Ihse Draco MultiView 4K60 MV42 Series User manual

Document MV42_REV05.00_en
Firmware version: 02.00
Edition: 2023-03-22
Software version: 2.0.3.0
USER MANUAL
Draco MultiView 4K
60
KVM Switch
Series MV42

Introduction
This manual contains important safety instructions as well as instructions for setting up the product and
operating it.
Please read the general safety instructions (see chapter 2, page 11) and additional notice in
the respective chapters.
Read carefully through the User Manual before you switch on the product.
Product Identification
The model and serial number of your products are indicated on the bottom of our products. Always refer to this
information when you need to contact your dealer or the support of IHSE GmbH (see chapter 18, page 222).
Trademarks and Trade Names
All trademark and trade names mentioned in this document are acknowledged to be the property of their respective
owners.
Validity of this Manual
This manual applies to all products of the series named on the cover page. Differences between the various models
are clearly described. Please note the change log for this manual in chapter 22, page 234.
The manufacturer reserves the right to change specifications, functions or circuitry of the series described here
without notice. Information in this manual can be changed, expanded, or deleted without notice. You can find the
current version of the manual in the download area of our website.
Copyright
© 2023. All rights reserved. This manual may not be reproduced in any manner without the prior written consent of
the manufacturer.
Available Documentation
Name Format Description Provision
User Manual PDF Provides an overview of the product together with technical
data and safety instructions.
Contains all instructions required to operate the product to a
basic level.
Download from
website
Quick Setup Print Provides a quick installation guide and safety instructions Contained in the
scope of delivery
Contact
IHSE GmbH
Benzstraße 1
88094 Oberteuringen
Germany
phone: [phone]
fax: [phone]
e-mail: [e-mail]
website: https://www.ihse.com
