IDEAL AP80 PRO User manual

IDEAL AP60 PRO
IDEAL AP80 PRO
www.idealhealthstore.com
EN
Operating Instructions
Air Purier

25
EN Operating Instructions (25 – 47)
Intended use 26
Safety instructions 26
Product features 28
Included in the box 28
Unpacking and setting up 29
Overview and description of parts 31
Control panel 32
Fan speeds 33
Timer function 33
Quiet function 34
Air quality indicator 34
Filter replacement indicator 34
Daylight sensor 34
IR receiver 34
Air quality sensor 34
Remote control (when using for the rst time) 35
Remote control (replacing the battery) 36
Remote control (function) 37
Changing the lter 38
App Control / WLAN 39
Cleaning and maintenance / Accessories 40
Troubleshooting 41
Technical data 44

26
Introduction
Thank you for choosing a device from IDEAL.
Intended use
• The device is used exclusively for cleaning the ambient air indoors.
• Please read these operating instructions before starting to use the device
and please follow the safety instructions.
The operating instructions must be kept available with the device at
all times.
Safety instructions
• Keep packing material, such as plastic wrapping, away from children!
(Risk of suffocation)
• Pleasefollowthesafetyinstructionstopreventreorelectricshock.
Only use the device indoors.
• Only use a wall socket that supplies the correct voltage (see rating plate).
• Do not modify or repair the device.
• Do not use the device if the power cable or mains plug is damaged or if
the connection at the wall socket is not stable.
• Make sure that the power cable does not get crushed while you are using
the device and that it cannot be damaged in any other way. Place the
cable so that no one will trip over it. Do not place the power cable under
strain.
• Disconnect the plug from the wall socket for cleaning purposes and
wheneverthedeviceisnotinuseforasignicantperiodoftime.
• Do not touch the plug or the device if you have wet hands.
• Do not spray any insect repellent.
• Do not use in rooms where the device may come into contact with fuel
vapour or metal dust.
•Do not use any volatile liquids, petroleum, kerosene, paint thinner or
polishing paste to clean the device. Such liquids may damage the surface
of the device.
• Do not expose the device to rain, water, moisture or high humidity, and do
not set it up in a bathroom or kitchen next to a sink.
• Make sure that no foreign objects get into the outlet grilles.
• Donotusenearanopenreorsparks.
• The device is not suitable for removing harmful gases (carbon monoxide,
e.g. from heating appliances).
• The appliance is not to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction.
• Children being supervised not to play with the appliance.
Safety instructions

27
Safety instructions
• Do not block the air intake and outlet.
• Keepthisairpurierawayfromdirectsunlight,nakedflamesorheat.
• Onlyusetheairpurierinclosedinteriorsandwithinthespecied
technical parameters. Improper usage may pose a threat to life and health.
• Donotusetheunitneararealarm.Iftheoutletairisblowingtowards
arealarm,thealarmmayrespondlateornotatall.
Caution
Risk of injury due to electric shock.
Always disconnect the mains plug prior to:
• Carrying out maintenance work or cleaning
• Moving the device
• Changingthelter
Danger
• Do not use any spray cans with flammable content near to the
AirPurier!
Danger
• Do not use any flammable cleaning agents.
Safety instructions

28
Included in the box
Air Purier
(including lter cartridge) Filter cartridge Remote control • With self-adhesive
magneticlm
• With 3V lithium battery
Power cable Printed operating
instructions
Product features
•Filter replacement indicator:
Anilluminatedredreplacementindicatorontheairpurierindicatesthattheltercartridge
needs to be replaced.
•Air purication in 5 speed settings
•3-stage air purication system:
Pre-lter,HEPAltercoatedwithactivatedcarbon
•360° lter (Pre-lter, HEPA + active carbon)
Easymaintenanceandreplacementoftheltercartridge.
Turbo Auto
8h
4h
2h
1h
3
2
1
IDEAL AP60 PRO
IDEAL AP80 PRO
www.ideal.de
DE Betriebsanleitung
EN OperatingInstructions
FR Moded´emploi
ES Instruccionesde uso
IT Manualed´istruzione
NL Gebruiksaanwijzing
Luftreiniger
Air Purier
Puricateur
Puricador
Depuratore
Zuiveraar
Product features / Included in the box

29
Unpacking and setting up
Take out the power cable (1.), operating
instructions (2.) and remote control (3. with
self-adhesivemagneticlm).
Remove top packaging tray. Grasp the
AirPurierbytheairintakeductsand
lift it out of the box.
Installation guidelines for optimum performance:
• The air intake ducts on the top can be used as handles
(see adjacent diagram).
• Place the device at least 10 cm away from the wall.
• Keep the device away from areas subjected to draft (wind).
• Make sure that furniture, fabrics or other objects do not come in contact with the air intake/
outlet or block them.
• Placethedeviceonastable,evensurfaceandmakesurethereissufcientaircirculation.
4.
4.
5.
6.
7.
8.
1.
2. 3.
Please remove and dispose the self-adhesive
tape (4. Transport safety).
The front panel is hooked from below at two
ends and is kept closed by totally 4 magnets.
Openthefrontpanelatthetop,gripitrmly(5.)
and then swing it downwards (6.).
Remove the single piece of
cardboard (7. Transport safety).
Remove the front panel (8.).

30
Unpacking and setting up
Hookinthefrontpanelatthebottomrst(13.),
then pivot upwards and press shut (14.).
Connectthepowercabletothedevicerst
(15.), then to the socket (16.).
Note:
Use the original packaging to store the air
purierifyouarenotusingitallyearround.
Packandstoretheltercartridgeairtightto
protect the activated carbon.
Inserttheltercartridgewiththethreetabsin
the notches provided and lock in position by
turning clockwise (12.).
Holdtheltercartridgewithbothhands
using the recessed grips provided and turn it
anti-clockwise (9.).
Takeouttheltercartridge(10.) and remove
theprotectivelm(11.).
7.
8.
9.
14.
13.
13.
14.
10.
9.
10.
11.
12.
14.
13.
15.
16.
Operatingtheairpurierwithoutpanelsand
protective covers (motor protection grille,
ventilation outlet grille, door, etc.) fully and
securely attached is not permitted.
Safety information

31
Air outlet grill
Overview and description of parts
Front panel Power cable
Filter cartridge
Control panel
Air intake ducts

32
Control panel
AOn/off button DQuiet button EAir quality indicator
FFilter replacement
indicator IQuiet indicator
KIR receiver
HTimer indicator
GFan speed indicator
JDaylight sensor LAir quality sensor
BFan speed button CTimer button
Note:
The air quality sensor (L)isrecalibratedthersttimeyouswitchiton(A) and after being
disconnected from the mains power supply. Once the air quality sensor has been calibrated, the
airpurieralwaysstartsinautomaticmode.Iftheltercartridgeismissing,thelterreplacement
(F) and air quality indicators (E) flash red alternately.
MDust sensor

33
Fan speeds
• Press the on/off button (A)toswitchtheairpurieronoroff.
• Theairpurierrunsinautomaticmode . In automatic mode, the fan speed (G) automatically
adapts to the measured air quality. The worse the air quality, the higher the fan speed.
• Press the fan speed button (B)toexitautomaticmode.Theairpuriernowrunsat
fan speed . Press again to increase the fan speed to .
Press again to increase the fan speed to , or to the turbofan speed .
• Theturbospeedsettingforfastpuricationoftheambientairrequirestheairpuriertorunat
maximum capacity. This can only be selected manually.
Timer functions
Pressingthetimerwhiletheairpurierisswitchedonactivatesthe“switch-offtimer” after the
settime,theairpurierswitchesoff:
• Switchtheairpurieron(on/offbuttonA).
• Press the timer button (C) to activate the timer. Press repeatedly to increase the timer time:
(h)   . Each number lights up in turn. Press the timer button again (no number
lights up) to disable the timer function.
• The timer indicator counts the respective time with ( Countdown). The remaining time is
displayed.
Pressingthetimerbuttonwhiletheairpurierisswitchedoffactivatesthe"switch-ontimer"
 afterthesettime,theairpurierswitcheson.
AOn/off button DQuiet button EAir quality indicator
FFilter replacement
indicator IQuiet indicator
KIR receiver
HTimer indicator
GFan speed indicator
JDaylight sensor LAir quality sensor
BFan speed button CTimer button
Control panel

34
Quiet function
The Quiet button (D) is provided for particularly low-noise, unobtrusive operation
(e.g. bedrooms). Press the Quiet button (D) to switch the fan speed (G) to its lowest capacity
and switch off all indicators. Only the Quiet indicator (I) is dimly lit.
Air quality indicator (E)
The air quality is displayed in 3 colours:
Green: good air quality
Yellow: average air quality
Red: poor air quality
Filter replacement indicator (F)
An illuminated red " "onthecontrolpanelindicatesthatthelterneedsreplacing.
• Thelifeexpectancyofthelterisapprox.1year
(dependingonoperationandpuricationactivities).
• Ifodoursarenolongerbeinglteredout,orifthelterproducesunpleasantodours,
thentheltercartridgeneedstobereplacedsooner.
• OnlyuseoriginalIDEALltercartridge.ThedevicewillonlyfunctionwithanoriginalIDEAL
ltercartridge.
Daylight sensor (J)
The display brightness is automatically adjusted to the ambient light.
IR receiver (K)
Receives the signals from the remote control.
Air quality sensor (L)
AOn/off button DQuiet button EAir quality indicator
FFilter replacement
indicator IQuiet indicator
KIR receiver
HTimer indicator
GFan speed indicator
JDaylight sensor LAir quality sensor
BFan speed button CTimer button
Control panel

35
Remote control
Battery usage
• Always use 3V lithium batteries CR2025 for the remote control.
• Incorrect battery usage may result in leakage of battery fluid and/or damage.
• If the remote control is not going to be used for a long time, please remove the battery.
Unsuitable location
• Make sure that no objects or furnishings are situated between the remote control and the
airpurier.
• Theairpuriershouldnotbeplacedindirectsunlight.Thiscouldimpairtheinfraredsensor.
• Locations where fluorescent tubes are flickering because they are defective or old.
• Do not store the remote control in direct sunlight and/or close to radiators/heaters.
•When using for the rst time
The remote control has a pre-installed lithium
battery CR2025. Remove the protective flap to
activate the remote control battery.
How to use correctly
• Pointtheremotecontrolattheairpurier(IRreceiverK).
Turbo Auto
8h
4h
2h
1h
3
2
1
K

36
Important information about the batteries and how to dispose of them
Batteries must NOT be disposed of with household waste. As the user, you are legally obligated
to return used batteries for proper disposal. You can hand in your batteries at public collection
points in your community or wherever the same type of batteries are sold.
• It is very important that you make sure that the polarity of the batteries is correct.
Wronglyinsertedbatteriescoulddestroythedevice–arehazard.
• Donottrytoopenordamagebatteriesanddonotthrowbatteriesintoare.
• Batteries that are leaking fluid are dangerous. Only touch these with suitable gloves.
• Keep batteries out of the reach of children.
• Takethebatteriesoutofthedeviceifyouarenotgoingtobeusingitforasignicant
period of time.
Replacing the battery
• Open the battery compartment by pressing
(A) and pulling out (B) at the same time.
Take out the flat battery.
• Insert a new battery into the battery compart-
ment, making sure the polarity is correct (+ / -).
• Always use 3V lithium batteries CR2025.
• Slide the battery compartment back into its
seating (C).
The remote control comes with a self-
adhesivemagneticlm(D). If required, this
can be stuck on the back of the remote
control.Withthemagneticlmstuckonit,the
remote control can easily be attached to any
ferromagnetic surface
(e.g.onthebackoftheairpurier).
AC
B
CR2025
3V
D
Turbo Auto
8h
4h
2h
1h
3
2
1
Remote control

37
Remote control
N: Select the required fan speed .
O: Switchestheairpuriertoautomaticmode .
P: Switchestheairpurieron/off .
Q: SwitchestheairpuriertoQuietmode .
R: Select the required timer time .
S: Press the locking button tolockthebuttonsonthecontrolpanel(airpurier).
Press the locking button again to unlock.
Thelockcanalsoberemovedbydisconnectingtheairpurierfromthemainsorby
pressing and holding down the on/off button (A) on the device.
Note:
When you operate the remote control, the air quality indicator (E) lights up for approx. 1 second
inacknowledgement.Ifyouoperateabuttononthecontrolpanel(airpurier)whilethelocking
function is activated, the air quality indicator (E) lights up briefly in red.
POn/off button
NFan speed buttons
OAutomatic button
QQuiet button
SLocking button
RTimer buttons
Function
Turbo Auto 8h
4h
2h
1h
3
2
1
AOn/off button EAir quality indicator

38
CAUTION: Disconnect the mains plug!
The front panel is hooked in at the bottom in two
places, and kept shut with 4 magnets. Open the
front panel from the top and hold (1.), pivot
downwards (2.) and take off (3.).
Holdthespentltercartridgewithbothhands
using the recessed grips provided and turn it
anti-clockwise (4.).
Removetheltercartridge(5.). Remove the
protectivelmfromthenewltercartridge(6.).
Insertthenewltercartridgewiththethreetabs
in the notches provided and lock in position by
turning clockwise (7.).
Hookinthefrontpanelatthebottomrst(8.),
then pivot upwards and press shut (9.). Connect
thepowercabletothedevicerst(10.), then to
the socket (11.).
Filter replacement (e.g.inaccordancewiththelterreplacementindicator F, see page 34)
Note:
Only original IDEAL lter cartridges (order from www.ideal.de) may be used. No tools are
required to replace the lter cartridge.
Note:
The air purier automatically detects that a new IDEAL lter cartridge has been inserted
and automatically resets the lter replacement indicator.
1.
2.
3.
4.
5.
6.
7.
10.
11.
9.
8.
Changing the lter

39
App Control / WLAN
App Control
Yourpuriercanadditionallybecontrolledbythe"IDEALAIRPRO"Appviayour
smartphone/tablet (iOS /Android).
WLAN
Enabling/disabling WLAN
Theairpurierisconnectedtothepowersupplyandswitchedoff.
Press and hold down the Quiet button (D) until the air quality indicator (E) flashes
The WLAN is enabled
when the air quality indicator (E) flashes blue
The WLAN is disabled
when the air quality indicator (E) flashes white.
Resetting the WLAN
Theairpurierisdisconnectedfromthepowersupply.
Press and hold down the Quiet button (D), plug in the power cable and continue to hold down
the Quiet button (D) until the air quality indicator (E) flashes pink
The WLAN is reset to factory settings.
Note:
ToensureastableWLANconnection,aminimumdistanceof1mbetweenairpurierand
smartphone/tablet should be maintained during setup (connection setup).
DQuiet button
EAir quality indicator

40
Cleaning and maintenance
CAUTION: Disconnect the mains plug prior to any cleaning or maintenance work!
• Replacetheltercartridgeassoonasthelterreplacementindicator(F, page 34) lights up.
Theaveragelifeexpectancyofthelterisapprox.1year(dependingonoperationand
puricationactivities).
• Cleantheairpurierhousingwithalint-freeclothmoistenedwithsoapywater.
• Clean the control panel with a dry, lint-free cloth.
• Clean the openings for the air quality sensor (L) and the dust sensor (Mpage 32) with a
vacuum cleaner.
• Cleantheairintakeducts(page31)andtheinterioroftheairpurierwithavacuumcleaner.
• Cleantheltercartridge'spre-lterwithavacuumcleaner.Todothis,removethelter
cartridge ("Changing the lter" page 38).
• Do not use any solvents. These could damage the housing surface, the control panel and the
air quality sensor.
• Protecttheairpurierfromwater.
• Do not use any substances containing silicone, since this could destroy the air quality sensor.
• Do not test the effectiveness of the air quality sensor with high quantities of gas, or alcohol,
since this could destroy the air quality sensor.
Cleaning and maintenance / Accessories
Accessories
You can source accessories via your dealer or at www.ideal.de.
IDEALltercartridge Orderno.8741099
Wall mount Order no. 8741 001
Trolley Order no. 8741 002

41
Troubleshooting
The air purier won't switch on. Is the power cable securely connected to
the back of the device?
Make sure that the power cable is not
damaged in any way.
Check both ends of the power cable. Make
sure that these are plugged in and that the
purierisconnectedtothepowersupply
(page 30).
Has a lter cartridge been inserted? Is the
lter cartridge inserted correctly?
MakesurethatanoriginalIDEALlter
cartridge is inserted.
Makesurethattheltercartridgeisclicked
in place with all 3 tabs and is fully locked
(padlock icon, page 30).
The buttons on the air purier do
not work.
The buttons on the remote control do
not work.
Has the locking function been activated?
Disable the locking function on the remote
control (function S,page 37).
Unplug the power cable and then plug it
back in.
Is the battery in the remote control?
Or is it flat?
Check the battery (3V lithium CR2025).
Is the IR receiver dirty?
Clean the IR receiver with a dry, lint-free
cloth.
Are you using it correctly?
Pointtheremotecontrolattheairpurier
(page 35).
Having joined the power cord or
exchangedthelter,thefunctionofthe
remote control is blocked for
about 10 seconds

42
The indicators on the control panel do not
light up at all. Is the air purier switched on?
Switchtheairpurieronbypressingthe
on/off button (A, page 32).
Has the Quiet function been activated?
Disable the Quiet function by pressing
the Quiet button (D, page 34).
Automatic mode is not working properly. The air purier calibrates the air
quality sensor. This happens when you
rst switch it on and after disconnecting it
from the mains.
Wait until the calibration process
(see Note, page 32) has been completed
(this may take a few minutes)
The air quality sensor is dirty.
Clean the openings for the air quality
sensor L, dust sensor M(page 32), the air
intake ducts and the interior of the air
purier(wheretheltercartridgeis
located) with a vacuum cleaner.
The air quality sensor is not detecting the
air quality reliably
Calibrate the air quality sensor by briefly
disconnecting it from the mains again!
Odours are not being ltered properly. Is the air purier continuously exposed to
strong odours?
Thelterneedstobechanged(page38)
becausetheactivatedcarbonlter
becomes saturated and reliable
airpuricationisnolongerguaranteed.
Are the odours being drawn in at all?
Placetheairpurierclosertothesource
of the odours.
Switchtheairpuriermanuallytoahigher
fan speed (page 33).
Troubleshooting

43
The air purier is making loud noises. Is the lter cartridge really dirty?
Cleanthepre-lterwithavacuumcleaner.
Is the air purier located on an even
surface?
Place the device on an even surface.
Is the air purier running at a high fan
speed?
Use the fan speed button (B, page 33) to
set a lower fan speed (G, page 33).
In bright environments, the indicators on
the air purier control panel are too dark. Is the daylight sensor dirty?
Clean the relevant section on the control
panel (J, page 32)!
The display intensity automatically adapts
to its surroundings.
Troubleshooting
Did none of the specied solutions help you
with your problem?
Contact: Service
•www.idealhealthstore.com
Service
