iDataLink maestro Rr User manual

NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in
are the properties of their respective owners.
WARNING
Pressing the printer icon or “quick printing” this document will print
all of the guides in this compilation.
Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
Print only the pages for your vehicle using the advanced
options in the Print menu.
Install your Maestro RR according to the guide for your vehicle.
HOW TO USE THIS INSTALL GUIDE
1
2
3
SELECT VEHICLE
PRINT PAGES NEEDED

OPTIONAL ACCESSORIES
None
PROGRAMMED FIRMWARE
ADS-RR(SR)-CHR01-DS
PRODUCTS REQUIRED
iDatalink Maestro RR Radio Replacement Interface
iDatalink Maestro CH2 Installation Harness
INSTALL GUIDE
CHRYSLER 300
BASE 20052007
retains steering wheel controls, Uconnect, Uconnect BlUetooth, and more!
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler 300 Base 2005-2007
Automotive Data Solutions Inc. © 2015 2
WELCOME
NEED HELP?
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the Installation Diagram and Vehicle
Wire Reference Chart.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
1 866 427-2999
[email protected]
maestro.idatalink.com/support
www.12voltdata.com/forum
DURING INSTALLATION
Installation Instructions 3
Wiring Diagram 4
Vehicle Wire Reference Chart 5
Radio Wire Reference Chart 6

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler 300 Base 2005-2007
Automotive Data Solutions Inc. © 2015 3
INSTALLATION INSTRUCTIONS
STEP 1
• Remove the factory radio.
• Access the main 22 pin factory radio connector (2.1) and
determine if you have a factory amplifier.
If you have wires in PIN 7, 8, 9 and 10, you don’t have a
factory amplifier.
If you don’t have wires in PIN 7, 8, 9 and 10, you have a
factory amplifier.
• Unbox the aftermarket radio and locate its main harness.
• Connect the wires shown on the next page from
aftermarket radio main harness to the CH2 T-harness and
match the wire functions.
STEP 2
• Connect the factory harness to the CH2 T-harness.
STEP 3
• Access the OBDII connector located under the driver side
dashboard.
• Connect the BROWN /RED wire of the CH2 T-harness to
the wire located at pin 6 of the OBDII connector. (See the
vehicle wire chart reference for wire colors)
• Connect the BROWN /YELLOW wire of the CH2 T-harness
to the wire located at pin 14 of the OBDII connector. (See
the vehicle wire chart reference for wire colors)
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the Data cable to the data port of the aftermarket
radio.
• Insert the Audio cable into the iDatalink 3.5 mm audio jack
of the aftermarket radio.
STEP 5
• Connect all the harnesses to the Maestro RR module then
proceed to module setup.
The module is now ready to be used.
Insert the aftermarket radio in the dashboard housing and
test all the functionalities.
Reassemble the dashboard carefully.
TROUBLESHOOTING TIPS:
• To reset the module back its factory settings, turn the key
to the OFF position then disconnect all connectors from
the module. Press and hold the module’s programming
button and connect all the connectors back to the module.
Wait, the module’s LED will flash RED rapidly (this may
take up to 10 seconds). Release the programming button.
Wait, the LED will turn solid GREEN for 2 seconds.
• For technical assistance call 1-866-427-2999 or e-mail
“[email protected]”. Visit us at “maestro.idatalink.
com/support” and “www.12voltdata.com/forum/”
1
Fig. 2.1
45671121 3
15 16 17 18
8 9 10
19 20 21 221312 14

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler 300 Base 2005-2007
Automotive Data Solutions Inc. © 2015 4
10 11 12 13 14 15 16
1234567 8
9
C
A
H
F
G
D
C
A
G
F
H
1
D
BROWN/RED - CANH
BROWN/YELLOW - CANL
NOTE: PIN SIDE VIEW.
CONNECT TO TWISTED WIRES BEHIND CONNECTOR.
WIRING DIAGRAM
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
MAESTRO RR MODULE
WHITE - LF SPEAKER (+)
WHITE/BLACK - LF SPEAKER (-)
GRAY - RF SPEAKER (+)
GRAY/BLACK - RF SPEAKER (-)
GREEN - LR SPEAKER (+)
GREEN/BLACK - LR SPEAKER (-)
PURPLE/BLACK - RR SPEAKER (-)
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
BROWN (NOT CONNECTED)
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) SEE CHART ON
NEXT PAGE FOR
RADIO WIRE
COLORS
LTGREEN - E-BRAKE (-)
BLUE/WHITE - AMP. TURN ON (+)
MAIN
HARNESS
DATA
CABLE
AUDIO
CABLE
PURPLE - RR SPEAKER (+)
CONNECT TO
AFTERMARKET RADIO
CH2 T-HARNESS
FACTORY RADIO
HARNESS
OBDII CONNECTOR
WIRES FROM
VEHICLE
YELLOW/BLACK - FOOT BRAKE
PINK - VEHICLE SPEED

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler 300 Base 2005-2007
Automotive Data Solutions Inc. © 2015 5
VEHICLE WIRE REFERENCE CHART
Wire
Description
Connector
Name
Connector
Color
Connector
Type Position Wire Color Polarity Wire
Location
CanH A ~ 16 pin 06 White/LtBlue (DATA) OBDII connector, under driver side dash
CanL A ~ 16 pin 14 White/DkBlue (DATA) OBDII connector, under driver side dash

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler 300 Base 2005-2007
Automotive Data Solutions Inc. © 2015 6
RADIO WIRE REFERENCE CHART
Wire
Description Polarity Wire Color on Maestro
T-Harness Wire Color on Alpine cable Wire Color on Kenwood cable Wire Color on Pioneer cable
Illumination (+) Orange N/A Orange/White Orange/White
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green
Foot Brake (+) Yellow/Black Yellow/Black N/A N/A
VSS (vehicle speed sensor) (DATA) Pink Green/White N/A Pink

OPTIONAL ACCESSORIES
None
PROGRAMMED FIRMWARE
ADS-RR(SR)-CHR01-DS
PRODUCTS REQUIRED
iDatalink Maestro RR Radio Replacement Interface
iDatalink Maestro CH2 Installation Harness
INSTALL GUIDE
CHRYSLER PT CRUISER
BASE 20062010
retains steering wheel controls, Uconnect, Uconnect BlUetooth, and more!
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler Pt crUiser Base 2006-2010
Automotive Data Solutions Inc. © 2015 2
WELCOME
NEED HELP?
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the Installation Diagram and Vehicle
Wire Reference Chart.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
1 866 427-2999
[email protected]
maestro.idatalink.com/support
www.12voltdata.com/forum
DURING INSTALLATION
Installation Instructions 3
Wiring Diagram 4
Vehicle Wire Reference Chart 5
Radio Wire Reference Chart 6

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler Pt crUiser Base 2006-2010
Automotive Data Solutions Inc. © 2015 3
INSTALLATION INSTRUCTIONS
STEP 1
• Remove the factory radio.
• Access the main 22 pin factory radio connector (2.1) and
determine if you have a factory amplifier.
If you have wires in PIN 7, 8, 9 and 10, you don’t have a
factory amplifier.
If you don’t have wires in PIN 7, 8, 9 and 10, you have a
factory amplifier.
• Unbox the aftermarket radio and locate its main harness.
• Connect the wires shown on the next page from
aftermarket radio main harness to the CH2 T-harness and
match the wire functions.
STEP 2
• Connect the factory harness to the CH2 T-harness.
STEP 3
• Access the OBDII connector located under the driver side
dashboard.
• Connect the BROWN /RED wire of the CH2 T-harness to
the wire located at pin 6 of the OBDII connector. (See the
vehicle wire chart reference for wire colors)
• Connect the BROWN /YELLOW wire of the CH2 T-harness
to the wire located at pin 14 of the OBDII connector. (See
the vehicle wire chart reference for wire colors)
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the Data cable to the data port of the aftermarket
radio.
• Insert the Audio cable into the iDatalink 3.5 mm audio jack
of the aftermarket radio.
STEP 5
• Connect all the harnesses to the Maestro RR module then
proceed to module setup.
The module is now ready to be used.
Insert the aftermarket radio in the dashboard housing and
test all the functionalities.
Reassemble the dashboard carefully.
TROUBLESHOOTING TIPS:
• To reset the module back its factory settings, turn the key
to the OFF position then disconnect all connectors from
the module. Press and hold the module’s programming
button and connect all the connectors back to the module.
Wait, the module’s LED will flash RED rapidly (this may
take up to 10 seconds). Release the programming button.
Wait, the LED will turn solid GREEN for 2 seconds.
• For technical assistance call 1-866-427-2999 or e-mail
“[email protected]”. Visit us at “maestro.idatalink.
com/support” and “www.12voltdata.com/forum/”
1
Fig. 2.1
45671121 3
15 16 17 18
8 9 10
19 20 21 221312 14

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler Pt crUiser Base 2006-2010
Automotive Data Solutions Inc. © 2015 4
10 11 12 13 14 15 16
1234567 8
9
C
A
H
F
G
D
C
A
G
F
H
1
D
BROWN/RED - CANH
BROWN/YELLOW - CANL
NOTE: PIN SIDE VIEW.
CONNECT TO TWISTED WIRES BEHIND CONNECTOR.
WIRING DIAGRAM
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
MAESTRO RR MODULE
WHITE - LF SPEAKER (+)
WHITE/BLACK - LF SPEAKER (-)
GRAY - RF SPEAKER (+)
GRAY/BLACK - RF SPEAKER (-)
GREEN - LR SPEAKER (+)
GREEN/BLACK - LR SPEAKER (-)
PURPLE/BLACK - RR SPEAKER (-)
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
BROWN (NOT CONNECTED)
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) SEE CHART ON
NEXT PAGE FOR
RADIO WIRE
COLORS
LTGREEN - E-BRAKE (-)
BLUE/WHITE - AMP. TURN ON (+)
MAIN
HARNESS
DATA
CABLE
AUDIO
CABLE
PURPLE - RR SPEAKER (+)
CONNECT TO
AFTERMARKET RADIO
CH2 T-HARNESS
FACTORY RADIO
HARNESS
OBDII CONNECTOR
WIRES FROM
VEHICLE
YELLOW/BLACK - FOOT BRAKE
PINK - VEHICLE SPEED

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler Pt crUiser Base 2006-2010
Automotive Data Solutions Inc. © 2015 5
VEHICLE WIRE REFERENCE CHART
Wire
Description
Connector
Name
Connector
Color
Connector
Type Position Wire Color Polarity Wire
Location
CanH A ~ 16 pin 06 White/LtBlue (DATA) OBDII connector, under driver side dash
CanL A ~ 16 pin 14 White/DkBlue (DATA) OBDII connector, under driver side dash

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
chrysler Pt crUiser Base 2006-2010
Automotive Data Solutions Inc. © 2015 6
RADIO WIRE REFERENCE CHART
Wire
Description Polarity Wire Color on Maestro
T-Harness Wire Color on Alpine cable Wire Color on Kenwood cable Wire Color on Pioneer cable
Illumination (+) Orange N/A Orange/White Orange/White
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green
Foot Brake (+) Yellow/Black Yellow/Black N/A N/A
VSS (vehicle speed sensor) (DATA) Pink Green/White N/A Pink

OPTIONAL ACCESSORIES
None
PROGRAMMED FIRMWARE
ADS-RR(SR)-CHR01-DS
PRODUCTS REQUIRED
iDatalink Maestro RR Radio Replacement Interface
iDatalink Maestro CH2 Installation Harness
INSTALL GUIDE
DODGE CALIBER
BASE 20072008
retains steering wheel controls, Uconnect, Uconnect BlUetooth, and more!
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
dodge caliBer Base 2007-2008
Automotive Data Solutions Inc. © 2015 2
WELCOME
NEED HELP?
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the Installation Diagram and Vehicle
Wire Reference Chart.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
1 866 427-2999
[email protected]
maestro.idatalink.com/support
www.12voltdata.com/forum
DURING INSTALLATION
Installation Instructions 3
Wiring Diagram 4
Vehicle Wire Reference Chart 5
Radio Wire Reference Chart 6

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
dodge caliBer Base 2007-2008
Automotive Data Solutions Inc. © 2015 3
INSTALLATION INSTRUCTIONS
STEP 1
• Remove the factory radio.
• Access the main 22 pin factory radio connector (2.1) and
determine if you have a factory amplifier.
If you have wires in PIN 7, 8, 9 and 10, you don’t have a
factory amplifier.
If you don’t have wires in PIN 7, 8, 9 and 10, you have a
factory amplifier.
• Unbox the aftermarket radio and locate its main harness.
• Connect the wires shown on the next page from
aftermarket radio main harness to the CH2 T-harness and
match the wire functions.
STEP 2
• Connect the factory harness to the CH2 T-harness.
STEP 3
• Access the OBDII connector located under the driver side
dashboard.
• Connect the BROWN /RED wire of the CH2 T-harness to
the wire located at pin 6 of the OBDII connector. (See the
vehicle wire chart reference for wire colors)
• Connect the BROWN /YELLOW wire of the CH2 T-harness
to the wire located at pin 14 of the OBDII connector. (See
the vehicle wire chart reference for wire colors)
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the Data cable to the data port of the aftermarket
radio.
• Insert the Audio cable into the iDatalink 3.5 mm audio jack
of the aftermarket radio.
STEP 5
• Connect all the harnesses to the Maestro RR module then
proceed to module setup.
The module is now ready to be used.
Insert the aftermarket radio in the dashboard housing and
test all the functionalities.
Reassemble the dashboard carefully.
TROUBLESHOOTING TIPS:
• To reset the module back its factory settings, turn the key
to the OFF position then disconnect all connectors from
the module. Press and hold the module’s programming
button and connect all the connectors back to the module.
Wait, the module’s LED will flash RED rapidly (this may
take up to 10 seconds). Release the programming button.
Wait, the LED will turn solid GREEN for 2 seconds.
• For technical assistance call 1-866-427-2999 or e-mail
“[email protected]”. Visit us at “maestro.idatalink.
com/support” and “www.12voltdata.com/forum/”
1
Fig. 2.1
45671121 3
15 16 17 18
8 9 10
19 20 21 221312 14

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
dodge caliBer Base 2007-2008
Automotive Data Solutions Inc. © 2015 4
10 11 12 13 14 15 16
1234567 8
9
C
A
H
F
G
D
C
A
G
F
H
1
D
BROWN/RED - CANH
BROWN/YELLOW - CANL
NOTE: PIN SIDE VIEW.
CONNECT TO TWISTED WIRES BEHIND CONNECTOR.
WIRING DIAGRAM
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
MAESTRO RR MODULE
WHITE - LF SPEAKER (+)
WHITE/BLACK - LF SPEAKER (-)
GRAY - RF SPEAKER (+)
GRAY/BLACK - RF SPEAKER (-)
GREEN - LR SPEAKER (+)
GREEN/BLACK - LR SPEAKER (-)
PURPLE/BLACK - RR SPEAKER (-)
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
BROWN (NOT CONNECTED)
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) SEE CHART ON
NEXT PAGE FOR
RADIO WIRE
COLORS
LTGREEN - E-BRAKE (-)
BLUE/WHITE - AMP. TURN ON (+)
MAIN
HARNESS
DATA
CABLE
AUDIO
CABLE
PURPLE - RR SPEAKER (+)
CONNECT TO
AFTERMARKET RADIO
CH2 T-HARNESS
FACTORY RADIO
HARNESS
OBDII CONNECTOR
WIRES FROM
VEHICLE
YELLOW/BLACK - FOOT BRAKE
PINK - VEHICLE SPEED

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
dodge caliBer Base 2007-2008
Automotive Data Solutions Inc. © 2015 5
VEHICLE WIRE REFERENCE CHART
Wire
Description
Connector
Name
Connector
Color
Connector
Type Position Wire Color Polarity Wire
Location
CanH A ~ 16 pin 06 White/Tan (DATA) OBDII connector, under driver side dash
CanL A ~ 16 pin 14 White/DkBlue (DATA) OBDII connector, under driver side dash

ADS-RR(SR)-CHR01-DS maestro.idatalink.com
dodge caliBer Base 2007-2008
Automotive Data Solutions Inc. © 2015 6
RADIO WIRE REFERENCE CHART
Wire
Description Polarity Wire Color on Maestro
T-Harness Wire Color on Alpine cable Wire Color on Kenwood cable Wire Color on Pioneer cable
Illumination (+) Orange N/A Orange/White Orange/White
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green
Foot Brake (+) Yellow/Black Yellow/Black N/A N/A
VSS (vehicle speed sensor) (DATA) Pink Green/White N/A Pink

OPTIONAL ACCESSORIES
None
PROGRAMMED FIRMWARE
ADS-RR(SR)-CHR01-DS
PRODUCTS REQUIRED
iDatalink Maestro RR Radio Replacement Interface
iDatalink Maestro CH2 Installation Harness
INSTALL GUIDE
DODGE CHARGER
BASE 20062007
retains steering wheel controls, Uconnect, Uconnect BlUetooth, and more!
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.
