IKA C 6000 global standards User manual

IKA®C 6000 global standards
IKA®C 6000 isoperibol
20000004212
Operating instructions EN
C6000_092016

3
Source language: German EN
Page
Declaration of conformity 04
Explication of warning symbols 04
Safety instructions 05
Correct use 07
User instructions 07
System features 07
Warranty and liability 08
Transport and storage 08
Transport and storage conditions 08
Unpacking 09
Scope of supply 09
Description of system components 10
IKA® C 6000 calorimeter global standards/isoperibol 10
Hoses 11
Commissioning 11
Place of installation 11
Connection to the condenser 12
Connection to the water 12
Connection to the oxygen supply 13
Connection to the mains power supply 13
Connection of peripherals 14
On/off switch 15
Display and operating elements 16
Explanation of the screen display 16
Working with the IKA®C 6000 global standards/isoperibol calorimeter 20
Switching on the device 20
System test 20
Switching off the device 21
The standard calorimetric procedure 22
- Calorific value determination 22
- Corrections 23
- Note on the sample 24
- Complete combustion 25
- Calibration (only IKA®C 6000 global standards) 25
- Calibrating 26
- Instructions on calibration 26
Preparation for measurement 27
Charging the decomposition vessel 29
Calorimetric measurement without automatic decomposition vessel detection 29
Starting the measurement 30
Evaluation 32
Menu (main overview) 33
Library 34
Method of operation, decomposition vessels and calibration 35
Servicing the decomposition vessel 38
Contents

4
We declare under our sole responsibility that this product corrosponds to the regulations 2006/42/EC, 2011/65/EU,
2014/30/EU and 2014/35/EU and conforms with the standards or standardized documents EN 61010-1, EN 61010-2-051,
EN 61326-1, EN 60529 (A1+A2) and EN ISO 12100.
Declaration of conformity
Explication of warning symbols
Other Settings 38
Evaluation 38
Measurement 39
Ignition aids 40
Combustion aid 41
Balance 41
Printer 42
Other 42
Help and servicing system 44
Displaying / hiding the sample rack 46
Cleaning 48
Cleaning the system 48
Cleaning the filter 48
Troubleshooting 49
Fault rectification 51
Checks 55
Accessories and consumables 56
Accessories 56
Technical data 57
Technical data IKA®C 6000 global standards 57
Technical data IKA®C 6000 isoperibol 59
DANGER
WARNING
This symbol indicates information which is essential for the safety of your health.
Failure to observe this information can cause damage to health and injuries.
This symbol indicates information which is important for ensuring that the
appliance functions without any technical problems.
Failure to observe this information could damage the calorimeter system.
This symbol indicates information which is important for ensuring that calori-
metric measurements are performed eciently and for using the calorime-
ter system.
Failure to observe this information can result in inaccurate measurements.
General hazard
ATTENTION

5
Safety instructions
Read the operating instructions in full before
starting up and follow the safety instruc-
tions.
Keep the operating instructions in a place where
they can be accessed by everyone.
Ensure that only trained staff work with the device.
Follow the safety instructions, guidelines, occupa-
tional health and safety and accident prevention
regulations.
The IKA®C 6000 global standards/isoperibol calo-
rimeter system may be used only in conjunction
with the decomposition vessels C 6010 or C 6012
for determination of the calorific values of solid
and liquid substances to national and international
standards (such as DIN 51900, BS 1016 T5, ISO
1928, ASTM 5468, ASTM 5865 and ASTM 4809).
The maximum extra energy added to the decom-
position vessel must not exceed 40,000 J (select
the test mass accordingly). The permitted operat-
ing pressure of 230 bar (23 MPa) must not be
exceeded. The maximum permitted operating tem-
perature must not exceed 50 °C.
When burning substances containing metals, en-
sure that the maximum energy input is not ex-
ceeded!
Only fill the decomposition vessel with oxygen to a
maximum pressure of 40 bar (4 MPa). Check the
pressure setting on the pressure reducer for your
oxygen supply. Perform a leakage test before each
combustion process (see section „Leaktightness
testing“).
Some materials tend to explode when combusted
(e.g. due to formation of peroxides), which could
cause the decomposition vessel to crack. The IKA®
C 6000 global standards/isoperibol calorim-
eter may not be used for testing explosive
samples.
If the burning behaviour of a material is unknown,
it must be tested before combustion in the decom-
position vessel (risk of explosion). If you are burn-
ing unknown samples, leave the room or keep
your distance from the calorimeter.
Benzoic acid may only be combusted in its pressed
form! Flammable dust and powder must be first
pressed. Oven-dry dust and powder such as splints,
hay, straw etc. explode when combusted! Always
wet these materials first! Highly flammable liquids
with a low vapour pressure (e.g. tetramethyl dihy-
drogen disiloxane) must not directly touch the cot-
ton thread!
Furthermore, toxic combustion residue in the form
of gases, ashes or condensation, for example, is
possible in the inner wall of the decomposition
vessel.
Observe the accident prevention
requirements applicable to the
activity and the work station.
Wear your personal protective equipment.
When handling combustion samples, combustion
residue and auxiliary materials, please observe
the relevant safety regulations. The following
materials, for example, could pose a risk:
- corrosive
- highly flammable
- explosive
- bacteriologically contaminated
- toxic
Please observe the relevant regulations when
handling oxygen.
Warning: oxygen as a compressed gas is oxidising;
intensively aids combustion; can react violently
with flammable materials.
Do not use oil or grease!
Tubes and screwed joints for oxygen must be kept
free of grease.
Combustion gases are
hazardous to health,
therefore the venting
hose must be connected to a suitable gas
cleaning system or extraction system.
At the end of the work period, close the main
valve for the oxygen supply.
Perform servicing work only when the equipment
is depressurised.
When using stainless steel crucibles thoroughly
check their condition after each experiment. If the
material gets thinner, the crucible may catch fire
and damage the decomposition vessel. Crucibles
must not be used for more than 25 combustions
for safety reasons.
DANGER
DANGER

6
We recommend that you send the decom-
position vessel to our factory for inspection,
and if necessary, repair after 1000 tests or
after one year or sooner depending on use
A pressure test must be performed after a decom-
position vessel has reached or exceeded the re-
commended number of ignition cycles. Once the
pressure test has been performed a release code
can be entered to enable the decomposition ves-
sel to be used for further measurements (see the
sections “Maintenance of the Decomposition Ves-
sel” and “Inputting a Service Code”).
The warning message will then disappear!
Note: You can then continue to use the device /
decomposition vessel.
Contact the IKA®Service Department to perform
the pressure test. Comply with the safety instruc-
tions in this respect. The user will be given specific
instructions on the relevant screen.
For the purposes of these operating instructions a
technical expert is someone
1. who guarantees to conduct the tests properly
on the basis of his training, knowledge and
experience gained through practical work,
2. who is suciently reliable,
3. who is not subject to any instructions in terms
of the test activity,
4. who has suitable test equipment if necessary,
5. who can provide appropriate proof of the re-
quirements listed in 1.
National directives and laws must be obser-
ved for operating pressure vessels!
Anyone operating a pressure vessel must keep it
in a proper condition, operate it properly, super-
vise it, carry out the necessary maintenance and
repair work immediately and implement the safety
measures required in the circumstances.
Pressure vessels must not be used if they have
defects which could pose a risk to staff or third
parties.
The decomposition vessel is manufactured in ac-
cordance with the directive for pressure equip-
ment 97/23/EC. This is indicated by the CE sym-
bol with the ID number of the notified body. The
decomposition vessel is a category III pressure
device. The decomposition vessel has undergone
an EC prototype test. The CE declaration of con-
formity confirms that this decomposition vessel
corresponds to the pressure device described in
the EC prototype test certificate. The decomposi-
tion vessel has undergone a pressure test with
test pressure of 33 MPa and a leakage test with
oxygen at 3 MPa.
Refer also to the operating instructions for the
C 6010/ 6012 decomposition vessel, see chapter
„maintenance of the decomposition vessel“.
Decomposition vessels are experiment autoclaves
and must be tested by a technical expert after
each use.
Individual use is understood here to include a se-
ries of experiments performed under roughly the
same conditions in terms of pressure and tempe-
rature. Experiment autoclaves must be operated in
special chambers
The decomposition vessels must undergo repea-
ted tests (internal tests and pressure tests) perfor-
med by the technical expert. The frequency of
these tests is to be determined by the operator on
the basis of experience, type of operation and the
material used in the decompositionvessel.
The declaration of conformity becomes invalid if
mechanical modifications are carried out to the
experiment autoclaves or if tightness can no lon-
ger be guaranteed as a result of major corrosion
(e.g. pitting by halogens).
In particular the threads on the pressure vessel and
the union nut are subject to considerable stress
and must therefore be checked regularly for wear.
The condition and function of the seals must be
checked and ensured by way of a leakage test
(see the operating instructions for the C 6010/
6012 decomposition vessel, section „Leaktight-
ness testing“).
If the maintenance, and especially the pressure
testing, is not performed or is performed incor-
rectly, there is a risk the decomposition vessel may
burst or an uncontrolled internal fire may occur at
the electrodes which could burn away the seals
(oxyacetylene torch effect), thus posing a risk to
life and limb.
Only technical experts may perform pressure
tests and service work on the decomposition vessel.

7
The IKA®C 6000 global standards/isoperibol cal-
orimeter system is used for calorific value determi-
nation of solid and liquid substances.
This is done by placing a known quantity of a
substance in a decomposition vessel which is sur-
rounded by a water jacket. The sample is then
combusted in an oxygen atmosphere . The calo-
rific value of the sample can then be calculated
from the resulting increase in temperature, the
sample mass and the known thermal capacity of
the overall system.
The IKA®C 6000 global standards/isoperibol cal-
orimeter system is subject to the Pressure Vessel
Directive 2014/68/EU. Comply with the safety in-
structions accordingly.
For adaptation to individual laboratory tasks, use
original IKA®consumables and accessories.
Correct use
The calorimeter system is ready to perform mea-
surements once you have completed the proce-
dures in the section „Setting up and commission-
ing“, „Preparing a measurement“ and „Starting a
measurement“.
Numbers 1, 2, 3 etc. indicate operating instruc-
tions in the following sections. These must always
be carried out in the specified sequence.
In this chapter you can find out how to work
through these Operating Instructions most effec-
tively to be able to work reliably with the calorim-
eter system.
The instructions in the section „Safety in-
structions“ must be complied with.
The chapters are designed for you to work through
them in order.
The section „Transport, storage“ is relevant for
system reliability and for ensuring high measuring
accuracy. The section „Description of system com-
ponents“ describes the system components, and
the section „The standard calorimetric procedure“
describes the essentials of calorimetry.
User instructions
• Operation with active cooling unit 17-27 °C
(e.g. IKA® KV 600; optional)
• Measurement and calculation of gross calorific
value according to DIN 51900, ISO 1928, ASTM
D240, ASTM D4809, ASTM D5865, ASTM
D1989, ASTM D5468, ASTM E711
• Calculation of net calorific value according to
DIN 51900, ASTM D240, ASTM D4809, ASTM
D5865, ASTM D1989, ASTM D5468, ASTM
E711
• Measurement range: max. 40,000 J (This cor-
responds to an increase in temperature in the
decomposition vessel of approx. 5 K).
• PC-operation of one or several calorimeters
(Software CalWin®)
• A sample rack can be connected
• USB printer port is available
System properties
The calorimeter system IKA®C 6000 global stan-
dards/isoperibol is routinely used for deter-mina-
tion of gross calorific values of solid and liquid
substances. The accessories of the system ensure
customized adaptation to laboratory tasks.
The system is characterized by the following fea-
tures:
• Relieves you of routine tasks through automated
measurement procedure
• Integral oxygen filling/degassing
• Automatic detection of decomposition vessel
• Operation without the cooling unit: Connection
to a water faucet with the pressure valve IKA®
C 25; temperature range 12 °C upto 27 °C; wa-
ter consumption per measurement about 4 l;
water pressure max. 1 bar upto 1.5 bar.

8
Transport and storage
Transport and storage conditions
The system must be protected against mechani-
cal impact, vibrations, dust deposits and corrosive
ambient air during transportation and storage. It is
also important to ensure that the relative humidity
does not exceed 80 %.
The appliance must be completely emptied before
storing and transportation.
In accordance with IKA®warranty conditions, the
warranty period is 12 months. For claims under
the warranty please contact your local dealer. You
may also send the machine direct to our factory,
enclosing the delivery invoice and giving reasons
for the claim. You will be liable for freight costs.
The warranty does not cover worn out parts, nor
does it apply to faults resulting from improper use,
insu cient care or maintenance not carried out in
accordance with the instructions in this operating
manual.
Please read these operating instructions carefully.
IKA®only consider themselves to be responsible
for the safety, reliability and performance of the
appliance when
• the appliance has been operated in accordance
with the operating instructions,
• only persons authorised by the manufacturer
interfere with the appliance,
• only original parts and original accessories are
used for repairs.
The calorimeter system may be opened only by
an authorised Service Agent or Customer Service
Centre.
If service is required, we recommend that you
contact our customer service department
Furthermore, we refer you to the applicable safety
conditions and accident requirements.
IKA®is not responsible for damages or costs result-
ing from accident, improper use of the device or
impermissible modifications, repairs or renovations.
Warranty and liability
• Operating mode based on the adiabatic, isoperi-
bolic or dynamic principle at 22 °C, 25 °C or 30
°C (the beginning temperature of the water in
the inner vessel) depending on the cooling wa-
ter temperature.
Differences between the room temperature and
working temperature have an influence on accu-
racy in dynamic mode; as a result, the working
temperature should always be kept similar to the
room temperature.
Cooling water Mode of operation Mode of operation
temperature C 6000 global standards C 6000 isoperibol
12 °C to 20 °C Adiabatic 22 °C -
Isoperibolic 22 °C Isoperibolic 22 °C
Dynamic 22 °C Dynamic 22 °C
20 °C to 23 °C Adiabatic 25 °C -
Isoperibolic 25 °C Isoperibolic 25 °C
Dynamic 25 °C Dynamic 25 °C
23 °C to 27 °C Adiabatic 30 °C -
Isoperibolic 30 °C Isoperibolic 30 °C
Dynamic 30 °C Dynamic 30 °C

9
Scope of supply
Calorimeter IKA®C 6000 global standards/isoperibol
• Calorimeter IKA®C 6000 global standards/isoperibol
• Attachment set
• Stylus for touch screen operation
• Discharge hose (1.5 m)
• Connection tube O2
• Venting hose
• Mains connection cable
• Warranty card
• Water inflow pipe
• Water return pipe
• Operating instructions
Unpacking
Please unpack the system components carefully
and check for any damage. When you unpack the
equipment, check for any damages which may
have occurred during transportation.
In the case of any damage a fact report must be
sent immediately (post, rail or forwarder).

10
Description of system components
Touch Screen
Lift
Stylus for
operating the
touch screen
Calorimeter IKA®C 6000 global standards/isoperibol
Decomposition vessel
Water filter
Water Oxygen
Interfaces
Mains power supply

11
Commissioning
C 6000
C 6000
Condenser
C 6000
C 6000
• O2connection tube
(in)
• Inflow pipe
(in)
• Venting hose
(out)
• Discharge hose
(empty)
M 8x1
Place of installation
A constant ambient temperature is an important
requirement for ensuring the high measuring
accuracy of the system. The following conditions
must therefore be fulfilled at the place of
installation:
• No direct solar radiation
• No draughts (e.g. beside windows, doors, air
conditioning)
• Sucient distance to radiators and other heat
sources
• The minimum distance between the wall and
the rear side of the device must be at least 25
cm.
• The system must not have laboratory hardware
such as shelves, wire ducts, ring lines, etc.
installed above it.
• The (constant) room temperature should be
around 20 °C ... 25 °C.
• The system must be set up on a horizontal
surface.
For operation of the system the following must be
available at the place of installation:
- A power supply corresponding to the nameplates
on the system components,
- An oxygen supply (99.95 % pure oxygen, quality
3.5; pressure 30 bar) with pressure gauge.
A shut-off valve for the oxygen supply must be
installed. Observe the instructions on handling
oxygen given in the chapter „Safety instructions“.
Please read these operating instructions carefully.
IKA®consider themselves responsible for the
safety, reliability and performance of the appliance
only when
• the device has been operated in accordance
with the operating instructions,
• the specifications for the place of
installation have been met.
Do not use distilled or demineralized water
(increased risk of corrosion)! Fill the cooler
according to the cooler operating instructions. is
recommended in drinking tap water quality. Mix
in (max. 1 ml for 4-5 l of water) of the supplied
water additive. Thus, the durability of the water is
improved.
• Return pipe
(out)
Hoses

12
Connection to the condenser
Make sure the filter casing is always se-
curely closed (see „Servicing and clean-
ing the filter“)!
Insert the inflow pipe into the „IN“
port until it clicks home. Connect the
other end of the pipe to the „OUT“
port of the condenser (water pressure
max 1.5 bar).
Insert the return pipe into the „OUT“
port until it clicks home. Connect the
other end of the pipe to the „IN“ port
of the condenser.
The connection „EMPTY“ is intended
only for emptying the device, e.g.
for transport purposes. In normal
operation the discharge hose need not
be inserted!
Rear view without hoses attached
Connection to the water
Operatrion is only allowed with the
pressure valve IKA®C 25!
The IKA®C 25 pressure valve is ab-
solutely essential on the water faucet
for operation of the calorimeter, and it
must be preset to an output pressure
of approximately 1.5 bar.
The valve is installed into the line of
the water connection, see operating
instruction IKA®C 25.

13
Connecting the oxygen supply
Insert the O2connection tube into the calorimeter
„IN“ port until it clicks home and connect the free
end to the pressure reducer, using the adapters
supplied if necessary. IKA®C 29. Removal entails
the same operations performed in the reverse
sequence.
Note: The O2connection tube can be removed
only after it has been depressurised.
Screw the venting hose to the screw coupling
(8 AF) on the calorimeter and position the free
end under the extractor hood or connect it to a
gas washing device. Comply with the applicable
safety regulations in this respect.
O2connection tube IN
max. 4 MPa
Venting hose
IKA®C 29
Combustion gases are haz-
ardous to health, therefore
the venting hose must be
connected to a suitable gas cleaning system
or extraction system.
The venting hose discharges the combustion
gases from the decomposition vessel after every
combustion trial. When laying the venting hose
ensure that it is not crushed or kinked.
Secure the end of the hose with an
adhesive strip.
Connection to the mains power supply
Check that the available mains power supply
matches the mains power supply particulars listed
on the rating plate.
DANGER

14
Connection of peripherals
Note: While the peripheral devices are being connected, they and the calorimeter must be
turned-off on the mains power switch!
RS232 PC: Serial connection for controlling the calorimeter using CALWIN or operating
with serial printer C1.50.
Standard setting: Baud rate: 9600
Data bits: 8
Stop bits: 1
Parity: none
Handshake: none
RS232 BALANCE: Interface for connecting scales (Mettler, Ohaus, Sartorius, Kern)
Standard setting: Baud rate: 1200
Data bits: 7
Parity: odd
Stop bits: 1
Handshake: none
ETHERNET: Network connection for data transfer via the network, e.g. to a network printer.
USB-DEVICE: USB interface (only for service).
USB-HOST: Interface for connection of a printer or with a USB mouse.
SAMPLE-RACK: Interface for connection of the C 5020 sample rack.

15
On/off switch
The device is switched on and off via the on/off
switch located on the right-hand side.
Switch the device off at the on/off switch.
Lift moves upwards.
Switch the appliance off only by using the menu com-
mands.
Lift moves downwards.
Data may be lost if the appliance is
switched off other than by follow-
ing the menu commands.
Note: Switch the device off at the on/off switch only
when directed to do so by the menu command.
ATTENTION

16
Display and operating elements
After the IKA®C 6000 global standards/iso-
peribol calorimeter has been switched on,
the touch screen display is active and can be
operated using the stylus or finger.
Explanation of the screen display
Schematic representation of the display components
Pos. Designation
A Tab
C Arrow symbol, tabs
D Arrow symbol, vertical scroll bar
E Vertical scroll bar
F Info line
G Arrow symbol, horizontal scroll bar
H Horizontal scroll bar
I Control button
Other view-based presentations of display components are described in the relevant section.
A
D
D
E
F
G
G
IH
C

17
The contents of the screen display are often dis-
tributed over several tabs. You can switch be-
tween tabs at any time by clicking on them. Thus
for instance the screen display during the calori-
metric standard procedure consists of the three
views „Measurements“, „Device“ and „Graphics“.
List displays and report fields have scroll bars.
Clicking on the pale areas of the scroll bar scrolls
the list display or report field. Clicking in the dark
area and dragging it allows you to move continu-
ously through the display, as does clicking on the
arrow symbols and maintaining the selection.
Note: Greyed-out fields cannot be selected.
Report
field
Status symbols
Green tick
Measurement completed but not yet evaluated, or selection acknowledgement.
Pocket calculator
Measurement completed end evaluated, evaluation inputs can no longer be changed.
Blank tick
Measurement prepared but not yet performed.
Yellow X
Field property not selected, or cancelled before ignition.
Red X
Cancellation after ignition.
Circle
Measurement selected.
List display

18
The view „Graph“ shows the temperature by time.
The most important actions available at any point
in time are gathered together as clickable buttons
along the bottom edge of the screen.
To initiate an action it is sucient to click on one of
the discrete areas showing the relevant images or
text. For instance during the „Preparation for mea-
surement“ dialogue the most important actions are
explained below.
Weighted sample:
Permits manual input of a weight value using the
virtual keyboard.
Calibration:
Selection field for marking a calibration (on/off).
Decomposition vessel:
Manual selection box when decomposition vessel
detection is inactive.
Name:
Alphanumeric editable field.
User:
Alphanumeric editable field.
Properties
Alphanumeric editable field.
IKA®thread
Selection box which allows a selection list to be
opened.
Switch
Switch
Selection
box

19
Input of a numerical value, such as weight-
ed sample:
The entire area with the exception of the „Scale“
button is available to be clicked here. A numerical
virtual keyboard is opened and can be used to
input the value:
After the virtual keyboard has been closed with
„OK“, the value in the input field is loaded. Alter-
natively, clicking on the „Scale“ button automati-
cally loads a value from a connected balance.
Input of an alphanumeric value, such as
„Designation“ :
Here again the entire area is available to be clicked.
A complete virtual keyboard is opened.
Note: The maximum input is 23 characters.
After the virtual keyboard has been closed with
„OK“, the value in the input field is loaded.
Select from a selection box, e.g. for the ig-
nition aid:
After the selection box has been clicked, a list of
the options is displayed. The option that is clicked
is selected.
Single selection field, such as calibration :
Clicking on the entire area allows the prepared
measurement to be marked as a calibration.
Selection box
Weighted sample
Shift key for upper and lower case
letters and special characters

20
System test
The system test is performed automatically every time the IKA®C 6000 global standards/isoperibol is
switched on.
During the system test the start screen is shown
again; clicking on the „Show details“ button pro-
vides detailed information.
Safety instructions regarding information on and
activation of the calorimeter are then shown on
the IKA®Homepage.
The system test includes the following steps:
- Testing the external water circuit with the cir-
culation pump and heater (approx. 30 to 45
seconds).
- Testing the internal water circuit with the con-
denser and water supply, plus the heater once
again (approx. 30 to 45 seconds).
- Testing whether the temperature of the cooling
waters is correct for the selected function of the
IKA®C 6000 global standards/isoperibol. (ap-
prox. 60 to 180 seconds).
If any one of these steps is not performed success-
fully, the system test stops with an error message.
After all the components have been checked the
system test can be restarted the same as after a
manual cancellation. To do this, press the „Re-
start“ button.
With the system test in standby, no measure-
ments can be made. However it is possible to se-
lect some menu options.
Working with the IKA®C 6000 global standards/isoperibol calorimeter
Switching on the device
The IKA®C 6000 global standards/isoperibol is
switched on with the On/off switch. The cover
opens automatically. A start screen appears for
about 30 seconds, during which the hardware is
initialised and the software is loaded.
