Icom Ic-fr5000 Installation and operating instructions

Addendum |

UC-FR5000/ UC-FR5300 Ribbon Cable Part Number

Part number for the Ribbon (flat) Cable on the UC-FR5000/UC-FR5300 Trunking Controller: 8900010952

SERVICE MANUAL

ADDENDUM

July 2016

[VERSION LIST]

Model Version Version

number

Output

power

(W)

Channel spacing

(kHz)

MAIN

UNIT

MAIN-A

UNIT

MAIN-B

UNIT

IC-FR5000

USA-01 [#01]

6.25/12.5 ✔

EXP-01 [#03]

6.25/12.5/25

✔

CHN-01 [#04]

✔

EXP-11 [#07]*

✔

USA-21 [#14]*

6.25/12.5 ✔

EXP-21 [#15]*

6.25/12.5/25

✔

CHN-21 [#16]*

✔

IC-FR5100

EUR-01 [#22]

6.25/12.5/20/25

✔

EUR-21 [#23]*

✔

DPM-01 [#32] ✔

IC-FR5000 DPM-03 [#33] 50 6.25/12.5/25 ✔

IC-FR5100 DPM-02 [#34] 25 6.25/12.5/20/25

✔

DPM-21 [#35]* ✔

IC-FR5000 DPM-23 [#36]* 50 6.25/12.5/25 ✔

IC-FR5100 DPM-22 [#37]* 25

6.25/12.5/20/25

✔

IC-FR5100H DPM-01 [#81] 50

✔

DPM-21 [#82]* ✔

* Newly added versions.

✔UNIT installed.

NOTE: Use these amended pages as one addendum set.

Do not mix them up with the previous master pages.

CONTENTS

REPLACEMENT PAGES:

MECHANICAL PART . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1 and 8-2

AMENDED PAGES:

ADJUSTMENT PROCEDURE. . . . . . . . . . . . . . . . . . . . . 6-7 to 6-11

PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

BOARD LAYOUTS (MAIN-B UNIT: B-8211B) . . . . . . . . . 11

VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

8-1

SECTION 8 MECHANICAL PARTS

[CHASSIS PARTS]

REF PART DESCRIPTION QTY.

NO. NO.

W1 8920001170 CAB-1147 Only [#07] 1

MP1 8810003361 SET SCREWC M3 X 6 ZC3 4

MP2 8810003361 SET SCREWC M3 X 6 ZC3 1

MP3 8110009330 3063 U-COVER 1

MP4 8110009340 3063 BOTTOM COVER D [#01] 1

8110009340 3063 BOTTOM COVER D [#03] 1

8110009340 3063 BOTTOM COVER D [#04] 1

8110010730 3063 A-BOTTOM COVER [#07] 1

8110009340 3063 BOTTOM COVER D [#14] 1

8110009340 3063 BOTTOM COVER D [#15] 1

8110009340 3063 BOTTOM COVER D [#16] 1

8110009340 3063 BOTTOM COVER D [#22] 1

8110009340 3063 BOTTOM COVER D [#23] 1

8110009340 3063 BOTTOM COVER D [#32] 1

8110009340 3063 BOTTOM COVER D [#33] 1

8110009340 3063 BOTTOM COVER D [#34] 1

8110009340 3063 BOTTOM COVER D [#35] 1

8110009340 3063 BOTTOM COVER D [#36] 1

8110009340 3063 BOTTOM COVER D [#37] 1

8110009340 3063 BOTTOM COVER D [#81] 1

8110009340 3063 BOTTOM COVER D [#82] 1

MP5 8930073980 3063 ANGLE 2

MP6 8930073990 3063 CENTER ANGLE 1

MP7 8810005771 BIND M3 X 8 ZK3BLACK 11

MP9 8810009061 FLAT M3 X 6 ZK3 7

MP10 8810008661 PHBT M3 X 8 NI-ZC3 2

MP11 8810003361 SET SCREWC M3 X 6 ZC3 Only [#82] 6

MP12 8810003361 SET SCREWC M3 X 6 ZC3 Only [#07] 1

MP13 8930091270 3063 PLATE (NC)Y3008 Only [#07] 1

MP14 8810008661 PHBT M3 X 8 NI-ZC3 Only [#07] 2

MP15 8930091280 3063 SHEETOnly [#07] 2

[FRONT UNIT]

REF PART DESCRIPTION QTY.

NO. NO.

J501* 6510019121 S8B-PH-SM4-TB (LF) (SN) 1

J502* 6510019121 S8B-PH-SM4-TB (LF) (SN) 1

J503 6450002210 3017-8821 1

J504* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1

DS500 5030004230 L5-1077TRR 1

DS501 5040002710 EMPG3338S 1

DS502 5040002720 EMVR3338S 1

DS503 5040002710 EMPG3338S 1

DS504 5040002720 EMVR3338S 1

DS511 5040002150 VRPG3349S-734 1

DS512 5040002150 VRPG3349S-734 1

S506 2250000511 RH70N1037E20-13F-2781 1

SP501 2510001910 ND3050GA13Y04 1

MF1 2710001020 MGT6012HR-O15 Only [#07] 1

MF2 2710001020 MGT6012HR-O15 Only [#07] 1

W501 8900011801 OPC-1199A 1

W502 8900017541 OPC-1785-1 1

EP501 8930065150 SRCN-2781-SP-N-W (SHJ) 2

EP503 6910019600 LM-5 2

EP504 6910019610 LM-7 (SPACER) 4

MP501 8930064260 2781 LCD HOLDER Y753 1

MP502 8210021190 2781 REFLECTOR 1

MP503 8610012161 KNOB N-324-1 1

MP504 8610012151 KNOB N-325-1 1

MP507 8930064220 2781 KNOB RUBBER (TOP)S 1

MP508 8930075200 HIMELON SHEET (CY) 2

MP510 8930059001 2601 SP NET-1 1

MP511 8210025550 3063 FRONT PANEL (A) 1

MP512 8930074161 3063 FRONT PLATE-1 [#14] 1

8930074161 3063 FRONT PLATE-1 [#15] 1

8930074161 3063 FRONT PLATE-1 [#16] 1

8930074161 3063 FRONT PLATE-1 [#23] 1

8930074161 3063 FRONT PLATE-1 [#35] 1

8930074161 3063 FRONT PLATE-1 [#36] 1

8930074161 3063 FRONT PLATE-1 [#37] 1

MP513 8310070870 3063 WINDOW PLATE [#01] 1

8310070870 3063 WINDOW PLATE [#03] 1

8310070870 3063 WINDOW PLATE [#04] 1

8310070870 3063 WINDOW PLATE [#07] 1

8310070870 3063 WINDOW PLATE [#14] 1

8310070870 3063 WINDOW PLATE [#15] 1

8310070870 3063 WINDOW PLATE [#16] 1

8310070870 3063 WINDOW PLATE [#22] 1

8310070870 3063 WINDOW PLATE [#23] 1

8310083780 3063 WINDOW PLATE (A) [#32] 1

8310083780 3063 WINDOW PLATE (A) [#33] 1

8310083780 3063 WINDOW PLATE (A) [#34] 1

8310083780 3063 WINDOW PLATE (A) [#35] 1

8310083780 3063 WINDOW PLATE (A) [#36] 1

8310083780 3063 WINDOW PLATE (A) [#37] 1

8310083780 3063 WINDOW PLATE (A) [#81] 1

8310083780 3063 WINDOW PLATE (A) [#82] 1

MP514 8210024431 3063 M-PANEL-1 1

MP515 8930074000 3063 SP ANGLE 1

MP516 8110009350 3063 FRONT COVER Y2145 1

MP517 8930073820 3063 FRONT KEY (SC) 1

MP518 8930073911 3063 M-COVER-1 1

MP519 8930074020 3063 KNOB RUBBER (TOP) 1

MP520 8930075010 3063 A-PACKING (TOP) 1

MP529 8810008661 PHBT M3 X 8 NI-ZC3 6

MP530 8810008661 PHBT M3 X 8 NI-ZC3 2

MP531 8810008661 PHBT M3 X 8 NI-ZC3 4

MP532 8810008661 PHBT M3 X 8 NI-ZC3 6

MP533 8810008661 PHBT M3 X 8 NI-ZC3 [#14] 5

8810008661 PHBT M3 X 8 NI-ZC3 [#15] 5

8810008661 PHBT M3 X 8 NI-ZC3 [#16] 5

8810008661 PHBT M3 X 8 NI-ZC3 [#23] 5

8810008661 PHBT M3 X 8 NI-ZC3 [#35] 5

8810008661 PHBT M3 X 8 NI-ZC3 [#36] 5

8810008661 PHBT M3 X 8 NI-ZC3 [#37] 5

MP534 8810010780 PH BT M3 X20 NI-ZK3 Only [#07] 4

MP535 8930091230 3705 FRONT NET Only [#07] 1

MP536 8930091630 2781 LCD FILTER 1

*: Refer to “BOARD LAYOUTS” for the location.

(Replacement page)

[CONNECT UNIT]

[FAN UNIT]

REF PART DESCRIPTION QTY.

NO. NO.

REF PART DESCRIPTION QTY.

NO. NO.

J601* 6510027920 IMSA-9631S-28Y934 1

J602 6510023210 CD6125SA1J0 1

S1* 2260003070 MINISMDC150F/24-2 1

W601 8900017500 OPC-1852 (P0.5N28L90) 1

J1 6510011441 B4P-VH (LF) (SN) 1

J2 6510009371 B4B-ZR (LF) (SN) 1

J3 6510009371 B4B-ZR (LF) (SN) 1

MP1 8930073170 SPONGE (JQ) 1

July 2016

July 2016 (Amended page)

[MAIN-B UNIT]

REF PART DESCRIPTION QTY.

NO. NO.

J1* 6510026770 AXK540147YG 1

J2* 6510023092 20FLT-SM2-TB (LF) (SN) (M) 1

J4* 6510023512 28FLT-SM2-TB (LF) (SN) (M) 1

J5 6510023110 3008L-8P8C 1

J6 6450002470 JY-3510A*01-130 1

J8* 6510023092 20FLT-SM2-TB (LF) (SN) (M) 1

J9* 6510019371 B3B-ZR-SM4-TF (LF) (SN) 1

J10 6510004910 NR-DS-E 01 1

J11 6510004910 NR-DS-E 01 1

J12* 6510025970 41-002AA-R 1

MF1 2710000870 AFB0512HB-7X22 HK 1

W1 7030014230 RJ20S0OHM 1

W2 7030014230 RJ20S0OHM 1

W4 8920000830 CAB-1116 1

W5 8900020500 OPC-2249 [#37] 1

8900020500 OPC-2249 [#82] 1

EP10 6910011560 HF70BB4.5X5X1.6 2

EP13 6910011330 OT-009 M3 1

EP14 6910011330 OT-009 M3 1

MP1 8510018070 2979 VCO CASE Y1005 1

MP2 8510018060 2979 VCO COVER Y1006 1

MP3 8510018070 2979 VCO CASE Y1005 1

MP4 8510018060 2979 VCO COVER Y1006 1

MP5 8210024440 3063 SUB M-PANEL 1

MP6 8310070880 3063 S-LED PLATE [#07] 1

8310070880 3063 S-LED PLATE [#14] 1

8310070880 3063 S-LED PLATE [#15] 1

8310070880 3063 S-LED PLATE [#16] 1

8310070880 3063 S-LED PLATE [#23] 1

8310083910 3063 S-LED PLATE (B) [#35] 1

8310083910 3063 S-LED PLATE (B) [#36] 1

8310083910 3063 S-LED PLATE (B) [#37] 1

8310083910 3063 S-LED PLATE (B) [#82] 1

MP7 8930073920 3063 SP COVER 1

MP8 8010020981 3063 CHASSIS-1 1

MP9 8110009360 3063 SU-COVER 1

MP10 8110009370 3063 SL-COVER 1

MP11 8930074300 3063 PC PLATE [#07] 1

8930074300 3063 PC PLATE [#14] 1

8930074300 3063 PC PLATE [#15] 1

8930074300 3063 PC PLATE [#16] 1

8930074300 3063 PC PLATE [#23] 1

8930074300 3063 PC PLATE [#35] 1

8930074300 3063 PC PLATE [#36] 1

8930085080 3063 IF PLATE [#37] 1

8930085080 3063 IF PLATE [#82] 1

MP12 8930074180 O-RING (BR) (TOP) 1

MP13 8930075020 3063 B-PACKING (TOP) 1

MP14 8930075030 3063 C-PACKING (TOP) 1

MP15 8930073930 3063 SP RUBBER (TOP) 1

MP17 8930062160 HIMELON SHEET (CL) 1

MP18 8930079651 2979 D-SUB PLATE (A)-1 Y2142A 1

MP19 8930058990 SHIELD SPONGE (V) 1

MP20 8510015660 2681 F-SHIELD PLATE 1

MP21 8930048550 2177 CLIP 1

MP22 8810008451 BIND M4 X 8 ZK3 4

MP23 8930075080 HR25F DUST CAP 1

MP24 8810009611 FLAT M2.6X 6 ZK3 8

MP25 8810009611 FLAT M2.6X 6 ZK3 9

MP26 8810010780 PH BT M3 X20 NI-ZK3 4

MP27 8810008661 PHBT M3 X 8 NI-ZC3 19

MP28 8810008661 PHBT M3 X 8 NI-ZC3 2

MP29 8810008661 PHBT M3 X 8 NI-ZC3 1

MP30 8810008661 PHBT M3 X 8 NI-ZC3 2

MP31 8810008661 PHBT M3 X 8 NI-ZC3 3

MP32 8810008661 PHBT M3 X 8 NI-ZC3 4

MP33 8510018780 3063 ANT CASE Y1076 2

MP35 8810003361 SET SCREWC M3 X 6 ZC3 2

MP37 8510018790 3063 VCO SHIELD Y1078 1

MP38 8510018820 3063 SHIELD PLATE Y1085 1

MP40 8930050472 SHIELD SPONGE (A)-2 1

MP41 8930050472 SHIELD SPONGE (A)-2 1

MP42 8930050472 SHIELD SPONGE (A)-2 1

[ACCESSORIES]

REF PART DESCRIPTION QTY.

NO. NO.

W1 8900017530 OPC-1784 M2K 1

W2 8900017530 OPC-1784 M2K Only [#82] 1

W3 8900021150 OPC-2243 Only [#82] 1

W4 8920001160 CAB-1149 Only [#07] 1

MP1 8930075520 3063 HANDLE 1

MP4 8310071490 3063 KEY SEAL 1

[PA UNIT] (For only FR5100H])

REF PART DESCRIPTION QTY.

NO. NO.

EP1 (Option) UR-PA5000 1

MP1 For handle attachment

MP2

MP3

MP4

KEY SEAL

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

*: Refer to “BOARD LAYOUTS” for the location.

8-2

July 2016 (Amended page)

█ADJUSTMENT CHANNEL LISTS

(For [#07], [#14], [#15], [#16], [#23], [#35], [#36], [#37] and [#82])

Clone the adjust channels into the repeater before starting adjustment. Each channel must be assigned [Frequency], [RF

PWR], [CH Type], [TX C. Tone] and [W/N] as below.

6-7

July 2016 (Amended page)

6-5 FREQUENCY ADJUSTMENT

(For [#07], [#14], [#15], [#16], [#23], [#35], [#36], [#37] and [#82])

1) Select an adjustment item using cursor or [] / [] keys of the PC’s keyboard.

2) Set or modify the adjustment value as speciﬁed using [] / [] keys of the PC’s keyboard, then push the [ENTER] key.

ADJUSTMENT ADJUSTMENT CONDI-

TION OPERATION

ADJUST-

MENT

ITEM

VALUE

PLL LOCK

VOLTAGE

–

1) Connect an RF power meter to the

TX antenna.

2) Set the preset adjustment value on

the adjustment utility window.

[LV (RX L)] 169 [3.31 V]

[LV (RX H)] 161 [3.15 V]

[LV (TX L)] 191 [3.74 V]

[LV (TX H)] 161 [3.15 V]

(Band center)

2 • Channel: 1-1

• Receiving

• Select the item [RX LVA L], then

push the [ENTER] key. [RX LVA L]

(Automatic

adjustment)

(Band high)

3 • Channel: 1-2

• Receiving

•

Select the item [RX LVA H], then

push the [ENTER] key.

[RX LVA H]

(Band low)

4 • Channel: 1-3

• Transmitting

• Select the item [TX LVA L], then push

the [ENTER] key. [TX LVA L]

(Band center)

5 • Channel: 1-4

• Transmitting

• Select the item [TX LVA H], then

push the [ENTER] key. [TX LVA H]

LOCK

VOLTAGE

VERIFY

(Band low)

1 • Channel: 1-5

• Receiving

• Verify the lock voltage at each chan-

nels on the [RX LIVIN] item on the

"I/O Check window" as below. [RX LIVIN]

(I/O Check

window)

0.5–2.0 V

(Verify)

(Band center)

2 • Channel: 1-6

• Receiving

(Band low)

3 • Channel: 1-7

• Transmitting

• Verify the lock voltage at each chan-

nels on the [TX LIVIN] item on the

"I/O Check window" on the MAIN/-A

UNIT as below.

[TX LIVIN]

(I/O Check

window)

(Band high)

4 • Channel: 1-8

• Transmitting

FREQUENCY

VERIFY

1NOTE: Only when the RX frequency is not in the speciﬁed range, re-adjust the RX frequency.

• Channel: 1-8

• Receiving

• Connect an frequency counter to the

1st LO check point as below. [RX REF]

220.2500 MHz (1st LO)

(

±50 Hz)

FREQUENCY

–

1) Set the item [TX Mode] to "1."

2) Connect an RF power meter to the

TX antenna.

[TX Mode]

"1"

(Analog Voice)

2 • Channel: 1-9

• Transmitting

1) Adjust the frequency using [] / []

keys of the PC’s keyboard.

2) Push [ENTER] to store the value.

[TX REF]

173.9000 MHz

(

±50 Hz)

6-8

DSUB

CPU FLASH

RXLO

GND

• I/O CHECK WINDOW • 1ST LO CHECK POINT

(MAIN/-A UNIT)

Lock voltage verify

July 2016 (Amended page)

6-6 TRANSMIT ADJUSTMENT

(For [#07], [#14], [#15], [#16], [#23], [#35], [#36], [#37] and [#82])

1) Select an adjustment item using cursor or [] / [] keys of the PC’s keyboard.

2) Set or modify the adjustment value as speciﬁed using [] / [] keys of the PC’s keyboard, then push the [ENTER] key.

ADJUSTMENT ADJUSTMENT CONDI-

TION OPERATION

ADJUST-

MENT

ITEM

VALUE

Output Power

-Preparation-

–

• Connect the RF power meter to the

TX antenna connector. ––

-Adjust-

(Hi Power)

2 • Channel: 1-10

• Transmitting

1) While transmitting, set the power

supply voltage set to:

[

EUR], [DPM] versions:

13.2 V

Other than above versions:

13.6 V

Adjust the TX output power using []

/ [] keys of the PC’s keyboard.

3) Push the [ENTER] key to store the

adjust value.

[Power(Hi)]

50 W

[50 W ver.]

25 W

[25 W ver.]

5.0 W*

(L2 Power) 3 • Channel: 1-11

• Transmitting [Power(L2)]

25 W

[50 W ver.]

10 W

[25 W ver.]

5.0 W*

(L1 Power) 4 • Channel: 1-12

• Transmitting [Power(L1)]

5 W

[50 W ver.]

2.5 W

[25 W ver.]

5.0 W*

MODULATION

BALANCE

–

1) Connect the modulation analyzer to

the TX antenna connector through

the attenuator.

2) Set the modulation analyzer set to:

HPF: OFF

LPF: 20 kHz

De-emphasis: OFF

Detector: (P-P)/2

––

2 – • Set the item [TX Mode] to "2." [TX Mode]

"2"

3 • Channel: 1-13

• Transmitting

1) Connect the oscilloscope to the Mod-

ulation Analyzer’s detector terminals.

Then, connect the Modulation Ana-

lyzer to the transceiver through the

attenuator.

2) Observe the waveform on the oscil-

loscope.

[BAL]

4 • Channel: 1-14

• Transmitting

[BAL Offset

(High]

DIGITAL

DEVIATION

-Preparation-

1 – • Set the item [TX Mode] to "16." [TX Mode]

"16"

–

1) Connect the modulation analyzer to

the TX antenna connector through

the attenuator.

2) Set the modulation analyzer set to:

HPF: OFF

LPF: 20 kHz

De-emphasis: OFF

Detector: (P-P)/2

––

-Adjust-

(Band 1)

3 • Channel: 1-15

• Transmitting

1) Adjust the deviation using [] / []

keys of the PC’s keyboard.

2) Push the [ENTER] key to store the

adjust value.

[MOD

(Digital)]

±1.37 ±0.02 kHz

(Band 2) 4 • Channel: 1-16

• Transmitting

[MOD Slant

Band 0]

(Band 3) 5 • Channel: 1-17

• Transmitting

[MOD Slant

Band 1]

(Band 4) 6 • Channel: 1-18

• Transmitting

[MOD Slant

Band 2]

(Band 5) 7 • Channel: 1-19

• Transmitting

[MOD Offset

(High)]

(Band 6) 8 • Channel: 1-20

• Transmitting

[MOD Slant

Band 3]

(Band 7) 9 • Channel: 1-21

• Transmitting

[MOD Slant

Band 4]

(Band 8) 10 • Channel: 1-22

• Transmitting

[MOD Slant

Band 5]

*: For IC-FR5100H.

6-9

No over or under shoot.

As flat as possible.

6-6 TRANSMIT ADJUSTMENT (continued)

(For [#07], [#14], [#15], [#16], [#23], [#35], [#36], [#37] and [#82])

1) Select an adjustment item using cursor or [] / [] keys of the PC’s keyboard.

2) Set or modify the adjustment value as speciﬁed using [] / [] keys of the PC’s keyboard, then push the [ENTER] key.

ADJUSTMENT ADJUSTMENT CONDI-

TION OPERATION

ADJUST-

MENT

ITEM

VALUE

ANALOG

DEVIATION

-Preparation-

1–• Set the item [TX Mode] to "1." [TX Mode]

"1"

(Analog voice)

2•Connect the modulation

analyzer to the TX antenna

connector through the

attenuator.

• Set the Modulation Analyzer set to:

HPF: OFF

LPF: 20 kHz

De-emphasis: OFF

Detector: (P-P)/2

––

3•Connect an Audio Genera-

tor to the MIC line through

the JIG cable.

• Set the Audio Generator set to:

Modulation: 1015 Hz

Level: 40 mVrms

Waveform: Sine wave

––

-Adjust-

(Wide)

4 • Channel: 1-23

• Transmitting

1) Adjust the deviation using [] / []

keys of the PC’s keyboard.

2) Push the [ENTER] key to store the

adjust value.

[MOD

(Wide)] ±4.10 ±0.05 kHz

(Middle)

<Only [FR5100]

and [FR5100H]>

5 • Channel: 1-24

• [Wide Band Width]

: "Middle" (see the page 6-4)

• Transmitting

[MOD

(Middle)] ±3.20 ±0.05 kHz

(Narrow) 6 • Channel: 1-25

• Transmitting

[MOD (Nar-

row)] ±2.10 ±0.05 kHz

CTCSS/DTCS

DEVIATION

-Preparation-

–

• Set the item [TX Mode] to "3."

[TX Mode]

"3"

(CTCSS 151.4Hz)

-Adjust-

(Wide)

2 • Channel: 1-26

• Transmitting

1) Adjust the deviation using [] / []

keys of the PC’s keyboard.

2) Push the [ENTER] key to store the

adjust value.

[CTCSS/

DTCS]

±0.70 ±0.02 kHz

(Narrow) 3 • Channel: 1-26

• Transmitting ±0.35 ±0.02 kHz

6-10

July 2016 (Amended page)

6-7 RECEIVE ADJUSTMENT

(For [#07], [#14], [#15], [#16], [#23], [#35], [#36], [#37] and [#82])

1) Select an adjustment item using cursor or [] / [] keys of the PC’s keyboard.

2) Set or modify the adjustment value as speciﬁed using [] / [] keys of the PC’s keyboard, then push the [ENTER] key.

ADJUSTMENT ADJUSTMENT CONDI-

TION OPERATION

ADJUST-

MENT

ITEM/

POINT

VALUE

RECEIVE

SENSITIVITY

1 • Channel: 1-27

• Receiving

1) Connect the SSG to the RX antenna

connector, and set to:

Level†: +20 dBµ (–87 dBm)

Modulation: 1 kHz

Deviation: ±3.5 kHz

Frequency: 136.100 MHz

2) Select the item [BPF C ALL], then

push the [ENTER] key.

[BPF C

ALL]

(Automatic

adjustment)

S-METER

(S3 level)

NOTE: "RECEIVE SENSITIVITY" MUST be adjusted before "S-METER." When "RECEIVE SENSITIVITY" is re-

adjusted, "S-METER" MUST be re-adjusted, too.

1 • Channel: 1-28

• Receiving

1) Set the SSG set to:

Frequency: 173.900 MHz

Modulation: 1 kHz

Deviation: ±3.5 kHz

Level†: +23 dBµ (–84 dBm)

2) Select the item [RSSI S3 Level],

then push the [ENTER] key to store

the adjust value.

[RSSI S3

Level]

(Automatic

adjustment)

(S1 level) 2 • Channel: 1-28

• Receiving

1) Set the SSG set to:

Level†: –7 dBµ (–114 dBm)

2) Select the item [RSSI S1 Level],

then push the [ENTER] key, to store

the adjust value.

[RSSI S1

Level]

(Automatic

adjustment)

SQUELCH

-Preparation-

1–• Set the item [SQL Level] to "2." [SQL Level] "2"

2•Connect the SSG to the RX

antenna connector.

• Set the SSG set to:

Frequency: 136.100 MHz

Modulation: 1 kHz

Deviation: ±3.5 kHz

Level†: –13 dBµ (–120 dBm)

––

-Adjust- 3 • Channel: 1-29

• Receiving

• Push [ENTER] key to store the value.

[SQL]

To the level where

the squelch just

opens.

†; The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.

6-11

SECTION 6

PART LIST

IC500 1130009121 S.IC S1D15206F00A200 B 69.5/36.0

IC501 1110005771 S.IC S-80942CNMC-G9CT2G B 105.3/24.1

IC502 1140014582 S.IC UPD78F1153GK(R)-GAK-AX

(3063C-3) B 101.4/38.8

IC503 1110005350 S.IC NJM2870F05-TE1-#FZZB B 47.3/30.5

IC506 1140013200 S.IC CD4053BPWR B 39.1/31.7

IC508 1110002751 S.IC TA75S01F(TE85RF) B 143.0/18.1

IC509 1110006770 S.IC TDA8547TS/N B 28.5/55.8

Q500 1590001050 S.TRA DTC114TUA T106 B 148.5/41.4

Eqv. 1590004820 S.TRA DRC5114T0L

Q501 1590001050 S.TRA DTC114TUA T106 B 161.8/34.6

Eqv. 1590004820 S.TRA DRC5114T0L

Q502 1590001050 S.TRA DTC114TUA T106 B 161.9/41.4

Eqv. 1590004820 S.TRA DRC5114T0L

Q503 1590001050 S.TRA DTC114TUA T106 B 148.5/34.6

Eqv. 1590004820 S.TRA DRC5114T0L

Q504 1590001050 S.TRA DTC114TUA T106 B 91.4/45.6

Eqv. 1590004820 S.TRA DRC5114T0L

Q506 1590004590 S.TRA DMC506010R B 33.0/48.2

Q508 1520000460 S.TRA 2SB1132 T100 R B 36.9/52.7

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R

Q510 1590001050 S.TRA DTC114TUA T106 B 152.9/53.3

Eqv. 1590004820 S.TRA DRC5114T0L

Q511 1590001050 S.TRA DTC114TUA T106 B 166.3/53.0

Eqv. 1590004820 S.TRA DRC5114T0L

Q513 1590001060 S.TRA DTA114TUA T106 B 168.8/53.0

Q514 1590001060 S.TRA DTA114TUA T106 B 160.1/49.6

Q515 1590001060 S.TRA DTA114TUA T106 B 155.4/53.3

Q516 1590001060 S.TRA DTA114TUA T106 B 145.4/49.9

Q517 1590001050 S.TRA DTC114TUA T106 B 160.1/46.9

Eqv. 1590004820 S.TRA DRC5114T0L

Q518 1590001050 S.TRA DTC114TUA T106 B 145.4/47.1

Eqv. 1590004820 S.TRA DRC5114T0L

D503 1750002210 S.DIO DA2S00100L B 112.3/33.9

D504 1750002020 S.DIO DA2S10100L B 95.1/45.9

D505 1790001450 S.DIO RB160L-40 TE-25 B 41.8/26.6

D506 1790001450 S.DIO RB160L-40 TE-25 B 63.2/6.6

D507 1750001980 S.ZEN DZ2J056M0L B 160.8/29.9

D508 1750000370 S.DIO DA221 TL B 153.2/27.7

D509 1750000370 S.DIO DA221 TL B 166.4/28.1

D510 1750002020 S.DIO DA2S10100L B 43.2/51.6

D511 1750002020 S.DIO DA2S10100L B 115.9/45.0

D512 1750002020 S.DIO DA2S10100L B 65.3/10.2

D513 1750002020 S.DIO DA2S10100L B 36.3/24.4

X501 6050012680 S.XTA CR-858(SMD-49/18.432 MHz) B 113.1/28.2

L500 6200002861 S.COI NLV25T-4R7J-PF B 106.1/17.9

L501 6200003640 S.COI MLF1608E 100K-T B 161.6/17.9

L502 6200002861 S.COI NLV25T-4R7J-PF B 86.0/39.4

R500 7030003810 S.RES ERJ3GEYJ 125 V (1.2M) B 83.6/43.7

R501 7030003810 S.RES ERJ3GEYJ 125 V (1.2M) B 87.4/47.5

R506 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 157.8/36.3

R507 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 167.9/44.3

R508 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 167.9/37.8

R509 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 155.4/44.6

R510 7030005530 S.RES ERJ2GEJ 100 X (10) B 106.8/30.6

R511 7030005160 S.RES ERJ2GEJ 105 X (1M) B 105.9/30.6

R512 7510001730 S.THE ERTJ0EP 473J B 103.1/48.9

R513 7030005120 S.RES ERJ2GEJ 102 X (1K) B 102.2/49.9

R514 7030008010 S.RES ERJ2GEJ 123 X (12K) B 113.1/32.3

R515 7030008010 S.RES ERJ2GEJ 123 X (12K) B 112.3/36.0

R516 7030005050 S.RES ERJ2GEJ 103 X (10K) B 103.2/26.4

R517 7030008010 S.RES ERJ2GEJ 123 X (12K) B 110.3/33.1

R518 7410001140 S.ARR EXB28V104JX B 107.0/47.1

R519 7030005090 S.RES ERJ2GEJ 104 X (100K) B 105.4/48.5

R520 7030005090 S.RES ERJ2GEJ 104 X (100K) B 96.1/30.8

R523 7030005710 S.RES ERJ2GEJ 121 X (120) B 114.1/37.6

R524 7030005090 S.RES ERJ2GEJ 104 X (100K) B 104.5/48.5

R525 7030005710 S.RES ERJ2GEJ 121 X (120) B 113.2/37.6

R526 7030005710 S.RES ERJ2GEJ 121 X (120) B 112.3/37.6

R532 7030005120 S.RES ERJ2GEJ 102 X (1K) B 33.2/45.5

R533 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 31.2/47.7

R534 7030008290 S.RES ERJ2GEJ 183 X (18K) B 32.3/45.8

R536 7030005090 S.RES ERJ2GEJ 104 X (100K) B 158.7/30.8

R538 7030005090 S.RES ERJ2GEJ 104 X (100K) B 155.7/29.3

R539 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 27.7/51.1

R540 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 26.6/49.9

R541 7030005050 S.RES ERJ2GEJ 103 X (10K) B 139.2/32.0

R542 7030005080 S.RES ERJ2GEJ 823 X (82K) B 26.2/51.1

R543 7030005050 S.RES ERJ2GEJ 103 X (10K) B 137.4/31.5

R544 7030005240 S.RES ERJ2GEJ 473 X (47K) B 164.9/29.4

R545 7030004980 S.RES ERJ2GEJ 101 X (100) B 140.4/19.9

R546 7030005120 S.RES ERJ2GEJ 102 X (1K) B 164.9/27.8

R547 7030005120 S.RES ERJ2GEJ 102 X (1K) B 155.7/27.7

R548 7030005120 S.RES ERJ2GEJ 102 X (1K) B 159.8/28.0

R549 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 32.0/51.3

R551 7210003050 VAR EVU-F2KFK3 B14 (10KB)

R552 7030005050 S.RES ERJ2GEJ 103 X (10K) B 142.3/20.4

R553 7030005050 S.RES ERJ2GEJ 103 X (10K) B 144.7/20.2

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[FRONT UNIT]

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[FRONT UNIT]

R554 7030005120 S.RES ERJ2GEJ 102 X (1K) B 32.6/53.4

R556 7030005240 S.RES ERJ2GEJ 473 X (47K) B 161.1/19.0

R557 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 29.3/51.3

R558 7030008370 S.RES ERJ2GEJ 561 X (560) B 169.2/51.1

R559 7030008370 S.RES ERJ2GEJ 561 X (560) B 155.8/51.1

R560 7030010040 S.RES ERJ2GEJ-JPW B 139.5/17.2

R562 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 86.2/43.7

R563 7030003740 S.RES ERJ3GEYJ 334 V (330K) B 88.2/44.9

R564 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 153.1/19.8

R566 7030008370 S.RES ERJ2GEJ 561 X (560) B 162.0/49.2

R567 7030008370 S.RES ERJ2GEJ 561 X (560) B 148.3/49.9

R568 7030005050 S.RES ERJ2GEJ 103 X (10K) B 87.5/17.0

R570 7030005220 S.RES ERJ2GEJ 223 X (22K) B 103.1/24.8

R571 7030005070 S.RES ERJ2GEJ 683 X (68K) B 45.8/51.6

R572 7030005090 S.RES ERJ2GEJ 104 X (100K) B 46.3/50.3

R573 7030005090 S.RES ERJ2GEJ 104 X (100K) B 108.4/33.0

R574 7030005090 S.RES ERJ2GEJ 104 X (100K) B 108.4/32.1

R575 7030005050 S.RES ERJ2GEJ 103 X (10K) B 34.8/24.7

R576 7030005050 S.RES ERJ2GEJ 103 X (10K) B 62.6/12.9

C500 4030016930 S.CER C1005 JB 1A 104K-T B 79.4/47.9

C501 4030016930 S.CER C1005 JB 1A 104K-T B 80.9/47.5

C502 4030016930 S.CER C1005 JB 1A 104K-T B 80.9/46.6

C503 4030016930 S.CER C1005 JB 1A 104K-T B 80.4/45.3

C504 4030016930 S.CER C1005 JB 1A 104K-T B 81.3/45.3

C505 4030017490 S.CER C1608 JB 1A 105K-T B 81.0/41.0

C506 4030017460 S.CER C1005 JB 1H 102K-T B 84.0/39.8

C507 4030017490 S.CER C1608 JB 1A 105K-T B 80.9/39.5

C508 4030017730 S.CER C1005 JB 1H 471K-T B 146.4/41.2

C509 4030017730 S.CER C1005 JB 1H 471K-T B 159.8/34.4

C510 4030017730 S.CER C1005 JB 1H 471K-T B 159.9/41.2

C511 4030017730 S.CER C1005 JB 1H 471K-T B 146.4/34.4

C512 4030017030 S.CER C1005 JB 1A 273K-T B 104.8/21.8

C513 4030017630 S.CER C1005 CH 1H 120J-T B 106.4/29.4

C514 4030017420 S.CER C1005 CH 1H 470J-T B 157.7/44.6

C515 4030016790 S.CER C1005 JB 1E 103K-T B 103.6/50.3

C516 4030017580 S.CER C1005 CH 1H 060C-T B 113.1/31.4

C517 4030016930 S.CER C1005 JB 1A 104K-T B 102.2/50.8

C518 4030016790 S.CER C1005 JB 1E 103K-T B 113.4/35.1

C519 4030017640 S.CER C1005 CH 1H 150J-T B 111.3/31.8

C520 4030016930 S.CER C1005 JB 1A 104K-T B 105.2/27.1

C521 4030018900 S.CER C1005 JB 0J 474K-T B 105.0/30.1

C522 4550006480 S.TAN TEESVA 1C 475M8R B 46.7/33.3

Eqv. 4550007260 S.TAN F931C475MAABMA

C523 4030019990 S.CER C1005 JB 1C 104K-T B 45.0/31.1

C524 4030016790 S.CER C1005 JB 1E 103K-T B 49.9/29.5

C525 4550006250 S.TAN TEESVA 1A 106M8R B 49.0/27.8

Eqv. 4550007520 S.TAN F931A106MAABMA

C526 4030016930 S.CER C1005 JB 1A 104K-T B 48.9/26.2

C527 4030016930 S.CER C1005 JB 1A 104K-T B 34.4/30.0

C530 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/55.4

C531 4550006250 S.TAN TEESVA 1A 106M8R B 106.6/20.2

Eqv. 4550007520 S.TAN F931A106MAABMA

C532 4030017460 S.CER C1005 JB 1H 102K-T B 31.4/45.8

C533 4030017460 S.CER C1005 JB 1H 102K-T B 45.4/27.1

C534 4030016930 S.CER C1005 JB 1A 104K-T B 62.1/14.2

C535 4030016930 S.CER C1005 JB 1A 104K-T B 30.8/49.1

C536 4030017460 S.CER C1005 JB 1H 102K-T B 161.0/28.5

C537 4030017460 S.CER C1005 JB 1H 102K-T B 33.6/53.4

C538 4030018860 S.CER C1005 JB 0J 105K-T B 26.6/49.0

C539 4030017420 S.CER C1005 CH 1H 470J-T B 154.8/27.7

C540 4510008590 S.ELE EEE1AA101SP B 36.9/59.5

C541 4030019990 S.CER C1005 JB 1C 104K-T B 150.2/20.0

C542 4030017460 S.CER C1005 JB 1H 102K-T B 139.4/19.9

C544 4550006250 S.TAN TEESVA 1A 106M8R B 29.7/60.9

Eqv. 4550007520 S.TAN F931A106MAABMA

C545 4030017420 S.CER C1005 CH 1H 470J-T B 168.1/28.2

C546 4030017420 S.CER C1005 CH 1H 470J-T B 137.4/32.4

C547 4030017420 S.CER C1005 CH 1H 470J-T B 134.3/32.5

C548 4030017460 S.CER C1005 JB 1H 102K-T B 161.0/27.5

C549 4030017460 S.CER C1005 JB 1H 102K-T B 44.2/47.5

C551 4030017420 S.CER C1005 CH 1H 470J-T B 158.1/19.3

C553 4030017420 S.CER C1005 CH 1H 470J-T B 140.7/17.6

C555 4030018860 S.CER C1005 JB 0J 105K-T B 148.6/18.0

C556 4030016790 S.CER C1005 JB 1E 103K-T B 143.2/23.6

C558 4550006480 S.TAN TEESVA 1C 475M8R B 143.5/22.1

Eqv. 4550007260 S.TAN F931C475MAABMA

C559 4030017730 S.CER C1005 JB 1H 471K-T B 166.3/51.1

C560 4030017730 S.CER C1005 JB 1H 471K-T B 153.1/51.2

C561 4030017730 S.CER C1005 JB 1H 471K-T B 162.0/47.0

C562 4030017730 S.CER C1005 JB 1H 471K-T B 147.4/46.7

C563 4030016930 S.CER C1005 JB 1A 104K-T B 105.2/28.1

C564 4030016930 S.CER C1005 JB 1A 104K-T B 103.2/28.0

C565 4030016930 S.CER C1005 JB 1A 104K-T B 44.0/29.9

C566 4030017460 S.CER C1005 JB 1H 102K-T B 42.9/49.5

C567 4030016930 S.CER C1005 JB 1A 104K-T B 42.9/50.4

C568 4030017460 S.CER C1005 JB 1H 102K-T B 67.3/6.6

C569 4550006250 S.TAN TEESVA 1A 106M8R B 89.7/40.7

Eqv. 4550007520 S.TAN F931A106MAABMA

C573 4030016930 S.CER C1005 JB 1A 104K-T B 34.8/23.8

C574 4030016930 S.CER C1005 JB 1A 104K-T B 62.6/12.0

C575 4510009020 S.ELE EEE0JA331P B 106.0/11.4

J501 6510019121 S.CON S8B-PH-SM4-TB(LF)(SN) B 26.9/27.6

J502 6510019121 S.CON S8B-PH-SM4-TB(LF)(SN) B 52.9/15.2

J503 6450002210 CON 3017-8821

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[FRONT UNIT]

J504 6510014961 S.CON B2B-ZR-SM4-TF(LF)(SN) B 18.4/57.1

DS500 5030004230 LCD L5-1077TRR

DS501 5040002710 LED EMPG3338S

DS502 5040002720 LED EMVR3338S

DS503 5040002710 LED EMPG3338S

DS504 5040002720 LED EMVR3338S

DS505 5040002310 S.LED SML-311YTT86 T 111.3/43.2

DS506 5040002310 S.LED SML-311YTT86 T 101.3/43.2

DS507 5040002310 S.LED SML-311YTT86 T 91.3/43.2

DS508 5040002310 S.LED SML-311YTT86 T 81.3/43.2

DS509 5040002310 S.LED SML-311YTT86 T 71.3/43.2

DS510 5040002310 S.LED SML-311YTT86 T 61.3/43.2

DS511 5040002150 LED VRPG3349S-734

DS512 5040002150 LED VRPG3349S-734

S506 2250000511 ENC RH70N1037E20-13F-2781

SP501 2510001910 SPE ND3050GA13Y04

MF1 2710001020 FAN MGT6012HR-O15 Only [#07]

MF2 2710001020 FAN MGT6012HR-O15 Only [#07]

W501 8900011801 CAB OPC-1199A

W502 8900017541 CAB OPC-1785-1

EP501 8930065150 LCD SRCN-2781-SP-N-W (SHJ)

EP503 6910019600 SPA LM-5

EP504 6910019610 SPA LM-7 (SPACER)

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[CONNECT UNIT]

C601 4030017420 S.CER C1005 CH 1H 470J-T T 13.8/12.4

C602 4030017400 S.CER C1005 CH 1H 220J-T T 12.2/12.4

C603 4030017420 S.CER C1005 CH 1H 470J-T T 16.6/12.4

C604 4030017400 S.CER C1005 CH 1H 220J-T T 15.0/14.2

C605 4030017420 S.CER C1005 CH 1H 470J-T T 17.8/13.9

C606 4030017420 S.CER C1005 CH 1H 470J-T T 19.4/12.4

C607 4030017420 S.CER C1005 CH 1H 470J-T T 20.6/13.9

C608 4030017420 S.CER C1005 CH 1H 470J-T T 22.7/12.4

C609 4030017420 S.CER C1005 CH 1H 470J-T T 25.5/12.4

C610 4030017420 S.CER C1005 CH 1H 470J-T T 29.7/12.8

C611 4030017420 S.CER C1005 CH 1H 470J-T T 31.0/14.1

C612 4030017420 S.CER C1005 CH 1H 470J-T T 32.5/12.8

C613 4030017420 S.CER C1005 CH 1H 470J-T T 33.6/14.1

C614 4030017420 S.CER C1005 CH 1H 470J-T T 35.2/14.1

C615 4030017420 S.CER C1005 CH 1H 470J-T T 35.8/12.8

C616 4030017420 S.CER C1005 CH 1H 470J-T B 35.2/15.6

C617 4030017420 S.CER C1005 CH 1H 470J-T T 37.6/13.6

C618 4030017420 S.CER C1005 CH 1H 470J-T T 39.3/12.2

C619 4030017420 S.CER C1005 CH 1H 470J-T T 39.9/13.4

C620 4030017420 S.CER C1005 CH 1H 470J-T T 41.3/12.6

C621 4030017420 S.CER C1005 CH 1H 470J-T T 27.4/13.9

J601 6510027920 S.CON IMSA-9631S-28Y934 B 22.8/16.2

J602 6510023210 CON CD6125SA1J0

S1 2260003070 S.SWI MINISMDC150F/24-2 B 38.9/18.0

W601 8900017500 CAB OPC-1852 (P0.5N28L90)

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

Q63 1560000990 S.FET PMBFJ310 B 66.3/110.0

Q64 1560000990 S.FET PMBFJ310 B 63.4/110.0

Q66 1590004350 S.TRA DRC9144E0L B 95.0/4.8

Q67 1590004350 S.TRA DRC9144E0L B 125.0/4.7

Q68 1590004350 S.TRA DRC9144E0L B 110.0/4.7

Q69 1590004350 S.TRA DRC9144E0L T 9.5/53.3

Q70 1590004190 S.TRA DRA9144E0L T 9.5/51.0

Q71 1560000990 S.FET PMBFJ310 B 60.5/110.0

Q72 1530002851 S.TRA 2SC4116-BL(TE85RF) B 107.0/26.3

Q75 1590004330 S.TRA DRC9114E0L B 119.1/58.7

Q76 1590004330 S.TRA DRC9114E0L B 117.1/59.7

Q77 1590004330 S.TRA DRC9114E0L T 32.9/73.5

Q78 1590004330 S.TRA DRC9114E0L T 34.9/73.5

D1 1750001070 S.DIO DAN235ETL B 57.3/78.6

Eqv. 1750002470 S.DIO KDS112E-RTK/P

D2 1750001070 S.DIO DAN235ETL B 50.0/79.7

Eqv. 1750002470 S.DIO KDS112E-RTK/P

D3 1790001622 S.DIO 1SV308L3F B 69.3/94.8

D4 1790001622 S.DIO 1SV308L3F B 69.3/92.2

D5 1750002560 S.VAR 1SV281(TPH3F) B 29.9/120.1

D7 1720000691 S.VAR 1SV282(TPH2F) B 28.6/125.1

D8 1720000691 S.VAR 1SV282(TPH2F) B 26.5/113.3

D9 1720000691 S.VAR 1SV282(TPH2F) B 84.7/59.8

D10 1720000691 S.VAR 1SV282(TPH2F) B 86.4/51.2

D11 1790001622 S.DIO 1SV308L3F B 63.5/103.1

D12 1790001622 S.DIO 1SV308L3F B 62.4/101.1

D13 1720000691 S.VAR 1SV282(TPH2F) B 84.9/61.8

D14 1720000691 S.VAR 1SV282(TPH2F) B 84.4/52.0

D15 1720000691 S.VAR 1SV282(TPH2F) B 28.6/122.6

D16 1720000691 S.VAR 1SV282(TPH2F) B 26.5/114.6

D17 1750002560 S.VAR 1SV281(TPH3F) B 83.5/63.5

D18 1720000471 S.VAR 1SV239(TPH3F) B 96.3/66.7

D19 1750001850 S.DIO LDAN222T1G T 59.6/39.8

D20 1750002210 S.DIO DA2S00100L T 39.5/57.9

D21 1750001771 S.VAR 1SV323H3F B 63.0/139.4

D22 1750001771 S.VAR 1SV323H3F B 59.8/136.7

D23 1750001771 S.VAR 1SV323H3F B 63.0/136.7

D24 1750001771 S.VAR 1SV323H3F B 59.8/139.4

D27 1750002020 S.DIO DA2S10100L B 58.3/142.5

D30 1720000471 S.VAR 1SV239(TPH3F) B 95.6/56.8

D31 1750001771 S.VAR 1SV323H3F B 34.4/135.7

D32 1750001771 S.VAR 1SV323H3F B 34.4/138.4

D35 1750002520 S.DIO RN739FT106 B 143.7/92.9

D36 1750001080 S.DIO RB886G T2R [#07] T 144.4/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#07]

D36 1750001080 S.DIO RB886G T2R [#14] T 144.4/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#14]

D36 1750001080 S.DIO RB886G T2R [#15] T 144.4/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#15]

D36 1750001080 S.DIO RB886G T2R [#16] T 144.4/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#16]

D36 1750001080 S.DIO RB886G T2R [#36] T 144.4/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#36]

D37 1750001080 S.DIO RB886G T2R [#07] T 145.6/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#07]

D37 1750001080 S.DIO RB886G T2R [#14] T 145.6/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#14]

D37 1750001080 S.DIO RB886G T2R [#15] T 145.6/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#15]

D37 1750001080 S.DIO RB886G T2R [#16] T 145.6/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#16]

D37 1750001080 S.DIO RB886G T2R [#36] T 145.6/120.2

Eqv. 1750002450 S.DIO HSD88KRF-E [#36]

D38 1750002190 S.DIO JDP2S12CR(TE85LQ) B 84.9/134.0

D39 1750000581 S.DIO 1SV307(TPH3F) B 36.0/144.8

D40 1750000370 S.DIO DA221 TL T 114.3/77.8

D42 1750002560 S.VAR 1SV281(TPH3F) B 26.5/112.0

D44 1750002190 S.DIO JDP2S12CR(TE85LQ) B 90.8/127.1

D45 1790001670 S.DIO RB706F-40T106 B 83.8/128.0

D46 1750001850 S.DIO LDAN222T1G T 13.3/131.2

D47 1750001850 S.DIO LDAN222T1G T 13.3/129.2

D48 1790001670 S.DIO RB706F-40T106 B 119.6/144.5

D49 1790001670 S.DIO RB706F-40T106 B 139.5/133.2

D51 1750002020 S.DIO DA2S10100L T 10.6/127.1

D53 1790001810 S.VAR AVR-M1005C080MTABB T 32.5/11.7

D55 1790001810 S.VAR AVR-M1005C080MTABB T 30.5/11.7

D56 1790001810 S.VAR AVR-M1005C080MTABB T 36.6/11.7

D59 1790000700 DIO DSA3A1

D61 1750001850 S.DIO LDAN222T1G T 118.4/14.7

D62 1750003030 S.DIO HSMS-2829-TR1G B 68.3/123.3

D63 1750002020 S.DIO DA2S10100L B 34.2/20.8

D64 1750000370 S.DIO DA221 TL T 63.2/93.9

D65 1750000370 S.DIO DA221 TL T 65.2/93.9

D66 1750000370 S.DIO DA221 TL T 67.2/93.9

D67 1750000370 S.DIO DA221 TL T 61.9/105.9

D68 1750000370 S.DIO DA221 TL T 59.9/105.5

D69 1750000370 S.DIO DA221 TL T 69.2/93.9

D70 1750000370 S.DIO DA221 TL T 71.2/93.9

D71 1750000370 S.DIO DA221 TL T 69.2/109.5

D72 1750000370 S.DIO DA221 TL T 71.3/109.5

D73 1750000370 S.DIO DA221 TL T 73.3/109.5

D74 1750000370 S.DIO DA221 TL T 75.4/109.5

D75 1750002020 S.DIO DA2S10100L B 41.1/38.7

D76 1750002020 S.DIO DA2S10100L B 26.5/41.3

D77 1750002020 S.DIO DA2S10100L B 49.2/29.9

D78 1750002130 S.ZEN DZ2J062M0L B 52.3/29.9

D79 1750002560 S.VAR 1SV281(TPH3F) B 83.1/52.0

D81 1750002020 S.DIO DA2S10100L T 138.3/127.4

FI1 2020001520 CER CFWLA450KFFA-B0

(CFWS450F)

FI2 2020002510 CER LTW450HT

FI3 2030000500 S.MON DSF753SBF 46.35 MHz (FL-401) B 72.0/101.1

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

IC1 1110005330 S.IC NJM12904V-TE1-#ZZZB T 58.1/71.4

IC2 1110007290 S.IC AK2330P-L T 58.7/56.2

IC3 1130017760 S.IC SC-1449A (ML7351CGDZ0ANL) B 120.4/42.9

IC4 1130017760 S.IC SC-1449A (ML7351CGDZ0ANL) B 32.3/82.2

IC5 1110007720 S.IC AA32416A B 70.5/82.5

IC7 1110007280 S.IC NJM2716F-TE1-#ZZZB B 56.8/46.4

IC9 1190002080 S.IC AD7476ARTZ-REEL7 B 49.6/46.4

IC10 1130013040 S.IC TC7WBD125AFK(T5LF) B 46.6/49.2

IC11 1110006230 S.IC NJM2711F-TE1-#ZZZB B 53.1/35.0

IC12 1140013290 S.IC TMS320VC5509AZHH B 33.4/37.9

IC13 1180002591 S.REG XC6204B332MR-G T 81.0/20.4

IC14 1180003271 S.REG R1114Q161D-TR-FE T 84.4/21.4

IC15 1180002591 S.REG XC6204B332MR-G T 87.9/21.4

IC17 1190001340 S.IC M62334FP 600C T 67.3/61.7

IC18 1110005771 S.IC S-80942CNMC-G9CT2G T 41.4/52.8

IC19 1180003210 S.REG NJM2831F10-TE1-#ZZZB B 111.0/26.2

IC20 1140014550 S.IC HD64F2506RFC26DV T 33.5/37.7

IC21 1140012950 S.IC 24LC512T-I/SM T 59.2/21.8

IC22 1150002073 IC RA60H1317M-125 [#07]

1150002073 IC RA60H1317M-125 [#14]

1150002073 IC RA60H1317M-125 [#15]

1150002073 IC RA60H1317M-125 [#16]

1150002042 IC RA30H1317M-121 [#23]

1150002042 IC RA30H1317M-121 [#35]

1150002073 IC RA60H1317M-125 [#36]

1150002042 IC RA30H1317M-121 [#37]

1150002042 IC RA30H1317M-121 [#82]

IC23 1110002751 S.IC TA75S01F(TE85RF) T 141.7/125.1

IC25 1130008561 S.IC TC75S51F(TE85LF) B 29.0/16.3

IC26 1120003070 S.IC MAX3232EIPWR T 42.8/70.0

IC27 1180002010 S.REG BA08FP-E2 T 112.9/85.0

IC28 1110003091 IC LA4425A-E

IC29 1110002751 S.IC TA75S01F(TE85RF) T 12.0/123.1

IC30 1180003460 S.REG NJM2831F05-TE1-#ZZZB T 99.4/91.4

IC31 1130011760 S.IC CD4094BPWR T 8.2/45.2

IC32 1130017800 S.IC EN25Q40A-104GIP B 8.9/36.1

IC34 1110005340 S.IC NJM12902V-TE1-#ZZZB B 12.3/58.2

IC35 1140013200 S.IC CD4053BPWR B 20.6/58.3

IC36 1110005330 S.IC NJM12904V-TE1-#ZZZB B 27.8/55.4

IC37 1130008561 S.IC TC75S51F(TE85LF) T 56.7/66.7

IC38 1110006380 S.IC LM2904PWR T 114.1/23.8

IC39 1180004630 S.REG NJM7805DL1A-TE1-#FZZB T 101.2/25.8

IC40 1110005330 S.IC NJM12904V-TE1-#ZZZB B 50.6/57.2

IC41 1180003500 S.REG NJM7808DL1A-TE1-#FZZB B 130.5/16.6

IC42 1140015750 S.IC TLV320AIC3254IRHBR B 38.4/59.8

IC43 1180003790 S.REG XC6204B182MR-G T 75.7/20.4

IC44 1180003790 S.REG XC6204B182MR-G T 70.6/20.4

IC45 1130011741 S.IC TC7W66FK(TE85LF) B 114.5/60.2

IC46 1130011741 S.IC TC7W66FK(TE85LF) B 23.8/87.3

Q1 1590004190 S.TRA DRA9144E0L B 53.4/79.7

Q2 1530002851 S.TRA 2SC4116-BL(TE85RF) B 36.3/77.8

Q4 1560000541 S.FET 2SK880-Y(T5RICOMF) B 89.5/42.8

Q5 1560000541 S.FET 2SK880-Y(T5RICOMF) B 38.7/106.6

Q6 1560000541 S.FET 2SK880-Y(T5RICOMF) B 34.1/101.1

Q7 1530002601 S.TRA 2SC4215-O(TE85RF) B 73.0/92.9

Q8 1560000541 S.FET 2SK880-Y(T5RICOMF) B 94.4/47.5

Q10 1530002851 S.TRA 2SC4116-BL(TE85RF) B 89.8/46.2

Q11 1530002851 S.TRA 2SC4116-BL(TE85RF) B 34.1/104.2

Q12 1590004190 S.TRA DRA9144E0L B 66.1/100.3

Q13 1530002851 S.TRA 2SC4116-BL(TE85RF) B 90.0/49.9

Q14 1530002851 S.TRA 2SC4116-BL(TE85RF) B 34.1/107.3

Q15 1530002851 S.TRA 2SC4116-BL(TE85RF) B 97.5/43.8

Q16 1530002851 S.TRA 2SC4116-BL(TE85RF) B 38.7/103.6

Q17 1560001360 S.FET 2SK3019 TL B 68.2/74.6

Eqv. 1560001840 S.FET 2SK3107-T1-AT

Eqv. 1560001860 S.FET 2SK1824-T1-A

Q19 1530002601 S.TRA 2SC4215-O(TE85RF) B 63.2/106.9

Q20 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 39.9/123.1

Q21 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 39.6/114.5

Q22 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 95.2/64.3

Q23 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 95.2/54.5

Q24 1530003311 S.TRA 2SC5107-O(TE85RF) B 100.6/58.6

Q25 1530003311 S.TRA 2SC5107-O(TE85RF) B 44.9/117.4

Q26 1590004500 S.TRA DMC561040R B 40.5/117.8

Q27 1590004500 S.TRA DMC561040R B 96.0/59.6

Q28 1590004330 S.TRA DRC9114E0L B 93.3/59.6

Q29 1590004350 S.TRA DRC9144E0L T 57.2/41.9

Q30 1590004330 S.TRA DRC9114E0L B 37.8/117.8

Q31 1590004190 S.TRA DRA9144E0L T 57.2/39.8

Q32 1530003311 S.TRA 2SC5107-O(TE85RF) B 46.2/111.7

Q33 1530003311 S.TRA 2SC5107-O(TE85RF) B 101.9/53.0

Q34 1530003311 S.TRA 2SC5107-O(TE85RF) B 46.2/123.1

Q35 1530003311 S.TRA 2SC5107-O(TE85RF) B 101.9/64.4

Q36 1580000731 S.FET 3SK293(TE85LF) B 48.3/136.6

Q38 1530002680 S.TRA 2SC3357-T1 B 139.5/86.0

Q39 1560000841 S.FET 2SK1829(TE85RF) B 54.2/142.5

Q40 1590004590 S.TRA DMC506010R T 101.7/87.4

Q41 1520001010 S.TRA 2SB1132G-R-AB3-R T 101.7/82.8

Q42 1590004350 S.TRA DRC9144E0L T 13.3/67.6

Q43 1590004350 S.TRA DRC9144E0L T 136.6/125.0

Q44 1590004150 S.TRA DRC9114T0L T 114.3/80.1

Q45 1540000830 S.TRA 2SD1664G-Q-AB3-R T 118.4/75.2

Q46 1530002851 S.TRA 2SC4116-BL(TE85RF) T 137.3/120.2

Q48 1510000920 S.TRA 2SA1577 T106 Q T 101.5/77.8

Q49 1590004350 S.TRA DRC9144E0L T 102.3/73.7

Q52 1590004350 S.TRA DRC9144E0L T 10.9/131.7

Q53 1590004350 S.TRA DRC9144E0L T 10.9/129.7

Q56 1590004710 S.FET TPC6111(TE85LF) T 7.7/132.7

Q57 1550000190 S.FET 2SJ506STR-E T 123.3/99.6

Q58 1590004350 S.TRA DRC9144E0L T 129.4/102.2

Q59 1590000990 S.TRA DTC363EK T146 T 7.7/127.6

Q61 1530002851 S.TRA 2SC4116-BL(TE85RF) T 6.8/118.5

Q62 1530004210 S.TRA DSC7004S0L T 118.4/18.6

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

R34 7030005240 S.RES ERJ2GEJ 473 X (47K) T 27.1/68.1

R35 7030005240 S.RES ERJ2GEJ 473 X (47K) T 28.0/68.1

R36 7030005240 S.RES ERJ2GEJ 473 X (47K) T 28.9/68.1

R38 7030005230 S.RES ERJ2GEJ 334 X (330K) T 27.7/70.4

R39 7030005230 S.RES ERJ2GEJ 334 X (330K) T 28.6/70.4

R40 7030005230 S.RES ERJ2GEJ 334 X (330K) T 29.5/70.4

R41 7030005110 S.RES ERJ2GEJ 224 X (220K) B 68.2/78.2

R42 7030007060 S.RES ERJ2GEJ 684X (680K) B 38.0/76.0

R44 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 71.4/78.2

R45 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 64.6/75.5

R46 7030005000 S.RES ERJ2GEJ 471 X (470) T 52.7/57.1

R47 7030005050 S.RES ERJ2GEJ 103 X (10K) B 64.6/76.4

R48 7030010040 S.RES ERJ2GEJ-JPW B 62.8/76.4

R49 7030010040 S.RES ERJ2GEJ-JPW T 55.6/57.3

R52 7030004980 S.RES ERJ2GEJ 101 X (100) B 36.1/56.0

R53 7030005210 S.RES ERJ2GEJ 822 X (8.2K) B 16.8/57.6

R54 7030005000 S.RES ERJ2GEJ 471 X (470) B 19.5/64.3

R56 7030010040 S.RES ERJ2GEJ-JPW T 118.3/44.2

R57 7030005090 S.RES ERJ2GEJ 104 X (100K) B 62.8/75.5

R58 7030008290 S.RES ERJ2GEJ 183 X (18K) B 56.5/49.0

R59 7030008290 S.RES ERJ2GEJ 183 X (18K) B 57.4/49.0

R60 7030010040 S.RES ERJ2GEJ-JPW B 35.7/73.2

R62 7030005120 S.RES ERJ2GEJ 102 X (1K) B 18.5/62.5

R63 7030005090 S.RES ERJ2GEJ 104 X (100K) T 55.6/60.5

R65 7030010040 S.RES ERJ2GEJ-JPW B 126.4/46.9

R66 7030004980 S.RES ERJ2GEJ 101 X (100) B 56.5/50.6

R68 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 67.5/86.8

R69 7030011910 S.RES ERJ2GEJ 106 X (10M) B 20.8/86.3

R70 7030005050 S.RES ERJ2GEJ 103 X (10K) B 69.8/71.9

R72 7030004980 S.RES ERJ2GEJ 101 X (100) B 57.6/44.2

R75 7030005110 S.RES ERJ2GEJ 224 X (220K) B 45.1/70.8

R76 7030010040 S.RES ERJ2GEJ-JPW B 91.3/42.3

R77 7030005580 S.RES ERJ2GEJ 560 X (56) B 102.5/44.6

R78 7030010040 S.RES ERJ2GEJ-JPW B 35.9/101.0

R79 7030005580 S.RES ERJ2GEJ 560 X (56) B 44.7/99.8

R80 7030004970 S.RES ERJ2GEJ 470 X (47) B 41.8/56.5

R81 7030007250 S.RES ERJ2GEJ 220 X (22) B 49.9/50.5

R82 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 56.0/44.2

R84 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 94.5/43.2

R85 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 42.3/104.8

R87 7030005090 S.RES ERJ2GEJ 104 X (100K) B 73.8/81.2

R88 7030005530 S.RES ERJ2GEJ 100 X (10) B 44.2/70.8

R89 7030008400 S.RES ERJ2GEJ 182 X (1.8K) B 67.2/83.2

R90 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 53.0/72.2

R91 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 95.1/44.9

R92 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 88.5/41.1

R93 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 40.5/104.8

R94 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 32.6/99.5

R97 7410001170 S.ARR EXB28V470JX B 42.9/49.9

R98 7030005530 S.RES ERJ2GEJ 100 X (10) B 71.0/95.7

R99 7030005110 S.RES ERJ2GEJ 224 X (220K) B 71.0/92.9

R100 7030005600 S.RES ERJ2GEJ 273 X (27K) B 67.9/93.8

R101 7030004980 S.RES ERJ2GEJ 101 X (100) B 88.0/45.0

R102 7030004980 S.RES ERJ2GEJ 101 X (100) B 36.5/104.4

R103 7030004980 S.RES ERJ2GEJ 101 X (100) B 32.3/103.7

R104 7030005050 S.RES ERJ2GEJ 103 X (10K) B 88.0/46.7

R105 7030005050 S.RES ERJ2GEJ 103 X (10K) B 36.5/107.8

R106 7030005050 S.RES ERJ2GEJ 103 X (10K) B 32.3/105.4

R107 7030004980 S.RES ERJ2GEJ 101 X (100) B 92.5/44.7

R108 7030005810 S.RES RR0510P-152-D (1.5K) B 91.6/43.6

R109 7030005090 S.RES ERJ2GEJ 104 X (100K) B 64.8/98.2

R110 7030005810 S.RES RR0510P-152-D (1.5K) B 36.0/103.0

R111 7030011910 S.RES ERJ2GEJ 106 X (10M) B 26.6/87.8

R112 7030005120 S.RES ERJ2GEJ 102 X (1K) B 88.5/48.0

R113 7030005120 S.RES ERJ2GEJ 102 X (1K) B 32.3/107.1

R114 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 67.4/96.2

R115 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 68.0/91.3

R116 7030005050 S.RES ERJ2GEJ 103 X (10K) B 92.6/47.9

R117 7030011920 S.RES RR0510P-561-D (560) B 92.6/46.2

R118 7030004990 S.RES ERJ2GEJ 221 X (220) B 72.8/94.8

R119 7030007270 S.RES ERJ2GEJ 151 X (150) B 68.1/89.0

R120 7030011920 S.RES RR0510P-561-D (560) B 36.9/106.4

R121 7030009280 S.RES ERJ2GEJ 391 X B 28.0/108.1

R122 7030004970 S.RES ERJ2GEJ 470 X (47) B 56.7/33.9

R123 7030004970 S.RES ERJ2GEJ 470 X (47) B 49.5/38.5

R124 7030005240 S.RES ERJ2GEJ 473 X (47K) B 55.3/38.3

R125 7030009280 S.RES ERJ2GEJ 391 X B 86.9/49.5

R126 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 99.5/43.6

R127 7030005720 S.RES ERJ2GEJ 563 X (56K) T 88.4/58.4

R128 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 40.5/103.1

R129 7030005240 S.RES ERJ2GEJ 473 X (47K) B 55.3/35.1

R130 7030005240 S.RES ERJ2GEJ 473 X (47K) B 56.2/36.7

R131 7030004980 S.RES ERJ2GEJ 101 X (100) B 54.3/32.5

R132 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 50.8/34.9

R133 7030004990 S.RES ERJ2GEJ 221 X (220) B 67.6/104.4

R134 7030007270 S.RES ERJ2GEJ 151 X (150) B 62.4/97.1

R136 7030011910 S.RES ERJ2GEJ 106 X (10M) B 114.2/62.8

R137 7030011910 S.RES ERJ2GEJ 106 X (10M) B 115.2/57.3

R138 7030005240 S.RES ERJ2GEJ 473 X (47K) T 95.3/65.8

R139 7030005060 S.RES ERJ2GEJ 333 X (33K) T 95.3/64.9

R140 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 63.9/100.3

R141 7030005050 S.RES ERJ2GEJ 103 X (10K) T 95.3/64.0

R142 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 65.4/102.5

R143 7030005240 S.RES ERJ2GEJ 473 X (47K) B 48.6/38.5

R144 7030005240 S.RES ERJ2GEJ 473 X (47K) B 48.6/36.9

R145 7030004970 S.RES ERJ2GEJ 470 X (47) B 47.7/36.9

R146 7030005060 S.RES ERJ2GEJ 333 X (33K) T 93.1/54.8

R148 7030004980 S.RES ERJ2GEJ 101 X (100) B 59.6/107.1

R151 7030005310 S.RES ERJ2GEJ 124 X (120K) B 93.1/57.7

R152 7030005070 S.RES ERJ2GEJ 683 X (68K) B 65.2/107.0

R153 7030005000 S.RES ERJ2GEJ 471 X (470) B 61.4/104.4

R154 7030008340 S.RES RR0510P-182-D (1.8K) B 37.9/122.2

R155 7030011000 S.RES RR0510P-392-D (3.9K) B 36.7/120.7

R156 7030011000 S.RES RR0510P-392-D (3.9K) B 37.6/112.0

R157 7030005310 S.RES ERJ2GEJ 124 X (120K) B 93.0/67.3

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

FI4 2030000670 S.MON DSF753SBF 46.35 MHz (FL-420) B 63.6/91.2

FI5 2040001440 S.LC NFE31PT152Z1E9L

(NFM60R20T152) T 116.5/108.4

FI6 2040001440 S.LC NFE31PT152Z1E9L

(NFM60R20T152) T 116.5/111.5

FI7 2040001440 S.LC NFE31PT152Z1E9L

(NFM60R20T152) T 116.5/114.6

X1 6050012380 S.XTA CR-826 DSA535SD 15.3 MHz B 130.3/44.9

X2 6050012380 S.XTA CR-826 DSA535SD 15.3 MHz B 39.8/71.3

X3 6070000300 S.DIS JTBM450CX24 B 63.5/83.5

X4 6050012932 S.XTA CR-886B DSA321SDN

12.288 MHz B 52.9/38.3

X5 6050012680 S.XTA CR-858(SMD-49/18.432 MHz) T 46.9/52.8

L1 6200004660 S.COI MLF1608A 1R8K-T T 118.6/36.7

L2 6200004660 S.COI MLF1608A 1R8K-T B 23.7/82.4

L3 6200004480 S.COI MLF1608D R82K-T B 41.4/79.4

L4 6200003540 S.COI MLF1608D R22K-T B 39.5/76.7

L5 6200005721 S.COI ELJRE 33NGFA B 102.8/46.6

L6 6200005721 S.COI ELJRE 33NGFA B 46.7/102.2

L8 6200014280 S.COI BRC2012T4R7MD B 27.0/124.1

L9 6200014280 S.COI BRC2012T4R7MD B 27.0/120.8

L10 6200014280 S.COI BRC2012T4R7MD B 25.9/116.8

L11 6200014280 S.COI BRC2012T4R7MD B 82.5/61.4

L12 6200014280 S.COI BRC2012T4R7MD B 83.1/49.9

L13 6200014280 S.COI BRC2012T4R7MD B 28.7/111.6

L14 6200014280 S.COI BRC2012T4R7MD B 85.3/66.4

L15 6200013220 S.COI C6342A-R13G-A B 88.6/54.6

L16 6200010600 S.COI C6342A-67NG-A B 33.8/122.7

L17 6200014280 S.COI BRC2012T4R7MD B 28.7/116.8

L18 6200009910 S.COI C6342A-88NG-A B 88.8/63.9

L19 6200014280 S.COI BRC2012T4R7MD B 83.5/66.4

L20 6200014280 S.COI BRC2012T4R7MD B 30.2/124.7

L21 6200009910 S.COI C6342A-88NG-A B 33.1/114.4

L22 6200003550 S.COI MLF1608A 4R7K-T B 73.4/109.9

L23 6200005011 S.COI NLV25T-100J-PF B 60.5/113.3

L24 6200010740 S.COI C2520C-R27G-A B 70.0/109.1

L25 6200014280 S.COI BRC2012T4R7MD B 97.4/62.5

L26 6200014280 S.COI BRC2012T4R7MD B 98.0/56.1

L27 6130002961 S.COI #617DB-1327=P3 B 68.3/117.0

L29 6200005731 S.COI ELJRE 39NGFA B 102.6/58.6

L30 6200006981 S.COI ELJRE R10GFA B 46.9/117.4

L31 6200002861 S.COI NLV25T-4R7J-PF T 91.2/20.0

L32 6130002961 S.COI #617DB-1327=P3 B 68.3/128.7

L33 6200009571 S.COI ELJRE R12GFA B 47.3/109.2

L34 6200005721 S.COI ELJRE 33NGFA B 61.1/117.5

L35 6200006981 S.COI ELJRE R10GFA B 102.7/50.5

L36 6200007001 S.COI ELJRE 82NGFA B 44.3/123.1

L37 6200005721 S.COI ELJRE 33NGFA B 61.1/120.1

L38 6200007001 S.COI ELJRE 82NGFA B 100.0/64.4

L39 6200010610 S.COI C6342A-50NG-A B 67.4/138.5

L41 6200010610 S.COI C6342A-50NG-A B 53.7/136.7

L43 6200007001 S.COI ELJRE 82NGFA B 138.9/90.1

L45 6200005741 S.COI ELJRE 47NGFA B 142.8/87.4

L46 6200005741 S.COI ELJRE 47NGFA B 142.8/90.1

L47 6200010610 S.COI C6342A-50NG-A B 29.9/136.7

L48 6200010000 S.COI C2012C-56NG-A B 33.3/141.2

L49 6200010050 S.COI AS080547-47N B 97.2/119.2

L50 6200007750 S.COI LQW2BHN56NJ03L B 85.5/137.4

L51 6200010000 S.COI C2012C-56NG-A B 25.1/142.9

L52 6200010420 S.COI FHW1210HC 1R0JGT B 86.6/122.4

L53 6200010050 S.COI AS080547-47N B 90.1/135.3

L55 6200010050 S.COI AS080547-47N B 107.6/135.0

L56 6200010050 S.COI AS080547-47N B 115.2/138.8

L57 6200010050 S.COI AS080547-47N B 143.7/140.9

L58 6200002861 S.COI NLV25T-4R7J-PF T 55.4/37.5

L59 6200010420 S.COI FHW1210HC 1R0JGT B 147.2/146.2

L60 6200010420 S.COI FHW1210HC 1R0JGT B 24.5/147.0

L61 6200002961 S.COI NLV32T-4R7J-PF T 118.4/23.8

L62 6200014280 S.COI BRC2012T4R7MD B 83.7/56.6

L63 6200010000 S.COI C2012C-56NG-A B 72.3/137.8

L64 6200014280 S.COI BRC2012T4R7MD B 81.8/54.9

L65 6200014280 S.COI BRC2012T4R7MD B 41.7/120.7

L66 6200014280 S.COI BRC2012T4R7MD B 42.4/115.3

L68 6200003960 S.COI MLF1608A 1R0K-T B 140.7/94.7

L70 6200009930 S.COI C2012C-68NG-A T 30.9/142.4

R1 7030005310 S.RES ERJ2GEJ 124 X (120K) T 54.9/64.1

R2 7030005050 S.RES ERJ2GEJ 103 X (10K) T 58.7/61.7

R3 7030005240 S.RES ERJ2GEJ 473 X (47K) T 62.4/69.6

R4 7030007340 S.RES ERJ2GEJ 153 X (15K) B 57.3/80.1

R6 7030007300 S.RES ERJ2GEJ 332 X (3.3K) T 9.5/57.1

R7 7030010040 S.RES ERJ2GEJ-JPW T 61.6/66.3

R8 7030005160 S.RES ERJ2GEJ 105 X (1M) T 24.9/70.4

R9 7030005160 S.RES ERJ2GEJ 105 X (1M) T 25.8/70.4

R10 7030005160 S.RES ERJ2GEJ 105 X (1M) T 26.7/70.4

R12 7510001730 S.THE ERTJ0EP 473J B 132.5/47.4

R13 7030005090 S.RES ERJ2GEJ 104 X (100K) B 130.8/47.4

R15 7030007340 S.RES ERJ2GEJ 153 X (15K) B 54.6/78.3

R17 7030004980 S.RES ERJ2GEJ 101 X (100) T 19.8/68.9

R18 7030007340 S.RES ERJ2GEJ 153 X (15K) B 55.4/79.2

R20 7030009150 S.RES ERJ2GEJ 824 X (820K) T 56.1/63.5

R22 7410001130 S.ARR EXB28V102JX B 123.2/39.0

R23 7410001130 S.ARR EXB28V102JX B 27.7/78.4

R25 7030004970 S.RES ERJ2GEJ 470 X (47) B 65.3/79.4

R26 7030010040 S.RES ERJ2GEJ-JPW T 57.7/64.5

R27 7030005120 S.RES ERJ2GEJ 102 X (1K) T 57.9/51.0

R29 7030007570 S.RES ERJ2GEJ 122 X (1.2K) B 37.5/74.8

R30 7030007340 S.RES ERJ2GEJ 153 X (15K) B 52.8/81.2

R32 7030007340 S.RES ERJ2GEJ 153 X (15K) B 51.3/78.4

R33 7030007340 S.RES ERJ2GEJ 153 X (15K) B 48.5/78.2

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

R274 7030005090 S.RES ERJ2GEJ 104 X (100K) B 36.0/137.5

R275 7030005060 S.RES ERJ2GEJ 333 X (33K) T 93.1/55.7

R277 7030004980 S.RES ERJ2GEJ 101 X (100) T 145.0/126.0

R278 7030005090 S.RES ERJ2GEJ 104 X (100K) T 14.0/65.6

R279 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 102.4/90.1

R280 7030004990 S.RES ERJ2GEJ 221 X (220) T 141.3/127.7

R281 7410001150 S.ARR EXB28V471JX T 21.3/31.8

R282 7030005090 S.RES ERJ2GEJ 104 X (100K) T 37.9/20.4

R283 7030005100 S.RES ERJ2GEJ 154 X (150K) [#07] T 144.0/124.4

7030005100 S.RES ERJ2GEJ 154 X (150K) [#14]

7030005100 S.RES ERJ2GEJ 154 X (150K) [#15]

7030005100 S.RES ERJ2GEJ 154 X (150K) [#16]

7030005110 S.RES ERJ2GEJ 224 X (220K) [#23]

7030005110 S.RES ERJ2GEJ 224 X (220K) [#35]

7030005100 S.RES ERJ2GEJ 154 X (150K) [#36]

7030005110 S.RES ERJ2GEJ 224 X (220K) [#37]

7030005110 S.RES ERJ2GEJ 224 X (220K) [#82]

R285 7030005050 S.RES ERJ2GEJ 103 X (10K) T 101.7/79.6

R286 7030005080 S.RES ERJ2GEJ 823 X (82K) B 46.0/70.8

R287 7410001140 S.ARR EXB28V104JX T 49.7/27.7

R288 7030005110 S.RES ERJ2GEJ 224 X (220K) T 139.5/122.5

R289 7030006070 S.RES ERJ12YJ101U (100) B 87.0/117.6

R290 7030005110 S.RES ERJ2GEJ 224 X (220K) T 138.6/122.5

R291 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 138.0/125.4

R292 7030005050 S.RES ERJ2GEJ 103 X (10K) T 144.0/126.0

R295 7030005110 S.RES ERJ2GEJ 224 X (220K) T 137.6/122.5

R296 7030000440 S.RES MCR10EZHJ 3.3K (332) T 118.4/79.6

R297 7030000440 S.RES MCR10EZHJ 3.3K (332) T 120.2/79.6

R298 7030000440 S.RES MCR10EZHJ 3.3K (332) T 116.6/79.6

R299 7030004980 S.RES ERJ2GEJ 101 X (100) B 29.1/19.4

R300 7030005530 S.RES ERJ2GEJ 100 X (10) T 47.6/73.1

R301 7030008300 S.RES ERJ2GEJ 184 X (180K) B 85.6/105.6

R302 7030010040 S.RES ERJ2GEJ-JPW B 135.6/85.0

R303 7410001150 S.ARR EXB28V471JX T 47.7/68.4

R304 7030005050 S.RES ERJ2GEJ 103 X (10K) B 84.3/130.0

R306 7520000261 S.POS PRF18BB471QB5RB B 84.4/104.4

R308 7030005060 S.RES ERJ2GEJ 333 X (33K) T 144.0/127.7

R309 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 102.3/75.7

R310 7030005030 S.RES ERJ2GEJ 152 X (1.5K) [#07] T 143.3/120.2

7030005030 S.RES ERJ2GEJ 152 X (1.5K) [#14]

7030005030 S.RES ERJ2GEJ 152 X (1.5K) [#15]

7030005030 S.RES ERJ2GEJ 152 X (1.5K) [#16]

7030005030 S.RES ERJ2GEJ 152 X (1.5K) [#36]

R311 7030008410 S.RES ERJ2GEJ 392 X (3.9K) [#07] T 145.0/122.6

7030008410 S.RES ERJ2GEJ 392 X (3.9K) [#14]

7030008410 S.RES ERJ2GEJ 392 X (3.9K) [#15]

7030008410 S.RES ERJ2GEJ 392 X (3.9K) [#16]

7030008410 S.RES ERJ2GEJ 392 X (3.9K) [#36]

R312 7030005050 S.RES ERJ2GEJ 103 X (10K) T 147.5/120.3

R313 7030005050 S.RES ERJ2GEJ 103 X (10K) T 103.5/77.8

R314 7030007280 S.RES ERJ2GEJ 331 X (330) [#07] T 146.0/124.4

7030007280 S.RES ERJ2GEJ 331 X (330) [#14]

7030007280 S.RES ERJ2GEJ 331 X (330) [#15]

7030007280 S.RES ERJ2GEJ 331 X (330) [#16]

7030004980 S.RES ERJ2GEJ 101 X (100) [#23]

7030004980 S.RES ERJ2GEJ 101 X (100) [#35]

7030007280 S.RES ERJ2GEJ 331 X (330) [#36]

7030004980 S.RES ERJ2GEJ 101 X (100) [#37]

7030004980 S.RES ERJ2GEJ 101 X (100) [#82]

R315 7030005700 S.RES ERJ2GEJ 274 X (270K) B 86.0/128.9

R316 7030005050 S.RES ERJ2GEJ 103 X (10K) T 11.2/128.2

R317 7030005010 S.RES ERJ2GEJ 681 X (680) [#07] B 138.5/95.1

7030005010 S.RES ERJ2GEJ 681 X (680) [#14]

7030005010 S.RES ERJ2GEJ 681 X (680) [#15]

7030005010 S.RES ERJ2GEJ 681 X (680) [#16]

7030005010 S.RES ERJ2GEJ 681 X (680) [#36]

R318 7030003220 S.RES ERJ3GEYJ 150 V (15) B 140.2/90.1

R320 7030005090 S.RES ERJ2GEJ 104 X (100K) T 15.1/124.2

R321 7030003370 S.RES ERJ3GEYJ 271 V (270) B 119.6/141.7

R322 7030005600 S.RES ERJ2GEJ 273 X (27K) B 121.5/143.4

R324 7030005050 S.RES ERJ2GEJ 103 X (10K) B 31.3/12.0

R325 7030005120 S.RES ERJ2GEJ 102 X (1K) B 32.3/12.0

R326 7030005240 S.RES ERJ2GEJ 473 X (47K) T 13.2/125.8

R327 7030000260 S.RES MCR10EZHJ 100 (101) B 119.7/132.9

R328 7030000280 S.RES MCR10EZHJ 150 (151) B 139.3/144.4

R331 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.0/120.0

R332 7030003370 S.RES ERJ3GEYJ 271 V (270) B 139.5/136.0

R333 7030005600 S.RES ERJ2GEJ 273 X (27K) B 137.7/131.9

R334 7030005651 S.RES ERA3YKD 304V (300K) T 57.8/30.5

R335 7030005871 S.RES ERA3YKD 104V (100K) T 55.9/29.8

R336 7030005110 S.RES ERJ2GEJ 224 X (220K) T 12.0/120.9

R337 7030005110 S.RES ERJ2GEJ 224 X (220K) T 13.2/120.6

R339 7030005090 S.RES ERJ2GEJ 104 X (100K) T 12.0/125.3

R341 7030005050 S.RES ERJ2GEJ 103 X (10K) B 33.3/12.0

R342 7030005090 S.RES ERJ2GEJ 104 X (100K) B 45.3/56.9

R346 7410001150 S.ARR EXB28V471JX T 43.6/73.8

R347 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.9/132.9

R348 7030000620 S.RES MCR10EZHJ 100 K (104) B 147.3/150.9

R349 7030000620 S.RES MCR10EZHJ 100 K (104) B 26.0/149.7

R350 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 6.4/131.1

R352 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 10.7/125.5

R353 7030005240 S.RES ERJ2GEJ 473 X (47K) B 55.8/56.9

R354 7030005700 S.RES ERJ2GEJ 274 X (270K) T 123.3/103.0

R355 7030005090 S.RES ERJ2GEJ 104 X (100K) T 127.4/102.2

R356 7030005090 S.RES ERJ2GEJ 104 X (100K) T 9.9/134.5

R357 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 10.2/150.2

R362 7540000290 ABS ERZV10D220

R364 7030005110 S.RES ERJ2GEJ 224 X (220K) T 65.1/71.2

R365 7030005050 S.RES ERJ2GEJ 103 X (10K) T 7.5/120.7

R366 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 6.2/122.7

R367 7030004980 S.RES ERJ2GEJ 101 X (100) T 9.8/117.3

R368 7030008300 S.RES ERJ2GEJ 184 X (180K) T 8.6/117.8

R369 7030005230 S.RES ERJ2GEJ 334 X (330K) T 9.8/118.2

R370 7030008280 S.RES ERJ2GEJ 271 X (270) T 6.2/120.7

R371 7030010040 S.RES ERJ2GEJ-JPW T 5.1/117.3

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

R158 7030005240 S.RES ERJ2GEJ 473 X (47K) T 93.1/56.7

R159 7030005530 S.RES ERJ2GEJ 100 X (10) B 65.2/106.1

R160 7030010040 S.RES ERJ2GEJ-JPW B 37.9/124.0

R161 7030008340 S.RES RR0510P-182-D (1.8K) B 37.6/112.9

R162 7030010040 S.RES ERJ2GEJ-JPW B 37.6/114.7

R163 7030011000 S.RES RR0510P-392-D (3.9K) B 91.7/62.0

R164 7030011000 S.RES RR0510P-392-D (3.9K) B 93.1/52.3

R165 7030010040 S.RES ERJ2GEJ-JPW B 93.0/64.6

R166 7030010040 S.RES ERJ2GEJ-JPW B 93.1/55.0

R167 7030005530 S.RES ERJ2GEJ 100 X (10) B 62.5/112.2

R168 7030008340 S.RES RR0510P-182-D (1.8K) B 93.0/62.8

R169 7030008340 S.RES RR0510P-182-D (1.8K) B 93.1/53.2

R171 7030011920 S.RES RR0510P-561-D (560) B 41.7/123.2

R172 7030009820 S.RES RR0510P-681-D (680) B 97.4/65.0

R173 7030009820 S.RES RR0510P-681-D (680) B 97.2/53.7

R174 7030009820 S.RES RR0510P-681-D (680) B 42.1/113.8

R175 7030005530 S.RES ERJ2GEJ 100 X (10) B 73.6/111.0

R176 7030005310 S.RES ERJ2GEJ 124 X (120K) B 100.6/56.8

R177 7030005090 S.RES ERJ2GEJ 104 X (100K) B 44.9/115.6

R178 7030004980 S.RES ERJ2GEJ 101 X (100) B 100.6/55.9

R179 7030004980 S.RES ERJ2GEJ 101 X (100) B 44.9/114.7

R180 7030005050 S.RES ERJ2GEJ 103 X (10K) B 38.1/108.5

R181 7030005050 S.RES ERJ2GEJ 103 X (10K) B 97.1/48.8

R185 7030010040 S.RES ERJ2GEJ-JPW B 62.3/117.5

R186 7030005120 S.RES ERJ2GEJ 102 X (1K) T 39.2/50.8

R187 7030008010 S.RES ERJ2GEJ 123 X (12K) T 41.5/56.1

R188 7410001150 S.ARR EXB28V471JX T 48.6/41.1

R189 7030005090 S.RES ERJ2GEJ 104 X (100K) T 55.7/39.6

R190 7030008010 S.RES ERJ2GEJ 123 X (12K) T 43.3/56.1

R191 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 43.5/112.2

R192 7030005110 S.RES ERJ2GEJ 224 X (220K) B 44.4/112.2

R194 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 99.2/53.0

R195 7030005110 S.RES ERJ2GEJ 224 X (220K) B 100.1/53.0

R196 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 48.0/120.7

R197 7030005050 S.RES ERJ2GEJ 103 X (10K) T 40.5/50.6

R198 7030004980 S.RES ERJ2GEJ 101 X (100) B 103.7/62.0

R199 7030005050 S.RES ERJ2GEJ 103 X (10K) T 67.6/57.5

R200 7030004980 S.RES ERJ2GEJ 101 X (100) B 43.1/123.1

R201 7030005090 S.RES ERJ2GEJ 104 X (100K) B 48.0/122.6

R202 7030005160 S.RES ERJ2GEJ 105 X (1M) T 41.4/48.6

R204 7030005050 S.RES ERJ2GEJ 103 X (10K) T 54.8/39.6

R205 7030008010 S.RES ERJ2GEJ 123 X (12K) T 36.5/57.9

R207 7030005050 S.RES ERJ2GEJ 103 X (10K) B 103.7/64.0

R208 7030010040 S.RES ERJ2GEJ-JPW B 46.2/120.7

R209 7030005000 S.RES ERJ2GEJ 471 X (470) T 67.6/56.5

R211 7030005050 S.RES ERJ2GEJ 103 X (10K) B 102.7/62.0

R212 7410001140 S.ARR EXB28V104JX T 52.4/41.1

R213 7030005530 S.RES ERJ2GEJ 100 X (10) T 41.4/47.7

R214 7030004980 S.RES ERJ2GEJ 101 X (100) B 98.9/64.0

R215 7030004990 S.RES ERJ2GEJ 221 X (220) B 100.9/62.0

R216 7410001140 S.ARR EXB28V104JX T 17.6/52.3

R217 7410001140 S.ARR EXB28V104JX T 38.6/56.0

R218 7030005090 S.RES ERJ2GEJ 104 X (100K) B 61.4/138.5

R220 7410001140 S.ARR EXB28V104JX T 15.3/50.7

R222 7410001140 S.ARR EXB28V104JX T 36.1/56.0

R223 7030005050 S.RES ERJ2GEJ 103 X (10K) B 61.4/137.6

R224 7410001150 S.ARR EXB28V471JX T 30.5/53.1

R225 7030005090 S.RES ERJ2GEJ 104 X (100K) B 61.4/139.4

R226 7030005110 S.RES ERJ2GEJ 224 X (220K) B 43.7/72.9

R227 7410001150 S.ARR EXB28V471JX T 42.9/28.8

R230 7410001150 S.ARR EXB28V471JX T 28.7/50.9

R231 7030008280 S.RES ERJ2GEJ 271 X (270) B 58.2/139.4

R232 7410001150 S.ARR EXB28V471JX T 26.0/49.4

R233 7030004980 S.RES ERJ2GEJ 101 X (100) B 58.2/135.8

R234 7410001150 S.ARR EXB28V471JX T 43.3/25.9

R235 7410001150 S.ARR EXB28V471JX T 24.2/47.6

R237 7030004970 S.RES ERJ2GEJ 470 X (47) B 49.4/138.8

R238 7410001150 S.ARR EXB28V471JX T 45.9/29.0

R239 7410001150 S.ARR EXB28V471JX T 22.5/45.8

R240 7030004980 S.RES ERJ2GEJ 101 X (100) B 134.7/86.7

R241 7030004990 S.RES ERJ2GEJ 221 X (220) B 49.4/134.3

R242 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 48.4/138.8

R243 7030005090 S.RES ERJ2GEJ 104 X (100K) B 47.4/138.8

R244 7410001150 S.ARR EXB28V471JX T 39.6/25.7

R245 7410001150 S.ARR EXB28V471JX T 20.3/42.5

R246 7030005310 S.RES ERJ2GEJ 124 X (120K) B 45.6/136.6

R247 7030008290 S.RES ERJ2GEJ 183 X (18K) B 48.4/140.4

R248 7030008010 S.RES ERJ2GEJ 123 X (12K) [#23] B 136.5/88.4

7030008010 S.RES ERJ2GEJ 123 X (12K) [#35]

7030008010 S.RES ERJ2GEJ 123 X (12K) [#37]

7030008010 S.RES ERJ2GEJ 123 X (12K) [#82]

R249 7030008010 S.RES ERJ2GEJ 123 X (12K) [#07] B 135.6/88.4

7030008010 S.RES ERJ2GEJ 123 X (12K) [#14]

7030008010 S.RES ERJ2GEJ 123 X (12K) [#15]

7030008010 S.RES ERJ2GEJ 123 X (12K) [#16]

7030008010 S.RES ERJ2GEJ 123 X (12K) [#36]

R250 7030004980 S.RES ERJ2GEJ 101 X (100) B 133.8/90.1

R253 7030004970 S.RES ERJ2GEJ 470 X (47) B 136.5/90.1

R255 7030008400 S.RES ERJ2GEJ 182 X (1.8K) B 52.4/142.5

R256 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 137.7/90.1

R257 7410001140 S.ARR EXB28V104JX T 14.5/45.7

R258 7030005110 S.RES ERJ2GEJ 224 X (220K) B 59.5/142.5

R259 7030005170 S.RES ERJ2GEJ 474 X (470K) B 57.1/142.5

R260 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 108.8/25.3

R261 7030005050 S.RES ERJ2GEJ 103 X (10K) T 52.6/25.3

R262 7030005090 S.RES ERJ2GEJ 104 X (100K) T 52.0/22.8

R263 7410001140 S.ARR EXB28V104JX T 46.3/20.1

R264 7410001140 S.ARR EXB28V104JX T 50.2/24.0

R267 7410001140 S.ARR EXB28V104JX T 14.9/42.5

R268 7410001150 S.ARR EXB28V471JX T 45.8/31.9

R269 7030004980 S.RES ERJ2GEJ 101 X (100) B 143.2/94.7

R270 7030005050 S.RES ERJ2GEJ 103 X (10K) B 36.0/136.6

R271 7030005090 S.RES ERJ2GEJ 104 X (100K) T 23.8/26.7

R272 7410001150 S.ARR EXB28V471JX T 17.9/32.3

R273 7410001150 S.ARR EXB28V471JX T 17.9/35.1

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

R560 7030006610 S.RES ERJ2GEJ 394 X (390K) [#07] T 139.5/130.0

7030006610 S.RES ERJ2GEJ 394 X (390K) [#14]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#15]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#16]

7030005310 S.RES ERJ2GEJ 124 X (120K) [#23]

7030005310 S.RES ERJ2GEJ 124 X (120K) [#35]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#36]

7030005310 S.RES ERJ2GEJ 124 X (120K) [#37]

7030005310 S.RES ERJ2GEJ 124 X (120K) [#82]

R561 7030007320 S.RES ERJ2GEJ 225 X (2.2M) [#07] T 140.4/130.0

7030007320 S.RES ERJ2GEJ 225 X (2.2M) [#14]

7030007320 S.RES ERJ2GEJ 225 X (2.2M) [#15]

7030007320 S.RES ERJ2GEJ 225 X (2.2M) [#16]

7030005160 S.RES ERJ2GEJ 105 X (1M) [#23]

7030005160 S.RES ERJ2GEJ 105 X (1M) [#35]

7030007320 S.RES ERJ2GEJ 225 X (2.2M) [#36]

7030005160 S.RES ERJ2GEJ 105 X (1M) [#37]

7030005160 S.RES ERJ2GEJ 105 X (1M) [#82]

R562 7410001170 S.ARR EXB28V470JX B 32.3/49.8

R563 7030005090 S.RES ERJ2GEJ 104 X (100K) T 42.1/62.4

R565 7030010040 S.RES ERJ2GEJ-JPW B 15.3/62.2

R566 7030010040 S.RES ERJ2GEJ-JPW [#23] T 146.6/120.3

7030010040 S.RES ERJ2GEJ-JPW [#35]

7030010040 S.RES ERJ2GEJ-JPW [#37]

7030010040 S.RES ERJ2GEJ-JPW [#82]

R567 7030004990 S.RES ERJ2GEJ 221 X (220) T 137.2/127.9

R568 7030005000 S.RES ERJ2GEJ 471 X (470) [#23] B 138.5/94.2

7030005000 S.RES ERJ2GEJ 471 X (470) [#35]

7030005000 S.RES ERJ2GEJ 471 X (470) [#37]

7030005000 S.RES ERJ2GEJ 471 X (470) [#82]

R600 7030010040 S.RES ERJ2GEJ-JPW B 124.6/41.5

R601 7030005120 S.RES ERJ2GEJ 102 X (1K) B 124.6/42.4

R602 7030005120 S.RES ERJ2GEJ 102 X (1K) B 124.6/43.3

R603 7030010040 S.RES ERJ2GEJ-JPW B 118.3/48.0

R604 7030010040 S.RES ERJ2GEJ-JPW T 119.2/41.5

R605 7030010040 S.RES ERJ2GEJ-JPW B 121.1/49.7

R606 7030007570 S.RES ERJ2GEJ 122 X (1.2K) B 90.2/40.7

R607 7030007570 S.RES ERJ2GEJ 122 X (1.2K) B 92.3/41.2

R609 7030005120 S.RES ERJ2GEJ 102 X (1K) B 120.9/38.5

R610 7030005050 S.RES ERJ2GEJ 103 X (10K) B 126.0/45.6

R611 7030010040 S.RES ERJ2GEJ-JPW B 31.0/78.3

R612 7030005120 S.RES ERJ2GEJ 102 X (1K) B 31.9/78.3

R613 7030005120 S.RES ERJ2GEJ 102 X (1K) B 32.8/78.3

R614 7030010040 S.RES ERJ2GEJ-JPW B 37.5/84.2

R615 7030010040 S.RES ERJ2GEJ-JPW T 32.4/81.0

R616 7030010040 S.RES ERJ2GEJ-JPW B 39.2/81.5

R617 7030010040 S.RES ERJ2GEJ-JPW T 33.7/84.5

R618 7030007570 S.RES ERJ2GEJ 122 X (1.2K) B 33.8/99.2

R619 7030007570 S.RES ERJ2GEJ 122 X (1.2K) B 35.4/99.2

R621 7030005120 S.RES ERJ2GEJ 102 X (1K) B 28.5/80.9

R622 7030005050 S.RES ERJ2GEJ 103 X (10K) B 35.3/72.0

R623 7030004970 S.RES ERJ2GEJ 470 X (47) T 30.3/22.3

R624 7030004970 S.RES ERJ2GEJ 470 X (47) T 30.3/23.2

R629 7030004970 S.RES ERJ2GEJ 470 X (47) T 43.9/24.0

R632 7030004970 S.RES ERJ2GEJ 470 X (47) T 44.8/22.7

R633 7030005050 S.RES ERJ2GEJ 103 X (10K) B 118.1/61.6

R634 7030005050 S.RES ERJ2GEJ 103 X (10K) B 117.2/61.6

R635 7030005050 S.RES ERJ2GEJ 103 X (10K) T 36.3/74.8

R636 7030005050 S.RES ERJ2GEJ 103 X (10K) T 33.5/75.1

R638 7030005710 S.RES ERJ2GEJ 121 X (120) B 18.8/37.5

C1 4030017420 S.CER C1005 CH 1H 470J-T B 122.3/37.0

C2 4030017420 S.CER C1005 CH 1H 470J-T B 25.8/79.3

C3 4030016930 S.CER C1005 JB 1A 104K-T B 130.8/48.3

C4 4030017420 S.CER C1005 CH 1H 470J-T B 126.8/37.1

C5 4030017420 S.CER C1005 CH 1H 470J-T B 21.0/78.3

C6 4030016930 S.CER C1005 JB 1A 104K-T B 52.5/78.0

C7 4030017420 S.CER C1005 CH 1H 470J-T B 124.2/36.3

C8 4030017420 S.CER C1005 CH 1H 470J-T B 21.0/79.2

C9 4030017460 S.CER C1005 JB 1H 102K-T T 17.6/59.0

C10 4030016930 S.CER C1005 JB 1A 104K-T B 55.8/78.0

C11 4030016930 S.CER C1005 JB 1A 104K-T B 125.6/39.9

C12 4030016930 S.CER C1005 JB 1A 104K-T B 21.0/77.4

C13 4030016930 S.CER C1005 JB 1A 104K-T B 55.6/80.7

C14 4030017460 S.CER C1005 JB 1H 102K-T T 16.1/59.9

C15 4030016930 S.CER C1005 JB 1A 104K-T T 62.4/67.5

C17 4030016930 S.CER C1005 JB 1A 104K-T T 120.1/38.2

C18 4030017430 S.CER C1005 CH 1H 101J-T T 62.4/71.2

C19 4030016930 S.CER C1005 JB 1A 104K-T B 25.7/82.7

C20 4550006250 S.TAN TEESVA 1A 106M8R T 123.9/39.5

Eqv. 4550007520 S.TAN F931A106MAABMA

C21 4550006250 S.TAN TEESVA 1A 106M8R B 19.8/82.1

Eqv. 4550007520 S.TAN F931A106MAABMA

C22 4030016930 S.CER C1005 JB 1A 104K-T B 50.1/78.0

C23 4030016930 S.CER C1005 JB 1A 104K-T T 57.9/52.7

C24 4030016930 S.CER C1005 JB 1A 104K-T B 50.3/81.2

C25 4030016930 S.CER C1005 JB 1A 104K-T B 54.4/81.2

C26 4030017460 S.CER C1005 JB 1H 102K-T T 121.0/38.2

C27 4030017460 S.CER C1005 JB 1H 102K-T B 26.6/82.7

C28 4030016930 S.CER C1005 JB 1A 104K-T B 53.4/78.0

C30 4030017460 S.CER C1005 JB 1H 102K-T T 59.8/67.1

C31 4030016930 S.CER C1005 JB 1A 104K-T T 60.6/53.1

C32 4030017590 S.CER C1005 CH 1H 070C-T B 40.3/79.5

C33 4030016930 S.CER C1005 JB 1A 104K-T T 58.9/67.1

C34 4030017570 S.CER C1005 CH 1H 040B-T B 39.0/78.7

C35 4030016930 S.CER C1005 JB 1A 104K-T B 39.3/74.8

C36 4030017500 S.CER C1005 CH 1H 560J-T B 39.0/79.6

C37 4030016930 S.CER C1005 JB 1A 104K-T B 48.5/79.8

C38 4030016930 S.CER C1005 JB 1A 104K-T B 69.8/78.2

C39 4030017360 S.CER C1005 CH 1H 030B-T B 71.4/77.3

C40 4030017500 S.CER C1005 CH 1H 560J-T B 68.2/76.4

C41 4030020450 S.CER C1005 JB 0J 475M-T B 32.0/57.2

C42 4030017500 S.CER C1005 CH 1H 560J-T B 66.4/78.2

C43 4030016930 S.CER C1005 JB 1A 104K-T B 55.6/49.0

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

R372 7030005000 S.RES ERJ2GEJ 471 X (470) T 115.3/15.8

R373 7030005050 S.RES ERJ2GEJ 103 X (10K) T 115.3/14.0

R374 7030000140 S.RES MCR10EZHJ 10 (100) T 111.2/12.3

R375 7030010040 S.RES ERJ2GEJ-JPW T 100.1/16.3

R377 7030010040 S.RES ERJ2GEJ-JPW B 62.3/124.7

R378 7030010040 S.RES ERJ2GEJ-JPW B 63.2/126.1

R380 7030007260 S.RES ERJ2GEJ 330 X (33) B 57.8/123.7

R424 7410001150 S.ARR EXB28V471JX T 46.3/42.9

R425 7410001150 S.ARR EXB28V471JX T 36.9/23.0

R426 7410001150 S.ARR EXB28V471JX T 47.9/33.9

R427 7030005000 S.RES ERJ2GEJ 471 X (470) T 25.5/26.7

R428 7410001140 S.ARR EXB28V104JX T 48.0/22.7

R429 7410001140 S.ARR EXB28V104JX T 49.8/30.2

R430 7410001140 S.ARR EXB28V104JX T 52.4/43.7

R431 7410001150 S.ARR EXB28V471JX T 17.8/40.3

R432 7410001140 S.ARR EXB28V104JX T 15.3/48.2

R433 7410001150 S.ARR EXB28V471JX T 40.0/22.7

R434 7410000750 S.ARR EXB-V4V 104JV (100K) B 36.8/48.0

R435 7410001140 S.ARR EXB28V104JX B 39.2/47.6

R436 7410001140 S.ARR EXB28V104JX B 44.4/41.2

R438 7410001140 S.ARR EXB28V104JX B 34.5/47.8

R443 7030005000 S.RES ERJ2GEJ 471 X (470) T 60.4/59.2

R444 7030005240 S.RES ERJ2GEJ 473 X (47K) B 13.5/33.6

R445 7030005240 S.RES ERJ2GEJ 473 X (47K) B 13.5/36.1

R446 7030005240 S.RES ERJ2GEJ 473 X (47K) B 13.5/37.4

R448 7030005090 S.RES ERJ2GEJ 104 X (100K) T 49.3/19.2

R449 7030005170 S.RES ERJ2GEJ 474 X (470K) T 39.5/19.3

R450 7030005050 S.RES ERJ2GEJ 103 X (10K) T 50.2/16.5

R452 7030005090 S.RES ERJ2GEJ 104 X (100K) T 51.1/19.2

R454 7030005120 S.RES ERJ2GEJ 102 X (1K) B 95.0/2.8

R455 7030005010 S.RES ERJ2GEJ 681 X (680) B 125.0/2.8

R456 7030005120 S.RES ERJ2GEJ 102 X (1K) B 110.0/2.8

R467 7030005240 S.RES ERJ2GEJ 473 X (47K) B 37.7/44.6

R468 7030005090 S.RES ERJ2GEJ 104 X (100K) B 26.3/44.6

R469 7030005090 S.RES ERJ2GEJ 104 X (100K) B 32.6/44.6

R470 7030005090 S.RES ERJ2GEJ 104 X (100K) T 10.9/20.2

R471 7030005090 S.RES ERJ2GEJ 104 X (100K) B 47.7/44.2

R472 7030005240 S.RES ERJ2GEJ 473 X (47K) B 4.8/36.1

R473 7030005090 S.RES ERJ2GEJ 104 X (100K) B 46.2/44.6

R474 7030005530 S.RES ERJ2GEJ 100 X (10) B 15.6/55.4

R475 7030005240 S.RES ERJ2GEJ 473 X (47K) B 9.6/53.2

R476 7030008270 S.RES RR0510P-104-D (100K) B 15.0/53.5

R477 7030005860 S.RES RR0510P-823-D (82K) B 15.0/52.6

R478 7030005050 S.RES ERJ2GEJ 103 X (10K) B 9.2/54.8

R479 7030005110 S.RES ERJ2GEJ 224 X (220K) T 64.2/69.6

R480 7030005050 S.RES ERJ2GEJ 103 X (10K) B 15.3/63.9

R481 7030005050 S.RES ERJ2GEJ 103 X (10K) B 14.0/63.5

R482 7410001150 S.ARR EXB28V471JX T 19.6/45.2

R483 7030005090 S.RES ERJ2GEJ 104 X (100K) T 31.3/56.5

R484 7030005090 S.RES ERJ2GEJ 104 X (100K) B 28.8/50.9

R485 7410001150 S.ARR EXB28V471JX T 67.3/96.9

R486 7410001150 S.ARR EXB28V471JX T 63.9/107.0

R487 7410001150 S.ARR EXB28V471JX T 73.0/106.9

R488 7030005000 S.RES ERJ2GEJ 471 X (470) T 9.5/54.9

R489 7030004980 S.RES ERJ2GEJ 101 X (100) B 24.1/58.7

R490 7030008290 S.RES ERJ2GEJ 183 X (18K) B 28.3/58.4

R491 7030004980 S.RES ERJ2GEJ 101 X (100) B 26.1/51.2

R492 7030005060 S.RES ERJ2GEJ 333 X (33K) B 29.9/58.9

R493 7030010040 S.RES ERJ2GEJ-JPW T 11.3/19.0

R494 7030005000 S.RES ERJ2GEJ 471 X (470) T 73.3/99.0

R495 7030008270 S.RES RR0510P-104-D (100K) T 54.9/55.3

R496 7030006020 S.RES RR0510P-682-D (6.8K) T 52.7/56.2

R497 7030008250 S.RES RR0510P-562-D (5.6K) T 52.7/55.3

R498 7030005600 S.RES ERJ2GEJ 273 X (27K) B 61.4/103.1

R499 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.4/57.0

R500 7030005600 S.RES ERJ2GEJ 273 X (27K) T 21.2/57.5

R501 7030005220 S.RES ERJ2GEJ 223 X (22K) T 22.8/53.8

R502 7030005090 S.RES ERJ2GEJ 104 X (100K) T 28.0/55.0

R503 7030007350 S.RES ERJ2GEJ 393 X (39K) T 55.6/58.9

R504 7030011920 S.RES RR0510P-561-D (560) T 52.7/54.4

R505 7030010040 S.RES ERJ2GEJ-JPW T 113.4/18.3

R506 7030005110 S.RES ERJ2GEJ 224 X (220K) T 113.4/19.3

R507 7030005090 S.RES ERJ2GEJ 104 X (100K) T 115.0/19.3

R509 7030005050 S.RES ERJ2GEJ 103 X (10K) B 33.3/15.2

R510 7030007350 S.RES ERJ2GEJ 393 X (39K) B 29.0/14.1

R511 7030005050 S.RES ERJ2GEJ 103 X (10K) B 29.1/18.5

R512 7030005050 S.RES ERJ2GEJ 103 X (10K) B 30.8/18.5

R513 7030007280 S.RES ERJ2GEJ 331 X (330) B 72.6/91.0

R530 7030005060 S.RES ERJ2GEJ 333 X (33K) T 62.5/66.3

R532 7030005000 S.RES ERJ2GEJ 471 X (470) B 45.1/37.1

R533 7030005090 S.RES ERJ2GEJ 104 X (100K) T 57.2/18.4

R534 7030005600 S.RES ERJ2GEJ 273 X (27K) B 45.3/58.6

R535 7030004980 S.RES ERJ2GEJ 101 X (100) B 56.7/56.9

R536 7030005600 S.RES ERJ2GEJ 273 X (27K) B 55.8/58.6

R537 7030010040 S.RES ERJ2GEJ-JPW B 41.6/41.2

R539 7030005110 S.RES ERJ2GEJ 224 X (220K) T 64.2/71.2

R540 7030005090 S.RES ERJ2GEJ 104 X (100K) T 90.8/17.9

R541 7030005220 S.RES ERJ2GEJ 223 X (22K) T 28.9/55.0

R542 7030005120 S.RES ERJ2GEJ 102 X (1K) T 70.4/65.1

R544 7030010040 S.RES ERJ2GEJ-JPW B 66.7/73.8

R545 7030010040 S.RES ERJ2GEJ-JPW T 61.2/98.7

R546 7030010040 S.RES ERJ2GEJ-JPW T 61.2/99.6

R547 7030010040 S.RES ERJ2GEJ-JPW T 69.7/99.1

R548 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 38.7/139.0

R549 7030001070 S.RES MCR50JZHJ 33 (330) T 87.6/30.2

R550 7030001070 S.RES MCR50JZHJ 33 (330) T 87.6/33.3

R551 7030010040 S.RES ERJ2GEJ-JPW B 15.5/60.5

R553 7030010040 S.RES ERJ2GEJ-JPW B 15.9/59.3

R557 7030010040 S.RES ERJ2GEJ-JPW B 10.3/62.6

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

C170 4030017650 S.CER C1005 CH 1H 270J-T B 28.7/114.6

C171 4030017400 S.CER C1005 CH 1H 220J-T B 28.7/113.7

C172 4030017420 S.CER C1005 CH 1H 470J-T B 85.8/63.9

C173 4030017550 S.CER C1005 CH 1H 1R5B-T B 93.0/66.4

C174 4030017670 S.CER C1005 CH 1H 390J-T B 84.4/54.1

C175 4030017460 S.CER C1005 JB 1H 102K-T T 93.1/53.9

C176 4030018860 S.CER C1005 JB 0J 105K-T B 90.9/57.7

C177 4030017590 S.CER C1005 CH 1H 070C-T B 36.7/123.3

C178 4030017580 S.CER C1005 CH 1H 060C-T B 37.6/111.1

C179 4030017420 S.CER C1005 CH 1H 470J-T T 14.9/129.1

C180 4030017640 S.CER C1005 CH 1H 150J-T B 91.7/65.0

C181 4030017390 S.CER C1005 CH 1H 180J-T B 83.4/54.1

C182 4030016790 S.CER C1005 JB 1E 103K-T B 63.1/104.4

C183 4030017420 S.CER C1005 CH 1H 470J-T T 14.9/131.3

C184 4030017670 S.CER C1005 CH 1H 390J-T B 37.9/124.9

C185 4030017660 S.CER C1005 CH 1H 330J-T B 37.6/115.6

C186 4030017420 S.CER C1005 CH 1H 470J-T T 93.1/57.7

C187 4030017420 S.CER C1005 CH 1H 470J-T T 95.3/67.6

C188 4030017500 S.CER C1005 CH 1H 560J-T B 84.9/63.9

C189 4030017610 S.CER C1005 CH 1H 090C-T B 93.1/51.4

C190 4030017550 S.CER C1005 CH 1H 1R5B-T B 93.1/56.8

C191 4030017670 S.CER C1005 CH 1H 390J-T B 93.0/65.5

C192 4030017670 S.CER C1005 CH 1H 390J-T B 93.1/55.9

C193 4030017460 S.CER C1005 JB 1H 102K-T B 61.4/107.1

C194 4030017660 S.CER C1005 CH 1H 330J-T B 37.9/123.1

C195 4030017670 S.CER C1005 CH 1H 390J-T B 40.3/120.7

C196 4030018010 S.CER C1005 CH 1H 360J-T B 37.6/113.8

C197 4030017670 S.CER C1005 CH 1H 390J-T B 41.7/112.2

C198 4030016790 S.CER C1005 JB 1E 103K-T B 60.5/107.1

C199 4030017460 S.CER C1005 JB 1H 102K-T T 95.3/63.1

C200 4030017650 S.CER C1005 CH 1H 270J-T B 93.0/63.7

C201 4030017660 S.CER C1005 CH 1H 330J-T B 96.0/62.0

C202 4030017670 S.CER C1005 CH 1H 390J-T B 93.1/54.1

C203 4030017420 S.CER C1005 CH 1H 470J-T B 97.2/52.0

C204 4550006250 S.TAN TEESVA 1A 106M8R T 81.7/15.2

Eqv. 4550007520 S.TAN F931A106MAABMA

C205 4550006250 S.TAN TEESVA 1A 106M8R T 85.1/17.1

Eqv. 4550007520 S.TAN F931A106MAABMA

C206 4550006250 S.TAN TEESVA 1A 106M8R T 88.8/16.8

Eqv. 4550007520 S.TAN F931A106MAABMA

C208 4030017490 S.CER C1608 JB 1A 105K-T T 80.0/15.6

C209 4030017490 S.CER C1608 JB 1A 105K-T T 83.4/16.6

C210 4030017490 S.CER C1608 JB 1A 105K-T T 87.0/16.3

C211 4030016930 S.CER C1005 JB 1A 104K-T B 38.5/120.7

C212 4030016790 S.CER C1005 JB 1E 103K-T B 39.9/112.2

C213 4030017650 S.CER C1005 CH 1H 270J-T B 68.5/106.1

C214 4030017460 S.CER C1005 JB 1H 102K-T B 66.8/107.0

C215 4030017540 S.CER C1005 CH 1H R75B-T B 42.8/118.5

C216 4030017540 S.CER C1005 CH 1H R75B-T B 42.8/116.9

C217 4030017460 S.CER C1005 JB 1H 102K-T B 39.4/120.7

C218 4030017460 S.CER C1005 JB 1H 102K-T B 40.8/112.2

C219 4030016790 S.CER C1005 JB 1E 103K-T B 94.2/62.0

C220 4030017530 S.CER C1005 CH 1H 0R5B-T B 98.5/59.6

C221 4030016790 S.CER C1005 JB 1E 103K-T B 95.4/52.0

C222 4030017530 S.CER C1005 CH 1H 0R5B-T B 99.4/56.6

C224 4030017460 S.CER C1005 JB 1H 102K-T B 95.1/62.0

C225 4030017460 S.CER C1005 JB 1H 102K-T B 96.3/52.0

C228 4030017490 S.CER C1608 JB 1A 105K-T T 77.9/24.2

C229 4030017490 S.CER C1608 JB 1A 105K-T T 82.7/24.8

C230 4030017490 S.CER C1608 JB 1A 105K-T T 86.8/24.4

C231 4550005980 S.TAN TEESVA 1A 475M8R T 80.0/25.1

Eqv. 4550007270 S.TAN F931A475MAABMA

C232 4550005980 S.TAN TEESVA 1A 475M8R T 84.4/25.6

Eqv. 4550007270 S.TAN F931A475MAABMA

C233 4550005980 S.TAN TEESVA 1A 475M8R T 88.5/25.7

Eqv. 4550007270 S.TAN F931A475MAABMA

C235 4030017030 S.CER C1005 JB 1A 273K-T T 41.0/55.0

C236 4030017730 S.CER C1005 JB 1H 471K-T B 100.6/55.0

C237 4030017460 S.CER C1005 JB 1H 102K-T B 100.6/60.4

C238 4030017730 S.CER C1005 JB 1H 471K-T B 44.9/113.8

C239 4030017460 S.CER C1005 JB 1H 102K-T B 44.9/119.2

C240 4510009550 S.ELE EEEFK1C100R T 95.1/22.4

C241 4030017350 S.CER C1005 CH 1H 020B-T B 68.3/120.9

C242 4030016790 S.CER C1005 JB 1E 103K-T B 68.7/111.2

C243 4030017460 S.CER C1005 JB 1H 102K-T B 70.3/106.1

C244 4030016790 S.CER C1005 JB 1E 103K-T B 70.3/107.0

C245 4030017460 S.CER C1005 JB 1H 102K-T T 94.8/60.2

C246 4030017620 S.CER C1005 CH 1H 100C-T B 46.9/114.7

C247 4030017460 S.CER C1005 JB 1H 102K-T B 42.6/112.2

C248 4030017460 S.CER C1005 JB 1H 102K-T B 36.0/117.8

C249 4030017420 S.CER C1005 CH 1H 470J-T B 48.0/112.2

C250 4030017640 S.CER C1005 CH 1H 150J-T B 103.7/58.7

C251 4030017620 S.CER C1005 CH 1H 100C-T B 102.6/55.9

C252 4030017460 S.CER C1005 JB 1H 102K-T B 99.2/51.3

C253 4030017590 S.CER C1005 CH 1H 070C-T B 48.0/117.4

C254 4030017460 S.CER C1005 JB 1H 102K-T B 103.7/53.0

C255 4030016930 S.CER C1005 JB 1A 104K-T T 42.1/50.6

C256 4030017640 S.CER C1005 CH 1H 150J-T T 43.3/55.2

C257 4030016790 S.CER C1005 JB 1E 103K-T T 36.5/58.8

C258 4030017390 S.CER C1005 CH 1H 180J-T B 59.6/117.8

C259 4030017580 S.CER C1005 CH 1H 060C-T T 48.5/46.4

C260 4030017460 S.CER C1005 JB 1H 102K-T B 46.6/107.6

C261 4030017460 S.CER C1005 JB 1H 102K-T B 47.7/110.3

C262 4030016930 S.CER C1005 JB 1A 104K-T T 69.2/57.5

C264 4030017460 S.CER C1005 JB 1H 102K-T B 102.4/49.5

C265 4030017460 S.CER C1005 JB 1H 102K-T B 43.5/120.7

C266 4030018900 S.CER C1005 JB 0J 474K-T T 43.7/45.6

C267 4030017660 S.CER C1005 CH 1H 330J-T B 59.6/119.3

C269 4550006780 S.TAN TEESVB2 0J 476M8R T 72.2/60.8

Eqv. 4550007200 S.TAN F930J476MBABMA

C270 4030016930 S.CER C1005 JB 1A 104K-T T 40.5/49.7

C271 4030017590 S.CER C1005 CH 1H 070C-T B 70.7/137.8

C272 4030017630 S.CER C1005 CH 1H 120J-T T 47.4/60.1

C274 4030017460 S.CER C1005 JB 1H 102K-T B 44.4/120.7

C275 4030017620 S.CER C1005 CH 1H 100C-T B 48.0/124.4

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

C44 4030018860 S.CER C1005 JB 0J 105K-T B 33.9/57.2

C45 4030016950 S.CER C1005 JB 1A 473K-T B 37.6/55.9

C46 4030017500 S.CER C1005 CH 1H 560J-T B 68.2/77.3

C47 4030017420 S.CER C1005 CH 1H 470J-T B 64.6/77.3

C48 4030016930 S.CER C1005 JB 1A 104K-T T 54.3/54.4

C49 4030018860 S.CER C1005 JB 0J 105K-T B 15.5/58.1

C50 4030016930 S.CER C1005 JB 1A 104K-T B 133.6/45.1

C51 4030017620 S.CER C1005 CH 1H 100C-T B 126.9/45.6

C52 4030017920 S.CER C1005 JB 1A 683K-T B 117.4/40.4

C53 4030016930 S.CER C1005 JB 1A 104K-T B 29.5/84.9

C54 4030017660 S.CER C1005 CH 1H 330J-T B 35.4/75.8

C56 4030016950 S.CER C1005 JB 1A 473K-T B 33.7/54.0

C58 4030017920 S.CER C1005 JB 1A 683K-T B 28.6/84.9

C59 4030017460 S.CER C1005 JB 1H 102K-T B 35.7/74.3

C60 4030017620 S.CER C1005 CH 1H 100C-T B 36.2/72.0

C61 4030018900 S.CER C1005 JB 0J 474K-T B 18.1/63.9

C63 4030016930 S.CER C1005 JB 1A 104K-T T 55.6/62.1

C64 4030017460 S.CER C1005 JB 1H 102K-T B 36.9/103.0

C66 4030017460 S.CER C1005 JB 1H 102K-T B 125.1/47.3

C67 4030017460 S.CER C1005 JB 1H 102K-T B 67.5/87.7

C70 4030017460 S.CER C1005 JB 1H 102K-T B 64.3/79.4

C71 4030016930 S.CER C1005 JB 1A 104K-T B 57.6/43.3

C73 4030017460 S.CER C1005 JB 1H 102K-T B 95.5/43.2

C74 4030017780 S.CER C1005 JB 1H 472K-T B 87.8/43.1

C75 4030017460 S.CER C1005 JB 1H 102K-T B 41.4/104.8

C76 4030017780 S.CER C1005 JB 1H 472K-T B 32.3/102.1

C77 4030016930 S.CER C1005 JB 1A 104K-T T 53.9/57.7

C79 4030017630 S.CER C1005 CH 1H 120J-T B 47.0/100.4

C80 4030017430 S.CER C1005 CH 1H 101J-T B 101.1/47.2

C81 4030017430 S.CER C1005 CH 1H 101J-T B 43.6/99.8

C82 4550006250 S.TAN TEESVA 1A 106M8R B 61.1/79.2

Eqv. 4550007520 S.TAN F931A106MAABMA

C83 4030017460 S.CER C1005 JB 1H 102K-T B 71.8/86.8

C84 4030017420 S.CER C1005 CH 1H 470J-T B 74.8/81.2

C85 4030017620 S.CER C1005 CH 1H 100C-T B 56.0/43.3

C86 4030016930 S.CER C1005 JB 1A 104K-T B 51.8/47.2

C87 4030018910 S.CER C1608 JB 0J 475K-T B 54.3/48.4

C90 4030017680 S.CER C1005 CH 1H 820J-T B 69.1/86.8

C91 4030016930 S.CER C1005 JB 1A 104K-T T 60.7/66.3

C92 4030016790 S.CER C1005 JB 1E 103K-T B 72.8/88.0

C93 4030017460 S.CER C1005 JB 1H 102K-T B 70.5/87.2

C94 4030017620 S.CER C1005 CH 1H 100C-T B 102.4/47.6

C95 4030017620 S.CER C1005 CH 1H 100C-T B 47.7/102.2

C96 4030018910 S.CER C1608 JB 0J 475K-T B 49.2/48.9

C97 4030016930 S.CER C1005 JB 1A 104K-T B 57.4/50.6

C98 4030017460 S.CER C1005 JB 1H 102K-T B 40.5/106.5

C99 4030017460 S.CER C1005 JB 1H 102K-T B 44.6/72.0

C100 4030017460 S.CER C1005 JB 1H 102K-T B 93.2/43.6

C104 4030016790 S.CER C1005 JB 1E 103K-T B 43.3/71.7

C105 4030017630 S.CER C1005 CH 1H 120J-T B 103.6/48.1

C106 4030017630 S.CER C1005 CH 1H 120J-T B 47.0/104.0

C107 4030017590 S.CER C1005 CH 1H 070C-T B 72.3/90.0

C108 4030017460 S.CER C1005 JB 1H 102K-T B 93.9/44.9

C109 4030017620 S.CER C1005 CH 1H 100C-T B 102.4/48.6

C110 4030017620 S.CER C1005 CH 1H 100C-T B 46.6/105.3

C111 4030016790 S.CER C1005 JB 1E 103K-T B 71.0/93.8

C114 4030017630 S.CER C1005 CH 1H 120J-T B 102.5/45.5

C116 4030017460 S.CER C1005 JB 1H 102K-T B 71.0/91.0

C117 4030016790 S.CER C1005 JB 1E 103K-T B 73.5/95.7

C118 4030016790 S.CER C1005 JB 1E 103K-T B 71.0/92.0

C121 4030016790 S.CER C1005 JB 1E 103K-T B 71.0/94.8

C122 4030016790 S.CER C1005 JB 1E 103K-T B 69.1/90.1

C123 4030016930 S.CER C1005 JB 1A 104K-T B 67.4/98.3

C124 4030016930 S.CER C1005 JB 1A 104K-T B 48.5/50.5

C125 4030016790 S.CER C1005 JB 1E 103K-T B 100.5/43.6

C126 4030016790 S.CER C1005 JB 1E 103K-T B 57.2/35.1

C127 4030016790 S.CER C1005 JB 1E 103K-T B 41.4/103.1

C128 4030017460 S.CER C1005 JB 1H 102K-T B 31.4/108.0

C131 4030017460 S.CER C1005 JB 1H 102K-T B 88.2/49.2

C133 4030017590 S.CER C1005 CH 1H 070C-T B 59.5/92.0

C134 4550008300 S.TAN F931V684MAA B 28.6/106.5

C135 4030019630 S.CER GRM31C2C1H104JA01L T 28.1/110.0

C136 4030016930 S.CER C1005 JB 1A 104K-T B 50.4/36.9

C137 4030017620 S.CER C1005 CH 1H 100C-T B 56.2/38.3

C138 4030017630 S.CER C1005 CH 1H 120J-T B 75.8/101.1

C139 4030017650 S.CER C1005 CH 1H 270J-T B 59.5/90.3

C140 4030016930 S.CER C1005 JB 1A 104K-T B 55.3/36.7

C141 4550008300 S.TAN F931V684MAA B 84.6/47.3

C144 4550006250 S.TAN TEESVA 1A 106M8R B 98.2/41.5

Eqv. 4550007520 S.TAN F931A106MAABMA

C145 4030017420 S.CER C1005 CH 1H 470J-T B 50.4/38.5

C146 4030017460 S.CER C1005 JB 1H 102K-T B 56.2/35.1

C147 4550006250 S.TAN TEESVA 1A 106M8R B 40.1/100.9

Eqv. 4550007520 S.TAN F931A106MAABMA

C149 4030016790 S.CER C1005 JB 1E 103K-T B 67.4/97.3

C150 4030016790 S.CER C1005 JB 1E 103K-T B 67.9/92.9

C151 4030017610 S.CER C1005 CH 1H 090C-T B 63.3/97.1

C152 4030016930 S.CER C1005 JB 1A 104K-T B 55.3/32.5

C153 4030017380 S.CER C1005 CH 1H 050B-T B 49.8/34.9

C154 4030017420 S.CER C1005 CH 1H 470J-T B 25.6/124.3

C155 4030017460 S.CER C1005 JB 1H 102K-T B 25.6/119.8

C156 4030017420 S.CER C1005 CH 1H 470J-T B 27.3/117.4

C157 4030017460 S.CER C1005 JB 1H 102K-T B 30.8/111.5

C158 4030017420 S.CER C1005 CH 1H 470J-T B 81.8/59.8

C159 4030017420 S.CER C1005 CH 1H 470J-T T 82.6/47.6

C160 4030016790 S.CER C1005 JB 1E 103K-T B 65.7/104.4

C161 4030016790 S.CER C1005 JB 1E 103K-T B 62.4/98.9

C162 4030018860 S.CER C1005 JB 0J 105K-T T 95.3/66.7

C163 4030019630 S.CER GRM31C2C1H104JA01L T 80.0/68.9

C164 4030016930 S.CER C1005 JB 1A 104K-T B 49.5/36.9

C165 4030019630 S.CER GRM31C2C1H104JA01L T 82.2/69.2

C166 4030017460 S.CER C1005 JB 1H 102K-T B 82.3/58.2

C167 4030017460 S.CER C1005 JB 1H 102K-T B 81.8/67.3

C168 4030017650 S.CER C1005 CH 1H 270J-T B 29.9/122.2

C169 4030017650 S.CER C1005 CH 1H 270J-T B 30.8/122.2

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

C370 4030011120 S.CER GRM31M2C2H100JV01L

(GRM42-6) B 97.4/123.5

C371 4030007060 S.CER C1608 CH 1H 270J-T T 35.5/142.5

C372 4030011050 S.CER GRM31M3C2H3R0CY21L

(GRM42-6) [#07] B 101.0/122.0

4030011050 S.CER GRM31M3C2H3R0CY21L

(GRM42-6) [#14]

4030011050 S.CER GRM31M3C2H3R0CY21L

(GRM42-6) [#15]

4030011050 S.CER GRM31M3C2H3R0CY21L

(GRM42-6) [#16]

4030011050 S.CER GRM31M3C2H3R0CY21L

(GRM42-6) [#36]

C373 4030017780 S.CER C1005 JB 1H 472K-T [#07] T 140.4/122.5

4030017780 S.CER C1005 JB 1H 472K-T [#14]

4030017780 S.CER C1005 JB 1H 472K-T [#15]

4030017780 S.CER C1005 JB 1H 472K-T [#16]

4030017760 S.CER C1005 JB 1H 222K-T [#23]

4030017760 S.CER C1005 JB 1H 222K-T [#35]

4030017780 S.CER C1005 JB 1H 472K-T [#36]

4030017760 S.CER C1005 JB 1H 222K-T [#37]

4030017760 S.CER C1005 JB 1H 222K-T [#82]

C374 4030017460 S.CER C1005 JB 1H 102K-T B 89.6/115.1

C375 4030017460 S.CER C1005 JB 1H 102K-T T 110.7/108.7

C376 4030017600 S.CER C1005 CH 1H 080C-T B 85.0/138.9

C377 4030017730 S.CER C1005 JB 1H 471K-T B 84.2/119.4

C378 4030017420 S.CER C1005 CH 1H 470J-T T 110.7/109.6

C379 4030017360 S.CER C1005 CH 1H 030B-T B 25.1/144.5

C380 4030017380 S.CER C1005 CH 1H 050B-T B 87.2/138.9

C381 4030017400 S.CER C1005 CH 1H 220J-T T 112.1/117.0

C382 4030017630 S.CER C1005 CH 1H 120J-T B 24.1/141.0

C383 4030017460 S.CER C1005 JB 1H 102K-T T 115.3/75.6

C384 4030020000 S.CER C1005 JB 1A 105K-T [#07] T 138.9/125.4

4030020000 S.CER C1005 JB 1A 105K-T [#14]

4030020000 S.CER C1005 JB 1A 105K-T [#15]

4030020000 S.CER C1005 JB 1A 105K-T [#16]

4030018890 S.CER C1005 JB 0J 224K-T [#23]

4030018890 S.CER C1005 JB 0J 224K-T [#35]

4030020000 S.CER C1005 JB 1A 105K-T [#36]

4030018890 S.CER C1005 JB 0J 224K-T [#37]

4030018890 S.CER C1005 JB 0J 224K-T [#82]

C385 4030017400 S.CER C1005 CH 1H 220J-T B 23.2/144.4

C386 4030017460 S.CER C1005 JB 1H 102K-T T 136.3/127.9

C387 4030017390 S.CER C1005 CH 1H 180J-T B 86.0/135.9

C388 4510009550 S.ELE EEEFK1C100R T 123.3/76.8

C389 4030019420 S.CER GRM31A7U2J102JW31D B 94.2/132.5

C390 4030011170 S.CER GRM31M2C2H180JV01L

(GRM42-6) B 84.7/131.6

C391 4030017460 S.CER C1005 JB 1H 102K-T T 115.3/74.0

C392 4030017520 S.CER C1005 CH 1H 0R3B-T B 86.0/130.0

C394 4550006250 S.TAN TEESVA 1A 106M8R B 26.3/15.3

Eqv. 4550007520 S.TAN F931A106MAABMA

C396 4510009550 S.ELE EEEFK1C100R T 97.1/77.8

C397 4030017460 S.CER C1005 JB 1H 102K-T T 136.6/122.5

C398 4550006250 S.TAN TEESVA 1A 106M8R B 31.7/15.5

Eqv. 4550007520 S.TAN F931A106MAABMA

C399 4030017460 S.CER C1005 JB 1H 102K-T T 100.0/76.1

C400 4030017460 S.CER C1005 JB 1H 102K-T B 85.6/103.9

C401 4030011170 S.CER GRM31M2C2H180JV01L

(GRM42-6) B 103.4/131.2

C402 4030016930 S.CER C1005 JB 1A 104K-T T 47.2/71.6

C404 4030017460 S.CER C1005 JB 1H 102K-T T 143.1/127.7

C405 4030017420 S.CER C1005 CH 1H 470J-T B 57.6/56.9

C406 4030016790 S.CER C1005 JB 1E 103K-T T 103.5/76.2

C408 4030017460 S.CER C1005 JB 1H 102K-T B 85.6/127.6

C409 4030011170 S.CER GRM31M2C2H180JV01L

(GRM42-6) B 112.4/131.2

C410 4030011170 S.CER GRM31M2C2H180JV01L

(GRM42-6) B 114.6/131.2

C411 4550007650 S.TAN F931V105MAABMA T 37.6/68.6

C412 4030017460 S.CER C1005 JB 1H 102K-T T 104.5/77.8

C413 4030016930 S.CER C1005 JB 1A 104K-T T 38.5/71.9

C414 4030017420 S.CER C1005 CH 1H 470J-T B 37.6/134.0

C415 4550007650 S.TAN F931V105MAABMA T 37.6/63.4

C416 4550006250 S.TAN TEESVA 1A 106M8R T 106.9/81.6

Eqv. 4550007520 S.TAN F931A106MAABMA

C417 4030016930 S.CER C1005 JB 1A 104K-T T 15.0/125.8

C418 4550007650 S.TAN F931V105MAABMA T 39.5/74.0

C419 4030011170 S.CER GRM31M2C2H180JV01L

(GRM42-6) B 117.3/131.2

C420 4030016930 S.CER C1005 JB 1A 104K-T B 27.4/18.5

C421 4030017460 S.CER C1005 JB 1H 102K-T B 86.5/127.6

C422 4030017730 S.CER C1005 JB 1H 471K-T B 119.6/139.5

C423 4030017460 S.CER C1005 JB 1H 102K-T B 121.5/145.1

C424 4030016930 S.CER C1005 JB 1A 104K-T T 14.1/125.8

C426 4030017640 S.CER C1005 CH 1H 150J-T B 120.9/139.5

C428 4030017390 S.CER C1005 CH 1H 180J-T B 144.3/86.6

C429 4030017460 S.CER C1005 JB 1H 102K-T B 122.4/143.4

C431 4030018860 S.CER C1005 JB 0J 105K-T B 33.3/13.6

C432 4030016930 S.CER C1005 JB 1A 104K-T T 10.8/120.7

C433 4030017730 S.CER C1005 JB 1H 471K-T B 139.5/138.1

C434 4030017460 S.CER C1005 JB 1H 102K-T B 137.7/133.5

C435 4030017460 S.CER C1005 JB 1H 102K-T T 54.9/29.9

C436 4030011170 S.CER GRM31M2C2H180JV01L

(GRM42-6) B 143.7/137.0

C437 4030016930 S.CER C1005 JB 1A 104K-T B 34.4/12.0

C438 4030016790 S.CER C1005 JB 1E 103K-T T 109.7/89.0

C439 4510009810 S.ELE EEEFK1E220R T 129.9/96.8

C440 4030018900 S.CER C1005 JB 0J 474K-T T 8.0/129.6

C441 4030017440 S.CER C1005 CH 1H 221J-T T 12.0/126.2

C442 4510008780 S.ELE EEE1EA471P B 9.6/119.8

C443 4030017460 S.CER C1005 JB 1H 102K-T T 108.8/89.0

C444 4030011170 S.CER GRM31M2C2H180JV01L

(GRM42-6) B 147.0/149.0

C445 4030017640 S.CER C1005 CH 1H 150J-T B 26.1/141.0

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

C276 4030017630 S.CER C1005 CH 1H 120J-T B 71.9/139.9

C277 4030016790 S.CER C1005 JB 1E 103K-T T 48.7/36.8

C278 4030017460 S.CER C1005 JB 1H 102K-T B 101.8/62.0

C279 4030017390 S.CER C1005 CH 1H 180J-T B 59.6/120.9

C280 4030017460 S.CER C1005 JB 1H 102K-T B 98.9/66.3

C281 4030017460 S.CER C1005 JB 1H 102K-T B 100.0/62.0

C282 4030017630 S.CER C1005 CH 1H 120J-T B 61.4/122.2

C283 4030017620 S.CER C1005 CH 1H 100C-T B 103.7/65.9

C286 4030017570 S.CER C1005 CH 1H 040B-T B 61.4/140.3

C287 4030017350 S.CER C1005 CH 1H 020B-T B 58.2/138.5

C288 4030017570 S.CER C1005 CH 1H 040B-T B 64.1/139.8

C289 4030017600 S.CER C1005 CH 1H 080C-T B 71.9/135.7

C290 4030017600 S.CER C1005 CH 1H 080C-T B 70.7/139.5

C291 4030017340 S.CER C1005 CH 1H 010B-T B 102.4/66.6

C292 4030017460 S.CER C1005 JB 1H 102K-T B 61.4/136.7

C295 4030017460 S.CER C1005 JB 1H 102K-T B 61.4/135.8

C296 4030019420 S.CER GRM31A7U2J102JW31D B 98.7/132.7

C297 4030017580 S.CER C1005 CH 1H 060C-T B 88.8/138.9

C298 4030017460 S.CER C1005 JB 1H 102K-T B 132.9/86.7

C299 4030017460 S.CER C1005 JB 1H 102K-T B 58.2/137.6

C300 4030017460 S.CER C1005 JB 1H 102K-T B 58.2/134.9

C301 4030016790 S.CER C1005 JB 1E 103K-T B 58.2/136.7

C302 4030017460 S.CER C1005 JB 1H 102K-T B 54.2/139.8

C304 4030017420 S.CER C1005 CH 1H 470J-T B 133.8/86.7

C305 4030017420 S.CER C1005 CH 1H 470J-T B 47.4/134.3

C306 4030017460 S.CER C1005 JB 1H 102K-T B 48.4/134.3

C307 4030017460 S.CER C1005 JB 1H 102K-T B 46.5/138.8

C309 4030016790 S.CER C1005 JB 1E 103K-T B 134.7/88.4

C310 4030017460 S.CER C1005 JB 1H 102K-T B 136.5/86.7

C311 4030016930 S.CER C1005 JB 1A 104K-T B 46.5/140.4

C312 4030016930 S.CER C1005 JB 1A 104K-T B 51.4/142.5

C313 4030016930 S.CER C1005 JB 1A 104K-T B 47.4/140.4

C314 4030017460 S.CER C1005 JB 1H 102K-T B 50.4/142.5

C315 4030017730 S.CER C1005 JB 1H 471K-T B 136.5/92.3

C318 4030017460 S.CER C1005 JB 1H 102K-T [#23] T 117.8/106.3

4030017460 S.CER C1005 JB 1H 102K-T [#35]

4030017460 S.CER C1005 JB 1H 102K-T [#37]

4030017460 S.CER C1005 JB 1H 102K-T [#82]

C319 4030017460 S.CER C1005 JB 1H 102K-T [#23] T 117.8/105.4

4030017460 S.CER C1005 JB 1H 102K-T [#35]

4030017460 S.CER C1005 JB 1H 102K-T [#37]

4030017460 S.CER C1005 JB 1H 102K-T [#82]

C320 4030017460 S.CER C1005 JB 1H 102K-T [#23] T 115.2/106.3

4030017460 S.CER C1005 JB 1H 102K-T [#35]

4030017460 S.CER C1005 JB 1H 102K-T [#37]

4030017460 S.CER C1005 JB 1H 102K-T [#82]

C321 4030017420 S.CER C1005 CH 1H 470J-T T 66.0/57.5

C322 4030017420 S.CER C1005 CH 1H 470J-T T 62.3/52.9

C323 4030017560 S.CER C1005 CH 1H 2R5B-T B 45.6/138.8

C324 4030017460 S.CER C1005 JB 1H 102K-T B 135.6/83.3

C325 4030017460 S.CER C1005 JB 1H 102K-T B 134.7/90.1

C327 4030017640 S.CER C1005 CH 1H 150J-T B 142.8/85.0

C328 4030017420 S.CER C1005 CH 1H 470J-T B 137.8/92.3

C329 4030017460 S.CER C1005 JB 1H 102K-T B 36.0/142.3

C330 4030017460 S.CER C1005 JB 1H 102K-T B 138.9/92.3

C331 4030017460 S.CER C1005 JB 1H 102K-T B 60.4/142.5

C332 4030017460 S.CER C1005 JB 1H 102K-T B 56.0/142.5

C333 4030016930 S.CER C1005 JB 1A 104K-T T 23.1/29.4

C334 4510009810 S.ELE EEEFK1E220R T 137.5/89.8

C335 4030017390 S.CER C1005 CH 1H 180J-T B 144.3/89.3

C336 4030017420 S.CER C1005 CH 1H 470J-T B 61.3/142.5

C337 4030017400 S.CER C1005 CH 1H 220J-T B 144.3/88.2

C338 4030017460 S.CER C1005 JB 1H 102K-T B 36.0/139.4

C339 4030017460 S.CER C1005 JB 1H 102K-T B 36.0/135.7

C340 4030016930 S.CER C1005 JB 1A 104K-T T 54.0/20.4

C341 4030017420 S.CER C1005 CH 1H 470J-T B 132.9/90.1

C342 4030017730 S.CER C1005 JB 1H 471K-T T 138.8/108.0

C345 4030017460 S.CER C1005 JB 1H 102K-T B 36.0/134.8

C346 4030017420 S.CER C1005 CH 1H 470J-T T 63.2/56.9

C347 4030017460 S.CER C1005 JB 1H 102K-T T 145.0/127.7

C348 4030017420 S.CER C1005 CH 1H 470J-T T 64.2/55.5

C349 4030017400 S.CER C1005 CH 1H 220J-T B 144.2/91.0

C350 4030017420 S.CER C1005 CH 1H 470J-T T 138.7/112.3

C351 4030017460 S.CER C1005 JB 1H 102K-T T 138.7/113.2

C353 4030017460 S.CER C1005 JB 1H 102K-T T 140.4/127.7

C354 4030017420 S.CER C1005 CH 1H 470J-T T 113.0/117.0

C355 4030017340 S.CER C1005 CH 1H 010B-T B 34.4/134.0

C357 4030017640 S.CER C1005 CH 1H 150J-T B 36.0/140.7

C358 4030016790 S.CER C1005 JB 1E 103K-T T 142.2/127.7

C359 4510009550 S.ELE EEEFK1C100R T 105.3/87.6

C360 4030017460 S.CER C1005 JB 1H 102K-T T 113.9/117.0

C362 4030017370 S.CER C1005 CH 1H 3R5B-T B 30.7/141.2

C364 4030011040 S.CER GRM31M4C2H2R0CY21L

(GRM42-6) [#07] B 93.3/119.3

4030011040 S.CER GRM31M4C2H2R0CY21L

(GRM42-6) [#14]

4030011040 S.CER GRM31M4C2H2R0CY21L

(GRM42-6) [#15]

4030011040 S.CER GRM31M4C2H2R0CY21L

(GRM42-6) [#16]

4030011040 S.CER GRM31M4C2H2R0CY21L

(GRM42-6) [#36]

C365 4030017730 S.CER C1005 JB 1H 471K-T T 114.8/117.0

C366 4030016780 S.CER C1005 JB 1E 153K-T [#07] T 145.0/124.4

4030016780 S.CER C1005 JB 1E 153K-T [#14]

4030016780 S.CER C1005 JB 1E 153K-T [#15]

4030016780 S.CER C1005 JB 1E 153K-T [#16]

4030016790 S.CER C1005 JB 1E 103K-T [#23]

4030016790 S.CER C1005 JB 1E 103K-T [#35]

4030016780 S.CER C1005 JB 1E 153K-T [#36]

4030016790 S.CER C1005 JB 1E 103K-T [#37]

4030016790 S.CER C1005 JB 1E 103K-T [#82]

C367 4510009810 S.ELE EEEFK1E220R T 110.3/113.1

C368 4030006860 S.CER C1608 JB 1H 102K-T T 87.7/142.0

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

C553 4030016930 S.CER C1005 JB 1A 104K-T B 30.8/19.4

C555 4030016930 S.CER C1005 JB 1A 104K-T B 69.8/75.5

C556 4030019990 S.CER C1005 JB 1C 104K-T T 105.2/28.6

C557 4030016930 S.CER C1005 JB 1A 104K-T T 97.0/28.6

C558 4550006250 S.TAN TEESVA 1A 106M8R T 95.1/27.9

Eqv. 4550007520 S.TAN F931A106MAABMA

C559 4550006250 S.TAN TEESVA 1A 106M8R T 45.9/75.5

Eqv. 4550007520 S.TAN F931A106MAABMA

C562 4030017420 S.CER C1005 CH 1H 470J-T T 38.4/76.1

C563 4030019630 S.CER GRM31C2C1H104JA01L T 24.1/119.4

C566 4030018860 S.CER C1005 JB 0J 105K-T B 46.9/70.8

C568 4030018100 S.CER C1005 JB 1H 681K-T T 89.8/58.8

C570 4030017430 S.CER C1005 CH 1H 101J-T B 70.7/136.1

C571 4030017580 S.CER C1005 CH 1H 060C-T T 64.0/99.1

C572 4030017580 S.CER C1005 CH 1H 060C-T T 64.9/99.1

C573 4030017580 S.CER C1005 CH 1H 060C-T T 64.7/97.8

C574 4030017580 S.CER C1005 CH 1H 060C-T B 61.4/134.9

C575 4030017420 S.CER C1005 CH 1H 470J-T B 61.4/134.0

C576 4030017460 S.CER C1005 JB 1H 102K-T T 67.3/105.8

C577 4030017460 S.CER C1005 JB 1H 102K-T T 67.3/104.9

C578 4030019420 S.CER GRM31A7U2J102JW31D T 90.8/126.0

C579 4550006250 S.TAN TEESVA 1A 106M8R B 98.1/46.6

Eqv. 4550007520 S.TAN F931A106MAABMA

C580 4030017420 S.CER C1005 CH 1H 470J-T T 100.7/73.5

C581 4030018910 S.CER C1608 JB 0J 475K-T B 46.3/60.9

C582 4030018910 S.CER C1608 JB 0J 475K-T B 65.2/61.3

C583 4030016930 S.CER C1005 JB 1A 104K-T B 46.3/58.6

C584 4030016790 S.CER C1005 JB 1E 103K-T B 56.7/55.3

C585 4030016930 S.CER C1005 JB 1A 104K-T B 54.9/58.6

C586 4030017730 S.CER C1005 JB 1H 471K-T B 54.9/56.9

C587 4030016790 S.CER C1005 JB 1E 103K-T B 52.3/59.8

C588 4030018910 S.CER C1608 JB 0J 475K-T B 65.2/62.5

C601 4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#07] T 97.6/111.3

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#14]

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#15]

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#16]

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#36]

C610 4030018080 S.CER C1005 JB 1H 182K-T T 63.3/69.6

C612 4030017460 S.CER C1005 JB 1H 102K-T B 55.7/29.9

C614 4030017730 S.CER C1005 JB 1H 471K-T B 29.0/13.2

C616 4030017460 S.CER C1005 JB 1H 102K-T T 95.3/62.2

C617 4030017420 S.CER C1005 CH 1H 470J-T B 134.1/43.7

C618 4030017420 S.CER C1005 CH 1H 470J-T T 64.2/53.8

C619 4030017420 S.CER C1005 CH 1H 470J-T T 76.8/109.5

C620 4030017420 S.CER C1005 CH 1H 470J-T T 73.8/97.8

C621 4030017420 S.CER C1005 CH 1H 470J-T T 31.5/2.8

C622 4030019560 S.CER GRM21BB31C106KE15L T 64.5/73.4

C623 4030019990 S.CER C1005 JB 1C 104K-T B 126.8/16.0

C624 4030019990 S.CER C1005 JB 1C 104K-T B 126.3/20.3

C625 4030017460 S.CER C1005 JB 1H 102K-T B 126.8/17.2

C626 4510009810 S.ELE EEEFK1E220R B 129.4/23.0

C629 4030016790 S.CER C1005 JB 1E 103K-T B 113.2/27.1

C630 4030016930 S.CER C1005 JB 1A 104K-T B 108.8/27.1

C631 4550007080 S.TAN TEESVA 1C 106M8R B 104.6/26.8

Eqv. 4550008220 S.TAN F931C106MAA

C632 4550007080 S.TAN TEESVA 1C 106M8R B 111.0/23.3

Eqv. 4550008220 S.TAN F931C106MAA

C633 4550007080 S.TAN TEESVA 1C 106M8R B 105.8/23.3

Eqv. 4550008220 S.TAN F931C106MAA

C634 4030017460 S.CER C1005 JB 1H 102K-T B 108.4/22.1

C645 4030016930 S.CER C1005 JB 1A 104K-T T 57.2/46.7

C648 4510009680 S.ELE EEEFK1E471P B 85.7/23.3

C649 4030018860 S.CER C1005 JB 0J 105K-T T 71.2/64.2

C650 4030019120 S.CER GRM188B31E105KA75D T 11.7/133.7

C652 4030016930 S.CER C1005 JB 1A 104K-T B 33.9/59.0

C653 4030019560 S.CER GRM21BB31C106KE15L B 31.9/59.9

C656 4030016930 S.CER C1005 JB 1A 104K-T B 34.8/62.1

C657 4030019560 S.CER GRM21BB31C106KE15L T 35.6/64.8

C658 4030016930 S.CER C1005 JB 1A 104K-T B 36.8/63.4

C659 4030019560 S.CER GRM21BB31C106KE15L B 30.1/62.3

C660 4030016930 S.CER C1005 JB 1A 104K-T B 38.9/63.3

C661 4030019560 S.CER GRM21BB31C106KE15L B 43.2/62.7

C662 4030017490 S.CER C1608 JB 1A 105K-T T 75.0/15.6

C663 4030017490 S.CER C1608 JB 1A 105K-T T 69.9/15.6

C664 4030017490 S.CER C1608 JB 1A 105K-T T 74.4/24.2

C665 4030017490 S.CER C1608 JB 1A 105K-T T 69.9/24.2

C666 4550006250 S.TAN TEESVA 1A 106M8R T 76.7/15.3

Eqv. 4550007520 S.TAN F931A106MAABMA

C667 4550006250 S.TAN TEESVA 1A 106M8R T 71.6/15.2

Eqv. 4550007520 S.TAN F931A106MAABMA

C668 4550006250 S.TAN TEESVA 1A 106M8R T 76.1/25.0

Eqv. 4550007520 S.TAN F931A106MAABMA

C669 4550006250 S.TAN TEESVA 1A 106M8R T 71.6/25.0

Eqv. 4550007520 S.TAN F931A106MAABMA

C670 4030016930 S.CER C1005 JB 1A 104K-T B 44.2/34.2

C689 4030017400 S.CER C1005 CH 1H 220J-T B 134.0/82.8

C690 4030017360 S.CER C1005 CH 1H 030B-T B 30.7/140.3

C700 4030018900 S.CER C1005 JB 0J 474K-T T 124.9/44.5

C701 4030018900 S.CER C1005 JB 0J 474K-T T 124.9/45.4

C702 4030016930 S.CER C1005 JB 1A 104K-T B 122.8/46.0

C703 4030017460 S.CER C1005 JB 1H 102K-T T 121.2/42.5

C704 4030017460 S.CER C1005 JB 1H 102K-T T 119.2/40.6

C705 4030017460 S.CER C1005 JB 1H 102K-T T 121.6/44.6

C706 4030016930 S.CER C1005 JB 1A 104K-T B 121.9/47.7

C707 4030016930 S.CER C1005 JB 1A 104K-T B 121.0/47.7

C709 4030019460 S.CER C1608 JB 0J 106M-T B 119.9/48.2

C710 4030016930 S.CER C1005 JB 1A 104K-T B 118.4/47.1

C711 4030017460 S.CER C1005 JB 1H 102K-T B 118.4/46.2

C712 4030016930 S.CER C1005 JB 1A 104K-T T 115.9/44.4

C713 4030019630 S.CER GRM31C2C1H104JA01L B 83.9/45.2

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

C446 4030017460 S.CER C1005 JB 1H 102K-T T 6.7/130.1

C448 4030017460 S.CER C1005 JB 1H 102K-T T 126.9/103.4

C449 4510008870 S.ELE EEE1AA471UP B 8.9/139.2

C450 4030019090 S.CER C2012 JB 1C 225M-T T 7.5/125.1

C451 4030018860 S.CER C1005 JB 0J 105K-T T 9.7/125.5

C452 4030018860 S.CER C1005 JB 0J 105K-T T 71.5/98.2

C453 4030017460 S.CER C1005 JB 1H 102K-T T 127.9/103.4

C454 4030017430 S.CER C1005 CH 1H 101J-T B 46.3/56.9

C458 4030017460 S.CER C1005 JB 1H 102K-T T 129.6/113.3

C459 4030017460 S.CER C1005 JB 1H 102K-T T 117.8/117.7

C460 4030017460 S.CER C1005 JB 1H 102K-T B 9.7/147.4

C461 4030017420 S.CER C1005 CH 1H 470J-T T 130.5/113.3

C462 4030017420 S.CER C1005 CH 1H 470J-T T 117.8/116.7

C463 4030017420 S.CER C1005 CH 1H 470J-T B 9.7/146.5

C464 4510009680 S.ELE EEEFK1E471P B 144.4/121.1

C465 4550008050 S.TAN TCFGA1C106M8R T 96.1/87.8

C466 4030017420 S.CER C1005 CH 1H 470J-T T 99.9/88.1

C467 4030016930 S.CER C1005 JB 1A 104K-T T 62.3/58.5

C468 4030016930 S.CER C1005 JB 1A 104K-T T 61.8/56.9

C469 4030017460 S.CER C1005 JB 1H 102K-T B 141.3/90.1

C470 4030018860 S.CER C1005 JB 0J 105K-T T 7.5/122.3

C471 4030016790 S.CER C1005 JB 1E 103K-T T 6.2/123.6

C472 4030018860 S.CER C1005 JB 0J 105K-T T 11.0/117.8

C473 4030018860 S.CER C1005 JB 0J 105K-T T 5.1/118.9

C474 4030017780 S.CER C1005 JB 1H 472K-T T 115.3/17.6

C475 4510009700 S.ELE EEEFK1C101P T 125.1/12.1

C476 4510009700 S.ELE EEEFK1C101P T 125.1/19.3

C477 4030017780 S.CER C1005 JB 1H 472K-T T 118.9/12.2

C478 4030017780 S.CER C1005 JB 1H 472K-T T 115.3/12.2

C479 4510009700 S.ELE EEEFK1C101P T 104.8/14.3

C481 4030017460 S.CER C1005 JB 1H 102K-T B 63.2/122.2

C491 4030016930 S.CER C1005 JB 1A 104K-T T 60.4/60.1

C492 4030016930 S.CER C1005 JB 1A 104K-T B 13.5/32.6

C493 4510008870 S.ELE EEE1AA471UP B 66.3/45.3

C494 4030019990 S.CER C1005 JB 1C 104K-T T 101.5/92.0

C495 4030016930 S.CER C1005 JB 1A 104K-T T 101.5/90.1

C496 4030019990 S.CER C1005 JB 1C 104K-T T 123.3/92.9

C497 4030016930 S.CER C1005 JB 1A 104K-T T 109.9/81.2

C498 4030016930 S.CER C1005 JB 1A 104K-T T 11.5/43.3

C501 4030017420 S.CER C1005 CH 1H 470J-T T 11.7/31.2

C502 4030017460 S.CER C1005 JB 1H 102K-T T 29.5/2.8

C503 4030017420 S.CER C1005 CH 1H 470J-T T 48.0/99.4

C506 4030016930 S.CER C1005 JB 1A 104K-T B 26.3/43.4

C507 4030016930 S.CER C1005 JB 1A 104K-T B 32.9/31.0

C508 4030016930 S.CER C1005 JB 1A 104K-T B 40.2/42.7

C509 4030016930 S.CER C1005 JB 1A 104K-T B 26.3/39.1

C510 4030016930 S.CER C1005 JB 1A 104K-T B 26.6/33.0

C511 4030016930 S.CER C1005 JB 1A 104K-T B 40.1/34.2

C512 4030017420 S.CER C1005 CH 1H 470J-T T 92.1/14.8

C513 4550006250 S.TAN TEESVA 1A 106M8R B 7.0/53.7

Eqv. 4550007520 S.TAN F931A106MAABMA

C514 4030016930 S.CER C1005 JB 1A 104K-T B 11.7/53.5

C515 4030016930 S.CER C1005 JB 1A 104K-T B 15.6/54.5

C516 4030016930 S.CER C1005 JB 1A 104K-T T 65.1/69.6

C517 4030016930 S.CER C1005 JB 1A 104K-T B 17.3/59.6

C518 4030016930 S.CER C1005 JB 1A 104K-T B 12.8/62.9

C519 4030017460 S.CER C1005 JB 1H 102K-T B 14.0/62.6

C521 4030016930 S.CER C1005 JB 1A 104K-T B 18.1/53.6

C522 4030016930 S.CER C1005 JB 1A 104K-T T 51.2/31.8

C523 4030016930 S.CER C1005 JB 1A 104K-T T 51.2/33.0

C524 4030018910 S.CER C1608 JB 0J 475K-T T 9.5/56.0

C525 4030018910 S.CER C1608 JB 0J 475K-T B 25.8/58.3

C526 4030018100 S.CER C1005 JB 1H 681K-T B 29.9/58.0

C527 4030016790 S.CER C1005 JB 1E 103K-T B 26.1/50.3

C528 4030017670 S.CER C1005 CH 1H 390J-T B 37.6/120.7

C529 4030017630 S.CER C1005 CH 1H 120J-T B 39.0/112.2

C530 4030017420 S.CER C1005 CH 1H 470J-T T 58.7/62.6

C531 4030017670 S.CER C1005 CH 1H 390J-T B 93.0/61.9

C532 4030017670 S.CER C1005 CH 1H 390J-T B 94.5/52.0

C533 4510009700 S.ELE EEEFK1C101P T 125.1/26.4

C534 4030016790 S.CER C1005 JB 1E 103K-T T 118.4/26.7

C535 4030016790 S.CER C1005 JB 1E 103K-T B 66.4/102.5

C536 4030016790 S.CER C1005 JB 1E 103K-T B 64.8/99.1

C538 4030006860 S.CER C1608 JB 1H 102K-T T 36.3/145.1

C539 4030017790 S.CER C1005 JB 1H 682K-T T 22.8/57.0

C540 4030017730 S.CER C1005 JB 1H 471K-T T 21.2/56.6

C541 4030016930 S.CER C1005 JB 1A 104K-T T 22.8/55.4

C542 4030017440 S.CER C1005 CH 1H 221J-T T 27.1/55.0

C543 4030016930 S.CER C1005 JB 1A 104K-T T 56.3/68.9

C544 4030017460 S.CER C1005 JB 1H 102K-T T 62.4/72.9

C545 4030011120 S.CER GRM31M2C2H100JV01L

(GRM42-6) [#07] T 97.6/106.8

4030011120 S.CER GRM31M2C2H100JV01L

(GRM42-6) [#14]

4030011120 S.CER GRM31M2C2H100JV01L

(GRM42-6) [#15]

4030011120 S.CER GRM31M2C2H100JV01L

(GRM42-6) [#16]

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#23]

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#35]

4030011120 S.CER GRM31M2C2H100JV01L

(GRM42-6) [#36]

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#37]

4030011100 S.CER GRM31M2C2H8R0DV01L

(GRM42-6) [#82]

C546 4030019560 S.CER GRM21BB31C106KE15L T 63.1/63.9

C547 4030017770 S.CER C1005 JB 1H 332K-T T 53.9/72.2

C548 4030016930 S.CER C1005 JB 1A 104K-T T 14.1/120.6

C549 4030017420 S.CER C1005 CH 1H 470J-T T 23.1/86.6

C550 4030017420 S.CER C1005 CH 1H 470J-T T 71.5/85.1

C551 4030019990 S.CER C1005 JB 1C 104K-T T 114.1/28.1

C552 4030016930 S.CER C1005 JB 1A 104K-T T 117.8/43.0

July 2016 (Amended page)

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on PART orders and repairs.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PART DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN-B UNIT]

C714 4030019630 S.CER GRM31C2C1H104JA01L B 83.9/43.1

C715 4030019630 S.CER GRM31C2C1H104JA01L B 83.9/40.9

C716 4030019630 S.CER GRM31C2C1H104JA01L T 83.9/46.0

C717 4030019630 S.CER GRM31C2C1H104JA01L T 83.9/43.8

C719 4030016930 S.CER C1005 JB 1A 104K-T B 117.4/39.5

C720 4030016930 S.CER C1005 JB 1A 104K-T B 116.3/62.0

C721 4030020000 S.CER C1005 JB 1A 105K-T B 113.4/57.3

C725 4030018900 S.CER C1005 JB 0J 474K-T T 35.3/78.8

C726 4030018900 S.CER C1005 JB 0J 474K-T T 32.8/78.3

C727 4030016930 S.CER C1005 JB 1A 104K-T B 35.4/80.1

C728 4030017460 S.CER C1005 JB 1H 102K-T T 34.2/81.4

C729 4030017460 S.CER C1005 JB 1H 102K-T T 33.0/79.7

C730 4030017460 S.CER C1005 JB 1H 102K-T T 33.3/81.4

C731 4030016930 S.CER C1005 JB 1A 104K-T B 37.0/80.5

C732 4030016930 S.CER C1005 JB 1A 104K-T B 36.6/81.4

C734 4030019460 S.CER C1608 JB 0J 106M-T B 37.4/82.5

C735 4030016930 S.CER C1005 JB 1A 104K-T B 36.6/84.2

C736 4030017460 S.CER C1005 JB 1H 102K-T B 35.7/84.2

C737 4030016930 S.CER C1005 JB 1A 104K-T T 31.7/84.5

C738 4030016930 S.CER C1005 JB 1A 104K-T T 32.2/85.4

C739 4030019630 S.CER GRM31C2C1H104JA01L B 28.5/104.1

C740 4030019630 S.CER GRM31C2C1H104JA01L B 28.5/102.0

C741 4030019630 S.CER GRM31C2C1H104JA01L B 28.5/99.9

C742 4030019630 S.CER GRM31C2C1H104JA01L T 28.5/102.5

C743 4030019630 S.CER GRM31C2C1H104JA01L T 28.5/100.4

C746 4030020000 S.CER C1005 JB 1A 105K-T B 29.2/88.2

C747 4030020000 S.CER C1005 JB 1A 105K-T B 20.6/88.3

C752 4030017400 S.CER C1005 CH 1H 220J-T B 16.9/37.5

C753 4030017400 S.CER C1005 CH 1H 220J-T B 43.1/60.4

C755 4030017640 S.CER C1005 CH 1H 150J-T B 46.5/35.6

C756 4030017400 S.CER C1005 CH 1H 220J-T T 18.4/20.2

C760 4030017390 S.CER C1005 CH 1H 180J-T T 29.4/140.6

C761 4030017640 S.CER C1005 CH 1H 150J-T T 32.3/140.6

C762 4030017340 S.CER C1005 CH 1H 010B-T T 30.9/140.8

J1 6510026770 S.CON AXK540147YG T 23.1/63.7

J2 6510023092 S.CON 20FLT-SM2-TB(LF)(SN)(M) T 15.1/15.6

J4 6510023512 S.CON 28FLT-SM2-TB(LF)(SN)(M) T 70.9/102.1

J5 6510023110 CON 3008L-8P8C

J6 6450002470 CON JY-3510A1-130

J8 6510023092 S.CON 20FLT-SM2-TB(LF)(SN)(M) T 58.9/15.7

J9 6510019371 S.CON B3B-ZR-SM4-TF(LF)(SN) T 94.7/14.3

J10 6510004910 CON NR-DS-E 01

J11 6510004910 CON NR-DS-E 01

J12 6510025970 S.CON 41-002AA-R T 58.7/44.6

DS1 5040002961 S.LED SML-A12MT T86J B 96.0/1.1

DS2 5040002961 S.LED SML-A12MT T86J B 126.0/1.1

DS3 5040003001 S.LED SML-A12UT T86J B 111.0/1.1

MF1 2710000870 FAN AFB0512HB-7X22 HK

W1 7030014230 JUM RJ20S0OHM

W2 7030014230 JUM RJ20S0OHM

W4 8920000830 C_C CAB-1116

W5 8900020500 CAB OPC-2249 [#37]

8900020500 CAB OPC-2249 [#82]

EP1 6910024570 S.BEA MMZ1005A601ET B 134.1/46.4

EP2 6910015370 S.BEA ACZ1005Y-102-T T 120.4/39.9

EP3 6910015370 S.BEA ACZ1005Y-102-T T 35.5/80.1

EP4 6910016330 S.BEA MMZ1005S 601CT-S B 28.7/62.0

EP5 6910016330 S.BEA MMZ1005S 601CT-S B 41.3/73.9

EP6 6910015370 S.BEA ACZ1005Y-102-T B 39.5/109.0

EP7 6910016330 S.BEA MMZ1005S 601CT-S B 40.7/36.7

EP8 6910015370 S.BEA ACZ1005Y-102-T B 96.1/48.8

EP9 6910016330 S.BEA MMZ1005S 601CT-S T 48.9/39.4

EP10 6910011560 BEA HF70BB4.5X5X1.6

EP13 6910011330 TER OT-009 M3

EP14 6910011330 TER OT-009 M3

EP16 6910018460 S.BEA MMZ1005Y102C-T T 64.1/105.0

EP17 6910018460 S.BEA MMZ1005Y102C-T T 65.1/105.0

EP18 6910018460 S.BEA MMZ1005Y102C-T T 66.1/105.0

EP19 6910018460 S.BEA MMZ1005Y102C-T T 66.1/106.8

EP20 6910018460 S.BEA MMZ1005Y102C-T T 62.8/98.7

EP21 6910018460 S.BEA MMZ1005Y102C-T T 62.8/99.6

EP22 6910018460 S.BEA MMZ1005Y102C-T T 74.1/105.0

EP23 6910018460 S.BEA MMZ1005Y102C-T T 73.2/105.0

EP24 6910018460 S.BEA MMZ1005Y102C-T T 72.3/105.0

EP25 6910018460 S.BEA MMZ1005Y102C-T T 71.1/105.0

EP26 6910018460 S.BEA MMZ1005Y102C-T T 72.4/99.0

EP27 6910018460 S.BEA MMZ1005Y102C-T T 68.2/99.1

EP28 6910018460 S.BEA MMZ1005Y102C-T T 67.3/99.1

EP29 6910018460 S.BEA MMZ1005Y102C-T T 65.8/99.1

EP30 6910018460 S.BEA MMZ1005Y102C-T T 74.3/99.0

EP31 6910018460 S.BEA MMZ1005Y102C-T T 70.6/98.2

EP32 6910023420 S.BEA MMZ1005A222ET B 44.8/60.4

EP33 6910024570 S.BEA MMZ1005A601ET B 134.6/45.1

EP34 6910021240 S.BEA MMZ1005A152ET B 36.2/70.3

EP35 6910021770 S.BEA MMZ1005F560CT B 17.8/37.5

EP37 6910021770 S.BEA MMZ1005F560CT B 44.0/47.8

EP38 6910021770 S.BEA MMZ1005F560CT B 46.4/36.5

July 2016 (Amended page)

SECTION 9 BOARD LAYOUTS

• MAIN-B UNIT B-8211B

(TOP VIEW)

C14

C15

C17

C18

C20

C23

C26

C30

C31

C33

C48

C63

C77

C91

C135

C159

C162

C163

C165

C175

C179 C183

C186

C187

C199

C204

C205

C206

C208

C209

C210

C228

C229

C230

C231

C232

C233

C235

C240

C245

C255

C256

C257

C259

C262

C266

C269

C270

C272

C277

C318

C319

C320

C321

C322

C333

C334

C340

C342

C346

C347

C348

C350

C351

C353

C354

C358

C359

C360

C365

C366

C367

C368

C371

C373

C375

C378

C381

C383

C384

C386

C388

C391

C396

C397

C399

C402

C404

C406

C411

C412

C413

C415

C416

C417

C418

C424

C432

C435

C438

C439

C440

C441

C443

C446

C448

C450

C451

C452

C453

C458

C459

C461

C462

C465

C466

C467

C468

C470

C471

C472

C473

C474

C475

C476

C477

C478

C479

C491

C494C495

C496

C497

C498

C501

C502

C503

C512

C516

C522

C523

C524

C530

C533

C534

C538

C539

C540

C541

C542

C543

C544

C545

C546

C547

C548

C549

C550

C551

C552

C556

C557

C558

C559

C562

C563

C568

C571

C572

C573

C576

C577

C578

C580

C601

C610

C616

C618

C619

C620

C621

C622

C645

C649

C650

C657

C662

C663

C664

C665

C666

C667

C668

C669

C700

C701

C703

C704

C705

C712

C716

C717

C725

C726

C728

C729

C730

C737

C738

C742

C743

C756

C760

C761

C762

D19

D20

D36

D37

D40

D46

D47

D51

D53

D55

D56

D61

D64 D65 D66

D67

D68

D69 D70

D71 D72 D73 D74

D81

EP2

EP3

EP9

EP13

EP14

EP16

EP17

EP18 EP19

EP20

EP21

EP22

EP23

EP24

EP25

EP26

EP27

EP28

EP29

EP30

EP31

FI5

FI6

FI7

IC1

IC2

IC13

IC14 IC15

IC17

IC18

IC20

IC21

IC23

IC26

IC27

IC28

IC29

IC30

IC31

IC37

IC38

IC39

IC43IC44

J12

L31

L58

L61

L70

MP33

Q29Q31

Q40

Q41

Q42

Q43

Q44

Q45

Q46

Q48

Q49

Q52Q53

Q56

Q57

Q58

Q59

Q61

Q62

Q69

Q70

Q77 Q78

R10

R17

R20

R26

R27

R34

R35

R36

R38

R39

R40

R46

R49

R56

R63

R90

R127

R138

R139

R141

R146

R158

R186

R187

R188

R189

R190

R197

R199

R202

R204

R205

R209

R212

R213

R216

R217

R220

R222

R224

R227

R230

R232

R234

R235

R238

R239

R244

R245

R257

R261

R262

R263

R264

R267

R268

R271

R272 R273

R275

R277

R278

R279

R280

R281

R282

R283

R285

R287

R288

R290

R291

R292

R295

R296

R297

R298

R300

R303

R308

R309

R310

R311

R312

R313

R314

R316

R320

R326

R331

R334

R335

R336

R337

R339

R346

R347

R352

R354

R355

R356

R364

R365

R366

R367

R368

R369

R370

R371

R372R373

R374

R375

R424

R425

R426

R427

R428

R429

R430

R431

R432

R433

R443

R448

R449

R450

R452

R470

R479

R482

R483

R485

R486

R487

R488

R493

R494

R495

R496

R497

R499

R500

R501

R502

R503

R504

R505

R506 R507

R530

R533

R539

R540

R541

R542

R545

R546

R547

R549

R550

R560

R561

R563

R566

R567

R604

R615

R617

R623

R624

R629

R632

R635

R636

BLACK RED

Duplex

Simplex

Duplex

OPTION UNIT

Simplex

RXLV

DSUB

PC BOARD

GPIO3

GPIO2

GPIO1 GPIO0

CLKOUT

GPIO8

GND

TX LV

VHF

Simplex

T8V

+5V

REF5

R8V

RXC

FAN

DSP FLASH

CPU FLASH

RXLO

GND

J2 J8

Duplex

Simplex

18 19

16 17

11 12

-T2

-RSSI

-R8V

-T1

-EXMOD

-NWC1

-3.3VA

MFDA-

-FMDA

-SQL

-NWC2

-DET

-CPU5V

-REF5

+5V

-TEMP

-TMUT

PWR-

TUNLK

PLSCK

TPLST PLSSO

PWR

-LEDT

-LEDR

1.6VC

-CLKOUT

-DSP3

CPU3V-

-AFO

DAFO- -EXDISC

+5V

-RFPO

-DET

-NOIS

PLSCK-

-RLVA

-AFON2

-AFON

RUNLK-

-R8V

+5V

DRES-

-3.3VD

DSP5V

3.3VD

TLVA

148

SCRM

CODE

VCC

+10V

-TVCO8V

+10V

PLSSO-

MFDA

F8V AFO GND GND

FMDA

MCIN

PTT

1.6VC

-RVCO8V

-TVCO LV

BATV

-RVCO SW

-RVCO LV

DATAIN-

-SIGO

+5V

-RLVA SW

-MOD

-TXVCO SW

-T8V

PDET-

-RFPO

3.3VA1.8VA1.8VD

-MDRES

D-IF

RPLST

B8211B

Duplex

MP33

H0H5H10H15H20H25H30H35H40H45H50H55H60H65H70H75H80H85H90H95H100H105H110H115H120H125H130H135H140H145H150H155

V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50 V55 V60 V65 V70 V75 V80 V85 V90 V95 V100 V105 V110 V115 V120 V125 V130 V135 V140 V145 V150 V155

Other manuals for iC-FR5000

This manual suits for next models

Table of contents

Popular Repeater manuals by other brands

URC

URC ZR-1N owner's manual

Hytera

Hytera HR65X user manual

RFS

RFS 48810A user manual

Electronics Line

Electronics Line iConnect EL-4635 installation guide

Halco

Halco sollos ColorSplash SCSBTR installation instructions

Monacor

Monacor HDMI-101 quick guide

Ihse

Ihse K471-CT manual

Converters.TV

Converters.TV 554 Operation manual

Skipper

Skipper CD401MR-SC Operation and installation manual

AnyTone

AnyTone AT6200 GW installation guide

Capacicom

Capacicom NBX R1000-RF user manual

Eminent

Eminent EM4590 user guide

GST

GST GRS-1915D-SPR user manual

ATEN

ATEN VC880 user guide

GMI

GMI D5039SB instruction manual

Cypress

Cypress TruVolume DCT-8S SRS Operation manual

GarrettCom

GarrettCom 5843HRT Installation procedures

Kenwood

Kenwood TKR-850 instruction manual

Icom iC-FR5000 Installation and operating instructions

Popular Repeater manuals by other brands
