G-Series Cooler
Instruction Manual
TE Cooler
Models: Listed on Inside Cover

Innovative DisplayWorks, Inc. 3
TE Cooler
G-Series Cooler
Instruction Manual
For Future Reference
• This easy-to-use manual will guide you in getting the best use of your cooler.
• Remember to record the model number and the serial number. This information can be
found on the inside of your cooler.
• Keep your receipt with this manual for future warranty service.
Model #:
Serial #:
Date of Purchase:
Models Included:
B61N*
N61N*
(*=G,7,I,M or J plug)
Table of Contents
Safety Instructions & Precautions..........................4
Ambient Environment ............................................5
Circuit Diagram .......................................................5

Innovative DisplayWorks, Inc.
Instruction Manual
4 5
TE Cooler
INSTRUCTIONS
Ambient Environment
•Place cooler on an even surface to reduce vibration and noise.
•To transport, do not tilt the cooler beyond a 45 degree angle.
•Do not place cooler in direct sunlight or near any heat sources.
•Do not place cooler in environment temperatures that exceed 109°F.
•Do not place cooler in below normal temperatures.
•Do not place cooler in extreme humid environments, this may cause components to rust.
•Do not place cooler near constant running or splattering water, this may cause immediate
damage to refrigeration system.
•Must allow at least 2” between rear of cooler and wall for proper ventilation and heat
dissipation of cooler.
•Do not place furniture or other articles with sharp edges near the cooler in order to
prevent damage to the glass door.
TE Cooler CIRCUIT DIAGRAM
R1 Resistor
L1 LED
S1 Switch
TCM Thermoelectric Cooling Module
F1 Fan Motor
F2 Fan Motor
XS1 DC Voltage Outlet
XS2 AC Voltage Outlet
SP1 Switching Power Supply
MCC Micro-Computer Controller
Correct Disposal of this product
This marking idicates that this product
should not be disposed of with other
household waste throughout the
EU. To prevent possible harm to the
environment or human health due to
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable
reuse of material resources. To return
your used device, please use the return
and collections system, or contact
the retailer where the product was
purchased for instructions on disposal.
1. When using this appliance, always follow the basic
safety precautions:
2. DO NOT use the appliance outside. For indoor use
only
3. DO NOT use jet/pressure washers to clean this
appliance.
4. DO NOT allow children to play with the packaging,
and destroy plastic bags safely.
5. Always switch off and disconnect the power supply to
the unit before cleaning.
6. If the power cord is damaged, it must be replaced by
the manufacturer, a service agent or similarly qualifi ed
persons in order to avoid a hazard.
7. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
8. Children should be supervised to ensure that they do
not play with this appliance.
9. This appliance can be used by children age 8 years
and above; and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be preformed by children
without supervision.
10. The appliances are not intended to be operated by
means of an external timer or separate remote-control
system.
11. Keep the appliance and its cord out of reach of
children less than 8 years of age.
12. Do not store explosive substances such as aerosol
cans with a fl ammable propellant in this appliance.
13. The appliance is only to be used with the power supply
unit provided with the appliance.
14. This appliance is intended to be used in household
and similar applications such as
- staff kitchen areas in shops, offi ces and other
working environments;
- farm houses and by clients in hotels, motels and
other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
SAFETY INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS!
DANGER!
PROPER DISPOSAL OF THE
REFRIGERATOR
Pre-Caution, Non-Operating Coolers
Should Have:
1. Door removed.
2. Shelves kept in place in order to
prevent any small child from climbing
inside cooler.
Then the distributor/retailer can contact
their local metal recycling center to pick
up the remaining cabinet, shelves, etc. By
law, disposal of hazardous wastes may be
subject to fi nes and imprisonment under the
provisions of the environmental regulations.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or
damaged.
WARNING: Do not locate multiple portable
socket-outlets or portable power supplies at
the rear of the appliance.
12V DC XS1
MCC
S1
TCM F1 F2
SP1100-240V
AC
XS2
R1
L1
