IEI Technology PM-BT-E38xx1W2-R10 Series User manual

1
PC/104-Plus SBC with Intel® Atom™/Celeron® on-board SoC with
DDR3L, VGA, LVDS, GbE, USB 2.0, SATA 3Gb/s,
RS-232/422/485 and 5V DC input, RoHS
PM-BT
Quick Installation Guide
Version 1.0
Jun 15, 2018.
Package List
PM-BT package includes the following items:
1 x PM-BT single board computer
1 x COM port cable
1 x LAN cable
1 x SATA cable kit
1 x Single-port USB cable
1 x VGA cable
©2018 Copyright by IEI Integration corp.
All rights reserved.

2
Specifications
SoC:
Intel® Atom™ E3845 on-board SoC (1.91GHz, quad-core,
2MB cache, TDP=10W)
Intel® Atom™ E3827 on-board SoC (1.75GHz, dual-core, 1MB
cache, TDP=8W)
Intel® Atom™ E3826 on-board SoC (1.46GHz, dual-core, 1MB
cache, TDP=7W)
Intel® Atom™ E3825 on-board SoC (1.33GHz, dual-core, 1MB
cache, TDP=6W)
Intel® Atom™ E3815 on-board SoC (1.46GHz, single-core,
512KB cache, TDP=5W)
Intel® Celeron® J1900 on-board SoC (2GHz, quad-core, 2MB
cache, TDP=10W)
Intel® Celeron® N2930 on-board SoC (1.83GHz, quad-core,
2MB cache, TDP=7.5W)
Intel® Celeron® N2807 on-board SoC (1.58GHz, dual-core,
2MB cache, TDP=4.3W)
Memory:
One 204-pin 1333/1066 MHz single-channel DDR3L
SO-DIMM supports up to 8 GB (J1900, N2930, E3845, E3827,
E3826, E3825, E3815) or 4 GB (N2807)
BIOS: AMI UEFI BIOS
Graphics:
Intel® HD Graphics Gen 7 Engine with four execution units,
supporting DX11.1, OpenGL 4.2 and OpenCL1.2
Display Output:
Dual independent display
1 x VGA (up to 2560x1600@60 Hz)
1 x 18/24-bit single-channel LVDS (2x10 pin)
Ethernet:
1 x Intel® I210
Super I/O:
Fintek F81866

3
Internal I/O Interface:
1 x SATA 3Gb/s with 5V SATA power connector
3 x USB 2.0 (1x4 pin, P=1.25)
2 x RS-232/422/485 (2x5, P=2.0)
Storage:
On-board SSD (optional, support by request)
Front Panel:
1 x 10-pin header, P=2.0 (power LED, HDD LED, power button
and reset button)
Expansion:
1 x Full-size PCIe Mini slot (supports mSATA)
1 x PC/104-Plus (ISA+PCI)
* The ISA function is limited. Please refer to page 5 for
details.
Digital I/O:1 x 8-bit digital I/O (2x5 pin, P=2.0)
Power supply:
5V DC input
12V for fan, LVDS and PCI-104 plus
» 5V for PCI-104 plus (1x3 pin, P=2.0)
» 12V for PCI-104 plus (1x3 pin, P=2.0)
3/5V jumper for PCI-104 plus
Support AT/ATX mode
ErP/EuP Compliant
Watchdog Timer:
Software programmable, supports 1~255 sec. system reset
Operating Temperature:
-20°C ~ 60°C (for J1900/N2930/N2807)
-40°C ~ 85°C (for E38xx)
Storage Temperature: -40°C ~ 85°C
Thermal: Heatsink
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 96 mm x 90 mm

4
Weight: GW: 500g / NW 120g
CE/FCC compliant
Ordering Information

PC/104-Plus Single Board Computer with Intel® Atom™
PM-BT-J19001-R10:
J1900 SoC with DDR3L, VGA, LVDS, USB 2.0, SATA 3Gb/s,
GbE, RS-232/422/485 and 5V DC input, RoHS

PC/104-Plus Single Board Computer with Intel® Atom™
PM-BT-N28071-R10:
N2807 SoC with DDR3L, VGA, LVDS, USB 2.0, SATA 3Gb/s,
GbE, RS-232/422/485 and 5V DC input, RoHS
PM-BT-E38xx1W2-R10**:
PC/104-Plus Single Board Computer with Intel® Atom™
E38xx SoC with DDR3L, VGA, LVDS, USB 2.0, SATA 3Gb/s,
GbE, RS-232/422/485 and 5V DC input, RoHS,-40°C ~ 85°C
**Note: Models with other CPUs not listed in the table are requested
by MOQ - 100 pcs/lot.
All the drivers and One Key Recovery
utility for the PM-BT are available on IEI
Resource Download Center. Type
PM-BT and press Enter to find all the
relevant software, utilities, and
documentation. To install software from
the downloaded ISO file, mount the file
as a virtual drive to view its content.
IEI Resource Download Center
https://download.ieiworld.com

5

PC104 plus spacer (For PCI) 120 Pin socket connector
33403-000015-RS:

PC104 plus spacer (For ISA) 64+40 Pin socket connector
33403-000016-RS:
NOTE:
ISA Limitation of PM-BT
Due to the limitation of Intel® Bay Trail processors, the PM-BT does not
support the following features:
Bus Master Cycles
DMA
LPC Memory Mapped Transactions
IRQ0, IRQ1, IRQ2, IRQ8, IRQ9, IRQ13, IRQ14
ISA Enable (IE) Bit
PnP

6
Jumpers setting and connectors
LABEL FUNCTION
BAT1 Clear COMS Setup
J_ATX_AT1 Select ATX or AT Mode
J_VLVDS1 LVDS VDD Power Selection
SW1 LVDS Panel Resolution Selection
PCI_P_CN1 PCI Power Voltage Selection
ISA_P_CN1 ISA Power Voltage Selection ( External Input )
LAN1 LAN Port
PWR1 DC +5V Power IN
F_PANEL1 F_PANEL Pin Connector
PC104_PLUS1 PCI-104 Plus slot ( PCI )
CN1 PCI-104 slot ( ISA )
JSPI1 SPI Flash Connector
INV_CN1 Panel Power Supply
M_PCIE1 PCI-E Mini Card for M-SATA
LVDS1 LVDS Connector
DIMM1 DDR3L SO-DIMM Slot
SATA1 SATA Connector
SATA_PWR1 SATA Power Connector
COM1, COM2 Internal RS-232/RS-422/RS-485 Serial Port Connectors
USB1, USB2, USB3
Internal USB 2.0 Connectors
DIO1 Digital Input / Output Connector
J_ATX_AT1: Select ATX or AT Mode
PIN NO.
DESCRIPTION
Short A - B ATX mode (default)
Short B - C
AT mode
BAT1: Clear COMS Setup
PIN NO.
DESCRIPTION
Short
Clear CMOS

7
ISA_P_CN1: ISA Power Voltage Selection ( External Input )
PIN NO.
DESCRIPTION
1
-12V (default)
2
GND
3
-5V
PCI_P_CN1: PCI Power Voltage Selection
PIN NO. DESCRIPTION
Short 1 - 2 +3.3V (default)
Short 2 - 3
+5V
SW1: LVDS Panel Resolution Selection (ON=0, OFF=1) (S=Single)
SW1 DESCRIPTION
4-3-2-1
0000
800 x 600 18bit S (default)
0001
1024 x 768 18bit S
0010
1024 x 768 24bit S
0011
1280 x 768 18bit S
0100 1280 x 800 18bit S
0101
1280 x 960 18bit S
0111
1366 x 768 18bit S
1000
1366 x 768 24bit S
J_VLVDS1: LVDS VDD Power Selection
PIN NO.
DESCRIPTION
Short 1 - 3 Back-light Enable +3.3V (default)
Short 2 - 4
Set The Voltage Level Of Panel To +3.3V (default)
Short 3 - 5
Back-light Enable +5V
Short 4 - 6
Set The Voltage Level Of Panel To +5V

8
F_PANEL1: F_PANEL Pin Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 VCC 2 GND
3 PWR_LED+ 4 PWR_LED-
5 HDD_LED+ 6 HDD_LED-
7 PWR_BTN+ 8 PWR_BTN-
9 RESET+ 10 RESET-
PWR1: DC +5V Power IN
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 12V 2 GND
3 5V
LAN1: LAN Port
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 LAN1_MDX0+ 2 LAN1_MDX0-
3 LAN1_MDX1+ 4 LAN1_MDX1-
5 LAN1_MDX2+ 6 LAN1_MDX2-
7 LAN1_MDX3+ 8 LAN1_MDX3-
9 LAN_GND 10 LAN_GND
11 LAN_LINKLED+ 12 LAN_LINKLED-
13 LAN_SPEEDLED 14 LAN_SPEEDLED2

9
PC104_PLUS1: PC-104 Plus Connector
PIN
Description
PIN
Description
PIN
Description
PIN
Description
A1
GND
B1
SERIRQ_PCI
C1
+V5S
D1
A_D0
A2
+PIO_VCC
B2
A_D2
C2
A_D1
D2
+V5S
A3
A_D5
B3
GND
C3
A_D4
D3
A_D3
A4
C_BE0
B4
A_D7
C4
GND
D4
A_D6
A5
GND
B5
A_D9
C5
A_D8
D5
GND
A6
A_D11
B6
+PIO_VCC
C6
A_D10
D6
GND
A7
A_D14
B7
A_D13
C7
GND
D7
A_D12
A8
+V3.3S
B8
C_BE1
C8
A_D15
D8
+V3.3S
A9
-SERR
B9
GND
C9
+V3.3S
D9
PAR
A10
GND
B10
-PERR
C10
+V3.3S
D10
+V3.3S
A11
-STOP
B11
+V3.3S
C11
-PLOCK
D11
GND
A12
+V3.3S
B12
-TRDY
C12
GND
D12
-DEVSEL
A13
-FRAME
B13
GND
C13
-IRDY
D13
+V3.3S
A14
GND
B14
A_D16
C14
+V3.3S
D14
C_BE2
A15
A_D18
B15
+V3.3S
C15
A_D17
D15
GND
A16
A_D21
B16
A_D20
C16
GND
D16
A_D19
A17
+V3.3S
B17
A_D23
C17
A_D22
D17
+V3.3S
A18
A_D16
B18
GND
C18
A_D17
D18
A_D18
A19
A_D24
B19
C_BE3
C19
+PIO_VCC
D19
A_D19
A20
GND
B20
A_D26
C20
A_D25
D20
GND
A21
A_D29
B21
+V5S
C21
A_D28
D21
A_D27
A22
+V5S
B22
A_D30
C22
GND
D22
A_D31
A23
PREQ-0
B23
GND
C23
PREQ-1
D23
+PIO_VCC
A24
GND
B24
PREQ-2
C24
+V5S
D24
PGNT-0
A25
PGNT-1
B25
+PIO_VCC
C25
PGNT-2
D25
GND
A26
+V5S
B26
PCLK_BUF0
C26
GND
D26
PCLK_BUF1
A27
PCLK_BUF2
B27
+V5S
C27
PCLK_BUF3
D27
GND
A28
GND
B28
-PIRQD
C28
+V5S
D28
PCIRST-
A29
+V12S
B29
-PIRQA
C29
-PIRQB
D29
-PIRQC
A30
-12V
B30
PREQ-3
C30
PREQ-3
D30
GND

10
CN1: PC-104 ISA Connector
PIN
Description
PIN
Description
PIN
Description
PIN
Description
A1
IOCHK#
B1
GND
C1
GND
D1
GND
A2
SD7
B2
RSTDRV
C2
SBHE#
D2
MEMCS16#
A3
SD6
B3
+V5S
C3
LA23
D3
IOCS16#
A4
SD5
B4
IRQ9
C4
LA22
D4
IRQ10
A5
SD4
B5
-5V
C5
LA21
D5
IRQ11
A6
SD3
B6
DRQ2
C6
LA20
D6
IRQ12
A7
SD2
B7
-12V
C7
LA19
D7
IRQ15
A8
SD1
B8
NOWS#
C8
LA18
D8
IRQ14
A9
SD0
B9
+V12S
C9
LA17
D9
DACK0#
A10
IOCHRDY
B10
GND
C10
MEMR#
D10
DRQ0
A11
AEN
B11
SMEMW#
C11
MEMW#
D11
DACK5#
A12
SA19
B12
SMEMR#
C12
SD8
D12
DRQ5
A13
SA18
B13
IOW#
C13
SD9
D13
DACK#6
A14
SA17
B14
IOR#
C14
SD10
D14
DRQ6
A15
SA16
B15
DACK3#
C15
SD11
D15
DACK#7
A16
SA15
B16
DRQ3
C16
SD12
D16
DRQ7
A17
SA14
B17
DACK1#
C17
SD13
D17
+V5S
A18
SA13
B18
DRQ1
C18
SD14
D18
RMASTER#
A19
SA12
B19
REFRESH#
C19
SD15
D19
GND
A20
SA11
B20
SYSCLK
C20
N/C
D20
GND
A21
SA10
B21
IRQ7
A22
SA9
B22
IRQ6
A23
SA8
B23
IRQ5
A24
SA7
B24
IRQ4
A25
SA6
B25
IRQ3
A26
SA5
B26
DACK2#
A27
SA4
B27
TC
A28
SA3
B28
BALE
A29
SA2
B29
+V5S
A30
SA1 B30
ISA_14.318M
_OUT1
A31
SA0
B31
GND
A32
GND
B32
GND

11
M_PCIE1: PCI-E Mini Card for M-SATA
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 PCIE_WAKE# 2 +V3.3A_MINI-1
3
N/C
4
GND
5 N/C 6 +V1.5_MINI-1
7 GND 8 N/C
9
GND
10
N/C
11
CLK_PCIE_MINI_N
12
N/C
13 CLK_PCIE_MINI_P 14 N/C
15 GND 16 N/C
17
N/C
18
GND
19 N/C 20 +V3.3S
21 GND 22 BUF_PLT_RST#
23
MPCIE_RXDN
24
+V3.3A_MINI-1
25
MPCIE_RXDP
26
GND
27 GND 28 +V1.5_MINI-1
29
GND
30
SMB_CLK
31
MPCIE_TXDN
32
SMB_DATA
33 MPCIE_TXDP 34 GND
35 GND 36 USB_PN3-
37
GND
38
USB_PP3+
39 +V3.3_MINI-1 40 GND
41 +V3.3_MINI-1 42 N/C
43
N/C
44
N/C
45
N/C
46
N/C
47 N/C 48 +V1.5_MINI-1
49
N/C
50
GND
51
mSATA_DET#
52
+V3.3_MINI-1
JSPI1: SPI Flash Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+V1.8M_SPI_CON
2
SPI_CS
3
SPI_SO
4
SPI_CLK
5
SPI_SI
6
GND

12
INV_CN1: Panel Power Supply
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+12V
2
+12V
3
ENABKL
4
BRIGHTNESS
5
GND
6
GND
SATA_PWR1: SATA Power Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 +5V 2 GND
SATA1: SATA Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 TX1+
3 TX1- 4 GND
5 RX1- 6 RX1+
7
GND
LVDS1: LVDS Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 GND 2 GND
3 A1M_L 4 A0M_L
5 A1P_L 6 A0P_L
7 GND 8 GND
9 CLK1M_L 10 A2M_L
11 CLK1P_L 12 A2P_L
13 GND 14 GND
15 A3M_L 16 NC
17 A3P_L 18 +VCC_LCD
19 GND 20 +VCC_LCD

13
COM2: Internal RS-232/RS-422/RS-485 Serial Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 -NDCD2 2 -NDSR2
3 NSIN2 4 -NRTS2
5 NSOUT2 6 -NCTS2
7 -NDTR2 8 -XRI2
9 GND 10 N/C
COM1: Internal RS-232/RS-422/RS-485 Serial Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 -NDCD1 2 -NDSR1
3 NSIN1 4 -NRTS1
5 NSOUT1 6 -NCTS1
7 -NDTR1 8 -XRI1
9 GND 10 N/C

14
DIO1: Digital Input / Output Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 GND 2 +5V
3 DOUT3 4 DOUT2
5 DOUT1 6 DOUT0
7 DIN3 8 DIN2
9 DIN1 10 DIN0
USB3: Internal USB 2.0 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 +5A 2 D2F-
3 D2F+ 4 GND
USB2: Internal USB 2.0 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 +5A 2 D1F-
3 D1F+ 4 GND
USB1: Internal USB 2.0 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 +5A 2 D0F-
3 D0F+ 4 GND

15
Board Layout: Jumper and Connector Locations
(Unit: mm)
