IEI Technology IVS-300-ULT3-i5/4G User manual

IVS-300 Embedded System
Page i
User Manual
eIVS-300 Embedded System
MODEL:MODEL:
IVS-300
Fanless Embedded System with Intel® Skylake ULT / Baytrail
Processor, 4 GB DDR3L/DDR4, Quad GbE LAN with PoE,
On-board GPS, HDMI, VGA, Dual SSD Bay, RoHS Compliant,
Rev. 1.02 – February 1, 2018

IVS-300 Embedded System
Page ii
Revision
Date Version Changes
February 1, 2018 1.02 Eliminated mSATA support
December 6, 2017 1.01 Added some IVS-300-ULT3 specifications
Added the optional OBD-II cable and its connector
pinouts
Modified Section 3.13: Mobile AP
Added Section 3.14: RAID Configuration (ULT3 Model
Only)
October 5, 2016 1.00 Initial release

IVS-300 Embedded System
Page iii
Safety Instructions
Warning! Read the user manual before connecting the system to the power
source.
Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine
Stromquelle anschließen.
Attention! Avant de brancher le système à la source d'alimentation, consultez le
mode d'emploi.
Avvertenza! Consultare il manuale utente prima di collegare il sistema
all'alimentatore.
Atención! Lea atentamente este manual del usuario antes de operar la fuente de
alimentación.
警告！在將系統連接到電源之前，請仔細閱讀使用手冊。
警告！在将系统连接到电源之前，请仔细阅读使用手册。
Warning! To prevent the system from overheating, do not operate it in an area that
exceeds the maximum operating temperature described in the user manual.
Vorsicht! Um eine Überhitzung des Systems zu vermeiden, betreiben Sie es
ausschließlich im zulässigen Betriebstemperaturbereich. Dieser ist in der
Bedienungsanleitung vermerkt.
Attention! Pour éviter la surchauffe du système, ne l'utilisez pas dans une zone
dont la température dépasse les limites décrits dans le mode d'emploi.
Avvertenza! Per evitare che il sistema si surriscaldi, non utilizzarlo in aree che
superino la temperatura massima d'esercizio descritta nel manuale utente.
Atención! Para evitar el excesivo calentamiento del sistema, no opere en las
condiciones de temperatura superior a lo recomendado en este manual del
usuario.
警告！為防止系統過熱，不要在使用手冊上記載的產品工作溫度範圍之外操作此系
統。
警告！为防止系统过热，不要在使用手册上记载的产品工作温度范围之外操作此系
统。

IVS-300 Embedded System
Page iv
Warning! Use only the adapter and power cord approved for this system. Use of
another type of adapter may risk fire or explosion. Please refer to the user manual
for the power adapter specifications.
Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die
Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur
Folge haben. Prüfen Sie die jeweiligen Spezifikationen in der
Bedienungsanleitung.
Attention! Utilisez exclusivement le câble d'alimentation et l’adaptateur
homologués pour ce système. L’utilisation d’un autre type d’adaptateur risquerait
de provoquer un incendie ou une explosion. Veuillez référer au mode d'emploi
pour les spécifications de l'adaptateur d'alimentation.
Avvertenza! Utilizzare solo l'adattatore e il cavo di alimentazione approvati per
questo sistema. L'uso di un altro tipo di adattatore può causare rischio d'incendio
o esplosione. Si prega di fare riferimento al manuale utente per le specifiche
sull'alimentazione.
Atención! Utilice solamente el adaptador de corriente alterna (CA) con Marcas
Conformidad otorgadas. Cualquier otro adaptador no otorgado aumenta el riesgo
de explosión o incendio. Por favor consulte el manual del usuario para las
especificaciones del adaptador de alimentación.
警告！只能使用經過認證、適用於本系統的電源變壓器與電源線。使用不適用的電
源變壓器將可能導致火災或爆炸。電源變壓器規格請參考使用手冊。
警告！只能使用经过认证，适用于本系统的电源适配器与电源线。使用不适用的电
源适配器将可能导致火灾或爆炸。电源适配器规格请参考使用手册。
Warning! Ultimate disposal of this product should be handled according to all
national laws and regulations.
Vorsicht! Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und
Gesetzen des Landes erfolgen.
Attention! La mise au rebut ou le recyclage de ce produit sont généralement
soumis aux lois et/ou directives de respect de l'environnement. Renseignez-vous
auprès de l'organisme compétent.
Avvertenza! Lo smaltimento di questo prodotto deve essere eseguito secondo le
leggi e i regolamenti locali.
Atención! La disposición final de residuos de este producto se debe cumplir con
las normativas y leyes del país.
警告！本產品的廢棄處理應根據該國家的法律和規章進行。
警告！本产品的废弃处理应根据该国家的法律和规章进行。

IVS-300 Embedded System
Page v
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IVS-300 Embedded System
Page vi
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

IVS-300 Embedded System
Page vii
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 BENEFITS ................................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 MODEL VARIATIONS ................................................................................................... 3
1.5 FRONT PANEL............................................................................................................. 4
1.5.1 LED Indicators................................................................................................... 4
1.6 REAR PANEL............................................................................................................... 5
1.7 BOTTOM PANEL.......................................................................................................... 6
1.8 DIMENSIONS............................................................................................................... 6
1.9 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 UNPACKING................................................................................................................. 9
2.1 UNPACKING.............................................................................................................. 10
2.2 PACKING LIST........................................................................................................... 10
2.3 OPTIONAL ITEMS.......................................................................................................11
3 INSTALLATION ......................................................................................................... 13
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 14
3.2 INSTALLATION PRECAUTIONS................................................................................... 14
3.2.1 High Surface Temperature ............................................................................... 15
3.3 INSTALLATION PROCEDURE...................................................................................... 15
3.4 DISASSEMBLE THE SYSTEM...................................................................................... 16
3.5 PCIE MINI CARD INSTALLATION .............................................................................. 18
3.5.1 PCIe Mini Slot (MINI-PCIE3) Pinouts............................................................ 20
3.6 WLAN/WWAN MODULE INSTALLATION ................................................................ 21
3.6.1 WWAN Module Slot (MINI-PCIE1) Pinouts.................................................... 24
3.6.2 WLAN Module Slot (MINI-PCIE2) Pinouts..................................................... 25
3.7 SIM CARD INSTALLATION........................................................................................ 26
3.8 SOLID-STATE DRIVE INSTALLATION ......................................................................... 26
3.9 MOUNTING THE SYSTEM .......................................................................................... 29

IVS-300 Embedded System
Page viii
3.10 EXTERNAL I/O CONNECTORS ................................................................................. 30
3.10.1 COM Port Connection................................................................................... 30
3.10.2 DIO and RS-422/485 (COM6) Connection.................................................... 31
3.10.3 OBD-II/J1939 Connection............................................................................. 32
3.10.4 GPS Speed Pulse/Direction Connection........................................................ 34
3.11 POWER-ON PROCEDURE......................................................................................... 34
3.11.1 Installation Checklist...................................................................................... 34
3.11.2 Power Input Connection................................................................................. 35
3.11.3 Power-on Procedure....................................................................................... 36
3.12 DRIVER INSTALLATION........................................................................................... 36
3.13 MOBILE AP............................................................................................................ 37
3.13.1 Installation..................................................................................................... 37
3.13.2 Usage ............................................................................................................. 38
3.14 RAID CONFIGURATION (ULT3 MODEL ONLY)....................................................... 39
4 BIOS.............................................................................................................................. 43
4.1 INTRODUCTION......................................................................................................... 44
4.1.1 Starting Setup................................................................................................... 44
4.1.2 Using Setup...................................................................................................... 44
4.1.3 Getting Help..................................................................................................... 45
4.1.4 BIOS Menu Bar................................................................................................ 45
4.2 MAIN........................................................................................................................ 46
4.3ADVANCED............................................................................................................... 47
4.3.1 ACPI Settings................................................................................................... 48
4.3.2 Super IO Configuration ................................................................................... 49
4.3.2.1 Serial Port n Configuration....................................................................... 49
4.3.3 Hardware Monitor ........................................................................................... 54
4.3.3.1 Smart Fan Mode Configuration................................................................ 55
4.3.4 Power Management......................................................................................... 57
4.3.4.1 Power State ............................................................................................... 58
4.3.5 CPU Configuration.......................................................................................... 59
4.3.6 IDE Configuration........................................................................................... 61
4.3.7 USB Configuration........................................................................................... 62
4.4 CHIPSET ................................................................................................................... 63
4.4.1 North Bridge Configuration............................................................................. 64

IVS-300 Embedded System
Page ix
4.4.1.1 Intel IGD Configuration............................................................................ 65
4.4.2 South Bridge Configuration............................................................................. 66
4.5 SECURITY................................................................................................................. 67
4.6 BOOT........................................................................................................................ 68
4.7 SAVE &EXIT ............................................................................................................ 70
5 TROUBLESHOOTINGAND MAINTENANCE ..................................................... 72
5.1 IVS-300 SYSTEM MAINTENANCE OVERVIEW .......................................................... 73
5.2 SYSTEM TROUBLESHOOTING.................................................................................... 73
5.2.1 The System Doesn’t Turn On............................................................................ 73
5.2.2 The System Doesn’t Boot Up............................................................................ 74
5.2.3 More Troubleshooting...................................................................................... 74
5.3 COMPONENT REPLACEMENT PROCEDURE ................................................................ 75
5.3.1 SO-DIMM Replacement................................................................................... 75
A REGULATORY COMPLIANCE.............................................................................. 77
B SAFETY PRECAUTIONS......................................................................................... 82
B.1 SAFETY PRECAUTIONS............................................................................................. 83
B.1.1 General Safety Precautions............................................................................. 83
B.1.2 Anti-static Precautions .................................................................................... 84
B.1.3 Product Disposal............................................................................................. 85
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 86
B.2.1 Maintenance and Cleaning.............................................................................. 86
B.2.2 Cleaning Tools................................................................................................. 86
C BIOS MENU OPTIONS............................................................................................. 88
C.1 BIOS CONFIGURATION OPTIONS ............................................................................. 89
D WATCHDOG TIMER ................................................................................................ 91
E HAZARDOUS MATERIALS DISCLOSURE ......................................................... 94

IVS-300 Embedded System
Page x
List of Figures
Figure 1-1: IVS-300 Series Embedded System............................................................................2
Figure 1-2: Front Panel ..................................................................................................................4
Figure 1-3: LED Indicators.............................................................................................................4
Figure 1-4: Rear Panel....................................................................................................................5
Figure 1-5: Bottom Panel...............................................................................................................6
Figure 1-6: Dimensions (mm)........................................................................................................6
Figure 3-1: Bottom Panel Retention Screws..............................................................................17
Figure 3-2: Internal Chassis Retention Screws.........................................................................17
Figure 3-3: Front Panel Retention Screws.................................................................................17
Figure 3-4: Rear Panel Retention Screws..................................................................................18
Figure 3-5: Internal Platform Removal........................................................................................18
Figure 3-6: PCIe Mini Slot Location............................................................................................19
Figure 3-7: Removing the Retention Screws.............................................................................19
Figure 3-8: Inserting the Full-size PCIe Mini Card into the Slot at an Angle..........................20
Figure 3-9: Securing the Full-size PCIe Mini Card ....................................................................20
Figure 3-10: Knockouts for External Antennas.........................................................................22
Figure 3-11: WLAN and WWAN Card Slot Locations................................................................22
Figure 3-12: Connecting RF Cable..............................................................................................23
Figure 3-13: Securing SMA Connector and External Antenna Installation ............................23
Figure 3-14: SIM Card Slot Locations.........................................................................................26
Figure 3-15: SSD Bracket Retention Screws.............................................................................27
Figure 3-16: Removing SSD Bracket..........................................................................................27
Figure 3-17: SSD Retention Screws............................................................................................28
Figure 3-18: SSD Installation.......................................................................................................28
Figure 3-19: Mounting Bracket Retention Screws ....................................................................29
Figure 3-20: RS-232 Connector (COM1, COM2).........................................................................30
Figure 3-21: DIO and RS-422/485 Connector.............................................................................31
Figure 3-22: OBD-II/J1939 Connector.........................................................................................32
Figure 3-23: OBD-II Cable ............................................................................................................33
Figure 3-24: OBD-II Connector Pinouts......................................................................................33
Figure 3-25: GPS Speed Pulse/Direction Connector ................................................................34

IVS-300 Embedded System
Page xi
Figure 3-26: Power Input Connector...........................................................................................35
Figure 3-27: ACC Power Cable....................................................................................................35
Figure 3-28: Power Button...........................................................................................................36
Figure 3-29: Mobile AP–Connection...........................................................................................38
Figure 3-30: RAID Configuration–BIOS Setting.........................................................................40
Figure 5-1: SO-DIMM Locations..................................................................................................76
Figure 5-2: SO-DIMM Installation ................................................................................................76

IVS-300 Embedded System
Page xii
List of Tables
Table 1-1: Model Variations...........................................................................................................3
Table 1-2: LED Indicators ..............................................................................................................5
Table 1-3: Technical Specifications..............................................................................................8
Table 2-1: Package List................................................................................................................11
Table 2-2: Optional Items.............................................................................................................12
Table 3-1: PCIe Mini Slot (MINI-PCIE3) Pinouts.........................................................................21
Table 3-2: WWAN Module Slot (MINI-PCIE1) Pinouts ...............................................................24
Table 3-3: WLAN Module Slot (MINI-PCIE2) Pinouts.................................................................25
Table 3-4: RS-232 Connector Pinouts ........................................................................................30
Table 3-5: DIO and RS-422/485 Connector Pinouts ..................................................................31
Table 3-6: OBD-II/J1939 Connector Pinouts ..............................................................................32
Table 3-7: GPS Speed Pulse/Direction Connector Pinouts......................................................34
Table 3-8: Power Input Connector Pinouts................................................................................35
Table 4-1: BIOS Navigation Keys................................................................................................45
Table 4-2: Power State and Ignition System..............................................................................58

IVS-300 Embedded System
Page xiii
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................46
BIOS Menu 2: Advanced..............................................................................................................47
BIOS Menu 3: ACPI Settings .......................................................................................................48
BIOS Menu 4: Super IO Configuration........................................................................................49
BIOS Menu 5: Serial Port n Configuration Menu.......................................................................49
BIOS Menu 6: Hardware Monitor.................................................................................................54
BIOS Menu 7: Smart Fan Mode Configuration ..........................................................................55
BIOS Menu 8: Power Management .............................................................................................57
BIOS Menu 9: CPU Configuration...............................................................................................59
BIOS Menu 10: IDE Configuration...............................................................................................61
BIOS Menu 11: USB Configuration.............................................................................................62
BIOS Menu 12: Chipset................................................................................................................63
BIOS Menu 13: North Bridge .......................................................................................................64
BIOS Menu 14: Intel IGD Configuration......................................................................................65
BIOS Menu 15: South Bridge.......................................................................................................66
BIOS Menu 16: Security...............................................................................................................67
BIOS Menu 17: Boot.....................................................................................................................68
BIOS Menu 18: Save & Exit..........................................................................................................70

IVS-300 Embedded System
Page 1
Chapter
1
1 Introduction

IVS-300 Embedded System
Page 2
1.1 Overview
Figure 1-1: IVS-300 Series Embedded System
The IVS-300 fanless embedded system is powered by Intel®Core™i5-6300U processor
or Intel®Celeron®processor J1900. It is designed for vehicle surveillance applications that
require minimum installation space.
The IVS-300 accepts a wide range of DC power input (9 V–30 V), allowing it to be
powered anywhere. Wi-Fi and WWAN capabilities plus four RJ-45 Ethernet connectors
with PoE ensure smooth network connectivity. The display interface options include VGA
and HDMI with two audio jacks.
Two USB 3.0 ports, two RS-232 ports, one RS-422/485 port and one OBD-II port provide
rich I/O options for various applications. The IVS-300 embedded systems are all capable
of supporting two 2.5” SATA 6Gb/s solid-state drives.
1.2 Benefits
The IVS-300 embedded system has the following benefits:
Complete integration saves solution development time and cost
Secure storage with SATA SSD supported
Compact size saves space
Powerful preinstalled 6th generation Intel®processor and motherboard
ensures rigorous processing needs can be met

IVS-300 Embedded System
Page 3
1.3 Features
The IVS-300 has the following features
RoHS compliant design
Fanless system
Intel®Core™i5-6300U processor or Intel®Celeron®processor J1900
supported
Quad GbE LAN with PoE IEEE802.3af support
Support two RS-232 ports and one RS-422/485 port
Support two USB 3.0 ports
Support one OBD-II port
Two SATA 6Gb/s SSD supported
Two external SIM card slots support WWAN connection
Optional 802.11b/g/n 1T1R wireless connection
1.4 Model Variations
There are two models in the IVS-300 embedded system series. The model variations are
listed in Table 1-1 below.
Processor Memory
IVS-300-ULT3-i5/4G Intel®Core™i5-6300U (dual-core,
2.4 GHz, 15W TDP)
4 GB DDR4 preinstalled
(max. 32 GB)
IVS-300-BT-J1/4G Intel®Celeron®J1900
(quad-core, 2.0 GHz, 10W TDP)
4 GB DDR3L preinstalled
(max. 8 GB)
Table 1-1: Model Variations

IVS-300 Embedded System
Page 4
1.5 Front Panel
An overview of the front panel is shown in Figure 1-2 below.
Figure 1-2: Front Panel
1.5.1 LED Indicators
The LED indicators on the front panel show the status of power, HDD, Wi-Fi, PoE and
GPRS/HSUPA connection.
Figure 1-3: LED Indicators
Power LED Amber The system is off with power connected
Blue The system is turned on

IVS-300 Embedded System
Page 5
Blinking
At regular intervals: low voltage warning
(configured by BIOS option: Section 4.3.4)
At irregular intervals (long-short-short):
GPS antenna is not connected.
SIM LED
Off The WWAN module is not installed or the SIM slot
is not being used.
Green The WWAN module is installed and the SIM slot is
being used for WWAN connection.
Wi-Fi LED Off The Wi-Fi module is not installed.
Green The Wi-Fi module is installed.
HDD LED Off HDD is not active
Blinking HDD is active
PoE LED Off PoE is not connected
Green PoE is connected
Table 1-2: LED Indicators
1.6 Rear Panel
An overview of the rear panel is shown in Figure 1-4.
Figure 1-4: Rear Panel

IVS-300 Embedded System
Page 6
1.7 Bottom Panel
The bottom surface of the IVS-300 contains six retention screw holes for installing two
side mounting brackets.
Figure 1-5: Bottom Panel
1.8 Dimensions
The dimensions of the IVS-300 are listed below and shown in Figure 1-6.
Figure 1-6: Dimensions (mm)
