Icom IC-F3400DP Series User manual

INSTRUCTIONS
A-7311D-1EX-ePrinted in Japan
© 2016–2017 Icom Inc.
1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan
VHF DIGITAL TRANSCEIVERS
Iç-F4400D series
Iç-F4400DP series
UHF DIGITAL TRANSCEIVERS
Iç-F3400D series
Iç-F3400DP series
- 1 -
Thank you for choosing this Icom product.
READ ALL INSTRUCTIONS carefully and completely
before using this product.
This instruction sheet includes some functions that are
usable only when they are preset by your dealer. The
transceiver may have other functions and operations that
are not described in this instruction sheet. Ask your dealer
for preset function details.
IMPORTANT
Battery pack Belt clip Connector cover
(with a screw)
Flexible Antenna
SUPPLIED ACCESSORIES
NOTE: Some accessories are not supplied, or the shape
is different, depending on the transceiver version.
DAbout the transceiver types
There are 3 types of transceivers.
IC-F3400D, IC-F4400D, IC-F3400DP, IC-F4400DP:
Non-display types
IC-F3400DS, IC-F4400DS, IC-F3400DPS, IC-F4400DPS:
Simple key types
IC-F3400DT, IC-F4400DT, IC-F3400DPT, IC-F4400DPT:
Ten-key types
DAbout the Status indicator
• Lights white, then blinks red, yellow, and green when
turning ON the transceiver.
• Lights red while transmitting.
• Lights green while receiving a signal, or when the squelch
is open.
• Blinks magenta when the battery is exhausted.
DAbout the Multi-connector
Connects to an optional speaker microphone or headset.
CAUTION: DO NOT use the transceiver without the
connector cover
or the optional equipment attached.
The transceiver meets IP68 requirements for dust-tight and
waterproof protection only when the connector cover or the
optional HM-222 is attached.
DAbout the Software key functions
NOTE: Your dealers can assign the Software key
functions to the keys, keypads, and the Lever switch.
PANEL DESCRIPTION
[Emer]
[P1]
[P2]
[Selector]
[VOL]
[Back]
[OK]
[PTT]
Status
indicator
Function
Display
Ten-Key
Pad
[F2]
[F3]
microSD
Card Slot
USB
Connector
Antenna
Connector
Lever
Switch
DBATTERY PACKS
•BP-283*1 Li-ion BATTERY PACK
Voltage: 7.2 V
Capacity: 1910 mAh (minimum), 2010 mAh (typical)
Battery life: Approximately 10.5 hours
•BP-284*1 Li-ion BATTERY PACK
Voltage: 7.2 V
Capacity: 3070 mAh (minimum), 3210 mAh (typical)
Battery life: Approximately 16.5 hours
*1
When the power save function is set to “Short,” and the
operating periods are calculated under the following
conditions:
TX : RX : standby = 5 : 5 : 90
DCHARGERS
•BC-219 DESKTOP CHARGER + BC-123S AC ADAPTER
For rapidly charging of battery packs.
Charging time: Approximately 2.8 hours for the BP-283
A power adapter may be supplied, depending on the charger’s
version.
•BC-214 MULTI-CHARGER
+ BC-157S AC ADAPTER, OPC-656 DC POWER CABLE
For rapidly charging of up to 6 battery packs
simultaneously.
Charging time: Approximately 2.8 hours for the BP-283
The AD-130 CHARGER ADAPTER may be needed, depending on
the charger's version.
The BC-157S AC ADAPTER or OPC-656 DC POWER CABLE must
be purchased separately.
DDC CABLES
•CP-23L CIGARETTE LIGHTER CABLE
Used when charging battery packs through a 12 V
cigarette lighter socket. For use with the BC-219.
•OPC-515L, OPC-656 DC POWER CABLES
Used when charging battery packs using a 13.8 V DC
power source instead of the power adapter.
OPC-515L: For the BC-219
OPC-656: For the BC-214
DBELT CLIPS and BELT HANGERS
• MB-133 BELT CLIP
• MB-136 BELT CLIP
Rotating type.
• MB-96F, MB-96FL, MB-96N BELT HANGERS
DANTENNAS
•FA-S81VS, FA-S82VS, FA-S83VS,
FA-S81US, FA-S82US STUBBY ANTENNAS
Shorter VHF or UHF antennas.
FA-S81VS: 136 ~ 150 MHz FA-S82VS: 150 ~ 162 MHz
FA-S83VS: 160 ~ 174 MHz FA-S81US: 400 ~ 450 MHz
FA-S82US: 450 ~ 490 MHz
•FA-S81V, FA-S82V, FA-S83V,
FA-S81U, FA-S82U, FA-S83U FLEXIBLE ANTENNAS
VHF or UHF antennas.
FA-S81V: 136 ~ 150 MHz FA-S82V: 148 ~ 160 MHz
FA-S83V: 160 ~ 174 MHz FA-S81U: 380 ~ 430 MHz
FA-S82U: 430 ~ 480 MHz FA-S83U: 470 ~ 520 MHz
• FA-S67VC, FA-S76UC CUT ANTENNAS
FA-S67VC: 136 ~ 174 MHz FA-S76UC: 380 ~ 520 MHz
DOTHERS
• AD-118 ACC ADAPTER
To connect an accessory. See the AD-118 instruction
sheet for details of recommended accessories.
CAUTION: The AD-118 does not have waterproof
protection. When it is connected, NEVER expose the
adaptor and the transceiver to rain, snow or any liquids.
• LC-184 CARRYING CASE
For the Simple key types and Ten-key types.
• LC-186 CARRYING CASE
For the Non-display types.
•VS-4MC*2 PTT SWITCH CABLE
+ HS-94, HS-95, HS-97 HEADSET
VS-4MC: Used to connect a headset to a transceiver.
HS-94: Ear-hook type
HS-95: Neck-arm type
HS-97: Throat microphone
*2 Non-waterproof.
•HM-222 SPEAKER MICROPHONE
With an Emergency key.
The HM-222 meets IP68 requirements for waterproof
protection.
•VS-3 Bluetooth®HEADSET
The Bluetooth® headset with a [PTT] switch.
•About the third party Bluetooth®headsets:
Icom has checked the PTT operation with some 3M Peltor
headsets such as the WS Headset XP, WS ProTac XP and
WS Alert XP. (Compatibility not guaranteed.)
OPTIONS
Some options may not be available in some countries.
Ask your dealer for details.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor-
porated (Japan) in Japan, the United States, the United Kingdom, Germa-
ny, France, Spain, Russia, Australia, New Zealand, and/or other countries.
The Bluetooth word mark and logos are registered trademarks owned by
the Bluetooth SIG, Inc. and any use of such marks by Icom Inc. is under
license. Other trademarks and trade names are those of their respective
owners.
All other products or brands are registered trademarks or trademarks of
their respective holders.
Multi-
connector
[F1]
Speaker
Micro-
phone
[Up]/[Down]
[Right]/[Left]
- 4 -
The illustration is of the Ten-key type transceiver.

- 2 - - 3 -
FUNCTION DISPLAY
DIcon Area
Indicators
qSIGNAL STRENGTH INDICATOR
Displays the relative receive signal strength level.
w CLOCK
Displays the current time.
“AM” or “PM” is displayed beside the time display when 12
hour display format is selected.
e BATTERY INDICATOR
Displayed or blinks to indicate the battery status.
Indication
Battery
status Full Mid Charging required
Battery
exhausted
blinks when the battery is exhausted.
Icons
The following icons are displayed in the Icon Area.
POWER ICON
• “L1” is displayed when the output power is set to Low.
• “L2” is displayed when the output power is set to Mid.
• “H” is displayed when the output power is set to High.
AUDIBLE ICON
Displayed when the channel is in the ‘audible’ (unmute)
mode.
MESSAGE ICON
• Blinks after Messages (Message or Status Message) have been
received.
• Stops blinking when the screen is changed, or any key is pushed,
but is displayed if unread messages are still in the Message
memory.
• Disappears when all messages in the Message memory have
been read.
BELL ICON
Displayed when a matching signal is received, depending
on the presetting.
SCAN ICON
•Displayed when a scan is paused.
• Blinks while scanning.
SCAN TARGET CHANNEL ICON
Displayed when the channel is selected as a scan target channel.
NOTE: The screen capture is an example.
The displayed position of each icon may differ, depending
on the function being used.
Icon Area
Text Area
Key Display
Area
q w
e
SCRAMBLER ICON
In the Analog mode:
•Displayed when the Voice Scrambler function is ON.
In the Digital mode:
•Displayed when the Voice Encryption function is ON.
• Blinks when decoding an encrypted signal.
GPS ICON
• Displayed when valid position data is received.
• Blinks when searching for satellites or calculating position data.
RECORD ICON
• Displayed when the Record function is ON.
• Blinks while recording audio.
“ ” is displayed when there is no microSD card’s free space
and cannot record audio.
TALK AROUND ICON
Displayed when the Talk Around function is ON.
PHONE ICON
•Displayed when the transceiver is connected to a telephone
network on the selected channel.
• Blinks while receiving a phone call.
SITE LOCK ICON
Displayed when the Site Lock function is ON.
LONE WORKER ICON
Displayed when the Lone Worker function is ON.
MOTION SENSOR ICON
Displayed when the Motion Sensor function is ON.
NOISE CANCEL ICON
Displayed when the Noise Cancel function is ON.
SURVEILLANCE ICON
Displayed when the Surveillance function is ON.
VIBRATION ICON
Displayed when the Vibration function is ON.
VOX ICON
Displayed when the VOX function is ON.
Bluetooth®ICON
• Displayed when Bluetooth® is activated.
• Lights Blue when a Bluetooth®device is connected.
• Does not light when no Bluetooth®device is connected.
microSD ICON
Displayed when the microSD card is inserted into the card slot.
“ ” is displayed when the microSD card has not been formatted.
USB ICON
Displayed when a USB device is connected.
DText Area
Displays the selected Zone number, Channel number, and
Channel name, if set.
DKey Display Area
Displays the names of the function assigned to [P1] and [P2].
Ask your dealer about the assigned Software key functions.
DTurning ON the transceiver
NOTE: Before using the transceiver for the fi rst time, the
battery pack must be fully charged for optimum life and
operation. See the BATTERY CHARGING section of this
sheet.
Rotate [VOL] to turn ON the transceiver.
DReceiving and Transmitting
Receiving:
1. Select a channel.
Rotate [Selector].
Push [Up] or [Down].
2. When receiving a call, rotate [VOL] to adjust the audio
output level to a comfortable listening level.
Transmitting:
CAUTION: Attach an antenna before transmitting.
Transmitting without an antenna may damage the
transceiver.
1. Wait until the channel is clear to avoid interference.
2. While holding down [PTT], speak at your normal voice
level.
3. Release [PTT] to receive.
IMPORTANT:
To maximize the readability of your signal:
1. After pushing [PTT], pause briefl y before you start
speaking.
2. Hold the microphone 5 to 10 cm (2 to 4 inches) from
your mouth, then speak at your normal voice level.
BASIC OPERATION
BATTERY CHARGING
DRapid charging with the BC-219
DRapid charging with the BC-214
You can rapidly charge up to 6 battery packs with the
optional BC-214.
Charging time:
Approximately 2.8 hours for the BP-283
Additionally needed items (purchase separately):
• The BC-157S AC ADAPTER or the OPC-656 DC POWER CABLE
• The AD-130 CHARGER ADAPTER (may be supplied with the
charger, depending on the charger version)
CAUTION: NEVER reverse the polarity when connecting
the OPC-656 to a power source. This will ruin the battery
charger.
Red line: +,Black line: _
Battery pack
+ Transceiver
OPC-656
Connect to a
DC power supply:
12 to 16 V, at least 7 A
Red line: +
Black line: _
BC-214
BC-157S
Battery pack
Turn OFF
Power adapter
(A different type, or no power adapter is
supplied, depending on the charger version.)
Battery pack
+ Transceiver
The OPC-515L*
(for a 13.8 V power
source) or the
CP-23L (for a 12 V
cigarette lighter
socket) can be
used instead of the
power adapter.
Turn OFF
Battery pack
You can rapidly charge the Li-ion battery pack with the
BC-219.
Charging time:
Approximately 2.8 hours for the BP-283
Additionally needed item (purchase separately):
• A power adapter (may be supplied with the charger,
depending on the charger version) or the OPC-515L/CP-23L DC
POWER CABLES.
CAUTION: NEVER reverse the polarity when connecting
the OPC-515L to a power source. This will ruin the battery
charger.
White line: +,Black line: _
NOTE:
• Before detaching or attaching a battery pack, BE SURE to turn OFF the transceiver by rotating [VOL] fully counter clockwise, until it makes a
“click” sound. Otherwise, a transceiver malfunction could occur.
• The internal clock will be reset to 00:00 if an exhausted battery is left in the transceiver, or the battery pack is detached, for long periods of time.
“ ”
and cannot record audio.
