iLive Home Dock for iPhone/iPod with Intelli Set... User manual

USER’S GUIDE
V:0858-0804-10
For the most up-to-date version of this User’s Guide, go to www.ilive.net
ICP689B
Home Dock for iPhone and iPod
with Intelli Set™

2
 Lithium batteries, like all rechargeable
batteries are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices in
your area. They should never be incinerated since they
might explode.
 : Shock hazard - Do Not Open.
• AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS
OUVRIR
Mains plug is used as disconnect device and it should
remain readily operable during intended use. In order
to disconnect the apparatus from the mains completely,
the mains plug should be disconnected from the mains
socket outlet completely.
La prise du secteur est utilisé pour déconnecter le
système.
La prise du secteur ne doit pas être obstruée ou doit être
facilement accessible pendant son utilisation. Pour être
complètement déconnecté de l’alimentation d’entrée, la
prise doit être débranchée du secteur.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o
recargables (ni-cad, ni-mh, etc.).
 : TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
 To reduce the risk of re or electric shock,
do not expose this apparatus to rain or moisture.
  Pour réduire le risque d’incendie
ou de choc électrique, ne pas exposer cet appareil sous la
pluie et l’humidité.
  Use of any controls or adjustments or
performance of procedures other than those herein
specied may result in hazardous radiation exposure.
  Changes or modications to this unit
not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
  Do not place the unit on top of any soft,
porous, or sensitive surfaces to avoid damaging the
surface. Use a protective barrier between the unit and
surface to protect the surface.
  Use of this unit near uorescent lighting
may cause interference regarding use of the remote. If
the unit is displaying erratic behavior move away from
any uorescent lighting, as it may be the cause.
 Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
• PRÉCAUTION: Danger d’explosion si les piles sont
remplacées de façon incorrect. Remplacer les piles
seulement par le même type de pile ou l’équivalent.
  There is a danger of explosion if you
attempt to charge standard Alkaline batteries in the unit.
Only use rechargeable NiMH batteries.
  The remote control’s button cell battery
contains mercury. Do not put in the trash, instead recycle
or dispose of as hazardous waste
Warnings and Precautions
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.

Customer Support: 1-888-999-4215 3
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and
that no objects lled with liquids, such as vases, shall be placed on
apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux
éclaboussures et aucun objet ne contenant de liquide, tel qu’un vase,
ne doit être placé sur l’objet.
• Main plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus
from the mains completely, the mains plug should be disconnected
form the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être facilement
accessible pendant son utilisation. Pour être complètement
déconnecté de l’alimentation d’entrée, la prise doit être débranchée
du secteur.
• Battery shall not be exposed to excessive heat such as sunshine, re
or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la
lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the rear or back of the apparatus.
Attention marquage est situé à l’arrière ou à l’arrière de l’appareil
• The marking information is located at the rear or back of apparatus.
Les informations de marquage est situé à l’arrière ou à l’arrière de
l’appareil.
FCC Warnings
Additional Warnings
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
When the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12.
Important Safety Instructions
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
Use only with a cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

4
• Made for iPod and iPhone
• Dock plays and charges iPod and
iPhone
• AM/FM radio with digital tuning
• Intelli Set™ auto clock set
• Dual alarm
• Digital clock
• Remote
• Digital volume control
• Preset EQ settings
• Auxiliary input for iPod shue and
other audio devices
• Gradual wake
• Wake to iPod, radio, or buzzer
• Snooze function
• Sleep function
• Battery backup
• 0.8” LCD display with white
backlight
• AC power: requires an AC/DC
power adapter (included)
• AC/DC power adapter
• Remote control
• Docking brackets for iPod
Home Dock for iPhone and iPod with Intelli Set™
Features
Included

Customer Support: 1-888-999-4215 5
TABLE OF CONTENTS
Warnings and Precautions . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . 3
• FCC Warnings
• Additional Warnings
Home Dock for iPhone and iPod with Intelli Set™ . . . . . 4
• Features
• Included
Introduction . . . . . . . . . . . . . . 6
Setup . . . . . . . . . . . . . . . . 8
• Power
• Battery Backup Power
• Remote Batteries
iPod and iPhone . . . . . . . . . . . . . 9
• Docking an iPod
• Playing a Docked iPod
Clock and Sleep Timer . . . . . . . . . . . . 10
• Setting the Clock with Intelli Set™
• Time Zone Chart
• Manually Setting the Clock
• Setting the Sleep Timer
Alarm and Sleep . . . . . . . . . . . . . 11
• Setting the Alarms
• Using the Auxiliary Input
• Tuning the AM or FM Radio
• Saving a Station as a Preset
• Tuning to a Preset
Company Information . . . . . . . . . . . . 12
• International Support
• Contact Information

6
Introduction
AM/FM/STOP
Press to switch between
AM and FM radio when
in Radio Mode. Press
to stop a docked iPod
while playing.
HOUR/MINUTE/TUNE
Press to adjust the
hour and minute when
setting the clock or
alarms. Press to adjust
the AM and FM radio
station when in Radio
Mode. Press and hold
to scan for the next
available AM or FM
radio station. Press to
skip between songs on
a docked iPod when in
iPod Mode. Press and
hold to search within
an individual track on
a docked iPod when in
iPod Mode.
PLAY/PAUSE/FM ST.
Press to play or pause
a docked iPod. In Radio
Mode press to turn FM
Stereo Mode o and on.
POWER/ALARM OFF
Press to turn the unit
o and on. Press to turn
the alarm o after it has
sounded.
SOURCE
Press to switch between
the unit’s dierent
modes. (iPod Mode,
Radio Mode, or Aux
Mode)
DC POWER INPUT
DST
Press to turn Daylight
Savings Time o or on.
DOCK FOR IPHONE
AND IPOD
SNOOZE/DIMMER
Press, after the alarm has sounded,
to delay the alarm for an additional 9
minutes. Press to adjust the brightness
of the display.
VOLUME
Press to adjust the
volume.
PRESET/ALARM
Press to cycle through
saved AM and FM radio
stations.
Press to set alarm 1 or
alarm 2, and to activate
or deactivate alarm 1 or
alarm 2.
TIME ZONE/PRESET
Press to adjust the unit’s
currently set time zone.
Press to save the current
AM or FM radio station
to the unit’s memory.
EQ/DISPLAY
Press to switch between
the unit’s preset
equalizer settings.
(Classic, Rock, Pop, and
Jazz) Press and hold to
view the time when in
Radio Mode.
CLOCK ADJUST/SLEEP
Press to adjust the unit’s
clock. Press to adjust
the unit’s sleep timer.
(90, 80, 70, 60, 50, 40, 30,
20, or 10 minutes)
AUXILIARY INPUT
Use to connect an MP3
Player or other audio
source to the unit.
AM ANTENNA
CONNECTION & FM
WIRE ANTENNA
Use the AM Antenna
Connection to connect
the included AM Loop
Antenna to the unit.

Customer Support: 1-888-999-4215 7
POWER/ALARM OFF
Press to turn the unit o and on.
Press to turn the alarm o after
it has sounded.
REPEAT
Press to repeat the current track,
album, or playlist.
Press Once: Repeat current
track.
Press Twice: Repeat album or
playlist.
ALARM 1
With the unit powered o, press
and hold to set alarm 1.
With the unit powered o,
press to activate or deactivate
alarm 1.
ALARM 2
With the unit powered o, press
and hold to set alarm 2.
With the unit powered o,
press to activate or deactivate
alarm 2.
MEMORY
Press to save the current FM or
AM radio station to the unit’s
memory.
PLAY/PAUSE/FM ST.
Press to play or pause a docked
iPod. In Radio Mode press to
turn FM Stereo Mode o and on.
TIME ZONE
Press to adjust the currently set
time zone.
See the Operations on
setting the time for detailed
instructions on using the Time
Zone button.
SLEEP
Press to adjust the unit’s sleep
timer. (90, 80, 70, 60, 50, 40, 30,
20, or 10 minutes)
EQ
Press to switch between the
unit’s preset equalizer settings.
(Classic, Rock, Pop, and Jazz)
MUTE
Press to decrease the unit’s
volume completely.
SNOOZE/DIMMER
Press, after the alarm has
sounded, to delay the alarm for
an additional 9 minutes. Press
to adjust the brightness of the
display.
DISPLAY
Press and hold to view the time
when in Radio Mode.
RADIO
Press to switch to Radio
Mode. When activated,
the unit can be switched
between AM and FM radio
modes.
AUXILIARY
Press to switch to Auxiliary
Mode. When activated,
the unit will output audio
from the audio source
connected to the Auxiliary
Input. iPod
Press to switch to iPod Mode.
When activated, the unit will
amplify audio from a docked
iPod or iPhone.
MENU
Press to go to the previous
menu on a docked iPod/iPhone.
This button works exactly like
the “Menu” button on an iPod.
MENU UP/DOWN BUTTONS
Press the Menu Up/Down
buttons to navigate through
the menus on a docked iPod/
iPhone.
SELECT BUTTONS
Press the Select button to make
a selection on a docked iPod/
iPhone.
The Select button functions
exactly like the select button
on an iPod.
SKIP/SEARCH
Press to skip tracks on a docked
iPod/iPhone.
Press and hold to search
through an individual track on a
docked iPod/iPhone.
AM/FM/STOP
Press to switch between AM and
FM radio when in Radio Mode.
Press to stop a docked iPod
while playing.
VOLUME
Press to adjust the volume.
MEMORY UP/DOWN
BUTTONS
Press the Memory Up/Down
buttons to cycle through AM
and FM radio stations that
have been saved to the unit’s
memory.

8
Plug the included AC/DC power adapter into
the DC POWER INPUT and a standard AC power
outlet to power the unit.
Requires 1, CR2025 size, battery
(pre-installed)
Requires 1, CR2032 size, battery
(not included)
Please note, the Battery Backup is meant for
short term unexpected power outages. It will only
preserve the time and alarm times. None of the
other playback functions will work solely o of the
backup battery power.
To access the backup battery, use a phillips head
screwdriver to remove the battery compartment
door.
Power
Remote Batteries
Battery Backup Power
Setup
LITHIUM BATTERY
CR 2025
3V
PUSH
OPEN
Battery: CR2025

Customer Support: 1-888-999-4215 9
Docking an iPod
1. Locate the numbered bracket that ts the
iPhone/iPod model that will be docked.
Each included bracket has a number on it,
indicating which iPhone/iPod model that
bracket is compatible with. See the separate
bracket chart page to identify which bracket
is needed.
2. Snap the bracket into place over the
iPhone/iPod connector in the dock.
3. Connect the iPhone or iPod to the
connector inside the Dock for iPhone/iPod.
4. When the dock is plugged in, using AC
power, the docked iPhone or iPod will
charge.
iPod and iPhone
Playing a Docked iPod
1. Follow the instructions for Docking an iPod.
2. Press the POWER button to turn the clock
radio on.
3. Press the SOURCE button to switch to iPod
mode.
4. Press the PLAY/PAUSE button to begin
playing the docked iPod or iPhone.

10
Clock and Sleep Timer
  
 AST Atlantic Standard Time UTC - 4 hours
ADT Atlantic Daylight Time UTC - 3 hours
 EST Estern Standard Time UTC - 5 hours
EDT Eastern Daylight Time UTC - 4 hours
 CST Central Standard Time UTC - 6 hours
CDT Central Daylight Time UTC - 5 hours
 MST Mountain Standard Time UTC - 7 hours
MDT Mountain Daylight Time UTC - 6 hours
 PST Pacic Standard Time UTC - 8 hours
PDT Pacic Daylight Time UTC - 7 hours
 AKST Alaska Standard Time UTC - 9 hours
AKDT Alaska Daylight Time UTC - 8 hours
 HAST Hawaii-Aleutian Standard Time UTC - 10 hours
HADT Hawaii-Aleutian Daylight Time UTC - 9 hours
1. When the unit is rst powered on, the time will automatically be set to Eastern Standard Time.
2. Press the POWER button to turn the unit o.
3. Press and hold the TIME ZONE button.
4. While holding the TIME ZONE button, press the HOUR/MINUTE buttons on the unit to adjust
the time zone.
Refer to the Time Zone Chart to nd your specic time zone.
1. Adjust a docked iPod to the desired track,
album, or playlist, or adjust the AM or FM
radio to the desired station.
2. Press the SLEEP button repeatedly to cycle
through the available sleep times (90, 80,
70, 60, 50, 40, 30, 20, or 10 minutes.)
3. When the sleep timer is set, “SLP” will
appear on the display.
4. After the set amount of time has expired,
the unit will power o.
1. Press the POWER button to turn the unit
o.
2. Press and hold the CLOCK ADJUST button.
3. While holding the CLOCK ADJUST button,
press the HOUR/MINUTE buttons to adjust
the hour and minute.
A PM Indicator will appear on the display
when the time is set in the PM.
4. After the correct time is set, release the
CLOCK ADJUST button to nish setting
the clock.
Setting the Clock with Intelli Set™
Setting the Sleep Timer
Time Zone Chart
Manually Setting the Clock

Customer Support: 1-888-999-4215 11
Alarm and Sleep
1. Press the POWER button to turn the unit
o.
2. Press and hold the ALARM 1 button or
ALARM 2 button.
3. While holding the ALARM 1 or 2 button
press the HOUR/MINUTE buttons to adjust
the alarm time.
4. While holding the ALARM 1 or 2 button
press the SOURCE button to adjust the
alarm source. (iPod, Radio, or Buzzer)
5. Release the ALARM 1 or 2 button to nish
setting the alarm.
6. Press the ALARM 1 or 2 button to activate
or deactivate alarm 1 or 2.
1. Connect an MP3 player or other audio
source to the AUXILIARY INPUT on the
back of the unit.
Requires a 3.5mm Line-Input Cable. (not
included)
2. Press the POWER button to turn the unit
on.
3. Press the Source button to switch the unit
to Auxiliary Mode.
Use the native controls on the MP3 player
or other audio source to control playback
options.
Use the volume controls on the unit to control
the volume.
1. Press the POWER button to turn the unit
on.
2. Press the SOURCE button to switch to Radio
Mode.
3. Press the AM/FM button to switch between
AM or FM radio mode.
4. Press the TUNE buttons to adjust the AM
and FM radio station when in Radio Mode.
5. Press and hold the TUNE buttons to scan
for the next available AM or FM radio
station.
1. Tune to the desired AM or FM radio station.
2. Press the MEMORY button on the remote.
3. Press the MEMORY UP/DOWN buttons to
select a memory slot to save the current
radio station to.
4. Press the MEMORY button on the remote,
to save the current AM or FM station to the
selected memory slot.
Up to 20 AM and 20 FM radio stations can be
saved to the unit’s memory at one time.
1. Press the MEMORY UP/DOWN buttons on
the remote or the PRESET buttons on the
unit to cycle through saved AM or FM radio
stations.
Setting the Alarms
Using the Auxiliary Input
Tuning the AM or FM Radio
Saving a Station as a Preset
Tuning to a Preset

Copyright © 2010 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective
owners. Specications are subject to change without notice
To download this User’s Guide in English,
Spanish, or French, visit the support section at
www.ilive.net.
Para transferir esta guía de usuario en inglés,
español, o francés, visite la sección de la ayuda en
www.ilive.net.
Pour télécharger ce guide de l’utilisateur en
anglais, espagnol, ou français, visitez la section
de soutien chez www.ilive.net.
Phone: [phone]
Email: [email protected]
Parts Email: par[email protected]
Website: www.ilive.net
International Support
Contact Information
Company Information
