IEI Technology ECK-161B User manual

ECK-161B Embedded System
Page i
ECK-161B Embedded System

ECK-161B Embedded System
Page ii
Revision
Date Version Changes
2008-07 1.00 Initial Release

ECK-161B Embedded System
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

ECK-161B Embedded System
Page iv
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the ECK-161B or
personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the ECK-161B. Cautions are easy to recognize. The word “caution” is written as
“CAUTION,” both capitalized and bold and is followed. The italicized text is the cautionary
message. A caution message is shown below:

ECK-161B Embedded System
Page v
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the ECK-161B. Please
take caution messages seriously.
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the ECK-161B. Please take
note messages seriously.

ECK-161B Embedded System
Page vi
Packing List
NOTE:
If any of the components listed in the checklist below are missing, please do not
proceed with the installation. Contact the IEI reseller or vendor you purchased
the ECK-161B from or contact an IEI sales representative directly. To contact
an IEI sales representative, please send an email to [e-mail].
The items listed below should all be included in the ECK-161B package.
 1 x ECK-161B embedded system
 1 x Screw set
 1 x Power adaptor
 1 x Power cord
 1 x QIG
 2 x Wall mount brackets
 1 x HDD installation kit
 1 x Driver CD
 1 x Manual CD
Images of the above items are shown in Chapter 4.
