SERVICE MANUAL
ADDENDUM
CONTENTS
REPLACEMENT PAGE . . . . . . . . . . . . . . . . . . . . . . . 4-5
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 26
Nov. 2011
[VERSION LIST]
Model Version
IC-M802
USA
OTH
CAN
CHN
CHN-01
IC-M802FMS VNM

4 - 5
4-3 PA AND FILTER UNITS ADJUSTMENT
IDLING
CURRENT
(For drive
FETs)
(For final
transistors)
SWR
DETECTOR
1
2
3
sOperating frequency : 12.2350 MHz
sMode : J3E
sApply no audio signal to the [MICRO-
PHONE] connector.
sDisconnect J6702.
sPreset R6304 and R6412 on the PA
unit to maximum counter clockwise.
sConnect a dummy load or RF power
meter to the [ANT] connector.
sTransmitting
sTransmitting
sTransmitting
sOperating frequency : 22.0000 MHz
sMode : J3E
sConnect the CP7332 (FOR line) on
the FILTER unit to ground.
sConnect an audio generator to the
[MICROPHONE] connector and set
as;
Frequency : 1.5 kHz
sTransmitting
Rear
panel
Rear
panel
FIL-
TER
Connect an ammeter
(10 A) between an
external power supply
and the transceiver.
Connect an RF power
meter to the [ANT]
connector.
Connect a DC volt-
meter to check point,
CP7331.
+2.0 A*
more than
the initial value.
1.0 A**
more than
the initial value.
Note the current
as the initial value.
+0.7 A
more than
step “2.”
140 W
Minimum level
PA
Audio
gen-
erator
FIL-
TER
–
R6304
R6412
Output
level
C7275
ADJUSTMENT ADJUSTMENT CONDITIONS
UNIT LOCATION
VALUE
UNIT ADJUST
TNEMTSUJDATNEMERUSAEM
sAfter the adjustment, connect J6701 to the PA unit.
1
2
sAfter adjustment, disconnect CP7332 (FOR line) on the FILTER unit from ground.
*; For all models except [VNM].**; For [VNM].
(Replacement page)
Nov. 2011

Nov. 2011
1
SECTION 6
.
PARTS LIST
IC1 1110004080 S.IC UPC2709T-E3 T 184.6/110.3
IC501 1110005461 S.IC TA4107F(TE12LF) T 91.3/61.0
IC901 1110005461 S.IC TA4107F(TE12LF) T 78.2/61.2
IC1001 1130006221 S.IC TC4W53FU(TE12LF) T 77.6/33.9
IC1002 1110005450 S.IC TS522IDT T 90.7/40.5
IC1051 1110005450 S.IC TS522IDT T 74.2/23.0
IC1101 1110005450 S.IC TS522IDT T 53.6/63.9
IC1201 1110005140 S.IC NJM3403AV-TE1-#ZZZB T 118.2/93.7
IC1301 1160000132 S.IC TD62783AFG(OSEL) T 98.7/96.2
IC1302 1160000132 S.IC TD62783AFG(OSEL) T 166.8/72.5
IC1303 1160000132 S.IC TD62783AFG(OSEL) T 57.9/87.0
IC1501 1180000421 S.IC TA78L05F(TE12RF) T 9.0/54.7
IC1502 1180002182 S.IC TA78M08F(TE16L1NQ) T 152.4/98.5
IC1551 1110001401 S.IC UPC1555G2-E1-A T 61.1/101.5
IC1601 1110003091 IC LA4425A-E
IC1602 1130006221 S.IC TC4W53FU(TE12LF) T 15.5/4.3
IC1603 1110003300 S.IC M5282FP 70CD T 28.7/16.6
IC1701 1130006221 S.IC TC4W53FU(TE12LF) T 25.6/36.3
IC1702 1110005450 S.IC TS522IDT T 45.8/24.3
IC1703 1130006221 S.IC TC4W53FU(TE12LF) T 76.9/44.6
IC2001 1140013200 S.IC CD4053BPWR T 57.6/16.3
IC2701 1110005461 S.IC TA4107F(TE12LF) [USA] T 40.0/38.9
1110005461 S.IC TA4107F(TE12LF) [CAN]
1110005461 S.IC TA4107F(TE12LF) [CHN]
1110005461 S.IC TA4107F(TE12LF) [VNM]
IC2702 1110005450 S.IC TS522IDT [USA] T 56.9/36.5
1110005450 S.IC TS522IDT [CAN]
1110005450 S.IC TS522IDT [CHN]
1110005450 S.IC TS522IDT [VNM]
IC3101 1180000421 S.IC TA78L05F(TE12RF) T 140.1/4.9
IC3201 1130005721 S.IC TC7W04F(TE12LF) T 85.6/19.4
IC3301 1140009241 S.IC R1EX24128ASA00A [USA] T 105.3/54.9
1130011211 S.IC CAT24FC64WI-TE13 [OTH]
1140009241 S.IC R1EX24128ASA00A [CAN]
1140009241 S.IC R1EX24128ASA00A [CHN]
1130011211 S.IC CAT24FC64WI-TE13 [CHN-01]
1140009241 S.IC R1EX24128ASA00A [VNM]
IC3302 1110005771 S.IC S-80942CNMC-G9CT2G T 104.0/45.6
IC3303 1140010633 S.IC M30624FGAFP D5 (SX-2429A-4)
[USA] T 118.1/41.2
1140010051 S.IC M30620FCAFP(SX-2429C-2)
[OTH]
1140010633 S.IC M30624FGAFP D5 (SX-2429A-4)
[CAN]
1140010633 S.IC M30624FGAFP D5 (SX-2429A-4)
[CHN]
1140010051 S.IC M30620FCAFP(SX-2429C-2)
[CHN-01]
1140016041 S.IC M30624FGAFP(SX-2429D-1)
[VNM]
IC3601 1130007700 S.IC BU4094BCF-E2 T 95.8/5.9
IC3602 1130007700 S.IC BU4094BCF-E2 T 99.3/85.8
IC3603 1130007700 S.IC BU4094BCF-E2 T 86.5/26.6
IC3604 1130007700 S.IC BU4094BCF-E2 T 170.0/62.0
IC3605 1130007700 S.IC BU4094BCF-E2 T 68.6/86.8
IC3606 1110003690 S.IC M62354GP 75EC T 67.3/72.2
Q51 1530003091 S.TRA 2SC4213-B(TE85RF) T 153.4/104.5
Q201 1560000721 S.FET 2SK2171-4-TD-E T 184.4/56.3
Q202 1560000721 S.FET 2SK2171-4-TD-E T 179.5/59.8
Q203 1580000620 S.FET 3SK131-T2 MAS T 191.4/32.6
Q401 1580000620 S.FET 3SK131-T2 MAS T 136.6/80.3
Q501 1580000620 S.FET 3SK131-T2 MAS T 92.2/74.6
Q601 1530003340 S.TRA 2SC3357-T1 RF T 201.4/55.5
Q701 1580000620 S.FET 3SK131-T2 MAS T 204.6/78.4
Q702 1580000620 S.FET 3SK131-T2 MAS T 212.9/55.5
Q703 1580000620 S.FET 3SK131-T2 MAS T 207.9/55.5
Q801 1580000620 S.FET 3SK131-T2 MAS T 132.9/70.8
Q1203 1510000771 S.TRA 2SA1586-GR(TE85LF) T 131.7/93.0
Q1204 1510000771 S.TRA 2SA1586-GR(TE85LF) T 136.8/100.2
Q1205 1530003091 S.TRA 2SC4213-B(TE85RF) T 132.9/101.5
Q1206 1530003091 S.TRA 2SC4213-B(TE85RF) [OTH] T 112.6/103.3
1530003091 S.TRA 2SC4213-B(TE85RF) [CHN-01]
Q1207 1510000771 S.TRA 2SA1586-GR(TE85LF) [OTH] T 116.6/102.1
1510000771 S.TRA 2SA1586-GR(TE85LF) [CHN-01]
Q1501 1540000441 S.TRA 2SD1619T-TD-E T 83.7/91.3
Q1502 1540000441 S.TRA 2SD1619T-TD-E T 85.6/98.7
Q1503 1590000680 S.TRA DTC114EUA T106 T 87.8/92.5
Q1504 1590000680 S.TRA DTC114EUA T106 T 88.4/102.5
Q1601 1590000680 S.TRA DTC114EUA T106 T 6.9/11.5
Q1801 1540000441 S.TRA 2SD1619T-TD-E T 140.6/15.8
Q2101 1590000680 S.TRA DTC114EUA T106 [USA] T 41.6/111.4
1590000680 S.TRA DTC114EUA T106 [CAN]
1590000680 S.TRA DTC114EUA T106 [CHN]
1590000680 S.TRA DTC114EUA T106 [VNM]
Q2102 1530002691 S.TRA 2SC4116-GR(TE85RF) [USA] T 41.6/108.1
1530002691 S.TRA 2SC4116-GR(TE85RF) [CAN]
1530002691 S.TRA 2SC4116-GR(TE85RF) [CHN]
1530002691 S.TRA 2SC4116-GR(TE85RF) [VNM]
Q2301 1560000721 S.FET 2SK2171-4-TD-E [USA] T 36.8/75.0
1560000721 S.FET 2SK2171-4-TD-E [CAN]
1560000721 S.FET 2SK2171-4-TD-E [CHN]
1560000721 S.FET 2SK2171-4-TD-E [VNM]
Q2302 1560000721 S.FET 2SK2171-4-TD-E [USA] T 36.8/69.0
1560000721 S.FET 2SK2171-4-TD-E [CAN]
1560000721 S.FET 2SK2171-4-TD-E [CHN]
1560000721 S.FET 2SK2171-4-TD-E [VNM]
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
Q2401 1580000620 S.FET 3SK131-T2 MAS [USA] T 34.3/57.3
1580000620 S.FET 3SK131-T2 MAS [CAN]
1580000620 S.FET 3SK131-T2 MAS [CHN]
1580000620 S.FET 3SK131-T2 MAS [VNM]
Q2501 1580000620 S.FET 3SK131-T2 MAS [USA] T 44.0/50.8
1580000620 S.FET 3SK131-T2 MAS [CAN]
1580000620 S.FET 3SK131-T2 MAS [CHN]
1580000620 S.FET 3SK131-T2 MAS [VNM]
Q3001 1590000680 S.TRA DTC114EUA T106 T 130.4/102.1
Q3004 1530002691 S.TRA 2SC4116-GR(TE85RF) T 137.4/22.6
D51 1750001360 S.DIO L709CER (9401) T 160.3/109.7
D52 1750001360 S.DIO L709CER (9401) T 163.1/109.7
D53 1790001770 S.DIO MA80WK-(TX) T 174.4/110.2
D101 1790001770 S.DIO MA80WK-(TX) T 171.9/103.1
D102 1790001770 S.DIO MA80WK-(TX) T 178.0/103.8
D103 1790001770 S.DIO MA80WK-(TX) T 189.7/103.8
D104 1790001770 S.DIO MA80WK-(TX) T 204.8/103.8
D105 1790000620 S.DIO MA77(TX) T 216.7/103.6
D106 1790001770 S.DIO MA80WK-(TX) T 167.8/86.3
D107 1790001770 S.DIO MA80WK-(TX) T 181.6/83.7
D108 1790001770 S.DIO MA80WK-(TX) T 192.1/84.7
D109 1790001770 S.DIO MA80WK-(TX) T 206.3/84.7
D110 1790000620 S.DIO MA77(TX) T 216.8/84.9
D201 1790001770 S.DIO MA80WK-(TX) T 192.8/81.1
D301 1790001770 S.DIO MA80WK-(TX) T 207.1/32.9
D302 1750000431 S.DIO HSB88WSTR-E T 160.0/30.3
D303 1790001770 S.DIO MA80WK-(TX) T 154.8/50.1
D401 1790000620 S.DIO MA77(TX) T 127.1/75.2
D402 1790000620 S.DIO MA77(TX) T 94.8/77.2
D403 1790000620 S.DIO MA77(TX) T 124.0/67.9
D404 1790000620 S.DIO MA77(TX) T 97.1/66.2
D601 1730002900 S.ZEN KDZTR9.1B T 194.1/54.3
D602 1790001770 S.DIO MA80WK-(TX) T 193.1/50.4
D901 1790001770 S.DIO MA80WK-(TX) T 82.8/52.5
D1102 1790001241 S.DIO MA2S7280GL T 55.5/58.5
D1201 1790001241 S.DIO MA2S7280GL T 112.6/88.1
D1202 1790001251 S.DIO MA2S1110GL [USA] T 123.5/97.1
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D1203 1790001251 S.DIO MA2S1110GL [USA] T 123.5/98.4
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D1204 1790001251 S.DIO MA2S1110GL [USA] T 126.3/89.8
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D1205 1790001251 S.DIO MA2S1110GL [USA] T 127.7/93.0
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D1206 1790000620 S.DIO MA77(TX) T 138.5/89.0
D1207 1790001251 S.DIO MA2S1110GL [USA] T 127.7/94.3
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D1501 1790001670 S.DIO RB706F-40T106 T 83.2/95.5
D1502 1790001670 S.DIO RB706F-40T106 T 83.4/102.9
D1551 1730002321 S.ZEN MAZ8051GML [USA] T 65.4/110.9
1730002321 S.ZEN MAZ8051GML [OTH]
1730002321 S.ZEN MAZ8051GML [CAN]
1730002321 S.ZEN MAZ8051GML [CHN]
1730002321 S.ZEN MAZ8051GML [CHN-01]
1730002830 S.ZEN DZ2J051M0L [VNM]
D1552 1790001670 S.DIO RB706F-40T106 T 70.8/106.6
D1554 1730002900 S.ZEN KDZTR9.1B T 57.7/106.5
D1801 1790001251 S.DIO MA2S1110GL [USA] T 137.5/20.7
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D2101 1790001241 S.DIO MA2S7280GL [USA] T 34.9/106.1
1790001241 S.DIO MA2S7280GL [CAN]
1790001241 S.DIO MA2S7280GL [CHN]
1790001241 S.DIO MA2S7280GL [VNM]
D2102 1790001251 S.DIO MA2S1110GL [USA] T 32.1/111.6
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1750002020 S.DIO DA2S10100L [VNM]
D2103 1750001360 S.DIO L709CER (9401) [USA] T 34.6/110.7
1750001360 S.DIO L709CER (9401) [CAN]
1750001360 S.DIO L709CER (9401) [CHN]
1750001360 S.DIO L709CER (9401) [VNM]

Nov. 2011
2
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
D2104 1750001360 S.DIO L709CER (9401) [USA] T 37.4/110.7
1750001360 S.DIO L709CER (9401) [CAN]
1750001360 S.DIO L709CER (9401) [CHN]
1750001360 S.DIO L709CER (9401) [VNM]
D2201 1790001770 S.DIO MA80WK-(TX) [USA] T 32.2/102.1
1790001770 S.DIO MA80WK-(TX) [CAN]
1790001770 S.DIO MA80WK-(TX) [CHN]
1790001770 S.DIO MA80WK-(TX) [VNM]
D2202 1790001770 S.DIO MA80WK-(TX) [USA] T 12.3/102.1
1790001770 S.DIO MA80WK-(TX) [CAN]
1790001770 S.DIO MA80WK-(TX) [CHN]
1790001770 S.DIO MA80WK-(TX) [VNM]
D2203 1790001770 S.DIO MA80WK-(TX) [USA] T 35.9/81.6
1790001770 S.DIO MA80WK-(TX) [CAN]
1790001770 S.DIO MA80WK-(TX) [CHN]
1790001770 S.DIO MA80WK-(TX) [VNM]
D2204 1790001770 S.DIO MA80WK-(TX) [USA] T 13.5/81.6
1790001770 S.DIO MA80WK-(TX) [CAN]
1790001770 S.DIO MA80WK-(TX) [CHN]
1790001770 S.DIO MA80WK-(TX) [VNM]
D2301 1750000431 S.DIO HSB88WSTR-E [USA] T 24.5/72.6
1750000431 S.DIO HSB88WSTR-E [CAN]
1750000431 S.DIO HSB88WSTR-E [CHN]
1750000431 S.DIO HSB88WSTR-E [VNM]
D3001 1790001670 S.DIO RB706F-40T106 T 105.6/61.1
D3002 1790001670 S.DIO RB706F-40T106 T 41.8/13.7
D3003 1790001670 S.DIO RB706F-40T106 T 45.6/15.0
D3004 1790001251 S.DIO MA2S1110GL [USA] T 146.5/23.5
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D3006 1790001670 S.DIO RB706F-40T106 T 114.2/80.9
D3007 1790001670 S.DIO RB706F-40T106 T 107.7/65.1
D3301 1790001251 S.DIO MA2S1110GL [USA] T 110.9/26.6
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D3302 1790001251 S.DIO MA2S1110GL [USA] T 113.7/27.4
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D3336 1790001251 S.DIO MA2S1110GL [USA] T 107.3/23.9
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D3337 1790001251 S.DIO MA2S1110GL [USA] T 107.3/25.3
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
FI201 2010002600 XTA 64M15A 64.455 MHz (FL-345)
FI231 2010001880 MON HC-49/U 10.700 MHz (FL-231)
[USA]
2010001880 MON HC-49/U 10.700 MHz (FL-231)
[CAN]
2010001880 MON HC-49/U 10.700 MHz (FL-231)
[CHN]
2010001880 MON HC-49/U 10.700 MHz (FL-231)
[VNM]
FI301 2010002470 XTA 64M15B1 64.45500 MHz (FL-315)
FI401 2020001960 CER CFWLB455KHFA-B0
(CFWM455H)
FI402 2020001330 CER CFWLA455KHFA-B0
(CFWS455HT)
X3301 6050010501 S.XTA CR-636A SMD-49 14.7456 MHz
<KDS> T 103.7/35.5
L1 6200002651 S.COI NLV25T-R18J T 198.1/110.7
L2 6200002911 S.COI NLV25T-R27J T 193.3/109.2
L3 6200002861 S.COI NLV25T-4R7J T 187.6/110.2
L51 6200002861 S.COI NLV25T-4R7J T 166.1/111.0
L52 6200009881 S.COI NLV25T-820J T 165.4/104.8
L53 6200004671 S.COI NLV25T-3R9J T 170.2/110.5
L54 6200002041 S.COI NLV25T-101J T 161.6/104.8
L55 6200002041 S.COI NLV25T-101J T 173.6/105.9
L56 6200002041 S.COI NLV25T-101J T 181.1/106.2
L101 6200003941 S.COI NLV25T-5R6J T 161.2/97.5
L102 6200002861 S.COI NLV25T-4R7J T 168.3/97.7
L103 6200002041 S.COI NLV25T-101J T 167.7/100.5
L104 6200003281 S.COI NLV25T-2R2J T 174.8/97.6
L105 6200002041 S.COI NLV25T-101J T 174.2/100.5
L106 6200009861 S.COI NLV25T-1R5J T 182.0/97.7
L107 6200002041 S.COI NLV25T-101J T 181.2/100.5
L108 6200001981 S.COI NLV25T-1R0J T 188.6/97.5
L109 6200002041 S.COI NLV25T-101J T 188.0/100.5
L110 6200002851 S.COI NLV25T-R82J T 195.5/97.6
L111 6200002041 S.COI NLV25T-101J T 194.9/100.5
L112 6200003661 S.COI NLV25T-R68J T 202.2/97.6
L113 6200002041 S.COI NLV25T-101J T 201.6/101.4
L114 6200002611 S.COI NLV25T-R47J T 209.2/97.7
L115 6200002041 S.COI NLV25T-101J T 208.6/100.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
L116 6200004961 S.COI NLV25T-R33J T 216.2/97.6
L117 6200002041 S.COI NLV25T-101J T 215.7/100.5
L118 6200002861 S.COI NLV25T-4R7J T 161.2/94.0
L119 6200002001 S.COI NLV25T-3R3J T 167.8/94.9
L120 6200003281 S.COI NLV25T-2R2J T 174.2/94.7
L121 6200009861 S.COI NLV25T-1R5J T 181.4/94.8
L122 6200001981 S.COI NLV25T-1R0J T 188.0/94.5
L123 6200003661 S.COI NLV25T-R68J T 195.0/94.6
L124 6200002611 S.COI NLV25T-R47J T 201.6/94.6
L125 6200009851 S.COI NLV25T-R39J T 208.6/94.7
L126 6200002911 S.COI NLV25T-R27J T 215.6/94.6
L127 6200002001 S.COI NLV25T-3R3J T 166.5/91.9
L128 6200003281 S.COI NLV25T-2R2J T 173.7/90.5
L129 6200003661 S.COI NLV25T-R68J T 195.5/91.7
L130 6200002611 S.COI NLV25T-R47J T 202.2/91.6
L131 6200009851 S.COI NLV25T-R39J T 209.2/91.8
L132 6200002911 S.COI NLV25T-R27J T 216.2/91.7
L133 6200003941 S.COI NLV25T-5R6J T 166.1/89.1
L134 6200004951 S.COI NLV25T-1R8J T 180.5/90.6
L135 6200001981 S.COI NLV25T-1R0J T 188.6/91.5
L136 6200003661 S.COI NLV25T-R68J T 194.3/88.9
L137 6200003271 S.COI NLV25T-R56J T 200.4/88.3
L138 6200009851 S.COI NLV25T-R39J T 208.3/89.0
L139 6200004961 S.COI NLV25T-R33J T 214.5/88.3
L140 6200002041 S.COI NLV25T-101J T 160.3/100.7
L141 6200004951 S.COI NLV25T-1R8J T 174.4/87.5
L142 6200004741 S.COI NLV25T-1R2J T 181.4/87.8
L143 6200002851 S.COI NLV25T-R82J T 186.8/88.1
L144 6200002041 S.COI NLV25T-101J T 161.9/85.9
L201 6200002041 S.COI NLV25T-101J T 199.1/82.4
L202 6200002911 S.COI NLV25T-R27J T 189.6/80.2
L203 6200002911 S.COI NLV25T-R27J T 184.3/79.3
L204 6140003620 COI LR-403
L205 6200002041 S.COI NLV25T-101J T 216.0/34.0
L206 6200002631 S.COI NLV25T-R10J T 183.3/61.0
L207 6150004270 COI LS-483A (C-14924)
L208 6150005110 COI LS-540
L209 6150005110 COI LS-540
L210 6150004270 COI LS-483A (C-14924)
L301 6150005110 COI LS-540
L302 6150005110 COI LS-540
L303 6140002810 S.COI LR-317 T 160.0/23.6
L304 6140003530 COI LR-395
L305 6200005011 S.COI NLV25T-100J T 161.5/46.1
L306 6200009871 S.COI NLV25T-120J T 157.3/47.1
L307 6150005110 COI LS-540
L401 6150005140 COI LS-542
L402 6150005140 COI LS-542
L403 6150002291 COI LS-450
L404 6150005140 COI LS-542
L405 6150005140 COI LS-542
L406 6200003520 S.COI ELJFB 102K-F T 128.0/70.3
L502 6200003520 S.COI ELJFB 102K-F T 87.5/71.9
L504 6200002041 S.COI NLV25T-101J T 94.1/66.9
L505 6200002041 S.COI NLV25T-101J T 91.2/64.0
L506 6200003520 S.COI ELJFB 102K-F T 87.7/66.4
L601 6200005011 S.COI NLV25T-100J T 195.5/63.1
L602 6200002841 S.COI NLV25T-R22J T 204.3/63.9
L603 6200003281 S.COI NLV25T-2R2J T 196.8/56.6
L604 6200004961 S.COI NLV25T-R33J T 199.9/49.1
L605 6200002841 S.COI NLV25T-R22J T 196.6/47.7
L701 6140002810 S.COI LR-317 T 198.0/78.6
L702 6200001981 S.COI NLV25T-1R0J T 210.7/79.7
L703 6200003661 S.COI NLV25T-R68J T 213.6/78.7
L704 6200002041 S.COI NLV25T-101J T 212.5/62.0
L705 6200002041 S.COI NLV25T-101J T 208.5/60.9
L706 6150004270 COI LS-483A (C-14924)
L707 6140002810 S.COI LR-317 T 202.9/44.0
L801 6150004440 COI LS-495
L901 6200002041 S.COI NLV25T-101J T 85.1/61.0
L902 6200002041 S.COI NLV25T-101J T 82.3/59.9
L903 6200002041 S.COI NLV25T-101J T 82.4/63.8
L904 6180003630 COI EL0607SKI-102J
L1301 6200005491 S.COI NLV32T-331J T 87.8/87.4
L1302 6200005491 S.COI NLV32T-331J T 83.1/83.9
L1551 6180001000 COI LAL 04NA 102K
L1552 6180001000 COI LAL 04NA 102K
L1601 6170000140 COI LW-15
L1801 6200003950 S.COI HF50ACC 322513-T T 148.7/14.0
L1802 6200003950 S.COI HF50ACC 322513-T T 145.1/11.2
L1803 6200002041 S.COI NLV25T-101J T 148.7/9.9
L1804 6200002041 S.COI NLV25T-101J T 149.3/25.0
L1901 6200002041 S.COI NLV25T-101J T 143.3/105.4
L1902 6200002041 S.COI NLV25T-101J T 136.3/102.7
L1903 6200002041 S.COI NLV25T-101J T 120.6/108.5
L1904 6200003950 S.COI HF50ACC 322513-T T 140.6/105.1
L1905 6200002041 S.COI NLV25T-101J T 126.0/105.6
L1906 6140002220 COI LR-270 (TR6X3X2 3A9)
L1907 6200003950 S.COI HF50ACC 322513-T T 17.0/11.4
L1908 6200003950 S.COI HF50ACC 322513-T T 137.0/105.4
L2051 6200002041 S.COI NLV25T-101J T 35.1/8.3
L2052 6200002041 S.COI NLV25T-101J T 43.8/10.1
L2053 6200002041 S.COI NLV25T-101J T 61.4/12.5
L2054 6200002041 S.COI NLV25T-101J T 46.3/10.1
L2101 6200002041 S.COI NLV25T-101J [USA] T 35.4/102.9
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2201 6200003281 S.COI NLV25T-2R2J [USA] T 36.3/99.9
6200003281 S.COI NLV25T-2R2J [CAN]
6200003281 S.COI NLV25T-2R2J [CHN]
6200003281 S.COI NLV25T-2R2J [VNM]

Nov. 2011
3
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
L2202 6200002041 S.COI NLV25T-101J [USA] T 39.3/100.9
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2204 6200002041 S.COI NLV25T-101J [USA] T 28.7/100.6
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2205 6180001730 COI LAL 02NA 1R8K [USA]
6180001730 COI LAL 02NA 1R8K [CAN]
6180001730 COI LAL 02NA 1R8K [CHN]
6180001730 COI LAL 02NA 1R8K [VNM]
L2206 6200002041 S.COI NLV25T-101J [USA] T 8.5/100.9
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2207 6200003711 S.COI NLV25T-2R7J [USA] T 42.3/99.0
6200003711 S.COI NLV25T-2R7J [CAN]
6200003711 S.COI NLV25T-2R7J [CHN]
6200003711 S.COI NLV25T-2R7J [VNM]
L2208 6200002611 S.COI NLV25T-R47J [USA] T 28.4/97.8
6200002611 S.COI NLV25T-R47J [CAN]
6200002611 S.COI NLV25T-R47J [CHN]
6200002611 S.COI NLV25T-R47J [VNM]
L2209 6200007790 S.COI LQW2BHNR15J03L [USA] T 7.0/97.4
6200007790 S.COI LQW2BHNR15J03L [CAN]
6200007790 S.COI LQW2BHNR15J03L [CHN]
6200007790 S.COI LQW2BHNR15J03L [VNM]
L2210 6200004951 S.COI NLV25T-1R8J [USA] T 36.3/96.3
6200004951 S.COI NLV25T-1R8J [CAN]
6200004951 S.COI NLV25T-1R8J [CHN]
6200004951 S.COI NLV25T-1R8J [VNM]
L2211 6180002380 COI LAL 02NA 2R2K [USA]
6180002380 COI LAL 02NA 2R2K [CAN]
6180002380 COI LAL 02NA 2R2K [CHN]
6180002380 COI LAL 02NA 2R2K [VNM]
L2212 6180001730 COI LAL 02NA 1R8K [USA]
6180001730 COI LAL 02NA 1R8K [CAN]
6180001730 COI LAL 02NA 1R8K [CHN]
6180001730 COI LAL 02NA 1R8K [VNM]
L2213 6200005031 S.COI NLV25T-180J [USA] T 39.2/96.0
6200005031 S.COI NLV25T-180J [CAN]
6200005031 S.COI NLV25T-180J [CHN]
6200005031 S.COI NLV25T-180J [VNM]
L2214 6200002001 S.COI NLV25T-3R3J [USA] T 27.5/94.9
6200002001 S.COI NLV25T-3R3J [CAN]
6200002001 S.COI NLV25T-3R3J [CHN]
6200002001 S.COI NLV25T-3R3J [VNM]
L2215 6200002851 S.COI NLV25T-R82J [USA] T 6.4/93.2
6200002851 S.COI NLV25T-R82J [CAN]
6200002851 S.COI NLV25T-R82J [CHN]
6200002851 S.COI NLV25T-R82J [VNM]
L2216 6200003281 S.COI NLV25T-2R2J [USA] T 38.6/93.0
6200003281 S.COI NLV25T-2R2J [CAN]
6200003281 S.COI NLV25T-2R2J [CHN]
6200003281 S.COI NLV25T-2R2J [VNM]
L2217 6200003281 S.COI NLV25T-2R2J [USA] T 27.5/91.9
6200003281 S.COI NLV25T-2R2J [CAN]
6200003281 S.COI NLV25T-2R2J [CHN]
6200003281 S.COI NLV25T-2R2J [VNM]
L2218 6180002300 COI LAL 02NA 1R2K [USA]
6180002300 COI LAL 02NA 1R2K [CAN]
6180002300 COI LAL 02NA 1R2K [CHN]
6180002300 COI LAL 02NA 1R2K [VNM]
L2219 6200005041 S.COI NLV25T-220J [USA] T 36.3/89.9
6200005041 S.COI NLV25T-220J [CAN]
6200005041 S.COI NLV25T-220J [CHN]
6200005041 S.COI NLV25T-220J [VNM]
L2220 6200003711 S.COI NLV25T-2R7J [USA] T 42.3/92.9
6200003711 S.COI NLV25T-2R7J [CAN]
6200003711 S.COI NLV25T-2R7J [CHN]
6200003711 S.COI NLV25T-2R7J [VNM]
L2221 6180001210 COI LAL 03NA 8R2K [USA]
6180001210 COI LAL 03NA 8R2K [CAN]
6180001210 COI LAL 03NA 8R2K [CHN]
6180001210 COI LAL 03NA 8R2K [VNM]
L2222 6200004961 S.COI NLV25T-R33J [USA] T 31.7/92.1
6200004961 S.COI NLV25T-R33J [CAN]
6200004961 S.COI NLV25T-R33J [CHN]
6200004961 S.COI NLV25T-R33J [VNM]
L2223 6200004741 S.COI NLV25T-1R2J [USA] T 4.0/87.2
6200004741 S.COI NLV25T-1R2J [CAN]
6200004741 S.COI NLV25T-1R2J [CHN]
6200004741 S.COI NLV25T-1R2J [VNM]
L2224 6200007780 S.COI LQW2BHNR12J03L [USA] T 10.4/91.6
6200007780 S.COI LQW2BHNR12J03L [CAN]
6200007780 S.COI LQW2BHNR12J03L [CHN]
6200007780 S.COI LQW2BHNR12J03L [VNM]
L2225 6200004741 S.COI NLV25T-1R2J [USA] T 37.2/86.8
6200004741 S.COI NLV25T-1R2J [CAN]
6200004741 S.COI NLV25T-1R2J [CHN]
6200004741 S.COI NLV25T-1R2J [VNM]
L2226 6200001981 S.COI NLV25T-1R0J [USA] T 25.6/85.4
6200001981 S.COI NLV25T-1R0J [CAN]
6200001981 S.COI NLV25T-1R0J [CHN]
6200001981 S.COI NLV25T-1R0J [VNM]
L2227 6200002611 S.COI NLV25T-R47J [USA] T 4.6/83.1
6200002611 S.COI NLV25T-R47J [CAN]
6200002611 S.COI NLV25T-R47J [CHN]
6200002611 S.COI NLV25T-R47J [VNM]
L2228 6200002001 S.COI NLV25T-3R3J [USA] T 42.5/88.7
6200002001 S.COI NLV25T-3R3J [CAN]
6200002001 S.COI NLV25T-3R3J [CHN]
6200002001 S.COI NLV25T-3R3J [VNM]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
L2229 6200002611 S.COI NLV25T-R47J [USA] T 32.4/89.1
6200002611 S.COI NLV25T-R47J [CAN]
6200002611 S.COI NLV25T-R47J [CHN]
6200002611 S.COI NLV25T-R47J [VNM]
L2230 6200007780 S.COI LQW2BHNR12J03L [USA] T 9.9/86.8
6200007780 S.COI LQW2BHNR12J03L [CAN]
6200007780 S.COI LQW2BHNR12J03L [CHN]
6200007780 S.COI LQW2BHNR12J03L [VNM]
L2231 6200002041 S.COI NLV25T-101J [USA] T 43.1/84.8
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2232 6200002041 S.COI NLV25T-101J [USA] T 29.7/83.4
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2233 6200002041 S.COI NLV25T-101J [USA] T 9.1/81.9
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2235 6180000680 COI LAL 02NA 4R7K [USA]
6180000680 COI LAL 02NA 4R7K [CAN]
6180000680 COI LAL 02NA 4R7K [CHN]
6180000680 COI LAL 02NA 4R7K [VNM]
L2236 6200002041 S.COI NLV25T-101J [USA] T 18.0/101.3
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2237 6200007760 S.COI LQW2BHN82NJ03L [USA] T 17.7/97.9
6200007760 S.COI LQW2BHN82NJ03L [CAN]
6200007760 S.COI LQW2BHN82NJ03L [CHN]
6200007760 S.COI LQW2BHN82NJ03L [VNM]
L2238 6180002920 COI LAL 02NA 5R6K [USA]
6180002920 COI LAL 02NA 5R6K [CAN]
6180002920 COI LAL 02NA 5R6K [CHN]
6180002920 COI LAL 02NA 5R6K [VNM]
L2239 6200003661 S.COI NLV25T-R68J [USA] T 17.2/95.0
6200003661 S.COI NLV25T-R68J [CAN]
6200003661 S.COI NLV25T-R68J [CHN]
6200003661 S.COI NLV25T-R68J [VNM]
L2240 6200003941 S.COI NLV25T-5R6J [USA] T 17.1/91.9
6200003941 S.COI NLV25T-5R6J [CAN]
6200003941 S.COI NLV25T-5R6J [CHN]
6200003941 S.COI NLV25T-5R6J [VNM]
L2241 6200001981 S.COI NLV25T-1R0J [USA] T 14.7/88.9
6200001981 S.COI NLV25T-1R0J [CAN]
6200001981 S.COI NLV25T-1R0J [CHN]
6200001981 S.COI NLV25T-1R0J [VNM]
L2242 6200007760 S.COI LQW2BHN82NJ03L [USA] T 20.0/92.0
6200007760 S.COI LQW2BHN82NJ03L [CAN]
6200007760 S.COI LQW2BHN82NJ03L [CHN]
6200007760 S.COI LQW2BHN82NJ03L [VNM]
L2243 6200003271 S.COI NLV25T-R56J [USA] T 16.4/85.8
6200003271 S.COI NLV25T-R56J [CAN]
6200003271 S.COI NLV25T-R56J [CHN]
6200003271 S.COI NLV25T-R56J [VNM]
L2244 6200007760 S.COI LQW2BHN82NJ03L [USA] T 21.4/87.6
6200007760 S.COI LQW2BHN82NJ03L [CAN]
6200007760 S.COI LQW2BHN82NJ03L [CHN]
6200007760 S.COI LQW2BHN82NJ03L [VNM]
L2245 6200002041 S.COI NLV25T-101J [USA] T 19.0/82.6
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2301 6200002041 S.COI NLV25T-101J [USA] T 39.3/80.5
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L2302 6140003660 COI LR-409 [USA]
6140003660 COI LR-409 [CAN]
6140003660 COI LR-409 [CHN]
6140003660 COI LR-409 [VNM]
L2304 6140003660 COI LR-409 [USA]
6140003660 COI LR-409 [CAN]
6140003660 COI LR-409 [CHN]
6140003660 COI LR-409 [VNM]
L2305 6200004940 S.COI MLF1608D R27K-T [USA] T 10.2/76.9
6200004940 S.COI MLF1608D R27K-T [CAN]
6200004940 S.COI MLF1608D R27K-T [CHN]
6200004940 S.COI MLF1608D R27K-T [VNM]
L2306 6150005150 COI LS-543 [USA]
6150005150 COI LS-543 [CAN]
6150005150 COI LS-543 [CHN]
6150005150 COI LS-543 [VNM]
L2307 6150005380 COI LS-552 [USA]
6150005380 COI LS-552 [CAN]
6150005380 COI LS-552 [CHN]
6150005380 COI LS-552 [VNM]
L2401 6200010221 S.COI NLV25T-560J [USA] T 38.2/61.2
6200010221 S.COI NLV25T-560J [CAN]
6200010221 S.COI NLV25T-560J [CHN]
6200010221 S.COI NLV25T-560J [VNM]
L2501 6200010221 S.COI NLV25T-560J [USA] T 44.5/47.2
6200010221 S.COI NLV25T-560J [CAN]
6200010221 S.COI NLV25T-560J [CHN]
6200010221 S.COI NLV25T-560J [VNM]
L2701 6200003520 S.COI ELJFB 102K-F [USA] T 33.9/38.8
6200003520 S.COI ELJFB 102K-F [CAN]
6200003520 S.COI ELJFB 102K-F [CHN]
6200003520 S.COI ELJFB 102K-F [VNM]
L2702 6200003520 S.COI ELJFB 102K-F [USA] T 35.7/35.1
6200003520 S.COI ELJFB 102K-F [CAN]
6200003520 S.COI ELJFB 102K-F [CHN]
6200003520 S.COI ELJFB 102K-F [VNM]

Nov. 2011
4
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
L2703 6200002041 S.COI NLV25T-101J [USA] T 31.9/41.9
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L3301 6200001831 S.COI NLV32T-100J T 128.6/2.8
L3601 6200003950 S.COI HF50ACC 322513-T T 65.5/10.2
L3602 6200003950 S.COI HF50ACC 322513-T T 68.9/12.0
R1 7030003270 S.RES ERJ3GEYJ 390 V (39) T 202.3/108.7
R2 7030003340 S.RES ERJ3GEYJ 151 V (150) T 202.9/110.7
R3 7030003340 S.RES ERJ3GEYJ 151 V (150) T 201.6/110.7
R4 7030003300 S.RES ERJ3GEYJ 680 V (68) T 190.1/108.0
R5 7030003230 S.RES ERJ3GEYJ 180 V (18) T 181.3/108.4
R6 7030003370 S.RES ERJ3GEYJ 271 V (270) T 182.0/110.5
R7 7030003370 S.RES ERJ3GEYJ 271 V (270) T 180.7/110.5
R8 7030003400 S.RES ERJ3GEYJ 471 V (470) T 178.0/110.3
R54 7030003410 S.RES ERJ3GEYJ 561 V (560) T 170.4/106.6
R56 7030003360 S.RES ERJ3GEYJ 221 V (220) T 170.4/105.2
R57 7030003400 S.RES ERJ3GEYJ 471 V (470) T 174.0/108.0
R58 7030003400 S.RES ERJ3GEYJ 471 V (470) T 178.1/106.2
R59 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 156.1/103.8
R60 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 156.8/102.5
R61 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 154.3/106.4
R101 7030003360 S.RES ERJ3GEYJ 221 V (220) T 163.9/89.2
R102 7030003360 S.RES ERJ3GEYJ 221 V (220) T 173.8/85.6
R103 7030003360 S.RES ERJ3GEYJ 221 V (220) T 180.6/85.9
R104 7030003360 S.RES ERJ3GEYJ 221 V (220) T 186.2/86.2
R105 7030003360 S.RES ERJ3GEYJ 221 V (220) T 194.4/87.0
R106 7030003360 S.RES ERJ3GEYJ 221 V (220) T 200.2/86.4
R107 7030003360 S.RES ERJ3GEYJ 221 V (220) T 207.2/87.1
R108 7030003360 S.RES ERJ3GEYJ 221 V (220) T 214.1/86.4
R109 7030003360 S.RES ERJ3GEYJ 221 V (220) T 160.6/90.9
R110 7030003400 S.RES ERJ3GEYJ 471 V (470) T 164.6/84.8
R201 7030003400 S.RES ERJ3GEYJ 471 V (470) T 195.6/82.2
R202 7030003360 S.RES ERJ3GEYJ 221 V (220) T 179.0/74.6
R203 7030003240 S.RES ERJ3GEYJ 220 V (22) T 214.1/32.4
R204 7030003400 S.RES ERJ3GEYJ 471 V (470) T 184.1/64.6
R205 7030003400 S.RES ERJ3GEYJ 471 V (470) T 179.8/64.5
R207 7030003400 S.RES ERJ3GEYJ 471 V (470) T 185.2/61.0
R208 7030003320 S.RES ERJ3GEYJ 101 V (100) T 181.6/41.6
R209 7030003240 S.RES ERJ3GEYJ 220 V (22) T 187.7/35.1
R210 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 188.3/29.5
R211 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 190.5/35.1
R212 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 189.8/29.5
R213 7030003320 S.RES ERJ3GEYJ 101 V (100) T 193.8/35.9
R214 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 194.0/30.9
R215 7030003320 S.RES ERJ3GEYJ 101 V (100) T 197.4/27.3
R301 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 204.9/32.0
R306 7030003280 S.RES ERJ3GEYJ 470 V (47) T 161.5/41.6
R307 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 157.9/43.6
R309 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 208.3/35.1
R401 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 167.6/52.6
R404 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 140.3/80.1
R405 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 139.6/78.7
R406 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 136.6/84.0
R407 7030003320 S.RES ERJ3GEYJ 101 V (100) T 136.0/76.6
R408 7030003400 S.RES ERJ3GEYJ 471 V (470) T 134.2/82.0
R409 7030003320 S.RES ERJ3GEYJ 101 V (100) T 140.0/83.3
R410 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 121.4/79.7
R413 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 104.9/79.1
R414 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 128.9/75.1
R415 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 89.2/85.2
R502 7030003690 S.RES ERJ3GEYJ 124 V (120K) T 89.0/74.4
R503 7030003610 S.RES ERJ3GEYJ 273 V (27K) T 88.9/75.7
R504 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 89.0/77.0
R505 7030003410 S.RES ERJ3GEYJ 561 V (560) T 95.2/72.1
R506 7030003400 S.RES ERJ3GEYJ 471 V (470) T 91.2/71.3
R507 7030003320 S.RES ERJ3GEYJ 101 V (100) T 85.6/75.0
R508 7510001541 S.THE NTCG16 4BH 332JT T 95.2/73.4
R514 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 91.2/65.9
R601 7070000211 RES ERG1SJ 470 (47)
R602 7030003290 S.RES ERJ3GEYJ 560 V (56) T 202.2/62.0
R603 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 197.6/58.6
R604 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 201.9/59.3
R605 7030003200 S.RES ERJ3GEYJ 100 V (10) T 198.2/53.3
R606 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 194.1/52.4
R607 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 191.2/51.1
R701 7030003360 S.RES ERJ3GEYJ 221 V (220) T 202.2/78.6
R702 7030003410 S.RES ERJ3GEYJ 561 V (560) T 202.3/75.2
R703 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 207.0/81.4
R704 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 204.9/80.8
R705 7030003360 S.RES ERJ3GEYJ 221 V (220) T 205.7/75.5
R706 7030003320 S.RES ERJ3GEYJ 101 V (100) T 207.7/78.8
R707 7510001461 S.THE NTCG16 3NH 471JT T 207.7/77.5
R708 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 215.3/55.2
R709 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 210.4/55.2
R710 7030003360 S.RES ERJ3GEYJ 221 V (220) T 211.4/59.3
R711 7030003400 S.RES ERJ3GEYJ 471 V (470) T 210.2/53.0
R712 7030003370 S.RES ERJ3GEYJ 271 V (270) T 210.0/42.4
R713 7030003230 S.RES ERJ3GEYJ 180 V (18) T 194.2/42.0
R714 7030003370 S.RES ERJ3GEYJ 271 V (270) T 192.2/41.2
R715 7030003230 S.RES ERJ3GEYJ 180 V (18) T 210.0/41.1
R716 7030003370 S.RES ERJ3GEYJ 271 V (270) T 207.6/41.6
R717 7030003370 S.RES ERJ3GEYJ 271 V (270) T 192.2/42.8
R718 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 193.2/48.3
R719 7030003320 S.RES ERJ3GEYJ 101 V (100) T 198.7/75.3
R720 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 199.0/43.1
R722 7510001461 S.THE NTCG16 3NH 471JT T 203.6/75.4
R801 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 136.4/71.0
R802 7030003240 S.RES ERJ3GEYJ 220 V (22) T 131.5/75.1
R804 7030003400 S.RES ERJ3GEYJ 471 V (470) T 130.6/68.3
R813 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 131.2/73.2
R901 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 80.3/51.7
R902 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 82.5/56.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
R903 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 85.5/52.1
R904 7030003280 S.RES ERJ3GEYJ 470 V (47) T 82.4/61.8
R910 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 82.8/58.0
R911 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 84.1/67.5
R1002 7030003400 S.RES ERJ3GEYJ 471 V (470) T 74.4/36.3
R1003 7030003400 S.RES ERJ3GEYJ 471 V (470) T 79.5/41.8
R1004 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 75.7/30.6
R1005 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 80.1/30.7
R1006 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 81.0/40.1
R1007 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 82.3/40.1
R1008 7030003320 S.RES ERJ3GEYJ 101 V (100) T 85.8/39.9
R1009 7030003320 S.RES ERJ3GEYJ 101 V (100) T 87.2/45.6
R1010 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 85.5/43.0
R1011 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 91.9/44.8
R1014 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 92.6/46.6
R1015 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 88.5/45.6
R1016 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 91.1/46.6
R1017 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 81.7/34.0
R1018 7030003320 S.RES ERJ3GEYJ 101 V (100) T 72.2/29.4
R1051 7030003320 S.RES ERJ3GEYJ 101 V (100) T 70.8/29.4
R1052 7030003320 S.RES ERJ3GEYJ 101 V (100) T 78.4/21.9
R1053 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 76.1/28.0
R1054 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 79.4/28.8
R1055 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 77.6/24.2
R1057 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 69.4/22.1
R1058 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 70.7/19.4
R1059 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 74.7/18.0
R1060 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 70.7/24.7
R1101 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 57.7/63.4
R1102 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 54.8/56.4
R1103 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 57.7/64.8
R1104 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 55.5/69.3
R1105 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 54.2/58.5
R1106 7030003730 S.RES ERJ3GEYJ 274 V (270K) T 56.8/69.3
R1107 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 52.3/59.2
R1108 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 53.6/68.5
R1109 7030003320 S.RES ERJ3GEYJ 101 V (100) T 51.7/69.3
R1110 7030003320 S.RES ERJ3GEYJ 101 V (100) T 57.7/60.8
R1111 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 57.7/62.1
R1112 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 57.7/66.1
R1113 7030003320 S.RES ERJ3GEYJ 101 V (100) T 50.1/61.6
R1114 7030003320 S.RES ERJ3GEYJ 101 V (100) T 50.1/64.6
R1202 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 110.6/98.2
R1203 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 112.7/92.5
R1205 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 114.8/88.4
R1206 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 115.4/90.2
R1207 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 128.1/96.1
R1208 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 123.6/94.5
R1209 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 123.7/100.2
R1210 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 109.4/96.2
R1211 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 124.5/91.9
R1212 7030003740 S.RES ERJ3GEYJ 334 V (330K) T 123.4/93.2
R1213 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 112.7/95.1
R1214 7030003770 S.RES ERJ3GEYJ 564 V (560K) T 112.7/93.8
R1215 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 123.4/95.8
R1216 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 120.9/98.4
R1217 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 118.4/89.8
R1218 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 115.8/98.4
R1219 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 122.6/91.4
R1220 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 120.9/97.1
R1221 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) T 115.9/97.1
R1222 7030003240 S.RES ERJ3GEYJ 220 V (22) T 123.7/89.5
R1223 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 136.9/89.4
R1224 7030003320 S.RES ERJ3GEYJ 101 V (100) T 118.5/97.7
R1225 7030003320 S.RES ERJ3GEYJ 101 V (100) T 117.1/88.4
R1226 7030003360 S.RES ERJ3GEYJ 221 V (220) T 131.9/95.4
R1228 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 134.8/100.3
R1230 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 136.4/68.4
R1232 7030009930 S.RES ERJ3GEYJ 825 V (8.2M) T 125.3/96.9
R1233 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 112.5/89.9
R1234 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 138.8/100.3
R1235 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 140.7/99.5
R1236 7030003440 S.RES ERJ3GEYJ 102 V (1K) [OTH] T 114.6/102.2
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN-01]
R1237 7030003560 S.RES ERJ3GEYJ 103 V (10K) [OTH] T 117.9/104.0
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CHN-01]
R1238 7030003560 S.RES ERJ3GEYJ 103 V (10K) [OTH] T 115.3/104.0
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CHN-01]
R1240 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 112.6/97.8
R1241 7030003400 S.RES ERJ3GEYJ 471 V (470) T 128.2/98.7
R1301 7030003200 S.RES ERJ3GEYJ 100 V (10) T 94.3/103.4
R1302 7030003200 S.RES ERJ3GEYJ 100 V (10) T 95.6/103.4
R1303 7030003200 S.RES ERJ3GEYJ 100 V (10) T 96.9/103.4
R1304 7030003200 S.RES ERJ3GEYJ 100 V (10) T 98.2/103.4
R1305 7030003200 S.RES ERJ3GEYJ 100 V (10) T 99.5/103.4
R1306 7030003200 S.RES ERJ3GEYJ 100 V (10) T 100.8/103.4
R1307 7030003200 S.RES ERJ3GEYJ 100 V (10) T 102.1/103.4
R1308 7030003200 S.RES ERJ3GEYJ 100 V (10) T 103.4/103.4
R1309 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 91.5/94.2
R1310 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 161.6/81.7
R1311 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 162.9/81.7
R1312 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 164.2/81.7
R1313 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 165.5/81.7
R1314 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 166.8/81.7
R1315 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 168.1/81.7
R1316 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 169.4/81.7
R1317 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 170.7/81.7
R1318 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 174.3/70.1
R1319 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 53.8/76.9
R1320 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 50.8/89.6
R1501 7030008190 S.RES ERJ12YJ330U (33) T 4.1/55.3
R1502 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 89.5/96.1
R1503 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 89.5/97.4
R1504 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 87.4/90.6
R1505 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 88.8/99.5

Nov. 2011
5
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
R1551 7030006220 S.RES ERJ12YJ470U (47) T 75.2/107.0
R1553 7030006220 S.RES ERJ12YJ470U (47) T 55.6/109.4
R1555 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 60.0/108.9
R1556 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 61.3/107.0
R1601 7030003400 S.RES ERJ3GEYJ 471 V (470) T 12.9/12.7
R1602 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 12.3/5.2
R1603 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 14.8/9.2
R1606 7030003400 S.RES ERJ3GEYJ 471 V (470) T 11.1/3.3
R1607 7030003400 S.RES ERJ3GEYJ 471 V (470) T 17.6/8.5
R1609 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 33.8/10.2
R1610 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 31.2/11.3
R1611 7030003320 S.RES ERJ3GEYJ 101 V (100) T 28.4/27.7
R1612 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 37.7/26.3
R1613 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 37.7/27.6
R1614 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 34.4/20.7
R1615 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 34.1/14.6
R1701 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 26.8/30.4
R1702 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 24.6/32.3
R1703 7030003400 S.RES ERJ3GEYJ 471 V (470) T 28.0/33.6
R1704 7030003400 S.RES ERJ3GEYJ 471 V (470) T 25.3/39.5
R1705 7030005691 S.RES ERA3YED 123V (12K) T 29.3/36.1
R1706 7030003580 S.RES ERJ3GEYJ 153 V (15K) T 30.1/34.2
R1707 7030003410 S.RES ERJ3GEYJ 561 V (560) [USA] T 30.1/32.9
7030003410 S.RES ERJ3GEYJ 561 V (560) [CAN]
7030003410 S.RES ERJ3GEYJ 561 V (560) [CHN]
7030003410 S.RES ERJ3GEYJ 561 V (560) [VNM]
R1709 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 48.5/29.9
R1710 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 49.2/25.8
R1711 7030003320 S.RES ERJ3GEYJ 101 V (100) T 42.3/26.2
R1712 7030003320 S.RES ERJ3GEYJ 101 V (100) T 49.2/23.2
R1713 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 42.3/22.3
R1715 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 44.5/20.0
R1716 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 44.5/18.7
R1717 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 46.5/19.3
R1718 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 44.5/17.4
R1719 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 79.3/44.6
R1720 7030003400 S.RES ERJ3GEYJ 471 V (470) T 75.5/48.8
R1721 7030003400 S.RES ERJ3GEYJ 471 V (470) T 75.2/40.1
R1722 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 75.2/41.4
R1723 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 74.5/43.4
R1724 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 31.3/35.7
R1801 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 143.8/14.4
R1802 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 145.1/14.4
R1803 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 146.4/14.7
R1804 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 145.1/17.1
R1901 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 131.2/104.2
R1902 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 130.5/106.0
R1903 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 121.6/110.9
R2001 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 62.4/23.0
R2002 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 62.8/19.8
R2003 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 136.0/13.3
R2101 7030003600 S.RES ERJ3GEYJ 223 V (22K) [USA] T 37.1/105.3
7030003600 S.RES ERJ3GEYJ 223 V (22K) [CAN]
7030003600 S.RES ERJ3GEYJ 223 V (22K) [CHN]
7030003600 S.RES ERJ3GEYJ 223 V (22K) [VNM]
R2102 7030003560 S.RES ERJ3GEYJ 103 V (10K) [USA] T 42.7/105.5
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CAN]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CHN]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [VNM]
R2103 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 43.9/111.6
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2104 7030003620 S.RES ERJ3GEYJ 333 V (33K) [USA] T 45.4/111.6
7030003620 S.RES ERJ3GEYJ 333 V (33K) [CAN]
7030003620 S.RES ERJ3GEYJ 333 V (33K) [CHN]
7030003620 S.RES ERJ3GEYJ 333 V (33K) [VNM]
R2105 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] T 38.4/102.9
7030003400 S.RES ERJ3GEYJ 471 V (470) [CAN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [CHN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [VNM]
R2106 7030003630 S.RES ERJ3GEYJ 393 V (39K) [USA] T 20.0/104.6
7030003630 S.RES ERJ3GEYJ 393 V (39K) [CAN]
7030003630 S.RES ERJ3GEYJ 393 V (39K) [CHN]
7030003630 S.RES ERJ3GEYJ 393 V (39K) [VNM]
R2107 7030003630 S.RES ERJ3GEYJ 393 V (39K) [USA] T 17.4/104.6
7030003630 S.RES ERJ3GEYJ 393 V (39K) [CAN]
7030003630 S.RES ERJ3GEYJ 393 V (39K) [CHN]
7030003630 S.RES ERJ3GEYJ 393 V (39K) [VNM]
R2201 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 50.7/83.0
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2202 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 50.7/81.7
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2203 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 50.7/84.3
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2204 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 50.7/85.6
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2205 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [USA] T 42.9/81.0
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CAN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CHN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [VNM]
R2206 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [USA] T 48.0/81.2
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CAN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CHN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [VNM]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
R2207 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [USA] T 46.9/86.2
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CAN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CHN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [VNM]
R2208 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [USA] T 46.9/84.8
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CAN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [CHN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [VNM]
R2301 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 39.5/82.5
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R2302 7030003240 S.RES ERJ3GEYJ 220 V (22) [USA] T 43.4/69.9
7030003240 S.RES ERJ3GEYJ 220 V (22) [CAN]
7030003240 S.RES ERJ3GEYJ 220 V (22) [CHN]
7030003240 S.RES ERJ3GEYJ 220 V (22) [VNM]
R2303 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) [USA] T 32.5/78.0
7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) [CAN]
7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) [CHN]
7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) [VNM]
R2306 7030003280 S.RES ERJ3GEYJ 470 V (47) [USA] T 11.0/75.1
7030003280 S.RES ERJ3GEYJ 470 V (47) [CAN]
7030003280 S.RES ERJ3GEYJ 470 V (47) [CHN]
7030003280 S.RES ERJ3GEYJ 470 V (47) [VNM]
R2401 7030003660 S.RES ERJ3GEYJ 683 V (68K) [USA] T 32.0/60.5
7030003660 S.RES ERJ3GEYJ 683 V (68K) [CAN]
7030003660 S.RES ERJ3GEYJ 683 V (68K) [CHN]
7030003660 S.RES ERJ3GEYJ 683 V (68K) [VNM]
R2402 7030003580 S.RES ERJ3GEYJ 153 V (15K) [USA] T 33.3/60.5
7030003580 S.RES ERJ3GEYJ 153 V (15K) [CAN]
7030003580 S.RES ERJ3GEYJ 153 V (15K) [CHN]
7030003580 S.RES ERJ3GEYJ 153 V (15K) [VNM]
R2403 7030003800 S.RES ERJ3GEYJ 105 V (1M) [USA] T 34.8/54.9
7030003800 S.RES ERJ3GEYJ 105 V (1M) [CAN]
7030003800 S.RES ERJ3GEYJ 105 V (1M) [CHN]
7030003800 S.RES ERJ3GEYJ 105 V (1M) [VNM]
R2404 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 35.4/61.2
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2405 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 41.4/62.7
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2406 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [USA] T 37.9/57.1
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [CAN]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [CHN]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [VNM]
R2501 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [USA] T 47.8/52.8
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [CAN]
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [CHN]
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [VNM]
R2502 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [USA] T 47.9/51.5
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [CAN]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [CHN]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [VNM]
R2503 7030003760 S.RES ERJ3GEYJ 474 V (470K) [USA] T 39.2/54.7
7030003760 S.RES ERJ3GEYJ 474 V (470K) [CAN]
7030003760 S.RES ERJ3GEYJ 474 V (470K) [CHN]
7030003760 S.RES ERJ3GEYJ 474 V (470K) [VNM]
R2504 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 48.5/49.4
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2505 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 47.4/42.9
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2506 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] T 45.2/43.6
7030003400 S.RES ERJ3GEYJ 471 V (470) [CAN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [CHN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [VNM]
R2701 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 35.0/41.4
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R2702 7030003650 S.RES ERJ3GEYJ 563 V (56K) [USA] T 51.9/35.9
7030003650 S.RES ERJ3GEYJ 563 V (56K) [CAN]
7030003650 S.RES ERJ3GEYJ 563 V (56K) [CHN]
7030003650 S.RES ERJ3GEYJ 563 V (56K) [VNM]
R2703 7030003560 S.RES ERJ3GEYJ 103 V (10K) [USA] T 51.9/34.6
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CAN]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CHN]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [VNM]
R2704 7030003650 S.RES ERJ3GEYJ 563 V (56K) [USA] T 51.9/37.2
7030003650 S.RES ERJ3GEYJ 563 V (56K) [CAN]
7030003650 S.RES ERJ3GEYJ 563 V (56K) [CHN]
7030003650 S.RES ERJ3GEYJ 563 V (56K) [VNM]
R2705 7030003650 S.RES ERJ3GEYJ 563 V (56K) [USA] T 51.9/38.5
7030003650 S.RES ERJ3GEYJ 563 V (56K) [CAN]
7030003650 S.RES ERJ3GEYJ 563 V (56K) [CHN]
7030003650 S.RES ERJ3GEYJ 563 V (56K) [VNM]
R2706 7030003370 S.RES ERJ3GEYJ 271 V (270) [USA] T 47.5/34.8
7030003370 S.RES ERJ3GEYJ 271 V (270) [CAN]
7030003370 S.RES ERJ3GEYJ 271 V (270) [CHN]
7030003370 S.RES ERJ3GEYJ 271 V (270) [VNM]
R2708 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 53.6/40.0
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R2709 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 56.5/41.3
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]

Nov. 2011
6
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
R2710 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 54.3/28.4
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R2711 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 56.5/40.0
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R2712 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 61.2/34.2
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R2713 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 64.2/39.0
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R2714 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 61.2/40.3
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R2715 7030003230 S.RES ERJ3GEYJ 180 V (18) [USA] T 45.6/34.1
7030003230 S.RES ERJ3GEYJ 180 V (18) [CAN]
7030003230 S.RES ERJ3GEYJ 180 V (18) [CHN]
7030003230 S.RES ERJ3GEYJ 180 V (18) [VNM]
R2716 7030003370 S.RES ERJ3GEYJ 271 V (270) [USA] T 43.7/34.8
7030003370 S.RES ERJ3GEYJ 271 V (270) [CAN]
7030003370 S.RES ERJ3GEYJ 271 V (270) [CHN]
7030003370 S.RES ERJ3GEYJ 271 V (270) [VNM]
R3001 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 117.4/65.0
R3002 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 113.5/65.0
R3003 7030003360 S.RES ERJ3GEYJ 221 V (220) T 108.4/60.9
R3004 7030003360 S.RES ERJ3GEYJ 221 V (220) T 110.1/60.9
R3006 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 123.4/22.1
R3007 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 111.8/60.9
R3008 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 113.9/61.0
R3009 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 115.2/60.9
R3010 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 109.6/81.9
R3011 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 118.7/61.0
R3012 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 97.7/53.7
R3013 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 104.5/65.0
R3014 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 97.7/52.4
R3015 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 105.8/65.0
R3017 7030003360 S.RES ERJ3GEYJ 221 V (220) T 97.7/45.6
R3018 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 124.4/24.7
R3019 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 122.5/59.9
R3020 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 122.6/64.5
R3023 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 49.9/13.1
R3024 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 51.7/12.9
R3025 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 39.9/12.6
R3026 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 43.7/15.0
R3027 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 145.6/20.6
R3028 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 144.2/22.5
R3029 7030003580 S.RES ERJ3GEYJ 153 V (15K) T 137.6/24.6
R3030 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 134.7/22.1
R3035 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 149.2/23.1
R3036 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 110.9/65.0
R3050 7030005691 S.RES ERA3YED 123V (12K) T 115.5/67.2
R3051 7030009591 S.RES ERA3YED 472V (4.7K) T 108.8/67.8
R3052 7030005871 S.RES ERA3YKD 104V (100K) T 110.7/67.7
R3101 7030008190 S.RES ERJ12YJ330U (33) T 138.4/10.2
R3201 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 80.9/22.9
R3202 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 91.6/20.1
R3203 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 89.0/20.1
R3204 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 93.2/21.9
R3301 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 118.8/55.1
R3302 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 119.8/56.4
R3303 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 101.7/46.2
R3304 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 101.7/43.5
R3305 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 107.2/46.1
R3306 7030003610 S.RES ERJ3GEYJ 273 V (27K) T 121.3/62.2
R3307 7030003360 S.RES ERJ3GEYJ 221 V (220) T 124.2/27.1
R3308 7030003360 S.RES ERJ3GEYJ 221 V (220) T 97.7/57.6
R3309 7030003360 S.RES ERJ3GEYJ 221 V (220) T 97.7/51.1
R3310 7030003360 S.RES ERJ3GEYJ 221 V (220) T 97.7/49.8
R3311 7030003360 S.RES ERJ3GEYJ 221 V (220) T 97.7/48.5
R3312 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 97.7/47.2
R3313 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 121.5/27.1
R3314 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 119.4/22.8
R3315 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 106.0/13.1
R3316 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 136.9/61.0
R3317 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 138.2/61.0
R3318 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 139.5/61.0
R3319 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 141.6/59.4
R3320 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 135.6/61.0
R3321 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 134.3/61.0
R3322 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 133.0/61.0
R3323 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 131.7/61.0
R3324 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 130.4/61.0
R3325 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 129.1/61.0
R3326 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 127.8/61.0
R3327 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 126.5/61.0
R3328 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 125.2/61.0
R3329 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 123.9/61.0
R3330 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 136.7/29.3
R3331 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 135.1/28.6
R3332 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 110.9/23.8
R3333 7030003360 S.RES ERJ3GEYJ 221 V (220) T 109.5/25.5
R3334 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 114.9/24.3
R3335 7030003360 S.RES ERJ3GEYJ 221 V (220) T 113.0/25.6
R3336 7030003360 S.RES ERJ3GEYJ 221 V (220) T 115.8/27.1
R3337 7030003360 S.RES ERJ3GEYJ 221 V (220) T 117.1/27.1
R3338 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/53.2
R3339 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/51.9
R3340 7030003360 S.RES ERJ3GEYJ 221 V (220) T 122.9/27.1
R3350 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 120.0/65.0
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
R3402 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 138.2/64.5
R3403 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 139.5/64.5
R3404 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 140.8/62.8
R3405 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 135.6/64.5
R3406 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 134.3/64.5
R3408 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 131.7/64.5
R3412 7030003560 S.RES ERJ3GEYJ 103 V (10K) [USA] T 126.5/64.5
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CAN]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CHN]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [VNM]
R3601 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 73.0/9.4
R3602 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 79.1/1.7
R3603 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 77.8/1.7
R3604 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 76.5/1.7
R3605 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 75.2/1.7
R3606 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 73.9/1.7
R3608 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 86.2/35.1
R3609 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 87.3/31.8
R3610 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 86.0/31.8
R3611 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 84.7/31.8
R3612 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 83.4/31.8
R3613 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 142.5/35.0
R3614 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/49.3
R3615 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/46.7
R3616 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/54.5
R3617 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/48.0
R3618 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/28.5
R3619 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/38.9
R3620 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/42.8
R3621 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/41.5
R3622 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/40.2
R3623 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/32.4
R3624 7030003360 S.RES ERJ3GEYJ 221 V (220) T 142.5/31.1
R3625 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 142.5/50.6
R3626 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 142.5/44.1
R3627 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 142.5/45.4
R3628 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 142.5/37.6
R3629 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 142.5/36.3
R3630 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 142.5/29.8
R3903 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 118.4/26.9
R3906 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 108.9/11.1
R3907 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 130.4/27.6
R3908 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 128.1/23.5
R3909 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 128.1/24.8
R3915 7030003360 S.RES ERJ3GEYJ 221 V (220) T 111.7/2.9
R3916 7030003360 S.RES ERJ3GEYJ 221 V (220) T 112.1/11.2
R3917 7030003360 S.RES ERJ3GEYJ 221 V (220) T 113.0/2.9
R3918 7030003360 S.RES ERJ3GEYJ 221 V (220) T 113.6/10.8
R3919 7030003360 S.RES ERJ3GEYJ 221 V (220) T 114.3/2.9
R3920 7030003360 S.RES ERJ3GEYJ 221 V (220) T 116.5/9.5
R3921 7030003360 S.RES ERJ3GEYJ 221 V (220) T 107.4/30.7
W501 7030003860 S.RES ERJ3GE JPW V T 85.6/80.4
W803 7030003860 S.RES ERJ3GE JPW V T 133.8/73.2
W1011 7030003860 S.RES ERJ3GE JPW V T 94.0/44.0
W1101 7030003860 S.RES ERJ3GE JPW V T 153.6/30.2
W1102 7030003860 S.RES ERJ3GE JPW V T 153.6/31.5
W1227 7030003860 S.RES ERJ3GE JPW V T 133.8/94.9
W1231 7030003860 S.RES ERJ3GE JPW V T 115.8/99.7
W1601 7030003860 S.RES ERJ3GE JPW V T 32.7/8.1
W1701 7030003860 S.RES ERJ3GE JPW V [USA] T 30.1/31.6
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]
W2001 7030003860 S.RES ERJ3GE JPW V [USA] T 61.0/21.1
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]
W2002 7030003860 S.RES ERJ3GE JPW V T 182.0/65.3
C1 4030007110 S.CER C1608 CH 1H 680J-T T 200.3/110.6
C2 4030007120 S.CER C1608 CH 1H 820J-T T 198.1/108.8
C3 4030007150 S.CER C1608 CH 1H 151J-T T 195.6/110.7
C4 4030007050 S.CER C1608 CH 1H 220J-T T 193.6/111.4
C5 4030007120 S.CER C1608 CH 1H 820J-T T 190.9/110.6
C6 4030011600 S.CER C1608 JB 1E 104K-T T 186.8/107.9
C7 4030011600 S.CER C1608 JB 1E 104K-T T 189.5/110.5
C8 4030011600 S.CER C1608 JB 1E 104K-T T 186.8/106.5
C9 4030011600 S.CER C1608 JB 1E 104K-T T 184.1/107.6
C10 4030011600 S.CER C1608 JB 1E 104K-T T 179.4/110.3
C11 4030011600 S.CER C1608 JB 1E 104K-T T 176.5/110.3
C54 4030011600 S.CER C1608 JB 1E 104K-T T 161.7/106.8
C56 4030006870 S.CER C1608 JB 1H 222K-T T 164.5/106.8
C57 4030006900 S.CER C1608 JB 1H 103K-T T 165.1/108.7
C59 4030010020 S.CER C1608 JB 1H 122K-T T 167.1/106.7
C61 4030008860 S.CER C1608 JB 1H 153K-T T 166.6/108.7
C62 4030006870 S.CER C1608 JB 1H 222K-T T 170.4/108.0
C63 4030008860 S.CER C1608 JB 1H 153K-T T 168.1/108.7
C64 4030011600 S.CER C1608 JB 1E 104K-T T 159.1/103.1
C65 4030011600 S.CER C1608 JB 1E 104K-T T 176.1/107.1
C66 4030011600 S.CER C1608 JB 1E 104K-T T 158.1/105.7
C67 4030011600 S.CER C1608 JB 1E 104K-T T 156.8/105.7
C68 4030011600 S.CER C1608 JB 1E 104K-T T 154.0/102.6
C101 4030011600 S.CER C1608 JB 1E 104K-T T 164.7/101.1
C102 4030011600 S.CER C1608 JB 1E 104K-T T 171.1/101.1
C103 4030011600 S.CER C1608 JB 1E 104K-T T 178.0/101.1
C104 4030011600 S.CER C1608 JB 1E 104K-T T 185.0/101.1
C105 4030011600 S.CER C1608 JB 1E 104K-T T 191.8/101.2
C106 4030011600 S.CER C1608 JB 1E 104K-T T 198.5/101.3
C107 4030011600 S.CER C1608 JB 1E 104K-T T 205.5/101.3
C108 4030011600 S.CER C1608 JB 1E 104K-T T 212.6/101.3
C109 4030006870 S.CER C1608 JB 1H 222K-T T 158.5/95.6
C110 4030009980 S.CER C1608 JB 1H 152K-T T 165.8/98.1

Nov. 2011
7
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C111 4030010040 S.CER C1608 JB 1H 561K-T T 172.3/96.8
C112 4030010040 S.CER C1608 JB 1H 561K-T T 179.5/98.1
C113 4030006850 S.CER C1608 JB 1H 471K-T T 186.1/98.1
C114 4030011330 S.CER C1608 CH 1H 391J-T T 193.0/98.1
C115 4030007170 S.CER C1608 CH 1H 221J-T T 199.7/98.1
C116 4030010750 S.CER C1608 CH 1H 201J-T T 206.7/98.1
C117 4030007150 S.CER C1608 CH 1H 151J-T T 213.7/98.1
C118 4030011280 S.CER C1608 CH 1H 271J-T T 172.3/98.1
C119 4030011280 S.CER C1608 CH 1H 271J-T T 159.3/93.7
C120 4030010750 S.CER C1608 CH 1H 201J-T T 165.8/96.8
C121 4030007130 S.CER C1608 CH 1H 101J-T T 179.5/96.8
C122 4030007100 S.CER C1608 CH 1H 560J-T T 186.1/96.8
C123 4030007080 S.CER C1608 CH 1H 390J-T T 193.0/96.8
C124 4030007090 S.CER C1608 CH 1H 470J-T T 199.7/96.8
C125 4030007050 S.CER C1608 CH 1H 220J-T T 206.7/96.8
C126 4030007040 S.CER C1608 CH 1H 180J-T T 213.7/96.8
C127 4030008920 S.CER C1608 JB 1H 473K-T T 162.0/90.9
C128 4030009970 S.CER C1608 JB 1H 182K-T T 158.5/91.7
C129 4030008470 S.CER C1608 JB 1H 272K-T T 168.4/92.3
C130 4030009980 S.CER C1608 JB 1H 152K-T T 164.7/95.5
C131 4030009980 S.CER C1608 JB 1H 152K-T T 171.9/93.4
C132 4030007140 S.CER C1608 CH 1H 121J-T T 174.2/92.8
C133 4030010040 S.CER C1608 JB 1H 561K-T T 171.2/95.4
C134 4030006850 S.CER C1608 JB 1H 471K-T T 178.4/95.4
C135 4030010760 S.CER C1608 CH 1H 331J-T T 185.0/95.4
C136 4030011280 S.CER C1608 CH 1H 271J-T T 192.7/93.5
C137 4030011830 S.CER C1608 CH 1H 301J-T T 192.0/95.4
C138 4030011280 S.CER C1608 CH 1H 271J-T T 199.2/93.5
C139 4030007170 S.CER C1608 CH 1H 221J-T T 198.5/95.4
C140 4030007160 S.CER C1608 CH 1H 181J-T T 206.3/93.6
C141 4030007160 S.CER C1608 CH 1H 181J-T T 205.5/95.5
C142 4030007150 S.CER C1608 CH 1H 151J-T T 213.3/93.5
C143 4030007130 S.CER C1608 CH 1H 101J-T T 212.5/95.4
C144 4030007140 S.CER C1608 CH 1H 121J-T T 181.4/92.9
C145 4030010040 S.CER C1608 JB 1H 561K-T T 179.1/93.5
C146 4030006850 S.CER C1608 JB 1H 471K-T T 185.7/93.3
C147 4030008850 S.CER C1608 JB 1H 123K-T T 164.6/94.1
C148 4030006880 S.CER C1608 JB 1H 472K-T T 171.2/91.0
C149 4030009970 S.CER C1608 JB 1H 182K-T T 178.5/90.9
C150 4030006870 S.CER C1608 JB 1H 222K-T T 186.2/91.3
C151 4030006870 S.CER C1608 JB 1H 222K-T T 192.8/91.6
C152 4030009980 S.CER C1608 JB 1H 152K-T T 199.6/91.6
C153 4030009980 S.CER C1608 JB 1H 152K-T T 206.7/91.7
C154 4030006860 S.CER C1608 JB 1H 102K-T T 213.7/91.6
C155 4030009980 S.CER C1608 JB 1H 152K-T T 168.4/89.7
C156 4030011600 S.CER C1608 JB 1E 104K-T T 164.6/91.9
C157 4030006870 S.CER C1608 JB 1H 222K-T T 171.2/89.7
C158 4030009980 S.CER C1608 JB 1H 152K-T T 178.2/89.0
C159 4030006880 S.CER C1608 JB 1H 472K-T T 186.2/90.0
C160 4030007170 S.CER C1608 CH 1H 221J-T T 196.6/88.8
C161 4030011600 S.CER C1608 JB 1E 104K-T T 192.0/88.9
C162 4030007160 S.CER C1608 CH 1H 181J-T T 202.8/88.3
C163 4030011600 S.CER C1608 JB 1E 104K-T T 199.6/90.2
C164 4030007150 S.CER C1608 CH 1H 151J-T T 210.5/89.1
C165 4030011600 S.CER C1608 JB 1E 104K-T T 206.0/89.9
C166 4030007130 S.CER C1608 CH 1H 101J-T T 216.8/88.6
C167 4030011600 S.CER C1608 JB 1E 104K-T T 213.7/90.2
C168 4030011600 S.CER C1608 JB 1E 104K-T T 157.3/100.1
C169 4030006860 S.CER C1608 JB 1H 102K-T T 175.6/90.5
C170 4030011600 S.CER C1608 JB 1E 104K-T T 171.2/87.9
C171 4030006850 S.CER C1608 JB 1H 471K-T T 182.5/90.9
C172 4030011600 S.CER C1608 JB 1E 104K-T T 178.2/87.7
C173 4030010760 S.CER C1608 CH 1H 331J-T T 189.1/88.4
C174 4030011600 S.CER C1608 JB 1E 104K-T T 184.3/88.2
C175 4030007040 S.CER C1608 CH 1H 180J-T T 199.7/99.5
C201 4030011600 S.CER C1608 JB 1E 104K-T T 190.3/82.8
C202 4030007120 S.CER C1608 CH 1H 820J-T T 192.3/77.5
C203 4030007050 S.CER C1608 CH 1H 220J-T T 189.7/78.3
C204 4030007150 S.CER C1608 CH 1H 151J-T T 189.1/76.3
C205 4030006990 S.CER C1608 CH 1H 080D-T T 182.4/78.9
C206 4030007130 S.CER C1608 CH 1H 101J-T T 186.8/78.2
C207 4030011600 S.CER C1608 JB 1E 104K-T T 182.0/74.6
C208 4030006880 S.CER C1608 JB 1H 472K-T T 216.0/37.1
C209 4030011600 S.CER C1608 JB 1E 104K-T T 185.5/64.6
C210 4030011600 S.CER C1608 JB 1E 104K-T T 178.4/64.5
C211 4030006880 S.CER C1608 JB 1H 472K-T T 216.1/29.2
C212 4030011600 S.CER C1608 JB 1E 104K-T T 186.1/50.1
C213 4030007000 S.CER C1608 CH 1H 090D-T T 180.0/53.2
C214 4030006860 S.CER C1608 JB 1H 102K-T T 191.1/55.3
C215 4030007020 S.CER C1608 CH 1H 120J-T T 170.3/42.3
C217 4030006960 S.CER C1608 CH 1H 050C-T T 188.6/32.9
C218 4030006880 S.CER C1608 JB 1H 472K-T T 184.4/27.1
C219 4030006880 S.CER C1608 JB 1H 472K-T T 192.7/29.4
C220 4030006880 S.CER C1608 JB 1H 472K-T T 191.2/29.5
C221 4030006880 S.CER C1608 JB 1H 472K-T T 192.4/35.9
C223 4030006880 S.CER C1608 JB 1H 472K-T T 202.5/27.3
C224 4030006880 S.CER C1608 JB 1H 472K-T T 186.3/25.8
C301 4030006880 S.CER C1608 JB 1H 472K-T T 206.1/28.8
C302 4030006970 S.CER C1608 CH 1H 060D-T T 211.3/21.9
C303 4030006960 S.CER C1608 CH 1H 050C-T T 200.0/21.2
C305 4030006850 S.CER C1608 JB 1H 471K-T T 160.0/32.7
C307 4030011280 S.CER C1608 CH 1H 271J-T T 158.7/41.6
C308 4030009580 S.CER C1608 JB 1H 681K-T T 161.5/42.9
C309 4030011600 S.CER C1608 JB 1E 104K-T T 159.3/43.6
C310 4030006880 S.CER C1608 JB 1H 472K-T T 163.7/46.4
C311 4030010770 S.CER C1608 JB 1H 392K-T T 158.5/49.2
C312 4030011600 S.CER C1608 JB 1E 104K-T T 209.2/37.2
C314 4030006860 S.CER C1608 JB 1H 102K-T T 164.8/32.6
C401 4030011600 S.CER C1608 JB 1E 104K-T T 164.6/53.5
C402 4030006880 S.CER C1608 JB 1H 472K-T T 141.1/76.7
C403 4030011600 S.CER C1608 JB 1E 104K-T T 140.3/81.4
C404 4030011600 S.CER C1608 JB 1E 104K-T T 138.7/83.2
C405 4030006880 S.CER C1608 JB 1H 472K-T T 136.3/82.7
C406 4030011600 S.CER C1608 JB 1E 104K-T T 136.0/77.9
C407 4030006880 S.CER C1608 JB 1H 472K-T T 119.0/68.7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C408 4030011600 S.CER C1608 JB 1E 104K-T T 133.7/84.0
C409 4030011600 S.CER C1608 JB 1E 104K-T T 121.4/78.4
C410 4030011600 S.CER C1608 JB 1E 104K-T T 104.9/77.8
C411 4030011600 S.CER C1608 JB 1E 104K-T T 132.9/79.3
C412 4030006880 S.CER C1608 JB 1H 472K-T T 109.7/77.6
C413 4030007140 S.CER C1608 CH 1H 121J-T T 116.4/68.7
C414 4030007160 S.CER C1608 CH 1H 181J-T T 107.9/78.2
C501 4030011600 S.CER C1608 JB 1E 104K-T T 84.2/77.7
C502 4030006880 S.CER C1608 JB 1H 472K-T T 93.1/77.7
C503 4030011600 S.CER C1608 JB 1E 104K-T T 85.6/77.7
C504 4030006880 S.CER C1608 JB 1H 472K-T T 86.9/76.8
C505 4030006880 S.CER C1608 JB 1H 472K-T T 89.0/78.3
C506 4030011600 S.CER C1608 JB 1E 104K-T T 95.2/74.7
C507 4030011600 S.CER C1608 JB 1E 104K-T T 84.0/72.6
C508 4030011600 S.CER C1608 JB 1E 104K-T T 92.8/71.3
C509 4030011600 S.CER C1608 JB 1E 104K-T T 91.0/48.5
C510 4510008520 S.ELE EEE1CA470SP T 79.7/74.9
C511 4030011600 S.CER C1608 JB 1E 104K-T T 91.0/49.8
C512 4510008520 S.ELE EEE1CA470SP T 68.0/65.9
C516 4030011600 S.CER C1608 JB 1E 104K-T T 91.2/68.1
C517 4030011600 S.CER C1608 JB 1E 104K-T T 94.2/63.1
C518 4030011600 S.CER C1608 JB 1E 104K-T T 94.2/58.4
C519 4030011600 S.CER C1608 JB 1E 104K-T T 91.0/58.4
C520 4510008540 S.ELE EEE1CA100SR T 90.7/55.3
C521 4030011600 S.CER C1608 JB 1E 104K-T T 88.1/59.1
C601 4030006880 S.CER C1608 JB 1H 472K-T T 198.8/63.1
C602 4030006880 S.CER C1608 JB 1H 472K-T T 199.8/59.3
C603 4030006880 S.CER C1608 JB 1H 472K-T T 193.7/56.7
C604 4030006860 S.CER C1608 JB 1H 102K-T T 202.6/52.2
C605 4030010760 S.CER C1608 CH 1H 331J-T T 196.9/53.3
C606 4030007010 S.CER C1608 CH 1H 100D-T T 200.0/51.4
C607 4030009510 S.CER C1608 CH 1H 010B-T T 201.9/50.3
C608 4030007010 S.CER C1608 CH 1H 100D-T T 197.8/50.2
C609 4030006970 S.CER C1608 CH 1H 060D-T T 195.9/49.7
C610 4030009510 S.CER C1608 CH 1H 010B-T T 195.7/51.0
C611 4030011600 S.CER C1608 JB 1E 104K-T T 191.2/47.3
C612 4030007060 S.CER C1608 CH 1H 270J-T T 203.8/58.1
C701 4030011600 S.CER C1608 JB 1E 104K-T T 199.7/73.4
C702 4030011600 S.CER C1608 JB 1E 104K-T T 204.9/82.1
C703 4030011600 S.CER C1608 JB 1E 104K-T T 201.0/74.7
C705 4030011600 S.CER C1608 JB 1E 104K-T T 215.2/75.5
C706 4030007070 S.CER C1608 CH 1H 330J-T T 208.6/75.5
C707 4030006970 S.CER C1608 CH 1H 060D-T T 210.4/77.5
C709 4030007080 S.CER C1608 CH 1H 390J-T T 211.2/75.5
C710 4030007040 S.CER C1608 CH 1H 180J-T T 215.5/78.6
C711 4030007050 S.CER C1608 CH 1H 220J-T T 213.3/75.5
C712 4030011600 S.CER C1608 JB 1E 104K-T T 206.5/59.0
C714 4030011600 S.CER C1608 JB 1E 104K-T T 199.6/45.6
C715 4030006960 S.CER C1608 CH 1H 050C-T T 210.2/51.7
C716 4030006860 S.CER C1608 JB 1H 102K-T T 198.3/45.1
C717 4030006860 S.CER C1608 JB 1H 102K-T T 207.6/37.2
C718 4030006860 S.CER C1608 JB 1H 102K-T T 194.2/44.6
C720 4030007080 S.CER C1608 CH 1H 390J-T T 209.6/33.8
C801 4030011600 S.CER C1608 JB 1E 104K-T T 136.4/73.6
C802 4030011600 S.CER C1608 JB 1E 104K-T T 138.3/76.8
C804 4030006880 S.CER C1608 JB 1H 472K-T T 132.7/68.4
C805 4030006880 S.CER C1608 JB 1H 472K-T T 130.6/71.0
C806 4510008520 S.ELE EEE1CA470SP T 154.7/78.0
C901 4030011600 S.CER C1608 JB 1E 104K-T T 80.5/55.3
C902 4030011600 S.CER C1608 JB 1E 104K-T T 85.5/53.4
C903 4030006880 S.CER C1608 JB 1H 472K-T T 79.7/57.9
C904 4030011600 S.CER C1608 JB 1E 104K-T T 85.4/58.0
C905 4030011600 S.CER C1608 JB 1E 104K-T T 75.8/61.0
C906 4030011600 S.CER C1608 JB 1E 104K-T T 77.9/56.2
C907 4030011600 S.CER C1608 JB 1E 104K-T T 77.1/57.9
C908 4510008540 S.ELE EEE1CA100SR T 78.3/66.2
C909 4030011600 S.CER C1608 JB 1E 104K-T T 74.5/61.0
C910 4030011600 S.CER C1608 JB 1E 104K-T T 82.6/65.7
C1001 4030011600 S.CER C1608 JB 1E 104K-T T 74.4/32.2
C1002 4030011600 S.CER C1608 JB 1E 104K-T T 76.2/36.3
C1003 4030011600 S.CER C1608 JB 1E 104K-T T 81.7/35.3
C1004 4030009970 S.CER C1608 JB 1H 182K-T T 79.0/37.6
C1005 4030010040 S.CER C1608 JB 1H 561K-T T 79.0/36.3
C1006 4030006880 S.CER C1608 JB 1H 472K-T T 81.7/37.9
C1007 4030006880 S.CER C1608 JB 1H 472K-T T 81.7/36.6
C1008 4030006880 S.CER C1608 JB 1H 472K-T T 87.0/41.8
C1010 4510008540 S.ELE EEE1CA100SR T 92.3/34.1
C1011 4510008540 S.ELE EEE1CA100SR T 83.5/47.6
C1012 4030011600 S.CER C1608 JB 1E 104K-T T 89.8/46.6
C1051 4510008540 S.ELE EEE1CA100SR T 66.6/28.1
C1052 4510008540 S.ELE EEE1CA100SR T 79.7/18.8
C1054 4030006900 S.CER C1608 JB 1H 103K-T T 78.7/26.9
C1055 4030006860 S.CER C1608 JB 1H 102K-T T 77.4/27.0
C1056 4030008880 S.CER C1608 JB 1H 223K-T T 74.8/28.0
C1057 4030008880 S.CER C1608 JB 1H 223K-T T 73.5/28.0
C1058 4030008880 S.CER C1608 JB 1H 223K-T T 80.3/26.1
C1059 4030006900 S.CER C1608 JB 1H 103K-T T 78.9/23.9
C1061 4030006860 S.CER C1608 JB 1H 102K-T T 76.0/18.0
C1062 4030008880 S.CER C1608 JB 1H 223K-T T 72.1/18.0
C1063 4030008880 S.CER C1608 JB 1H 223K-T T 73.4/18.0
C1064 4030008880 S.CER C1608 JB 1H 223K-T T 70.7/22.1
C1101 4030011600 S.CER C1608 JB 1E 104K-T T 50.3/69.3
C1102 4030011600 S.CER C1608 JB 1E 104K-T T 56.9/58.5
C1201 4030006880 S.CER C1608 JB 1H 472K-T T 128.5/91.7
C1202 4030011600 S.CER C1608 JB 1E 104K-T T 119.3/99.7
C1203 4030011600 S.CER C1608 JB 1E 104K-T T 114.7/87.1
C1204 4030008680 S.CER C2012 JF 1C 105Z-T T 123.3/88.0
C1205 4510008540 S.ELE EEE1CA100SR T 132.4/89.1
C1206 4030006860 S.CER C1608 JB 1H 102K-T T 133.7/92.9
C1208 4030008680 S.CER C2012 JF 1C 105Z-T T 133.3/98.4
C1209 4030011600 S.CER C1608 JB 1E 104K-T T 140.7/100.8
C1210 4030008680 S.CER C2012 JF 1C 105Z-T T 129.8/98.4
C1211 4030008680 S.CER C2012 JF 1C 105Z-T T 131.5/98.4
C1212 4030008680 S.CER C2012 JF 1C 105Z-T T 136.0/93.2
C1213 4030008680 S.CER C2012 JF 1C 105Z-T T 136.4/91.5

Nov. 2011
8
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C1214 4030011600 S.CER C1608 JB 1E 104K-T T 119.7/88.4
C1223 4030011600 S.CER C1608 JB 1E 104K-T [OTH] T 112.6/100.1
4030011600 S.CER C1608 JB 1E 104K-T [CHN-01]
C1224 4030011600 S.CER C1608 JB 1E 104K-T [OTH] T 112.6/101.4
4030011600 S.CER C1608 JB 1E 104K-T [CHN-01]
C1301 4030011600 S.CER C1608 JB 1E 104K-T T 94.6/111.8
C1302 4030011600 S.CER C1608 JB 1E 104K-T T 95.9/111.8
C1303 4030011600 S.CER C1608 JB 1E 104K-T T 97.2/111.8
C1304 4030011600 S.CER C1608 JB 1E 104K-T T 98.5/111.8
C1305 4030011600 S.CER C1608 JB 1E 104K-T T 99.8/111.8
C1306 4030011600 S.CER C1608 JB 1E 104K-T T 101.1/111.8
C1307 4030011600 S.CER C1608 JB 1E 104K-T T 102.4/111.8
C1308 4030011600 S.CER C1608 JB 1E 104K-T T 103.7/111.8
C1309 4030011600 S.CER C1608 JB 1E 104K-T T 105.6/101.2
C1310 4030011600 S.CER C1608 JB 1E 104K-T T 174.3/74.0
C1311 4030011600 S.CER C1608 JB 1E 104K-T T 63.6/93.1
C1312 4510008520 S.ELE EEE1CA470SP T 176.3/80.6
C1313 4510008600 S.ELE EEE1CA4R7NR T 77.4/88.8
C1314 4510008520 S.ELE EEE1CA470SP T 59.6/76.9
C1315 4030011600 S.CER C1608 JB 1E 104K-T T 159.4/81.7
C1451 4030011600 S.CER C1608 JB 1E 104K-T T 31.5/3.6
C1501 4510008520 S.ELE EEE1CA470SP T 15.4/47.2
C1502 4030011600 S.CER C1608 JB 1E 104K-T T 11.5/51.6
C1503 4030011600 S.CER C1608 JB 1E 104K-T T 12.4/55.5
C1504 4510008540 S.ELE EEE1CA100SR T 4.5/60.6
C1505 4510008540 S.ELE EEE1CA100SR T 146.4/97.6
C1506 4030011600 S.CER C1608 JB 1E 104K-T T 146.9/93.3
C1507 4030011600 S.CER C1608 JB 1E 104K-T T 152.4/91.7
C1508 4510008520 S.ELE EEE1CA470SP T 154.4/86.8
C1509 4030008680 S.CER C2012 JF 1C 105Z-T T 87.4/94.7
C1510 4030008680 S.CER C2012 JF 1C 105Z-T T 86.2/103.0
C1551 4030008680 S.CER C2012 JF 1C 105Z-T T 76.6/110.7
C1552 4510008520 S.ELE EEE1CA470SP T 75.2/99.3
C1555 4510008520 S.ELE EEE1CA470SP T 67.5/100.6
C1557 4030011600 S.CER C1608 JB 1E 104K-T T 51.9/110.4
C1558 4510008540 S.ELE EEE1CA100SR T 55.9/100.4
C1559 4030011600 S.CER C1608 JB 1E 104K-T T 56.8/104.1
C1560 4030011600 S.CER C1608 JB 1E 104K-T T 64.7/105.1
C1561 4030007170 S.CER C1608 CH 1H 221J-T T 62.7/107.0
C1562 4030011600 S.CER C1608 JB 1E 104K-T T 59.3/97.0
C1563 4030007170 S.CER C1608 CH 1H 221J-T T 64.0/107.0
C1601 4510008510 S.ELE EEE1CA471P T 10.0/18.9
C1602 4030011600 S.CER C1608 JB 1E 104K-T T 3.8/22.2
C1603 4510008510 S.ELE EEE1CA471P T 5.7/31.3
C1604 4510008510 S.ELE EEE1CA471P T 5.7/45.4
C1605 4510008510 S.ELE EEE1CA471P T 16.5/38.2
C1606 4030006900 S.CER C1608 JB 1H 103K-T T 3.7/10.6
C1607 4510008540 S.ELE EEE1CA100SR T 10.6/9.6
C1608 4030011600 S.CER C1608 JB 1E 104K-T T 14.8/1.8
C1609 4030008680 S.CER C2012 JF 1C 105Z-T T 19.2/7.8
C1610 4030011600 S.CER C1608 JB 1E 104K-T T 17.1/6.6
C1611 4030008680 S.CER C2012 JF 1C 105Z-T T 31.1/8.4
C1612 4510008600 S.ELE EEE1CA4R7NR T 19.4/16.5
C1613 4030011600 S.CER C1608 JB 1E 104K-T T 31.2/12.6
C1614 4510008510 S.ELE EEE1CA471P T 21.5/25.4
C1615 4510008540 S.ELE EEE1CA100SR T 30.5/22.4
C1616 4510008540 S.ELE EEE1CA100SR T 37.1/16.8
C1617 4510008540 S.ELE EEE1CA100SR T 32.3/27.7
C1618 4030008680 S.CER C2012 JF 1C 105Z-T T 35.6/26.7
C1619 4030008920 S.CER C1608 JB 1H 473K-T T 5.0/10.6
C1701 4030006880 S.CER C1608 JB 1H 472K-T T 26.8/31.7
C1702 4030011600 S.CER C1608 JB 1E 104K-T T 28.0/36.2
C1703 4030011600 S.CER C1608 JB 1E 104K-T T 23.3/35.9
C1704 4030011600 S.CER C1608 JB 1E 104K-T T 32.1/33.8
C1705 4030008680 S.CER C2012 JF 1C 105Z-T [USA] T 34.3/32.4
4030008680 S.CER C2012 JF 1C 105Z-T [CAN]
4030008680 S.CER C2012 JF 1C 105Z-T [CHN]
4030008680 S.CER C2012 JF 1C 105Z-T [VNM]
C1706 4510008600 S.ELE EEE1CA4R7NR T 41.3/30.3
C1707 4030008850 S.CER C1608 JB 1H 123K-T T 49.0/28.6
C1709 4030014300 S.CER C1608 JB 1E 563K-T T 45.9/28.6
C1710 4030014300 S.CER C1608 JB 1E 563K-T T 45.9/29.9
C1711 4030014300 S.CER C1608 JB 1E 563K-T T 42.3/19.6
C1713 4510008540 S.ELE EEE1CA100SR T 38.0/22.7
C1714 4510008540 S.ELE EEE1CA100SR T 52.3/24.8
C1715 4030011600 S.CER C1608 JB 1E 104K-T T 47.8/19.3
C1716 4030011600 S.CER C1608 JB 1E 104K-T T 74.5/46.1
C1717 4030011600 S.CER C1608 JB 1E 104K-T T 77.3/40.2
C1801 4030011600 S.CER C1608 JB 1E 104K-T T 134.1/20.8
C1802 4030006880 S.CER C1608 JB 1H 472K-T T 143.8/17.1
C1803 4030011600 S.CER C1608 JB 1E 104K-T T 171.6/7.6
C1804 4030011600 S.CER C1608 JB 1E 104K-T T 144.3/19.7
C1805 4030011600 S.CER C1608 JB 1E 104K-T T 147.1/21.5
C1806 4030011600 S.CER C1608 JB 1E 104K-T T 155.7/20.2
C1807 4030011600 S.CER C1608 JB 1E 104K-T T 142.3/12.2
C1901 4030011600 S.CER C1608 JB 1E 104K-T T 146.9/102.1
C1902 4030011600 S.CER C1608 JB 1E 104K-T T 119.0/110.9
C1903 4030011600 S.CER C1608 JB 1E 104K-T T 139.4/102.3
C1904 4030011600 S.CER C1608 JB 1E 104K-T T 129.2/106.0
C1905 4030011600 S.CER C1608 JB 1E 104K-T T 142.5/100.8
C1906 4030011600 S.CER C1608 JB 1E 104K-T T 143.8/101.5
C1907 4030006880 S.CER C1608 JB 1H 472K-T T 127.9/106.0
C1908 4030011600 S.CER C1608 JB 1E 104K-T T 127.1/103.4
C1910 4030006880 S.CER C1608 JB 1H 472K-T T 120.3/110.9
C2001 4510008600 S.ELE EEE1CA4R7NR [USA] T 65.9/21.9
4510008600 S.ELE EEE1CA4R7NR [CAN]
4510008600 S.ELE EEE1CA4R7NR [CHN]
4510008600 S.ELE EEE1CA4R7NR [VNM]
C2002 4510008600 S.ELE EEE1CA4R7NR T 64.2/16.2
C2003 4030011600 S.CER C1608 JB 1E 104K-T T 55.8/12.8
C2004 4510008600 S.ELE EEE1CA4R7NR T 51.4/18.3
C2005 4030006880 S.CER C1608 JB 1H 472K-T T 58.4/19.8
C2006 4030006880 S.CER C1608 JB 1H 472K-T T 56.0/21.2
C2007 4030011600 S.CER C1608 JB 1E 104K-T T 61.0/19.6
C2008 4030006880 S.CER C1608 JB 1H 472K-T T 55.7/19.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C2101 4030007010 S.CER C1608 CH 1H 100D-T [USA] T 27.9/104.5
4030007010 S.CER C1608 CH 1H 100D-T [CAN]
4030007010 S.CER C1608 CH 1H 100D-T [CHN]
4030007010 S.CER C1608 CH 1H 100D-T [VNM]
C2102 4030007030 S.CER C1608 CH 1H 150J-T [USA] T 33.6/106.1
4030007030 S.CER C1608 CH 1H 150J-T [CAN]
4030007030 S.CER C1608 CH 1H 150J-T [CHN]
4030007030 S.CER C1608 CH 1H 150J-T [VNM]
C2103 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 30.8/111.6
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2104 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 30.9/104.4
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2105 4030008920 S.CER C1608 JB 1H 473K-T [USA] T 39.3/106.1
4030008920 S.CER C1608 JB 1H 473K-T [CAN]
4030008920 S.CER C1608 JB 1H 473K-T [CHN]
4030008920 S.CER C1608 JB 1H 473K-T [VNM]
C2106 4030008680 S.CER C2012 JF 1C 105Z-T [USA] T 44.0/108.2
4030008680 S.CER C2012 JF 1C 105Z-T [CAN]
4030008680 S.CER C2012 JF 1C 105Z-T [CHN]
4030008680 S.CER C2012 JF 1C 105Z-T [VNM]
C2107 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 31.2/106.7
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2201 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 42.6/100.9
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2202 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 31.1/99.4
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2203 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 10.4/101.2
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2204 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 39.0/98.8
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C2205 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 26.1/98.8
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2206 4030007090 S.CER C1608 CH 1H 470J-T [USA] T 2.3/98.8
4030007090 S.CER C1608 CH 1H 470J-T [CAN]
4030007090 S.CER C1608 CH 1H 470J-T [CHN]
4030007090 S.CER C1608 CH 1H 470J-T [VNM]
C2207 4030009490 S.CER C1608 JB 1H 821K-T [USA] T 43.1/96.7
4030009490 S.CER C1608 JB 1H 821K-T [CAN]
4030009490 S.CER C1608 JB 1H 821K-T [CHN]
4030009490 S.CER C1608 JB 1H 821K-T [VNM]
C2208 4030009980 S.CER C1608 JB 1H 152K-T [USA] T 31.4/95.7
4030009980 S.CER C1608 JB 1H 152K-T [CAN]
4030009980 S.CER C1608 JB 1H 152K-T [CHN]
4030009980 S.CER C1608 JB 1H 152K-T [VNM]
C2209 4030010040 S.CER C1608 JB 1H 561K-T [USA] T 10.2/95.4
4030010040 S.CER C1608 JB 1H 561K-T [CAN]
4030010040 S.CER C1608 JB 1H 561K-T [CHN]
4030010040 S.CER C1608 JB 1H 561K-T [VNM]
C2210 4030007170 S.CER C1608 CH 1H 221J-T [USA] T 41.1/96.0
4030007170 S.CER C1608 CH 1H 221J-T [CAN]
4030007170 S.CER C1608 CH 1H 221J-T [CHN]
4030007170 S.CER C1608 CH 1H 221J-T [VNM]
C2211 4030007170 S.CER C1608 CH 1H 221J-T [USA] T 29.4/94.9
4030007170 S.CER C1608 CH 1H 221J-T [CAN]
4030007170 S.CER C1608 CH 1H 221J-T [CHN]
4030007170 S.CER C1608 CH 1H 221J-T [VNM]
C2212 4030007150 S.CER C1608 CH 1H 151J-T [USA] T 8.3/94.3
4030007150 S.CER C1608 CH 1H 151J-T [CAN]
4030007150 S.CER C1608 CH 1H 151J-T [CHN]
4030007150 S.CER C1608 CH 1H 151J-T [VNM]
C2213 4030010020 S.CER C1608 JB 1H 122K-T [USA] T 36.1/93.0
4030010020 S.CER C1608 JB 1H 122K-T [CAN]
4030010020 S.CER C1608 JB 1H 122K-T [CHN]
4030018590 S.CER C1608 CH 1H 122J-T [VNM]
C2214 4030007170 S.CER C1608 CH 1H 221J-T [USA] T 25.1/92.8
4030007170 S.CER C1608 CH 1H 221J-T [CAN]
4030007170 S.CER C1608 CH 1H 221J-T [CHN]
4030007170 S.CER C1608 CH 1H 221J-T [VNM]
C2215 4030007090 S.CER C1608 CH 1H 470J-T [USA] T 2.0/89.4
4030007090 S.CER C1608 CH 1H 470J-T [CAN]
4030007090 S.CER C1608 CH 1H 470J-T [CHN]
4030007090 S.CER C1608 CH 1H 470J-T [VNM]
C2216 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 43.1/95.3
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C2217 4030006870 S.CER C1608 JB 1H 222K-T [USA] T 31.4/94.4
4030006870 S.CER C1608 JB 1H 222K-T [CAN]
4030006870 S.CER C1608 JB 1H 222K-T [CHN]
4030006870 S.CER C1608 JB 1H 222K-T [VNM]
C2218 4030009580 S.CER C1608 JB 1H 681K-T [USA] T 10.2/94.1
4030009580 S.CER C1608 JB 1H 681K-T [CAN]
4030009580 S.CER C1608 JB 1H 681K-T [CHN]
4030009580 S.CER C1608 JB 1H 681K-T [VNM]
C2219 4030007130 S.CER C1608 CH 1H 101J-T [USA] T 38.2/90.2
4030007130 S.CER C1608 CH 1H 101J-T [CAN]
4030007130 S.CER C1608 CH 1H 101J-T [CHN]
4030007130 S.CER C1608 CH 1H 101J-T [VNM]

Nov. 2011
9
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C2220 4030007160 S.CER C1608 CH 1H 181J-T [USA] T 27.3/89.2
4030007160 S.CER C1608 CH 1H 181J-T [CAN]
4030007160 S.CER C1608 CH 1H 181J-T [CHN]
4030007160 S.CER C1608 CH 1H 181J-T [VNM]
C2221 4030007110 S.CER C1608 CH 1H 680J-T [USA] T 5.9/87.1
4030007110 S.CER C1608 CH 1H 680J-T [CAN]
4030007110 S.CER C1608 CH 1H 680J-T [CHN]
4030007110 S.CER C1608 CH 1H 680J-T [VNM]
C2222 4030010020 S.CER C1608 JB 1H 122K-T [USA] T 39.7/90.2
4030010020 S.CER C1608 JB 1H 122K-T [CAN]
4030010020 S.CER C1608 JB 1H 122K-T [CHN]
4030010020 S.CER C1608 JB 1H 122K-T [VNM]
C2223 4030007160 S.CER C1608 CH 1H 181J-T [USA] T 29.4/89.2
4030007160 S.CER C1608 CH 1H 181J-T [CAN]
4030007160 S.CER C1608 CH 1H 181J-T [CHN]
4030007160 S.CER C1608 CH 1H 181J-T [VNM]
C2224 4030007110 S.CER C1608 CH 1H 680J-T [USA] T 7.3/87.1
4030007110 S.CER C1608 CH 1H 680J-T [CAN]
4030007110 S.CER C1608 CH 1H 680J-T [CHN]
4030007110 S.CER C1608 CH 1H 680J-T [VNM]
C2225 4030010020 S.CER C1608 JB 1H 122K-T [USA] T 42.2/90.6
4030010020 S.CER C1608 JB 1H 122K-T [CAN]
4030010020 S.CER C1608 JB 1H 122K-T [CHN]
4030010020 S.CER C1608 JB 1H 122K-T [VNM]
C2226 4030009980 S.CER C1608 JB 1H 152K-T [USA] T 32.4/86.5
4030009980 S.CER C1608 JB 1H 152K-T [CAN]
4030009980 S.CER C1608 JB 1H 152K-T [CHN]
4030009980 S.CER C1608 JB 1H 152K-T [VNM]
C2227 4030009580 S.CER C1608 JB 1H 681K-T [USA] T 10.5/88.4
4030009580 S.CER C1608 JB 1H 681K-T [CAN]
4030009580 S.CER C1608 JB 1H 681K-T [CHN]
4030009580 S.CER C1608 JB 1H 681K-T [VNM]
C2228 4030007090 S.CER C1608 CH 1H 470J-T [USA] T 39.7/87.5
4030007090 S.CER C1608 CH 1H 470J-T [CAN]
4030007090 S.CER C1608 CH 1H 470J-T [CHN]
4030007090 S.CER C1608 CH 1H 470J-T [VNM]
C2229 4030007030 S.CER C1608 CH 1H 150J-T [USA] T 14.3/96.4
4030007030 S.CER C1608 CH 1H 150J-T [CAN]
4030007030 S.CER C1608 CH 1H 150J-T [CHN]
4030007030 S.CER C1608 CH 1H 150J-T [VNM]
C2232 4030007100 S.CER C1608 CH 1H 560J-T [USA] T 28.6/85.7
4030007100 S.CER C1608 CH 1H 560J-T [CAN]
4030007100 S.CER C1608 CH 1H 560J-T [CHN]
4030007100 S.CER C1608 CH 1H 560J-T [VNM]
C2234 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 39.1/84.8
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2235 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 20.8/98.9
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2236 4030011330 S.CER C1608 CH 1H 391J-T [USA] T 27.5/82.7
4030011330 S.CER C1608 CH 1H 391J-T [CAN]
4030011330 S.CER C1608 CH 1H 391J-T [CHN]
4030011330 S.CER C1608 CH 1H 391J-T [VNM]
C2237 4030010020 S.CER C1608 JB 1H 122K-T [USA] T 21.0/97.0
4030010020 S.CER C1608 JB 1H 122K-T [CAN]
4030010020 S.CER C1608 JB 1H 122K-T [CHN]
4030010020 S.CER C1608 JB 1H 122K-T [VNM]
C2238 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 6.8/82.2
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2239 4030007060 S.CER C1608 CH 1H 270J-T [USA] T 14.3/97.7
4030007060 S.CER C1608 CH 1H 270J-T [CAN]
4030007060 S.CER C1608 CH 1H 270J-T [CHN]
4030007060 S.CER C1608 CH 1H 270J-T [VNM]
C2240 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 42.2/82.3
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2241 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 33.5/84.2
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2242 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 11.3/84.4
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2243 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 21.0/95.7
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C2244 4030007170 S.CER C1608 CH 1H 221J-T [USA] T 19.1/95.0
4030007170 S.CER C1608 CH 1H 221J-T [CAN]
4030007170 S.CER C1608 CH 1H 221J-T [CHN]
4030007170 S.CER C1608 CH 1H 221J-T [VNM]
C2245 4030007060 S.CER C1608 CH 1H 270J-T [USA] T 14.7/92.0
4030007060 S.CER C1608 CH 1H 270J-T [CAN]
4030007060 S.CER C1608 CH 1H 270J-T [CHN]
4030007060 S.CER C1608 CH 1H 270J-T [VNM]
C2246 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 21.0/94.2
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C2247 4030007150 S.CER C1608 CH 1H 151J-T [USA] T 16.6/89.0
4030007150 S.CER C1608 CH 1H 151J-T [CAN]
4030007150 S.CER C1608 CH 1H 151J-T [CHN]
4030007150 S.CER C1608 CH 1H 151J-T [VNM]
C2248 4030007060 S.CER C1608 CH 1H 270J-T [USA] T 17.9/89.0
4030007060 S.CER C1608 CH 1H 270J-T [CAN]
4030007060 S.CER C1608 CH 1H 270J-T [CHN]
4030007060 S.CER C1608 CH 1H 270J-T [VNM]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C2249 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 21.2/89.3
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C2250 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 21.9/92.3
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C2251 4030007040 S.CER C1608 CH 1H 180J-T [USA] T 19.4/84.5
4030007040 S.CER C1608 CH 1H 180J-T [CAN]
4030007040 S.CER C1608 CH 1H 180J-T [CHN]
4030007040 S.CER C1608 CH 1H 180J-T [VNM]
C2252 4030011280 S.CER C1608 CH 1H 271J-T [USA] T 15.4/83.0
4030011280 S.CER C1608 CH 1H 271J-T [CAN]
4030011280 S.CER C1608 CH 1H 271J-T [CHN]
4030011280 S.CER C1608 CH 1H 271J-T [VNM]
C2253 4030010020 S.CER C1608 JB 1H 122K-T [USA] T 19.2/86.4
4030010020 S.CER C1608 JB 1H 122K-T [CAN]
4030010020 S.CER C1608 JB 1H 122K-T [CHN]
4030010020 S.CER C1608 JB 1H 122K-T [VNM]
C2254 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 21.4/83.8
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2263 4030009510 S.CER C1608 CH 1H 010B-T [USA] T 13.4/91.8
4030009510 S.CER C1608 CH 1H 010B-T [CAN]
4030009510 S.CER C1608 CH 1H 010B-T [CHN]
4030009510 S.CER C1608 CH 1H 010B-T [VNM]
C2264 4030009510 S.CER C1608 CH 1H 010B-T [USA] T 19.2/89.0
4030009510 S.CER C1608 CH 1H 010B-T [CAN]
4030009510 S.CER C1608 CH 1H 010B-T [CHN]
4030009510 S.CER C1608 CH 1H 010B-T [VNM]
C2266 4030007010 S.CER C1608 CH 1H 100D-T [USA] T 8.6/88.9
4030007010 S.CER C1608 CH 1H 100D-T [CAN]
4030007010 S.CER C1608 CH 1H 100D-T [CHN]
4030007010 S.CER C1608 CH 1H 100D-T [VNM]
C2267 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 46.7/81.2
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2268 4030007080 S.CER C1608 CH 1H 390J-T [USA] T 14.1/84.7
4030007080 S.CER C1608 CH 1H 390J-T [CAN]
4030007080 S.CER C1608 CH 1H 390J-T [CHN]
4030007080 S.CER C1608 CH 1H 390J-T [VNM]
C2269 4030007080 S.CER C1608 CH 1H 390J-T [USA] T 4.1/85.0
4030007080 S.CER C1608 CH 1H 390J-T [CAN]
4030007080 S.CER C1608 CH 1H 390J-T [CHN]
4030007080 S.CER C1608 CH 1H 390J-T [VNM]
C2270 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 11.4/80.9
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2271 4030007090 S.CER C1608 CH 1H 470J-T [USA] T 25.6/83.5
4030007090 S.CER C1608 CH 1H 470J-T [CAN]
4030007090 S.CER C1608 CH 1H 470J-T [CHN]
4030007090 S.CER C1608 CH 1H 470J-T [VNM]
C2301 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 40.4/78.6
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2302 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 45.0/70.0
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2303 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 30.6/77.3
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2304 4030011340 S.CER C1608 CH 1H 471J-T [USA] T 7.4/77.5
4030011340 S.CER C1608 CH 1H 471J-T [CAN]
4030011340 S.CER C1608 CH 1H 471J-T [CHN]
4030011340 S.CER C1608 CH 1H 471J-T [VNM]
C2307 4030007040 S.CER C1608 CH 1H 180J-T [USA] T 6.6/64.3
4030007040 S.CER C1608 CH 1H 180J-T [CAN]
4030007040 S.CER C1608 CH 1H 180J-T [CHN]
4030007040 S.CER C1608 CH 1H 180J-T [VNM]
C2308 4030007040 S.CER C1608 CH 1H 180J-T [USA] T 30.7/57.5
4030007040 S.CER C1608 CH 1H 180J-T [CAN]
4030007040 S.CER C1608 CH 1H 180J-T [CHN]
4030007040 S.CER C1608 CH 1H 180J-T [VNM]
C2309 4030007040 S.CER C1608 CH 1H 180J-T [USA] T 12.5/73.6
4030007040 S.CER C1608 CH 1H 180J-T [CAN]
4030007040 S.CER C1608 CH 1H 180J-T [CHN]
4030007040 S.CER C1608 CH 1H 180J-T [VNM]
C2310 4030007130 S.CER C1608 CH 1H 101J-T [USA] T 8.4/75.1
4030007130 S.CER C1608 CH 1H 101J-T [CAN]
4030007130 S.CER C1608 CH 1H 101J-T [CHN]
4030007130 S.CER C1608 CH 1H 101J-T [VNM]
C2311 4030007140 S.CER C1608 CH 1H 121J-T [USA] T 9.7/75.1
4030007140 S.CER C1608 CH 1H 121J-T [CAN]
4030007140 S.CER C1608 CH 1H 121J-T [CHN]
4030019360 S.CER C1608 C0G 1H 121J-T [VNM]
C2402 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 32.0/57.5
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2403 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 31.7/54.9
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2404 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 35.4/59.9
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]

Nov. 2011
10
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C2405 4030009910 S.CER C1608 CH 1H 040B-T [USA] T 39.2/57.1
4030009910 S.CER C1608 CH 1H 040B-T [CAN]
4030009910 S.CER C1608 CH 1H 040B-T [CHN]
4030009910 S.CER C1608 CH 1H 040B-T [VNM]
C2406 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 35.3/62.5
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2409 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 44.1/54.0
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2501 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 41.5/52.4
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2502 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 47.1/49.4
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2503 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 47.4/45.7
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2504 4030009910 S.CER C1608 CH 1H 040B-T [USA] T 45.2/45.0
4030009910 S.CER C1608 CH 1H 040B-T [CAN]
4030009910 S.CER C1608 CH 1H 040B-T [CHN]
4030009910 S.CER C1608 CH 1H 040B-T [VNM]
C2701 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 39.7/43.3
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2702 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 37.5/40.8
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2703 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 42.4/36.4
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2704 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 42.4/39.1
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2705 4510008540 S.ELE EEE1CA100SR [USA] T 45.5/38.9
4510008540 S.ELE EEE1CA100SR [CAN]
4510008540 S.ELE EEE1CA100SR [CHN]
4510008540 S.ELE EEE1CA100SR [VNM]
C2706 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 40.2/35.6
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2707 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 51.9/33.3
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C2708 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 53.7/41.3
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2710 4510008540 S.ELE EEE1CA100SR [USA] T 55.4/46.9
4510008540 S.ELE EEE1CA100SR [CAN]
4510008540 S.ELE EEE1CA100SR [CHN]
4510008540 S.ELE EEE1CA100SR [VNM]
C2711 4510008540 S.ELE EEE1CA100SR [USA] T 58.1/28.5
4510008540 S.ELE EEE1CA100SR [CAN]
4510008540 S.ELE EEE1CA100SR [CHN]
4510008540 S.ELE EEE1CA100SR [VNM]
C2712 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 62.5/36.9
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2713 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 61.2/36.9
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C2714 4030009970 S.CER C1608 JB 1H 182K-T [USA] T 59.8/32.7
4030009970 S.CER C1608 JB 1H 182K-T [CAN]
4030009970 S.CER C1608 JB 1H 182K-T [CHN]
4030009970 S.CER C1608 JB 1H 182K-T [VNM]
C2715 4030010040 S.CER C1608 JB 1H 561K-T [USA] T 58.5/32.7
4030010040 S.CER C1608 JB 1H 561K-T [CAN]
4030010040 S.CER C1608 JB 1H 561K-T [CHN]
4030010040 S.CER C1608 JB 1H 561K-T [VNM]
C2716 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 59.6/40.3
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C3001 4030008920 S.CER C1608 JB 1H 473K-T T 109.6/65.0
C3002 4030008920 S.CER C1608 JB 1H 473K-T T 112.2/65.0
C3003 4030008920 S.CER C1608 JB 1H 473K-T T 114.8/65.0
C3004 4030008920 S.CER C1608 JB 1H 473K-T T 116.1/65.0
C3005 4030008920 S.CER C1608 JB 1H 473K-T T 118.7/65.0
C3006 4030011600 S.CER C1608 JB 1E 104K-T T 97.7/55.0
C3007 4030007130 S.CER C1608 CH 1H 101J-T T 116.5/20.2
C3008 4030011600 S.CER C1608 JB 1E 104K-T T 97.7/56.3
C3009 4030011600 S.CER C1608 JB 1E 104K-T T 95.1/52.6
C3101 4510008520 S.ELE EEE1CA470SP T 146.2/4.8
C3102 4030011600 S.CER C1608 JB 1E 104K-T T 141.7/1.5
C3103 4030011600 S.CER C1608 JB 1E 104K-T T 138.1/1.7
C3104 4510008520 S.ELE EEE1CA470SP T 134.0/4.7
C3201 4030011600 S.CER C1608 JB 1E 104K-T T 96.2/24.8
C3202 4030006880 S.CER C1608 JB 1H 472K-T T 90.3/20.1
C3302 4030011600 S.CER C1608 JB 1E 104K-T T 119.0/57.7
C3303 4030011600 S.CER C1608 JB 1E 104K-T T 103.5/48.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
C3304 4030007060 S.CER C1608 CH 1H 270J-T T 106.5/42.3
C3305 4030007060 S.CER C1608 CH 1H 270J-T T 107.0/38.5
C3306 4030008890 S.CER C1608 JB 1H 273K-T T 103.6/43.1
C3307 4030008920 S.CER C1608 JB 1H 473K-T T 121.3/65.0
C3308 4030011600 S.CER C1608 JB 1E 104K-T T 112.4/55.8
C3309 4030006880 S.CER C1608 JB 1H 472K-T T 112.4/57.2
C3310 4030011600 S.CER C1608 JB 1E 104K-T T 108.3/41.5
C3311 4030011600 S.CER C1608 JB 1E 104K-T T 129.0/39.1
C3312 4030006930 S.CER C1608 CH 1H 020C-T T 99.9/39.0
C3601 4030011600 S.CER C1608 JB 1E 104K-T T 94.3/37.2
C3602 4030011600 S.CER C1608 JB 1E 104K-T T 105.5/82.5
C3603 4030011600 S.CER C1608 JB 1E 104K-T T 92.4/24.7
C3604 4030011600 S.CER C1608 JB 1E 104K-T T 173.5/57.2
C3605 4030011600 S.CER C1608 JB 1E 104K-T T 66.8/80.9
C3606 4030011600 S.CER C1608 JB 1E 104K-T T 70.2/75.7
C3901 4030011600 S.CER C1608 JB 1E 104K-T T 142.5/33.7
RL2101 6330001320 REL AHY103 [USA]
6330001320 REL AHY103 [CAN]
6330001320 REL AHY103 [CHN]
6330001320 REL AHY103 [VNM]
J1 6510028210 CON SJ050010 (TMP-J01X-V6)
J51 6510028210 CON SJ050010 (TMP-J01X-V6)
J301 6510028210 CON SJ050010 (TMP-J01X-V6)
J601 6510028210 CON SJ050010 (TMP-J01X-V6)
J1101 6510021651 CON IMSA-9180B-30B-PT1
J1102 6510022811 CON IMSA-9180B-22B-PT1
J1301 6510022611 S.CON 16FMN-BMTTR-A-TBT(LF)(SN) T 101.0/107.6
J1451 6450000140 CON HSJ0807-01-010
J1801 6510023671 CON TCS4480-0141577
J1901 6510022541 S.CON 20FMN-BMTTR-A-TBT(LF)(SN) T 133.5/110.2
J2051 6510023181 CON TCS7282-0121177
J2101 6510028210 CON SJ050010 (TMP-J01X-V6) [USA]
6510028210 CON SJ050010 (TMP-J01X-V6) [CAN]
6510028210 CON SJ050010 (TMP-J01X-V6) [CHN]
6510028210 CON SJ050010 (TMP-J01X-V6) [VNM]
J2301 6510028210 CON SJ050010 (TMP-J01X-V6) [USA]
6510028210 CON SJ050010 (TMP-J01X-V6) [CAN]
6510028210 CON SJ050010 (TMP-J01X-V6) [CHN]
6510028210 CON SJ050010 (TMP-J01X-V6) [VNM]
J3001 6510022621 S.CON 10FMN-BMTTR-A-TBT(LF)(SN) T 124.2/8.2
J3601 6510022581 S.CON 24FMN-BMTTR-A-TBT(LF)(SN) T 78.0/6.0
J3602 6510021722 S.CON 30FLT-SM2-TB(LF)(SN)(M) T 108.6/6.4
EP2 0880000900 UNI EX-2432 #02 #2432DSP [USA]
0880001190 UNI EX-2432 #03 #2432DSP [OTH]
0880000900 UNI EX-2432 #02 #2432DSP [CAN]
0880000900 UNI EX-2432 #02 #2432DSP [CHN]
0880001190 UNI EX-2432 #03 #2432DSP [CHN-01]
0880000900 UNI EX-2432 #02 #2432DSP [VNM]

Nov. 2011
11
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
IC5001 1180001072 S.IC TA7805F(TE16L1NQ) T 66.5/55.6
IC5031 1180001252 S.IC TA7808F(TE16L1NQ) T 37.5/37.8
IC5081 1120002921 S.IC ADM202EARNZ-REEL7 <FE> T 37.0/17.2
IC5082 1130006801 S.IC TC7W08F(TE12LF) T 13.7/19.0
IC5083 1130007041 S.IC TC7W32F(TE12LF) T 47.8/14.2
IC5084 1170000290 S.IC PS2701-1-F3 T 24.6/16.3
IC5085 1170000290 S.IC PS2701-1-F3 [USA] T 8.0/15.1
1170000290 S.IC PS2701-1-F3 [CAN]
1170000290 S.IC PS2701-1-F3 [CHN]
1170000290 S.IC PS2701-1-F3 [VNM]
IC5101 1140007881 S.IC TC190G08EFG0046JDZ/
SC1246A T 158.0/59.6
IC5102 1130004831 S.IC TC7SU04F(TE85RF) T 159.2/45.5
IC5103 1130004831 S.IC TC7SU04F(TE85RF) T 170.0/70.1
IC5401 1130009230 S.IC LMX2306TMX/NOPB T 203.6/69.3
IC5701 1140014960 S.IC TC190G02EFG-0058/SC1287A T 64.1/88.8
IC5702 1130004831 S.IC TC7SU04F(TE85RF) T 56.7/97.3
IC5801 1140014960 S.IC TC190G02EFG-0058/SC1287A
[USA] T 36.3/83.9
1140014960 S.IC TC190G02EFG-0058/SC1287A
[CAN]
1140014960 S.IC TC190G02EFG-0058/SC1287A
[CHN]
1140014960 S.IC TC190G02EFG-0058/SC1287A
[VNM]
IC5802 1130004831 S.IC TC7SU04F(TE85RF) [USA] T 44.4/91.4
1130004831 S.IC TC7SU04F(TE85RF) [CAN]
1130004831 S.IC TC7SU04F(TE85RF) [CHN]
1130004831 S.IC TC7SU04F(TE85RF) [VNM]
IC5901 1140014960 S.IC TC190G02EFG-0058/SC1287A
[USA] T 36.4/57.7
1140014960 S.IC TC190G02EFG-0058/SC1287A
[CAN]
1140014960 S.IC TC190G02EFG-0058/SC1287A
[CHN]
1140014960 S.IC TC190G02EFG-0058/SC1287A
[VNM]
IC5902 1130004831 S.IC TC7SU04F(TE85RF) [USA] T 44.5/65.0
1130004831 S.IC TC7SU04F(TE85RF) [CAN]
1130004831 S.IC TC7SU04F(TE85RF) [CHN]
1130004831 S.IC TC7SU04F(TE85RF) [VNM]
Q5081 1530002691 S.TRA 2SC4116-GR(TE85RF) T 85.0/4.5
Q5082 1530002691 S.TRA 2SC4116-GR(TE85RF) T 84.9/7.7
Q5083 1590000680 S.TRA DTC114EUA T106 T 48.0/6.0
Q5084 1530002691 S.TRA 2SC4116-GR(TE85RF) T 29.0/7.8
Q5085 1590000680 S.TRA DTC114EUA T106 T 28.7/3.7
Q5101 1530002691 S.TRA 2SC4116-GR(TE85RF) T 147.5/39.0
Q5202 1530002601 S.TRA 2SC4215-O(TE85RF) T 123.8/56.0
Q5281 1530002601 S.TRA 2SC4215-O(TE85RF) T 99.9/78.9
Q5301 1560000331 S.FET 2SK210-GR(TE85RF) T 193.7/53.6
Q5302 1530002691 S.TRA 2SC4116-GR(TE85RF) T 201.0/54.6
Q5351 1530002601 S.TRA 2SC4215-O(TE85RF) T 196.9/42.3
Q5401 1590001330 S.TRA DTA114EUA T106 T 205.9/73.7
Q5521 1560000491 S.FET 2SK508-T2B-A K52 T 138.8/89.5
Q5553 1530002691 S.TRA 2SC4116-GR(TE85RF) T 136.0/98.1
Q5601 1530002601 S.TRA 2SC4215-O(TE85RF) T 177.7/91.0
Q5602 1530002601 S.TRA 2SC4215-O(TE85RF) T 182.4/93.9
Q5603 1530002601 S.TRA 2SC4215-O(TE85RF) T 188.3/89.6
Q5604 1530002601 S.TRA 2SC4215-O(TE85RF) T 184.9/83.8
Q5881 1530003340 S.TRA 2SC3357-T1 RF [USA] T 9.1/89.0
1530003340 S.TRA 2SC3357-T1 RF [CAN]
1530003340 S.TRA 2SC3357-T1 RF [CHN]
1530003340 S.TRA 2SC3357-T1 RF [VNM]
Q5882 1530002601 S.TRA 2SC4215-O(TE85RF) [USA] T 19.3/84.1
1530002601 S.TRA 2SC4215-O(TE85RF) [CAN]
1530002601 S.TRA 2SC4215-O(TE85RF) [CHN]
1530002601 S.TRA 2SC4215-O(TE85RF) [VNM]
D5051 1790001251 S.DIO MA2S1110GL [USA] T 187.8/13.7
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1750002020 S.DIO DA2S10100L [VNM]
D5081 1790001251 S.DIO MA2S1110GL [USA] T 27.4/12.4
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D5082 1790001251 S.DIO MA2S1110GL [USA] T 10.5/11.1
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1750002020 S.DIO DA2S10100L [VNM]
D5083 1790001251 S.DIO MA2S1110GL [USA] T 48.0/8.0
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D5084 1790001251 S.DIO MA2S1110GL [USA] T 32.0/3.5
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
D5085 1790001251 S.DIO MA2S1110GL [USA] T 30.7/3.5
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [VNM]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
D5086 1790001251 S.DIO MA2S1110GL [USA] T 17.1/20.5
1790001251 S.DIO MA2S1110GL [CAN]
1790001251 S.DIO MA2S1110GL [CHN]
1750002020 S.DIO DA2S10100L [VNM]
D5101 1750000271 S.DIO 1SS301(TE85LF) T 171.1/63.9
D5301 1790000540 S.VAR MA338(TX) T 183.5/49.8
D5302 1790001211 S.DIO 1SS375-TL-E T 200.5/49.7
D5303 1790001211 S.DIO 1SS375-TL-E T 200.5/45.9
D5402 1750000271 S.DIO 1SS301(TE85LF) T 212.9/71.3
D5521 1720000831 S.VAR KV1770STL-G 1-3 T 146.8/90.4
FI5101 2020001820 S.CER SFECV10M5FA00-R0
(SFECV10.5MA5S) T 156.8/39.4
X5251 6050011520 XTA CR-604. POCO 32.000 MHz
[USA]
6050011520 XTA CR-604. POCO 32.000 MHz
[CAN]
6050011520 XTA CR-604. POCO 32.000 MHz
[CHN]
6050011520 XTA CR-604. POCO 32.000 MHz
[VNM]
X5281 6050011390 XTA CR-338. POC 32.00000 MHz
[OTH]
6050011390 XTA CR-338. POC 32.00000 MHz
[CHN-01]
L5005 6200009300 S.COI ELJPA 100KF 10U T 63.5/35.7
L5021 2040000490 COI EXC-ELDR25C
L5101 6200001831 S.COI NLV32T-100J T 172.6/41.8
L5201 2040000490 COI EXC-ELDR25C [OTH]
2040000490 COI EXC-ELDR25C [CHN-01]
L5202 6200003261 S.COI NLV32T-101J T 128.1/60.7
L5203 6150004250 COI LS-471A (C-14922)
L5204 6150004250 COI LS-471A (C-14922)
L5301 6200003261 S.COI NLV32T-101J T 183.7/54.4
L5302 6130001850 COI LB-185
L5303 6200001831 S.COI NLV32T-100J T 194.1/56.8
L5304 6200003261 S.COI NLV32T-101J T 199.4/58.4
L5351 6200003261 S.COI NLV32T-101J T 206.0/43.3
L5352 6200003101 S.COI NLV32T-3R9J T 190.7/41.5
L5401 6200001831 S.COI NLV32T-100J T 210.4/74.0
L5521 6170000401 COI LW-38A
L5522 6170000401 COI LW-38A
L5523 6190001281 COI #E544GN-110248
L5552 6200003261 S.COI NLV32T-101J T 123.9/82.4
L5601 6200003261 S.COI NLV32T-101J T 176.3/85.0
L5602 6200003421 S.COI NLV32T-R15J T 192.1/93.2
L5603 6200003431 S.COI NLV32T-R10J T 195.1/89.3
L5604 6200003431 S.COI NLV32T-R10J T 197.8/92.7
L5605 6200003261 S.COI NLV32T-101J T 180.7/84.9
L5701 6200009300 S.COI ELJPA 100KF 10U T 73.9/96.2
L5781 6200001711 S.COI NLV32T-220J T 75.0/72.0
L5782 6200001711 S.COI NLV32T-220J T 75.6/77.0
L5783 6200003151 S.COI NLV32T-180J T 74.3/82.2
L5801 6200009300 S.COI ELJPA 100KF 10U [USA] T 42.3/74.2
6200009300 S.COI ELJPA 100KF 10U [CAN]
6200009300 S.COI ELJPA 100KF 10U [CHN]
6200009300 S.COI ELJPA 100KF 10U [VNM]
L5881 6200001851 S.COI NLV32T-5R6J [USA] T 19.5/73.8
6200001851 S.COI NLV32T-5R6J [CAN]
6200001851 S.COI NLV32T-5R6J [CHN]
6200001851 S.COI NLV32T-5R6J [VNM]
L5882 6200001851 S.COI NLV32T-5R6J [USA] T 24.5/73.2
6200001851 S.COI NLV32T-5R6J [CAN]
6200001851 S.COI NLV32T-5R6J [CHN]
6200001851 S.COI NLV32T-5R6J [VNM]
L5883 6200004900 S.COI ELJFC 5R6K-F [USA] T 29.7/73.9
6200004900 S.COI ELJFC 5R6K-F [CAN]
6200004900 S.COI ELJFC 5R6K-F [CHN]
6200004900 S.COI ELJFC 5R6K-F [VNM]
L5884 6200005011 S.COI NLV25T-100J [USA] T 19.3/90.4
6200005011 S.COI NLV25T-100J [CAN]
6200005011 S.COI NLV25T-100J [CHN]
6200005011 S.COI NLV25T-100J [VNM]
L5885 6200002041 S.COI NLV25T-101J [USA] T 8.7/92.8
6200002041 S.COI NLV25T-101J [CAN]
6200002041 S.COI NLV25T-101J [CHN]
6200002041 S.COI NLV25T-101J [VNM]
L5901 6200009300 S.COI ELJPA 100KF 10U [USA] T 42.5/48.0
6200009300 S.COI ELJPA 100KF 10U [CAN]
6200009300 S.COI ELJPA 100KF 10U [CHN]
6200009300 S.COI ELJPA 100KF 10U [VNM]
L5981 6200003151 S.COI NLV32T-180J [USA] T 21.2/47.6
6200003151 S.COI NLV32T-180J [CAN]
6200003151 S.COI NLV32T-180J [CHN]
6200003151 S.COI NLV32T-180J [VNM]
L5982 6200001711 S.COI NLV32T-220J [USA] T 26.1/47.0
6200001711 S.COI NLV32T-220J [CAN]
6200001711 S.COI NLV32T-220J [CHN]
6200001711 S.COI NLV32T-220J [VNM]
L5983 6200003141 S.COI NLV32T-150J [USA] T 30.2/47.6
6200003141 S.COI NLV32T-150J [CAN]
6200003141 S.COI NLV32T-150J [CHN]
6200003141 S.COI NLV32T-150J [VNM]
R5002 7030003400 S.RES ERJ3GEYJ 471 V (470) T 82.4/35.3
R5003 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] T 78.3/37.5
7030003400 S.RES ERJ3GEYJ 471 V (470) [CAN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [CHN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [VNM]

Nov. 2011
12
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
R5004 7030003400 S.RES ERJ3GEYJ 471 V (470) T 75.7/37.5
R5005 7030003400 S.RES ERJ3GEYJ 471 V (470) T 73.1/37.5
R5006 7030003400 S.RES ERJ3GEYJ 471 V (470) T 70.5/37.5
R5008 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] T 79.6/37.5
7030003400 S.RES ERJ3GEYJ 471 V (470) [CAN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [CHN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [VNM]
R5009 7030003400 S.RES ERJ3GEYJ 471 V (470) T 77.0/37.5
R5010 7030003400 S.RES ERJ3GEYJ 471 V (470) T 74.4/37.5
R5011 7030003400 S.RES ERJ3GEYJ 471 V (470) T 71.8/37.5
R5021 7070000311 RES ERG1SJ 100 (10)
R5051 7030003430 S.RES ERJ3GEYJ 821 V (820) [USA] T 215.8/21.6
7030003430 S.RES ERJ3GEYJ 821 V (820) [CAN]
7030003430 S.RES ERJ3GEYJ 821 V (820) [CHN]
7030003430 S.RES ERJ3GEYJ 821 V (820) [VNM]
R5081 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 81.7/4.4
R5082 7030003400 S.RES ERJ3GEYJ 471 V (470) T 28.7/12.5
R5083 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] T 12.2/12.5
7030003400 S.RES ERJ3GEYJ 471 V (470) [CAN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [CHN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [VNM]
R5084 7030003360 S.RES ERJ3GEYJ 221 V (220) T 46.0/8.4
R5085 7030003360 S.RES ERJ3GEYJ 221 V (220) T 45.5/10.3
R5086 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 81.7/7.8
R5087 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 35.9/10.0
R5088 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 87.1/7.9
R5089 7030009620 S.RES ERJ12YJ120U (12) T 32.2/7.8
R5090 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 14.2/22.6
R5091 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 6.0/20.7
R5092 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 28.9/5.8
R5093 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 39.6/21.5
R5094 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 36.0/21.5
R5095 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 10.1/20.7
R5096 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 45.2/17.7
R5097 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 18.5/20.4
R5098 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 87.1/5.0
R5101 7030007200 S.RES ERA3YEB 202V (2K) T 142.0/49.7
R5102 7030007200 S.RES ERA3YEB 202V (2K) T 142.0/51.3
R5103 7030007200 S.RES ERA3YEB 202V (2K) T 142.0/52.9
R5104 7030007200 S.RES ERA3YEB 202V (2K) T 142.0/54.5
R5105 7030007200 S.RES ERA3YEB 202V (2K) T 142.0/56.1
R5106 7030007220 S.RES ERA3YED 202V (2K) T 142.0/57.7
R5107 7030007220 S.RES ERA3YED 202V (2K) T 142.0/59.3
R5108 7030007220 S.RES ERA3YED 202V (2K) T 142.0/60.9
R5109 7030007220 S.RES ERA3YED 202V (2K) T 142.0/62.5
R5110 7030007220 S.RES ERA3YED 202V (2K) T 142.0/64.1
R5111 7030007220 S.RES ERA3YED 202V (2K) T 142.0/65.7
R5112 7030007220 S.RES ERA3YED 202V (2K) T 142.0/67.3
R5113 7030007210 S.RES ERA3YEB 102V (1K) T 140.0/50.5
R5114 7030007210 S.RES ERA3YEB 102V (1K) T 138.7/52.1
R5115 7030007210 S.RES ERA3YEB 102V (1K) T 140.0/53.7
R5116 7030007210 S.RES ERA3YEB 102V (1K) T 138.7/55.3
R5117 7030007210 S.RES ERA3YEB 102V (1K) T 140.0/56.9
R5118 7030007230 S.RES ERA3YED 102V (1K) T 138.7/58.5
R5119 7030007230 S.RES ERA3YED 102V (1K) T 140.0/60.1
R5120 7030007230 S.RES ERA3YED 102V (1K) T 138.7/61.7
R5121 7030007230 S.RES ERA3YED 102V (1K) T 140.0/63.3
R5122 7030007230 S.RES ERA3YED 102V (1K) T 138.7/64.9
R5123 7030007230 S.RES ERA3YED 102V (1K) T 140.0/66.5
R5124 7030007220 S.RES ERA3YED 202V (2K) T 142.0/68.9
R5125 7030003320 S.RES ERJ3GEYJ 101 V (100) T 156.7/47.3
R5126 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 161.9/45.9
R5127 7030003380 S.RES ERJ3GEYJ 331 V (330) T 162.1/40.1
R5128 7030003320 S.RES ERJ3GEYJ 101 V (100) T 152.7/45.8
R5129 7030003380 S.RES ERJ3GEYJ 331 V (330) T 152.2/38.9
R5130 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 145.4/38.8
R5131 7030003400 S.RES ERJ3GEYJ 471 V (470) T 149.4/38.9
R5132 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 144.0/38.8
R5133 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 165.7/48.4
R5134 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 167.6/48.9
R5135 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 169.7/67.8
R5136 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 169.6/56.9
R5137 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 169.9/54.5
R5138 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 153.6/69.2
R5139 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 150.8/72.4
R5140 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 156.0/72.4
R5141 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 153.4/72.4
R5142 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 150.3/70.5
R5143 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 157.3/72.4
R5144 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 154.7/72.4
R5145 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 152.1/72.4
R5146 7030003430 S.RES ERJ3GEYJ 821 V (820) T 169.1/58.8
R5203 7030003320 S.RES ERJ3GEYJ 101 V (100) T 126.5/57.9
R5204 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 123.6/57.9
R5205 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 120.9/57.9
R5206 7030003360 S.RES ERJ3GEYJ 221 V (220) T 120.9/56.4
R5251 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] T 99.6/88.0
7030003400 S.RES ERJ3GEYJ 471 V (470) [CAN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [CHN]
7030003400 S.RES ERJ3GEYJ 471 V (470) [VNM]
R5281 7030003400 S.RES ERJ3GEYJ 471 V (470) T 99.2/81.9
R5282 7030003320 S.RES ERJ3GEYJ 101 V (100) T 98.0/78.7
R5283 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 101.8/79.1
R5284 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 100.5/81.9
R5302 7030003340 S.RES ERJ3GEYJ 151 V (150) T 185.9/54.9
R5303 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 189.8/52.4
R5304 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 191.0/59.0
R5305 7030003340 S.RES ERJ3GEYJ 151 V (150) T 190.1/56.3
R5306 7030003320 S.RES ERJ3GEYJ 101 V (100) T 195.2/59.0
R5307 7030003690 S.RES ERJ3GEYJ 124 V (120K) T 199.0/54.7
R5308 7030003320 S.RES ERJ3GEYJ 101 V (100) T 203.8/54.4
R5309 7030003430 S.RES ERJ3GEYJ 821 V (820) T 204.0/51.8
R5310 7030003430 S.RES ERJ3GEYJ 821 V (820) T 204.5/46.2
R5311 7030003430 S.RES ERJ3GEYJ 821 V (820) T 203.2/49.5
R5312 7030003400 S.RES ERJ3GEYJ 471 V (470) T 205.8/46.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
R5351 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 200.1/42.3
R5352 7030003400 S.RES ERJ3GEYJ 471 V (470) T 198.8/42.3
R5353 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 201.5/42.3
R5354 7030003400 S.RES ERJ3GEYJ 471 V (470) T 186.1/42.4
R5403 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 195.6/70.9
R5404 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 209.7/67.9
R5406 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 209.7/71.8
R5407 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 203.0/74.3
R5408 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 209.7/69.2
R5410 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 209.7/70.5
R5522 7030003370 S.RES ERJ3GEYJ 271 V (270) T 137.7/84.4
R5524 7030003320 S.RES ERJ3GEYJ 101 V (100) T 139.2/96.7
R5551 7030003320 S.RES ERJ3GEYJ 101 V (100) T 186.6/69.1
R5556 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 134.1/98.0
R5557 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 132.8/96.5
R5601 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 177.9/89.0
R5602 7030003320 S.RES ERJ3GEYJ 101 V (100) T 175.6/90.0
R5603 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 179.4/93.6
R5604 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 182.9/91.8
R5605 7030003320 S.RES ERJ3GEYJ 101 V (100) T 184.4/89.1
R5606 7030003380 S.RES ERJ3GEYJ 331 V (330) T 184.4/90.5
R5607 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 188.5/87.7
R5608 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 188.5/93.7
R5609 7030003320 S.RES ERJ3GEYJ 101 V (100) T 186.3/89.5
R5610 7030003360 S.RES ERJ3GEYJ 221 V (220) T 189.8/92.7
R5611 7030003290 S.RES ERJ3GEYJ 560 V (56) T 190.4/89.5
R5612 7030003380 S.RES ERJ3GEYJ 331 V (330) T 183.6/87.0
R5613 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 184.5/85.7
R5614 7030003350 S.RES ERJ3GEYJ 181 V (180) T 180.5/89.9
R5701 7030007220 S.RES ERA3YED 202V (2K) T 58.1/75.9
R5702 7030007230 S.RES ERA3YED 102V (1K) T 59.4/75.9
R5703 7030007230 S.RES ERA3YED 102V (1K) T 60.7/75.9
R5704 7030007230 S.RES ERA3YED 102V (1K) T 62.0/75.9
R5705 7030007230 S.RES ERA3YED 102V (1K) T 64.2/75.9
R5706 7030007230 S.RES ERA3YED 102V (1K) T 65.5/75.9
R5707 7030007230 S.RES ERA3YED 102V (1K) T 66.8/75.9
R5708 7030007210 S.RES ERA3YEB 102V (1K) T 68.1/75.9
R5709 7030007210 S.RES ERA3YEB 102V (1K) T 69.4/75.9
R5710 7030007210 S.RES ERA3YEB 102V (1K) T 69.4/81.3
R5711 7030007220 S.RES ERA3YED 202V (2K) T 57.6/78.5
R5712 7030007220 S.RES ERA3YED 202V (2K) T 59.0/78.5
R5713 7030007220 S.RES ERA3YED 202V (2K) T 60.3/78.5
R5714 7030007220 S.RES ERA3YED 202V (2K) T 61.6/78.5
R5715 7030007220 S.RES ERA3YED 202V (2K) T 64.2/78.5
R5716 7030007220 S.RES ERA3YED 202V (2K) T 65.5/78.5
R5717 7030007220 S.RES ERA3YED 202V (2K) T 66.8/78.5
R5718 7030007200 S.RES ERA3YEB 202V (2K) T 68.1/78.5
R5719 7030007200 S.RES ERA3YEB 202V (2K) T 69.4/78.5
R5720 7030007200 S.RES ERA3YEB 202V (2K) T 72.5/84.5
R5721 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 60.7/97.2
R5722 7030003320 S.RES ERJ3GEYJ 101 V (100) T 62.8/98.5
R5781 7030003410 S.RES ERJ3GEYJ 561 V (560) T 75.2/68.4
R5782 7030007860 S.RES ERJ3GEYJ 8R2V (8.2) T 73.8/66.9
R5783 7030003410 S.RES ERJ3GEYJ 561 V (560) T 75.4/69.7
R5799 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 72.4/72.1
R5801 7030007220 S.RES ERA3YED 202V (2K) [USA] T 23.4/91.6
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5802 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.4/90.3
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5803 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.4/89.0
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5804 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.4/87.7
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5805 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.4/85.1
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5806 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.4/83.8
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5807 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.4/82.5
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5808 7030007210 S.RES ERA3YEB 102V (1K) [USA] T 23.4/81.2
7030007210 S.RES ERA3YEB 102V (1K) [CAN]
7030007210 S.RES ERA3YEB 102V (1K) [CHN]
7030007210 S.RES ERA3YEB 102V (1K) [VNM]
R5809 7030007210 S.RES ERA3YEB 102V (1K) [USA] T 23.4/79.9
7030007210 S.RES ERA3YEB 102V (1K) [CAN]
7030007210 S.RES ERA3YEB 102V (1K) [CHN]
7030007210 S.RES ERA3YEB 102V (1K) [VNM]
R5810 7030007210 S.RES ERA3YEB 102V (1K) [USA] T 28.3/78.8
7030007210 S.RES ERA3YEB 102V (1K) [CAN]
7030007210 S.RES ERA3YEB 102V (1K) [CHN]
7030007210 S.RES ERA3YEB 102V (1K) [VNM]
R5811 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.0/91.6
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5812 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.0/90.3
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]

Nov. 2011
13
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
R5813 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.0/89.0
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5814 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.0/87.7
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5815 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.0/85.1
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5816 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.0/83.8
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5817 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.0/82.5
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5818 7030007200 S.RES ERA3YEB 202V (2K) [USA] T 26.0/81.2
7030007200 S.RES ERA3YEB 202V (2K) [CAN]
7030007200 S.RES ERA3YEB 202V (2K) [CHN]
7030007200 S.RES ERA3YEB 202V (2K) [VNM]
R5819 7030007200 S.RES ERA3YEB 202V (2K) [USA] T 26.0/79.9
7030007200 S.RES ERA3YEB 202V (2K) [CAN]
7030007200 S.RES ERA3YEB 202V (2K) [CHN]
7030007200 S.RES ERA3YEB 202V (2K) [VNM]
R5820 7030007200 S.RES ERA3YEB 202V (2K) [USA] T 32.0/75.4
7030007200 S.RES ERA3YEB 202V (2K) [CAN]
7030007200 S.RES ERA3YEB 202V (2K) [CHN]
7030007200 S.RES ERA3YEB 202V (2K) [VNM]
R5821 7030003800 S.RES ERJ3GEYJ 105 V (1M) [USA] T 44.7/88.0
7030003800 S.RES ERJ3GEYJ 105 V (1M) [CAN]
7030003800 S.RES ERJ3GEYJ 105 V (1M) [CHN]
7030003800 S.RES ERJ3GEYJ 105 V (1M) [VNM]
R5822 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 45.5/85.4
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R5881 7030000220 S.RES MCR10EZHJ 47 (470) [USA] T 12.9/91.1
7030000220 S.RES MCR10EZHJ 47 (470) [CAN]
7030000220 S.RES MCR10EZHJ 47 (470) [CHN]
7030000220 S.RES MCR10EZHJ 47 (470) [VNM]
R5882 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 10.3/85.8
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R5883 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [USA] T 13.2/86.3
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [CAN]
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [CHN]
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [VNM]
R5885 7030003370 S.RES ERJ3GEYJ 271 V (270) [USA] T 16.9/81.7
7030003370 S.RES ERJ3GEYJ 271 V (270) [CAN]
7030003370 S.RES ERJ3GEYJ 271 V (270) [CHN]
7030003370 S.RES ERJ3GEYJ 271 V (270) [VNM]
R5886 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 19.3/82.2
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
R5887 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [USA] T 19.3/79.5
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [CAN]
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [CHN]
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [VNM]
R5888 7030003280 S.RES ERJ3GEYJ 470 V (47) [USA] T 20.2/86.9
7030003280 S.RES ERJ3GEYJ 470 V (47) [CAN]
7030003280 S.RES ERJ3GEYJ 470 V (47) [CHN]
7030003280 S.RES ERJ3GEYJ 470 V (47) [VNM]
R5889 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [USA] T 19.3/76.7
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [CAN]
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [CHN]
7030003450 S.RES ERJ3GEYJ 122 V (1.2K) [VNM]
R5890 7030003410 S.RES ERJ3GEYJ 561 V (560) [USA] T 16.9/86.9
7030003410 S.RES ERJ3GEYJ 561 V (560) [CAN]
7030003410 S.RES ERJ3GEYJ 561 V (560) [CHN]
7030003410 S.RES ERJ3GEYJ 561 V (560) [VNM]
R5891 7030003410 S.RES ERJ3GEYJ 561 V (560) [USA] T 19.3/78.1
7030003410 S.RES ERJ3GEYJ 561 V (560) [CAN]
7030003410 S.RES ERJ3GEYJ 561 V (560) [CHN]
7030003410 S.RES ERJ3GEYJ 561 V (560) [VNM]
R5892 7030003260 S.RES ERJ3GEYJ 330 V (33) [USA] T 6.9/83.3
7030003260 S.RES ERJ3GEYJ 330 V (33) [CAN]
7030003260 S.RES ERJ3GEYJ 330 V (33) [CHN]
7030003260 S.RES ERJ3GEYJ 330 V (33) [VNM]
R5901 7030007220 S.RES ERA3YED 202V (2K) [USA] T 23.5/65.4
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5902 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.5/64.1
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5903 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.5/62.8
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5904 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.5/61.5
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5905 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.5/58.9
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
R5906 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.5/57.6
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5907 7030007230 S.RES ERA3YED 102V (1K) [USA] T 23.5/56.3
7030007230 S.RES ERA3YED 102V (1K) [CAN]
7030007230 S.RES ERA3YED 102V (1K) [CHN]
7030007230 S.RES ERA3YED 102V (1K) [VNM]
R5908 7030007210 S.RES ERA3YEB 102V (1K) [USA] T 23.5/55.0
7030007210 S.RES ERA3YEB 102V (1K) [CAN]
7030007210 S.RES ERA3YEB 102V (1K) [CHN]
7030007210 S.RES ERA3YEB 102V (1K) [VNM]
R5909 7030007210 S.RES ERA3YEB 102V (1K) [USA] T 23.5/53.7
7030007210 S.RES ERA3YEB 102V (1K) [CAN]
7030007210 S.RES ERA3YEB 102V (1K) [CHN]
7030007210 S.RES ERA3YEB 102V (1K) [VNM]
R5910 7030007210 S.RES ERA3YEB 102V (1K) [USA] T 28.4/52.6
7030007210 S.RES ERA3YEB 102V (1K) [CAN]
7030007210 S.RES ERA3YEB 102V (1K) [CHN]
7030007210 S.RES ERA3YEB 102V (1K) [VNM]
R5911 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.1/65.4
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5912 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.1/64.1
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5913 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.1/62.8
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5914 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.1/61.5
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5915 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.1/58.9
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5916 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.1/57.6
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5917 7030007220 S.RES ERA3YED 202V (2K) [USA] T 26.1/56.3
7030007220 S.RES ERA3YED 202V (2K) [CAN]
7030007220 S.RES ERA3YED 202V (2K) [CHN]
7030007220 S.RES ERA3YED 202V (2K) [VNM]
R5918 7030007200 S.RES ERA3YEB 202V (2K) [USA] T 26.1/55.0
7030007200 S.RES ERA3YEB 202V (2K) [CAN]
7030007200 S.RES ERA3YEB 202V (2K) [CHN]
7030007200 S.RES ERA3YEB 202V (2K) [VNM]
R5919 7030007200 S.RES ERA3YEB 202V (2K) [USA] T 26.1/53.7
7030007200 S.RES ERA3YEB 202V (2K) [CAN]
7030007200 S.RES ERA3YEB 202V (2K) [CHN]
7030007200 S.RES ERA3YEB 202V (2K) [VNM]
R5920 7030007200 S.RES ERA3YEB 202V (2K) [USA] T 32.4/49.1
7030007200 S.RES ERA3YEB 202V (2K) [CAN]
7030007200 S.RES ERA3YEB 202V (2K) [CHN]
7030007200 S.RES ERA3YEB 202V (2K) [VNM]
R5921 7030003800 S.RES ERJ3GEYJ 105 V (1M) [USA] T 44.8/61.6
7030003800 S.RES ERJ3GEYJ 105 V (1M) [CAN]
7030003800 S.RES ERJ3GEYJ 105 V (1M) [CHN]
7030003800 S.RES ERJ3GEYJ 105 V (1M) [VNM]
R5922 7030003320 S.RES ERJ3GEYJ 101 V (100) [USA] T 46.1/59.2
7030003320 S.RES ERJ3GEYJ 101 V (100) [CAN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [VNM]
R5982 7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA] T 21.4/50.4
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CAN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [VNM]
W5051 7030003860 S.RES ERJ3GE JPW V [USA] T 189.7/21.6
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]
W5052 7030003860 S.RES ERJ3GE JPW V [USA] T 200.7/21.6
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]
W5053 7030003860 S.RES ERJ3GE JPW V [USA] T 203.3/21.6
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]
W5054 7030003860 S.RES ERJ3GE JPW V [USA] T 214.3/21.6
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]
W5081 7030003860 S.RES ERJ3GE JPW V T 69.4/12.7
W5082 7030003860 S.RES ERJ3GE JPW V T 67.7/14.2
W5203 7030003860 S.RES ERJ3GE JPW V [USA] T 124.3/61.3
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]
W5251 7030003860 S.RES ERJ3GE JPW V T 99.8/85.5
W5401 7030003860 S.RES ERJ3GE JPW V T 203.0/72.9
W5402 7030003860 S.RES ERJ3GE JPW V T 198.3/70.9
W5409 7030003860 S.RES ERJ3GE JPW V T 191.6/74.1
W5502 7030003860 S.RES ERJ3GE JPW V T 136.8/86.3
W5981 7030003860 S.RES ERJ3GE JPW V [USA] T 18.0/49.1
7030003860 S.RES ERJ3GE JPW V [CAN]
7030003860 S.RES ERJ3GE JPW V [CHN]
7030003860 S.RES ERJ3GE JPW V [VNM]

Nov. 2011
14
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
C5021 4510008520 S.ELE EEE1CA470SP T 59.2/56.6
C5022 4030011600 S.CER C1608 JB 1E 104K-T T 66.1/50.2
C5023 4030011600 S.CER C1608 JB 1E 104K-T T 70.7/52.5
C5024 4510008990 S.ELE EEE1AA470WR T 73.0/57.2
C5031 4510008520 S.ELE EEE1CA470SP T 30.0/38.3
C5032 4030011600 S.CER C1608 JB 1E 104K-T T 33.0/33.3
C5033 4030011600 S.CER C1608 JB 1E 104K-T T 42.5/33.8
C5034 4510008990 S.ELE EEE1AA470WR T 44.0/38.8
C5051 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 202.0/13.7
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5052 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 214.3/13.7
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5053 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 203.3/13.7
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5055 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 189.7/13.7
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5081 4030006880 S.CER C1608 JB 1H 472K-T T 24.7/12.3
C5082 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 7.9/11.1
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5083 4030006900 S.CER C1608 JB 1H 103K-T T 48.1/9.3
C5084 4030006900 S.CER C1608 JB 1H 103K-T T 83.0/7.8
C5085 4030008680 S.CER C2012 JF 1C 105Z-T T 33.4/12.7
C5086 4030008680 S.CER C2012 JF 1C 105Z-T T 36.8/12.7
C5087 4030008680 S.CER C2012 JF 1C 105Z-T T 40.1/12.7
C5088 4030008680 S.CER C2012 JF 1C 105Z-T T 30.9/17.6
C5089 4030006900 S.CER C1608 JB 1H 103K-T T 7.4/20.7
C5090 4030008680 S.CER C2012 JF 1C 105Z-T T 33.0/21.7
C5091 4030006900 S.CER C1608 JB 1H 103K-T T 44.4/15.6
C5092 4030006880 S.CER C1608 JB 1H 472K-T T 83.1/4.4
C5093 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 12.1/15.4
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5101 4030007060 S.CER C1608 CH 1H 270J-T T 146.4/52.9
C5102 4030007010 S.CER C1608 CH 1H 100D-T T 147.6/54.8
C5103 4030006960 S.CER C1608 CH 1H 050C-T T 147.6/57.5
C5104 4030006880 S.CER C1608 JB 1H 472K-T T 156.7/44.5
C5105 4030006860 S.CER C1608 JB 1H 102K-T T 163.5/40.1
C5106 4030006880 S.CER C1608 JB 1H 472K-T T 148.6/41.1
C5107 4030006880 S.CER C1608 JB 1H 472K-T T 150.8/38.9
C5108 4030006880 S.CER C1608 JB 1H 472K-T T 142.6/38.8
C5110 4510008540 S.ELE EEE1CA100SR T 172.4/37.7
C5111 4030006880 S.CER C1608 JB 1H 472K-T T 172.4/67.8
C5112 4030007090 S.CER C1608 CH 1H 470J-T T 168.3/56.9
C5113 4030006880 S.CER C1608 JB 1H 472K-T T 170.3/52.6
C5115 4030006880 S.CER C1608 JB 1H 472K-T T 169.0/52.6
C5116 4510008520 S.ELE EEE1CA470SP T 171.9/47.3
C5117 4030006880 S.CER C1608 JB 1H 472K-T T 168.6/61.1
C5118 4030006880 S.CER C1608 JB 1H 472K-T T 169.9/61.1
C5120 4030006880 S.CER C1608 JB 1H 472K-T T 161.1/49.3
C5121 4030006880 S.CER C1608 JB 1H 472K-T T 159.3/49.3
C5122 4030006880 S.CER C1608 JB 1H 472K-T T 156.9/49.4
C5123 4030006880 S.CER C1608 JB 1H 472K-T T 151.9/49.2
C5124 4030006880 S.CER C1608 JB 1H 472K-T T 150.3/69.2
C5125 4030011600 S.CER C1608 JB 1E 104K-T T 148.2/66.2
C5126 4030011600 S.CER C1608 JB 1E 104K-T T 149.1/52.4
C5201 4030006860 S.CER C1608 JB 1H 102K-T T 127.3/55.9
C5202 4030006860 S.CER C1608 JB 1H 102K-T T 123.6/59.2
C5203 4030006880 S.CER C1608 JB 1H 472K-T T 120.9/53.5
C5204 4030006880 S.CER C1608 JB 1H 472K-T T 120.9/55.1
C5205 4030007030 S.CER C1608 CH 1H 150J-T T 125.0/53.5
C5206 4030006910 S.CER C1608 CH 1H 0R5C-T T 119.9/45.5
C5207 4030007030 S.CER C1608 CH 1H 150J-T T 119.9/40.8
C5251 4030007130 S.CER C1608 CH 1H 101J-T [USA] T 98.1/89.4
4030007130 S.CER C1608 CH 1H 101J-T [CAN]
4030007130 S.CER C1608 CH 1H 101J-T [CHN]
4030007130 S.CER C1608 CH 1H 101J-T [VNM]
C5253 4030006880 S.CER C1608 JB 1H 472K-T T 82.0/93.7
C5254 4510008540 S.ELE EEE1CA100SR T 84.4/97.6
C5281 4030006880 S.CER C1608 JB 1H 472K-T T 103.1/79.1
C5282 4030006860 S.CER C1608 JB 1H 102K-T T 101.8/81.9
C5283 4030006880 S.CER C1608 JB 1H 472K-T T 111.4/86.8
C5301 4550000730 S.TAN TEESVA 0J 225M8R T 187.7/56.3
C5302 4030006880 S.CER C1608 JB 1H 472K-T T 172.0/57.6
C5303 4030009650 S.CER C1608 CH 1H 240J-T T 184.2/46.5
C5304 4030011570 S.CER CM105 CH 101G 50AT T 189.8/48.8
C5305 4610001850 S.TRI TZB4R200AB10R00
(TZBX4R200BA110) T 186.8/49.9
C5306 4030007150 S.CER C1608 CH 1H 151J-T T 191.1/48.8
C5307 4030007150 S.CER C1608 CH 1H 151J-T T 191.1/52.8
C5308 4030007150 S.CER C1608 CH 1H 151J-T T 190.1/55.0
C5309 4030006880 S.CER C1608 JB 1H 472K-T T 190.1/57.6
C5310 4030007010 S.CER C1608 CH 1H 100D-T T 197.1/54.7
C5311 4030006880 S.CER C1608 JB 1H 472K-T T 205.8/53.6
C5312 4510008540 S.ELE EEE1CA100SR T 207.8/57.5
C5313 4030006880 S.CER C1608 JB 1H 472K-T T 203.8/53.1
C5314 4030006880 S.CER C1608 JB 1H 472K-T T 204.5/49.5
C5315 4030006880 S.CER C1608 JB 1H 472K-T T 205.8/49.5
C5351 4030006880 S.CER C1608 JB 1H 472K-T T 203.2/46.2
C5352 4030006880 S.CER C1608 JB 1H 472K-T T 195.0/42.4
C5353 4030006880 S.CER C1608 JB 1H 472K-T T 203.0/42.3
C5354 4030010000 S.CER C1608 CH 1H 510J-T T 193.7/42.4
C5355 4030006960 S.CER C1608 CH 1H 050C-T T 190.7/43.7
C5356 4030010000 S.CER C1608 CH 1H 510J-T T 187.8/42.4
C5357 4030006880 S.CER C1608 JB 1H 472K-T T 184.6/42.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
C5401 4030011600 S.CER C1608 JB 1E 104K-T T 196.9/67.0
C5402 4030006860 S.CER C1608 JB 1H 102K-T T 196.9/68.3
C5403 4030006900 S.CER C1608 JB 1H 103K-T T 198.8/68.8
C5404 4030006880 S.CER C1608 JB 1H 472K-T T 196.6/69.6
C5408 4550005980 S.TAN TEESVA 1A 475M8R T 199.0/73.9
C5521 4610001830 S.TRI TZB4S100AB10R00
(TZBX4N100BA110) T 145.6/95.0
C5522 4030007130 S.CER C1608 CH 1H 101J-T T 143.9/89.8
C5523 4030007010 S.CER C1608 CH 1H 100D-T T 139.7/92.6
C5524 4030006880 S.CER C1608 JB 1H 472K-T T 144.7/88.4
C5525 4030006870 S.CER C1608 JB 1H 222K-T T 138.1/86.3
C5526 4030009510 S.CER C1608 CH 1H 010B-T T 141.7/88.4
C5528 4030006860 S.CER C1608 JB 1H 102K-T T 144.5/91.5
C5529 4030011340 S.CER C1608 CH 1H 471J-T T 140.5/95.2
C5551 4550005980 S.TAN TEESVA 1A 475M8R T 187.1/72.6
C5552 4550003250 S.TAN TEESVA 1V 474M8R T 181.6/72.7
C5556 4030006860 S.CER C1608 JB 1H 102K-T T 150.1/98.0
C5557 4030011600 S.CER C1608 JB 1E 104K-T T 148.8/98.0
C5558 4510004591 ELE 16 ME 470 HC
C5560 4510008660 S.ELE EEE0JA220SR T 129.7/95.2
C5561 4030011340 S.CER C1608 CH 1H 471J-T T 137.9/96.7
C5601 4030006880 S.CER C1608 JB 1H 472K-T T 176.2/93.0
C5602 4030006860 S.CER C1608 JB 1H 102K-T T 175.5/87.8
C5603 4030006880 S.CER C1608 JB 1H 472K-T T 182.3/89.9
C5604 4030006880 S.CER C1608 JB 1H 472K-T T 178.5/83.8
C5605 4030006880 S.CER C1608 JB 1H 472K-T T 184.5/93.7
C5606 4030006860 S.CER C1608 JB 1H 102K-T T 187.3/91.5
C5607 4030006880 S.CER C1608 JB 1H 472K-T T 186.4/86.3
C5608 4030006880 S.CER C1608 JB 1H 472K-T T 187.2/93.7
C5609 4030007090 S.CER C1608 CH 1H 470J-T T 190.4/86.9
C5610 4030011280 S.CER C1608 CH 1H 271J-T T 192.2/89.3
C5611 4030007090 S.CER C1608 CH 1H 470J-T T 193.1/87.1
C5612 4030007060 S.CER C1608 CH 1H 270J-T T 194.3/93.9
C5613 4030007020 S.CER C1608 CH 1H 120J-T T 195.7/87.1
C5614 4030007060 S.CER C1608 CH 1H 270J-T T 195.6/93.9
C5615 4030006980 S.CER C1608 CH 1H 070D-T T 198.0/89.3
C5616 4030007040 S.CER C1608 CH 1H 180J-T T 200.0/92.1
C5617 4030006860 S.CER C1608 JB 1H 102K-T T 187.9/85.5
C5618 4030006880 S.CER C1608 JB 1H 472K-T T 182.9/83.9
C5619 4030006930 S.CER C1608 CH 1H 020C-T T 180.8/88.1
C5701 4030006880 S.CER C1608 JB 1H 472K-T T 56.4/88.0
C5702 4030006880 S.CER C1608 JB 1H 472K-T T 72.0/86.4
C5703 4030006880 S.CER C1608 JB 1H 472K-T T 62.9/78.5
C5704 4030006880 S.CER C1608 JB 1H 472K-T T 70.1/94.9
C5705 4030006880 S.CER C1608 JB 1H 472K-T T 57.7/95.0
C5706 4030006880 S.CER C1608 JB 1H 472K-T T 64.9/96.6
C5707 4030006880 S.CER C1608 JB 1H 472K-T T 72.7/94.0
C5708 4510008490 S.ELE EEE1CS100SR T 69.5/98.3
C5709 4030006880 S.CER C1608 JB 1H 472K-T T 56.2/93.7
C5710 4030006860 S.CER C1608 JB 1H 102K-T T 60.9/99.6
C5711 4030007010 S.CER C1608 CH 1H 100D-T T 56.9/99.6
C5781 4030008770 S.CER C1608 JB 1H 562K-T T 73.2/74.2
C5782 4030009490 S.CER C1608 JB 1H 821K-T T 75.8/74.2
C5783 4030006900 S.CER C1608 JB 1H 103K-T T 72.6/75.5
C5784 4030009980 S.CER C1608 JB 1H 152K-T T 73.4/77.4
C5785 4030006900 S.CER C1608 JB 1H 103K-T T 74.8/79.9
C5794 4030008920 S.CER C1608 JB 1H 473K-T T 73.1/69.2
C5801 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 35.5/91.6
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5802 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 34.2/75.9
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5803 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 26.0/86.4
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5804 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 42.4/77.9
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5805 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 42.1/90.7
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5806 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 44.2/83.2
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5807 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 39.8/74.9
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5808 4510008490 S.ELE EEE1CS100SR [USA] T 45.7/77.1
4510008490 S.ELE EEE1CS100SR [CAN]
4510008490 S.ELE EEE1CS100SR [CHN]
4510008490 S.ELE EEE1CS100SR [VNM]
C5809 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 40.8/92.2
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5810 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 46.7/87.2
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C5811 4030007010 S.CER C1608 CH 1H 100D-T [USA] T 46.7/91.1
4030007010 S.CER C1608 CH 1H 100D-T [CAN]
4030007010 S.CER C1608 CH 1H 100D-T [CHN]
4030007010 S.CER C1608 CH 1H 100D-T [VNM]
C5881 4030008920 S.CER C1608 JB 1H 473K-T [USA] T 13.2/88.8
4030008920 S.CER C1608 JB 1H 473K-T [CAN]
4030008920 S.CER C1608 JB 1H 473K-T [CHN]
4030008920 S.CER C1608 JB 1H 473K-T [VNM]

Nov. 2011
15
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
C5882 4030007020 S.CER C1608 CH 1H 120J-T [USA] T 18.2/86.9
4030007020 S.CER C1608 CH 1H 120J-T [CAN]
4030007020 S.CER C1608 CH 1H 120J-T [CHN]
4030007020 S.CER C1608 CH 1H 120J-T [VNM]
C5883 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 19.3/80.9
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5884 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 17.1/77.4
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5885 4030006980 S.CER C1608 CH 1H 070D-T [USA] T 21.7/75.8
4030006980 S.CER C1608 CH 1H 070D-T [CAN]
4030006980 S.CER C1608 CH 1H 070D-T [CHN]
4030006980 S.CER C1608 CH 1H 070D-T [VNM]
C5886 4030009500 S.CER C1608 CH 1H 0R5B-T [USA] T 21.7/73.1
4030009500 S.CER C1608 CH 1H 0R5B-T [CAN]
4030009500 S.CER C1608 CH 1H 0R5B-T [CHN]
4030009500 S.CER C1608 CH 1H 0R5B-T [VNM]
C5887 4030006980 S.CER C1608 CH 1H 070D-T [USA] T 23.1/76.1
4030006980 S.CER C1608 CH 1H 070D-T [CAN]
4030006980 S.CER C1608 CH 1H 070D-T [CHN]
4030006980 S.CER C1608 CH 1H 070D-T [VNM]
C5888 4030009510 S.CER C1608 CH 1H 010B-T [USA] T 25.3/75.4
4030009510 S.CER C1608 CH 1H 010B-T [CAN]
4030009510 S.CER C1608 CH 1H 010B-T [CHN]
4030009510 S.CER C1608 CH 1H 010B-T [VNM]
C5889 4030011770 S.CER C1608 CH 1H 060B-T [USA] T 27.5/75.0
4030011770 S.CER C1608 CH 1H 060B-T [CAN]
4030011770 S.CER C1608 CH 1H 060B-T [CHN]
4030011770 S.CER C1608 CH 1H 060B-T [VNM]
C5890 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 8.2/85.0
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5891 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 16.9/84.3
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5892 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 11.0/92.5
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5893 4030007150 S.CER C1608 CH 1H 151J-T [USA] T 5.6/82.7
4030007150 S.CER C1608 CH 1H 151J-T [CAN]
4030007150 S.CER C1608 CH 1H 151J-T [CHN]
4030007150 S.CER C1608 CH 1H 151J-T [VNM]
C5901 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 26.1/60.2
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5902 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 34.4/49.6
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5903 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 35.6/65.4
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5904 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 42.5/51.7
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5905 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 42.2/64.3
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5906 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 44.2/57.0
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5907 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 39.9/48.6
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5908 4510008490 S.ELE EEE1CS100SR [USA] T 45.9/50.9
4510008490 S.ELE EEE1CS100SR [CAN]
4510008490 S.ELE EEE1CS100SR [CHN]
4510008490 S.ELE EEE1CS100SR [VNM]
C5909 4030006880 S.CER C1608 JB 1H 472K-T [USA] T 40.9/66.0
4030006880 S.CER C1608 JB 1H 472K-T [CAN]
4030006880 S.CER C1608 JB 1H 472K-T [CHN]
4030006880 S.CER C1608 JB 1H 472K-T [VNM]
C5910 4030006860 S.CER C1608 JB 1H 102K-T [USA] T 46.8/61.0
4030006860 S.CER C1608 JB 1H 102K-T [CAN]
4030006860 S.CER C1608 JB 1H 102K-T [CHN]
4030006860 S.CER C1608 JB 1H 102K-T [VNM]
C5911 4030007010 S.CER C1608 CH 1H 100D-T [USA] T 46.8/65.1
4030007010 S.CER C1608 CH 1H 100D-T [CAN]
4030007010 S.CER C1608 CH 1H 100D-T [CHN]
4030007010 S.CER C1608 CH 1H 100D-T [VNM]
C5981 4030011600 S.CER C1608 JB 1E 104K-T [USA] T 18.7/50.4
4030011600 S.CER C1608 JB 1E 104K-T [CAN]
4030011600 S.CER C1608 JB 1E 104K-T [CHN]
4030011600 S.CER C1608 JB 1E 104K-T [VNM]
C5982 4030007020 S.CER C1608 CH 1H 120J-T [USA] T 23.4/49.7
4030007020 S.CER C1608 CH 1H 120J-T [CAN]
4030007020 S.CER C1608 CH 1H 120J-T [CHN]
4030007020 S.CER C1608 CH 1H 120J-T [VNM]
C5983 4030009520 S.CER C1608 CH 1H 020B-T [USA] T 23.4/47.0
4030009520 S.CER C1608 CH 1H 020B-T [CAN]
4030009520 S.CER C1608 CH 1H 020B-T [CHN]
4030009520 S.CER C1608 CH 1H 020B-T [VNM]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL UNIT]
C5984 4030007050 S.CER C1608 CH 1H 220J-T [USA] T 25.5/50.5
4030007050 S.CER C1608 CH 1H 220J-T [CAN]
4030007050 S.CER C1608 CH 1H 220J-T [CHN]
4030007050 S.CER C1608 CH 1H 220J-T [VNM]
C5985 4030009530 S.CER C1608 CH 1H 030B-T [USA] T 25.5/49.2
4030009530 S.CER C1608 CH 1H 030B-T [CAN]
4030009530 S.CER C1608 CH 1H 030B-T [CHN]
4030009530 S.CER C1608 CH 1H 030B-T [VNM]
C5986 4030009990 S.CER C1608 CH 1H 200J-T [USA] T 27.5/49.8
4030009990 S.CER C1608 CH 1H 200J-T [CAN]
4030009990 S.CER C1608 CH 1H 200J-T [CHN]
4030009990 S.CER C1608 CH 1H 200J-T [VNM]
RL5081 6330001640 REL ATX209
J5001 6510022581 S.CON 24FMN-BMTTR-A-TBT(LF)(SN) T 78.0/29.5
J5051 6510023120 CON CD6109SA1J0 <CVI> [USA]
6510023120 CON CD6109SA1J0 <CVI> [CAN]
6510023120 CON CD6109SA1J0 <CVI> [CHN]
6510023120 CON CD6109SA1J0 <CVI> [VNM]
J5071 6510021722 S.CON 30FLT-SM2-TB(LF)(SN)(M) T 108.5/20.3
J5081 6510023120 CON CD6109SA1J0 <CVI>
J5091 6510023040 CON 01K1621 [USA]
6510023040 CON 01K1621 [CAN]
6510023040 CON 01K1621 [CHN]
6510023040 CON 01K1621 [VNM]

Nov. 2011
16
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PA UNIT]
IC6501 1110005450 S.IC TS522IDT T 114.0/15.8
IC6601 1180001252 S.IC TA7808F(TE16L1NQ) T 121.4/77.5
Q6101 1560001020 S.FET 2SK2973 (MTS101P) T 171.4/48.2
Q6401 1590003040 TRA SD1487 <AMSC>
Q6402 1590003040 TRA SD1487 <AMSC>
Q6403 1540000641 TRA 2SD2012(F)
Q6501 1540000550 S.TRA 2SD1664 T100Q T 36.6/74.0
Q6601 1510001040 S.TRA 2SA1037AKT146S T 144.2/68.6
Q6602 1590000680 S.TRA DTC114EUA T106 T 141.0/72.7
Q6701 1590000680 S.TRA DTC114EUA T106 T 169.3/8.3
Q6801 1590003051 S.FET PD55003-E T 159.5/58.0
D6601 1710001161 S.DIO DF40SC4-7072 T 14.4/62.8
D6701 1160000140 S.DIO DAP222 TL T 169.8/11.0
D6702 1730000481 S.ZEN RD10M-T2B-A B3 T 66.0/9.5
L6101 6200003840 S.COI MLF2012D R22K-T T 180.05/45.5
L6102 6180000990 COI LAL 04NA 101K
L6202 6180001240 COI LAL 04NA 820K
L6204 2040000490 COI EXC-ELDR25C
L6301 6140003720 COI LR-416 <KN>
L6303 2040000490 COI EXC-ELDR25C
L6401 2040000490 COI EXC-ELDR25C
L6402 2040000490 COI EXC-ELDR25C
L6403 2040000490 COI EXC-ELDR25C
L6404 6140003590 COI LR-400 (TR10X5X5 6H3)
L6405 6140003350 COI LR-376
L6406 6140002030 COI LR-230 (SK-10M-15Y 120)
L6407 2040000490 COI EXC-ELDR25C
L6408 6110001730 COI LA-262
L6501 6200003261 S.COI NLV32T-101J T 100.0/13.0
L6701 6200003590 S.COI EXCCL3225U1 T 114.8/6.5
L6702 6200002041 S.COI NLV25T-101J T 86.5/9.3
L6703 6200003261 S.COI NLV32T-101J T 177.1/73.8
L6704 6200003261 S.COI NLV32T-101J T 177.1/70.7
L6705 6200008820 S.COI HF70ACC 635050-T T 166.7/72.0
L6706 6200008820 S.COI HF70ACC 635050-T T 174.6/64.3
R6101 7030003270 S.RES ERJ3GEYJ 390 V (39) T 180.3/42.6
R6102 7030003350 S.RES ERJ3GEYJ 181 V (180) T 182.1/41.8
R6103 7030003350 S.RES ERJ3GEYJ 181 V (180) T 182.1/43.3
R6104 7030003300 S.RES ERJ3GEYJ 680 V (68) T 176.1/47.1
R6105 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 178.0/47.7
R6106 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 176.1/49.7
R6107 7030003420 S.RES ERJ3GEYJ 681 V (680) T 174.8/49.7
R6109 7030003400 S.RES ERJ3GEYJ 471 V (470) T 174.0/51.7
R6110 7030000210 S.RES MCR10EZHJ 39 (390) T 173.4/54.6
R6111 7030000210 S.RES MCR10EZHJ 39 (390) T 172.9/56.3
R6112 7030000210 S.RES MCR10EZHJ 39 (390) T 172.7/58.1
R6201 7030000250 S.RES MCR10EZHJ 82 (820) T 166.2/50.6
R6202 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 165.8/46.6
R6203 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 166.5/48.4
R6204 7030010800 S.RES ERJ1TYJ 2R7U (2.7) T 155.2/45.1
R6206 7030000340 S.RES MCR10EZHJ 470 (471) T 154.3/71.5
R6301 7030000260 S.RES MCR10EZHJ 100 (101) T 147.8/48.5
R6302 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 148.3/44.0
R6303 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 148.3/42.5
R6304 7310005250 TRI VM5CK-PVB 3K
R6401 7030010260 S.RES ERJ1TYJ 3R3 U T 94.0/17.5
R6402 7030010260 S.RES ERJ1TYJ 3R3 U T 94.0/21.5
R6403 7030010260 S.RES ERJ1TYJ 3R3 U T 94.5/25.5
R6404 7030010260 S.RES ERJ1TYJ 3R3 U T 94.0/72.5
R6405 7030010260 S.RES ERJ1TYJ 3R3 U T 94.0/68.5
R6406 7030010260 S.RES ERJ1TYJ 3R3 U T 94.5/64.5
R6407 7030001010 S.RES MCR50JZHJ 10 (100) T 84.3/31.5
R6408 7030001010 S.RES MCR50JZHJ 10 (100) T 84.2/56.9
R6409 7070000371 RES ERX2SJ 2R2 (2.2)
R6410 7070000371 RES ERX2SJ 2R2 (2.2)
R6411 7070000521 RES ERX3SJ 2R7 (2.7)
R6412 7310005200 TRI VM5CK-PVB 2K
R6413 7030000300 S.RES MCR10EZHJ 220 (221) T 134.3/19.0
R6415 7070001030 RES ERG5SJ 470
R6502 7030005981 S.RES ERA3YED 333V (33K) T 121.3/13.3
R6503 7030005981 S.RES ERA3YED 333V (33K) T 120.3/16.8
R6504 7030005971 S.RES ERA3YKD 683V (68K) T 122.0/19.7
R6505 7030005971 S.RES ERA3YKD 683V (68K) T 119.0/18.2
R6507 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) T 118.3/13.0
R6509 7030003320 S.RES ERJ3GEYJ 101 V (100) T 116.0/12.3
R6510 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 107.5/14.8
R6512 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 109.3/18.3
R6513 7030003740 S.RES ERJ3GEYJ 334 V (330K) T 109.5/14.8
R6514 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 107.3/18.3
R6515 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 103.0/13.0
R6516 7310005230 TRI VM5CK-PVB 10K
R6517 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 105.7/14.5
R6602 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 142.1/70.8
R6603 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 142.0/68.6
R6604 7030003580 S.RES ERJ3GEYJ 153 V (15K) T 138.8/71.8
R6702 7030003420 S.RES ERJ3GEYJ 681 V (680) T 63.2/7.7
R6704 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) T 66.0/7.0
R6705 7510001551 S.THE NTCG16 4LH 333JT T 66.0/12.1
R6801 7030003410 S.RES ERJ3GEYJ 561 V (560) T 157.8/67.5
R6802 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 168.8/57.5
W6701 7030008240 S.RES ERJ12Y0R00U T 180.6/59.2
C6101 4030007120 S.CER C1608 CH 1H 820J-T T 182.1/44.6
C6102 4030007120 S.CER C1608 CH 1H 820J-T T 182.1/46.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PA UNIT]
C6103 4030011600 S.CER C1608 JB 1E 104K-T T 178.0/46.4
C6104 4030011600 S.CER C1608 JB 1E 104K-T T 178.0/49.0
C6105 4030011600 S.CER C1608 JB 1E 104K-T T 174.8/47.1
C6106 4030011600 S.CER C1608 JB 1E 104K-T T 178.0/50.5
C6108 4030011600 S.CER C1608 JB 1E 104K-T T 168.0/46.4
C6109 4030005110 S.CER C2012 JB 1E 473K-T T 177.2/53.0
C6201 4030011600 S.CER C1608 JB 1E 104K-T T 168.6/50.1
C6202 4030011600 S.CER C1608 JB 1E 104K-T T 164.5/47.7
C6203 4030004750 S.CER C2012 JB 1H 103K-T T 160.0/47.0
C6205 4030008700 S.CER GRM21BB11H473KA01L
(GRM40 B) T 151.3/48.0
C6206 4030008700 S.CER GRM21BB11H473KA01L
(GRM40 B) T 147.0/74.3
C6301 4030008960 S.CER C2012 JB 1C 104K-T T 148.7/52.7
C6302 4030011600 S.CER C1608 JB 1E 104K-T T 148.3/45.5
C6303 4510004591 ELE 16 ME 470 HC
C6305 4030011600 S.CER C1608 JB 1E 104K-T T 111.8/60.2
C6306 4510004601 ELE 16 ME 1000 HC
C6307 4320000220 DIP DM19C 681J5
C6308 4030011790 S.CER GRM55RF52A684ZD01L
(GRM44-1) T 124.9/57.1
C6401 4030011760 S.CER GRM55R1X2D682JV01L
(GRM44-1) T 94.5/33.5
C6403 4030011760 S.CER GRM55R1X2D682JV01L
(GRM44-1) T 94.5/56.5
C6407 4030018370 S.CER ERF22X 6C1H 102J D01L T 61.5/44.9
C6408 4030018370 S.CER ERF22X 6C1H 102J D01L T 64.8/44.9
C6412 4510004601 ELE 16 ME 1000 HC
C6413 4510004601 ELE 16 ME 1000 HC
C6414 4030004740 S.CER C2012 JB 1H 472K-T T 5.2/19.1
C6415 4030011790 S.CER GRM55RF52A684ZD01L
(GRM44-1) T 41.0/23.3
C6416 4030008920 S.CER C1608 JB 1H 473K-T T 126.5/24.5
C6417 4510004601 ELE 16 ME 1000 HC
C6418 4030006880 S.CER C1608 JB 1H 472K-T T 126.5/23.2
C6419 4030006880 S.CER C1608 JB 1H 472K-T T 132.8/12.0
C6424 4030018370 S.CER ERF22X 6C1H 102J D01L T 95.0/45.1
C6425 4320000220 DIP DM19C 681J5
C6427 4030011600 S.CER C1608 JB 1E 104K-T T 150.5/24.5
C6428 4030011600 S.CER C1608 JB 1E 104K-T T 85.2/81.3
C6432 4030011740 S.CER GRM32N2C2H201JV01L
(GRM42-2 CH) T 62.5/13.4
C6433 4030011740 S.CER GRM32N2C2H201JV01L
(GRM42-2 CH) T 60.7/78.9
C6501 4030007130 S.CER C1608 CH 1H 101J-T T 118.3/16.0
C6503 4030011600 S.CER C1608 JB 1E 104K-T T 112.8/12.3
C6506 4030011600 S.CER C1608 JB 1E 104K-T T 30.9/83.8
C6507 4510004591 ELE 16 ME 470 HC
C6602 4030006880 S.CER C1608 JB 1H 472K-T T 140.6/68.6
C6603 4510004591 ELE 16 ME 470 HC
C6604 4510009150 S.ELE EEE1EA470WP T 106.0/72.5
C6605 4030011600 S.CER C1608 JB 1E 104K-T T 111.3/76.0
C6606 4030011600 S.CER C1608 JB 1E 104K-T T 111.3/79.0
C6607 4510009150 S.ELE EEE1EA470WP T 106.0/81.0
C6608 4030008700 S.CER GRM21BB11H473KA01L
(GRM40 B) T 56.1/5.7
C6609 4510006021 ELE 16 ME 2200 HC
C6610 4030017320 S.CER GRM21BB11H104KA01L
(GRM40-034) T 9.3/77.8
C6611 4030004740 S.CER C2012 JB 1H 472K-T T 9.3/75.5
C6612 4030004720 S.CER C2012 JB 1H 102K-T T 12.1/79.2
C6701 4030008920 S.CER C1608 JB 1H 473K-T T 166.5/11.0
C6702 4030008920 S.CER C1608 JB 1H 473K-T T 61.4/8.5
C6703 4030008920 S.CER C1608 JB 1H 473K-T T 66.0/5.5
C6704 4030006880 S.CER C1608 JB 1H 472K-T T 86.5/11.3
C6705 4030006880 S.CER C1608 JB 1H 472K-T T 111.8/6.5
C6706 4030006880 S.CER C1608 JB 1H 472K-T T 160.8/72.6
C6707 4030006880 S.CER C1608 JB 1H 472K-T T 173.7/71.3
C6708 4030006880 S.CER C1608 JB 1H 472K-T T 173.7/74.4
C6801 4030011600 S.CER C1608 JB 1E 104K-T T 160.5/67.5
RL6701 6330001471 REL AJS1311F-K2
J6301 6510021531 CON IMSA-9230B-1-04Z024-PT1
J6302 6510021531 CON IMSA-9230B-1-04Z024-PT1
J6401 6510028210 CON SJ050010 (TMP-J01X-V6)
J6411 6510021391 CON IMSA-9230B-1-03Z024-PT1
J6412 6510021391 CON IMSA-9230B-1-03Z024-PT1
J6501 6510003391 CON B03B-EH-S(LF)(SN)
J6701 6510022541 S.CON 20FMN-BMTTR-A-TBT(LF)(SN) T 99.5/8.3
J6702 6510028210 CON SJ050010 (TMP-J01X-V6)
J6703 6510003401 CON B04B-EH-S(LF)(SN)
F6701 5210000061 FUS FGB 5A PBF (FGB0 125V)
F6702 5220000230 HOL S-N5054 #01
F6703 5220000230 HOL S-N5054 #01
W6401 9054500690 WIR 76/98/020/X98/X98
W6402 9054500690 WIR 76/98/020/X98/X98
W6601 9045201001 WIR 74/98/040/X98/X98
EP6601 6910000630 BEA FSRH070140RN000B
(FSOH070RN)
EP6602 6510018330 TER F4053A
EP6603 6510018330 TER F4053A

Nov. 2011
17
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[FILTER UNIT]
Q7301 1590000680 S.TRA DTC114EUA T106 B 140.2/88.4
D7271 1750000191 S.DIO 1SS322(TE85RF) B 162.2/81.9
D7272 1750000191 S.DIO 1SS322(TE85RF) B 162.2/85.5
D7301 1750000550 S.DIO 1SS355 TE-17 B 137.2/92.4
L7031 6200002041 S.COI NLV25T-101J B 157.5/59.6
L7035 6200002041 S.COI NLV25T-101J B 149.5/4.5
L7036 6140002830 COI LR-236 <KN>
L7037 6140001990 COI LR-226 (T68-2)
L7038 6140002000 COI LR-227 (T68-2)
L7061 6200002041 S.COI NLV25T-101J B 116.4/64.3
L7065 6200002041 S.COI NLV25T-101J B 129.2/14.9
L7066 6140002900 COI LR-263 <KN>
L7067 6140002820 COI LR-235 <KN>
L7068 6140002830 COI LR-236 <KN>
L7091 6200002041 S.COI NLV25T-101J B 97.1/83.8
L7095 6200002041 S.COI NLV25T-101J B 111.9/15.5
L7096 6140002850 COI LR-238 KN>
L7097 6140002820 COI LR-235 <KN>
L7098 6140002820 COI LR-235 <KN>
L7121 6200002041 S.COI NLV25T-101J B 80.7/80.8
L7125 6200002041 S.COI NLV25T-101J B 97.2/16.0
L7126 6140002840 COI LR-237 <KN>
L7127 6140002900 COI LR-263 <KN>
L7128 6140002900 COI LR-263 <KN>
L7151 6200005051 S.COI NLV25T-330J B 65.5/82.4
L7155 6200005051 S.COI NLV25T-330J B 70.3/28.9
L7156 6140002860 COI LR-241 KN>
L7157 6140002840 COI LR-237 <KN>
L7158 6140002840 COI LR-237 <KN>
L7181 6200005051 S.COI NLV25T-330J B 51.4/89.7
L7182 6140003580 COI LR-399(3.5%)
L7183 6140003570 COI LR-398 (3.5%)
L7184 6140003570 COI LR-398 (3.5%)
L7185 6200005051 S.COI NLV25T-330J B 52.8/14.9
L7211 6200005011 S.COI NLV25T-100J B 48.3/89.0
L7215 6200005011 S.COI NLV25T-100J B 35.2/14.9
L7216 6140003570 COI LR-398 (3.5%)
L7217 6140003570 COI LR-398 (3.5%)
L7218 6140003570 COI LR-398 (3.5%)
L7241 6200005011 S.COI NLV25T-100J B 7.3/75.3
L7244 6200005011 S.COI NLV25T-100J B 17.6/30.5
L7245 6140003780 COI LR-437
L7246 6140003780 COI LR-437
L7248 6140003780 COI LR-437
L7271 6200002041 S.COI NLV25T-101J B 171.0/80.6
L7272 6140003490 COI LR-391 (TR10X5X5 3A6)
L7273 6200002041 S.COI NLV25T-101J B 171.0/87.6
L7321 6140001460 COI LR-170
L7331 6200002041 S.COI NLV25T-101J B 58.3/5.6
L7332 6200002041 S.COI NLV25T-101J B 59.1/9.8
R7271 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 168.6/81.6
R7272 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 167.8/79.4
R7273 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 165.0/79.4
R7274 7030008190 S.RES ERJ12YJ330U (33) B 156.4/83.7
R7275 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 168.6/85.8
R7276 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 167.8/88.8
R7277 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 165.0/88.8
R7301 7030003200 S.RES ERJ3GEYJ 100 V (10) B 132.3/95.5
R7314 7540000250 ABS SA05C 401N
R7315 7030010650 S.RES ERJ12YJ823U (82K) B 160.1/99.4
W7333 7030003860 S.RES ERJ3GE JPW V B 63.2/4.7
W7334 7030003860 S.RES ERJ3GE JPW V B 63.4/11.9
W7335 7030003860 S.RES ERJ3GE JPW V B 52.7/3.9
W7336 7030003860 S.RES ERJ3GE JPW V B 66.6/12.4
W7337 7030003860 S.RES ERJ3GE JPW V B 67.5/4.7
W7338 7030003860 S.RES ERJ3GE JPW V B 68.3/11.6
W7339 7030003860 S.RES ERJ3GE JPW V B 69.7/4.7
W7340 7030003860 S.RES ERJ3GE JPW V B 72.5/12.1
C7031 4510005481 ELE 50 ME 1 HC
C7032 4030011600 S.CER C1608 JB 1E 104K-T B 149.9/6.5
C7033 4320000270 DIP DM20C 102J5
C7034 4010006410 CER HM13SJ SL 471J 500V
C7035 4010006410 CER HM13SJ SL 471J 500V
C7036 4320000320 DIP DM20C 222J5
C7037 4010005360 CER HM11SJ SL 301J 500V
C7038 4010005880 CER HM95SJ SL 271J 500V
C7039 4320000330 DIP DM20C 272J5
C7041 4030011120 S.CER GRM31M2C2H100JV01L
(GRM42-6 CH) B 179.6/42.6
C7042 4010005930 CER HM11SJ SL 391J 500V
C7043 4010005930 CER HM11SJ SL 391J 500V
C7044 4010005930 CER HM11SJ SL 391J 500V
C7045 4010005370 CER HM11SJ SL 331J 500V
C7046 4030011600 S.CER C1608 JB 1E 104K-T B 160.1/60.6
C7049 4010005850 CER HM95SJ SL 181J 500V
C7061 4510005481 ELE 50 ME 1 HC
C7062 4030011600 S.CER C1608 JB 1E 104K-T B 129.6/16.8
C7063 4030011730 S.CER GRM31M2C2H101JV01L
(GRM42-6 CH) B 145.2/25.7
C7064 4010006410 CER HM13SJ SL 471J 500V
C7065 4010006410 CER HM13SJ SL 471J 500V
C7066 4010005370 CER HM11SJ SL 331J 500V
C7067 4010005880 CER HM95SJ SL 271J 500V
C7068 4010005880 CER HM95SJ SL 271J 500V
C7069 4010005880 CER HM95SJ SL 271J 500V
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[FILTER UNIT]
C7070 4030011730 S.CER GRM31M2C2H101JV01L
(GRM42-6 CH) B 157.0/30.5
C7071 4010006410 CER HM13SJ SL 471J 500V
C7072 4010006410 CER HM13SJ SL 471J 500V
C7073 4010006410 CER HM13SJ SL 471J 500V
C7074 4010006410 CER HM13SJ SL 471J 500V
C7075 4010005370 CER HM11SJ SL 331J 500V
C7076 4010005370 CER HM11SJ SL 331J 500V
C7077 4010005370 CER HM11SJ SL 331J 500V
C7078 4010005930 CER HM11SJ SL 391J 500V
C7079 4010006410 CER HM13SJ SL 471J 500V
C7080 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 129.4/48.6
C7081 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 126.7/48.6
C7082 4010005930 CER HM11SJ SL 391J 500V
C7083 4010005930 CER HM11SJ SL 391J 500V
C7084 4030011550 S.CER GRM31M2C2H680JV01L
(GRM42-6 CH) B 139.1/55.1
C7085 4030011600 S.CER C1608 JB 1E 104K-T B 119.3/61.9
C7086 4030011120 S.CER GRM31M2C2H100JV01L
(GRM42-6 CH) B 145.2/28.3
C7087 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 153.3/29.0
C7091 4510005481 ELE 50 ME 1 HC
C7092 4030006880 S.CER C1608 JB 1H 472K-T B 112.0/17.5
C7094 4010005370 CER HM11SJ SL 331J 500V
C7095 4010005930 CER HM11SJ SL 391J 500V
C7096 4010005930 CER HM11SJ SL 391J 500V
C7098 4010005370 CER HM11SJ SL 331J 500V
C7099 4010006410 CER HM13SJ SL 471J 500V
C7100 4030011730 S.CER GRM31M2C2H101JV01L
(GRM42-6 CH) B 107.6/67.2
C7101 4010005360 CER HM11SJ SL 301J 500V
C7102 4030006880 S.CER C1608 JB 1H 472K-T B 103.8/85.3
C7105 4010006410 CER HM13SJ SL 471J 500V
C7106 4010005830 CER HM74SJ SL 151J 500V
C7108 4010005370 CER HM11SJ SL 331J 500V
C7121 4510005481 ELE 50 ME 1 HC
C7122 4030006880 S.CER C1608 JB 1H 472K-T B 94.6/17.5
C7124 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 83.0/29.4
C7125 4010005930 CER HM11SJ SL 391J 500V
C7126 4030011120 S.CER GRM31M2C2H100JV01L
(GRM42-6 CH) B 86.1/41.7
C7127 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 83.5/41.7
C7128 4010005880 CER HM95SJ SL 271J 500V
C7129 4010005360 CER HM11SJ SL 301J 500V
C7130 4030011510 S.CER GRM31M2C2H560JV01L
(GRM42-6 CH) B 87.8/67.2
C7131 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6 CH) B 87.8/64.6
C7132 4010005360 CER HM11SJ SL 301J 500V
C7133 4030006880 S.CER C1608 JB 1H 472K-T B 86.4/79.6
C7136 4010005850 CER HM95SJ SL 181J 500V
C7137 4030011730 S.CER GRM31M2C2H101JV01L
(GRM42-6 CH) B 94.2/28.9
C7151 4510005481 ELE 50 ME 1 HC
C7152 4030006880 S.CER C1608 JB 1H 472K-T B 69.2/31.5
C7153 4030014460 S.CER GRM31M2C2H820JV01L
(GRM42-6 CH) B 68.7/42.8
C7154 4010005930 CER HM11SJ SL 391J 500V
C7155 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 73.5/55.1
C7156 4030011120 S.CER GRM31M2C2H100JV01L
(GRM42-6 CH) B 75.6/55.1
C7157 4010005930 CER HM11SJ SL 391J 500V
C7158 4030014460 S.CER GRM31M2C2H820JV01L
(GRM42-6 CH) B 74.2/67.8
C7160 4030006880 S.CER C1608 JB 1H 472K-T B 68.8/79.5
C7163 4010005850 CER HM95SJ SL 181J 500V
C7164 4030014460 S.CER GRM31M2C2H820JV01L
(GRM42-6 CH) B 62.7/38.1
C7181 4510005481 ELE 50 ME 1 HC
C7182 4030006880 S.CER C1608 JB 1H 472K-T B 51.7/17.5
C7183 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 53.4/24.9
C7184 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 44.5/28.8
C7185 4010005880 CER HM95SJ SL 271J 500V
C7186 4030011510 S.CER GRM31M2C2H560JV01L
(GRM42-6 CH) B 44.5/40.5
C7187 4010005370 CER HM11SJ SL 331J 500V
C7188 4030011180 S.CER GRM31M2C2H220JV01L
(GRM42-6 CH) B 51.6/68.8
C7190 4030006880 S.CER C1608 JB 1H 472K-T B 52.0/85.0
C7193 4010005850 CER HM95SJ SL 181J 500V
C7211 4510005481 ELE 50 ME 1 HC
C7212 4030006880 S.CER C1608 JB 1H 472K-T B 34.2/17.5
C7214 4030011240 S.CER GRM31M2C2H470JV01L
(GRM42-6 CH) B 36.6/61.7
C7216 4030011190 S.CER GRM31M2C2H270JV01L
(GRM42-6 CH) B 34.1/75.9
C7217 4030012480 S.CER GRM31M2C2H121JV01L
(GRM42-6 CH) B 30.0/77.3
C7218 4030006880 S.CER C1608 JB 1H 472K-T B 45.0/85.3
C7221 4030014460 S.CER GRM31M2C2H820JV01L
(GRM42-6 CH) B 31.1/45.2
C7222 4010005860 CER HM95SJ SL 201J 500V
C7223 4030014460 S.CER GRM31M2C2H820JV01L
(GRM42-6 CH) B 31.1/47.4
C7224 4030011210 S.CER GRM31M2C2H330JV01L
(GRM42-6 CH) B 31.3/65.8

Nov. 2011
20
SECTION 9
.
BOARD LAYOUTS
• MAIN UNIT
(TOP VIEW)
1
3
6
4
1
18
16 9
9
18 10
1
30
80
51
31 50
100 81
1
7
14
8
1
18
169
9
18 10
1
1
14
85
4
8
5
4
8
5
14
58
1
1
916
81
1
14
58
4
8
5
4
85
8
16
9
14
85
1
1
9
18
10 8
16
9
1
8
16
9
14
58
1
1
14
85
4
85
1
1
8
16
94
85
4
8
5
14
58
1
5
10
6
1
4
8
5
GND30
to DSP board
2
29
1
J1102
GND
DSPO1
GND
AGC2
GND
8V
GND
GND
GND
DSPI1
DSPO2
GND
GND
GND
AGC1
GND
8V
GND
DSPI2
GND
GND
GND11
to DSP board
29
2
30
J1101
GND1
RQI
CK
GND1
RQO
OBSY
GND1
OUT1
OUT3
OUT5
OUT7
GND1
KEYIN
DRES
192K
GND1
IBSY
DI
GND1
DO
STBO
GND1
OUT2
OUT4
OUT6
OUT8
GND1
UNLK
GND1
to FLASH
writer
1
210
9
J3001
FZTXD
RESET
EPM
NMEI2
FZBUSY
CNVSS
GND
CE
FZCLK
VCC
to PLL unit J5071 1
230
29
J3602
NSEN
DSAFE
DSMDE
NC
D1 D3 D5 D7
NC NC
RXPC
NMRS
RSSW
NMEI
GND
GND
DSAF
DSMD
GND
D0 D2 D4 D6
A16
NC
H5V
DTRM
NMEO
NMEI2
GND
to PLL unit J5001
1
224
23
J3601
H13P
S13P S13P
PDAT
PST1 PST3 PST4
DRES
REFS
GND
M3LO
D2LO
S13P S13P
UNLK
PCK
PST2
PCO2
PST5
NC NC
GND GND GND
to FILTER
board J7331
115
216
J1301
TRXS
L22M L12M
L6M L2M
GND
REF
FOR
S13L
L16M
L8M L4M L1M
GND GND GND
to PA unit J6701
119
220
J1901
T8V
GND GND GND
ANTC
KEYS
S13 S13
FANC
HV
THRM
GND GND
ICV
S TAT
S13 S13 S13
HV
PON
to RC-25
JACK board
J8602
8746
5213
J2051
FAFG
FMODG
FMOD
GND
RXD
TXD
FAF
H13V
13.6V
AGND
FALC SCAN
AAF AMOD
SEND CWK
ACC
CONTROLLER
SP
to SP-24
SPE
SPO
from FILTER board J7321
MRX P7321
from PLL unit J5601
M1LO P5601
from PA unit J6702
YGR P6702
from PLL unit J5201
M2LO P5201
from CHASSIS J4503
DSC ANT P501
from PLL unit J5801
D1LO P5801
[USA], [CAN] only
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10 C11
C54 C56
C57
C59
C61
C62
C63
C64
C65
C66 C67
C68
C101 401C301C201C C105 801C701C601C
C109
C110
C111
C112 C113 711C611C511C411CC118
C119
121C021C C122 621C521C421C321C
C127
C128
C129
C130
C131
C132
431C331C C135
C136
C137
C138
C139
C140
C141
C142
C143
C144
C145
C146
C147
C148
C149
C150 251C151C C153 C154
C155
C156
C157 C158
C159
C160
C161
C162
C163
C164
C165
C166
C167
C168
C169
C170
C171
C172
C173
C174
C175
C201
C202
C203
C204
C205
C206
C207
C208
C209
C210
C211
C212
C213
C214
C215
C217
C218
C219
C220
C221
C223
C224
C301
C302
C303
C305
C307
C308
C309
C310
C311
C312
C314 C401
C402
C403
C404
C405
C406
C407
C408
C409
C410
C411
C412
C413
C414
C501 C502 C503
C504
C505
C506
C507
C508
C509
C510
C511
C512
C516
C517
C518
C519
C520
C521
C601
C602
C603
C604
C605
C606
C607
C608
C609
C610
C611
C612
C701
C702
C703
C705 C706
C707
C709
C710
C711
C712
C714
C715
C716
C717
C718
C720
C801
C802
C804
C805
C806
C901
C902
C903
C904
C905
C906
C907
C908
C909
C910
C1001
C1002
C1003
C1004
C1005
C1006
C1007
C1008
C1010
C1011
C1012
C1051
C1052
C1054
C1055
C1056 C1057
C1058
C1059
C1061 C1062 C1063
C1064
C1101
C1102
C1201
C1202
C1203
C1204
C1205
C1206 C1208
C1209
C1210 C1211
C1212
C1213
C1214
C1223
C1224
C1301 C1302 C1303 C1304 C1305 C1306 C1307 C1308
C1309
C1310
C1311
C1312
C1313
C1314
C1315
C1451
C1501
C1502
C1503
C1504
C1505
C1506
C1507
C1508
C1509
C1510
C1551
C1552
C1555
C1557
C1558
C1559
C1560
C1561
C1562
C1563
C1601
C1602
4061C3061C
C1605
C1606
C1607
C1608
C1609
C1610
C1611
C1612
C1613
C1614
C1615
C1616
C1617
C1618
C1619
C1701
C1702
C1703
C1704
C1705
C1706
C1707C1709
C1710
C1711
C1713
C1714
C1715
C1716
C1717
C1801
C1802
C1803
C1804
C1805
C1806
C1807
C1901
C1902
C1903
C1904
C1905
C1906
C1907
C1908
C1910
C2001
C2002
C2003
C2004
C2005
C2006
C2007
C2008
C2101
C2102
C2103
C2104
C2105
C2106
C2107
C2201
C2202
C2203
C2204
C2205 C2206
C2207
C2208
C2209
C2210
C2211
C2212
C2213
C2214
C2215
C2216
C2217
C2218
C2219
C2220
C2221
C2222
C2223
C2224
C2225
C2226
C2227
C2228
C2229
C2232
C2234
C2235
C2236
C2237
C2238
C2239
C2240
C2241
C2242
C2243
C2244
C2245
C2246
C2247 C2248
C2249
C2250
C2251
C2252
C2253
C2254
C2263
C2264
C2266
C2267
C2268
C2269
C2270
C2271
C2301
C2302
C2303
C2304
C2307
C2308
C2309
C2310 C2311
C2402
C2403
C2404
C2405
C2406
C2409
C2501
C2502
C2503
C2504
C2701
C2702
C2703 C2704
C2705
C2706
C2707
C2708
C2710
C2711
C2712 C2713
C2714 C2715
C2716
C3001 C3002 C3003 C3004 C3005
C3006
C3007
C3008
C3009
C3101
C3102
C3103
C3104
C3201
C3202
C3302
C3303
C3304
C3305
C3306
C3307
C3308
C3309
C3310
C3311
C3312
C3601
C3602
C3603
C3604
C3605
C3606
C3901
CP1101
CP1201
CP3301
D51 D52
D53
D101
D102 D103 D104
D105
D106
D107
901D801D
D110
D201
D301
D302
D303
D401
D402
D403
D404
D601
D602
D901
D1102
D1201
D1202
D1203
D1204
D1205
D1206
D1207
D1501 D1502
D1551
D1552
D1554
D1801
D2101
D2102
D2103 D2104
D2201D2202
D2203D2204
D2301
D3001
D3002
D3003
D3004
D3006
D3007
D3301
D3302
D3336
D3337
FI201
FI401
FI402
FI231A
FI231B
FI301A
FI301B
IC1
IC501
IC901
IC1001
IC1002
IC1051
IC1101
IC1201
IC1301
IC1302
IC1303
IC1501
IC1502
IC1551
IC1601
IC1602
IC1603
IC1701
IC1702
IC1703
IC2001
IC2701
IC2702
IC3101
IC3201
IC3301
IC3302
IC3303
IC3601
IC3602
IC3603
IC3604
IC3605
IC3606
J1
J51
J301
J601
J1101
J1102
J1301
J1451
J1801
J1901
J2051
J2101
J2301
J3001
J3601 J3602
L1
L2
L3
L51
L52
L53
L54
L55 L56
L101
L102
L103
L104
L105
L106
L107
L108
L109
L110
L111
L112
L113
L114
L115
L116
L117
L118
L119 L120 L121 L122 421L321L L125 L126
L127
L128
L129
L130
L131
L132
L133
L134
L135
L136 L137 L138 L139
L140
L141 L142 L143
L144
L201
L202
L203
L204
L205
L206
L207
L208
L209
L210 L301
L302
L303
L304
L305
L306
L307
L401
L402
L403
L404
L405
L406
L502
L504
L505
L506
L601
L602
L603
L604
L605
L701
L702
L703
L704
L705
L706
L707
L801
L901
L902
L903
L904
L1301
L1302
L1551
L1552
L1601
L1801
L1802
L1803
L1804
L1901
L1902
L1903
L1904
L1905
L1906
L1907
L1908
L2051
L2052
L2053
L2054
L2101
L2201
L2202
L2204
L2205
L2206
L2207
L2208
L2209
L2210
L2211
L2212
L2213
L2214
L2215
L2216
L2217
L2218
L2219
L2220
L2221
L2222
L2223
L2224
L2225
L2226
L2227
L2228
L2229
L2230
L2231
L2232
L2233
L2235
L2236
L2237
L2238
L2239
L2240
L2241
L2242
L2243
L2244
L2245
L2301
L2302
L2304
L2305
L2306
L2307
L2401
L2501
L2701
L2702
L2703
L3301
L3601
L3602
MP201
MP701
MP1501
Q51
Q201
Q202
Q203
Q401
Q501
Q601
Q701
Q702Q703
Q801
Q1203
Q1204
Q1205
Q1206
Q1207
Q1501
Q1502
Q1503 Q1504
Q1601
Q1801
Q2101
Q2102
Q2301
Q2302
Q2401
Q2501
Q3001
Q3004
R1
R2
R3
R4
R5
R6 R7
R8
R54
R56
R57
R58
R59
R60
R61
R101
R102 R103 R104
R105 R106 R107 R108
R109
R110
R201
R202
R203
R204
R205
R207
R208
R209
R210
R211
R212
R213
R214
R215
R301
R306
R307
R309
R401
R404
R405
R406
R407
R408
R409
R410
R413
R414
R415
R502
R503
R504
R505
R506
R507
R508
R514
R601
R602
R603 R604
R605
R606
R607
R701
R702
R703
R704
R705
R706
R707
R708 R709
R710
R711
R712
R713
R714 R715
R716
R717
R718
R719
R720
R722
R801
R802
R804
R813
R901
R902
R903
R904
R910
R911
R1002
R1003
R1004
R1005
R1006 R1007
R1008
R1009
R1010
R1011
R1014
R1015
R1016
R1017
R1018 R1051
R1052
R1053
R1054
R1055
R1057
R1058
R1059
R1060
R1101
R1102
R1103
R1104
R1105
R1106
R1107
R1108
R1109
R1110
R1111
R1112
R1113 R1114
R1202
R1203
R1205
R1206
R1207
R1208
R1209
R1210
R1211
R1212
R1213
R1214
R1215
R1216
R1217
R1218
R1219
R1220R1221
R1222
R1223
R1224
R1225
R1226
R1228
R1230
R1232
R1233
R1234
R1235
R1236
R1237R1238
R1240
R1241
R1301 R1302 R1303 R1304 R1305 R1306 R1307 R1308
R1309
R1310 R1311 R1312 R1313 R1314 R1315 R1316 R1317
R1318
R1319
R1320
R1501
R1502
R1503
R1504
R1505
R1551
R1553
R1555
R1556
R1601
R1602
R1603
R1606
R1607
R1609
R1610
R1611
R1612
R1613
R1614
R1615
R1701
R1702
R1703
R1704
R1705
R1706
R1707
R1709
R1710
R1711
R1712
R1713
R1715
R1716
R1717
R1718
R1719
R1720
R1721
R1722
R1723
R1724
R1801 R1802
R1803
R1804
R1901
R1902
R1903
R2001
R2002
R2003
R2101 R2102
R2103 R2104
R2105
R2106R2107
R2201
R2202
R2203
R2204
R2205
R2206
R2207
R2208
R2301
R2302
R2303
R2306
R2401 R2402
R2403
R2404
R2405
R2406
R2501
R2502
R2503
R2504
R2505
R2506
R2701
R2702
R2703
R2704
R2705
R2706
R2708
R2709
R2710
R2711
R2712
R2713
R2714
R2715
R2716
R3001 R3002
R3003 R3004
R3006
R3007
R3008
R3009
R3010
R3011
R3012
R3013
R3014
R3015
R3017
R3018
R3019 R3020
R3023
R3024
R3025
R3026
R3027
R3028
R3029
R3030
R3035
R3036
R3050
R3051
R3052
R3101
R3201
R3202 R3203
R3204
R3301
R3302
R3303R3304
R3305
R3306
R3307
R3308
R3309
R3310
R3311
R3312
R3313
R3314
R3315
R3316 R3317 R3318
R3319
R3320 R3321 R3322 R3323 R3324 R3325 R3326 R3327 R3328 R3329
R3330
R3331
R3332
R3333
R3334
R3335
R3336 R3337
R3338
R3339
R3340
R3350
R3402 R3403
R3404
R3405 R3406 R3408 R3412
R3601
R3602 R3603 R3604 R3605 R3606
R3608
R3609 R3610 R3611 R3612
R3613
R3614
R3615
R3616
R3617
R3618
R3619
R3620
R3621
R3622
R3623
R3624
R3625
R3626
R3627
R3628
R3629
R3630
R3903
R3906
R3907
R3908
R3909
R3915 R3916 R3917 R3918 R3919
R3920
R3921
RL2101
W501
W803
W1011
W1101
W1102
W1227
W1231
W1601
W1701
W2001
W2002
X3301
RX
B-5722H
J3601
J1301
J3602
M1LO
M2LO
D2LO
BLACK
BLACK
7
5
3
2
4
6
8
MP2051
1
CP3301
CP1101
CP1201
J1901
H0H5H10H15H20H25H30H35H40H45H50H55H60H65H70H75H80H85H90H95H100H105H110H115H120H125H130H135H140H145H150
H155H160H165H170H175H180H185H190H195H200H205
H210H215H220
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50 V55 V60 V65 V70 V75 V80 V85 V90 V95 V100 V105 V110 V115
