IEI Technology IMBA-C604EP User manual

IMBA-C604EP ATX Server Board
Page i
IEI Technology Corp.
User Manual
MODEL:
IMBA-C604EP
ATX Server Board for 32nm LGA2011 Intel® Xeon® E5 Series
CPU, Intel® C206 Chipset, DDR3, VGA, Dual Intel®
PCIe GbE, PCIe Gen 3.0, SAS 3Gb/s, SATA 6Gb/s,
USB 3.0, HD Audio and RoHS
Rev. 1.00 – 25 February, 2013

IMBA-C604EP ATX Server Board
Page ii
Revision
Date Version Changes
25 February, 2013 1.00 Initial release

IMBA-C604EP ATX Server Board
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IMBA-C604EP ATX Server Board
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 3
1.3 CONNECTORS ............................................................................................................. 4
1.4 DIMENSIONS............................................................................................................... 5
1.5 DATA FLOW................................................................................................................ 6
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 IMBA-C604EP Layout..................................................................................... 15
3.1.2 Peripheral Interface Connectors ..................................................................... 16
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 18
3.2.1 +12V Power Connector................................................................................... 18
3.2.2 ATX Power Connector ..................................................................................... 18
3.2.3 Battery Connector............................................................................................ 20
3.2.4 Chassis Intrusion Connector............................................................................ 20
3.2.5 DDR3 DIMM Slots........................................................................................... 21
3.2.6 Digital I/O Connector...................................................................................... 22
3.2.7 Fan Connector (CPU)...................................................................................... 23
3.2.8 Fan Connectors (System)................................................................................. 24
3.2.9 Front Panel Audio Connector.......................................................................... 25
3.2.10 Front Panel Connector .................................................................................. 26
3.2.11 I2C Connector................................................................................................ 27

IMBA-C604EP ATX Server Board
Page v
3.2.12 PCIe x8 Slots.................................................................................................. 28
3.2.13 PMBus Connector.......................................................................................... 29
3.2.14 SAS 3Gb/s Drive Connectors......................................................................... 30
3.2.15 SAS LED Connector....................................................................................... 31
3.2.16 SAS SMBus Connector................................................................................... 31
3.2.17 SATA 3Gb/s Drive Connectors....................................................................... 32
3.2.18 SATA 6Gb/s Drive Connectors....................................................................... 33
3.2.19 SMBus Connector .......................................................................................... 34
3.2.20 SPI ROM Connector...................................................................................... 35
3.2.21 TPM Connector.............................................................................................. 36
3.2.22 USB 2.0 Connectors....................................................................................... 37
3.2.23 USB 2.0 Connector (Type A).......................................................................... 38
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 39
3.3.1 Audio Connector .............................................................................................. 39
3.3.2 Ethernet and USB 2.0 Connectors................................................................... 40
3.3.3 Ethernet and USB 3.0 Connectors................................................................... 41
3.3.4 Keyboard and Mouse Connector ..................................................................... 42
3.3.5 Serial Port and VGA Connector ...................................................................... 43
3.3.6 USB 2.0 Connector .......................................................................................... 44
4 INSTALLATION ......................................................................................................... 45
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 46
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 46
4.2.1 Socket LGA2011 CPU Installation .................................................................. 48
4.2.2 Socket LGA2011 Cooling Kit Installation........................................................ 51
4.2.3 DIMM Installation........................................................................................... 52
4.3 JUMPER SETTINGS .................................................................................................... 54
4.3.1 AT/ATX Power Mode Selection Jumper........................................................... 55
4.3.2 Clear CMOS Jumper........................................................................................ 55
4.3.3 USB Power Selection Jumpers......................................................................... 56
4.4 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 57
4.4.1 SATA Drive Connection ................................................................................... 57
4.4.2 Dual-Port USB Cable with Slot Bracket (Optional)........................................ 59
4.5 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 60
4.5.1 Audio Connector .............................................................................................. 61

IMBA-C604EP ATX Server Board
Page vi
4.5.2 LAN Connection............................................................................................... 61
4.5.3 Serial Device Connection ................................................................................ 62
4.5.4 USB Connection (Dual Connector)................................................................. 63
4.5.5 VGA Monitor Connection ................................................................................ 64
4.6 INSTALLING USB 3.0 DRIVER DURING WINDOWS®7OS INSTALLATION................. 65
5 BIOS.............................................................................................................................. 69
5.1 INTRODUCTION......................................................................................................... 70
5.1.1 Starting Setup................................................................................................... 70
5.1.2 Using Setup...................................................................................................... 70
5.1.3 Getting Help..................................................................................................... 71
5.1.4 Unable to Reboot after Configuration Changes.............................................. 71
5.1.5 BIOS Menu Bar................................................................................................ 71
5.2 MAIN........................................................................................................................ 72
5.3ADVANCED............................................................................................................... 73
5.3.1 ACPI Settings................................................................................................... 73
5.3.2 RTC Wake Settings........................................................................................... 75
5.3.3 Trusted Computing........................................................................................... 76
5.3.4 CPU Configuration.......................................................................................... 77
5.3.5 SATA Configuration ......................................................................................... 79
5.3.6 SAS Configuration ........................................................................................... 80
5.3.7 USB Configuration........................................................................................... 80
5.3.8 F81866 Super IO Configuration...................................................................... 82
5.3.8.1 Serial Port 1 Configuration....................................................................... 83
5.3.9 F81866 H/W Monitor....................................................................................... 84
5.3.9.1 Smart Fan Mode Configuration................................................................ 85
5.3.10 Serial Port Console Redirection .................................................................... 86
5.3.11 iEi Feature...................................................................................................... 89
5.3.12 Main Configuration Page.............................................................................. 90
5.3.12.1 NIC Configuration.................................................................................. 91
5.4 CHIPSET ................................................................................................................... 92
5.4.1 North Bridge .................................................................................................... 93
5.4.1.1 NB PCIe Configuration............................................................................. 94
5.4.1.2 Memory Configuration ............................................................................. 95
5.4.2 South Bridge..................................................................................................... 95

IMBA-C604EP ATX Server Board
Page vii
5.5 SERVER MANAGEMENT............................................................................................ 97
5.5.1 Bmc Self Test Log........................................................................................... 100
5.5.2 System Event Log........................................................................................... 101
5.5.3 BMC Network Configuration......................................................................... 103
5.6 BOOT...................................................................................................................... 104
5.7 SECURITY............................................................................................................... 106
5.8 SAVE &EXIT.......................................................................................................... 107
6 SOFTWARE DRIVERS............................................................................................ 109
6.1AVAILABLE SOFTWARE DRIVERS .............................................................................110
6.2 SOFTWARE INSTALLATION .......................................................................................110
6.3 CHIPSET DRIVER INSTALLATION..............................................................................112
6.4 GRAPHICS DRIVER INSTALLATION...........................................................................115
6.5 LAN DRIVER INSTALLATION...................................................................................118
6.6AUDIO DRIVER INSTALLATION ............................................................................... 122
6.7 INTEL®RAPID STORAGE TECHNOLOGY DRIVER INSTALLATION ............................ 124
6.8 USB 3.0 DRIVER INSTALLATION ............................................................................ 127
6.9 ISMM INSTALLATION............................................................................................. 130
A BIOS OPTIONS ........................................................................................................ 135
B ONE KEY RECOVERY........................................................................................... 138
B.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 139
B.1.1 System Requirement....................................................................................... 140
B.1.2 Supported Operating System......................................................................... 141
B.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 142
B.2.1 Hardware and BIOS Setup ............................................................................ 143
B.2.2 Create Partitions ........................................................................................... 143
B.2.3 Install Operating System, Drivers and Applications..................................... 147
B.2.4 Build-up Recovery Partition.......................................................................... 148
B.2.5 Create Factory Default Image....................................................................... 150
B.3AUTO RECOVERY SETUP PROCEDURE.................................................................... 155
B.4 SETUP PROCEDURE FOR LINUX.............................................................................. 160
B.5 RECOVERY TOOL FUNCTIONS ................................................................................ 163
B.5.1 Factory Restore ............................................................................................. 165
B.5.2 Backup System............................................................................................... 166

IMBA-C604EP ATX Server Board
Page viii
B.5.3 Restore Your Last Backup.............................................................................. 167
B.5.4 Manual........................................................................................................... 168
B.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN.................................. 169
B.6.1 Configure DHCP Server Settings.................................................................. 170
B.6.2 Configure TFTP Settings............................................................................... 171
B.6.3 Configure One Key Recovery Server Settings............................................... 172
B.6.4 Start the DHCP, TFTP and HTTP................................................................. 173
B.6.5 Create Shared Directory................................................................................ 173
B.6.6 Setup a Client System for Auto Recovery...................................................... 174
B.7 OTHER INFORMATION............................................................................................ 177
B.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller....................... 177
B.7.2 System Memory Requirement ........................................................................ 179
C TERMINOLOGY ..................................................................................................... 180
D DIGITAL I/O INTERFACE..................................................................................... 184
D.1 INTRODUCTION...................................................................................................... 185
D.2 DIO CONNECTOR PINOUTS ................................................................................... 185
D.3ASSEMBLY LANGUAGE SAMPLES........................................................................... 186
D.3.1 Enable the DIO Input Function .................................................................... 186
D.3.2 Enable the DIO Output Function.................................................................. 186
E WATCHDOG TIMER............................................................................................... 187
F INTEL® MATRIX STORAGE MANAGER.......................................................... 190
F.1 INTRODUCTION....................................................................................................... 191
F.1.1 Precautions .................................................................................................... 191
F.2 FEATURES AND BENEFITS ....................................................................................... 192
F.3 ACCESSING THE INTEL®MATRIX STORAGE MANAGER.......................................... 192
F.4 INSTALLING THE OPERATING SYSTEM TO THE RAIDARRAY.................................. 193
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 194
G.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 195

IMBA-C604EP ATX Server Board
Page ix
List of Figures
Figure 1-1: IMBA-C604EP ..............................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: IMBA-C604EP Dimensions (mm)...............................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connectors and Jumpers.........................................................................................15
Figure 3-2: +12V Power Connector Location.............................................................................18
Figure 3-3: ATX Power Connector Pinout Location..................................................................19
Figure 3-4: Battery Connector Locations...................................................................................20
Figure 3-5: Chassis Intrusion Connector Location...................................................................21
Figure 3-6: DDR3 DIMM Slot Locations......................................................................................22
Figure 3-7: Digital I/O Connector Location ................................................................................23
Figure 3-8: CPU Fan Connector Location..................................................................................24
Figure 3-9: System Fan Connector Locations...........................................................................25
Figure 3-10: Front Panel Audio Connector Location................................................................26
Figure 3-11: Front Panel Connector Location ...........................................................................27
Figure 3-12: I2C Connector Location..........................................................................................28
Figure 3-13: PCIe x8 Slot Locations ...........................................................................................29
Figure 3-14: PMBus Connector Location...................................................................................29
Figure 3-15: SAS 3Gb/s Drive Connector Locations.................................................................30
Figure 3-16: SAS LED Connector Location ...............................................................................31
Figure 3-17: SAS SMBus Connector Location ..........................................................................32
Figure 3-18: SATA 3Gb/s Drive Connector Locations..............................................................33
Figure 3-19: SATA 6Gb/s Drive Connector Locations..............................................................34
Figure 3-20: SMBus Connector Location...................................................................................35
Figure 3-21: SPI ROM Connector Location................................................................................36
Figure 3-22: TPM Connector Location........................................................................................36
Figure 3-23: USB 2.0 Connector Pinout Locations...................................................................37
Figure 3-24: USB 2.0 Connector (Type A) Location..................................................................38
Figure 3-25: External Peripheral Interface Connector..............................................................39
Figure 3-26: Audio Connector.....................................................................................................39

IMBA-C604EP ATX Server Board
Page x
Figure 3-27: Ethernet Connector.................................................................................................40
Figure 3-28: Ethernet Connector.................................................................................................41
Figure 3-29: RS-232 Serial Port Connector Pinouts..................................................................43
Figure 3-30: VGA Connector .......................................................................................................44
Figure 4-1: Disengage the CPU Socket Load Levers................................................................48
Figure 4-2: Remove the Protective Cover..................................................................................49
Figure 4-3: Insert the Socket LGA2011 CPU..............................................................................50
Figure 4-4: Close the Socket LGA2011 ......................................................................................50
Figure 4-5: Optional Cooling Kits ...............................................................................................51
Figure 4-6: Cooling Kit Support Bracket....................................................................................52
Figure 4-7: DIMM Installation.......................................................................................................53
Figure 4-8: AT/ATX Power Mode Selection Jumper Location..................................................55
Figure 4-9: Clear CMOS Jumper Location .................................................................................56
Figure 4-10: USB Power Selection Jumper Locations..............................................................57
Figure 4-11: SATA Drive Cable Connection...............................................................................58
Figure 4-12: SATA Power Drive Connection..............................................................................59
Figure 4-13: Dual USB Cable Connection..................................................................................60
Figure 4-14: Audio Connector.....................................................................................................61
Figure 4-15: LAN Connection......................................................................................................62
Figure 4-16: Serial Device Connection.......................................................................................63
Figure 4-17: USB Connection......................................................................................................64
Figure 4-18: VGA Connector .......................................................................................................65
Figure 4-19: Install Now ...............................................................................................................66
Figure 4-20: Load Driver ..............................................................................................................66
Figure 4-21: Browse for Folder ...................................................................................................67
Figure 4-22: Select the ASMedia XHCI Controller Driver..........................................................67
Figure 4-23: Confirm the Driver File ...........................................................................................68
Figure 4-24: Select the USB Root Hub Driver............................................................................68
Figure 6-1: Introduction Screen............................................................................................... 111
Figure 6-2: Available Drivers.................................................................................................... 111
Figure 6-3: Chipset Driver Welcome Screen........................................................................... 112
Figure 6-4: Chipset Driver License Agreement...................................................................... 113
Figure 6-5: Chipset Driver Read Me File ................................................................................. 113
Figure 6-6: Chipset Driver Setup Operations ......................................................................... 114
Figure 6-7: Chipset Driver Installation Finish Screen............................................................ 115

IMBA-C604EP ATX Server Board
Page xi
Figure 6-8: Graphics Driver Welcome Screen........................................................................ 116
Figure 6-9: Ready to Install the Program ................................................................................ 116
Figure 6-10: Graphics Driver Installation Status.................................................................... 117
Figure 6-11: Graphics Driver Installation Finish Screen ....................................................... 117
Figure 6-12: Windows Control Panel....................................................................................... 118
Figure 6-13: System Control Panel.......................................................................................... 118
Figure 6-14: Device Manager List ............................................................................................ 119
Figure 6-15: Update Driver Software Window ........................................................................ 120
Figure 6-16: Locate Driver Files............................................................................................... 120
Figure 6-17: LAN Driver Installation ........................................................................................ 121
Figure 6-18: LAN Driver Installation Complete....................................................................... 121
Figure 6-19: InstallShield Wizard Welcome Screen ............................................................... 122
Figure 6-20: Audio Driver Software Configuration................................................................. 123
Figure 6-21: Restart the Computer .......................................................................................... 123
Figure 6-22: SATA RAID Driver Welcome Screen.................................................................. 124
Figure 6-23: SATA RAID Driver Warning................................................................................. 125
Figure 6-24: SATA RAID Driver License Agreement.............................................................. 125
Figure 6-25: SATA RAID Driver Read Me File......................................................................... 126
Figure 6-26: SATA RAID Driver Setup Operations................................................................. 126
Figure 6-27: SATA RAID Driver Installation Finish Screen ................................................... 127
Figure 6-28: USB 3.0 Driver Welcome Screen........................................................................ 128
Figure 6-29: USB 3.0 Driver License Agreement.................................................................... 129
Figure 6-30: USB 3.0 Driver Setup Operations....................................................................... 129
Figure 6-31: USB 3.0 Driver Installation Finish Screen ......................................................... 130
Figure 6-32: iSMM Installation Welcome Screen.................................................................... 131
Figure 6-33: iSMM License Agreement.................................................................................... 131
Figure 6-34: Customer Information.......................................................................................... 132
Figure 6-35: Setup Type............................................................................................................ 132
Figure 6-36: Ready to Install the Program .............................................................................. 133
Figure 6-37: iSMM Installation Status...................................................................................... 133
Figure 6-38: iSMM Installation Finish Screen......................................................................... 134
Figure B-1: IEI One Key Recovery Tool Menu ........................................................................ 139
Figure B-2: Launching the Recovery Tool.............................................................................. 144
Figure B-3: Recovery Tool Setup Menu .................................................................................. 144
Figure B-4: Command Prompt ................................................................................................. 145

IMBA-C604EP ATX Server Board
Page xii
Figure B-5: Partition Creation Commands.............................................................................. 146
Figure B-6: Launching the Recovery Tool.............................................................................. 148
Figure B-7: Manual Recovery Environment for Windows..................................................... 148
Figure B-8: Building the Recovery Partition........................................................................... 149
Figure B-9: Press Any Key to Continue .................................................................................. 149
Figure B-10: Press F3 to Boot into Recovery Mode............................................................... 150
Figure B-11: Recovery Tool Menu ........................................................................................... 150
Figure B-12: About Symantec Ghost Window........................................................................ 151
Figure B-13: Symantec Ghost Path ......................................................................................... 151
Figure B-14: Select a Local Source Drive ............................................................................... 152
Figure B-15: Select a Source Partition from Basic Drive ...................................................... 152
Figure B-16: File Name to Copy Image to ............................................................................... 153
Figure B-17: Compress Image.................................................................................................. 153
Figure B-18: Image Creation Confirmation............................................................................. 154
Figure B-19: Image Creation Complete................................................................................... 154
Figure B-20: Image Creation Complete................................................................................... 154
Figure B-21: Press Any Key to Continue ................................................................................ 155
Figure B-22: Auto Recovery Utility.......................................................................................... 156
Figure B-23: Disable Automatically Restart............................................................................ 156
Figure B-24: Launching the Recovery Tool............................................................................ 157
Figure B-25: Auto Recovery Environment for Windows ....................................................... 157
Figure B-26: Building the Auto Recovery Partition................................................................ 158
Figure B-27: Factory Default Image Confirmation ................................................................. 158
Figure B-28: Image Creation Complete................................................................................... 159
Figure B-29: Press any key to continue.................................................................................. 159
Figure B-30: IEI Feature ............................................................................................................ 160
Figure B-31: Partitions for Linux.............................................................................................. 161
Figure B-32: System Configuration for Linux......................................................................... 162
Figure B-33: Access menu.lst in Linux (Text Mode).............................................................. 162
Figure B-34: Recovery Tool Menu ........................................................................................... 163
Figure B-35: Recovery Tool Main Menu.................................................................................. 164
Figure B-36: Restore Factory Default...................................................................................... 165
Figure B-37: Recovery Complete Window.............................................................................. 165
Figure B-38: Backup System.................................................................................................... 166
Figure B-39: System Backup Complete Window ................................................................... 166

IMBA-C604EP ATX Server Board
Page xiii
Figure B-40: Restore Backup ................................................................................................... 167
Figure B-41: Restore System Backup Complete Window..................................................... 167
Figure B-42: Symantec Ghost Window ................................................................................... 168
Figure B-43: Disable Automatically Restart............................................................................ 175

IMBA-C604EP ATX Server Board
Page xiv
List of Tables
Table 1-1: IMBA-C604EP Specifications.......................................................................................9
Table 2-1: Packing List.................................................................................................................13
Table 2-2: Optional Items.............................................................................................................13
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors..............................................................................................17
Table 3-3: +12V Power Connector Pinouts................................................................................18
Table 3-4: ATX Power Connector Pinouts .................................................................................19
Table 3-5: Chassis Intrusion Connector Pinouts......................................................................21
Table 3-6: Digital I/O Connector Pinouts....................................................................................23
Table 3-7: CPU Fan Connector Pinouts......................................................................................24
Table 3-8: System Fan Connector Pinouts ................................................................................25
Table 3-9: Front Panel Audio Connector Pinouts .....................................................................26
Table 3-10: Front Panel Connector Pinouts...............................................................................27
Table 3-11: I2C Connector Pinouts.............................................................................................28
Table 3-12: PMBus Connector Pinouts ......................................................................................30
Table 3-13: SAS 3Gb/s Drive Connector Pinouts......................................................................30
Table 3-14: SAS LED Connector Pinouts...................................................................................31
Table 3-15: SAS SMBus Connector Pinouts..............................................................................32
Table 3-16: SATA 3Gb/s Drive Connector Pinouts....................................................................33
Table 3-17: SATA 6Gb/s Drive Connector Pinouts....................................................................34
Table 3-18: SMBus Connector Pinouts ......................................................................................35
Table 3-19: SPI ROM Connector Pinouts ...................................................................................36
Table 3-20: TPM Connector Pinouts...........................................................................................37
Table 3-21: USB 2.0 Connector Pinouts.....................................................................................38
Table 3-22: USB 2.0 Connector (Type A) Pinouts .....................................................................38
Table 3-23: LAN2 Pinouts ............................................................................................................40
Table 3-24: Connector LEDs........................................................................................................40
Table 3-25: USB 2.0 Port Pinouts................................................................................................41
Table 3-26: LAN Pinouts ..............................................................................................................41
Table 3-27: Connector LEDs........................................................................................................41

IMBA-C604EP ATX Server Board
Page xv
Table 3-28: USB 3.0 Port Pinouts................................................................................................42
Table 3-29: PS/2 Connector Pinouts...........................................................................................42
Table 3-30: RS-232 Serial Port Connector Pinouts...................................................................43
Table 3-31: VGA Connector Pinouts...........................................................................................43
Table 3-32: USB 2.0 Port Pinouts................................................................................................44
Table 4-1: Jumpers.......................................................................................................................54
Table 4-2: AT/ATX Power Mode Selection Jumper Settings....................................................55
Table 4-3: Clear CMOS Jumper Settings....................................................................................56
Table 4-4: USB Power Selection Jumper Settings....................................................................56
Table 5-1: BIOS Navigation Keys................................................................................................71

IMBA-C604EP ATX Server Board
Page xvi
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................72
BIOS Menu 2: Advanced..............................................................................................................73
BIOS Menu 3: ACPI Settings .......................................................................................................74
BIOS Menu 4: RTC Wake Settings..............................................................................................75
BIOS Menu 5: Trusted Computing..............................................................................................76
BIOS Menu 6: CPU Configuration...............................................................................................77
BIOS Menu 7: SATA Configuration.............................................................................................79
BIOS Menu 8: SAS Configuration ...............................................................................................80
BIOS Menu 9: USB Configuration...............................................................................................81
BIOS Menu 10: F81866 Super IO Configuration........................................................................82
BIOS Menu 11: Serial Port 1 Configuration Menu.....................................................................83
BIOS Menu 12: F81866 H/W Monitor...........................................................................................84
BIOS Menu 13: Smart Fan Mode Configuration ........................................................................85
BIOS Menu 14: Serial Port Console Redirection.......................................................................86
BIOS Menu 15: IEI Feature...........................................................................................................89
BIOS Menu 16: Main Configuration Page...................................................................................90
BIOS Menu 17: NIC Configuration ..............................................................................................91
BIOS Menu 18: Chipset................................................................................................................92
BIOS Menu 19: North Bridge .......................................................................................................93
BIOS Menu 20: NB PCIe Configuration ......................................................................................94
BIOS Menu 21: Memory Configuration.......................................................................................95
BIOS Menu 22: South Bridge.......................................................................................................95
BIOS Menu 23: Server Management...........................................................................................97
BIOS Menu 24: BMC Self Test Log .......................................................................................... 100
BIOS Menu 25: System Event Log........................................................................................... 101
BIOS Menu 26: BMC Network Configuration.......................................................................... 103
BIOS Menu 27: Boot.................................................................................................................. 104
BIOS Menu 28: Security............................................................................................................ 106
BIOS Menu 29: Save & Exit.......................................................................................................107

IMBA-C604EP ATX Server Board
Page 1
Chapter
1
1 Introduction

IMBA-C604EP ATX Server Board
Page 2
1.1 Introduction
Figure 1-1: IMBA-C604EP
The IMBA-C604EP is an ATX server board. It accepts a Socket LGA2011 Intel® Xeon®
E5 Series processor (up to 8 cores) and supports eight 240-pin 1600/1333 MHz DDR3
DIMM modules.
The IMBA-C604EP is designed to support PCIe Gen 3.0 specifications with up to 40 lanes
at 8 GT/s I/O bandwidth. In addition, the IMBA-C604EP provides server management
function through the IPMI 2.0 and iKVM support.
The IMBA-C604EP is equipped with one VGA display output. Expansion and I/O include
four PCIe x8 slots, two USB 3.0, eleven USB 2.0, four SAS 3Gb/s connectors, two SATA
6Gb/s connectors, four SATA 3Gb/s connectors and one COM port.

IMBA-C604EP ATX Server Board
Page 3
1.2 Features
Some of the IMBA-C604EP server board features are listed below:
ATX form factor
LGA2011 CPU socket supporting Intel® Xeon® E5 Series processor (up to 8
cores)
Intel® C604 chipset
Quad-channel memory architecture (two DIMMs per channel) with
1600/1333 MHz DDR3 SDRAM support up to 64 GB of UDIMMs, 128 GB of
RDIMMs or 256 GB of LRDIMMs
Dual Intel® PCIe GbE controller
Server management function through the IPMI 2.0 and iKVM support
Supports USB 3.0
Supports SAS 3Gb/s, SATA 6Gb/s and SATA 3Gb/s with RAID function
Supports PCI Express Generation 3.0 up to 40 lanes at 8 GT/s I/O bandwidth
Four PCIe x8 slots
One external RS-232 serial port
High definition audio
RoHS compliant

IMBA-C604EP ATX Server Board
Page 4
1.3 Connectors
The connectors on the IMBA-C604EP are shown in the figure below.
Figure 1-2: Connectors
