IEI Technology HTB-100-HM170 User manual

HTB-100-HM170 Medical Box PC
Page i
User Manual
HTB-100-HM170 Medical Box PC
MODEL:MODEL:
HTB-100-HM170
IEI Fanless Medical Box PC with Intel® Core™ i7-6822EQ /
i5-6442EQ Processor, Isolated COM Ports, GbE LAN,
HDMI, VGA, USB 3.0, Audio, RoHS Compliant,
Rev. 1.00 – October 2, 2017

HTB-100-HM170 Medical Box PC
Page ii
Revision
Date Version Changes
October 2, 2017 1.00 Initial release

HTB-100-HM170 Medical Box PC
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
CONTACT INFORMATION
IEI Integration Corp.
Address: No. 29, Zongxing Rd., Xizhi Dist.,
New Taipei City 221, Taiwan
Phone: [phone]
Fax: [phone]
Web Site: www.ieiworld.com
Sales Email: [email protected]

HTB-100-HM170 Medical Box PC
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical information.
These messages should be read carefully as any directions or instructions
contained therein can help avoid making mistakes.
OPERATING INSTRUCTION
Follow operating instructions or consult instructions for use.
IEC 60417-5009: STAND-BY
IEC 60417-5021: EQUIPOTENTIALITY

HTB-100-HM170 Medical Box PC
Page v
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES................................................................................................................... 3
1.3 MODEL VARIATIONS ................................................................................................... 3
1.4 EXTERNAL OVERVIEW................................................................................................ 3
1.4.1 Front Panel ........................................................................................................ 4
1.4.2 Rear Panel ......................................................................................................... 4
1.5 TECHNICAL SPECIFICATIONS ...................................................................................... 5
1.6 DIMENSIONS............................................................................................................... 7
2 UNPACKING................................................................................................................. 8
2.1 UNPACKING................................................................................................................ 9
2.2 PACKING LIST............................................................................................................. 9
2.3 OPTIONAL ITEMS.......................................................................................................11
3 INSTALLATION ......................................................................................................... 12
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 13
3.2 INSTALLATION PRECAUTIONS................................................................................... 15
3.3 OPENING TOP COVER ............................................................................................... 15
3.4 HDD INSTALLATION................................................................................................. 16
3.5 PCIE MINI CARD INSTALLATION .............................................................................. 18
3.5.1 Full-size PCIe Mini Card Installation ............................................................. 19
3.5.2 Half-size PCIe Mini Card Installation............................................................. 20
3.6 M.2 MODULE INSTALLATION.................................................................................... 22
3.7 SERIAL DEVICE CONNECTION .................................................................................. 24
3.7.1 RS-232 Serial Port (COM3, COM4)................................................................ 24
3.7.2 RS-232/422/485 Serial Port (COM1, COM2) ................................................. 25
3.8 HDMI CABLE HOLDER INSTALLATION..................................................................... 25
3.9 GROUNDING CABLE CONNECTION ........................................................................... 27
3.10 MOUNTING THE SYSTEM ........................................................................................ 28

HTB-100-HM170 Medical Box PC
Page vi
3.11 CABLE COVER INSTALLATION (OPTIONAL)............................................................. 29
3.12AT/ATX MODE SELECTION.................................................................................... 31
3.13 POWER-ON PROCEDURE......................................................................................... 31
3.13.1 Installation Checklist..................................................................................... 31
3.13.2 Power-on Procedure...................................................................................... 32
3.14 CLEAR CMOS........................................................................................................ 33
3.15 DRIVER INSTALLATION........................................................................................... 34
4 BIOS.............................................................................................................................. 35
4.1 INTRODUCTION......................................................................................................... 36
4.1.1 Starting Setup................................................................................................... 36
4.1.2 Using Setup...................................................................................................... 36
4.1.3 Getting Help..................................................................................................... 37
4.1.4 BIOS Menu Bar................................................................................................ 37
4.2 MAIN........................................................................................................................ 38
4.3ADVANCED............................................................................................................... 40
4.3.1 Trusted Computing........................................................................................... 41
4.3.2 ACPI Settings................................................................................................... 42
4.3.3 Super IO Configuration ................................................................................... 43
4.3.3.1 Serial Port n Configuration....................................................................... 43
4.3.4 iWDD H/W Monitor......................................................................................... 50
4.3.5 RTC Wake Settings........................................................................................... 51
4.3.6 Serial Port Console Redirection ...................................................................... 52
4.3.6.1 Console Redirection Settings.................................................................... 53
4.3.7 CPU Configuration.......................................................................................... 55
4.3.8 SATA Configuration ......................................................................................... 58
4.3.9 NVMe Configuration........................................................................................ 59
4.3.10 USB Configuration......................................................................................... 60
4.3.11 IEI Feature ..................................................................................................... 61
4.4 CHIPSET ................................................................................................................... 62
4.4.1 System Agent (SA) Configuration .................................................................... 63
4.4.1.1 Graphics Configuration............................................................................. 64
4.4.1.2 PEG Port Configuration............................................................................ 66
4.4.1.3 Memory Configuration ............................................................................. 67
4.4.2 PCH-IO Configuration .................................................................................... 68

HTB-100-HM170 Medical Box PC
Page vii
4.4.2.1 PCI Express Configuration....................................................................... 70
4.4.2.2 HD Audio Configuration........................................................................... 71
4.5 SECURITY................................................................................................................. 72
4.6 BOOT........................................................................................................................ 73
4.7 SAVE &EXIT............................................................................................................ 75
5 TROUBLESHOOTINGAND MAINTENANCE ..................................................... 77
5.1 HTB-100-HM170 SYSTEM MAINTENANCE OVERVIEW ........................................... 78
5.2 SYSTEM TROUBLESHOOTING.................................................................................... 78
5.2.1 The System Doesn’t Turn On............................................................................ 78
5.2.2 The System Doesn’t Boot Up............................................................................ 79
5.2.3 More Troubleshooting...................................................................................... 79
5.3 COMPONENT REPLACEMENT PROCEDURE ................................................................ 80
5.3.1 SO-DIMM Replacement................................................................................... 80
6 INTERFACE CONNECTORS................................................................................... 83
6.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 84
6.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 85
6.2.1 +12 V Power Input Connector (CN3).............................................................. 86
6.2.2 Battery Connector (BAT1) ............................................................................... 86
6.2.3 Chassis Intrusion Connector (CHASSIS1)....................................................... 86
6.2.4 Digital I/O Connector (DIO1)......................................................................... 87
6.2.5 Fan Connector, CPU (CPU_FAN1)................................................................. 87
6.2.6 Fan Connector, System (SYS_FAN1)................................................................ 87
6.2.7 I2C Connector (I2C1)....................................................................................... 88
6.2.8 iDP Connector (DP1) ...................................................................................... 88
6.2.9 Keyboard/Mouse Connector (KB/MS1)........................................................... 89
6.2.10 PCIe Mini Slot, Full-size (MPCIE1).............................................................. 89
6.2.11 PCIe Mini Slot, Half-size (MPCIE2).............................................................. 90
6.2.12 RS-232 Serial Port Connectors (COM5, COM6).......................................... 91
6.2.13 SATA Power Connectors (SATA_PWR1, SATA_PWR2)................................. 91
6.2.14 SMBus Connector (SMB1)............................................................................. 92
6.2.15 Power Button Connector (PWR_CONN1)..................................................... 92
6.2.16 SPI Flash Connector, BIOS (JSPI1) .............................................................. 92
6.2.17 SPI Flash Connector, EC (JSPI2).................................................................. 93

HTB-100-HM170 Medical Box PC
Page viii
6.2.18 TPM Connector (CN1)................................................................................... 93
6.2.19 USB 2.0 Connector (USB1) ........................................................................... 94
6.2.20 VGA Power Connector (CN2)........................................................................ 94
6.3 EXTERNAL INTERFACE PANEL CONNECTORS............................................................ 94
6.3.1 HDMI Connector (HDMI1)............................................................................. 95
6.3.2 Ethernet and USB 3.0 Combo Connectors ...................................................... 95
6.3.3 Power Input Jack (PWR1) ............................................................................... 96
6.3.4 USB 2.0 Connectors (USB3)............................................................................ 96
6.3.5 VGA Connector (VGA1)................................................................................... 97
A REGULATORY COMPLIANCE.............................................................................. 98
B SAFETY PRECAUTIONS....................................................................................... 103
B.1 SAFETY PRECAUTIONS........................................................................................... 104
B.1.1 General Safety Precautions........................................................................... 104
B.1.2 Anti-static Precautions .................................................................................. 105
B.1.3 Product Disposal........................................................................................... 106
B.1.4 Classification................................................................................................. 107
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ...................................................... 107
B.2.1 Maintenance and Cleaning............................................................................ 107
B.2.2 Cleaning Tools............................................................................................... 108
C BIOS MENU OPTIONS........................................................................................... 109
C.1 BIOS CONFIGURATION OPTIONS ............................................................................110
D WATCHDOG TIMER ...............................................................................................112
E HAZARDOUS MATERIALS DISCLOSURE ........................................................115

HTB-100-HM170 Medical Box PC
Page ix
List of Figures
Figure 1-1: HTB-100-HM170 Series Medical Box PC...................................................................2
Figure 1-2: Front Panel ..................................................................................................................4
Figure 1-3: Rear Panel....................................................................................................................4
Figure 1-4: Dimensions (mm)........................................................................................................7
Figure 3-1: Top Cover Retention Screws...................................................................................16
Figure 3-2: HDD Bracket Retention Screws...............................................................................17
Figure 3-3: Inserting the HDD......................................................................................................17
Figure 3-4: Installing the HDD .....................................................................................................18
Figure 3-5: PCIe Mini Slot Locations..........................................................................................18
Figure 3-6: Removing the Retention Screw...............................................................................19
Figure 3-7: Inserting the Full-size PCIe Mini Card into the Slot at an Angle..........................20
Figure 3-8: Securing the Full-size PCIe Mini Card ....................................................................20
Figure 3-9: Removing the Retention Screw...............................................................................21
Figure 3-10: Inserting the Half-size PCIe Mini Card into the Slot at an Angle........................21
Figure 3-11: Securing the Half-size PCIe Mini Card..................................................................22
Figure 3-12: M.2 Module Slot Location.......................................................................................22
Figure 3-13: Inserting the M.2 Module into the Slot at an Angle .............................................23
Figure 3-14: Securing the M.2 Module........................................................................................23
Figure 3-15: HDMI Cable Holder Screw......................................................................................25
Figure 3-16: Insert into the HDMI Cable Holder.........................................................................26
Figure 3-17: Secure the HDMI Cable Holder ..............................................................................26
Figure 3-18: Secure the HDMI Cable...........................................................................................27
Figure 3-19: Grounding Cable Connection................................................................................27
Figure 3-20: Mounting Bracket Retention Screws ....................................................................28
Figure 3-21: Mounting Bracket Installation................................................................................29
Figure 3-22: Side Screws Removal.............................................................................................30
Figure 3-23: Cable Cover Installation.........................................................................................30
Figure 3-24: AT/ATX Mode Select Switch Location ..................................................................31
Figure 3-25: Power Button and Power LED ...............................................................................33
Figure 3-26: Clear CMOS Button.................................................................................................33
Figure 5-1: Elevated Platform Retention Screws ......................................................................81

HTB-100-HM170 Medical Box PC
Page x
Figure 5-2: SO-DIMM Location....................................................................................................81
Figure 5-3: SO-DIMM Installation................................................................................................82
Figure 6-1: Jumper and Connector Locations...........................................................................84

HTB-100-HM170 Medical Box PC
Page xi
List of Tables
Table 1-1: Model Variations...........................................................................................................3
Table 1-2: Technical Specifications..............................................................................................6
Table 2-1: Package List................................................................................................................11
Table 3-1: RS-232 Serial Port (COM1) Pinouts ..........................................................................24
Table 3-2: RS-232/422/485 Serial Port Pinouts..........................................................................25
Table 4-1: BIOS Navigation Keys................................................................................................37
Table 6-1: Peripheral Interface Connectors...............................................................................86
Table 6-2: +12 V Power Input Connector (CN3) Pinouts...........................................................86
Table 6-3: Battery Connector (BAT1) Pinouts...........................................................................86
Table 6-4: Chassis Intrusion Connector (CHASSIS1) Pinouts.................................................86
Table 6-5: Digital I/O Connector (DIO1) Pinouts........................................................................87
Table 6-6: CPU Fan Connector (CPU_FAN1) Pinouts...............................................................87
Table 6-7: System Fan Connector (SYS_FAN1) Pinouts..........................................................87
Table 6-8: I2C Connector (I2C1) Pinouts.....................................................................................88
Table 6-9: iDP Connector (DP1) Pinouts....................................................................................88
Table 6-10: Keyboard/Mouse Connector (KB/MS1) Pinouts ....................................................89
Table 6-11: Full-size PCIe Mini Slots (MPCIE1) Pinouts...........................................................90
Table 6-12: Half-size PCIe Mini Slots (MPCIE2) Pinouts...........................................................91
Table 6-13: RS-232 Serial Port Connector (COM5, COM6) Pinouts.........................................91
Table 6-14: SATA Power Connectors (SATA_PWR1, SATA_PWR2) Pinouts.........................91
Table 6-15: SMBus Connector (SMB1) Pinouts.........................................................................92
Table 6-16: Power Button Connector (PWR_CONN1) Pinouts ................................................92
Table 6-17: SPI Flash Connector (JSPI1) Pinouts.....................................................................92
Table 6-18: SPI Flash Connector (JSPI2) Pinouts.....................................................................93
Table 6-19: TPM Connector (CN1) Pinouts ................................................................................93
Table 6-20: USB 2.0 Connector (USB1) Pinouts........................................................................94
Table 6-21: VGA Power Connector (CN2) Pinouts ....................................................................94
Table 6-22: Peripheral Interface Connectors.............................................................................95
Table 6-23: HDMI Connector (HDMI1) Pinouts...........................................................................95
Table 6-24: Ethernet Connector Pinouts....................................................................................95
Table 6-25: USB 3.0 Connector Pinouts.....................................................................................96

HTB-100-HM170 Medical Box PC
Page xii
Table 6-26: Power Input Jack (PWR1) Pinouts..........................................................................96
Table 6-27: USB 2.0 Connectors (USB3) Pinouts......................................................................96
Table 6-28: VGA Connector (VGA1) Pinouts .............................................................................97

HTB-100-HM170 Medical Box PC
Page xiii
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................38
BIOS Menu 2: Advanced..............................................................................................................40
BIOS Menu 3: Trusted Computing..............................................................................................41
BIOS Menu 4: ACPI Settings .......................................................................................................42
BIOS Menu 5: Super IO Configuration........................................................................................43
BIOS Menu 6: Serial Port n Configuration Menu.......................................................................43
BIOS Menu 7: iWDD H/W Monitor ...............................................................................................50
BIOS Menu 8: RTC Wake Settings..............................................................................................51
BIOS Menu 9: Serial Port Console Redirection.........................................................................52
BIOS Menu 10: Console Redirection Settings...........................................................................53
BIOS Menu 11: CPU Configuration.............................................................................................55
BIOS Menu 12: SATA Configuration...........................................................................................58
BIOS Menu 13: Intel(R) Rapid Start Technology Configuration ..............................................59
BIOS Menu 14: USB Configuration.............................................................................................60
BIOS Menu 15: iEi Feature...........................................................................................................61
BIOS Menu 16: Chipset................................................................................................................62
BIOS Menu 17: System Agent (SA) Configuration....................................................................63
BIOS Menu 18: Graphics Configuration.....................................................................................64
BIOS Menu 19: NB PCIe Configuration ......................................................................................66
BIOS Menu 20: Memory Configuration.......................................................................................67
BIOS Menu 21: PCH-IO Configuration........................................................................................68
BIOS Menu 22: PCI Express Configuration ...............................................................................70
BIOS Menu 23: PCH Azalia Configuration .................................................................................71
BIOS Menu 24: Security...............................................................................................................72
BIOS Menu 25: Boot.....................................................................................................................73
BIOS Menu 26: Save & Exit..........................................................................................................75

HTB-100-HM170 Medical Box PC
Page 1
Chapter
1
1 Introduction

HTB-100-HM170 Medical Box PC
Page 2
1.1 Overview
Figure 1-1: HTB-100-HM170 Series Medical Box PC
The HTB-100-HM170 fanless medical box PC is powered by Intel® Corei7-6822EQ or
Intel® Corei5-6442EQ processor. It is designed for medical applications that require
reliable operating and easy maintenance features.
The HTB-100 is compliant with medical standards, including IEC 60601-1 V3.1, IEC
60601-1-2 V4.0, IEC 62304, IEC 62366, ISO 14971 and FCC part 18 Class B, making the
medical environment more reliable.
The HTB-100-HM170 accepts a wide range of DC power input (12 V–28 V), allowing it to
be powered anywhere. All of the COM ports support 4kV isolation that meets medical
standard. The display interface options include VGA and HDMI with three audio jacks.
The HTB-100-HM170 series systems are all capable of supporting one 2.5” SATA 6Gb/s
solid-state drive (SSD) or an mSATA module.

HTB-100-HM170 Medical Box PC
Page 3
1.2 Features
The HTB-100-HM170 has the following features
Medical grade with high performance fanless embedded computing
6th Gen Intel® Core™ processor platform with Intel® HM170 chipset and
DDR4 memory
Triple independent display with high resolution support; supports up to
4096x2160 resolutions with HDMI interface
Isolated COM ports for increasing safer applications among devices
Support six USB ports (two USB 2.0 and four USB 3.0)
Support one SATA 6Gb/s SSD or HDD
IP41 compliant top cover and cable cover
Optional PCIe x16 expansion for adding more flexible expansion functions
RoHS compliant design
1.3 Model Variations
There are two models in the HTB-100-HM170 medical box PC series. The two models are
all preinstalled with 4 GB of DDR4 memory. The model variations are listed in 654Table 1-1
below.
Processor
HTB-100-HM170-i7/4G-R10 Intel® Corei7-6822EQ 2.0 GHz
(up to 2.8 GHz, quad-core, 25W TDP)
HTB-100-HM170-i5/4G-R10 Intel® Corei5-6442EQ 1.9 GHz
(up to 2.7 GHz, quad-core, 25W TDP)
Table 1-1: Model Variations
1.4 External Overview
The HTB-100-HM170 RoHS compliant, fanless medical box PC features industrial grade
components that offer longer operating life, high shock/vibration resistance and endurance
over a wide temperature range. The HTB-100-HM170 combines these features in an

HTB-100-HM170 Medical Box PC
Page 4
aluminum enclosure, offering system integrators and developers the best selection of
robust and high performance computing system platforms for medical applications.
1.4.1 Front Panel
The front panel of the HTB-100-HM170 provides access to the following external I/O
connectors and buttons/switches as shown in 654Figure 1-2 below.
Figure 1-2: Front Panel
1.4.2 Rear Panel
An overview of the rear panel is shown in 654Figure 1-3.
Figure 1-3: Rear Panel

HTB-100-HM170 Medical Box PC
Page 5
1.5 Technical Specifications
The specifications for the Intel based medical box PCs are listed below.
HTB-100-HM170
CPU Intel® Core™ i7-6822EQ 2.0 GHz (up to 2.8 GHz, quad-core, 25W TDP)
Intel® Core™ i5-6442EQ 1.9 GHz (up to 2.7 GHz, quad-core, 25W TDP)
Chipset Intel® HM170
System Memory 2 x 260-pin DDR4 SO-DIMM slot (system max. 32 GB)
Preinstalled one 4.0 GB DDR4 SDRAM SO-DIMM
Thermal Solution Fanless
Ethernet 2 x RJ-45 PCIe GbE by Intel® I211 Ethernet controller
Display 1 x HDMI 2.0 port (up to 4096x2160 @ 60 Hz)
1 x VGA port (up to 1920x1200 @ 60 Hz)
Serial Port 2 x RS-232 (DB-9 with 4 kV isolation)
2 x RS-232/422/485 (DB-9 with 4 kV isolation)
USB 2 x USB 2.0 ports
4 x USB 3.0 ports
Audio Realtek ALC662 5.1-channel High Definition Audio (HDA)
1 x Audio line-in
1 x Audio line-out
1 x Audio mic-in
Storage 1 x 2.5” SATA 6Gb/s HDD/SSD bay
Expansion 1 x PCIe x16 slot
1 x Half-size PCIe Mini card slot
1 x Full-size PCIe Mini card slot with mSATA support (colay with SATA)
1 x M.2 slot (A-key & B-key)

HTB-100-HM170 Medical Box PC
Page 6
Chassis Construction Extruded aluminum alloy
Power Requirement 12 V–28 V DC
Power Supply 120 W medical-grade power adapter (Darfon H1120-B0)
Input: 100 V AC ~ 240 V AC, 47 Hz ~ 63 Hz, 2.0 A ~ 1.0 A
Output: 120 W Max., 19 V 6.31 A
Power Consumption 19 V @ 4.4 A (with Intel® Core™ i7-6822EQ processor and 4 GB DDR4
memory)
Operating Shock Half-sine wave shock 5G; 11ms; 100 shocks per axis
Operating Vibration MIL-STD-810G 514.6C-1 (with SSD)
Operating Temperature 0ºC–40ºC with air flow (SSD)
Storage Temperature -40ºC–70ºC with air flow (SSD)
Humidity 10%–95%, non-condensing
Color Silver + Grayish blue
Mounting Wall mounting
Weight (Net/Gross) 2.2 kg / 3.0 kg
Dimensions (W x D x H) 294 mm x 209 mm x 90.2 mm
Safety/EMC CE, FCC class B part 18, IEC 60601-1 V3.1, IEC 60601-1-2 V4.0,
IEC 62304, IEC 62366, ISO 14971
IP Rating IP 41 compliant top cover
Supported OS Microsoft Windows 8 or 8.1
Microsoft Windows 10
Microsoft Windows Embedded Standard 7
Table 1-2: Technical Specifications
