 1130012600 S.IC SN74AHC1G04DCKR T 92.8/63.3
IC1005 1140012211 S.IC TMS320C6713BZDP225 B 75.5/76.6
IC1006 1130013743 S.IC AT29LV040A-15TU T 54.0/76.8
IC1076 1110 00 6 412 S. IC R3111N111A-TR- FE T 76.8/ 91.6
IC1301 1130009981 S.IC TC7W53FK (TE85LF) B 101.6/16.7
IC1302 1110006100 S.IC NJM5534MD-TE1-#ZZZB B 110.6/10.5
IC1304 1110006100 S.IC NJM5534MD-TE1-#ZZZB B 101.3/26.5
IC1305 1110006100 S.IC NJM5534MD-TE1-#ZZZB B 112.5/26.8
IC1331 1110005100 S.IC NJM072BM-TE1-#ZZZB B 123.0/14.3
IC1332 1130009981 S.IC TC7W53FK(TE85LF) B 122.5/23.2
IC1351 111000 6111 S.IC AK5 3 9 4AVS P/ P B 103.4 /42.1
IC1353 1130006891 S.IC TC7S04FU (TE85RF) B 71.5/50.5
IC1355 1130012610 S.IC SN74AHC1GU04DCKR B 71.5/46.1
IC1401 1130012580 S.IC AK4355-VF-E2 B 83.2/50.1
IC1421 1110005420 S.IC BA15532F-E2 B 79.9/30.0
IC1471 1110005420 S.IC BA15532F-E2 B 90.2/30.1
IC1601 1180002650 S.REG SI-3012KS-TL B 64.9/95.0
IC2001 1180002650 S.REG SI-3012KS-TL B 121.4/95.3
IC2051 1180003030 S.REG S-812C25AUA-C2FT2G B 126.3/38.3
IC2201 1110006580 S.IC AD8007AKSZ-REEL7 T 121.7/42.0
IC2301 1190002031 S.IC AD7650ASTZ B 118.5/53.0
IC2302 1130006891 S.IC TC7S04FU (TE85RF) B 125.4/52.5
IC2351 1130008041 S.IC TC7SH04FU (TE85LJF) B 125.3/49.8
IC 2402 11100 0 6412 S.IC R3111N111A -T R- FE T 10 5 . 8 /61.8
IC2403 1140012221 S.IC TMS320C6711DZDP200 B 119.5/76.5
IC2404 1130015330 S.IC A29L040V-70UF(RX-2844E) T 98.0/76.8
IC2451 1130011930 S.IC SN74LVC1G04DCKR T 132.0/59.6
IC2452 1130011930 S.IC SN74LVC1G04DCKR T 132.1/55.4
IC3101 1140007881 S.IC TC190G08EFG0046JDZ T 33.0/35.5
IC3131 1130006891 S.IC TC7S04FU (TE85RF) T 40.7/24.4
IC3221 1110003201 S.IC TA31136FNG (EL) T 10.1/41.1
IC3222 1120002830 S.IC NJM2125F-TE1-#FZZB T 18.8/48.7
IC3251 1130012850 S.IC SN74LVC3G34DCUR T 40.0/95.0
IC3271 1110005610 S.IC NJM2058V-TE1-#ZZZB B 13.1/71.2
IC3321 1130009981 S.IC TC7W53FK (TE85LF) B 84.2/17.2
IC3322 1130009981 S.IC TC7W53FK (TE85LF) B 92.5/17.2
IC3323 1130009981 S.IC TC7W53FK (TE85LF) B 76.9/17.2
IC3324 1130013370 S.IC HD74LV2GT34AUSE-E T 35.5/22.1
Q201 1590003940 S.TRA RN1105 (TE85LF) B 68.1/37.1
Q1001 1590003940 S.TRA RN1105 (TE85LF) B 90.2/56.6
Q3141 1590003940 S.TRA RN1105 (TE85LF) B 23.3/34.7
Q3221 1510000510 S.TRA 2SA1576A T106R T 17.5/55.5
Q3321 1590003940 S.TRA RN1105 (TE85LF) B 81.7/18.5
Q3322 1590003940 S.TRA RN1105 (TE85LF) B 90.0/18.5
Q3323 1590003940 S.TRA RN1105 (TE85LF) B 74.4/18.5
D1602 1710000840 S.DIO 1SR154-400 TE25 B 59.2/95.0
D2001 1710000840 S.DIO 1SR154-400 TE25 B 115.6/95.3
FI1001 2040000790 S.LC EXCCET103U B 90.5/73.4
FI2401 2040000790 S.LC EXCCET103U B 127.6/59.3
FI3201 2020001810 S.CER SFECV10M7FA00-R0 T 11.1/27.7
FI3221 2020002250 CER LT450EW
X1001 6050011660 S.XTA CR-754 (30.000 MHz) B 94.3/60.7
L201 6200001831 S.COI NLV32T-100J-PF B 62.8/43.8
L301 6200003711 S.COI NLV25T-2R7J-PF B 68.1/22.3
L302 6200002981 S.COI NLV32T-R56J-PF B 73.7/26.2
L303 6200003041 S.COI NLV32T-R68J-PF B 72.8/31.4
L304 6200003051 S.COI NLV32T-R82J-PF B 70.7/37.6
L1001 6180003501 S.COI SLF6028T-100M1R3-PF T 71.8/95.0
L2301 6200001831 S.COI NLV32T-100J-PF T 110.0/56.2
L2302 6200001831 S.COI NLV32T-100J-PF T 114.7/45.4
L2481 6180003501 S.COI SLF6028T-100M1R3-PF T 124.5/94.0
L2482 6200001831 S.COI NLV32T-100J-PF B 99.3/58.8
L3101 6200001831 S.COI NLV32T-100J-PF B 29.2/25.6
L3151 6200003091 S.COI NLV32T-2R7J-PF B 20.7/50.0
L3152 6200003061 S.COI NLV32T-1R2J-PF B 21.7/38.1
L3153 6200003061 S.COI NLV32T-1R2J-PF B 19.9/34.6
L3201 6200010970 S.COI C2520C-1R8G-A (1.8U) T 11.1/21.8
L3221 6200002041 S.COI NLV25T-101J-PF T 17.3/39.8
L3222 6200003151 S.COI NLV32T-180J-PF T 9.3/33.6
R1 7030003370 S.RES ERJ3GEYJ 271 V (270) B 53.3/17.5
R2 7030003230 S.RES ERJ3GEYJ 180 V (18) B 53.9/19.5
R3 7030003370 S.RES ERJ3GEYJ 271 V (270) B 54.6/17.5
R21 7030003860 S.RES ERJ3GE JPW V T 103.6/26.7
R41 7030003860 S.RES ERJ3GE JPW V B 89.8/9.4
R42 7030003860 S.RES ERJ3GE JPW V B 85.9/9.4
R61 7030003320 S.RES ERJ3GEYJ 101 V (100) T 110.7/93.1
R62 7030003320 S.RES ERJ3GEYJ 101 V (100) T 110.7/91.8
R63 7030003320 S.RES ERJ3GEYJ 101 V (100) T 108.0/91.3
R64 7030003320 S.RES ERJ3GEYJ 101 V (100) T 106.7/91.3
R65 7030003320 S.RES ERJ3GEYJ 101 V (100) T 105.4/91.3
R66 7030003320 S.RES ERJ3GEYJ 101 V (100) T 104.1/91.3
R67 7030003320 S.RES ERJ3GEYJ 101 V (100) T 102.8/91.3
R68 7030003320 S.RES ERJ3GEYJ 101 V (100) T 101.5/91.3
R69 7030003320 S.RES ERJ3GEYJ 101 V (100) T 100.2/91.3
R70 7030003320 S.RES ERJ3GEYJ 101 V (100) T 98.9/91.3
R71 7030003320 S.RES ERJ3GEYJ 101 V (100) T 97.6/91.3
R72 7030003320 S.RES ERJ3GEYJ 101 V (100) T 96.3/91.3
R73 7030003320 S.RES ERJ3GEYJ 101 V (100) T 95.0/91.3
R74 7030003860 S.RES ERJ3GE JPW V T 93.7/91.3
R75 7030003320 S.RES ERJ3GEYJ 101 V (100) B 108.8/96.3
R76 7030003320 S.RES ERJ3GEYJ 101 V (100) B 107.5/96.3
R77 7030003320 S.RES ERJ3GEYJ 101 V (100) B 106.2/96.3
R78 7030003320 S.RES ERJ3GEYJ 101 V (100) B 104.9/96.3
R79 7030003320 S.RES ERJ3GEYJ 101 V (100) B 103.6/96.3
R80 7030003320 S.RES ERJ3GEYJ 101 V (100) B 102.3/96.3
R81 7030003320 S.RES ERJ3GEYJ 101 V (100) B 101.0/96.3
R82 7030003320 S.RES ERJ3GEYJ 101 V (100) B 99.7/96.3
R83 7030003320 S.RES ERJ3GEYJ 101 V (100) B 98.4/96.3
R84 7030003320 S.RES ERJ3GEYJ 101 V (100) B 97.1/96.3
R85 7030003320 S.RES ERJ3GEYJ 101 V (100) B 95.8/96.3
R86 7030003860 S.RES ERJ3GE JPW V B 94.5/96.3
R87 7030003860 S.RES ERJ3GE JPW V B 93.2/96.3
R91 7030003860 S.RES ERJ3GE JPW V T 117.6/38.5
R201 7030003320 S.RES ERJ3GEYJ 101 V (100) B 48.1/36.6
R202 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 52.4/44.2
R203 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 65.5/35.7
R204 7030003360 S.RES ERJ3GEYJ 221 V (220) B 57.9/43.5
R205 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 56.6/43.5
R206 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 55.3/43.5
R207 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 64.7/33.2
R208 7030007220 S.RES ERA3YED 202V (2 k) T 51.8/20.8
R209 7030007220 S.RES ERA3YED 202V (2 k) T 51.8/23.4
R210 7030007220 S.RES ERA3YED 202V (2 k) T 53.1/23.4
R211 7030007230 S.RES ERA3YED 102V (1 k) T 53.1/20.8
R212 7030007220 S.RES ERA3YED 202V (2 k) T 54.4/23.4
R213 7030007230 S.RES ERA3YED 102V (1 k) T 54.4/20.8
R214 7030007220 S.RES ERA3YED 202V (2 k) T 55.7/23.4
R215 7030007230 S.RES ERA3YED 102V (1 k) T 55.7/20.8
R216 7030007220 S.RES ERA3YED 202V (2 k) T 57.0/23.4
R217 7030007230 S.RES ERA3YED 102V (1 k) T 57.0/20.8
R218 7030007220 S.RES ERA3YED 202V (2 k) T 58.3/23.4
R219 7030007230 S.RES ERA3YED 102V (1 k) T 58.3/20.8
R220 7030007220 S.RES ERA3YED 202V (2 k) T 59.6/23.4
R221 7030007230 S.RES ERA3YED 102V (1 k) T 59.6/20.8
R222 7030007200 S.RES ERA3YEB 202V (2 k) T 60.9/23.4
R223 7030007210 S.RES ERA3YEB 102V (1 k) T 60.9/20.8
R224 7030007200 S.RES ERA3YEB 202V (2 k) T 62.2/23.4
R225 7030007210 S.RES ERA3YEB 102V (1 k) T 62.2/20.8
R226 7030007200 S.RES ERA3YEB 202V (2 k) T 63.5/23.4
R227 7030007210 S.RES ERA3YEB 102V (1 k) T 63.5/20.8
R228 7030007200 S.RES ERA3YEB 202V (2 k) T 64.8/23.4
R229 7030007210 S.RES ERA3YEB 102V (1 k) T 64.8/20.8
R230 7030007200 S.RES ERA3YEB 202V (2 k) T 66.1/23.4
R231 7030007210 S.RES ERA3YEB 102V (1 k) T 66.1/20.8
R301 7030003370 S.RES ERJ3GEYJ 271 V (270) B 72.7/40.7
R302 7030003230 S.RES ERJ3GEYJ 180 V (18) B 74.0/40.7
R303 7030003370 S.RES ERJ3GEYJ 271 V (270) B 73.2/42.7
R1001 7030003320 S.RES ERJ3GEYJ 101 V (100) T 90.7/57.9
R1002 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 95.0/60.4
R1003 7030003320 S.RES ERJ3GEYJ 101 V (100) T 90.6/61.4
R1006 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 82.6/80.6
R1007 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 89.2/83.5
R1008 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 85.5/90.4
R1009 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 84.4/91.2
R1010 7030003860 S.RES ERJ3GE JPW V T 79.3/89.9
R1011 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 82.6/78.0
R1012 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 72.7/69.5
R1013 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 70.6/61.6
R1014 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 74.0/69.5
R1015 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 83.1/61.6
R1100 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 53.2/58.0
R1101 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 67.6/57.1
R1104 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 67.6/55.2
R1303 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 104.5/16.6
R1304 7030009591 S.RES ERA3YED 472V (4.7 k) B 103.4/13.3
R1305 7030009591 S.RES ERA3YED 472V (4.7 k) B 110.5/14.2
R1306 7030003320 S.RES ERJ3GEYJ 101 V (100) B 106.6/13.7
R1307 7030003320 S.RES ERJ3GEYJ 101 V (100) B 112.5/7.0
R1308 7030003860 S.RES ERJ3GE JPW V B 110.5/16.3
R1309 7030006601 S.RES ERA3YED 272V (2.7 k) B 96.5/24.2
R1310 7030006601 S.RES ERA3YED 272V (2.7 k) B 107.7/24.7
R1311 7030009591 S.RES ERA3YED 472V (4.7 k) B 117.3/25.3
R1312 7030009591 S.RES ERA3YED 472V (4.7 k) B 116.0/22.5
R1313 7030010390 S.RES ERA3YED 821V (820) B 96.5/26.9
R1314 7030010390 S.RES ERA3YED 821V (820) B 107.7/27.4
R1315 7030003320 S.RES ERJ3GEYJ 101 V (100) B 99.5/21.0
R1316 7030003320 S.RES ERJ3GEYJ 101 V (100) B 110.6/21.1
R1317 7030003320 S.RES ERJ3GEYJ 101 V (100) B 105.9/27.4
R1318 7030003320 S.RES ERJ3GEYJ 101 V (100) B 117.3/28.0
R1319 7030009691 S.RES ERA3YED 101V (100) B 96.5/29.6
R1320 7030009691 S.RES ERA3YED 101V (100) B 107.7/30.2
R1331 7030005871 S.RES ERA3YKD 104V (100 k) B 115.8/15.7
R1332 7030005871 S.RES ERA3YKD 104V (100 k) B 118.3/15.7
R1333 7030005321 S.RES ERA3YED 103V (10 k) B 121.0/19.7
R1334 7030009691 S.RES ERA3YED 101V (100) B 122.2/19.7
R1335 7030005631 S.RES ERA3YKD 154V (150 k) B 128.6/16.0
R1336 7030005681 S.RES ERA3YKD 473V (47 k) B 128.6/18.4
R1337 7030005871 S.RES ERA3YKD 104V (100 k) B 128.6/14.8
R1338 7030005871 S.RES ERA3YKD 104V (100 k) B 124.7/19.7
R1339 7030009691 S.RES ERA3YED 101V (100) B 123.5/19.7
R1340 7030003320 S.RES ERJ3GEYJ 101 V (100) B 128.6/13.6
R1341 7030003320 S.RES ERJ3GEYJ 101 V (100) B 116.9/18.6
R1351 7030003200 S.RES ERJ3GEYJ 100 V (10) B 94.5/42.3
R1352 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 96.1/46.6
R1353 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 96.1/47.9
R1354 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 98.3/53.1
R1355 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 96.1/40.2
R1356 7030003320 S.RES ERJ3GEYJ 101 V (100) B 96.1/45.3
R1359 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 112.0/45.7
R1360 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 110.6/45.8
R1361 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 110.6/48.4
(Amended page)
October 2016

10
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R1362 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 73.4/46.2
R1401 7030003320 S.RES ERJ3GEYJ 101 V (100) B 76.9/48.9
R1402 7030003860 S.RES ERJ3GE JPW V B 74.4/48.9
R1421 7030009591 S.RES ERA3YED 472V (4.7 k) B 78.9/42.4
R1422 7030009961 S.RES ERA3YED 221V (220) B 77.5/37.0
R1423 7030009591 S.RES ERA3YED 472V (4.7 k) B 77.5/42.4
R1424 7030009591 S.RES ERA3YED 472V (4.7 k) B 76.2/42.3
R1425 7030009961 S.RES ERA3YED 221V (220) B 76.2/37.0
R1426 7030009591 S.RES ERA3YED 472V (4.7 k) B 78.9/37.0
R1431 7030003320 S.RES ERJ3GEYJ 101 V (100) T 76.3/29.5
R1433 7030003320 S.RES ERJ3GEYJ 101 V (100) T 83.6/30.3
R1441 7030009691 S.RES ERA3YED 101V (100) B 79.0/26.6
R1451 7030005321 S.RES ERA3YED 103V (10 k) B 83.5/42.3
R1452 7030007661 S.RES ERA3YED 331V (330) B 82.2/38.3
R1453 7030005321 S.RES ERA3YED 103V (10 k) B 82.1/42.2
R1454 7030005341 S.RES ERA3YED 332V (3.3 k) B 80.9/40.0
R1455 7030007661 S.RES ERA3YED 331V (330) B 80.9/37.2
R1456 7030005341 S.RES ERA3YED 332V (3.3 k) B 83.6/38.3
R1457 7030006461 S.RES ERA3YED 152V (1.5 k) T 75.8/43.6
R1458 7030006521 S.RES ERA3YED 561V (560) T 75.8/41.0
R1471 7030009591 S.RES ERA3YED 472V (4.7 k) B 89.6/43.5
R1472 7030009961 S.RES ERA3YED 221V (220) B 91.1/37.8
R1473 7030009591 S.RES ERA3YED 472V (4.7 k) B 90.8/43.5
R1474 7030009591 S.RES ERA3YED 472V (4.7 k) B 92.2/42.3
R1475 7030009961 S.RES ERA3YED 221V (220) B 92.5/37.8
R1476 7030009591 S.RES ERA3YED 472V (4.7 k) B 89.8/37.8
R1477 7030009691 S.RES ERA3YED 101V (100) B 90.9/25.8
R1478 7030003320 S.RES ERJ3GEYJ 101 V (100) T 86.2/30.3
R1479 7030003320 S.RES ERJ3GEYJ 101 V (100) T 92.2/23.0
R1491 7030005321 S.RES ERA3YED 103V (10 k) B 87.8/42.3
R1492 7030009961 S.RES ERA3YED 221V (220) B 86.7/37.8
R1493 7030005321 S.RES ERA3YED 103V (10 k) B 86.5/42.3
R1494 7030008061 S.RES ERA3YED 222V (2.2 k) B 85.3/42.3
R1495 7030009961 S.RES ERA3YED 221V (220) B 85.5/37.8
R1496 7030008061 S.RES ERA3YED 222V (2.2 k) B 87.9/37.8
R1497 7030009691 S.RES ERA3YED 101V (100) B 88.3/25.8
R1601 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 68.4/97.9
R2001 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 124.9/98.1
R2102 7030003860 S.RES ERJ3GE JPW V T 98.7/63.3
R2201 7030003200 S.RES ERJ3GEYJ 100 V (10) T 120.1/38.8
R2202 7030003200 S.RES ERJ3GEYJ 100 V (10) T 124.3/41.1
R2203 7030010600 S.RES ERA3YHD 150V (15) B 119.4/44.5
R2204 7030006521 S.RES ERA3YED 561V (560) B 120.1/42.3
R2205 7030008061 S.RES ERA3YED 222V (2.2 k) T 118.3/40.5
R2206 7030005451 S.RES ERA3YED 153V (15 k) T 118.9/41.7
R2207 7030005321 S.RES ERA3YED 103V (10 k) T 118.9/42.9
R2301 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 112.6/55.1
R2302 7030003320 S.RES ERJ3GEYJ 101 V (100) T 118.6/53.0
R2303 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 113.5/58.3
R2304 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 117.1/60.6
R2305 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 113.5/57.0
R2306 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 117.1/59.3
R2307 7030003320 S.RES ERJ3GEYJ 101 V (100) B 125.3/55.7
R2401 7030003280 S.RES ERJ3GEYJ 470 V (47) T 125.1/61.5
R2402 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 123.5/69.4
R2403 7030003280 S.RES ERJ3GEYJ 470 V (47) T 122.5/61.5
R2404 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 127.8/61.5
R2405 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 118.1/69.9
R2406 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 105.0/70.5
R2408 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 115.7/69.4
R2409 7030003860 S.RES ERJ3GE JPW V T 122.7/88.9
R2410 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 115.3/62.8
R2411 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 129.0/88.9
R2412 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 129.4/90.2
R2413 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 134.5/84.1
R2414 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 126.6/81.8
R2415 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 126.6/77.9
R2416 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 105.7/83.3
R2417 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 105.7/86.9
R2418 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 126.5/74.0
R2419 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 133.2/73.7
R2420 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 134.5/65.0
R2421 7030003860 S.RES ERJ3GE JPW V T 131.1/61.5
R2422 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 128.8/37.0
R2451 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 129.8/58.1
R2452 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 134.5/58.6
R2453 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 129.8/54.7
R2454 7030003320 S.RES ERJ3GEYJ 101 V (100) T 134.5/55.4
R3097 7030007200 S.RES ERA3YEB 202V (2 k) T 25.9/46.5
R3098 7030007210 S.RES ERA3YEB 102V (1 k) T 25.9/49.2
R3099 7030007200 S.RES ERA3YEB 202V (2 k) T 27.2/46.5
R3100 7030007210 S.RES ERA3YEB 102V (1 k) T 27.2/49.2
R3101 7030007200 S.RES ERA3YEB 202V (2 k) T 28.5/46.5
R3102 7030007210 S.RES ERA3YEB 102V (1 k) T 28.5/49.2
R3103 7030007200 S.RES ERA3YEB 202V (2 k) T 29.8/46.5
R3104 7030007210 S.RES ERA3YEB 102V (1 k) T 29.8/49.2
R3105 7030007200 S.RES ERA3YEB 202V (2 k) T 31.1/46.5
R3106 7030007210 S.RES ERA3YEB 102V (1 k) T 31.1/49.2
R3107 7030007220 S.RES ERA3YED 202V (2 k) T 32.4/46.5
R3108 7030007230 S.RES ERA3YED 102V (1 k) T 32.4/49.2
R3109 7030007220 S.RES ERA3YED 202V (2 k) T 33.7/46.5
R3110 7030007230 S.RES ERA3YED 102V (1 k) T 33.7/49.2
R3111 7030007220 S.RES ERA3YED 202V (2 k) T 35.0/46.5
R3112 7030007230 S.RES ERA3YED 102V (1 k) T 35.0/49.2
R3113 7030007220 S.RES ERA3YED 202V (2 k) T 36.3/46.5
R3114 7030007230 S.RES ERA3YED 102V (1 k) T 36.3/49.2
R3115 7030007220 S.RES ERA3YED 202V (2 k) T 37.6/46.5
R3116 7030007230 S.RES ERA3YED 102V (1 k) T 37.6/49.2
R3117 7030007220 S.RES ERA3YED 202V (2 k) T 38.9/46.5
R3118 7030007230 S.RES ERA3YED 102V (1 k) T 38.9/49.2
R3119 7030007220 S.RES ERA3YED 202V (2 k) T 40.2/46.5
R3120 7030007220 S.RES ERA3YED 202V (2 k) T 40.2/49.2
R3121 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 25.7/34.3
R3131 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 39.9/33.5
R3132 7030003320 S.RES ERJ3GEYJ 101 V (100) B 44.4/32.1
R3141 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 25.0/36.2
R3142 7030003360 S.RES ERJ3GEYJ 221 V (220) B 37.9/27.3
R3143 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 39.4/26.5
R3144 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 36.4/26.5
R3151 7030003370 S.RES ERJ3GEYJ 271 V (270) B 19.8/46.6
R3152 7030003230 S.RES ERJ3GEYJ 180 V (18) B 17.8/45.8
R3153 7030003370 S.RES ERJ3GEYJ 271 V (270) B 19.8/45.2
R3201 7030003370 S.RES ERJ3GEYJ 271 V (270) T 9.2/17.5
R3202 7030003230 S.RES ERJ3GEYJ 180 V (18) T 11.1/18.2
R3203 7030003370 S.RES ERJ3GEYJ 271 V (270) T 9.2/19.0
R3221 7030003280 S.RES ERJ3GEYJ 470 V (47) B 13.1/34.5
R3222 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.4/40.1
R3227 7030003860 S.RES ERJ3GE JPW V T 19.8/54.1
R3228 7030003320 S.RES ERJ3GEYJ 101 V (100) T 17.6/58.8
R3229 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 19.8/56.9
R3231 7030003650 S.RES ERJ3GEYJ 563 V (56 k) T 21.1/48.6
R3232 7030003860 S.RES ERJ3GE JPW V T 16.4/46.7
R3233 7030003360 S.RES ERJ3GEYJ 221 V (220) T 20.5/51.2
R3251 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 44.9/79.1
R3252 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 44.9/82.5
R3253 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 44.9/80.5
R3254 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 44.9/75.9
R3255 7030003360 S.RES ERJ3GEYJ 221 V (220) B 20.0/90.0
R3256 7030003360 S.RES ERJ3GEYJ 221 V (220) B 21.3/90.0
R3257 7030003360 S.RES ERJ3GEYJ 221 V (220) B 22.6/90.0
R3258 7030003360 S.RES ERJ3GEYJ 221 V (220) B 23.9/90.0
R3259 7030003360 S.RES ERJ3GEYJ 221 V (220) B 25.2/90.0
R3260 7030003360 S.RES ERJ3GEYJ 221 V (220) B 26.5/90.0
R3261 7030003360 S.RES ERJ3GEYJ 221 V (220) B 27.8/90.0
R3262 7030003360 S.RES ERJ3GEYJ 221 V (220) B 29.1/90.0
R3263 7030003360 S.RES ERJ3GEYJ 221 V (220) B 30.4/90.0
R3264 7030003360 S.RES ERJ3GEYJ 221 V (220) B 31.7/90.0
R3265 7030003360 S.RES ERJ3GEYJ 221 V (220) B 33.0/90.0
R3271 7030003320 S.RES ERJ3GEYJ 101 V (100) B 15.0/66.3
R3272 7030003320 S.RES ERJ3GEYJ 101 V (100) B 11.1/66.3
R3281 7030003860 S.RES ERJ3GE JPW V B 25.2/75.2
R3282 7030003630 S.RES ERJ3GEYJ 393 V (39 k) B 24.5/72.5
R3283 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 17.1/75.9
R3284 7030003730 S.RES ERJ3GEYJ 274 V (270 k) B 19.5/71.8
R3285 7030003730 S.RES ERJ3GEYJ 274 V (270 k) B 17.9/73.9
R3291 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 5.7/75.3
R3292 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 7.0/75.3
R3293 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 7.7/73.1
R3294 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 7.7/71.8
R3295 7030003320 S.RES ERJ3GEYJ 101 V (100) B 9.6/75.3
R3301 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 5.7/67.0
R3302 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 7.0/67.0
R3303 7030003860 S.RES ERJ3GE JPW V B 7.7/69.2
R3304 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 7.7/70.5
R3305 7030003320 S.RES ERJ3GEYJ 101 V (100) B 9.6/67.0
R3311 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 20.7/65.9
R3312 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 19.1/67.0
R3313 7030003860 S.RES ERJ3GE JPW V B 18.6/69.2
R3314 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 19.5/70.5
R3315 7030003320 S.RES ERJ3GEYJ 101 V (100) B 16.5/67.0
R3321 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 84.2/20.4
R3322 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 92.5/20.4
R3323 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 76.9/20.3
R3330 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 54.6/48.9
R3331 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 58.5/48.9
R3332 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 55.7/44.6
R3333 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 33.6/21.2
C41 4510008540 S.ELE EEE1CA100SR T 116.9/14.1
C42 4030006860 S.CER C1608 JB 1H 102K-T B 99.5/9.5
C43 4510008540 S.ELE EEE1CA100SR T 109.9/14.2
C44 4030006860 S.CER C1608 JB 1H 102K-T B 102.8/8.7
C45 4510008540 S.ELE EEE1CA100SR T 105.1/14.2
C46 4030006860 S.CER C1608 JB 1H 102K-T B 101.1/9.0
C47 4510008540 S.ELE EEE1CA100SR T 100.2/15.5
C48 4030006860 S.CER C1608 JB 1H 102K-T B 97.0/11.1
C49 4510008540 S.ELE EEE1CA100SR T 95.4/15.5
C50 4030006860 S.CER C1608 JB 1H 102K-T B 94.2/11.1
C51 4510008540 S.ELE EEE1CA100SR T 90.4/13.4
C52 4030006860 S.CER C1608 JB 1H 102K-T B 89.8/12.3
C53 4030006860 S.CER C1608 JB 1H 102K-T B 84.4/10.8
C54 4030006860 S.CER C1608 JB 1H 102K-T B 89.8/10.7
C101 4510008540 S.ELE EEE1CA100SR T 76.0/12.8
C102 4030011600 S.CER C1608 JB 1E 104K-T B 77.7/8.6
C103 4030011600 S.CER C1608 JB 1E 104K-T B 73.8/6.4
C104 4510008540 S.ELE EEE1CA100SR T 71.2/12.8
C201 4030011600 S.CER C1608 JB 1E 104K-T T 59.7/47.4
C202 4030006880 S.CER C1608 JB 1H 472K-T B 51.6/41.7
C203 4510008540 S.ELE EEE1CA100SR T 63.7/48.4
C204 4030011600 S.CER C1608 JB 1E 104K-T T 66.3/45.3
C205 4030011600 S.CER C1608 JB 1E 104K-T T 50.8/43.8
C206 4030006880 S.CER C1608 JB 1H 472K-T T 66.3/44.1
C207 4030011600 S.CER C1608 JB 1E 104K-T T 50.8/41.3
C208 4030011600 S.CER C1608 JB 1E 104K-T T 49.4/37.0
C209 4030011600 S.CER C1608 JB 1E 104K-T T 49.4/34.4
C210 4030011600 S.CER C1608 JB 1E 104K-T T 49.8/29.2
C211 4030011600 S.CER C1608 JB 1E 104K-T B 53.0/28.9
C212 4030011600 S.CER C1608 JB 1E 104K-T B 55.8/28.9
C213 4030011600 S.CER C1608 JB 1E 104K-T B 61.4/28.0
C214 4030011600 S.CER C1608 JB 1E 104K-T T 66.9/26.3
C215 4030011600 S.CER C1608 JB 1E 104K-T B 64.8/28.7
C216 4030011600 S.CER C1608 JB 1E 104K-T B 67.5/32.4
C217 4030011600 S.CER C1608 JB 1E 104K-T B 67.5/34.1
C218 4030011600 S.CER C1608 JB 1E 104K-T B 65.4/37.9
C219 4030011600 S.CER C1608 JB 1E 104K-T T 67.2/42.0
C220 4030011600 S.CER C1608 JB 1E 104K-T T 64.1/44.4
C221 4030011600 S.CER C1608 JB 1E 104K-T T 61.4/44.2
(Amended page)
October 2016

11
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C222 4030011600 S.CER C1608 JB 1E 104K-T T 58.2/43.6
C301 4030007100 S.CER C1608 CH 1H 560J-T T 67.6/23.4
C302 4030007160 S.CER C1608 CH 1H 181J-T B 68.6/24.2
C303 4030007140 S.CER C1608 CH 1H 121J-T B 71.5/25.5
C304 4030011330 S.CER C1608 CH 1H 391J-T B 71.5/28.3
C305 4030007080 S.CER C1608 CH 1H 390J-T B 73.7/29.1
C306 4030011280 S.CER C1608 CH 1H 271J-T B 70.9/33.5
C307 4030010760 S.CER C1608 CH 1H 331J-T B 73.1/34.2
C308 4030018580 S.CER C1608 CH 1H 821J-T B 70.9/34.8
C309 4030010760 S.CER C1608 CH 1H 331J-T B 73.1/37.7
C1001 4030011600 S.CER C1608 JB 1E 104K-T T 92.8/57.6
C1002 4030007030 S.CER C1608 CH 1H 150J-T T 95.0/57.6
C1003 4510007130 S.ELE EEFCD 0J 470R B 76.3/95.0
C1004 4030007030 S.CER C1608 CH 1H 150J-T T 95.0/63.2
C1005 4510007130 S.ELE EEFCD 0J 470R B 71.5/95.0
C1006 4030011600 S.CER C1608 JB 1E 104K-T T 92.8/61.4
C1007 4030011600 S.CER C1608 JB 1E 104K-T B 90.9/69.3
C1008 4510008540 S.ELE EEE1CA100SR T 86.7/59.1
C1009 4030011600 S.CER C1608 JB 1E 104K-T T 63.1/86.9
C1010 4030011600 S.CER C1608 JB 1E 104K-T T 62.9/65.1
C1011 4030011600 S.CER C1608 JB 1E 104K-T T 65.2/89.0
C1012 4030011600 S.CER C1608 JB 1E 104K-T T 65.2/62.9
C1013 4030011600 S.CER C1608 JB 1E 104K-T T 69.7/81.4
C1014 4030011600 S.CER C1608 JB 1E 104K-T T 69.7/80.2
C1015 4030011600 S.CER C1608 JB 1E 104K-T T 69.6/76.1
C1016 4030011600 S.CER C1608 JB 1E 104K-T T 69.6/74.9
C1017 4030011600 S.CER C1608 JB 1E 104K-T T 69.6/71.4
C1018 4030011600 S.CER C1608 JB 1E 104K-T T 71.5/82.5
C1019 4030011600 S.CER C1608 JB 1E 104K-T T 70.8/68.7
C1020 4030011600 S.CER C1608 JB 1E 104K-T T 76.2/89.1
C1021 4030011600 S.CER C1608 JB 1E 104K-T T 76.1/82.5
C1022 4030011600 S.CER C1608 JB 1E 104K-T T 75.3/69.5
C1023 4030011600 S.CER C1608 JB 1E 104K-T T 77.3/82.5
C1024 4030011600 S.CER C1608 JB 1E 104K-T T 77.4/68.8
C1025 4030011600 S.CER C1608 JB 1E 104K-T T 76.7/62.9
C1026 4030011600 S.CER C1608 JB 1E 104K-T T 80.7/82.5
C1027 4030011600 S.CER C1608 JB 1E 104K-T T 82.2/69.5
C1028 4030011600 S.CER C1608 JB 1E 104K-T T 82.6/81.9
C1029 4030011600 S.CER C1608 JB 1E 104K-T T 82.6/79.3
C1030 4030011600 S.CER C1608 JB 1E 104K-T T 82.6/76.7
C1031 4030011600 S.CER C1608 JB 1E 104K-T T 82.6/72.6
C1032 4030011600 S.CER C1608 JB 1E 104K-T T 83.4/69.5
C1033 4030011600 S.CER C1608 JB 1E 104K-T T 86.3/89.1
C1034 4030011600 S.CER C1608 JB 1E 104K-T T 82.6/71.4
C1035 4030011600 S.CER C1608 JB 1E 104K-T T 85.8/62.9
C1036 4030011600 S.CER C1608 JB 1E 104K-T T 89.1/89.1
C1037 4030011600 S.CER C1608 JB 1E 104K-T T 88.4/62.9
C1038 4030011600 S.CER C1608 JB 1E 104K-T T 89.2/76.7
C1039 4030011600 S.CER C1608 JB 1E 104K-T T 89.2/74.1
C1040 4030011600 S.CER C1608 JB 1E 104K-T B 89.9/66.0
C1041 4030011600 S.CER C1608 JB 1E 104K-T T 63.1/84.3
C1042 4030011600 S.CER C1608 JB 1E 104K-T T 62.9/70.8
C1043 4030011600 S.CER C1608 JB 1E 104K-T T 62.9/77.3
C1044 4030011600 S.CER C1608 JB 1E 104K-T T 62.9/74.0
C1045 4030011600 S.CER C1608 JB 1E 104K-T T 62.9/67.8
C1046 4030011600 S.CER C1608 JB 1E 104K-T T 68.0/89.0
C1047 4030011600 S.CER C1608 JB 1E 104K-T T 63.1/81.7
C1048 4030011600 S.CER C1608 JB 1E 104K-T T 69.6/78.5
C1049 4030011600 S.CER C1608 JB 1E 104K-T T 69.7/82.6
C1050 4030011600 S.CER C1608 JB 1E 104K-T T 69.6/77.3
C1051 4030011600 S.CER C1608 JB 1E 104K-T T 69.6/72.6
C1052 4030011600 S.CER C1608 JB 1E 104K-T T 68.9/69.5
C1053 4030011600 S.CER C1608 JB 1E 104K-T T 67.8/62.9
C1054 4030011600 S.CER C1608 JB 1E 104K-T T 72.7/82.5
C1055 4030011600 S.CER C1608 JB 1E 104K-T T 70.6/62.9
C1056 4030011600 S.CER C1608 JB 1E 104K-T T 74.9/82.5
C1057 4030011600 S.CER C1608 JB 1E 104K-T T 79.5/62.9
C1058 4030011600 S.CER C1608 JB 1E 104K-T T 78.7/82.5
C1059 4030011600 S.CER C1608 JB 1E 104K-T T 81.0/69.5
C1060 4030011600 S.CER C1608 JB 1E 104K-T T 83.5/89.1
C1061 4030011600 S.CER C1608 JB 1E 104K-T T 82.6/83.2
C1062 4030011600 S.CER C1608 JB 1E 104K-T T 83.1/62.9
C1063 4030011600 S.CER C1608 JB 1E 104K-T T 83.4/74.8
C1064 4030011600 S.CER C1608 JB 1E 104K-T T 89.2/80.4
C1065 4030011600 S.CER C1608 JB 1E 104K-T T 89.2/71.5
C1066 4030011600 S.CER C1608 JB 1E 104K-T T 89.2/65.1
C1067 4030011600 S.CER C1608 JB 1E 104K-T T 89.2/86.1
C1068 4510008540 S.ELE EEE1CA100SR T 50.2/61.0
C1201 4030011600 S.CER C1608 JB 1E 104K-T T 53.0/64.1
C1302 4030011600 S.CER C1608 JB 1E 104K-T B 100.4/18.6
C1303 4030011600 S.CER C1608 JB 1E 104K-T B 101.7/14.7
C1305 4510008540 S.ELE EEE1CA100SR T 110.0/6.7
C1306 4030011600 S.CER C1608 JB 1E 104K-T B 105.9/11.7
C1307 4030007050 S.CER C1608 CH 1H 220J-T B 115.3/10.3
C1308 4510008540 S.ELE EEE1CA100SR T 115.1/6.9
C1309 4030011600 S.CER C1608 JB 1E 104K-T B 109.8/7.0
C1310 4550007090 S.TAN TEESVA 1A 226M8R B 97.1/20.1
Eqv. 4550008160 S.TAN F931A226MAA
C1311 4550007090 S.TAN TEESVA 1A 226M8R B 108.4/20.6
Eqv. 4550008160 S.TAN F931A226MAA
C1312 4510008540 S.ELE EEE1CA100SR T 120.0/22.5
C1313 4030011600 S.CER C1608 JB 1E 104K-T B 104.7/24.1
C1314 4030011600 S.CER C1608 JB 1E 104K-T B 116.0/25.2
C1315 4030011600 S.CER C1608 JB 1E 104K-T B 97.8/24.2
C1316 4030011600 S.CER C1608 JB 1E 104K-T B 109.0/24.7
C1317 4030017810 S.CER C1608 CH 1H 102J-T B 97.8/26.9
C1318 4510008540 S.ELE EEE1CA100SR T 105.0/22.5
C1319 4030017810 S.CER C1608 CH 1H 102J-T B 109.0/27.4
C1320 4510008540 S.ELE EEE1CA100SR T 113.5/22.5
C1321 4030007050 S.CER C1608 CH 1H 220J-T B 97.8/29.6
C1322 4030007050 S.CER C1608 CH 1H 220J-T B 109.0/30.2
C1323 4510008540 S.ELE EEE1CA100SR T 107.2/28.3
C1324 4510008540 S.ELE EEE1CA100SR T 125.5/30.6
C1325 4030011600 S.CER C1608 JB 1E 104K-T B 104.7/27.4
C1326 4030011600 S.CER C1608 JB 1E 104K-T B 116.0/27.9
C1331 4030017490 S.CER C1608 JB 1A 105K-T B 117.0/15.7
C1332 4030007090 S.CER C1608 CH 1H 470J-T B 121.6/17.8
C1333 4030017490 S.CER C1608 JB 1A 105K-T B 128.6/17.2
C1334 4030007090 S.CER C1608 CH 1H 470J-T B 124.3/17.8
C1335 4030011600 S.CER C1608 JB 1E 104K-T B 128.6/12.4
C1336 4510008540 S.ELE EEE1CA100SR T 127.0/14.0
C1337 4030011600 S.CER C1608 JB 1E 104K-T B 118.2/18.6
C1338 4510008540 S.ELE EEE1CA100SR T 122.0/14.0
C1339 4030011600 S.CER C1608 JB 1E 104K-T B 120.3/22.7
C1340 4030011600 S.CER C1608 JB 1E 104K-T B 123.5/26.0
C1351 4030018620 S.CER C1608 CH 1H 222J-T B 96.6/38.0
C1352 4550006050 S.TAN TEESVA 0J 106M8R T 93.0/40.5
Eqv. 4550007480 S.TAN F930J106MAABMA
C1353 4030011600 S.CER C1608 JB 1E 104K-T B 96.7/42.6
C1354 4550006050 S.TAN TEESVA 0J 106M8R T 98.5/34.0
Eqv. 4550007480 S.TAN F930J106MAABMA
C1355 4550006050 S.TAN TEESVA 0J 106M8R T 98.5/40.5
Eqv. 4550007480 S.TAN F930J106MAABMA
C1356 4030011810 S.CER C1608 JB 1A 224K-T B 101.9/31.8
C1357 4030011810 S.CER C1608 JB 1A 224K-T B 96.9/34.5
C1360 4030011810 S.CER C1608 JB 1A 224K-T B 105.4/31.8
C1361 4030018620 S.CER C1608 CH 1H 222J-T B 110.0/38.2
C1362 4030011810 S.CER C1608 JB 1A 224K-T B 110.1/34.7
C1363 4550006050 S.TAN TEESVA 0J 106M8R T 109.0/34.0
Eqv. 4550007480 S.TAN F930J106MAABMA
C1364 4550006050 S.TAN TEESVA 0J 106M8R T 104.0/34.0
Eqv. 4550007480 S.TAN F930J106MAABMA
C1365 4030011600 S.CER C1608 JB 1E 104K-T B 110.0/41.2
C1366 4550006250 S.TAN TEESVA 1A 106M8R T 108.5/40.5
Eqv. 4550007520 S.TAN F931A106MAABMA
C1367 4030011600 S.CER C1608 JB 1E 104K-T B 70.5/52.7
C1368 4030011600 S.CER C1608 JB 1E 104K-T B 71.5/48.3
C1369 4030006860 S.CER C1608 JB 1H 102K-T B 73.2/43.9
C1401 4510008540 S.ELE EEE1CA100SR T 86.6/51.8
C1402 4030011600 S.CER C1608 JB 1E 104K-T B 87.3/55.2
C1403 4030011600 S.CER C1608 JB 1E 104K-T B 77.4/45.8
C1404 4030011600 S.CER C1608 JB 1E 104K-T B 77.3/52.8
C1405 4510008540 S.ELE EEE1CA100SR T 78.5/46.4
C1421 4030018640 S.CER C2012 CH 1H 103J-T B 77.9/39.0
C1422 4030018610 S.CER C1608 CH 1H 182J-T B 78.2/35.1
C1423 4030018620 S.CER C1608 CH 1H 222J-T B 78.2/40.6
C1425 4030018610 S.CER C1608 CH 1H 182J-T B 76.2/34.4
C1427 4030011600 S.CER C1608 JB 1E 104K-T T 78.2/30.3
C1429 4510008540 S.ELE EEE1CA100SR T 76.5/34.1
C1433 4510008540 S.ELE EEE1CA100SR T 81.7/34.1
C1435 4030011600 S.CER C1608 JB 1E 104K-T T 80.9/30.3
C1451 4030018620 S.CER C1608 CH 1H 222J-T B 82.8/40.3
C1452 4030017870 S.CER C1608 CH 1H 681J-T B 82.9/36.3
C1453 4030011600 S.CER C1608 JB 1E 104K-T B 80.9/43.1
C1454 4510009050 S.ELE EEE0GA101SR T 79.5/40.5
C1455 4030017870 S.CER C1608 CH 1H 681J-T B 80.9/34.4
C1471 4030018640 S.CER C2012 CH 1H 103J-T B 90.7/40.1
C1472 4030018610 S.CER C1608 CH 1H 182J-T B 90.6/35.9
C1473 4030018620 S.CER C1608 CH 1H 222J-T B 90.3/41.7
C1475 4030018610 S.CER C1608 CH 1H 182J-T B 93.8/37.8
C1476 4030011600 S.CER C1608 JB 1E 104K-T T 90.0/32.7
C1477 4510008540 S.ELE EEE1CA100SR T 86.9/34.1
C1478 4030011600 S.CER C1608 JB 1E 104K-T B 93.1/26.5
C1479 4510008540 S.ELE EEE1CA100SR T 89.5/26.0
C1491 4030019130 S.CER C2012 CH 1H 562JT-NS B 86.7/40.1
C1492 4030018610 S.CER C1608 CH 1H 182J-T B 87.3/35.9
C1495 4030018610 S.CER C1608 CH 1H 182J-T B 85.5/35.1
C1603 4550007090 S.TAN TEESVA 1A 226M8R T 63.2/95.0
Eqv. 4550008160 S.TAN F931A226MAA
C1604 4030011600 S.CER C1608 JB 1E 104K-T B 61.4/95.1
C1605 4030017490 S.CER C1608 JB 1A 105K-T B 68.4/94.2
C1606 4550007320 S.TAN F930J226MAABMA T 66.6/95.0
C2001 4550007090 S.TAN TEESVA 1A 226M8R T 115.6/95.5
Eqv. 4550008160 S.TAN F931A226MAA
C2002 4030011600 S.CER C1608 JB 1E 104K-T B 117.9/95.8
C2003 4030017490 S.CER C1608 JB 1A 105K-T B 124.9/95.3
C2004 4550007320 S.TAN F930J226MAABMA B 126.6/95.3
C2051 4510008540 S.ELE EEE1CA100SR T 126.6/45.2
C2052 4030011600 S.CER C1608 JB 1E 104K-T T 126.9/41.1
C2053 4550006250 S.TAN TEESVA 1A 106M8R B 121.3/36.5
Eqv. 4550007520 S.TAN F931A106MAABMA
C2054 4030011600 S.CER C1608 JB 1E 104K-T B 125.5/34.5
C2101 4030011600 S.CER C1608 JB 1E 104K-T T 96.3/63.2
C2202 4030011600 S.CER C1608 JB 1E 104K-T T 126.9/39.6
C2203 4030018640 S.CER C2012 CH 1H 103J-T B 118.8/46.9
C2205 4030011600 S.CER C1608 JB 1E 104K-T T 118.9/44.2
C2206 4030011600 S.CER C1608 JB 1E 104K-T T 124.3/39.6
C2207 4550006250 S.TAN TEESVA 1A 106M8R T 123.5/36.4
Eqv. 4550007520 S.TAN F931A106MAABMA
C2208 4550006250 S.TAN TEESVA 1A 106M8R T 125.8/36.4
Eqv. 4550007520 S.TAN F931A106MAABMA
C2301 4510008580 S.ELE EEE0JA470SR T 121.4/49.4
C2302 4030017490 S.CER C1608 JB 1A 105K-T B 121.8/47.1
C2303 4510008540 S.ELE EEE1CA100SR T 116.1/56.1
C2304 4030011600 S.CER C1608 JB 1E 104K-T B 112.6/50.0
C2305 4030011600 S.CER C1608 JB 1E 104K-T T 113.0/56.9
C2306 4510008540 S.ELE EEE1CA100SR T 116.1/49.9
C2307 4510008540 S.ELE EEE1CA100SR T 120.9/56.1
C2308 4030011600 S.CER C1608 JB 1E 104K-T B 125.3/54.4
C2309 4030011600 S.CER C1608 JB 1E 104K-T B 119.9/60.0
C2351 4030011600 S.CER C1608 JB 1E 104K-T B 127.2/49.8
C2401 4030011600 S.CER C1608 JB 1E 104K-T B 125.8/59.4
C2402 4510008540 S.ELE EEE1CA100SR T 126.0/56.1
C2403 4030011600 S.CER C1608 JB 1E 104K-T T 133.2/83.5
C2404 4030011600 S.CER C1608 JB 1E 104K-T T 133.2/65.0
C2405 4030011600 S.CER C1608 JB 1E 104K-T T 133.2/70.9
C2406 4030011600 S.CER C1608 JB 1E 104K-T T 133.2/80.7
C2407 4030011600 S.CER C1608 JB 1E 104K-T T 126.6/75.3
(Amended page)
October 2016

12
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C2408 4030011600 S.CER C1608 JB 1E 104K-T T 126.7/62.8
C2409 4030011600 S.CER C1608 JB 1E 104K-T T 126.6/83.1
C2410 4030011600 S.CER C1608 JB 1E 104K-T T 126.2/88.9
C2411 4030011600 S.CER C1608 JB 1E 104K-T T 124.8/69.4
C2412 4030011600 S.CER C1608 JB 1E 104K-T T 122.8/82.3
C2413 4030011600 S.CER C1608 JB 1E 104K-T T 122.8/62.8
C2414 4030011600 S.CER C1608 JB 1E 104K-T T 118.8/82.3
C2415 4030011600 S.CER C1608 JB 1E 104K-T T 115.9/61.5
C2416 4030011600 S.CER C1608 JB 1E 104K-T T 117.0/82.3
C2417 4030011600 S.CER C1608 JB 1E 104K-T T 112.0/62.8
C2418 4030011600 S.CER C1608 JB 1E 104K-T T 113.1/69.4
C2419 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/72.7
C2420 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/77.4
C2421 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/82.9
C2422 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/79.0
C2423 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/80.2
C2424 4030011600 S.CER C1608 JB 1E 104K-T T 112.3/88.9
C2425 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/67.7
C2426 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/74.8
C2427 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/77.5
C2428 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/70.5
C2429 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/83.4
C2430 4030011600 S.CER C1608 JB 1E 104K-T T 134.5/72.8
C2431 4030011600 S.CER C1608 JB 1E 104K-T B 133.9/76.0
C2432 4030011600 S.CER C1608 JB 1E 104K-T T 134.5/76.4
C2433 4030011600 S.CER C1608 JB 1E 104K-T T 133.1/62.8
C2434 4030011600 S.CER C1608 JB 1E 104K-T T 133.2/86.7
C2435 4030011600 S.CER C1608 JB 1E 104K-T T 130.1/62.8
C2436 4030011600 S.CER C1608 JB 1E 104K-T T 126.6/72.7
C2437 4030011600 S.CER C1608 JB 1E 104K-T T 131.8/88.9
C2438 4030011600 S.CER C1608 JB 1E 104K-T T 127.4/69.4
C2439 4030011600 S.CER C1608 JB 1E 104K-T T 126.6/71.4
C2440 4030011600 S.CER C1608 JB 1E 104K-T T 126.6/76.6
C2441 4030011600 S.CER C1608 JB 1E 104K-T T 126.6/79.2
C2442 4030011600 S.CER C1608 JB 1E 104K-T T 126.6/80.5
C2443 4030011600 S.CER C1608 JB 1E 104K-T T 126.1/69.4
C2444 4030011600 S.CER C1608 JB 1E 104K-T T 124.6/82.3
C2445 4030011600 S.CER C1608 JB 1E 104K-T T 120.1/62.8
C2446 4030011600 S.CER C1608 JB 1E 104K-T T 121.5/68.6
C2447 4030011600 S.CER C1608 JB 1E 104K-T T 121.4/82.3
C2448 4030011600 S.CER C1608 JB 1E 104K-T T 118.9/68.6
C2449 4030011600 S.CER C1608 JB 1E 104K-T T 120.1/82.3
C2450 4030011600 S.CER C1608 JB 1E 104K-T T 119.9/88.9
C2451 4030011600 S.CER C1608 JB 1E 104K-T T 114.4/69.4
C2452 4030011600 S.CER C1608 JB 1E 104K-T T 115.7/82.3
C2453 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/71.4
C2454 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/74.8
C2455 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/76.1
C2456 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/80.3
C2457 4030011600 S.CER C1608 JB 1E 104K-T T 133.2/68.1
C2458 4030011600 S.CER C1608 JB 1E 104K-T T 113.7/81.6
C2459 4030011600 S.CER C1608 JB 1E 104K-T T 109.2/62.8
C2460 4030011600 S.CER C1608 JB 1E 104K-T T 109.5/88.9
C2461 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/64.9
C2462 4030011600 S.CER C1608 JB 1E 104K-T T 107.0/86.8
C2463 4030011600 S.CER C1608 JB 1E 104K-T T 132.1/57.7
C2464 4030011600 S.CER C1608 JB 1E 104K-T T 132.2/53.5
C2465 4030006900 S.CER C1608 JB 1H 103K-T T 134.5/52.5
C2481 4550007310 S.TAN F930J227MNMBMA B 108.0/57.5
C2482 4550007310 S.TAN F930J227MNMBMA B 103.2/57.5
C2483 4550006960 S.TAN TEESVB2 0G 107M8R T 119.6/94.3
Eqv. 4550007460 S.TAN F930G107MBABMA
C3101 4510008540 S.ELE EEE1CA100SR T 28.1/21.7
C3102 4030011600 S.CER C1608 JB 1E 104K-T T 25.7/26.0
C3103 4030006880 S.CER C1608 JB 1H 472K-T T 25.7/24.7
C3104 4030011600 S.CER C1608 JB 1E 104K-T T 42.3/29.8
C3105 4030011600 S.CER C1608 JB 1E 104K-T T 42.3/33.3
C3106 4030011600 S.CER C1608 JB 1E 104K-T T 42.3/35.9
C3107 4030011600 S.CER C1608 JB 1E 104K-T T 42.3/40.8
C3108 4030011600 S.CER C1608 JB 1E 104K-T T 40.2/43.6
C3109 4030011600 S.CER C1608 JB 1E 104K-T B 36.8/42.9
C3110 4030011600 S.CER C1608 JB 1E 104K-T B 29.8/42.9
C3111 4030011600 S.CER C1608 JB 1E 104K-T T 24.9/44.0
C3112 4030011600 S.CER C1608 JB 1E 104K-T B 27.5/41.3
C3113 4030011600 S.CER C1608 JB 1E 104K-T B 25.8/38.3
C3114 4030011600 S.CER C1608 JB 1E 104K-T B 27.6/36.3
C3115 4030011600 S.CER C1608 JB 1E 104K-T B 27.4/32.8
C3116 4030011600 S.CER C1608 JB 1E 104K-T T 24.9/27.9
C3117 4030011600 S.CER C1608 JB 1E 104K-T T 28.0/25.6
C3118 4030011600 S.CER C1608 JB 1E 104K-T T 30.0/25.5
C3119 4030011600 S.CER C1608 JB 1E 104K-T T 34.0/26.3
C3131 4030011600 S.CER C1608 JB 1E 104K-T T 40.7/26.6
C3132 4030006880 S.CER C1608 JB 1H 472K-T B 41.4/32.1
C3141 4030011600 S.CER C1608 JB 1E 104K-T T 32.4/22.6
C3151 4030006900 S.CER C1608 JB 1H 103K-T T 24.6/47.3
C3153 4030007080 S.CER C1608 CH 1H 390J-T B 23.6/47.0
C3154 4030010760 S.CER C1608 CH 1H 331J-T B 19.8/47.9
C3155 4030007090 S.CER C1608 CH 1H 470J-T B 17.8/43.2
C3156 4030007060 S.CER C1608 CH 1H 270J-T B 19.1/43.2
C3157 4030011770 S.CER C1608 CH 1H 060B-T B 18.5/41.2
C3158 4030007120 S.CER C1608 CH 1H 820J-T B 18.5/39.9
C3159 4030007040 S.CER C1608 CH 1H 180J-T B 17.8/37.3
C3160 4030007120 S.CER C1608 CH 1H 820J-T B 19.9/30.5
C3161 4030011770 S.CER C1608 CH 1H 060B-T B 19.9/31.8
C3162 4030007090 S.CER C1608 CH 1H 470J-T B 17.0/34.9
C3163 4030007060 S.CER C1608 CH 1H 270J-T B 17.0/33.6
C3201 4030007110 S.CER C1608 CH 1H 680J-T T 8.4/25.6
C3202 4030007080 S.CER C1608 CH 1H 390J-T T 7.2/25.6
C3221 4550006250 S.TAN TEESVA 1A 106M8R T 19.6/39.3
Eqv. 4550007520 S.TAN F931A106MAABMA
C3222 4030007110 S.CER C1608 CH 1H 680J-T T 12.1/32.8
C3223 4030007000 S.CER C1608 CH 1H 090D-T T 9.1/37.0
C3224 4030006860 S.CER C1608 JB 1H 102K-T T 7.0/36.5
C3225 4030006900 S.CER C1608 JB 1H 103K-T B 13.8/36.5
C3226 4030006900 S.CER C1608 JB 1H 103K-T B 9.2/44.4
C3227 4030006900 S.CER C1608 JB 1H 103K-T B 12.2/50.3
C3228 4030011600 S.CER C1608 JB 1E 104K-T T 11.9/37.6
C3229 4030011600 S.CER C1608 JB 1E 104K-T T 12.3/44.5
C3230 4030006900 S.CER C1608 JB 1H 103K-T T 5.5/40.6
C3231 4030011600 S.CER C1608 JB 1E 104K-T T 17.6/57.5
C3232 4030006900 S.CER C1608 JB 1H 103K-T T 21.1/56.9
C3233 4030007170 S.CER C1608 CH 1H 221J-T T 18.8/46.0
C3234 4030011600 S.CER C1608 JB 1E 104K-T T 16.4/49.5
C3251 4030011600 S.CER C1608 JB 1E 104K-T T 40.0/93.1
C3252 4030007090 S.CER C1608 CH 1H 470J-T B 22.3/47.0
C3255 4030007170 S.CER C1608 CH 1H 221J-T B 20.0/86.7
C3256 4030007170 S.CER C1608 CH 1H 221J-T B 21.3/86.7
C3257 4030007170 S.CER C1608 CH 1H 221J-T B 22.6/86.7
C3258 4030007170 S.CER C1608 CH 1H 221J-T B 23.9/86.7
C3259 4030007170 S.CER C1608 CH 1H 221J-T B 25.2/86.7
C3260 4030007170 S.CER C1608 CH 1H 221J-T B 26.5/86.7
C3261 4030007170 S.CER C1608 CH 1H 221J-T B 27.8/86.7
C3262 4030007170 S.CER C1608 CH 1H 221J-T B 29.1/86.7
C3263 4030007170 S.CER C1608 CH 1H 221J-T B 30.4/86.7
C3264 4030007170 S.CER C1608 CH 1H 221J-T B 31.7/86.7
C3265 4030007170 S.CER C1608 CH 1H 221J-T B 33.0/86.7
C3271 4030011600 S.CER C1608 JB 1E 104K-T B 13.7/66.3
C3272 4510008540 S.ELE EEE1CA100SR T 13.3/60.6
C3273 4030011600 S.CER C1608 JB 1E 104K-T B 12.4/66.3
C3274 4510008540 S.ELE EEE1CA100SR T 8.5/60.6
C3281 4030018640 S.CER C2012 CH 1H 103J-T B 22.9/74.2
C3282 4030018640 S.CER C2012 CH 1H 103J-T B 21.2/74.2
C3283 4030018640 S.CER C2012 CH 1H 103J-T B 19.4/74.2
C3291 4030018620 S.CER C1608 CH 1H 222J-T B 4.4/75.3
C3293 4030007110 S.CER C1608 CH 1H 680J-T B 8.3/75.3
C3303 4030007130 S.CER C1608 CH 1H 101J-T B 8.3/67.0
C3313 4030017810 S.CER C1608 CH 1H 102J-T B 17.8/67.0
C3321 4030011600 S.CER C1608 JB 1E 104K-T B 86.1/17.8
C3322 4030011600 S.CER C1608 JB 1E 104K-T B 83.2/14.1
C3323 4030011600 S.CER C1608 JB 1E 104K-T B 94.4/17.8
C3324 4030011600 S.CER C1608 JB 1E 104K-T B 91.5/14.2
C3325 4030011600 S.CER C1608 JB 1E 104K-T B 78.8/17.8
C3326 4030011600 S.CER C1608 JB 1E 104K-T B 76.7/13.6
J1 6510028210 CON SJ050010
J21 6510018961 S.CON B2B-PH-SM4-TB T 99.4/26.4
J41 6510019981 S.CON 52808-1671 T 95.0/5.0
J61 6510021722 S.CON 30FLT-SM2-TB T 101.2/95.8
J91 6510018961 S.CON B2B-PH-SM4-TB T 117.7/31.0
J1101 6510019971 S.CON 52808-1071 T 58.7/55.3
J2401 6510019971 S.CON 52808-1071 T 133.9/40.8
J3201 6510028210 CON SJ050010
J3251 6510025960 S.CON AXN330C238P T 38.7/77.5
J3252 6510021722 S.CON 30FLT-SM2-TB T 24.7/95.4
EP41 6910015970 S.BEA MMZ1608B 301CT-AS T 99.7/9.2
EP42 6910014730 S.BEA MPZ2012S331A-T T 104.4/9.4
EP43 6910015970 S.BEA MMZ1608B 301CT-AS T 101.1/9.1
EP44 6910014730 S.BEA MPZ2012S331A-T T 97.1/10.3
EP45 6910014730 S.BEA MPZ2012S331A-T T 94.9/10.3
EP46 6910015970 S.BEA MMZ1608B 301CT-AS T 92.1/9.7
EP1001 6910014730 S.BEA MPZ2012S331A-T T 54.9/61.0
EP1351 6910014730 S.BEA MPZ2012S331A-T T 94.3/51.4
EP3251 6910015970 S.BEA MMZ1608B 301CT-AS T 44.9/72.7
(Amended page)
October 2016

(Amended page)
13
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[BPF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[BPF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
IC151 1130011530 S.IC CD74HC4094M96 T 7.9/42.3
IC152 1130011530 S.IC CD74HC4094M96 T 7.9/53.0
IC154 1160000132 S.IC TD62783AFG (OSEL) B 18.9/6.8
IC155 1160000132 S.IC TD62783AFG (OSEL) B 8.5/68.2
IC301 1180002770 S.REG BAJ0CC0FP-E2 T 8.5/88.2
Q180 1590003940 S.TRA RN1105 (TE85LF) T 12.7/81.7
Q181 1530002060 S.TRA 2SC4081 T106 R T 81.9/115.8
Q182 1590004310 S.TRA LDTA114EET1G T 85.3/112.9
Q183 1530002841 S.TRA 2SC4116-Y (TE85RF) T 85.1/115.8
D181 1750002020 S.DIO DA2S10100L B 83.7/108.4
D182 1790000981 S.DIO MA3J7420GL T 91.3/115.8
D201 1750002020 S.DIO DA2S10100L B 69.8/108.3
D202 1750002020 S.DIO DA2S10100L B 55.0/106.4
L1 6200005521 S.COI NLV25T-470J-PF T 23.0/62.5
L2 6140004090 COI LR-447
L3 6140004230 COI LR-458
L4 6140004230 COI LR-458
L5 6140004230 COI LR-458
L6 6140004090 COI LR-447
L21 6200005521 S.COI NLV25T-470J-PF T 6.9/10.9
L22 6140004090 COI LR-447
L23 6140004100 COI LR-448
L24 6140004100 COI LR-448
L25 6140004100 COI LR-448
L26 6140004090 COI LR-447
L42 6140004110 COI LR-449
L43 6140004120 COI LR-450
L44 6140004120 COI LR-450
L45 6140004120 COI LR-450
L46 6140004110 COI LR-449
L62 6140004140 COI LR-451
L63 6140004150 COI LR-452
L64 6140004150 COI LR-452
L65 6140004150 COI LR-452
L66 6140004140 COI LR-451
L81 6200007021 S.COI NLV25T-270J-PF B 80.3/88.8
L82 6140004160 COI LR-453
L83 6140004180 COI LR-454
L84 6140004180 COI LR-454
L85 6140004180 COI LR-454
L86 6140004160 COI LR-453
L101 6200005011 S.COI NLV25T-100J-PF B 86.8/88.8
L102 6140004190 COI LR-455
L103 6140004210 COI LR-456
L104 6140004210 COI LR-456
L105 6140004210 COI LR-456
L106 6140004190 COI LR-455
L121 6200009141 S.COI NLV25T-6R8J-PF B 93.2/88.8
L122 6140004220 COI LR-457
L123 6140004160 COI LR-453
L124 6140004160 COI LR-453
L125 6140004160 COI LR-453
L126 6140004220 COI LR-457
L141 6200009141 S.COI NLV25T-6R8J-PF B 99.5/88.8
L142 6200008080 S.COI LQW2BHNR22J03L B 113.9/71.6
L143 6200010870 S.COI C2520C-R33G-A (0.33U) T 113.8/72.7
L144 6200008080 S.COI LQW2BHNR22J03L B 113.9/87.3
L181 6200005521 S.COI NLV25T-470J-PF B 10.5/82.5
L201 6140002070 COI LR-233
L211 6200007780 S.COI LQW2BHNR12J03L T 57.4/112.6
L221 6200005521 S.COI NLV25T-470J-PF B 34.9/88.8
L222 6180004150 COI AL04 TB 150J
L223 6180004150 COI AL04 TB 150J
L241 6200005521 S.COI NLV25T-470J-PF B 28.5/88.8
L242 6140003980 COI LR-476
L243 6140003980 COI LR-476
L244 6140003980 COI LR-476
L245 6140003980 COI LR-476
L246 6140003980 COI LR-476
L247 6140003980 COI LR-476
L248 6140003980 COI LR-476
L261 6200005521 S.COI NLV25T-470J-PF B 41.3/88.8
L262 6140004040 COI LR-443
L263 6140004050 COI LR-444
L264 6140004050 COI LR-444
L265 6140004050 COI LR-444
L266 6140004040 COI LR-443
L281 6200005521 S.COI NLV25T-470J-PF B 47.8/88.8
L282 6140004060 COI LR-445
L283 6140004080 COI LR-446
L284 6140004080 COI LR-446
L285 6140004080 COI LR-446
L286 6140004060 COI LR-445
R151 7030003240 S.RES ERJ3GEYJ 220 V (22) T 28.3/10.0
R152 7030003240 S.RES ERJ3GEYJ 220 V (22) T 23.4/10.8
R153 7030003240 S.RES ERJ3GEYJ 220 V (22) T 23.4/9.2
R154 7030003240 S.RES ERJ3GEYJ 220 V (22) T 28.3/8.4
R155 7030003240 S.RES ERJ3GEYJ 220 V (22) T 23.4/7.6
R156 7030003240 S.RES ERJ3GEYJ 220 V (22) T 28.3/6.8
R157 7030003240 S.RES ERJ3GEYJ 220 V (22) T 23.4/6.0
R158 7030003240 S.RES ERJ3GEYJ 220 V (22) T 28.3/5.2
R159 7030003240 S.RES ERJ3GEYJ 220 V (22) T 12.8/60.3
R160 7030003240 S.RES ERJ3GEYJ 220 V (22) T 14.1/60.3
R161 7030003240 S.RES ERJ3GEYJ 220 V (22) T 14.9/63.9
R162 7030003240 S.RES ERJ3GEYJ 220 V (22) T 16.3/63.9
R163 7030003240 S.RES ERJ3GEYJ 220 V (22) T 12.7/77.6
R164 7030003240 S.RES ERJ3GEYJ 220 V (22) T 15.7/77.6
R165 7030003240 S.RES ERJ3GEYJ 220 V (22) T 14.2/77.6
R166 7030003240 S.RES ERJ3GEYJ 220 V (22) T 11.2/77.6
R167 7030003320 S.RES ERJ3GEYJ 101 V (100) T 7.4/64.4
R168 7030003320 S.RES ERJ3GEYJ 101 V (100) T 12.2/64.4
R182 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 82.5/113.7
R183 7030003320 S.RES ERJ3GEYJ 101 V (100) T 88.2/112.7
R184 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 88.2/113.9
R185 7030003860 S.RES ERJ3GE JPW V T 88.2/115.1
R186 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 88.2/116.3
R201 7030011700 S.RES ERJ1TYJ681U (680) T 104.4/97.0
R202 7030010420 S.RES ERJ1TYJ 560U (56) B 109.0/103.8
R203 7030010970 S.RES ERJ1TYJ 151U B 120.2/94.7
R204 7030010440 S.RES ERJ1TYJ 680U (68) B 120.2/103.3
R205 7030010610 S.RES ERJ1TYJ 470U (47) B 102.6/115.9
R206 7030010520 S.RES ERJ1TYJ 101U (100) B 111.2/115.9
R207 7540000260 ABS SA05C 201M
R208 7540000260 ABS SA05C 201M
R209 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 48.0/109.7
R221 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 29.2/32.6
R222 7030003860 S.RES ERJ3GE JPW V T 26.6/33.4
R301 7030003360 S.RES ERJ3GEYJ 221 V (220) T 9.4/32.5
R302 7030003360 S.RES ERJ3GEYJ 221 V (220) T 9.4/31.3
R303 7030003360 S.RES ERJ3GEYJ 221 V (220) T 9.4/30.1
R304 7030003360 S.RES ERJ3GEYJ 221 V (220) T 9.4/28.9
R305 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 13.3/31.3
R306 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 13.3/32.5
R307 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 13.3/30.1
R308 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 13.3/28.9
R309 7030003360 S.RES ERJ3GEYJ 221 V (220) T 9.4/27.7
R310 7030003360 S.RES ERJ3GEYJ 221 V (220) T 9.4/26.5
C1 4030006880 S.CER C1608 JB 1H 472K-T B 59.5/15.0
C2 4030017800 S.CER C1608 CH 1H 561J-T B 57.4/29.5
C3 4030011330 S.CER C1608 CH 1H 391J-T B 57.4/31.2
C4 4030007160 S.CER C1608 CH 1H 181J-T B 54.1/39.8
C5 4030007070 S.CER C1608 CH 1H 330J-T B 54.1/41.6
C6 4030007030 S.CER C1608 CH 1H 150J-T B 51.7/45.5
C7 4030007120 S.CER C1608 CH 1H 820J-T B 53.5/45.5
C8 4030007140 S.CER C1608 CH 1H 121J-T B 54.1/53.0
C9 4030007100 S.CER C1608 CH 1H 560J-T B 54.1/54.9
C10 4030007120 S.CER C1608 CH 1H 820J-T B 53.4/57.3
C11 4030007030 S.CER C1608 CH 1H 150J-T B 51.7/57.3
C12 4030007160 S.CER C1608 CH 1H 181J-T B 54.1/60.0
C13 4030007070 S.CER C1608 CH 1H 330J-T B 54.1/61.9
C14 4030017800 S.CER C1608 CH 1H 561J-T B 57.1/84.1
C15 4030011330 S.CER C1608 CH 1H 391J-T B 57.1/85.5
C16 4030006880 S.CER C1608 JB 1H 472K-T B 54.3/91.2
C21 4030006880 S.CER C1608 JB 1H 472K-T B 65.9/15.0
C22 4030010760 S.CER C1608 CH 1H 331J-T B 67.2/29.5
C23 4030007150 S.CER C1608 CH 1H 151J-T B 67.2/31.2
C24 4030007150 S.CER C1608 CH 1H 151J-T B 63.8/39.8
C25 4030007060 S.CER C1608 CH 1H 270J-T B 63.8/41.6
C26 4030007060 S.CER C1608 CH 1H 270J-T B 63.2/45.5
C27 4030007140 S.CER C1608 CH 1H 121J-T B 61.5/45.5
C28 4030007150 S.CER C1608 CH 1H 151J-T B 63.9/53.0
C29 4030007010 S.CER C1608 CH 1H 100D-T B 63.9/54.9
C30 4030007140 S.CER C1608 CH 1H 121J-T B 63.2/57.4
C31 4030007060 S.CER C1608 CH 1H 270J-T B 61.5/57.4
C32 4030007150 S.CER C1608 CH 1H 151J-T B 63.9/60.0
C33 4030007060 S.CER C1608 CH 1H 270J-T B 63.9/61.9
C34 4030010760 S.CER C1608 CH 1H 331J-T B 66.7/83.7
C35 4030007150 S.CER C1608 CH 1H 151J-T B 65.7/84.7
C36 4030006880 S.CER C1608 JB 1H 472K-T B 60.8/91.2
C41 4030006880 S.CER C1608 JB 1H 472K-T B 72.2/15.0
C42 4030007170 S.CER C1608 CH 1H 221J-T B 76.8/29.5
C43 4030007170 S.CER C1608 CH 1H 221J-T B 76.8/31.2
C44 4030007130 S.CER C1608 CH 1H 101J-T B 73.6/39.8
C45 4030007050 S.CER C1608 CH 1H 220J-T B 73.6/41.6
C46 4030007070 S.CER C1608 CH 1H 330J-T B 72.9/45.5
C47 4030007080 S.CER C1608 CH 1H 390J-T B 71.1/45.5
C48 4030007120 S.CER C1608 CH 1H 820J-T B 73.5/53.0
C49 4030007050 S.CER C1608 CH 1H 220J-T B 73.5/54.9
C50 4030007080 S.CER C1608 CH 1H 390J-T B 72.8/57.5
C51 4030007070 S.CER C1608 CH 1H 330J-T B 71.1/57.5
C52 4030007130 S.CER C1608 CH 1H 101J-T B 73.5/60.0
C53 4030007050 S.CER C1608 CH 1H 220J-T B 73.5/61.9
C54 4030007170 S.CER C1608 CH 1H 221J-T B 76.4/83.7
C55 4030007170 S.CER C1608 CH 1H 221J-T B 75.4/84.7
C56 4030006880 S.CER C1608 JB 1H 472K-T B 67.3/91.2
C61 4030006880 S.CER C1608 JB 1H 472K-T B 78.6/15.0
C62 4030007170 S.CER C1608 CH 1H 221J-T B 86.6/29.5
C63 4030007110 S.CER C1608 CH 1H 680J-T B 86.6/31.2
C64 4030007090 S.CER C1608 CH 1H 470J-T B 83.4/39.8
C65 4030007090 S.CER C1608 CH 1H 470J-T B 83.4/41.6
C66 4030007070 S.CER C1608 CH 1H 330J-T B 82.7/45.5
C67 4030007070 S.CER C1608 CH 1H 330J-T B 80.9/45.5
C68 4030007120 S.CER C1608 CH 1H 820J-T B 83.3/54.9
C69 4030007070 S.CER C1608 CH 1H 330J-T B 80.9/57.5
C70 4030007070 S.CER C1608 CH 1H 330J-T B 82.6/57.5
C71 4030007090 S.CER C1608 CH 1H 470J-T B 83.3/60.0
C72 4030007090 S.CER C1608 CH 1H 470J-T B 83.3/61.9
C73 4030007170 S.CER C1608 CH 1H 221J-T B 86.2/75.5
C74 4030007110 S.CER C1608 CH 1H 680J-T B 86.2/77.1
C75 4030006880 S.CER C1608 JB 1H 472K-T B 73.9/91.2
C81 4030006880 S.CER C1608 JB 1H 472K-T B 85.1/15.0
C82 4030007160 S.CER C1608 CH 1H 181J-T B 96.3/29.5
C83 4030007090 S.CER C1608 CH 1H 470J-T B 96.3/31.2
C84 4030007090 S.CER C1608 CH 1H 470J-T B 92.9/39.8
C85 4030007040 S.CER C1608 CH 1H 180J-T B 92.9/41.6
C86 4030007030 S.CER C1608 CH 1H 150J-T B 92.3/45.5
C87 4030007050 S.CER C1608 CH 1H 220J-T B 90.5/45.5
C88 4030007090 S.CER C1608 CH 1H 470J-T B 93.0/54.9
October 2016

14
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[BPF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[BPF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
C89 4030006990 S.CER C1608 CH 1H 080D-T B 93.0/53.0
C90 4030007050 S.CER C1608 CH 1H 220J-T B 92.3/57.4
C91 4030007030 S.CER C1608 CH 1H 150J-T B 90.6/57.4
C92 4030007090 S.CER C1608 CH 1H 470J-T B 93.0/60.0
C93 4030007040 S.CER C1608 CH 1H 180J-T B 93.0/61.9
C94 4030007160 S.CER C1608 CH 1H 181J-T B 95.9/75.5
C95 4030007090 S.CER C1608 CH 1H 470J-T B 95.9/77.1
C96 4030006880 S.CER C1608 JB 1H 472K-T B 80.3/91.2
C101 4030006880 S.CER C1608 JB 1H 472K-T B 91.5/15.0
C102 4030007140 S.CER C1608 CH 1H 121J-T B 105.7/31.2
C103 4030007040 S.CER C1608 CH 1H 180J-T B 105.7/29.5
C104 4030007070 S.CER C1608 CH 1H 330J-T B 102.7/39.8
C105 4030007040 S.CER C1608 CH 1H 180J-T B 102.7/41.6
C106 4030007010 S.CER C1608 CH 1H 100D-T B 102.1/45.5
C107 4030007070 S.CER C1608 CH 1H 330J-T B 100.3/45.5
C108 4030007090 S.CER C1608 CH 1H 470J-T B 102.8/53.0
C109 4030007070 S.CER C1608 CH 1H 330J-T B 102.1/56.3
C110 4030007010 S.CER C1608 CH 1H 100D-T B 100.3/56.3
C111 4030007070 S.CER C1608 CH 1H 330J-T B 102.8/59.5
C112 4030007040 S.CER C1608 CH 1H 180J-T B 102.8/61.5
C113 4030007140 S.CER C1608 CH 1H 121J-T B 105.9/77.1
C114 4030007040 S.CER C1608 CH 1H 180J-T B 105.9/75.6
C115 4030006880 S.CER C1608 JB 1H 472K-T B 86.8/91.2
C121 4030006880 S.CER C1608 JB 1H 472K-T B 98.1/15.0
C122 4030007130 S.CER C1608 CH 1H 101J-T B 112.7/24.0
C123 4030007030 S.CER C1608 CH 1H 150J-T B 112.7/25.7
C124 4030007050 S.CER C1608 CH 1H 220J-T B 113.4/34.2
C125 4030007020 S.CER C1608 CH 1H 120J-T B 113.4/36.0
C126 4030007050 S.CER C1608 CH 1H 220J-T B 115.3/39.9
C127 4030007050 S.CER C1608 CH 1H 220J-T B 113.4/46.7
C128 4030006980 S.CER C1608 CH 1H 070D-T B 113.4/48.5
C129 4030007050 S.CER C1608 CH 1H 220J-T B 115.3/51.2
C130 4030007050 S.CER C1608 CH 1H 220J-T B 113.4/53.9
C131 4030007020 S.CER C1608 CH 1H 120J-T B 113.4/55.8
C132 4030007130 S.CER C1608 CH 1H 101J-T B 110.8/86.4
C133 4030007030 S.CER C1608 CH 1H 150J-T B 110.8/84.8
C134 4030006880 S.CER C1608 JB 1H 472K-T B 93.2/91.2
C141 4030006880 S.CER C1608 JB 1H 472K-T B 104.5/15.0
C142 4030008560 S.CER C1608 CH 1H 300J-T B 116.8/70.2
C143 4030007060 S.CER C1608 CH 1H 270J-T B 116.9/72.9
C144 4030007130 S.CER C1608 CH 1H 101J-T B 116.9/74.5
C145 4030007130 S.CER C1608 CH 1H 101J-T B 116.5/84.8
C146 4030007060 S.CER C1608 CH 1H 270J-T B 116.5/86.4
C147 4030008560 S.CER C1608 CH 1H 300J-T B 116.5/88.5
C148 4030006880 S.CER C1608 JB 1H 472K-T B 99.5/91.2
C151 4030011600 S.CER C1608 JB 1E 104K-T B 10.7/16.5
C152 4030011600 S.CER C1608 JB 1E 104K-T B 4.4/77.9
C153 4030011600 S.CER C1608 JB 1E 104K-T T 14.3/39.9
C154 4030011600 S.CER C1608 JB 1E 104K-T T 13.9/50.8
C181 4030006880 S.CER C1608 JB 1H 472K-T B 85.0/108.4
C182 4030010760 S.CER C1608 CH 1H 331J-T T 94.0/114.3
C183 4030007050 S.CER C1608 CH 1H 220J-T T 91.2/113.9
C184 4030009520 S.CER C1608 CH 1H 020B-T T 91.2/112.7
C185 4030010210 S.CER C3216 JB 1C 105M-T B 86.2/112.9
C186 4030011600 S.CER C1608 JB 1E 104K-T B 86.2/104.6
C201 4030006880 S.CER C1608 JB 1H 472K-T B 109.4/91.2
C202 4030006880 S.CER C1608 JB 1H 472K-T B 115.6/91.2
C203 4030006880 S.CER C1608 JB 1H 472K-T B 99.9/111.8
C204 4030006880 S.CER C1608 JB 1H 472K-T B 71.1/108.2
C205 4030006880 S.CER C1608 JB 1H 472K-T B 56.3/106.4
C211 4030007020 S.CER C1608 CH 1H 120J-T T 61.1/113.3
C212 4030007020 S.CER C1608 CH 1H 120J-T T 59.8/113.3
C213 4030011770 S.CER C1608 CH 1H 060B-T T 55.0/113.3
C214 4030011770 S.CER C1608 CH 1H 060B-T T 53.8/113.3
C215 4030011770 S.CER C1608 CH 1H 060B-T T 52.6/113.3
C216 4030011770 S.CER C1608 CH 1H 060B-T T 51.4/113.3
C221 4030006880 S.CER C1608 JB 1H 472K-T B 40.1/15.0
C222 4030018610 S.CER C1608 CH 1H 182J-T T 27.5/38.2
C223 4030018510 S.CER C2012 CH 1H 682J-T T 28.3/53.8
C224 4030018640 S.CER C2012 CH 1H 103J-T T 28.3/55.9
C225 4030018610 S.CER C1608 CH 1H 182J-T T 27.5/71.5
C226 4030006880 S.CER C1608 JB 1H 472K-T B 34.9/91.2
C227 4030018640 S.CER C2012 CH 1H 103J-T T 27.6/36.2
C228 4030018640 S.CER C2012 CH 1H 103J-T T 27.6/73.5
C241 4030006880 S.CER C1608 JB 1H 472K-T B 33.7/15.0
C242 4030017810 S.CER C1608 CH 1H 102J-T B 20.4/30.4
C243 4030007130 S.CER C1608 CH 1H 101J-T B 21.2/39.8
C244 4030007130 S.CER C1608 CH 1H 101J-T B 21.2/41.6
C245 4030017810 S.CER C1608 CH 1H 102J-T B 21.9/45.5
C246 4030018610 S.CER C1608 CH 1H 182J-T B 23.7/45.5
C247 4030017810 S.CER C1608 CH 1H 102J-T B 21.2/54.9
C248 4030018600 S.CER C1608 CH 1H 152J-T B 21.2/53.0
C249 4030017810 S.CER C1608 CH 1H 102J-T B 23.7/57.3
C250 4030018610 S.CER C1608 CH 1H 182J-T B 21.9/57.3
C251 4030007130 S.CER C1608 CH 1H 101J-T B 21.2/61.9
C252 4030007130 S.CER C1608 CH 1H 101J-T B 21.2/60.0
C253 4030017810 S.CER C1608 CH 1H 102J-T B 20.8/83.0
C254 4030006880 S.CER C1608 JB 1H 472K-T B 28.5/91.2
C261 4030006880 S.CER C1608 JB 1H 472K-T B 46.7/15.0
C262 4030017810 S.CER C1608 CH 1H 102J-T B 38.3/29.5
C263 4030017810 S.CER C1608 CH 1H 102J-T B 38.3/31.2
C264 4030010760 S.CER C1608 CH 1H 331J-T B 34.9/39.8
C265 4030007140 S.CER C1608 CH 1H 121J-T B 34.9/41.6
C266 4030007160 S.CER C1608 CH 1H 181J-T B 34.2/45.6
C267 4030007060 S.CER C1608 CH 1H 270J-T B 32.4/45.6
C268 4030010760 S.CER C1608 CH 1H 331J-T B 34.8/53.0
C269 4030007090 S.CER C1608 CH 1H 470J-T B 34.8/54.9
C270 4030007160 S.CER C1608 CH 1H 181J-T B 34.1/57.4
C271 4030007060 S.CER C1608 CH 1H 270J-T B 32.5/57.4
C272 4030010760 S.CER C1608 CH 1H 331J-T B 34.8/60.0
C273 4030007140 S.CER C1608 CH 1H 121J-T B 34.8/61.9
C274 4030017810 S.CER C1608 CH 1H 102J-T B 37.9/84.0
C275 4030017810 S.CER C1608 CH 1H 102J-T B 37.9/85.4
C276 4030006880 S.CER C1608 JB 1H 472K-T B 41.3/91.2
C281 4030006880 S.CER C1608 JB 1H 472K-T B 53.1/15.0
C282 4030017800 S.CER C1608 CH 1H 561J-T B 47.9/29.5
C283 4030010760 S.CER C1608 CH 1H 331J-T B 47.9/31.2
C284 4030010760 S.CER C1608 CH 1H 331J-T B 44.5/39.8
C285 4030007080 S.CER C1608 CH 1H 390J-T B 44.5/41.6
C286 4030007100 S.CER C1608 CH 1H 560J-T B 42.1/45.5
C287 4030010760 S.CER C1608 CH 1H 331J-T B 43.9/45.5
C288 4030010760 S.CER C1608 CH 1H 331J-T B 44.5/53.0
C289 4030007090 S.CER C1608 CH 1H 470J-T B 44.5/54.9
C290 4030010760 S.CER C1608 CH 1H 331J-T B 43.8/57.4
C291 4030007100 S.CER C1608 CH 1H 560J-T B 42.1/57.4
C292 4030010760 S.CER C1608 CH 1H 331J-T B 44.5/60.0
C293 4030007080 S.CER C1608 CH 1H 390J-T B 44.5/61.9
C294 4030017800 S.CER C1608 CH 1H 561J-T B 47.6/84.0
C295 4030010760 S.CER C1608 CH 1H 331J-T B 47.6/85.4
C296 4030006880 S.CER C1608 JB 1H 472K-T B 47.8/91.2
C301 4030011600 S.CER C1608 JB 1E 104K-T T 13.5/24.1
C302 4550003210 S.TAN TEESVD2 1D 226M12R T 7.1/82.2
C303 4030011600 S.CER C1608 JB 1E 104K-T T 3.0/86.8
C304 4030011600 S.CER C1608 JB 1E 104K-T T 3.0/89.6
C305 4510008540 S.ELE EEE1CA100SR T 7.0/94.1
RL1 6330002020 REL FTR-B4CA009Z
RL2 6330002020 REL FTR-B4CA009Z
RL21 6330002020 REL FTR-B4CA009Z
RL22 6330002020 REL FTR-B4CA009Z
RL41 6330002020 REL FTR-B4CA009Z
RL42 6330002020 REL FTR-B4CA009Z
RL61 6330002020 REL FTR-B4CA009Z
RL62 6330002020 REL FTR-B4CA009Z
RL81 6330002020 REL FTR-B4CA009Z
RL82 6330002020 REL FTR-B4CA009Z
RL101 6330002020 REL FTR-B4CA009Z
RL102 6330002020 REL FTR-B4CA009Z
RL121 6330002020 REL FTR-B4CA009Z
RL122 6330002020 REL FTR-B4CA009Z
RL141 6330002020 REL FTR-B4CA009Z
RL142 6330002020 REL FTR-B4CA009Z
RL181 6330002020 REL FTR-B4CA009Z
RL201 6330002020 REL FTR-B4CA009Z
RL202 6330002020 REL FTR-B4CA009Z
RL203 6330002020 REL FTR-B4CA009Z
RL204 6330002020 REL FTR-B4CA009Z
RL205 6330002020 REL FTR-B4CA009Z
RL221 6330002020 REL FTR-B4CA009Z
RL222 6330002020 REL FTR-B4CA009Z
RL241 6330002020 REL FTR-B4CA009Z
RL242 6330002020 REL FTR-B4CA009Z
RL261 6330002020 REL FTR-B4CA009Z
RL262 6330002020 REL FTR-B4CA009Z
RL281 6330002020 REL FTR-B4CA009Z
RL282 6330002020 REL FTR-B4CA009Z
J1 6510020521 S.CON 52808-1271 T 4.5/26.9
J11 6510028210 CON SJ050010
J501 6510028210 CON SJ050010
J502 6450001800 CON JPJ1044-01-010
W1 7030012290 JUM RDS2T0R0
EP301 6910014730 S.BEA MPZ2012S331A-T T 10.4/20.6
EP302 6910018270 S.BEA MMZ1608Y301CT T 10.9/24.1
(Amended page)
October 2016

15
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
IC130 1190002010 S.IC SD5400CY T 67.8/92.9
IC210 1110006180 S.IC UPG2009TB-E3 T 66.5/65.4
IC311 1180000421 S.IC TA78L05F (TE12RF) B 145.0/5.3
IC380 1190002110 S.IC NJG1519KC1-TE3-#ZZZB T 29.3/72.4
IC500 1190002110 S.IC NJG1519KC1-TE3-#ZZZB T 27.0/32.0
IC620 1180002770 S.REG BAJ0CC0FP-E2 B 88.8/5.7
IC701 1110006180 S.IC UPG2009TB-E3 T 63.2/5.7
IC800 1130011530 S.IC CD74HC4094M96 T 149.7/48.7
IC801 1130011530 S.IC CD74HC4094M96 T 149.7/40.6
IC850 1180000720 S.IC AN79L05M-(E1) B 155.2/14.9
IC950 1110005100 S.IC NJM072BM-TE1-#ZZZB T 132.0/17.7
IC951 1110005420 S.IC BA15532F-E2 T 131.6/31.5
IC1000 1110006100 S.IC NJM5534MD-TE1-#ZZZB B 142.3/32.7
IC1030 1110000960 S.IC NJM4558M-TE1-#FMZB B 74.5/43.7
IC1031 1110006751 S.IC TK14570LTL-GH T 73.4/34.0
IC1032 1120002830 S.IC NJM2125F-TE1-#FZZB B 73.8/32.0
IC1060 1110006190 S.IC NJM074M-TE1-#ZZZB B 126.4/32.2
IC1090 1110006100 S.IC NJM5534MD-TE1-#ZZZB B 110.0/45.0
IC1091 1110006100 S.IC NJM5534MD-TE1-#ZZZB B 122.2/17.7
IC1311 1130011921 S.IC TC74LCX00F (ELF) T 95.9/28.2
IC1312 1130005971 S.IC TC74HC4053AF (F) T 142.5/17.2
Q20 1590004030 S.TRA KRX204U-RTK/P T 114.8/59.4
Q21 1590004030 S.TRA KRX204U-RTK/P T 111.2/59.4
Q22 1590004030 S.TRA KRX204U-RTK/P T 115.9/74.3
Q30 1530003852 S.TRA 2SC5551A-F-TD-E B 131.2/63.4
Q50 1530003852 S.TRA 2SC5551A-F-TD-E B 128.0/91.5
Q70 1530003852 S.TRA 2SC5551A-F-TD-E B 128.0/76.5
Q150 1590003940 S.TRA RN1105 (TE85LF) T 32.9/81.4
Q151 1550000090 S.FET RSQ035P03TR T 10.3/64.4
Q170 1530003860 TRA 2SC3950D
Q190 1530003860 TRA 2SC3950D
Q321 1560001311 S.FET MMBFU310LT1G T 58.9/57.6
Q350 1590004030 S.TRA KRX204U-RTK/P T 56.8/38.9
Q351 1590004030 S.TRA KRX204U-RTK/P T 56.8/35.1
Q550 1530003842 S.TRA 2SC5501A-4-TR-E B 7.2/17.4
Q580 1530004430 S.TRA BFR92W H6327 B 19.4/12.8
Q581 1530004430 S.TRA BFR92W H6327 B 14.4/9.6
Q640 1560001311 S.FET MMBFU310LT1G B 39.1/3.3
Q641 1560001311 S.FET MMBFU310LT1G B 39.1/6.8
Q671 1560001311 S.FET MMBFU310LT1G T 55.7/8.0
Q730 1530003340 S.TRA 2SC3357-T1 RF T 42.5/20.3
Q901 1590003940 S.TRA RN1105 (TE85LF) B 141.4/15.3
Q1011 1530003432 S.TRA 2SC5226A-4-TL-E T 68.7/11.1
Q1021 1530003432 S.TRA 2SC5226A-4-TL-E T 68.1/23.8
Q1200 1530003451 S.TRA 2SC4835GRL B 95.3/45.9
Q1201 1530003451 S.TRA 2SC4835GRL B 98.1/10.8
Q1310 1530002601 S.TRA 2SC4215-O (TE85RF) B 99.7/28.2
D1 1750000581 S.DIO 1SV307 (TPH3F) T 110.5/90.2
D20 1750000550 S.DIO 1SS355 TE-17 B 147.5/95.9
D21 1750000550 S.DIO 1SS355 TE-17 B 148.3/80.6
D90 1750000550 S.DIO 1SS355 TE-17 B 105.0/80.9
D91 1750000550 S.DIO 1SS355 TE-17 B 105.2/97.3
D460 1750000581 S.DIO 1SV307 (TPH3F) T 19.0/71.7
D461 1750000581 S.DIO 1SV307 (TPH3F) T 19.0/73.8
D462 1750000581 S.DIO 1SV307 (TPH3F) T 18.6/34.3
D463 1750000581 S.DIO 1SV307 (TPH3F) T 18.6/32.3
D600 1750000431 S.DIO HSB88WSTR-E T 42.1/12.5
D850 1750001820 S.DIO LRB706F-40T1G B 113.8/9.0
D851 1750001820 S.DIO LRB706F-40T1G T 113.6/14.2
D950 1750000550 S.DIO 1SS355 TE-17 T 132.5/24.4
D951 1750000550 S.DIO 1SS355 TE-17 T 132.5/22.6
D1021 1790001241 S.DIO MA2S7280GL B 67.8/25.5
D1250 1750000431 S.DIO HSB88WSTR-E T 92.1/38.3
D1251 1750000431 S.DIO HSB88WSTR-E T 92.0/18.3
FI400 2030000530 S.MON FL-384 (58.7 MHz) T 44.2/51.5
FI420 2030000540 S.MON FL-385 (58.7 MHz) T 35.6/53.7
FI440 2030000550 S.MON FL-386 (58.7 MHz) T 27.0/51.5
FI460 2030000560 S.MON FL-387 (58.7 MHz) T 18.4/53.7
FI480 2030000570 S.MON FL-388 (58.7 MHz) T 9.8/51.5
FI702 2020002430 CER SFVLF10M7LF00-B0
FI1011 2020 001170 S.CER SFECA10.7MS2- A -TC T 75.1/17.8
FI1030 2020001170 S.CER SFECA10.7MS2-A-TC T 68.6/28.8
L21 6200009690 S.COI LQH43CN101K03L T 177.6/14.4
L30 6140003890 COI LR-488
L31 6180001000 COI LAL 04NA 102K
L32 6200010680 S.COI C2520C-R22G-A (0.22U) T 96.2/58.0
L33 6140003900 COI LR-489
L51 6140003800 COI LR-439
L52 6190001650 COI ELC06D102E
L53 6140003881 COI LR-486-1
L54 6140003800 COI LR-439
L70 6190001650 COI ELC06D102E
L71 6140003881 COI LR-486-1
L110 6200010740 S.COI C2520C-R27G-A T 98.2/86.4
L111 6 20 0 01 074 0 S .C O I C2 52 0C - R 27G - A T 9 5. 4/ 82 .8
L112 6200007780 S.COI LQW2BHNR12J03L B 86.1/91.7
L113 6200007780 S.COI LQW2BHNR12J03L B 83.5/91.7
L114 6200010740 S.COI C2520C-R27G-A T 92.7/79.3
L131 6200010730 S.COI C2520C-68NG-A T 83.1/87.6
L132 6190001631 COI #E544EN-100021
L133 6200011410 S.COI C2520C-82NG-A T 67.5/76.6
L134 6200010860 S.COI C2520C-R10G-A (0.1U) T 66.2/70.3
L136 6140003920 COI LR-491
L138 6140003960 COI LR-495
L150 6180003990 COI AL04 TB 3R3K
L170 6200010740 S.COI C2520C-R27G-A T 50.8/94.8
L190 6200011450 S.COI C2520C-R39G-A T 30.9/94.4
L191 6140003910 COI LR-490
L211 6200010740 S.COI C2520C-R27G-A T 71.6/62.3
L230 6140004660 COI LR-524
L290 6200010650 S.COI C2520C-R12G-A (0.12U) T 87.8/65.8
L291 6200010860 S.COI C2520C-R10G-A (0.1U) T 84.1/62.7
L292 6200010670 S.COI C2520C-R18G-A (0.18U) T 80.9/59.0
L293 6200010680 S.COI C2520C-R22G-A (0.22U) T 75.8/55.7
L321 6200005011 S.COI NLV25T-100J-PF T 63.1/61.3
L322 6140002810 S.COI LR-317 T 69.1/54.9
L323 6200011220 S.COI C2012C-R47J-A T 63.0/53.3
L400 6200010960 S.COI C2520C-R47G-A (0.47U) T 44.3/64.7
L401 6200010960 S.COI C2520C-R47G-A (0.47U) T 44.2/41.8
L402 6200010960 S.COI C2520C-R47G-A (0.47U) T 44.3/61.4
L403 6200010960 S.COI C2520C-R47G-A (0.47U) T 44.2/38.3
L420 6200010770 S.COI C2520C-R68G-A T 35.4/66.9
L421 6200010770 S.COI C2520C-R68G-A T 35.8/43.9
L422 6200010780 S.COI C2520C-1R0G-A T 35.4/63.6
L423 6200010780 S.COI C2520C-1R0G-A T 35.8/40.7
L440 6200010450 S.COI C2520C-R82G-A (0.82U) T 26.9/64.5
L441 6200010450 S.COI C2520C-R82G-A (0.82U) T 26.9/41.7
L442 6200010440 S.COI C2520C-1R2G-A (1.2U) T 26.9/61.3
L443 6200010440 S.COI C2520C-1R2G-A (1.2U) T 26.9/38.5
L460 6200010440 S.COI C2520C-1R2G-A (1.2U) T 18.1/66.6
L461 6200010440 S.COI C2520C-1R2G-A (1.2U) T 18.0/43.8
L462 6200010440 S.COI C2520C-1R2G-A (1.2U) T 18.1/63.4
L463 6200010440 S.COI C2520C-1R2G-A (1.2U) T 18.0/40.6
L464 6200003711 S.COI NLV25T-2R7J-PF T 22.4/71.7
L465 6200003711 S.COI NLV25T-2R7J-PF T 22.0/32.5
L480 6200010810 S.COI C2520C-2R2G-A T 10.5/61.2
L481 6200010810 S.COI C2520C-2R2G-A T 9.2/41.7
L482 6200010680 S.COI C2520C-R22G-A (0.22U) T 10.5/64.7
L483 6200010680 S.COI C2520C-R22G-A (0.22U) T 9.2/38.4
L484 6200003711 S.COI NLV25T-2R7J-PF B 9.9/73.8
L485 6200003711 S.COI NLV25T-2R7J-PF B 10.3/71.2
L486 6200003711 S.COI NLV25T-2R7J-PF B 11.5/34.9
L487 6200003711 S.COI NLV25T-2R7J-PF B 15.7/36.2
L520 6200007790 S.COI LQW2BHNR15J03L T 19.1/25.4
L521 6200007740 S.COI LQW2BHN47NJ03L T 14.8/24.1
L550 6140003930 COI LR-492
L580 6190001740 COI #E544EN-100027
L600 6140003210 S.COI LR-358 T 35.1/12.5
L601 6140003210 S.COI LR-358 T 49.1/12.5
L611 6200010770 S.COI C2520C-R68G-A T 35.0/6.7
L612 6200011450 S.COI C2520C-R39G-A T 38.6/3.3
L613 6200010740 S.COI C2520C-R27G-A T 31.3/5.8
L620 6200005521 S.COI NLV25T-470J-PF T 23.7/3.4
L640 6200010970 S.COI C2520C-1R8G-A (1.8U) T 48.1/5.1
L641 6200002041 S.COI NLV25T-101J-PF B 32.3/5.5
L642 6200002041 S.COI NLV25T-101J-PF B 52.4/6.9
L702 6200010950 S.COI C2520C-1R5G-A (1.5U) T 79.5/5.8
L703 6200010970 S.COI C2520C-1R8G-A (1.8U) T 68.9/3.7
L704 6200010810 S.COI C2520C-2R2G-A T 77.6/10.6
L730 6200001920 S.COI ELJNC R15K-F T 51.2/20.9
L731 6200003290 S.COI ELJNC R12K-F T 50.5/25.2
L732 6200003290 S.COI ELJNC R12K-F T 44.5/24.7
L805 6200005011 S.COI NLV25T-100J-PF T 156.5/36.0
L1011 6200003711 S.COI NLV25T-2R7J-PF T 62.7/9.9
L1012 6200005011 S.COI NLV25T-100J-PF T 68.8/14.5
L1013 6200005011 S.COI NLV25T-100J-PF B 65.6/15.5
L1021 6200003941 S.COI NLV25T-5R6J-PF T 72.0/21.9
L1022 6200002861 S.COI NLV25T-4R7J-PF T 64.7/23.3
L1023 6200005011 S.COI NLV25T-100J-PF B 65.0/20.1
L1030 6190001750 S.COI #836BN-0541TY T 64.0/36.9
L1032 6200005011 S.COI NLV25T-100J-PF B 62.1/34.5
L1200 6200003520 S.COI ELJFB 102K-F T 99.7/45.5
L1250 6140003210 S.COI LR-358 T 99.1/38.3
L1251 6140003210 S.COI LR-358 T 99.0/18.3
L1252 6140003210 S.COI LR-358 T 85.1/38.3
L1253 6140003210 S.COI LR-358 T 85.0/18.3
L1310 6200003261 S.COI NLV32T-101J-PF T 80.1/30.2
L1311 6200003261 S.COI NLV32T-101J-PF B 88.8/32.1
L1312 6200010800 S.COI C2520C-4R7G-A T 88.8/25.7
L1313 6200003261 S.COI NLV32T-101J-PF B 88.8/25.1
R1 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 114.2/91.7
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 112.1/90.2
R3 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 114.2/88.1
R4 7030003620 S.RES ERJ3GEYJ 333 V (33 k) T 114.2/89.3
R20 7030003320 S.RES ERJ3GEYJ 101 V (100) T 143.5/73.2
R21 7030003320 S.RES ERJ3GEYJ 101 V (100) T 145.1/96.5
R22 7030003320 S.RES ERJ3GEYJ 101 V (100) B 104.7/82.4
R23 7030003320 S.RES ERJ3GEYJ 101 V (100) T 104.4/97.8
R30 7030003200 S.RES ERJ3GEYJ 100 V (10) B 140.4/66.8
R31 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 144.0/59.5
R32 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 144.0/60.7
R33 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6) B 131.0/66.8
R34 7030003280 S.RES ERJ3GEYJ 470 V (47) B 138.8/62.7
R35 7030003240 S.RES ERJ3GEYJ 220 V (22) T 133.8/58.9
R50 7030003280 S.RES ERJ3GEYJ 470 V (47) T 139.1/97.6
R51 7030003200 S.RES ERJ3GEYJ 100 V (10) B 132.5/91.1
R53 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 129.6/84.4
R54 7030003280 S.RES ERJ3GEYJ 470 V (47) B 123.7/93.9
R55 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) B 124.7/87.5
R70 7030003280 S.RES ERJ3GEYJ 470 V (47) B 139.8/76.0
R71 7030003200 S.RES ERJ3GEYJ 100 V (10) B 132.5/76.5
R73 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 130.1/69.4
R74 7030003280 S.RES ERJ3GEYJ 470 V (47) B 123.8/79.1
R75 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) B 124.5/72.7
R110 7030000010 S.RES MCR10EZHJ JPW (000) T 101.1/88.8
R111 7030003280 S.RES ERJ3GEYJ 470 V (47) B 88.6/90.7
R130 7030000010 S.RES MCR10EZHJ JPW (000) T 85.8/87.9
R131 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 74.3/94.9
(Amended page)
October 2016

16
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
R132 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 80.0/97.0
R134 7030003250 S.RES ERJ3GEYJ 270 V (27) T 70.9/77.3
R135 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 69.8/98.4
R136 7310004860 S.TRI EVM-3YSX50 B53 (502) T 85.5/94.6
R137 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 67.0/96.6
R139 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 78.1/95.2
R141 7030007680 S.RES ERJ8ENF 47R0V (47) T 62.4/98.2
R142 7030003400 S.RES ERJ3GEYJ 471 V (470) B 94.7/77.7
R143 7030007680 S.RES ERJ8ENF 47R0V (47) T 61.0/93.0
R150 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 35.4/86.5
R151 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 36.6/82.1
R161 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 83.0/94.8
R170 7030009620 S.RES ERJ12YJ120U (12) B 49.6/95.7
R171 7030003280 S.RES ERJ3GEYJ 470 V (47) T 48.4/93.0
R173 7030007180 S.RES ERJ12YJ150U (15) B 40.4/92.8
R175 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 41.9/94.1
R176 7030006240 S.RES ERJ12YJ181U (180) B 34.2/93.1
R177 7030007850 S.RES ERJ8ENF 1001V (1 k) T 34.1/91.3
R190 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 33.8/93.5
R191 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 35.0/94.9
R192 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) T 37.2/95.6
R193 7030006070 S.RES ERJ12YJ101U (100) B 26.6/93.0
R194 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 27.1/94.4
R195 7030003280 S.RES ERJ3GEYJ 470 V (47) T 36.2/87.1
R196 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 28.8/81.5
R197 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) T 27.6/81.5
R198 7030003420 S.RES ERJ3GEYJ 681 V (680) B 25.0/87.7
R199 7030003200 S.RES ERJ3GEYJ 100 V (10) T 25.1/86.1
R200 7030003280 S.RES ERJ3GEYJ 470 V (47) T 24.4/91.0
R210 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 63.7/64.0
R211 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 65.6/61.9
R214 7030003280 S.RES ERJ3GEYJ 470 V (47) B 52.3/63.2
R290 7030003370 S.RES ERJ3GEYJ 271 V (270) T 92.1/61.6
R291 7030003230 S.RES ERJ3GEYJ 180 V (18) T 91.4/63.5
R292 7030003370 S.RES ERJ3GEYJ 271 V (270) T 90.6/61.6
R321 7030003320 S.RES ERJ3GEYJ 101 V (100) T 60.5/60.3
R322 7030003320 S.RES ERJ3GEYJ 101 V (100) B 67.7/57.7
R324 7030003860 S.RES ERJ3GE JPW V T 69.2/59.8
R350 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 56.8/37.0
R351 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 56.8/33.2
R380 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 29.4/71.4
R381 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 26.6/70.1
R382 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 26.6/75.3
R383 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 29.5/76.9
R460 7030003400 S.RES ERJ3GEYJ 471 V (470) T 25.4/72.3
R461 7030003400 S.RES ERJ3GEYJ 471 V (470) T 22.5/35.1
R480 7030003380 S.RES ERJ3GEYJ 331 V (330) B 13.1/73.8
R481 7030003380 S.RES ERJ3GEYJ 331 V (330) B 13.6/71.7
R482 7030003380 S.RES ERJ3GEYJ 331 V (330) B 14.7/34.3
R483 7030003380 S.RES ERJ3GEYJ 331 V (330) B 14.7/32.3
R484 7030003320 S.RES ERJ3GEYJ 101 V (100) B 6.5/74.2
R485 7030003320 S.RES ERJ3GEYJ 101 V (100) B 7.2/70.8
R486 7030003320 S.RES ERJ3GEYJ 101 V (100) B 18.1/36.5
R487 7030003320 S.RES ERJ3GEYJ 101 V (100) B 8.8/35.9
R500 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 29.9/35.0
R501 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 29.9/30.6
R502 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 24.0/30.7
R503 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 24.0/35.0
R550 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 7.2/19.6
R551 7030003400 S.RES ERJ3GEYJ 471 V (470) B 6.2/14.1
R552 7030003340 S.RES ERJ3GEYJ 151 V (150) B 8.0/14.1
R553 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 4.4/14.1
R554 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) B 3.7/18.2
R555 7030003200 S.RES ERJ3GEYJ 100 V (10) B 10.2/14.8
R556 7030003300 S.RES ERJ3GEYJ 680 V (68) B 14.4/16.4
R580 7030003200 S.RES ERJ3GEYJ 100 V (10) B 13.8/12.0
R581 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 10.7/8.4
R582 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) B 14.1/6.8
R583 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 12.3/3.9
R584 7030003200 S.RES ERJ3GEYJ 100 V (10) B 22.8/12.8
R585 7030003200 S.RES ERJ3GEYJ 100 V (10) B 16.6/8.9
R587 7030003280 S.RES ERJ3GEYJ 470 V (47) B 18.7/5.7
R588 7510001671 S.THR NTCG16 4BH 103JT B 14.1/5.2
R611 7030003280 S.RES ERJ3GEYJ 470 V (47) T 32.5/2.4
R620 7030003320 S.RES ERJ3GEYJ 101 V (100) T 26.9/3.2
R641 7030003280 S.RES ERJ3GEYJ 470 V (47) B 35.3/5.5
R645 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) T 45.8/4.3
R671 7030003200 S.RES ERJ3GEYJ 100 V (10) T 56.0/4.5
R672 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 56.0/5.7
R673 7030003330 S.RES ERJ3GEYJ 121 V (120) T 59.6/9.0
R674 7030003340 S.RES ERJ3GEYJ 151 V (150) B 57.5/8.5
R704 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 59.0/4.4
R705 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 62.1/8.6
R730 7030003370 S.RES ERJ3GEYJ 271 V (270) T 46.9/18.4
R731 7030003230 S.RES ERJ3GEYJ 180 V (18) T 50.8/18.6
R732 7030003370 S.RES ERJ3GEYJ 271 V (270) T 47.4/19.6
R733 7030003330 S.RES ERJ3GEYJ 121 V (120) T 38.1/25.6
R734 7030003320 S.RES ERJ3GEYJ 101 V (100) T 38.1/20.0
R735 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 40.9/24.8
R736 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 38.1/22.7
R737 7030003370 S.RES ERJ3GEYJ 271 V (270) T 35.9/23.5
R738 7030003230 S.RES ERJ3GEYJ 180 V (18) T 35.1/21.4
R739 7030003370 S.RES ERJ3GEYJ 271 V (270) T 34.4/23.5
R800 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 120.3/10.4
R801 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 121.5/10.4
R802 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 122.7/10.4
R803 7030003280 S.RES ERJ3GEYJ 470 V (47) T 137.1/46.5
R804 7030003280 S.RES ERJ3GEYJ 470 V (47) T 140.3/44.4
R805 7030003280 S.RES ERJ3GEYJ 470 V (47) T 140.3/45.8
R806 7030003280 S.RES ERJ3GEYJ 470 V (47) T 137.1/49.3
R807 7030003280 S.RES ERJ3GEYJ 470 V (47) T 140.3/50.0
R808 7030003280 S.RES ERJ3GEYJ 470 V (47) T 137.1/50.7
R809 7030003280 S.RES ERJ3GEYJ 470 V (47) T 140.3/51.4
R810 7030003280 S.RES ERJ3GEYJ 470 V (47) T 140.3/48.6
R811 7030003280 S.RES ERJ3GEYJ 470 V (47) T 137.1/47.9
R812 7030003280 S.RES ERJ3GEYJ 470 V (47) T 140.3/47.2
R813 7030003280 S.RES ERJ3GEYJ 470 V (47) T 137.1/43.7
R814 7030003280 S.RES ERJ3GEYJ 470 V (47) T 137.1/45.1
R815 7030003280 S.RES ERJ3GEYJ 470 V (47) T 140.3/43.0
R816 7030003280 S.RES ERJ3GEYJ 470 V (47) T 137.1/42.3
R817 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 151.9/36.2
R818 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 156.7/41.1
R819 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 151.2/52.7
R820 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 152.5/41.9
R821 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 119.1/10.4
R850 7030003370 S.RES ERJ3GEYJ 271 V (270) B 151.1/13.5
R900 7030003860 S.RES ERJ3GE JPW V B 124.1/8.2
R904 7030003860 S.RES ERJ3GE JPW V T 147.1/28.0
R905 7030003320 S.RES ERJ3GEYJ 101 V (100) T 137.1/13.3
R907 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 143.2/19.7
R908 7030003320 S.RES ERJ3GEYJ 101 V (100) T 148.4/21.7
R950 7030003370 S.RES ERJ3GEYJ 271 V (270) T 136.7/20.4
R951 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135.4/20.4
R952 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 129.1/23.6
R953 7030003360 S.RES ERJ3GEYJ 221 V (220) T 132.6/26.0
R954 7030003360 S.RES ERJ3GEYJ 221 V (220) T 134.9/23.5
R955 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 127.1/32.8
R956 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 136.1/31.4
R957 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 127.1/29.6
R958 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 131.6/35.0
R959 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 137.0/29.5
R960 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 127.8/35.0
R961 7030003320 S.RES ERJ3GEYJ 101 V (100) T 134.9/12.3
R962 7030003320 S.RES ERJ3GEYJ 101 V (100) T 127.2/21.8
R963 7030003860 S.RES ERJ3GE JPW V T 131.8/12.3
R964 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 129.9/12.3
R965 7030003320 S.RES ERJ3GEYJ 101 V (100) T 136.1/34.1
R966 7030003320 S.RES ERJ3GEYJ 101 V (100) T 131.9/28.0
R1000 7030009691 S.RES ERA3YED 101V (100) B 143.4/25.0
R1001 7030003320 S.RES ERJ3GEYJ 101 V (100) T 147.3/34.0
R1002 7030010390 S.RES ERA3YED 821V (820) B 141.5/29.3
R1003 7030003320 S.RES ERJ3GEYJ 101 V (100) B 135.4/33.9
R1004 7030008061 S.RES ERA3YED 222V (2.2 k) B 132.6/34.2
R1011 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 66.3/11.8
R1012 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 66.1/10.3
R1013 7030003230 S.RES ERJ3GEYJ 180 V (18) T 70.6/11.5
R1014 7030003360 S.RES ERJ3GEYJ 221 V (220) T 72.7/10.7
R1015 7030003380 S.RES ERJ3GEYJ 331 V (330) T 70.7/14.8
R1021 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 68.2/21.9
R1022 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 70.1/21.6
R1023 7030003340 S.RES ERJ3GEYJ 151 V (150) B 70.3/25.4
R1024 7030003380 S.RES ERJ3GEYJ 331 V (330) T 64.2/21.3
R1031 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 81.0/42.5
R1032 7030003320 S.RES ERJ3GEYJ 101 V (100) T 76.6/40.0
R1033 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 68.0/41.3
R1034 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 81.0/44.1
R1035 7030003320 S.RES ERJ3GEYJ 101 V (100) B 67.1/46.3
R1036 7030003860 S.RES ERJ3GE JPW V B 68.0/42.9
R1037 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 70.4/37.7
R1039 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 81.0/45.6
R1040 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.4/39.5
R1041 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 70.0/39.7
R1042 7310004820 S.TRI EVM-3YSX50 B33 (302) T 85.3/45.6
R1043 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) T 80.6/45.6
R1044 7030003610 S.RES ERJ3GEYJ 273 V (27 k) B 71.4/36.5
R1045 7030003320 S.RES ERJ3GEYJ 101 V (100) B 74.3/27.7
R1046 7030003690 S.RES ERJ3GEYJ 124 V (120 k) B 70.6/31.9
R1048 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 62.7/45.1
R1049 7030005871 S.RES ERA3YKD 104V (100 k) B 72.1/34.5
R1050 7030008051 S.RES ERA3YKD 184V (180 k) B 75.7/36.0
R1051 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 76.9/34.5
R1053 7030008061 S.RES ERA3YED 222V (2.2 k) B 67.8/31.1
R1054 7030006461 S.RES ERA3YED 152V (1.5 k) B 68.6/29.0
R1060 7030005321 S.RES ERA3YED 103V (10 k) B 127.2/38.3
R1061 7030005321 S.RES ERA3YED 103V (10 k) B 127.3/26.1
R1062 7030005321 S.RES ERA3YED 103V (10 k) B 124.3/38.3
R1063 7030005321 S.RES ERA3YED 103V (10 k) B 124.3/26.1
R1064 7030005321 S.RES ERA3YED 103V (10 k) B 121.2/36.7
R1065 7030005321 S.RES ERA3YED 103V (10 k) B 121.2/28.9
R1066 7030005321 S.RES ERA3YED 103V (10 k) B 118.7/32.5
R1067 7030005321 S.RES ERA3YED 103V (10 k) B 118.7/30.9
R1068 7030005321 S.RES ERA3YED 103V (10 k) B 118.7/37.2
R1069 7030005321 S.RES ERA3YED 103V (10 k) B 118.7/26.1
R1070 7030003320 S.RES ERJ3GEYJ 101 V (100) T 124.5/32.8
R1071 7030003320 S.RES ERJ3GEYJ 101 V (100) B 133.4/31.4
R1090 7030003380 S.RES ERJ3GEYJ 331 V (330) B 116.4/43.1
R1091 7030003380 S.RES ERJ3GEYJ 331 V (330) T 127.4/14.0
R1092 7310004820 S.TRI EVM-3YSX50 B33 (302) T 116.8/24.0
R1093 7030009861 S.RES ERA3YED 471V (470) B 112.5/40.0
R1094 7030006091 S.RES ERA3YED 822V (8.2 k) T 116.0/18.6
R1095 7030005321 S.RES ERA3YED 103V (10 k) B 109.2/40.0
R1096 7030007661 S.RES ERA3YED 331V (330) B 105.0/48.8
R1097 7030007661 S.RES ERA3YED 331V (330) T 119.8/21.8
R1098 7030007230 S.RES ERA3YED 102V (1 k) B 110.0/38.2
R1099 7030007230 S.RES ERA3YED 102V (1 k) T 116.0/15.6
R1200 7030007230 S.RES ERA3YED 102V (1 k) B 102.6/45.9
R1201 7030007230 S.RES ERA3YED 102V (1 k) B 102.9/42.9
R1202 7030007230 S.RES ERA3YED 102V (1 k) B 115.9/18.2
R1203 7030007230 S.RES ERA3YED 102V (1 k) B 115.8/15.5
R1204 7030007230 S.RES ERA3YED 102V (1 k) B 100.9/11.1
R1205 7030007230 S.RES ERA3YED 102V (1 k) B 99.2/45.9
R1206 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 93.8/49.7
R1207 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 97.9/42.9
R1208 7030011050 S.RES ERA3YHD 100V (10) B 95.3/48.1
R1209 7030011050 S.RES ERA3YHD 100V (10) B 97.4/8.8
R1210 7030009851 S.RES ERA3YED 271V (270) B 92.8/44.6
R1211 7030009851 S.RES ERA3YED 271V (270) B 95.5/13.6
R1212 7030009841 S.RES ERA3YHD 330V (33) B 86.3/40.8
(Amended page)
October 2016

17
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
R1213 7030009841 S.RES ERA3YHD 330V (33) B 86.3/16.0
R1214 7030010980 S.RES ERA3YHD 470V (47) B 86.3/36.5
R1215 7030010980 S.RES ERA3YHD 470V (47) B 86.3/20.1
R1310 7030003320 S.RES ERJ3GEYJ 101 V (100) B 99.4/32.7
R1311 7030003320 S.RES ERJ3GEYJ 101 V (100) B 98.4/24.1
R1312 7030003320 S.RES ERJ3GEYJ 101 V (100) B 96.9/32.0
R1313 7030003320 S.RES ERJ3GEYJ 101 V (100) T 89.0/28.9
R1314 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 94.9/32.7
R1315 7030003400 S.RES ERJ3GEYJ 471 V (470) B 96.3/25.2
R1316 7030003630 S.RES ERJ3GEYJ 393 V (39 k) B 99.6/30.2
R1317 7030003280 S.RES ERJ3GEYJ 470 V (47) B 100.1/25.7
R1318 7030003220 S.RES ERJ3GEYJ 150 V (15) B 102.6/27.9
R1319 7030003380 S.RES ERJ3GEYJ 331 V (330) B 101.8/25.7
R1320 7030003380 S.RES ERJ3GEYJ 331 V (330) B 103.5/25.7
R1321 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 89.0/30.4
C1 4030007170 S.CER C1608 CH 1H 221J-T T 108.9/90.2
C2 4030011600 S.CER C1608 JB 1E 104K-T T 114.2/90.5
C20 4030006900 S.CER C1608 JB 1H 103K-T T 148.0/96.5
C21 4030006900 S.CER C1608 JB 1H 103K-T T 148.0/80.6
C22 4030006900 S.CER C1608 JB 1H 103K-T T 114.3/57.3
C23 4030006900 S.CER C1608 JB 1H 103K-T T 110.7/57.3
C24 4030006900 S.CER C1608 JB 1H 103K-T T 117.4/72.4
C25 4030006860 S.CER C1608 JB 1H 102K-T T 125.5/69.3
C26 4030006860 S.CER C1608 JB 1H 102K-T T 109.0/61.6
C27 4030006860 S.CER C1608 JB 1H 102K-T T 118.2/74.3
C30 4030018960 S.CER C3216 JB 1C 106MT-N B 126.5/56.7
C31 4030017490 S.CER C1608 JB 1A 105K-T T 143.5/68.9
C32 4030006990 S.CER C1608 CH 1H 080D-T B 137.6/66.8
C33 4030006860 S.CER C1608 JB 1H 102K-T T 144.0/61.9
C34 4030010210 S.CER C3216 JB 1C 105M-T B 129.2/59.6
C35 4030017490 S.CER C1608 JB 1A 105K-T T 140.8/57.8
C36 4030006860 S.CER C1608 JB 1H 102K-T B 125.8/62.1
C37 4030017490 S.CER C1608 JB 1A 105K-T T 137.2/57.8
C38 4030006860 S.CER C1608 JB 1H 102K-T T 133.8/57.7
C39 4030018810 S.CER C3216 CH 1H 333J-T B 119.0/66.0
C40 4030007090 S.CER C1608 CH 1H 470J-T B 113.2/66.5
C41 4550006120 S.TAN TEESVA 0G 226M8R T 141.8/54.9
Eqv. 4550007340 S.TAN F930G226MAABMA
C42 4550006120 S.TAN TEESVA 0G 226M8R T 136.1/55.0
Eqv. 4550007340 S.TAN F930G226MAABMA
C50 4030007100 S.CER C1608 CH 1H 560J-T B 141.1/77.6
C51 4030017490 S.CER C1608 JB 1A 105K-T T 137.0/87.0
C53 4030017490 S.CER C1608 JB 1A 105K-T T 137.0/77.7
C55 4030006860 S.CER C1608 JB 1H 102K-T B 126.9/86.8
C56 4030017490 S.CER C1608 JB 1A 105K-T B 128.6/86.8
C58 4030009510 S.CER C1608 CH 1H 010B-T B 123.7/90.6
C59 4030006860 S.CER C1608 JB 1H 102K-T B 123.8/85.6
C60 4030010210 S.CER C3216 JB 1C 105M-T B 123.6/83.7
C62 4030010210 S.CER C3216 JB 1C 105M-T T 117.6/86.2
C63 4030007130 S.CER C1608 CH 1H 101J-T B 116.4/82.4
C72 4030006860 S.CER C1608 JB 1H 102K-T B 127.0/72.0
C73 4030017490 S.CER C1608 JB 1A 105K-T B 128.8/72.0
C75 4030009510 S.CER C1608 CH 1H 010B-T B 123.8/75.8
C76 4030006860 S.CER C1608 JB 1H 102K-T B 122.8/70.0
C77 4030010210 S.CER C3216 JB 1C 105M-T B 123.4/67.5
C79 4030010210 S.CER C3216 JB 1C 105M-T T 117.6/80.0
C80 4030018960 S.CER C3216 JB 1C 106MT-N B 117.6/88.7
C90 4030006900 S.CER C1608 JB 1H 103K-T T 105.2/81.9
C91 4030006900 S.CER C1608 JB 1H 103K-T T 107.0/97.8
C110 4030007080 S.CER C1608 CH 1H 390J-T T 98.6/88.7
C111 4030007030 S.CER C1608 CH 1H 150J-T T 98.4/84.1
C112 4030007130 S.CER C1608 CH 1H 101J-T T 94.6/85.6
C113 4030007060 S.CER C1608 CH 1H 270J-T T 97.7/82.2
C114 4030007080 S.CER C1608 CH 1H 390J-T B 86.6/88.7
C115 4030007170 S.CER C1608 CH 1H 221J-T B 83.5/88.7
C116 4030007130 S.CER C1608 CH 1H 101J-T T 92.6/81.5
C117 4030007100 S.CER C1608 CH 1H 560J-T B 85.1/87.2
C119 4030007050 S.CER C1608 CH 1H 220J-T T 98.6/89.9
C120 4030007020 S.CER C1608 CH 1H 120J-T T 94.6/87.1
C130 4030006860 S.CER C1608 JB 1H 102K-T T 73.1/95.8
C131 4030006900 S.CER C1608 JB 1H 103K-T B 88.2/73.9
C132 4030007140 S.CER C1608 CH 1H 121J-T B 78.1/75.1
C133 4030006900 S.CER C1608 JB 1H 103K-T T 72.6/98.4
C134 4030007170 S.CER C1608 CH 1H 221J-T B 78.1/76.6
C135 4030007110 S.CER C1608 CH 1H 680J-T T 67.1/74.3
C136 4030006900 S.CER C1608 JB 1H 103K-T B 69.9/96.6
C137 4030007040 S.CER C1608 CH 1H 180J-T T 71.0/67.4
C138 4030006900 S.CER C1608 JB 1H 103K-T T 66.4/98.1
C139 4030006900 S.CER C1608 JB 1H 103K-T T 61.7/89.8
C144 4030007020 S.CER C1608 CH 1H 120J-T T 67.1/73.1
C146 4030011600 S.CER C1608 JB 1E 104K-T T 81.8/94.8
C150 4030011600 S.CER C1608 JB 1E 104K-T B 50.6/86.5
C151 4030006880 S.CER C1608 JB 1H 472K-T B 32.8/81.7
C152 4030011600 S.CER C1608 JB 1E 104K-T T 36.2/88.3
C170 4030006900 S.CER C1608 JB 1H 103K-T T 50.7/92.0
C171 4030009530 S.CER C1608 CH 1H 030B-T T 48.4/95.7
C172 4030011600 S.CER C1608 JB 1E 104K-T T 50.7/97.6
C174 4030011600 S.CER C1608 JB 1E 104K-T T 39.6/94.6
C175 4030011600 S.CER C1608 JB 1E 104K-T B 43.3/89.2
C190 4030007090 S.CER C1608 CH 1H 470J-T T 29.5/91.6
C191 4030006900 S.CER C1608 JB 1H 103K-T T 30.7/91.6
C192 4030011600 S.CER C1608 JB 1E 104K-T T 37.2/93.2
C193 4030006900 S.CER C1608 JB 1H 103K-T T 37.2/94.4
C194 4030007050 S.CER C1608 CH 1H 220J-T T 25.9/94.4
C195 4030006900 S.CER C1608 JB 1H 103K-T B 30.1/93.6
C196 4030011600 S.CER C1608 JB 1E 104K-T T 26.3/91.0
C197 4030006900 S.CER C1608 JB 1H 103K-T T 25.1/82.2
C198 4030007010 S.CER C1608 CH 1H 100D-T T 25.1/87.3
C199 4030011600 S.CER C1608 JB 1E 104K-T T 25.1/88.5
C210 4030006900 S.CER C1608 JB 1H 103K-T T 68.3/67.4
C211 4030007110 S.CER C1608 CH 1H 680J-T T 72.2/65.8
C212 4030006860 S.CER C1608 JB 1H 102K-T B 67.3/66.0
C213 4030006860 S.CER C1608 JB 1H 102K-T B 67.3/63.7
C214 4030006900 S.CER C1608 JB 1H 103K-T T 63.9/66.3
C215 4030007120 S.CER C1608 CH 1H 820J-T B 55.2/73.3
C216 4030007120 S.CER C1608 CH 1H 820J-T B 55.2/65.3
C217 4030011340 S.CER C1608 CH 1H 471J-T T 72.2/64.6
C218 4030007110 S.CER C1608 CH 1H 680J-T T 69.5/64.6
C290 4030007100 S.CER C1608 CH 1H 560J-T T 89.4/61.6
C291 4030007000 S.CER C1608 CH 1H 090D-T T 88.6/63.5
C292 4030007120 S.CER C1608 CH 1H 820J-T T 87.9/61.6
C293 4030007050 S.CER C1608 CH 1H 220J-T T 86.4/62.7
C294 4030007080 S.CER C1608 CH 1H 390J-T T 84.8/59.3
C295 4030007100 S.CER C1608 CH 1H 560J-T T 80.9/61.3
C296 4030011340 S.CER C1608 CH 1H 471J-T T 77.9/59.1
C297 4030007070 S.CER C1608 CH 1H 330J-T T 75.9/59.8
C298 4030007150 S.CER C1608 CH 1H 151J-T T 75.9/58.5
C299 4030007110 S.CER C1608 CH 1H 680J-T T 73.3/59.8
C316 4510008540 S.ELE EEE1CA100SR T 141.3/4.1
C317 4030011600 S.CER C1608 JB 1E 104K-T B 141.0/6.0
C318 4030011600 S.CER C1608 JB 1E 104K-T B 141.0/3.4
C319 4510008500 S.ELE EEE1CA101WP T 147.3/5.2
C321 4030011600 S.CER C1608 JB 1E 104K-T T 59.8/62.2
C322 4030011600 S.CER C1608 JB 1E 104K-T B 64.0/57.7
C323 4030007000 S.CER C1608 CH 1H 090D-T T 60.5/54.9
C324 4030006900 S.CER C1608 JB 1H 103K-T T 64.1/55.7
C380 4030006900 S.CER C1608 JB 1H 103K-T T 32.0/76.9
C381 4030006860 S.CER C1608 JB 1H 102K-T T 30.2/68.5
C382 4030006860 S.CER C1608 JB 1H 102K-T T 28.4/68.5
C383 4030006860 S.CER C1608 JB 1H 102K-T T 26.6/75.3
C384 4030006860 S.CER C1608 JB 1H 102K-T T 32.0/75.3
C400 4030006900 S.CER C1608 JB 1H 103K-T T 42.2/68.0
C401 4030009910 S.CER C1608 CH 1H 040B-T T 44.5/56.4
C402 4030007030 S.CER C1608 CH 1H 150J-T T 40.8/49.6
C403 4030009910 S.CER C1608 CH 1H 040B-T T 43.9/46.6
C404 4030006900 S.CER C1608 JB 1H 103K-T T 42.8/34.9
C405 4030007060 S.CER C1608 CH 1H 270J-T T 44.5/57.6
C406 4030011770 S.CER C1608 CH 1H 060B-T T 40.8/53.4
C407 4030007060 S.CER C1608 CH 1H 270J-T T 43.9/45.4
C420 4030006900 S.CER C1608 JB 1H 103K-T T 33.1/70.2
C421 4030009920 S.CER C1608 CH 1H 050B-T T 35.9/58.6
C422 4030007020 S.CER C1608 CH 1H 120J-T T 35.9/59.8
C423 4030009920 S.CER C1608 CH 1H 050B-T T 32.2/55.6
C424 4030009920 S.CER C1608 CH 1H 050B-T T 32.2/51.8
C425 4030009920 S.CER C1608 CH 1H 050B-T T 35.3/48.8
C426 4030007020 S.CER C1608 CH 1H 120J-T T 35.3/47.6
C427 4030006900 S.CER C1608 JB 1H 103K-T T 35.6/36.6
C440 4030006900 S.CER C1608 JB 1H 103K-T T 26.0/68.5
C441 4030006980 S.CER C1608 CH 1H 070D-T T 27.3/57.6
C442 4030011770 S.CER C1608 CH 1H 060B-T T 27.3/56.4
C443 4030011770 S.CER C1608 CH 1H 060B-T T 23.5/53.4
C444 4030009540 S.CER C1608 CH 1H 1R5B-T T 23.5/49.6
C445 4030011770 S.CER C1608 CH 1H 060B-T T 26.7/46.6
C446 4030006980 S.CER C1608 CH 1H 070D-T T 26.7/45.4
C447 4030006900 S.CER C1608 JB 1H 103K-T T 25.6/35.2
C460 4030006900 S.CER C1608 JB 1H 103K-T T 22.5/73.8
C461 4030006900 S.CER C1608 JB 1H 103K-T T 16.4/70.7
C462 4030009910 S.CER C1608 CH 1H 040B-T T 18.7/58.6
C463 4030009510 S.CER C1608 CH 1H 010B-T T 15.0/55.6
C464 4030009910 S.CER C1608 CH 1H 040B-T T 18.1/48.8
C465 4030006900 S.CER C1608 JB 1H 103K-T T 18.4/36.6
C466 4030006900 S.CER C1608 JB 1H 103K-T T 20.8/30.6
C467 4030011770 S.CER C1608 CH 1H 060B-T T 18.7/59.8
C468 4030009570 S.CER C1608 CH 1H 0R3B-T T 15.0/51.8
C469 4030011770 S.CER C1608 CH 1H 060B-T T 18.1/47.6
C480 4030006860 S.CER C1608 JB 1H 102K-T B 9.6/75.8
C481 4030006860 S.CER C1608 JB 1H 102K-T B 10.6/68.9
C482 4030006900 S.CER C1608 JB 1H 103K-T T 11.6/68.1
C483 4030009560 S.CER C1608 CH 1H R75B-T T 10.1/56.4
C484 4030007050 S.CER C1608 CH 1H 220J-T T 7.7/63.4
C485 4030009560 S.CER C1608 CH 1H R75B-T T 9.5/46.6
C486 4030006900 S.CER C1608 JB 1H 103K-T T 11.3/35.2
C487 4030006860 S.CER C1608 JB 1H 102K-T B 11.4/32.7
C488 4030006860 S.CER C1608 JB 1H 102K-T B 18.1/33.8
C490 4030007050 S.CER C1608 CH 1H 220J-T T 11.9/40.0
C492 4030006900 S.CER C1608 JB 1H 103K-T B 6.5/72.4
C493 4030006900 S.CER C1608 JB 1H 103K-T B 7.2/69.1
C500 4030006860 S.CER C1608 JB 1H 102K-T B 28.0/35.8
C501 4030006860 S.CER C1608 JB 1H 102K-T B 28.0/31.5
C502 4030006860 S.CER C1608 JB 1H 102K-T B 26.0/31.5
C503 4030006860 S.CER C1608 JB 1H 102K-T B 26.0/35.8
C504 4030006900 S.CER C1608 JB 1H 103K-T T 26.3/28.9
C520 4030010000 S.CER C1608 CH 1H 510J-T T 20.1/23.2
C521 4030007140 S.CER C1608 CH 1H 121J-T T 18.1/23.2
C523 4030006900 S.CER C1608 JB 1H 103K-T T 15.7/21.1
C550 4030011600 S.CER C1608 JB 1E 104K-T B 4.4/10.8
C551 4030011600 S.CER C1608 JB 1E 104K-T B 6.2/10.8
C552 4030007010 S.CER C1608 CH 1H 100D-T B 10.2/18.1
C553 4030006900 S.CER C1608 JB 1H 103K-T B 3.7/16.4
C580 4030006980 S.CER C1608 CH 1H 070D-T B 10.7/12.0
C581 4030006900 S.CER C1608 JB 1H 103K-T B 10.7/10.2
C582 4030006900 S.CER C1608 JB 1H 103K-T B 10.7/5.2
C583 4030007080 S.CER C1608 CH 1H 390J-T B 24.5/8.3
C584 4030017810 S.CER C1608 CH 1H 102J-T B 18.7/7.1
C585 4030006960 S.CER C1608 CH 1H 050C-T B 27.8/10.9
C602 4030006900 S.CER C1608 JB 1H 103K-T T 39.2/5.5
C611 4030007060 S.CER C1608 CH 1H 270J-T T 35.7/3.3
C612 4030010760 S.CER C1608 CH 1H 331J-T T 34.5/3.3
C613 4030007130 S.CER C1608 CH 1H 101J-T T 31.0/8.1
C614 4030007130 S.CER C1608 CH 1H 101J-T T 31.0/3.6
C620 4030006860 S.CER C1608 JB 1H 102K-T B 19.4/9.0
C621 4030011600 S.CER C1608 JB 1E 104K-T B 19.5/3.9
C622 4030011600 S.CER C1608 JB 1E 104K-T T 26.9/4.5
C623 4550003210 S.TAN TEESVD2 1D 226M12R T 87.9/5.3
C624 4030011600 S.CER C1608 JB 1E 104K-T B 82.6/7.1
C625 4030011600 S.CER C1608 JB 1E 104K-T B 82.7/4.2
(Amended page)
October 2016

18
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[RF-A UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
C626 4510008540 S.ELE EEE1CA100SR T 93.2/5.4
C640 4030011600 S.CER C1608 JB 1E 104K-T T 45.8/6.9
C642 4030007100 S.CER C1608 CH 1H 560J-T T 43.4/4.3
C643 4510008540 S.ELE EEE1CA100SR T 52.1/5.9
C644 4030006990 S.CER C1608 CH 1H 080D-T T 44.6/4.3
C660 4030007100 S.CER C1608 CH 1H 560J-T T 49.9/2.4
C671 4030007110 S.CER C1608 CH 1H 680J-T T 58.6/4.5
C672 4030011600 S.CER C1608 JB 1E 104K-T T 58.0/6.3
C673 4030011600 S.CER C1608 JB 1E 104K-T T 58.0/9.0
C701 4030006900 S.CER C1608 JB 1H 103K-T B 64.9/8.6
C705 4030006900 S.CER C1608 JB 1H 103K-T B 57.5/5.9
C706 4030006900 S.CER C1608 JB 1H 103K-T T 63.1/3.8
C707 4030006900 S.CER C1608 JB 1H 103K-T T 63.2/7.6
C708 4030006900 S.CER C1608 JB 1H 103K-T T 66.1/5.1
C709 4030007080 S.CER C1608 CH 1H 390J-T T 66.6/3.0
C710 4030007110 S.CER C1608 CH 1H 680J-T T 65.3/3.0
C730 4030007120 S.CER C1608 CH 1H 820J-T T 47.4/20.8
C731 4030007020 S.CER C1608 CH 1H 120J-T T 49.3/21.3
C732 4030007140 S.CER C1608 CH 1H 121J-T T 47.4/22.0
C733 4030007070 S.CER C1608 CH 1H 330J-T T 50.5/23.3
C734 4030007110 S.CER C1608 CH 1H 680J-T T 48.0/24.7
C735 4030011600 S.CER C1608 JB 1E 104K-T T 38.1/24.1
C736 4030007050 S.CER C1608 CH 1H 220J-T T 46.6/24.7
C737 4030007110 S.CER C1608 CH 1H 680J-T T 42.5/24.8
C738 4030006900 S.CER C1608 JB 1H 103K-T T 38.1/18.7
C740 4030006900 S.CER C1608 JB 1H 103K-T T 38.1/21.4
C800 4030006900 S.CER C1608 JB 1H 103K-T T 108.4/11.2
C801 4030011340 S.CER C1608 CH 1H 471J-T B 116.3/8.3
C802 4030006900 S.CER C1608 JB 1H 103K-T B 150.9/9.1
C803 4030011340 S.CER C1608 CH 1H 471J-T B 118.5/8.3
C804 4030006900 S.CER C1608 JB 1H 103K-T T 151.6/35.0
C805 4030011340 S.CER C1608 CH 1H 471J-T B 121.3/9.5
C806 4030011600 S.CER C1608 JB 1E 104K-T T 155.6/46.8
C807 4030011600 S.CER C1608 JB 1E 104K-T T 155.6/39.0
C850 4510008540 S.ELE EEE1CA100SR T 154.6/12.1
C851 4030011600 S.CER C1608 JB 1E 104K-T B 154.7/11.7
C852 4030011600 S.CER C1608 JB 1E 104K-T B 154.4/18.3
C853 4510008500 S.ELE EEE1CA101WP T 153.9/18.2
C903 4030011600 S.CER C1608 JB 1E 104K-T T 137.1/16.0
C905 4030011600 S.CER C1608 JB 1E 104K-T B 142.5/21.6
C950 4030017810 S.CER C1608 CH 1H 102J-T T 130.3/23.6
C951 4030011600 S.CER C1608 JB 1E 104K-T T 133.6/12.3
C952 4030011600 S.CER C1608 JB 1E 104K-T T 128.5/20.1
C956 4030011600 S.CER C1608 JB 1E 104K-T T 137.3/34.1
C957 4030011600 S.CER C1608 JB 1E 104K-T T 129.2/28.0
C1000 4030007050 S.CER C1608 CH 1H 220J-T B 147.9/32.0
C1001 4030011600 S.CER C1608 JB 1E 104K-T B 145.3/29.3
C1002 4510008500 S.ELE EEE1CA101WP T 142.4/26.3
C1003 4510008500 S.ELE EEE1CA101WP T 142.3/33.7
C1004 4030017870 S.CER C1608 CH 1H 681J-T B 141.5/27.8
C1005 4030011600 S.CER C1608 JB 1E 104K-T B 137.2/33.9
C1011 4030007110 S.CER C1608 CH 1H 680J-T T 66.1/7.7
C1012 4030006900 S.CER C1608 JB 1H 103K-T T 66.1/9.0
C1013 4030011600 S.CER C1608 JB 1E 104K-T T 64.8/13.0
C1014 4030011600 S.CER C1608 JB 1E 104K-T T 72.7/12.2
C1015 4030011600 S.CER C1608 JB 1E 104K-T T 66.9/15.2
C1016 4030006900 S.CER C1608 JB 1H 103K-T T 72.0/14.7
C1021 4030006900 S.CER C1608 JB 1H 103K-T T 74.4/22.5
C1022 4030011600 S.CER C1608 JB 1E 104K-T T 68.2/20.5
C1023 4030011600 S.CER C1608 JB 1E 104K-T T 70.6/25.5
C1024 4030011600 S.CER C1608 JB 1E 104K-T T 64.2/20.0
C1025 4030006900 S.CER C1608 JB 1H 103K-T T 66.2/25.7
C1030 4510008540 S.ELE EEE1CA100SR T 76.4/43.8
C1031 4030011600 S.CER C1608 JB 1E 104K-T B 76.5/40.3
C1032 4030011600 S.CER C1608 JB 1E 104K-T B 72.5/47.1
C1033 4510008540 S.ELE EEE1CA100SR T 71.5/44.2
C1034 4030011600 S.CER C1608 JB 1E 104K-T T 69.0/35.3
C1035 4030007120 S.CER C1608 CH 1H 820J-T T 70.4/36.5
C1036 4510008500 S.ELE EEE1CA101WP T 58.8/28.0
C1037 4030011600 S.CER C1608 JB 1E 104K-T T 67.8/32.7
C1038 4030006860 S.CER C1608 JB 1H 102K-T T 70.4/32.0
C1039 4030011600 S.CER C1608 JB 1E 104K-T T 77.0/34.2
C1040 4030011600 S.CER C1608 JB 1E 104K-T T 77.0/35.4
C1041 4030006900 S.CER C1608 JB 1H 103K-T T 73.8/30.5
C1044 4030011600 S.CER C1608 JB 1E 104K-T B 74.3/29.4
C1047 4030008880 S.CER C1608 JB 1H 223K-T B 73.9/39.0
C1048 4510008540 S.ELE EEE1CA100SR T 66.7/43.9
C1049 4030007130 S.CER C1608 CH 1H 101J-T B 75.7/37.4
C1050 4030008880 S.CER C1608 JB 1H 223K-T B 71.3/29.4
C1060 4030011600 S.CER C1608 JB 1E 104K-T B 132.0/36.0
C1061 4030007150 S.CER C1608 CH 1H 151J-T B 118.7/34.1
C1063 4030017870 S.CER C1608 CH 1H 681J-T B 118.7/29.3
C1064 4030011330 S.CER C1608 CH 1H 391J-T B 118.7/27.7
C1065 4510008500 S.ELE EEE1CA101WP T 121.9/37.1
C1066 4030011600 S.CER C1608 JB 1E 104K-T T 124.5/31.5
C1067 4030011600 S.CER C1608 JB 1E 104K-T B 131.6/31.4
C1068 4510008500 S.ELE EEE1CA101WP T 122.6/27.3
C1090 4030007050 S.CER C1608 CH 1H 220J-T T 115.6/45.0
C1091 4030007050 S.CER C1608 CH 1H 220J-T B 128.2/19.6
C1092 4030011600 S.CER C1608 JB 1E 104K-T B 115.6/45.2
C1093 4030011600 S.CER C1608 JB 1E 104K-T B 128.3/17.1
C1094 4510008540 S.ELE EEE1CA100SR T 112.5/45.3
C1095 4510008540 S.ELE EEE1CA100SR T 124.8/17.5
C1096 4510008540 S.ELE EEE1CA100SR T 107.5/45.4
C1097 4030007110 S.CER C1608 CH 1H 680J-T B 122.8/21.5
C1098 4030007110 S.CER C1608 CH 1H 680J-T B 110.0/41.5
C1099 4510008540 S.ELE EEE1CA100SR T 119.9/17.5
C1100 4030011600 S.CER C1608 JB 1E 104K-T B 107.7/48.8
C1101 4030011600 S.CER C1608 JB 1E 104K-T B 119.1/21.9
C1200 4030011600 S.CER C1608 JB 1E 104K-T B 101.2/42.9
C1201 4510008540 S.ELE EEE1CA100SR T 94.8/45.8
C1202 4030008880 S.CER C1608 JB 1H 223K-T B 99.3/47.5
C1203 4030008880 S.CER C1608 JB 1H 223K-T B 112.8/17.9
C1204 4030010760 S.CER C1608 CH 1H 331J-T B 99.6/42.9
C1205 4030010760 S.CER C1608 CH 1H 331J-T B 101.2/13.6
C1206 4030007010 S.CER C1608 CH 1H 100D-T B 92.8/47.3
C1207 4030007010 S.CER C1608 CH 1H 100D-T B 95.5/10.8
C1208 4030017480 S.CER C1608 JB 1A 474K-T B 96.2/42.9
C1209 4030017480 S.CER C1608 JB 1A 474K-T B 97.4/14.3
C1210 4030006900 S.CER C1608 JB 1H 103K-T B 94.6/42.9
C1211 4030006900 S.CER C1608 JB 1H 103K-T B 99.3/14.3
C1212 4550007660 S.TAN F931E105MAABMA B 87.7/44.4
C1213 4550007660 S.TAN F931E105MAABMA B 87.3/13.5
C1214 4030018640 S.CER C2012 CH 1H 103J-T B 88.5/35.5
C1215 4030018640 S.CER C2012 CH 1H 103J-T B 88.5/21.0
C1216 4030011600 S.CER C1608 JB 1E 104K-T B 101.2/8.9
C1255 4030007120 S.CER C1608 CH 1H 820J-T B 79.2/28.5
C1256 4030007120 S.CER C1608 CH 1H 820J-T B 79.3/20.8
C1310 4030006900 S.CER C1608 JB 1H 103K-T B 85.8/30.9
C1311 4030011600 S.CER C1608 JB 1E 104K-T T 90.4/32.3
C1312 4030017810 S.CER C1608 CH 1H 102J-T B 99.2/35.7
C1313 4030017810 S.CER C1608 CH 1H 102J-T B 98.6/21.1
C1314 4610001970 S.TRI TZC3P200A110R00 T 85.5/29.3
C1315 4030007050 S.CER C1608 CH 1H 220J-T T 85.5/25.8
C1316 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/28.3
C1317 4030011600 S.CER C1608 JB 1E 104K-T B 94.2/24.7
C1318 4030006900 S.CER C1608 JB 1H 103K-T B 102.2/30.2
C1319 4550007200 S.TAN F930J476MBABMA B 91.3/28.4
C1320 4030006900 S.CER C1608 JB 1H 103K-T B 93.6/32.3
RL20 6330002020 REL FTR-B4CA009Z
RL21 6330002020 REL FTR-B4CA009Z
RL90 6330002020 REL FTR-B4CA009Z
RL91 6330002020 REL FTR-B4CA009Z
J1 6510028210 CON SJ050010
J2 6510028210 CON SJ050010
J190 6510028210 CON SJ050010
J210 6510028210 CON SJ050010
J290 6510028210 CON SJ050010
J500 6510028210 CON SJ050010
J671 6510028210 CON SJ050010
J730 6510028210 CON SJ050010
J800 6510019981 S.CON 52808-1671 T 116.0/5.8
J900 6510018961 S.CON B2B-PH-SM4-TB T 152.9/27.8
J1310 6510028210 CON SJ050010
EP130 6910014730 S.BEA MPZ2012S331A-T B 91.1/75.4
EP800 6910015970 S.BEA MMZ1608B 301CT-AS T 115.5/10.4
EP801 6910015970 S.BEA MMZ1608B 301CT-AS T 116.7/10.4
EP802 6910015970 S.BEA MMZ1608B 301CT-AS T 117.9/10.4
EP803 6910015970 S.BEA MMZ1608B 301CT-AS T 112.5/10.4
EP804 6910015970 S.BEA MMZ1608B 301CT-AS T 114.3/10.4
EP805 6910014730 S.BEA MPZ2012S331A-T B 108.5/11.4
(Amended page)
October 2016

19
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF-B UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
[RF-B UNIT]
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
IC801 1110006180 S.IC UPG2009TB-E3 T 43.1/114.5
IC802 1110006180 S.IC UPG2009TB-E3 T 41.8/80.8
IC1201 1110006970 S.IC MAALSS0038TR-3000 T 29.8/99.0
IC1202 1110007090 S.IC NJG1608KB2-TE1-#ZZZB T 26.3/58.2
IC1203 1110007090 S.IC NJG1608KB2-TE1-#ZZZB T 29.7/71.3
IC1204 1110007090 S.IC NJG1608KB2-TE1-#ZZZB T 29.7/65.4
IC1241 1110006970 S.IC MAALSS0038TR-3000 T 44.5/70.3
IC1251 1110006970 S.IC MAALSS0038TR-3000 T 51.6/64.0
IC1302 1110006970 S.IC MAALSS0038TR-3000 T 103.1/9.9
IC1601 1180001072 S.IC TA7805F (TE16L1NQ) B 8.3/110.8
IC1602 1180001072 S.IC TA7805F (TE16L1NQ) B 152.6/28.7
IC1603 1130011530 S.IC CD74HC4094M96 B 135.5/54.7
IC1604 1130011530 S.IC CD74HC4094M96 B 135.5/42.9
IC1605 1130011530 S.IC CD74HC4094M96 B 7.4/79.9
IC1607 1130005721 S.IC TC7W04F (TE12LF) T 99.5/51.6
IC1608 1180001252 S.IC TA7808F (TE16L1NQ) B 161.1/41.1
IC1701 1110002700 S.IC NJM2904M-TE1-#FMZB T 86.6/50.8
IC1703 1160000132 S.IC TD62783AFG (OSEL) T 123.4/52.9
IC5004 1180002770 S.REG BAJ0CC0FP-E2 B 151.5/63.2
Q1201 1590003630 S.TRA EMD29-T2R T 22.5/92.5
Q1202 1590003940 S.TRA RN1105 (TE85LF) T 18.3/78.3
Q1241 1590003630 S.TRA EMD29-T2R T 56.9/71.2
Q1251 1590004030 S.TRA KRX204U-RTK/P T 74.2/52.2
Q1252 1590004030 S.TRA KRX204U-RTK/P T 74.2/49.1
Q1253 1590004030 S.TRA KRX204U-RTK/P T 74.2/45.9
Q1254 1590003630 S.TRA EMD29-T2R T 74.1/55.0
Q1302 1590004030 S.TRA KRX204U-RTK/P T 106.9/23.1
Q1304 1590004030 S.TRA KRX204U-RTK/P T 104.4/23.1
Q1401 1590004030 S.TRA KRX204U-RTK/P T 135.3/39.2
Q1402 1590004030 S.TRA KRX204U-RTK/P T 130.3/39.2
Q1403 1590004030 S.TRA KRX204U-RTK/P T 132.8/39.2
Q1601 1550000090 S.FET RSQ035P03TR T 154.2/37.6
Q1602 1590003940 S.TRA RN1105 (TE85LF) T 160.1/39.1
D101 1790001622 S.DIO 1SV308L3F B 139.2/112.5
D106 1790001622 S.DIO 1SV308L3F B 136.8/72.7
D201 1790001622 S.DIO 1SV308L3F B 137.5/111.7
D206 1790001622 S.DIO 1SV308L3F B 134.8/73.5
D301 1790001622 S.DIO 1SV308L3F B 123.5/111.7
D306 1790001622 S.DIO 1SV308L3F B 121.7/73.5
D401 1790001622 S.DIO 1SV308L3F B 108.3/111.7
D407 1790001622 S.DIO 1SV308L3F B 108.8/73.5
D501 1790001622 S.DIO 1SV308L3F B 94.5/111.7
D507 1790001622 S.DIO 1SV308L3F B 95.2/73.5
D601 1790001622 S.DIO 1SV308L3F B 82.2/111.7
D606 1790001622 S.DIO 1SV308L3F B 79.2/72.8
D607 1790001622 S.DIO 1SV308L3F B 84.8/112.5
D608 1790001622 S.DIO 1SV308L3F B 82.5/72.0
D701 1790001622 S.DIO 1SV308L3F B 75.8/112.5
D702 1790001622 S.DIO 1SV308L3F B 74.0/111.7
D707 1790001622 S.DIO 1SV308L3F B 67.5/73.3
D708 1790001622 S.DIO 1SV308L3F B 67.5/72.0
D802 1790001622 S.DIO 1SV308L3F B 59.6/111.1
D809 1790001622 S.DIO 1SV308L3F B 55.6/76.9
D831 1750002520 S.DIO RN739FT106 B 42.8/75.2
D1204 1750001051 S.VAR HVC417CTRU-E T 25.4/80.2
D1205 1750001051 S.VAR HVC417CTRU-E T 22.9/80.2
D1206 1750001051 S.VAR HVC417CTRU-E T 26.6/81.6
D1207 1750001051 S.VAR HVC417CTRU-E T 22.9/81.6
D1251 1790001622 S.DIO 1SV308L3F T 63.1/60.6
D1252 1790001622 S.DIO 1SV308L3F T 61.8/60.6
D1253 1790001622 S.DIO 1SV308L3F T 60.5/60.6
D1256 1720000261 S.VAR 1SV214 (TPH2F) T 44.2/48.7
D1257 1720000261 S.VAR 1SV214 (TPH2F) T 45.8/46.4
D1258 1790001622 S.DIO 1SV308L3F T 61.2/45.9
D1259 1790001622 S.DIO 1SV308L3F T 59.2/46.7
D1260 1790001622 S.DIO 1SV308L3F T 39.8/47.1
D1261 1790001622 S.DIO 1SV308L3F T 39.8/45.9
D1301 1790001622 S.DIO 1SV308L3F B 63.7/20.1
D1302 1790001622 S.DIO 1SV308L3F T 62.4/22.8
D1303 1790001622 S.DIO 1SV308L3F B 98.8/13.2
D1304 1790001622 S.DIO 1SV308L3F B 100.6/14.0
D1601 1750001850 S.DIO LDAN222T1G T 142.6/42.5
D1602 1750001850 S.DIO LDAN222T1G T 107.4/46.0
D1603 1750001850 S.DIO LDAN222T1G T 102.1/45.8
FI1315 4580000210 FIL FL-403
FI1316 4580000210 FIL FL-403
L101 6200003261 S.COI NLV32T-101J-PF B 153.6/107.0
L102 6200010530 S.COI C2520C-R56G-A (0.56U) T 152.1/104.5
L103 6200011450 S.COI C2520C-R39G-A T 151.5/100.8
L104 6200010870 S.COI C2520C-R33G-A (0.33U) T 152.1/97.2
L105 6200010670 S.COI C2520C-R18G-A (0.18U) T 147.8/91.5
L106 6200010660 S.COI C2520C-R15G-A (0.15U) T 148.5/88.0
L107 6200010860 S.COI C2520C-R10G-A (0.1U) T 148.2/84.1
L110 6200003261 S.COI NLV32T-101J-PF B 151.1/77.7
L201 6200003261 S.COI NLV32T-101J-PF B 140.3/107.0
L202 6200010870 S.COI C2520C-R33G-A (0.33U) T 139.0/104.6
L203 6200010680 S.COI C2520C-R22G-A (0.22U) T 138.4/100.8
L204 6200010670 S.COI C2520C-R18G-A (0.18U) T 138.8/97.1
L205 6200010650 S.COI C2520C-R12G-A (0.12U) T 134.6/91.4
L206 6200010860 S.COI C2520C-R10G-A (0.1U) T 135.4/87.9
L207 6200010730 S.COI C2520C-68NG-A T 134.8/84.1
L210 6200003261 S.COI NLV32T-101J-PF B 137.6/78.3
L301 6200003261 S.COI NLV32T-101J-PF B 126.5/107.0
L302 6200010670 S.COI C2520C-R18G-A (0.18U) T 125.1/104.5
L303 6200010650 S.COI C2520C-R12G-A (0.12U) T 124.7/100.8
L304 6200010650 S.COI C2520C-R12G-A (0.12U) T 125.3/97.0
L305 6200012990 S.COI 0.25-1.9-9TL 84.0N T 120.6/91.5
L306 6200012450 S.COI 0.25-1.9-8TL 73N (COAT) T 121.4/87.8
L307 6200010720 S.COI C2520C-56NG-A T 121.1/84.1
L310 6200003261 S.COI NLV32T-101J-PF B 124.2/78.4
L401 6200001831 S.COI NLV32T-100J-PF B 111.3/106.9
L402 6200010670 S.COI C2520C-R18G-A (0.18U) T 110.0/104.4
L403 6200010860 S.COI C2520C-R10G-A (0.1U) T 110.7/100.8
L404 6200011410 S.COI C2520C-82NG-A T 110.0/97.1
L405 6200010720 S.COI C2520C-56NG-A T 106.9/90.1
L406 6200011800 S.COI C2520C-47NG-A T 107.7/86.5
L407 6200012360 S.COI C2520C-33NG-A T 107.3/82.8
L411 6200001831 S.COI NLV32T-100J-PF B 111.8/77.9
L501 6200001831 S.COI NLV32T-100J-PF B 97.4/107.1
L502 6200011410 S.COI C2520C-82NG-A T 96.1/104.5
L503 6200010720 S.COI C2520C-56NG-A T 96.8/100.8
L504 6200011800 S.COI C2520C-47NG-A T 96.2/97.1
L505 6200012360 S.COI C2520C-33NG-A T 92.9/90.2
L506 6200010760 S.COI C2520C-27NG-A T 93.7/86.4
L507 6200010590 S.COI C2520C-22NG-A T 93.7/82.7
L511 6200001831 S.COI NLV32T-100J-PF B 96.6/79.7
L601 6200003331 S.COI NLV32T-1R0J-PF B 86.9/107.2
L602 6200010940 S.COI C2520C-39NG-A T 79.7/105.9
L603 6200010760 S.COI C2520C-27NG-A T 80.3/101.9
L604 6200010760 S.COI C2520C-27NG-A T 79.3/98.1
L605 6200010760 S.COI C2520C-27NG-A T 82.8/94.1
L606 6200010590 S.COI C2520C-22NG-A T 82.9/87.7
L607 6200010030 S.COI C2012C-15NG-A T 82.4/84.1
L611 6200003331 S.COI NLV32T-1R0J-PF B 84.4/76.4
L701 6200010760 S.COI C2520C-27NG-A T 64.9/105.7
L702 6200003331 S.COI NLV32T-1R0J-PF B 73.5/105.7
L703 6200010590 S.COI C2520C-22NG-A T 66.2/101.8
L704 6200012140 S.COI C2520C-18NG-A T 65.0/97.9
L705 6200012140 S.COI C2520C-18NG-A T 68.2/94.3
L706 6200010030 S.COI C2012C-15NG-A T 67.7/87.8
L707 6200011690 S.COI C2520C-12NG-A T 67.9/83.8
L713 6200003331 S.COI NLV32T-1R0J-PF B 71.2/77.0
L801 6200003331 S.COI NLV32T-1R0J-PF B 59.5/105.4
L802 6200009070 S.COI LQW18AN18NG00D T 52.5/104.7
L803 6200009220 S.COI LQW18AN15NG00D T 52.9/101.4
L804 6200010700 S.COI LQW18AN12NG00D T 52.2/98.3
L805 6200010700 S.COI LQW18AN12NG00D T 56.8/94.1
L806 6200011730 S.COI LQW18AN10NG00D T 56.1/91.9
L807 6200010130 S.COI LQW18AN6N8C00D T 55.7/88.6
L811 6200003331 S.COI NLV32T-1R0J-PF B 56.5/80.0
L901 6200009220 S.COI LQW18AN15NG00D T 38.4/104.4
L902 6200011730 S.COI LQW18AN10NG00D T 39.3/101.2
L903 6200010630 S.COI LQW18AN8N2D00D T 38.4/98.1
L904 6200010630 S.COI LQW18AN8N2D00D T 42.9/93.8
L905 6200010130 S.COI LQW18AN6N8C00D T 42.1/91.6
L906 6200010120 S.COI LQW18AN5N6C00D T 41.0/87.4
L1201 6200001831 S.COI NLV32T-100J-PF T 24.6/96.8
L1203 6200005641 S.COI ELJRE 6N8ZFA T 27.9/80.2
L1204 6200005621 S.COI ELJRE 4N7ZFA T 28.7/82.3
L1205 6200006771 S.COI ELJRE 1N5ZFA T 29.3/88.3
L1207 6200006781 S.COI ELJRE 1N8ZFA T 28.7/90.4
L1212 6200010940 S.COI C2520C-39NG-A T 28.3/96.0
L1231 6200005611 S.COI ELJRE 3N9ZFA T 26.5/68.3
L1241 6200010670 S.COI C2520C-R18G-A (0.18U) T 47.4/70.8
L1242 6200001831 S.COI NLV32T-100J-PF T 53.7/71.5
L1251 6200001831 S.COI NLV32T-100J-PF T 58.5/66.8
L1252 6200010670 S.COI C2520C-R18G-A (0.18U) T 54.7/66.1
L1253 6200003331 S.COI NLV32T-1R0J-PF T 51.9/54.7
L1254 6200005701 S.COI ELJRE 22NGFA T 52.4/47.2
L1255 6200005631 S.COI ELJRE 5N6ZFA T 48.5/55.3
L1256 6200005721 S.COI ELJRE 33NGFA T 63.7/53.1
L1257 6200005671 S.COI ELJRE 12NGFA T 59.2/53.1
L1260 6200005731 S.COI ELJRE 39NGFA T 63.0/48.7
L1261 6200005681 S.COI ELJRE 15NGFA T 58.5/48.7
L1262 6200005611 S.COI ELJRE 3N9ZFA T 44.2/51.9
L1263 6200005631 S.COI ELJRE 5N6ZFA T 43.5/54.0
L1264 6200005611 S.COI ELJRE 3N9ZFA T 40.2/53.3
L1265 6200005601 S.COI ELJRE 3N3ZFA T 40.2/49.6
L1266 6200001831 S.COI NLV32T-100J-PF B 66.9/47.6
L1267 6200003331 S.COI NLV32T-1R0J-PF B 62.3/44.8
L1268 6200003331 S.COI NLV32T-1R0J-PF B 39.9/45.1
L1301 6200002631 S.COI NLV25T-R10J-PF B 67.8/15.6
L1302 6200001981 S.COI NLV25T-1R0J-PF B 62.1/29.5
L1303 6200010590 S.COI C2520C-22NG-A T 67.2/19.4
L1304 6200010590 S.COI C2520C-22NG-A T 74.5/19.4
L1305 6200010590 S.COI C2520C-22NG-A T 82.3/19.3
L1306 6200010590 S.COI C2520C-22NG-A T 89.6/19.9
L1307 6200010030 S.COI C2012C-15NG-A T 93.4/24.6
L1308 6200001981 S.COI NLV25T-1R0J-PF B 102.9/18.4
L1309 6200002631 S.COI NLV25T-R10J-PF T 101.0/17.4
L1311 6200007710 S.COI LQW2BHN27NJ03L B 98.4/20.8
L1341 6200010670 S.COI C2520C-R18G-A (0.18U) T 104.0/13.7
L1342 6200001831 S.COI NLV32T-100J-PF T 105.4/17.5
R102 7030003320 S.RES ERJ3GEYJ 101 V (100) B 156.5/102.8
R111 7030003320 S.RES ERJ3GEYJ 101 V (100) B 152.5/75.0
R202 7030003320 S.RES ERJ3GEYJ 101 V (100) B 144.4/104.7
R211 7030003320 S.RES ERJ3GEYJ 101 V (100) B 140.7/77.6
R302 7030003320 S.RES ERJ3GEYJ 101 V (100) B 130.7/104.7
R311 7030003320 S.RES ERJ3GEYJ 101 V (100) B 127.5/77.6
R402 7030003320 S.RES ERJ3GEYJ 101 V (100) B 115.4/104.7
R411 7030003320 S.RES ERJ3GEYJ 101 V (100) B 114.0/75.7
R502 7030003320 S.RES ERJ3GEYJ 101 V (100) B 101.5/104.8
R511 7030003320 S.RES ERJ3GEYJ 101 V (100) B 98.1/76.7
R601 7030003320 S.RES ERJ3GEYJ 101 V (100) B 87.6/102.4
R611 7030003320 S.RES ERJ3GEYJ 101 V (100) B 88.0/76.5
R701 7030003320 S.RES ERJ3GEYJ 101 V (100) B 74.9/102.9
R711 7030003320 S.RES ERJ3GEYJ 101 V (100) B 74.7/76.4
R801 7030009810 S.RES ERJ12YJ821U (820) B 54.6/112.6
(Amended page)
October 2016
