ICOM
SERVICE
MANUAL
144 MHz FM TRANSCEIVER
IC-2000H
IC-2000
Icom Inc.

INTRODUCTION DANGER
This service manual describes the latest service informa-
tion for the IC-2000H/IC-2000 144 MHz FM TRANSCEIVER
at the time of publication.
MODEL !VERSION NO. version SYMBOL
i
IC-2000H
1^02 Europe EUR
#03 Italy ITA
#05 USA. jUSA
#06
1
Korea KOR
i#07 Australia '
iAUS
IC-200D #04 Thailand 1THA
To upgrade quality, any electrical or mechanical parts
and internal circuits are subject to change without
notice or obligation.
NEVER connect the transceiver to an AC outlet or to aDC
power supply that uses more than 16 V. This will ruin the
transceiver.
DO NOT expose the transceiver to rain ,snow or any liquids.
DO NOT reverse the polarities of the power supply whert
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the trans'
ceiver's front end.
ORDERING PARTS REPAIR NOTES
Be sure to include the following four points when ordering
replacement parts:
1.10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
(SAMPLE ORDER)
S.IC HD404S29C10H lQ-2Qm LOGICUNIT ^pieces
3610008661} Screw PKBTM3 k&NIZU C-20K1H Rear pane! 10 pieces
Addresses are provided on the inside back cover for your
convenience.
1, Make sure aproblem is internal before disassembling
the transceiver,
2. DO NOT open the transceiver until the transceiver is
disconnected from its power source,
3DO NOT force any of the variable components. Turn
Ihem slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An
insulated tuning toot MUST be used for all adiustments.
5. DO NOT keep power OM for along time when the
transceiver is defective.
6. DO NOT transmit power into asignal generator or a
sweep generator.
7. ALWAYS conned a50 dB to 60 dB altenuator between
the transceiver and adeviation meter or spectrum
analyzer when using such test equipment.
8. READ the instructions of test equipment thoroughly
before connecting equipment to the transceiver.

TABLE OF CONTENTS
SECTION 1SPECIFICATIONS 1-1
SECTION 2INSIDE VIEWS 2-1
SECTION 3CIRCUIT DESCRIPTION 3-1to3-4
3-1RECEIVER CIRCUITS 3-1
3-2TRANSMITTER CIRCUITS 3-2
3-3 PLL CIRCUITS 3-3
3-
4POWER SUPPLY CIRCUITS 3-3
3-5PORT ALLOCATIONS 3-4
SECTION 4ADJUSTMENT PROCEDURES 4-1 to 4-2
4-
1PLL ADJUSTMENT 4-1
4-2RECEIVER ADJUSTMENT 4-1
4-3 TRANSMITTER ADJUSTMENT 4-1
SECTION 5PARTS LIST 5-1to5-6
SECTION 6MECHANICAL PARTS AND DISASSEMBLY 6-1 to 6-2
SECTION 7BOARD LAYOUTS 7-1to7-4
7-1 LOGIC UNIT 7-1
7-
2MAIN UNIT 7-3
SECTION 8OPTIONAL UNITS 8-1
8-1UT-85 TONE SQUELCH UNIT 8-1
8-
2UT-101 DTMF UNIT 8-1
SECTION 9BLOCK DIAGRAM 9-1
SECTION 10 VOLTAGE DIAGRAM 10-1

SECTION 1SPECIFICATIONS
GENERAL
•Frequency coverage
•Mode
•Memory channels
•Antenna impedance
•Usable temperature range
•Frequency resolution
•Power supply requirement
•Current drain
•Dimensions
•Weight
VERSION RECEIVE TRANSMIT
EUR 144.000-146.000 MHz 144.000-146.000 MHz
ITA 136.000-174.000 MHz* 144.000-148.000 MHz
THA 144.000-146.000 MHz 144.000-146.000 MHz
USA 118.000-174.000 MHz* 144.000-148.000 MHz
KOR 144.000-146.000 MHz 144.000-146.000 MHz
AUS 144.000-148.000 MHz 144.000-148.000 MHz
SEA 136.000-174.000 MHz* 144.000-148.000 MHz
Guaranteed frequency range is 144-148 MHz
:FM (F3)
:50 channeis pius 6scan edge channels
:50 n(nominal)
:-10“Cto -F60°C(-M4°FtO -M40“F)
:5, 10, 12.5, 15, 20, 25, 30, 50 kHz
:13.8 VDC ±15% (negative ground)
:Receive Standby: 0.8 A
Max. power: less than 1.0 A
Transmit 50 W: 10.5 A
10 W: 5.5 A
5W: 4.0 A
(IC-2000 has no 50 W)
:150(W)x50(H)x 151 (D)mm
5.9 (W)x2.0 (H)x 5.9 (D) in (projections not included)
:1.2 kg; 2.6 lb
TRANSMITTER
•Modulation system
•RF output power
•Max. frequency deviation
•Suprious emissions
•Frequency stability
•Microphone impedance
:Variable reactance frequency modulation
—_£ower Range
Model High Middle Low
IC-2000H SOW 10 W5W
IC-2000 10 W-5W
±5.0 kHz
Less than -60 dB
±10 ppm (-10°C to +60°C)
600 n
RECEIVER
•Receiving system
•Intermediate frequencies
•Sensitivity
•Squelch threshold sensitivity
•Selectivity
•Spurious and image rejection ratio
:
•Audio output power
Double conversion superheterodyne
1st 17.2 MHz
2nd 455 kHz
0.18 mV for 12 dB SINAD
Less than 0.13 pV
More than 15 kHz/—6dB
Less than 30 kHz/—60 dB
More than 60 dB
More than 2.4 Wat 10% distortion with an 8Qload
1-1

SECTION 2INSIDE VIEWS
milNBiiL"]'.
,r»*MrtV
2nd LO crystal
(X2; CR477)
APC amplifier
(!C3: pPC350GR)
+9Vregulator
_(IC7; AN8009M)
-+5 Vregulator
(IC6: TA73L05F)
uifl 1M' 1
1
1
1
1iaji b•:^

SECTION 3CIRCUIT DESCRIPTION
3-1 RECEIVER CIRCUITS
3-1-1 ANTENNA SWITCHING CIRCUIT
(MAIN UNIT)
The antenna switching circuit functions as alow-pass
filter while receiving and aresonator circuit while trans-
mitting. The circiut does not allow transmit signals to
enter receiver circuits.
Received signals enter the antenna connector and then
pass through the low-pass filter (L9-L12, C54-C62), the
X/4 type antenna switching circuit (D7, D16, D17, L19,
L20, C107, Cl 08) and are then applied to the RF ampli-
fier (Q20).
3-1-2 RF AND 1st MIXER CIRCUITS
(MAIN UNIT)
The 1st mixer circuit converts the received signal to a
fixed frequency of the 1st IF signal with aPLL output
frequency. By changing the PLL frequency, only the
desired frequency will be passed through apair of crystal
filters at the next stage of the 1st mixer.
The signals from the antenna switching circuit are passed
through the tunable band-pass filter (D14, LI 8) and
amplified at the RF amplifier (Q20). The amplified signals
are again passed through the tunable band-pass filter
(DIO, D13, D31, L16, L17, L26) and applied to the 1st
mixer (Q19). The signals are then mixed with a1st LO
signal coming from the VCO circuit to produce a17.2 MHz
1st IF signal. The 1st IF signal is passed through apair
of crystal filters (FI1) and is then applied to the IF ampli-
fier (Q1 8).
•FM DETECTOR and SQUELCH CIRCUITS
3-1-3 2nd IF AND DEMODULATOR CIRCUITS
(MAIN UNIT)
The 2nd mixer circuit converts the 1st IF signal to a2nd
IF signal. Adouble superheterodyne system (which
converts receive signal twice) improves the image rejec-
tion ratio and obtains stable receiver gain.
The 1st IF signal from the crystal filter (FI1) is amplified
at Q18 and applied to a2nd mixer section of IC4 (pin 16).
The signal is then mixed with a2nd LO signal for conver-
sion to a455 kHz 2nd IF signal.
IC4 contains the 2nd mixer, local oscillator, limiter ampli-
fier, quadrature detector, S-meter detector and active
filter. The local oscillator section generates 16.745 MHz
using X2. The 2nd IF signal from the 2nd mixer (IC4
pin 3) passes through ceramic filters (FI2) to remove
unwanted heterodyned frequency and fix apassband
width. It Is then amplified at the limiter amplifier (IC4,
pin 5) and applied to the quadrature detector (IC4, pins 7,
8and X3) to demodulate the 2nd IF signal into AF signal.
The AF signal (detector signal) is output from pin 9.
3-1-4 AF CIRCUIT (MAIN UNIT)
The AF signals from IC4 (pin 9) pass through the AF
switch (Q30) and are amplified at the active filters (Q32
HPF; Q33 LPF). Those signals pass through the detector
mute switch (Q37), and are ievel adjusted with the
volume control on the LOGIC unit.
The AF amplifier IC8 amplifies the signals to asufficient
level to drive the speaker. The AF mute switch (Q40)
turns ON to cut the signai to be input to the AF amplifier
(108) during transmission.
Fig. 1
3-1

The AF OUT signals from the VOL1 line are also amplified
at the AF amplifier (LOGIC unit 02) to output AF signal
from the microphone connector.
3-1-5 SQUELCH CIRCUIT
(MAIN and LOGIC UNITS)
Asquelch circuit cuts out AF signals when no RF signals
are being received. By detecting noise components
in the AF signals, the squelch circuit turns the AF mute
switch OFF.
Aportion of the AF signals from the FM IF 1C (IC4 pin 9)
are applied to the active filter (104 pin 10) through the
noise filter (0145—0147, R128). The active filter section
in 104 amplifies noise components of frequency of 20 kHz
and above, and are rectified at the noise detector (D26)
and then triggers the noise switch (Q45).
3-2-3 DRIVE/POWER AMPLIFIER CIRCUITS
(MAIN UNIT)
The signal from the modulation circuit is passed through
the transmit/receive switching circuit (D2) and amplified
at the pre-driver (Oil), driver (012), and the power module
(102) in sequence to obtain 50 W* (at 13.8 VDC) of RF
power.
*10 Wfor the IC-2000 Thailand version.
The amplified signal is passed through the antenna
switching circuit (D7), ARC detector circuit (L10, D8, D9),
and low-pass filter (L11, LI 2, 061, 062) and is then
applied to the antenna connector.
The collector current of the driver (012) are controlled
by the ARC circuit to protect the power module from a
mismatched condition as well as to stabilize the output
power.
The noise switch (045) converts the rectified signals to
a“High” or “Low" signal and applied this to the CRU
(LOGIC unit 102 pin 5) as the busy signal. When the
CRU receives “High,” the CRU outputs the mute signal
through the Data expander 1C (MAIN unit IC9, pin 11)
to cut the AF signals at the detector mute switch (037).
3-2-4 APC CIRCUIT (MAIN UNIT)
The ARC circuit protects the power module (IC2) from a
mismatched output load and selects High or Low output
power.
Even when the squelch is closed, the AF mute switch
(040) opens at the moment of emitting been tones.
3-2 TRANSMITTER CIRCUITS
3-2-1 MICROPHONE AMPLIFIER
(LOGIC UNIT)
The ARC detector circuit (L10, D8, D9) detects forward
signals and rectified signals at D8 and D9 respectively.
The combined voltage is at aminimum level when the
antenna is matched at 50 Oand is increased when it is
mismatched.
The detected voltage is applied to the inverting amplifier
(IC3a) to control the base of 016 and input current of
IC2 (pin 2) and 012 using 013.
The microphone amplifier circuit amplifies audio signals
with -F6 dB/octave pre-emphasis characteristics from the
microphone to alevel needed for the modulation circuit.
The AF signals from the microphone through the mic mute
switch (04), and are amplified at the microphone amplifier
(05) and the limiter amplifier (IC1 a) which has anegative
feedback circuit for -1-6 dB/octave pre-emphasis.
The amplified signals are applied to the low-pass filter
(ICIb) to filter out RF components and then applied to
the MAIN unit as the “MOD” signal.
3-2-2 MODULATION CIRCUIT (MAIN UNIT)
The modulation circuit modulates the VCO oscillating
signal (RF signal) using the microphone audio signals.
The audio signals (MOD) change the reactance of D19 on
the VCO circuit (022, 023, D19) to modulate the oscillated
signal at the VCO (022, 023). The oscillated signal is
amplified at the buffer amplifier (024) and LO amplifier
(025, 026), then applied to the drive amplifiers.
When the antenna impedance is mismatched, negative
input voltage of the inverting amplifier (IC3a) increases,
and the base voltage of 016 and the collector current of
013 decreases to reduce the output power.
•APC CIRCUIT
3-2

3-3 PLL CIRCUITS (MAIN UNIT)
APLL circuit provides stable oscillation of the transmit
frequency and the receive local frequency. The PLL
circuit compares the phase of the divided VCO frequency
to the reference frequency. The PLL output frequency
is controlled by the divided ratio (N-data) of aprogram-
mable divider.
The VCO (Q22, Q23, D19) generates the disired
frequency. The signal is buffer-amplified at Q24, then
applied to the PLL 1C (IC1). The PLL 1C contains a
prescaler, programmable divider, and aphase detector,
etc.
The entered signal Is divided at the prescaler and pro-
grammable counter sections by the N-data ratio from
the CPU. The divided signals are detected on phase at
the phase detector using the reference frequency (5 kHz
or 6.25 kHz).
If the oscillated signal drifts, the phase of its frequency
changes from the reference frequency, causing alock
voltage change to compensate for the drift In the oscillated
frequency.
VCO signals are amplified at the buffer amplifiers and are
then applied to the receive 1st mixer (019) or transmitter
circuit (Oil).
3-4 POWER SUPPLY CIRCUITS
VOLTAGE LINES (MAIN UNIT)
LINE DESCRIPTION
13.8 V13.8 Vcontrolled by the power switching circuit
(Q38, Q39). When the [POWER] switch is pushed,
the CPU outputs the control signal to the power
switching circuit to turn the circuit ON.
-1-9 VCommon -1-9 Vis converted from 13.8 Vline by
the -1-9 Vregulator (IC7), and is used for the PLL
charge pump.
-i-e VCommon -t-8 Vis converted from 13.8 Vline by
the -1-8 Vregulator (ICS).
T8 VT8 Vis produced from -1-8 Vat 09 and 01 0on the
MAIN unit. Data expander (IC9 pin 7) controls 09
and 01 0.
R8 V R8 Vis produced at 041 and 042 on the MAIN unit
using acontrol signal from the Data expander (IC9
pin 12).
C5 VCommon 5Vfor the reset 1C (IC4) and the [POWER]
switch on the LOGIC unit. C5 V is produced at
IC10 on the MAIN unit from external DC input
directly regardless the power ON/OFF condition.
-1-5 VCommon -1-5 Vis converted from 13.8 Vline by the
-1-5 Vregulator (IC6).
The lock voltage is also used for the receiver tunable
band-pass filter of the receiver circuit to match the filter’s
center frequency to the desired receive frequency. The
lock voltage is amplified at the buffer amplifier 08 and
then applied to the tunable band-pass filter (DIO, D13,
D14, D31).
•PLL CIRCUIT
TX
RF circuit
RX
1St mixer amp.
RX
tuning voltage
switch
Fig. 3
3-3

3-5 PORT ALLOCATIONS
3-5-1 CPU (LOGIC UNIT IC2)
PIN
NUMBER PORT NAME SIGNAL
NAME DESCRIPTION
2ANO MIC UD Input port for the [UP]/[DN]
switch on the microphone.
3AN1 PTT Input port for the [PTT] switch.
“High”: PTT is pushed.
4AN2 S/RF Input port for the S/RF meter
signal.
5AN3 SQL Input port for the noise
squelch signal from the FM IF
1C (MAIN unit IC4).
"Low”: squelch open.
8OSC —Terminals for the CPU clock.
9OSC2
10 RESET RESET Input port for the CPU reset
signal.
14 DO 13/
DTSTB Outputs astrobe signal to an optional UT-101 DTMF UNIT.
15 D1 TOSTB Outputs astrobe signal to an
optional UT-85 TONE
SQUELCH UNIT.
16 D2 EXSTB Outputs astrobe signal to the
expander 1C (MAIN unit IC9).
17 D3 MREMO Outputs amic audio mute
signal to lead DTMF signals to
an optional UT-101 DTMF
UNIT for the mic remote
function.
18 D4 ECK Outputs clock signals to the
EEPROM (ICS).
19 D5 EDATA Serial bus line to the EEPROM
(ICS).
20 D6 STD Input port for the decode
signal for the DTMF decoder.
22 D8 DET Input port for the decode
signal for the tone squelch.
23 D9 PWRSW Input port for the power
switch.
24 DIO/
STOPC STOPC Input port for the stop mode
cancel signal.
25 Dll/
INTO UNLK Input port for the PLL unlock signal.
“High”: PLL unlocked
26 ROO/
INTI
BACK
UP Input port for the backup signal to save data before
power is turned OFF.
27 R01/
INT2 DLCK Input ports for the channel selector from the dial
28 R02/
INT3 DLUP selector.
29 R03/
INT4 DLDN
30 RIO/
TOB BEEP Outputs abeep tone signal.
PIN
NUMBER PORT NAME SIGNAL NAME DESCRIPTION
32 R12/
TOD DIMO Outputs LCD backlight intensity signals.
33 R13/
EVNB DIM1
34 R20/
EVND TOE Outputs port for an enable signal for the DTMF encoder.
35 R21/
SCK CK Outputs aserial clock signal.
36 R22/
SI
PWRON Outputs apower control
signal to the power switching
circuit (MAIN unit Q38, Q39).
37 R23/
SO DATA Outputs serial data.
38 R30/
SEG1 K1/ TONE Outputs astrobe signal for the
key matrix.
39 R31/
SEG2 K2/ TONE
40 R32/
SEG3
11/
TONE Outputs astrobe signal for the initial matrix.
41 R33/
SEG4 12/ TONE
42—45 R40/
SEG5—
R43/
SEG8
KRO—
KR3 Input ports for the initial matrix
and key matrix.
46—57 R50/
SEG9—
R73/
SEG20
SEG9—
SEG20 Output LCD drive signals.
90—92 COM1 —
COM3 COM1 — COM3 Output LCD drive signals.
3-5-2 DATA EXPANDER (MAIN UNIT IC9)
PIN
NUMBER PORT
NAME DESCRIPTION
4AMUT Outputs an AF amplifier mute signal.
“High”: amplifier mute
5LP1 Outputs atransmit power control signal.
6LP2
7TX Outputs aT8V control signal.
11 RMUTE Outputs areceive mute signal.
“High”: receiving mute.
12 RX Outputs an R8V control signal.
14 MMUTE Outputs amicrophone mute signal.
“High”: mic mute.
31 R11/
TOC PLSTB Outputs astrobe signal to the
PLL 1C. (MAIN unit IC1)

4-1 PLL AND TRANSMITTER ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITIONS MEASUREMENT VALUE ADJUSTMENT
POINT
UNIT LOCATION UNIT ADJUST
LCX2K
VOLTAGE
1•Displayed frequency; 145.000 MHz
•Receiving
MAIN Connect the digital
multi-meter or
osciiioscope to CP-A.
2.0 VMAIN L22
REFERENCE
FREQUENCY 1
•Displayed frequency: 145.000 MHz
•Transmitting
Rear
panel
Loosely couple the
frequency counter
to the antenna
connector.
145.0000 MHz MAIN
OUTPUT
POWER 1•Displayed frequency:
145.000 MHz (EUR. THA, KOR)
146.000 MHz (ITA, USA, AUS, SEA)
•Transmitting
•Power: High
Rear
panel
Connect the RF
power meter to the
antenna connector.
50 W(IC-2000H)
10 W(iC-2000)
MAIN R62
FM
DEVIATION
1•Displayed frequency:
145.000 MHz (EUR, THA. KOR)
146.000 MHz (ITA, USA, AUS, SEA)
•Apply an AF signal to the [MIC] jack.
1kHz/20 mV
•Set the FM deviation meter as;
HPF :50 Hz
LPF :20 kHz
De-emphasis: OFF
Detector :(P-P)/2
•Transmitting
Rear
panel
Connect the FM
deviation meter
to the antenna
connector via the
attenuator.
±4.8 kHz MAIN R115
CTCSS
TONE
DEVIATION
1•Displayed frequency;
145.000 MHz (EUR, THA, KOR)
146.000 MHz (ITA, USA, AUS, SEA)
•No signal applied to the [MIC] jack.
•CTCSS tone frequency: 88.5 Hz
•Set the FM deviation meter as:
HPF :OFF
LPF :20 kHz
De-emphasis: OFF
Detector ;(P-P)/2
Rear
panel
Connect the FM
deviation meter
to the antenna
connector via the
attenuator.
±0.8 kHz MAIN R168
4-2 RECEIVER ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITIONS MEASUREMENT VALUE ADJUSTMENT
POINT
UNIT LOCATION ADJUST
SENSITIVITY 1•Displayed frequency;
145.000 MHz (EUR, THA, KOR)
146.000 MHz (ITA, USA, AUS. SEA)
•Connect the SSG to the antenna
connector and set as:
Level :1.0 pV* (-107 dBm)
Deviation :±3.5 kHz
Modulation: 1kHz
•Turn the R146 to maximum level.
•Receiving
MAIN Connect the
voltmeter to the
CP-B.
Maximum DC voltage Adjust in
sequence.
L18, L17,
L26, L16
S-METER 1•Displayed frequency:
145.000 MHz (EUR, THA, KOR)
146.000 MHz (ITA, USA, AUS, SEA)
•Connect the SSG to the antenna
connector and set as:
Level :1.0pV*(-107dBm)
Deviation ;±3.5 kHz
Modulation: 1kHz
•Receiving
Function
display
S/RF indicator S3 (4 dots)
mamm MAIN R146
-This output level of the standard signal generator <SSG) is indicated as SSG’s open circuit.
4-1

ATTENUATOR
50 or 60 dB FM DEVIATION
METER
4-2

SECTION 5PARTS LIST
[LOGIC UKIT] [LOGIC UNUJ
REF.
NO. ORDER NO. DESCRIPTION
IC1 1110000960 S.IC NJM4558M(T1)
IC2 1140004770 S.IC HD404829C10H
IC3 1130003920 S.IC TC4S69F (TE8SR)
IC4 1130007340 S.IC S-80745SL-A9-T1
ICS 1190000260 S.IC 24LC08BTI/SN
Q1 1530003280 S.TRANSISTOR 2SC4211-6-TR
Q2 1530003280 S.TRANSISTOR 2SC4211-6-TR
Q3 1530003280 S.TRANSISTOR 2SC4211-6-TR
Q4 1590001390 S.FET 2SJ144-Y (TE85R)
Q5 1530003280 S.TRANSISTOR 2SC4211-6-TR
Q6 1590001390 S.FET 2SJ144-Y (TE85R)
Q7 1590000430 S.TRANSISTOR DTC144EU T107
Q8 1530002840 S.TRANSISTOR 2SC4116-Y{TE85R>
Q9 1530003280 S.TRANSISTOR 2SC4211.6-TR
Q10 1590001390 S.FET 2SJ144-Y (TE85R)
Q11 1590000430 S.TRANSISTOR DTC144EU T107
Q12 1590001390 S.FET 2SJ144-Y (TE85R)
Q13 1530003280 S.TRANSISTOR 2SC4211-6-TR
Q14 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q15 1530002840 S.TRANSISTOR 2SC4116-Y (TE85R)
Q16 1530003280 S.TRANSISTOR 2SC4211-6-TR
Q17 1510000880 S.TRANSISTOR 2SA1622-6-TR
Q19 1510000880 S.TRANSISTOR 2SA1622-6-TR
Q20 1510000880 S.TRANSISTOR 2SA1622-6-TR
D1 1790001000 S.ZENER MA8062-L(TX)
D2 1750000390 S.DIODE 1SS353TE-17
D3 1160000050 S.DIODE DAP202UT107
D4 1160000050 S.DIODE DAP202UT107
D5 1160000050 S.DIODE DAP202U T107
D6 1160000050 S.DIODE DAP202U T107
D8 1750000390 S.DIODE 1SS353 TE-17
[USA]. [EUR], [AUS]. [SEA].
fTHA). [KOR]
DS 1710000600 DIODE 1SS254 [EUR], [AUS]
DIO 1750000390 S.DIODE 1SS353 [THA], [KOR]
Dll 1750000390 S.DIODE 1SS353
[ITA]. [THA], [KOR], [SEA]
D12 1750000390 S.DIODE 1SS353
[EUR], [THA], [AUS]
D13 1750000390 S.DIODE 1SS3S3 [EUR]. [SEA]
D14 1750000390 S.DIODE 1SS353 [ITA], [THA]
D15 1750000390 S.DIODE 1SS353 [KOR]
Die 1750000130 S.DIODE DA204UT107
XI 6050009300 S.XTAL CR-505 SMD-49 (4MHz)
R1 7030003600 S.RESISTOR ERJ3QEYJ 223 V(22 kQ)
R2 7030003580 S.RESISTOR ERJ3GEYJ 103V(10kQ)
R3 7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
R4 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R5 7030003200 S.RESISTOR ERJ3GEYJ 100 V(10 Q)
R8 7030003360 S.RESISTOR ERJ3GEYJ 221 V(220 Q)
R7 7030003280 S.RESISTOR ERJ3GEYJ470V(47 Q)
R8 7030003800 S.RESISTOR ERJ3GEYJ105V(1 MQ)
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kO)
RIO 7030003560 S.RESISTOR ERJ3GEYJ 103V(10kQ)
R11 7030003360 S.RESISTOR ERJ3GEYJ 221 V(220 Q)
R12 7030003740 S.RESISTOR ERJ3GEYJ 334 V(330 kQ)
R13 7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
R14 7030003500 S.RESISTOR ERJ3GEYJ 332 V(3.3 kQ)
REF.
NO. ORDER
NO. DESCRIPTION
R15 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R18 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R17 7030003420 S.RESISTOR ERJ3GEYJ 881 V(680 Q)
R18 7030003530 S.RESISTOR ERJ3GEYJ 562 V(5.6 kQ)
R19 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R20 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R21 7030003410 S.RESISTOR ERJ3GEYJ 561 V(560 Q)
R22 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R23 7030003600 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R24 7030003310 S.RESISTOR ERJ3GEYJ 820 V(82 Q)
R25 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R26 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R27 7030003400 S.RESISTOR ERJ3GEYJ 471 V(470 Q)
R28 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R29 7030003500 S.RESISTOR ERJ3GEYJ 332 V(3.3 kQ)
R30 7030003390 S.RESISTOR ERJ3GEYJ 391 V(390 Q)
R31 7030003720 S.RESISTOR ERJ3GEYJ 224 V(220 kQ)
R32 7030003730 S.RESISTOR ERJ3GEYJ 274 V(270 kO)
R33 7030003790 S.RESISTOR ERJ3GEYJ 824 V(820 kQ)
R34 7030003710 S.RESISTOR ERJ3GEYJ 184 V(180 kQ)
R35 7030003550 S.RESISTOR ERJ3GEYJ 822 V(8.2 kQ)
R36 7030003650 S.RESISTOR ERJ3GEYJ 563 V(56 kQ)
R37 7030003720 S.RESISTOR ERJ3GEYJ 224 V(220 kQ)
R38 7030003670 S.RESISTOR ERJ3GEYJ 823 V(82 kQ)
R39 7030003670 S.RESISTOR ERJ3GEYJ 823 V(82 kQ)
R40 7030003670 S.RESISTOR ERJ3GEYJ 823 V(82 kQ)
R41 7030003550 S.RESISTOR ERJ3GEYJ 822 V(8.2 kQ)
R43 7030003670 S.RESISTOR ERJ3GEYJ 823 V(82 kQ)
R44 7030003590 S.RESISTOR ERJ3GEYJ183V(18kQ)
R4S 7030003840 S.RESISTOR ERJ3GEYJ 225 V(2.2 MQ)
R46 7030003840 S.RESISTOR ERJ3GEYJ 225 V(2.2 MQ)
R47 7030003600 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R48 7030003600 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R49 7030003600 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R50 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R51 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R52 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R53 7030003620 S.RESISTOR ERJ3GEYJ 333 V(33 kQ)
R54 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R55 7030003440 S.RESISTOR ERJ3GEYJ102V(1 kQ)
R56 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R57 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kO)
R58 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R59 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R80 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R81 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R62 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R63 7210001870 VARIABLE EVU-F2AF20A14 (10KA)
R64 7210001880 VARIABLE EVU-F2AF20 B14 (10KB)
R65 7030003740 S.RESISTOR ERJ3GEYJ 334 V(330 kO)
R86 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R87 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R68 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R69 7030000020 S.RESISTOR MCR10EZHJ1 Q(010)
R70 7030000020 S.RESISTOR MCR10EZHJ1 Q(010)
R71 7030001130 S.RESISTOR MCR50JZHJ 100 Q(101)
R72 7030003470 S.RESISTOR ERJ3GEYJ 182 V(1.8 kQ)
R73 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R74 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R75 7030003650 S.RESISTOR ERJ3GEYJ 563 V(56 kQ)
R76 7030003600 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R77 7030003840 S.RESISTOR ERJ3GEYJ473V(47kQ)
R78 7030003640 S.RESISTOR ERJ3GEYJ473V(47kQ)
R79 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R80 7030003800 S.RESISTOR ERJ3GEYJ105V(1 MQ)
R81 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R82 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R83 7030003720 S.RESISTOR ERJ3GEYJ 224 V(220 kQ)
R84 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R65 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
S.=Surface mount
5-1

[LOGIC UNIT] [LOGIC UNIT]
REF.
NO. ORDER
NO. DESCRIPTION
R86 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R87 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R89 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R90 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R91 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R92 7030003880 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R93 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R95 7030003840 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R98 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R99 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R100 7030003780 S.RESISTOR ERJ3GEYJ 474 V(470 kQ)
R101 7030003720 S.RESISTOR ERJ3GEYJ 224 V(220 kQ)
R102 7030003690 S.RESISTOR ERJ3GEYJ 124 V(120 kQ)
R103 7030003660 S.RESISTOR ERJ36EYJ 683 V(68 kQ)
R104 7030003880 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R105 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R106 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R107 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R108 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R109 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R110 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R111 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R112 7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
Cl 4030006860 S.CERAMIC C1608 JB1H102K-T-A
C2 4030006860 S.CERAMIC C1608JB1H102K-T-A
C3 4030006860 S.CERAMIC Cl 808 JB 1H 102K-T-A
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C6 4030008630 S.CERAMIC C1608JF1C104Z-T-A
C7 4030008630 S.CERAMIC C1608JF1C104Z-T-A
C8 4030008630 S.CERAMIC C1808 JF 1C 104Z-T-A
C9 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
CIO 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C11 4030008780 S.CERAMIC C2012 X7R 1C 104K-T-A
C12 4510005300 S.ELECTROLYTIC ECEV1AA330SR
C13 4030008680 S.CERAMIC C2012 JF1C105Z-T-A
C14 4030008680 S.CERAMIC C2012JF1C105Z-T-A
C15 4510004630 S.ELECTROLYTIC ECEV1CA100SR
cie 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C18 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C19 4030008630 S.CERAMIC C1808 JF 1C 104Z-T-A
C20 4030008630 S.CERAMIC C1608 JF1C104Z-T-A
C21 4030008900 S.CERAMIC Cl 608 JB1C333K-T-A
C22 4030007020 S.CERAMIC Cl 808 CH 1H 120J-T-A
C23 4030008680 S.CERAMIC C2012JF1C105Z-T-A
C24 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C25 4030009490 S.CERAMIC C1608 JB1H821K-T-A
C28 4030008650 S.CERAMIC C1808 JB 1H332K-T-A
C27 4030007120 S.CERAMIC Cl 808 CH 1H820J-T-A
C28 4030007130 S.CERAMIC C1808CH 1H 101J-T-A
C31 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C32 4030006870 S.CERAMIC C1608 JB 1H222K-T-A
C33 4030008760 S.CERAMIC C2012X7R 1C 104K-T-A
C35 4030008880 S.CERAMIC C1608 JB 1C223K-T-A
C38 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C37 4030008830 S.CERAMIC C1608 JF 1C 104Z-T-A
C38 4030008830 S.CERAMIC C1608 JF 1C 104Z-T-A
C39 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C40 4030008630 S.CERAMIC C1808 JF 1C 104Z-T-A
C41 4510005870 S.ELECTROLYTIC ECEV1HA3R3SR
C42 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C43 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C44 4030008630 S.CERAMIC Cie08JF1C104Z-T-A
C45 4030008630 S.CERAMIC C1808 JF 1C 104Z-T-A
C48 4030008630 S.CERAMIC Cie08JF1C104Z-T-A
C47 4510005590 S.ELECTROLYTIC ECEV0JA331P
C48 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C49 4030008630 S.CERAMIC C1608JF1C 104Z-T-A
C50 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C51 4030008630 S.CERAMIC Cieoa JF1C104Z-T-A
C52 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C53 4030007030 S.CERAMIC C1808 CH 1H 150J-T-A
REF.
NO. ORDER NO. DESCRIPTION
C54 4030007030 S.CERAMIC C1808 CH 1H 150J-T-A
C55 4030008630 S.CERAMIC C1608 JF1C104Z-T-A
C57 4030008630 S.CERAMIC C1808 JF1C 104Z-T-A
C58 4030008630 S.CERAMIC C1608 JF1C104Z-T-A
C60 4030008630 S.CERAMIC C1608 JF1C104Z-T-A
C62 4030007090 S.CERAMIC C1608CH1H470J-T-A
C63 4030007090 S.CERAMIC C1608CH1H470J-T-A
C64 4030008630 S.CERAMIC C1808 JF 1C 104Z-T-A
C65 4030007080 S.CERAMIC C1608 CH 1H 470J-T-A
C66 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C67 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C68 4030007090 S.CERAMIC Cl 608 CH 1H470J-T-A
C69 4030008630 S.CERAMIC C1608JF1C104Z-T-A
C70 4030007090 S.CERAMIC C1608CH1H470J-T-A
C71 4030008830 S.CERAMIC C1808 JF 1C 104Z-T-A
DS1 5030001180 LCD LD-HU4304E
DS2 5080000330 LAMP HRS-7219A-RE
DS3 5080000330 LAMP HRS-7219A-RE
W1 7120000380 JUMPER JPW01 R-01
[SEA], [ITA], [THA], [KORJ
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 7030003860 S.JUMPER ERJ3GEJPWV
W5 7030003860 S.JUMPER ERJ3GEJPWV
W6 7030003860 S.JUMPER ERJ3GEJPWV
W7 7030003880 S.JUMPER ERJ3GEJPWV
J1 6450001470 CONNECTOR 95003-2881
J2 6510016440 S.CONNECTOR 52465-1481
J3 6510018030 S.CONNECTOR 53248-1217
J4 6510018030 S.CONNECTOR 53248-1217
SI 2260001890 S.SWITCH SKQDPA
S2 2260001880 S.SWITCH SKQDPA
S3 2250000050 ENCODER EVQ-WQGF15 24B
S4 2260001880 S.SWITCH SKQDPA
S5 2260001890 S.SWITCH SKQDPA
se 2260001890 S.SWITCH SKQDPA
S7 2260001890 S.SWITCH SKQDPA
S8 2260001890 S.SWITCH SKQDPA
S9 2260001890 S.SWITCH SKQDPA
EP1 0810044112 PCB B4441B
EP2 8930035720 LCD CONTACT SRCN-1642SSW
S.=Surface mount
5-2

[MAIN UNIT]
REF.
NO. ORDER
NO. DESCRIPTION
IC1 1130005700 S.IC M56760FP
IC2 1150000760 1C SC1091 [IC-2000H]
1150001640 1C SC1005 [IC-2000]
IC3 1110003340 S.IC UPC358GR-T1
IC4 1110003570 S.IC MC3372VMEL
ICS 1180001190 1C TA78M08P
ice 1180000420 S.IC TA78L05F (TE12R)
IC7 1110002510 S.IC AN8009M-(E1)
IC8 1110002550 1C TA7252AP
ICS 1130007700 S.IC BU4094BCF-T1
IC10 1180000420 S.IC TA78L05F (TE12R)
IC11 1130003710 S.IC TC4S71F(TE85R)
IC12 1130003920 S.IC TC4S69F (TE85R)
Q1 1530002840 S.TRANSISTOR 2SC4116-Y (TE85R)
Q2 1530002560 S.TRANSISTOR 2SC4403-3-TR
Q3 1530003010 S.TRANSISTOR 2SC4117-GR(TE85R)
Q4 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
Q5 1560000530 S.FET 2SK880-GR {TE85R)
Q6 1560000530 S.FET 2SK880-GR (TE85R)
Q7 1530002840 S.TRANSISTOR 2SC4116-Y (TE85R)
Q8 1560000530 S.FET 2SK880-GR (TE85R)
Q9 1510000690 S.TRANSISTOR 2SA1734 (TE12R)
Q10 1590000430 S.TRANSISTOR DTC144EUT107
Q11 1530002340 S.TRANSISTOR 2SC2954-T2B
Q12 1530002340 S.TRANSISTOR 2SC2954-T2B
Q13 1510000900 TRANSISTOR 2SA1824 S
Q14 1590000430 S.TRANSISTOR DTC144EU T107
Q15 1590000430 S.TRANSISTOR DTC144EUT107
Q16 1530003280 S.TRANSISTOR 2SC4211-e-TR
Q17 1590000430 S.TRANSISTOR DTC144EU T107
Q18 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q19 1580000480 S.FET 3SK184-S (TX)
Q20 1580000490 S.FET 3SK166-2-T7
Q22 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q23 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q24 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q25 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q26 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q27 1590001050 S.TRANSISTOR DTC114TU T107
Q28 1560000530 S.FET 2SK880-GR {TE85R)
Q29 1590001390 S.FET 2SJ144-Y (TE85R)
Q30 1590001390 S.FET 2SJ144-Y {TE85R)
Q31 1590000430 S.TRANSISTOR DTC144EU T107
Q32 1530003280 S.TRANSISTOR 2SC4211.6-TR
Q33 1530003280 S.TRANSISTOR 2SC4211-e-TR
Q35 1590000430 S.TRANSISTOR DTC144EU T107
Q36 1530003280 S.TRANSISTOR 2SC4211-8-TR
Q37 1590001390 S.FET 2SJ144-Y (TE85R)
Q38 1530002970 S.TRANSISTOR 2SC4884(TE16R)
Q39 1590000690 S.TRANSISTOR IMD6T108
Q40 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q41 1590001040 S.TRANSISTOR DTA113ZUT107
Q42 1590000430 S.TRANSISTOR DTC144EU T107
Q43 1590001040 S.TRANSISTOR DTA113ZU T107
Q44 1590000430 S.TRANSISTOR DTC144EU T107
Q45 1530002840 S.TRANSISTOR 2SC41ie-Y (TE85R)
Q46 1530002840 S.TRANSISTOR 2SC41ie-Y (TE85R)
D1 1750000390 S.DIODE 1SS353TE-17
D2 1790000450 S.DIODE MA862(TX)
D4 1790000860 S.DIODE MA133(TX)
D5 1750000390 S.DIODE 1SS353 TE-17
D6 1790001010 S.ZENER MA8043-L(TX)
D7 1710000310 DIODE MI407
D8 1790000980 S.DIODE MA742(TX)
D9 1790000980 S.DIODE MA742fTX)
DIO 1720000370 S.VARICAP HVU350TRF
Dll 1790000620 S.DIODE MA77(TW)
D12 1790000620 S.DIODE MA77fTW)
D13 1720000370 S.VARICAP HVU350TRF
D14 1720000370 S.VARICAP HVU350TRF
[MAIN UNIT]
REF.
NO. ORDER
NO. DESCRIPTION
D15 1790000820 S.DIODE MA77(TW)
D18 1710000730 S.DIODE MI809-T11
D17 1710000730 S.DIODE MI809-T11
D18 1790000980 S.DIODE MA742(TX)
D19 1720000370 S.VARICAP HVU350TRF
D20 1790000620 S.DIODE MA77(TW)
D22 1790001000 S.ZENER MA8062-L(TX)
D23 1790000980 S.DIODE MA742(TX)
025 1790000700 DIODE DSA3A1
D26 1790000980 S.DIODE MA742frX)
D28 1750000390 S.DIODE 1SS353 TE-17
D30 1790000620 S.DIODE MA77fTW)
031 1720000370 S.VARICAP HVU350TRF
D32 1750000390 S.DIODE 1SS353 TE-17
FI1 2010001670 XTAL FL-207 UM-1 (17.200MHz)
FI2 2020000080 CERAMIC CFU455E2
XI 6050009090 XTAL CR-489 (12.800MHz)
X2 8050008940 XTAL CR-477 (16.745MHz)
X3 6070000090 DISCRI CDB455C16
U6200001570 S.COIL LER015T1R0M
L2 8200002420 S.COIL NL252018T-068J
L3 6200002580 S.COIL NL 25201 8T-033J
L4 8200002420 S.COIL NL 252018T-068J
L5 6200002580 S.COIL NL 25201 8T-033J
L6 8200002420 S.COIL NL252018T-O68J
L7 6200002420 S.COIL NL252018T-068J
L8 6170000180 COIL LW-19
L9 6110001600 COIL LA-243
L10 6110001550 COIL U-235
L11 6110001560 COIL LA-236
LI 28110001600 COIL LA-243
L13 6200003510 S.COIL LER015TR82M
L14 6200004670 S.COIL NL252018T-3R9J
L15 6200002640 S.COIL NL252018T-R15J
L18 6150004490 S.COIL LS-502
L17 6150004490 S.COIL LS-502
L18 6150004490 S.COIL LS-502
L19 8110001620 COIL LA-245
L20 8110001570 COIL LA-237
L21 8200001520 S.COIL MLF2012D R82K-T
L22 6130002480 S.COIL LB-277
L23 6200002840 S.COIL NL252018T-R22J
L24 6200002840 S.COIL NL 25201 8T-R22J
L25 6200002090 S.COIL EUFB 681 K-F
L26 6150004490 S.COIL LS-502
L28 8200002650 S.COIL NL252018T-R18J
R2 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R3 7030003240 S.RESISTOR ERJ3GEYJ 220 V(22 Q)
R4 7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R8 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R7 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R8 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R9 7030003800 S.RESISTOR ERJ3GEYJ 105 V(1 MQ)
RIO 7030003490 S.RESISTOR ERJ3GEYJ 272 V(2.7 kQ)
R11 7030003490 S.RESISTOR ERJ3GEYJ 272 V(2.7 kQ)
R12 7030003550 S.RESISTOR ERJ3GEYJ 822 V(8.2 kQ)
R13 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R14 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R15 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R16 7030003450 S.RESISTOR ERJ3GEYJ 122 V(1.2 kQ)
R17 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R18 7030003630 S.RESISTOR ERJ3GEYJ 393 V(39 kQ)
R19 7030003540 S.RESISTOR ERJ3GEYJ 882 V(8.8 kQ)
S.=Surface mount
5-3

[MAIN UNIT] [MAIN UNIT]
REF.
NO. ORDER
NO. DESCRIPTION
R20 7030003770 S.RESISTOR ERJ3GEYJ 564 V(560 kQ)
R21 7030003800 S.RESISTOR ERJ3GEYJ 105 V(1 MQ)
R22 7030003440 S.RESISTOR ERJ3GEYJ102V(1 kQ)
R23 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R24 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R25 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R26 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R27 7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
R28 7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
R28 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R30 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R31 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R32 7030003370 S.RESISTOR ERJ3GEYJ 271 V(270 Q)
R33 7030003230 S.RESISTOR ERJ3GEYJ 180 V(18 Q)
R34 7030003370 S.RESISTOR ERJ3GEYJ 271 V(270 Q)
R35 7030006300 S.RESISTOR ERJ14YJ200H (20 Q)
R37 7030003450 S.RESISTOR ERJ3GEYJ 122 V(1.2 kQ)
R38 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R39 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R40 7030003430 S.RESISTOR ERJ3GEYJ 821 V(820 Q)
R41 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R42 7030001090 S.RESISTOR MCR50JZHJ 47 Q(470)
R43 7030003580 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R44 7030003580 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R45 7030001130 S.RESISTOR MCR50JZHJ 100 Q(101)
R48 7030003550 S.RESISTOR ERJ3GEYJ 822 V(8.2 kQ)
R51 7030003550 S.RESISTOR ERJ3GEY3 822 V(8.2 kQ)
R54 7030003720 S.RESISTOR ERJ3GEYJ 224 V(220 kQ)
R58 7030003800 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R57 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R58 7030003790 S.RESISTOR ERJ3GEYJ 824 V(820 kQ)
R59 7030003540 S.RESISTOR ERJ3GEYJ 682 V(6.8 kQ)
R60 7030003490 S.RESISTOR ERJ3GEYJ 272 V(2.7 kQ)
R61 7030003460 S.RESISTOR ERJ3GEYJ 152 V(1.5 kQ)
R82 7310003610 S.TRIMMER EVM-1XSX50B14 (103)
R63 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R64 7520000120 POSISTOR PTH9M04 BC 222TS-2F333
R85 7030003580 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R66 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R67 7030003620 S.RESISTOR ERJ3GEYJ 333 V(33 kQ)
R68 7030001190 S.RESISTOR MCR50JZHJ 330 Q(331)
Rag 7030003540 S.RESISTOR ERJ3GEYJ 682 V(6.8 kQ)
R71 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R72 7030003400 S.RESISTOR ERJ3GEYJ 471 V(470 Q)
R73 7030003280 S.RESISTOR ERJ3GEYJ 470 V(47 Q)
R74 7030003400 S.RESISTOR ERJ3GEYJ 471 V(470 Q)
R7S 7030003800 S.RESISTOR ERJ3GEYJ 105 V(1 MQ)
R76 7030003470 S.RESISTOR ERJ3GEYJ 182 V(1.8 kQ)
R77 7030003280 S.RESISTOR ERJ3GEYJ 470 V(47 Q)
R78 7030003380 S.RESISTOR ERJ3GEYJ 221 V(220 Q)
R79 7030003580 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R80 7030003880 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R81 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R82 7030003580 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R83 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R84 7030003370 S.RESISTOR ERJ3GEYJ 271 V(270 Q)
R8S 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R86 7030003240 S.RESISTOR ERJ3GEYJ 220 V(22 Q)
R87 7030003310 S.RESISTOR ERJ3GEYJ 820 V(82 Q)
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R89 7030003860 S.RESISTOR ERJ3GEYJ 883 V(88 kQ)
R91 7030003880 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R92 7030003580 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R93 7030003530 S.RESISTOR ERJ3GEYJ 582 V(5.8 kQ)
R94 7030003600 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R95 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R96 7030003550 S.RESISTOR ERJ3GEYJ 822 V(8.2 kQ)
R97 7030003360 S.RESISTOR ERJ3GEYJ 221 V(220 Q)
R98 7030003550 S.RESISTOR ERJ3GEYJ 822 V(8.2 kQ)
R89 7030003380 S.RESISTOR ERJ3GEYJ 221 V(220 Q)
RlOO 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R101 7030003490 S.RESISTOR ERJ3GEYJ 272 V(2.7 kQ)
R102 7030003510 S.RESISTOR ERJ3GEYJ 392 V(3.9 kQ)
R103 7030003430 S.RESISTOR ERJ3GEYJ 821 V(820 Q)
R104 7030003360 S.RESISTOR ERJ3GEYJ 221 V(220 Q)
R105 7030003220 S.RESISTOR ERJ3GEYJ 150 V(15 Q)
REF.
NO. ORDER NO. DESCRIPTION
WM7030003220 S.RESISTOR ERJ3GEYJ 150 V(15 Q)
ISl 7030003220 S.RESISTOR ERJ3GEYJ 150 V(15 Q)
7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
R109 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R110 7030003400 S.RESISTOR ERJ3GEYJ 471 V(470 Q)
R111 7030003280 S.RESISTOR ERJ3GEYJ470V(47 Q)
R112 7030003420 S.RESISTOR ERJ3GEYJ 681 V(680 Q)
R113 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R114 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R115 7310003590 S.TRIMMER EVM-1XSX50 B24 (203)
R116 7030003550 S.RESISTOR ERJ3GEYJ 822 V(8.2 kQ)
R117 7030003510 S.RESISTOR ERJ3GEYJ 392 V(3.9 kQ)
R118 7030003600 S.RESISTOR ERJ3GEYJ 223 V(22 kQ)
R119 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R120 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R121 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R122 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R123 7030003680 S.RESISTOR ERJ3GEYJ 683 V(68 kQ)
R124 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R125 7030003760 S.RESISTOR ERJ3GEYJ 474 V(470 kQ)
R126 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R128 7030003430 S.RESISTOR ERJ3QEYJ 821 V(820 Q)
R129 7030003470 S.RESISTOR ERJ3GEYJ 182 V(1.8 kQ)
R130 7030003460 S.RESISTOR ERJ3GEYJ 152 V(1.5 kQ)
R131 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R132 7030003400 S.RESISTOR ERJ3GEYJ 471 V(470 Q)
R133 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R134 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R135 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R136 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R137 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R138 7030003710 S.RESISTOR ERJ3GEYJ 184 V(180 kQ)
R139 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R140 7030003750 S.RESISTOR ERJ3GEYJ 394 V(390 kQ)
R141 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R142 7030003630 S.RESISTOR ERJ3GEYJ 393 V(39 kQ)
R143 7030003630 S.RESISTOR ERJ3GEYJ 393 V(39 kQ)
R144 7030003560 S.RESISTOR ERJ3GEYJ103V(10kQ)
R146 7310003600 S.TRIMMER EVM-1XSX50 B54 (503)
R147 7030003640 S.RESISTOR ERJ3GEYJ473V (47 kQ)
R148 7030003660 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R149 7030003700 S.RESISTOR ERJ3GEYJ 154 V(150 kQ)
R150 7030003670 S.RESISTOR ERJ3GEYJ 823 V(82 kQ)
R151 7030003380 S.RESISTOR ERJ3GEYJ 331 V(330 Q)
R152 7030003580 S.RESISTOR ERJ3GEYJ 153 V(15 kQ)
R153 7030003320 S.RESISTOR ERJ3GEYJ 101 V(100 Q)
R154 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R155 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R158 7030003620 S.RESISTOR ERJ3GEYJ 333 V(33 kQ)
R157 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R158 7030003440 S.RESISTOR ERJ3GEYJ 102 V(1 kQ)
R159 7030001010 S.RESISTOR MCR50JZHJ 10 Q(100)
R160 7030003620 S.RESISTOR ERJ3GEYJ 333 V(33 kQ)
R161 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R162 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R163 7030003240 S.RESISTOR ERJ3GEYJ 220 V(22 Q)
R164 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R165 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R166 7030003640 S.RESISTOR ERJ3GEYJ 473 V(47 kQ)
R167 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R188 7310003590 S.TRIMMER EVM-1XSX50 B24 (203)
R189 7030003620 S.RESISTOR ERJ3GEYJ 333 V(33 kQ)
9170 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R171 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R173 7030003700 S.RESISTOR ERJ3GEYJ 154 V(150 kQ)
R174 7510000420 S.THERMISTOR TN20-3W472LT
R175 7030003520 S.RESISTOR ERJ3GEYJ 472 V(4.7 kQ)
R178 7030003580 S.RESISTOR ERJ3GEYJ 153 V(15 kQ)
R177 7030003790 S.RESISTOR ERJ3GEYJ 824 V(820 kQ)
R178 7030003400 S.RESISTOR ERJ3GEYJ 471 V(470 Q)
R179 7030003420 S.RESISTOR ERJ3GEYJ 681 V(680 Q)
R180 7510000430 S.THERMISTOR TN20-3K202LT
R181 7030003680 S.RESISTOR ERJ3GEYJ 104 V(100 kQ)
R182 7030003560 S.RESISTOR ERJ3GEYJ 103 V(10 kQ)
R183 7030003480 S.RESISTOR ERJ3GEYJ 222 V(2.2 kQ)
S.=Surface mount
5-4

[MAIN UNIT]
REF.
NO. ORDER
NO. DESCRIPTION
Cl 4610001260 S.TRIMMER ECR-JA020 E12W
C2 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C3 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C4 4030007170 S.CERAMIC C1608 CH 1H221J-T-A
C5 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C6 4030006930 S.CERAMIC Cl 608 CH1H020C-T-A
C7 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C9 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C10 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C12 4550006360 S.TANTALUM ECST1VY104R
C13 4SS0006360 S.TANTALUM ECST1VY104R
C14 4030008860 S.CERAMIC Cl 608 JB 1C 153K-T-A
CIS 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C16 4SS0006S60 S.TANTALUM ECST1CY225R
C17 4SS0006S60 S.TANTALUM ECST1CY225R
C18 4SS0006S60 S.TANTALUM ECST1CY225R
C19 4030006970 S.CERAMIC Cl 608 CH 1H080D-T-A
C20 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C21 4S1000S430 S.ELECTROLYTIC ECEV0JA220SR
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C24 4510005300 S.ELECTROLYTIC ECEV1AA330SR
C25 4030006660 S.CERAMIC C1608 JB 1H 102K-T-A
C26 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C27 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C28 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C29 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C30 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C31 4S10004640 S.ELECTROLYTIC ECEV1CA470SP
C32 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C33 40300070S0 S.CERAMIC Cl 808 CH1H220J-T-A
C34 4030007050 S.CERAMIC Cl 808 CH1H220J-T-A
C35 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C36 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C38 4030007050 S.CERAMIC Cl 808 CH1H220J-T-A
C39 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C40 4030007050 S.CERAMIC C1808 CH 1H220J-T-A
C41 4030006940 S.CERAMIC Cl 608 CH 1H030C-T-A
C42 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C43 4030007010 S.CERAMIC C1808 CH 1H 100D-T-A
C44 4030006940 S.CERAMIC Cl 808 CH 1H030C-T-A
C45 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C46 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C47 4030007050 S.CERAMIC Cl 808 CH 1H220J-T-A
C48 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C49 4030007040 S.CERAMIC C1808 CH 1H 180J-T-A
C50 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C51 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C52 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C53 4030011170 S.CERAMIC GRM42-6 CH 180J 500PT
[USA], [EUR], [AUS], [SEA],
[ITA], [KOR]
C54 4010005790 CERAMIC HM60SJ YB 102K500V
CSS 4030011050 S.CERAMIC GRM42-6 CJ 030C 500PT
CS8 4010007630 CERAMIC HM60SJ CH 270J 500V
CS7 4030011020 S.CERAMIC GRM42-8 CK 01 OC 500PT
CS8 4030007020 S.CERAMIC C1808 CH 1H 120J-T-A
CS9 4030011020 S.CERAMIC GRM42-6 CK010C 500PT
ceo 4030007020 S.CERAMIC C1808 CH 1H 120J-T-A
C61 4030011290 S.CERAMIC GRM42-6 CH 240J 500PT
C62 4030011290 S.CERAMIC GRM42-6 CH 240J 500PT
C83 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
C84 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
cae 4030006660 S.CERAMIC C1608 JB 1H 102K-T-A
C67 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C68 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C69 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C70 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C71 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C72 4550006210 S.TANTALUM ECST1CX106R
C73 4510005870 S.ELECTROLYTIC ECEV1HA3R3SR
C74 4030006860 S.CERAMIC Cl 808 JB 1H 102K-T-A
C7S 4550006210 S.TANTALUM ECST1CX106R
[MAIN UNIT]
REF.
NO. ORDER NO. DESCRIPTION
C76 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C77 4030006900 S.CERAMIC C1608 JB IE 103K-T-A
C78 4030006900 S.CERAMIC C1808 JB IE 103K-T-A
C79 4030006900 S.CERAMIC C1608 JB IE 103K-T-A
C80 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C81 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C82 4030006960 S.CERAMIC C1608 CH 1H050C-T-A
C83 4030007040 S.CERAMIC C1808 CH 1H 180J-T-A
C84 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C85 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C86 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
C87 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
C88 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
C89 4030007110 S.CERAMIC Cl 808 CH 1H 680J-T-A
C90 4030006980 S.CERAMIC Cl 608 CH 1H 070D-T-A
C9I 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
C92 4030009470 S.CERAMIC Cl 608 CH 1H R75C-T-A
C93 4030007030 S.CERAMIC Cl 808 CH 1H 150J-T-A
C94 4030006690 S.CERAMIC Cl 608 CH 1H 080D-T-A
COS 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C96 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C97 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C98 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C99 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C100 4030006970 S.CERAMIC C1608CH 1H060D-T-A
C101 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C102 4030007130 S.CERAMIC C1808 CH 1H 101J-T-A
C103 4030006950 S.CERAMIC C1608 CH 1H040C-T-A
C104 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C105 4030007100 S.CERAMIC Cl 808 CH 1H580J-T-A
C107 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C108 4010005490 CERAMIC HM60SJ CH 120J 500V
C100 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
Clio 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
cm 4030007050 S.CERAMIC C1808CH1H220J-T-A
C112 4030007050 S.CERAMIC C1808CH 1H220J-T-A
C113 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C114 4030006910 S.CERAMIC C1808CH 1H0R5C-T-A
C115 4030006910 S.CERAMIC C1808CH 1H0R5C-T-A
C118 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C117 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C118 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C119 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C120 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C121 4030007060 S.CERAMIC Cl 808 CH 1H270J-T-A
C122 4030006920 S.CERAMIC C1608 CH 1H 010C-T-A
C123 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C124 4030009470 S.CERAMIC C1608 CH 1H R75C-T-A
C125 4030007050 S.CERAMIC C1808 CH 1H 220J-T-A
C126 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C127 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C128 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
C129 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
Cl 30 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C131 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
Cl 32 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C133 4030007090 S.CERAMIC Cl 608 CH 1H470J-T-A
C134 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C135 4510004540 S.ELECTROLYTIC ECEV0JA470SR
C136 4030006900 S.CERAMIC C1608 JB IE 103K-T-A
C137 4030006900 S.CERAMIC C1608 JB IE 103K-T-A
C138 4030007160 S.CERAMIC C1608 CH 1H 181J-T-A
C139 4030006900 S.CERAMIC C1608 JB IE 103K-T-A
C140 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C141 4030006870 S.CERAMIC Cl 608 JB 1H222K-T-A
C142 4030006880 S.CERAMIC Cl 608 JB 1H472K-T-A
C143 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C144 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C145 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C146 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C147 4030006860 S.CERAMIC Cl 608 JB 1H 102K-T-A
C148 4030008630 S.CERAMIC C1808 JF 1C 104Z-T-A
C149 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C150 4030007120 S.CERAMIC Cl 608 CH 1H 820J-T-A
C151 4030006860 S.CERAMIC Cl 808 JB 1H 102K-T-A
C1S2 4030006850 S.CERAMIC C1608 JB 1H471K-T-A
S,=Surface mount
5-5

[MAIN UNIT]
REF.
NO. ORDER NO. DESCRIPTION
C153 4510004440 S.ELECTROLYTIC ECEV1HA010SR
Cl 54 4030006880 S.CERAMIC C1808 4B 1H 102K-T-A
Cl 55 4030008860 S.CERAMIC C1608JB1C153K-T-A
Cl 56 4030008860 S.CERAMIC C1808 JB 1C 153K-T-A
Cl 57 4030008630 S.CERAMIC C1608 JF1C104Z-T-A
Cl 56 4030006880 S.CERAMIC Cl 608 JB 1H472K-T-A
C160 4030006870 S.CERAMIC C1608 JB 1H222K-T-A
C161 4030008880 S.CERAMIC C2012 JF 1C 105Z-T-A
C163 4030008630 S.CERAMIC Cl 608 JF1C 104Z-T-A
C164 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C165 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C166 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C167 4030006860 S.CERAMIC C1808 JB 1H 102K-T-A
C168 4510005300 S.ELECTROLYTIC ECEV1AA330SR
C169 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C170 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C171 4030006860 S.CERAMIC Cl 608 JB1H 102K-T-A
C172 4510004840 S.ELECTROLYTIC ECEV1CA470SP
C173 4030008860 S.CERAMIC Cie08JB1H102K-T-A
C174 4030006860 S.CERAMIC C1808 JB1H102K-T-A
C175 4510005300 S.ELECTROLYTIC ECEV1AA330SR
C176 4030006860 S.CERAMIC C1608 JB1H 102K-T-A
Cl 77 4030006860 S.CERAMIC Cl 608 JB1H102K-T-A
Cl 78 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C179 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C180 4510004600 ELECTROLYTIC 16 MV 1000 HC
C181 4030006860 S.CERAMIC C1808JB1H102K-T-A
C182 4510005300 S.ELECTROLYTIC ECEV1AA330SR
C183 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C184 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C185 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C188 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
Cl 87 4510004540 S.ELECTROLYTIC ECEVOJA470SR
Cl 88 4510004640 S.ELECTROLYTIC ECEV1CA470SP
Cl 89 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C190 4510006260 S.ELECTROLYTIC ECEV1AA471UP
C191 4550006130 S.TANTALUM ECST1VY224R
C193 4030006850 S.CERAMIC C1808 JB 1H471K-T-A
Cl 64 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C195 4030008630 S.CERAMIC Cl 608 JF1C104Z-T-A
Cl 98 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C197 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C198 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C199 4030006860 S.CERAMIC C1608 JB IH 102K-T-A
C200 4030006860 S.CERAMIC C1608 JB IH 102K-T-A
C201 4030006860 S.CERAMIC C1608 JB IH 102K-T-A
C202 4030006860 S.CERAMIC C1808 JB IH 102K-T-A
C203 4030006860 S.CERAMIC C1808 JB IH 102K-T-A
C205 4030006880 S.CERAMIC Cl 608 JB IH 102K-T-A
C206 4030006860 S.CERAMIC C1808 JB IH 102K-T-A
C207 4030006860 S.CERAMIC C1608 JB IH I02K-T-A
C208 4030006860 S.CERAMIC CI808 JB IH 102K-T-A
C209 4030006860 S.CERAMIC C1608 JB IH 102K-T-A
C210 4030007130 S.CERAMIC CI808 CH1H101J-T-A
C211 4030006860 S.CERAMIC Cl 808 JB IH 102K-T-A
C212 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C213 4030006860 S.CERAMIC C1608 JB IH 102K-T-A
C214 4030009470 S.CERAMIC C1608 CH IH R75C-T-A
C215 4030007000 S.CERAMIC C1608 CH IH 090D-T-A
C218 4030007110 S.CERAMIC C1608 CH IH 680J-T-A
C217 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C218 4030008760 S.CERAMIC C2012X7R1C104K-T-A
C222 4030009990 S.CERAMIC C1608 CH IH 200J-T-A
C223 4030006990 S.CERAMIC Cl 608 CH IH 0800-T-A
C224 4030008630 S.CERAMIC Cl 608 JF 1C 104Z-T-A
C225 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C226 4030008630 S.CERAMIC C1608 JF1C104Z-T-A
C227 4030008630 S.CERAMIC C1608 JF1C 104Z-T-A
C229 4030008760 S.CERAMIC C2012X7R 1C 104K-T-A
C230 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C231 4030006900 S.CERAMIC C1608 JB IE 103K-T-A
C232 4030006860 S.CERAMIC 01608 JB IH 102K-T-A
C233 4030008990 S.CERAMIC C1808 CH IH 080D-T-A
C234 4030006920 S.CERAMIC C1808CH 1H010C-T-A
C235 4030011190 S.CERAMIC GRM42-6 CH 270J 500PT
ITHA] only
[MAIN UNIT]
REF.
NO. ORDER NO. DESCRIPTION
W1 8900004880 CABLE OPC-485
W2 7120000380 JUMPER JPW 01 R-01
W3 7120000380 JUMPER JPW 01 R4)1
W4 7030003860 S.JUMPER ERJ3GEJPWV
W5 7030003860 S.JUMPER ERJ3GEJPWV
J2 6510018040 CONNECTOR 52330-1217
J3 6510018040 CONNECTOR 52330-1217
J4 6510012880 S.CONNECTOR CEW91 14-0202
J5 6510014960 S.CONNECTOR B2B-ZR-SM3-TF
J6 6450000140 CONNECTOR HSJ0807-01-010
EP1 0910044122 PCB B4442B
S.=Surface mount
5-6

SECTION 6MECHANICAL PARTS AND DISASSEMBLY
•CHASSIS PARTS
LABEL
NUMBER ORDER NO. DESCRIPTION QTY.
©8810005250 Hex socket bolt M4 x18 ZK 2
8610006480 Knob N152 [SQL], [VOL] 2
8610006470 Knob N151 [DIAL] 1
©8210011920 1642 front panel assembly 1
8930034820 1642 LCD holder 1
5030001190 LCD LD-HU4304E 1
8930034830 1642 LCD filter 1
8930035720 LCD contact SRCN-1642SSW 1
®8210011930 1642 reflector 1
8930034810 White seat (attatched to the reflector) 1
HUH 7210001860 Variable resistor EVU-F2AF20 B14 [SQL] 1
7210001870 Variable resistor EVU-F2AF20 A14 [VOL] 1
2250000050 Encoder EVQ-WQGF15 24B [DIAL] 1
8010015900 1642 chassis 1
6510004880 Connector MR-DS-E 01 [ANT] 1
8810008660 Screw PH BT M3x8 NI-ZU 7
8900004880 Power receptacle cable OPC-465 1
8930034840 1642 speaker holder 1
8510009700 1642 module plate 1
8930035070 1642 clip 1
2510000470 Speaker EAS-6P100SA 1
@8110005440 1642 cover (include felt, speaker net) 1
8810008630 Screw PH BT M3x6 NI-ZU 1
8510009550 1642 VCO case 1
Screw abbreviations PH: Pan head Nl: Nickel ZK: Black
•ACCESSORIES
LABEL
NUMBER ORDER NO. DESCRIPTION QTY.
©5210000080 Fuse (20 A) 1
8900003760 DC power cable OPC-346 1
Optional product HM-95 DTMF microphone
(USA, KOR) 1
Optional product HM-96 hand microphone
(THA, AUS, SEA) 1
Optional product HM-97 hand microphone with
1750 Hz encoder (EUR, ITA) 1
8010008710 150 mobile mounting bracket 1
®.8930008050 Felt (A) (attatched to the bracket) 2
8820000530 Flange bolt 4
8810000470 Screw PH M5xl2(-F/-) 4
®8810000950 Screw PH AM5X16 4
®8850000150 Flat washer M5 Nl BS 4
@8850000390 Spring washer M5 4
®8830000120 Nut M5 4
Screw abbreviations PH: Pan head Nl: Nickel
BS: Brass
6-1
