IEI Technology IOVU-570M User manual

IOVU-570M Panel PC
Page i
IEI Technology Corp.
User Manual
MODEL:
IOVU-570M
Panel PC, 5.7" Touch Screen, 520 MHz Marvell XScale PXA270,
Fast Ethernet, 2 x USB, 802.11b/g Wireless, RS-232/422/485
RoHS Compliant, IP 64 Protection
Rev. 1.00 – 24 June, 2009

IOVU-570M Panel PC
Page ii
Revision
Date Version Changes
24 June, 2009 1.00 Initial release

IOVU-570M Panel PC
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IOVU-570M Panel PC
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 BENEFITS ................................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 3
1.5 CERTIFICATIONS......................................................................................................... 4
2 DETAILED SPECIFICATIONS.................................................................................. 5
2.1 FRONT PANEL............................................................................................................. 6
2.2 CONNECTOR PANEL.................................................................................................... 6
2.3 DIMENSIONS............................................................................................................... 8
2.4 POWER SUPPLY .......................................................................................................... 9
3 UNPACKING............................................................................................................... 10
3.1ANTI-STATIC PRECAUTIONS.......................................................................................11
3.2 UNPACKING PRECAUTIONS........................................................................................11
3.3 UNPACKING CHECKLIST........................................................................................... 12
3.4 OPTIONAL ITEMS...................................................................................................... 13
4 INSTALLATION ......................................................................................................... 15
4.1 INSTALLATION PRECAUTIONS................................................................................... 16
4.2 SD CARD INSTALLATION.......................................................................................... 16
4.3 EXTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 17
4.3.1 12 V~36 V DC Terminal Block......................................................................... 18
4.3.2 RS-232/422/485 Serial Port............................................................................. 18
4.3.2.1 Connecting the Serial Port........................................................................ 18
4.3.2.2 RS-232/422/485 Selection........................................................................ 19
4.3.2.3 Pinouts....................................................................................................... 20
4.3.2.4 RS-485 Terminator Jumper Setting........................................................... 21
4.3.3 USB Connectors............................................................................................... 22
4.3.4 Ethernet Connector.......................................................................................... 23

IOVU-570M Panel PC
Page v
4.4 MOUNTING THE SYSTEM .......................................................................................... 24
4.4.1 Wall Mounting.................................................................................................. 25
4.4.2 Panel Mounting................................................................................................ 27
4.4.3 Arm Mounting .................................................................................................. 29
4.4.4 Stand Mounting................................................................................................ 30
4.5 SOFTWARE................................................................................................................ 30
A CERTIFICATIONS .................................................................................................... 32
A.1 ROHS COMPLIANT.................................................................................................. 33
A.2 IP64 COMPLIANT FRONT PANEL ............................................................................. 33
B SAFETY PRECAUTIONS......................................................................................... 34
B.1 SAFETY PRECAUTIONS............................................................................................. 35
B.1.1 General Safety Precautions............................................................................. 35
B.1.2 Anti-static Precautions .................................................................................... 36
B.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 36
B.2.1 Maintenance and Cleaning.............................................................................. 36
B.2.2 Cleaning Tools................................................................................................. 37
C HAZARDOUS MATERIALS DISCLOSURE......................................................... 38
C.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 39

IOVU-570M Panel PC
Page vi
List of Figures
Figure 1-1: IOVU-570M ...................................................................................................................2
Figure 2-1: Front Panel ..................................................................................................................6
Figure 2-2: IOVU-570M Peripheral Connectors ...........................................................................6
Figure 2-3: IOVU-570M Physical Dimensions (millimeters) .......................................................8
Figure 4-1: SD Card Installation..................................................................................................17
Figure 4-2: IOVU-570M Peripheral Connectors .........................................................................17
Figure 4-3: Power Terminal Block...............................................................................................18
Figure 4-4: Serial Device Connector...........................................................................................19
Figure 4-5: Serial Port Mode Setting...........................................................................................20
Figure 4–6: Serial Port Pinouts...................................................................................................21
Figure 4-7: USB Connector..........................................................................................................22
Figure 4-8: LAN Connection........................................................................................................23
Figure 4-9: Ethernet Connector...................................................................................................24
Figure 4-10: Wall-mounting Bracket...........................................................................................25
Figure 4-11: Chassis Support Screws........................................................................................26
Figure 4-12: Secure the IOVU-570M............................................................................................27
Figure 4-13: IOVU-570M Panel Opening (mm)...........................................................................28
Figure 4-14: Panel Mounting Clamp ...........................................................................................28
Figure 4-15: Tighten the Panel Mounting Clamp Screws.........................................................29
Figure 4-16: Stand Mounting.......................................................................................................30

IOVU-570M Panel PC
Page vii
List of Tables
Table 1-1: Technical Specifications..............................................................................................4
Table 3-1: Package List Contents...............................................................................................12
Table 3-2: Optional Items.............................................................................................................14
Table 4-1: External Interface Connectors...................................................................................17
Table 4-2: 12~36 V Power Connector Pinouts...........................................................................18
Table 4-3: Serial Port Pinouts......................................................................................................21
Table 4-4: Serial Port Terminator Settings.................................................................................21
Table 4-5: USB Connector Pinouts.............................................................................................22
Table 4-6: Ethernet Connector Pinouts......................................................................................24
Table 4-7: Ethernet Connector LEDs..........................................................................................24

IOVU-570M Panel PC
Page 1
Chapter
1
1 Introduction

IOVU-570M Panel PC
Page 2
1.1 Overview
Figure 1-1: IOVU-570M
The IOVU-570M Panel PC comes with a 5.7" touch panel screen. It is powered by the
520 MHz Marvell XScale PXA270 processor and has 128 MB of SDRAM.
The IOVU-570M includes an SD card with Windows CE 5.0 installed. The package also
includes a software development kit and documentation to help easily customize the
operating system according to needs.
The IOVU-570M is an extremely low power Panel PC. The system is fanless, which allows
quiet and reliable operation
1.2 Benefits
Some of the IOVU-570M benefits include:
Customizable operating system to suit application needs.
Less downtime from overheating because there are not fans to fail
Cost savings with low power consumption
Easy installation with a wide range of input voltages supported
Can handle tough environments because of solid-state storage and IP64
protection of the front cover

IOVU-570M Panel PC
Page 3
1.3 Features
The IOVU-570M features are listed below:
520 MHz Marvell XScale PXA270 processor
128 MB of SDRAM
Two Ethernet ports
Two USB ports
One RS-232/422/485 serial communication connection
Two built-in speakers
4-wire resistive touch panel
12-36 VDC input
RoHS compliant
1.4 Technical Specifications
The IOVU-570M technical specifications are listed in Table 1-1.
Specifications
System
CPU 520 MHz Marvell XScale PXA270 processor
Memory 128 MB of SDRAM
1.0 GB SD card
Real-time Clock Battery backup RTC
Watchdog Timer Software programmable supports 1~255 sec. system reset
Reset Reset button
Display
Display Type TFT LCD screen
Display Size 5.7"
Resolution 640 x 480, 262,000
Brightness 400 cd/m2
Touch Panel 4-wired resistive touch panel

IOVU-570M Panel PC
Page 4
Specifications
I/O and Communications
Ethernet 2 x 10/100 Mb/s
Serial Ports 1 x RS-232/422/485
USB Interfaces 2 x USB host connectors
Audio 2 x 1.5 Watt speakers
Power
Power Supply 12-36 VDC
Power Consumption 8.5 W
Environmental and Mechanical
Operating Temperature Minimum: -20ºC (-4°F)
Maximum: 60°C (140°F)
Humidity 5%RH to 90%RH (non-condensing)
Vibration
Operating Random Vibration Mode (MIL-STD-810F
514.5C-3)
1.Axes: 3 axs (Vertical / Transverse / Longitudinal).
2.10-500 Hz, 60min/axis.
3.Equivalent to Z:2.18 Grms X:1.6 Grms Y:1.96 Grms
Front Panel Color Pantone Black C
Physical Dimensions 180 mm x 135.8 mm x 46.7 mm
Ingress Protection IP 64 compliant front panel
Table 1-1: Technical Specifications
1.5 Certifications
All IOVU-570M series models comply with the following international standards:
RoHS
IP 64
For a more detailed description of these standards, please refer to Appendix A.

IOVU-570M Panel PC
Page 5
Chapter
2
2 Detailed Specifications

IOVU-570M Panel PC
Page 6
2.1 Front Panel
The IOVU-570M front panel (Figure 2-1) comprises a 5.7" TFT WVGA 16-bit color touch
screen LCD in an ABS+PC plastic frame.
Figure 2-1: Front Panel
2.2 Connector Panel
All external peripheral interface connectors are located on the bottom panel of the
IOVU-570M . The peripheral interface connectors are shown in Figure 2-2.
Figure 2-2: IOVU-570M Peripheral Connectors

IOVU-570M Panel PC
Page 7
External peripheral interface connectors on the IOVU-570M include:
1 x DC-IN bare wire terminal block
2 x RJ-45 LAN connectors
1 x RS-232/422/485 connector
2 x USB connectors

IOVU-570M Panel PC
Page 8
2.3 Dimensions
The physical dimensions of the IOVU-570M are shown in Figure 2-3 and listed below:
Width: 180 mm
Height: 135.8 mm
Depth: 46.7 mm
Figure 2-3: IOVU-570M Physical Dimensions (millimeters)

IOVU-570M Panel PC
Page 9
2.4 Power Supply
WARNING:
Whenever you need to remove a part for maintenance or upgrading,
switch off the power supply and unplug the power cord first.
The IOVU-570M has a terminal block connector on the bottom panel. The IOVU-570M
also supports Power over Ethernet (PoE) through one of its LAN ports.

IOVU-570M Panel PC
Page 10
Chapter
3
3 Unpacking

IOVU-570M Panel PC
Page 11
3.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during installation may result in
permanent damage to the IOVU-570M and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the IOVU-570M. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the IOVU-570M or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the IOVU-570M, place it on an
antic-static pad. This reduces the possibility of ESD damaging the
IOVU-570M.
3.2 Unpacking Precautions
When the IOVU-570M is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 3.1.
Make sure the packing box is facing upwards so the IOVU-570M does not fall
out of the box.
Make sure all the components shown in Section 3.3 are present.

IOVU-570M Panel PC
Page 12
3.3 Unpacking Checklist
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the IOVU-570M from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [email protected].
The IOVU-570M is shipped with the following components:
Quantity Item and Part Number Image
1 IOVU-570M
1 Utility CD including SDK, utilities, and
technical documentation
1 Null modem cable
1 Touch pen
Table 3-1: Package List Contents
