12 Technical data
Operating voltage [V]������������������������������������������������������������������������������������������18���32 DC1)
Current consumption [mA]��������������������������������������������������������������������������������������������� < 50
Current rating per switching output [mA] ������������������������������������������������������������������������ 100
Reverse polarity protection, overload protection ������������������������������������������������� up to 40 V
Short-circuit protection; Integrated watchdog
Voltage drop [V] �������������������������������������������������������������������������������������������������������������� < 2
Power-on delay time [s] �������������������������������������������������������������������������������������������������� 0�3
Min� response time switching outputs [ms] ��������������������������������������������������������������������� 2�5
Switching frequency [Hz] ���������������������������������������������������������������������������������������max� 200
Accuracy / deviations (in % of the span)
- Set point accuracy �������������������������������������������������������������������������������������������������� < ± 0�5
- Deviation of the characteristics ������������������������������������������ < ± 0�25 (BFSL) / < ± 0�5 (LS)
- Hysteresis����������������������������������������������������������������������������������������������������������������� < 0�25
- Repeatability (in case of temperature fluctuations < 10 K) K ����������������������������������< ± 0�1
- Long-term stability (in % of the span per 6 months) ��������������������������������������������� < ± 0�05
-Temperaturecoefficients(TEMPCO)inthecompensated
temperature range 0 ��� 60 °C (in % of the span per 10 K)
-GreatestTEMPCOofthezeropoint/ofthespan����������������������������������� < ± 0�2 / < ± 0�2
Materials (wetted parts) �������������������������brass;FPM(Viton);silicon(coated);PBT(Pocan)
Housing materials ����������������������������������������������������� PBT(Pocan);FPM(Viton);polyester;
Protection ��������������������������������������������������������������������������������������������������������������� IP 65 III
Insulationresistance[MΩ]������������������������������������������������������������������������ > 100 (500 V DC)
Shock resistance [g] ������������������������������������������������������������� 50 (DIN / IEC 68-2-27, 11 ms)
Vibration resistance [g] ������������������������������������������������ 20 ( DIN / IEC 68-2-6, 10-2000 Hz)
Switching cycles min� ������������������������������������������������������������������������������������������� 50 million
Operating temperature [°C] ���������������������������������������������������������������������������������������� 0���70
Medium temperature [°C] �������������������������������������������������������������������������������������������� 0���60
Storage temperature [°C]������������������������������������������������������������������������������������������ -25���85
EMC EN 61000-4-2 ESD: ��������������������������������������������������������������������������������������� 4 / 8 kV
EN 61000-4-3 HF radiated: ���������������������������������������������������������������������������� 10 V/m
EN 61000-4-4 Burst: ������������������������������������������������������������������������������������������� 2 kV
EN 61000-4-5 Surge: ���������������������������������������������������������������������������������� 0�5 / 1 kV
EN 61000-4-6 HF conducted: ���������������������������������������������������������������������������� 10 V
1) to EN50178, SELV, PELV
BFSL = Best Fit Straight Line / LS = Limit Value Setting
