ICP DAS USA tET-P6 User manual

tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
1
tET-P6/tPET-P6
Quick Start
What’s in the box?
The package includes the following items:
tET/tPET-P(D)6 Module x 1 Quick Start x1 (This Document)
Product Website:
https://www.icpdas-usa.com/tpet_6.html


tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
2
1 Connecting the Power and Host PC
1) Make sure your PC has workable network settings.
Disable or well configure your Windows firewall and Anti-Virus firewall first,
else the “Search Servers” on Chapter 5 may not work. (Please contact
with your system Administrator)
2) Connect both the tET/tPET-P(D)6 and your PC to the same sub
network or the same Ethernet switch.
3) Supply power (PoE or +12~+48 V
DC ) to the tET/tPET-P(D)6.

tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
3
2 Pin Assignments & Wiring Note

Pin Assignments:


Digital Input Wiring of the tET/tPET-P6:

Digital Input
Readback as 1
Readback as 0
+10 ~ +50 V DC OPEN or <4 V DC
DIx 10K DIx 10K
Sink
+ - + -
To other To ther channels
To othe
r
DI.COM DI.COM
channels channels
+10 ~ +50 V DC OPEN or <4 V DC
DIx 10K DIx 10K
Source
- +
-
+
To ther channels
To other
To other
To ther channels
DI.COM DI.COM
channels channels

Digital Input Wiring of the tET/tPET-PD6:

Digital Input Readback as 0
Readback as 1
Relay Off Relay On
Dry Contact
DI.GND
DI.GND
Relay Open
DIx
Relay Close
DIx

tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
4
3 Wire the DI for Self-test

tET/tPET-P6:


1) Supply the External Power +24V to DI0. (External +10V connect to Pin06 )
2) Supply the External Power GND to DI.COM. (External GND connect
to Pin05)

tET/tPET-PD6:


1) Connect the DI0 and DI.COM. (Pin06 connect to Pin05)


tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
5
4 Modbus Address

(1xxxx) DI address:

Begin Points Description Bits Range Access
address Per Type
Point
0
1~6 Digital Input 1
0:Off
R
(0x0) 1:On
32
1~6 Digital latched status (high) 1
0:no
R
(0x20) 1:latched
64
1~6 Digital latched status (low) 1
0:no
R
(0x40) 1:latched

(0xxxx) DO address:

Begin Points Description Bits Range Access
address Per Type
Point
32
1
Clear all DI latched status
1 1: Clear W
(0x20) (high)
33
1
Clear all DI latched status
1 1: Clear W
(0x21) (low)
150
1
Enable All DI latched
1
0:Disable
R/W/F
(0x96) status (high/low) 1:Enable
151
1~6
Enable high speed digital
1
0:Disable
R/W/F
(0x97) counter 1:Enable
. . . . . .
. . . . . .
Note
For detail “DI/DO Modbus Address” information, refer to Section 6.3 Modbus Register
Table of user’s manual (http://ftp.icpdas.com/pub/cd/tinymodules/napdos/tpet/document/).

tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
6
5 Configuring Network Settings
1) Run the eSearch Utility.
The eSearch Utility is located at:

http://ftp.icpdas.com/pub/cd/tinymodules/napdos/software/esearch/
2) Click the “Search Servers” to search your tET/tPET-P(D)6.
3) Double-click your tET/tPET-P(D)6 to configure the settings


Factory Default Settings of tET/tPET-P(D)6:
IP Address 192.168.255.1
Subnet Mask 255.255.0.0
Gateway 192.168.0.1
4) Contact your Network Administrator to obtain a correct network
configuration (such as IP/Mask/Gateway). Enter the network settings
and click “OK”. Note: The tET/tPET-P(D)6 will use the new
settings 2 seconds later.


tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
7
6 Testing your tET/tPET Module
1) Wait 2 seconds and click “Search Servers” button again to ensure
the tET/tPET-P(D)6 is working well with new configuration.
2) Click the name of tET/tPET-P(D)6 to select it.
3) Click the “Web” button to log in to the web configuration pages.
(Or enter the URL address of the tET/tPET-P(D)6 in the address bar
of the browser.)

 

tPET-P6
Tiny Ethernet PoE module with 6 Digital Input Module - QuickStart (Mar/2019)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
8
4) Enter the password in the “login password” field and click “Submit”.
Use the default
password: Admin

5) In the “Home” page, check that the “DI0” status should show current
status is ON (Green).

