Iluminarc Ilumipanel 90 IP Optic RGB User manual

Ilumipanel 90 IP Optic RGBWA
User Manual

Edition Notes
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
Edition Notes
The Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 covers the description, safety
precautions, installation, programming, operation, and maintenance of the Ilumipanel 90 IP Optic
RGBWA. ILUMINARC
®
released this edition of the Ilumipanel 90 IP Optic RGBWA User
Manual Rev. 10 in November 2011.
Trademarks
The ILUMINARC
®
logo, the ILUMINARC
®
name and all other trademarks in this document
related to services or products by ILUMINARC
®
are trademarks owned or licensed by
ILUMINARC
®
, its affiliates or subsidiaries. Any other product names, logos, brands, company
names, trademarks featured or referred to within this document are the property of their respective
trademark holders.
Copyright Notice
The entire content of this document, except where applicable and unless otherwise noted, is solely
owned by ILUMINARC
®
, a wholly owned trademark of CHAUVET & Sons, Inc.
© Copyright 2011 ILUMINARC®.
All rights reserved.
Electronically published by ILUMINARC
®
in the United States of America.
Manual Usage
ILUMINARC
®
authorizes its customers to download and print this manual for professional
information purposes only. ILUMINARC
®
expressly prohibits the usage, copy, storage,
distribution, modification, or printing of this manual or its content for any other purpose without
its written consent.
Document Printing
For better results, print this document in color, on letter size paper (8.5 x 11 inches), double sided.
If using A4 paper (210 x 297 mm), configure your printer to scale the content of this document to
A4 paper.
Intended Audience
Any person in charge of installing, operating, and/or maintaining the Ilumipanel 90 IP Optic
RGBWA should read the Guide that shipped with it and this manual in their entirety before
installing, operating, or maintaining this product.
Disclaimer
ILUMINARC
®
believes that the information contained in this manual is accurate in all respects.
However, ILUMINARC
®
assumes no responsibility for any error or omissions in this document.
ILUMINARC
®
reserves the right to revise this document and to make changes from time to time
in the content hereof without obligation of ILUMINARC
®
to notify any person or company of
such revision or changes. This does not constitute in any way a commitment by ILUMINARC
®
to
make such changes. ILUMINARC
®
may issue a revision of this manual or a new edition of it to
incorporate such changes.
Document Revision
The Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 supersedes all previous versions of
this manual. Please discard any older versions of this manual you may have, whether in printed or
electronic format, and replace them with this version.
Author Date Editor Date
Daniel Couppe 11/14/11 Beth Pillow 11/14/11

Table of Contents
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 i
Table of Contents
1. Introduction......................................................................................................1
What Is In the Flight Case............................................................................................ 1 
Unpacking Instructions................................................................................................. 1 
Claims .................................................................................................................................1
Text Conventions ......................................................................................................... 1 
Safety Notes................................................................................................................. 2 
Personal Safety...................................................................................................................2
Mounting and Installation.....................................................................................................2
Power and Wiring................................................................................................................2
Operation.............................................................................................................................2
2. Product Description ........................................................................................3
Features ....................................................................................................................... 3 
Options................................................................................................................................3
Product Overview......................................................................................................... 4 
Product Dimensions..................................................................................................... 5 
3. Installation........................................................................................................6
Mounting....................................................................................................................... 6 
Orientation...........................................................................................................................6
Installation ...........................................................................................................................6
AC Power ..................................................................................................................... 7 
Power Consumption............................................................................................................7
AC Plug ...............................................................................................................................7
Power Wiring.......................................................................................................................7
DMX Linking................................................................................................................. 8 
DMX Modes.........................................................................................................................8
Signal Wiring .......................................................................................................................8
Protocol Connectivity...........................................................................................................8
Controllers.................................................................................................................... 9 
DMX Controller....................................................................................................................9
ILUMICON.........................................................................................................................10
Ilumicode...........................................................................................................................10
W-DMX™ Calibration................................................................................................. 11 
4. Operation........................................................................................................12
Ilumicode.................................................................................................................... 12 
Ilumicode Panel Description..............................................................................................12
Control Options .......................................................................................................... 12 
Programming.............................................................................................................. 12 
DMX Personality................................................................................................................12
DMX Starting Address.......................................................................................................12
Static Colors......................................................................................................................13
Dimmer..............................................................................................................................13
Color..................................................................................................................................13
Whites Setting ...................................................................................................................13
Reset to Factory Settings ..................................................................................................13
Menu Map .................................................................................................................. 14 
DMX Values ............................................................................................................... 15 
ARC FULL.........................................................................................................................15
ARC 1................................................................................................................................15
ARC 1 + D.........................................................................................................................15
ARC 2 + D.........................................................................................................................16
ARC 3................................................................................................................................16
ARC 3 + D.........................................................................................................................16
SOLID................................................................................................................................16
SPECIAL 2 ........................................................................................................................17

Table of Contents
ii Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
5. Technical Information ...................................................................................18
Product Maintenance ................................................................................................. 18 
Product Repairs.......................................................................................................... 18 
Troubleshooting Guide............................................................................................... 19 
Photometrics .............................................................................................................. 20 
LED Disclaimer........................................................................................................... 21 
LED Life.............................................................................................................................21
LED Binning.......................................................................................................................21
Color Rendering Index (CRI).............................................................................................21
Returns Procedure..................................................................................................... 22 
Contact Us.................................................................................................................. 22 
Technical Specifications............................................................................................. 23 

Introduction
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 1
1. Introduction
This icon
indicates useful,
although non-
critical information.
This icon
indicates
important
installation or
configuration information.
Failure to comply with this
information may prevent
the product from
functioning correctly.
This icon
indicates critical
installation,
configuration, or operation
information. Failure to
comply with this
information may render
the product partially or
completely inoperative,
damage third-party
equipment, or cause harm
to the user
The term “DMX”
used throughout
this document
refers to the USITT
DMX512-A transmission
protocol.
What Is In the Flight Case
One Ilumipanel 90 IP Optic RGBWA
One Power Input Cable (bare-Ended)
One Data Input/Output Cable (Bare-Ended)
One W-DMX™ Receiver
One Safety Cable
Warranty Card
Quick Reference Guide
Unpacking Instructions
Immediately upon receiving a product from ILUMINARC
®
, carefully unpack the flight case.
Check the contents to ensure that all parts are present and in good condition.
Claims
The carrier is responsible for any damage incurred during shipping. If the merchandise
appears to have been damaged during shipping, the customer must submit the damage
report and any related claims to the carrier, not ILUMINARC
®
. The customer must
submit the report upon receipt of the damaged merchandise. Failure to do so in a
timely manner may invalidate the customer’s claim with the carrier.
For other issues such as missing components or parts, damage not related to shipping,
or concealed damage, the customer must make claims to ILUMINARC
®
within seven
(7) days of receiving the merchandise.
Text Conventions
Convention Meaning
1~512 A range of values in the text
50/60 A set of mutually exclusive values in the text
“ILUMICON UM” The name of another publication or manual
<SET> A button on the product’s control panel
Settings A product function or a menu option
MENU > Settings A sequence of menu options
1~10 A range of menu values from which to choose in a menu
Yes/No A set of two mutually exclusive menu options in a menu
ON A unique value to enter or select in a menu

Introduction
2 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
There are no user
serviceable parts
inside this
product. Any reference to
servicing you may find
from now on in this User
Manual will only apply to
properly certified
ILUMINARC
®
technicians. Do not open
the housing or attempt
any repairs unless you
are certified to do so.
Please refer to
all applicable
local codes and
regulations for the proper
installation of this product.
Keep this
manual for future
consultation. If
you sell this product to
another user, make sure
that they also receive this
manual.
In the unlikely
event that your
Ilumipanel 90 IP
Optic RGBWA may
require service, please
contact ILUMINARC
®
Technical Support.
Safety Notes
Please read all the following safety notes carefully because they include important information
on how to install, use, and maintain this product safely.
Personal Safety
Avoid direct eye exposure to the light source while the product is on.
Always disconnect this product from its power source before servicing.
Always connect this product to a grounded circuit to avoid the risk of electrocution.
Do not touch this product’s housing when operating because it may be very hot.
Mounting and Installation
This product is for outdoor use and can be submerged (IP67). However, do not
submerge deeper than 1 m for more than thirty (30) minutes.
This product weighs 51 lbs. (23.22 kg). Always ask for help when mounting this
product to avoid personal injuries or damage to the unit.
Make sure there are no flammable materials close to this product while operating.
When hanging this product, always secure it to a fastening device using a safety cable
(included).
Power and Wiring
Always make sure that you are connecting this product to the proper voltage, as per the
specifications in this manual or on the product’s sticker.
Never connect this product to a dimmer pack.
Make sure that the power input cable is not cracked, crimped, or damaged.
Never disconnect this product by pulling or tugging on the power input cable.
Operation
The maximum ambient temperature is 104° F (40° C). Do not operate this product at a
higher temperature.
In case of a serious operating problem, stop using this product immediately!

Product Description
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 3
2. Product Description
The Ilumipanel 90 IP Optic RGBWA is a high intensity wash product used to light a variety of
both indoor and outdoor applications
The Ilumipanel 90 IP Optic RGBWA consists of a steel base and an adjustable panel. The base
contains the power supply and the control unit. The panel is attached to adjustable steel arms
that come from the base. The DMX and power input and output are located on the power
supply.
Features
1, 3, 4, 5, 6, 7, or 9 channel DMX-512 LED array light
Operating modes:
1-channel: Dimmer
3-channel: RGB control
4-channel: Dimmer, RGB control
4-channel: RGBW control
5-channel: Dimmer, RGBW control
5-channel: RGBWA control
6-channel: Dimmer, RGBWA control
7-channel: Dimmer, RGB, color macros, strobe, dimmer speed
9-channel: Dimmer, RGBWA control, color macros, strobe, dimmer speed
W-DMX™ receiver
Five distinct dimming curves
High power 5 W (700 ~ 1,000 mA) RGBWA LEDs
IP67 with 316 stainless steel hardware
Gore™ valve
Cast and extruded aluminum with Integrated Cooling Enhancement™
Options
Ilumicode addresser (required for product configuration)

Product Description
4 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
Product Overview
Locking
Adjustment
Plate
316Stainless
SteelGlandNuts
Position
Locking
Pin
PowerIn
SignalIn/Out
Gore™Valve
W‐DMXAntenna

Product Description
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 5
Product Dimensions

Operation
6 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
3. Installation
Make sure to
mount this
product away
from any flammable
material as indicated in
the Safety Notes.
Mounting
Before mounting this product, read and follow the safety recommendations indicated in the
Safety Notes section.
Orientation
Always mount this product in any safe position while making sure there is adequate
room for ventilation, configuration, and maintenance.
Installation
The Ilumipanel 90 IP Optic RGBWA has twelve (12) mounting points on the base of
the product to secure to almost any surface. ILUMINARC
®
recommends following
the general guidelines below when mounting the Ilumipanel 90 IP Optic RGBWA.
When selecting an installation location, consider ease of access to the product for
operation, programming adjustments, and routine maintenance.
Make sure that the location where you are mounting the product can support its
weight. Please see the Technical Specifications section of this manual for the
weight requirement of this product.
Mounting Points

Operation
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 7
Always connect
the Ilumipanel 90
IP Optic RGBWA
to a protected circuit with
an appropriate electrical
ground to avoid the risk of
electrocution or fire.
Never connect
the Ilumipanel 90
IP Optic RGBWA
to a rheostat (variable
resistor) or dimmer circuit,
even if the rheostat or
dimmer channel serves
only as a 0 to 100%
switch.
Make sure to
connect the
Ilumipanel 90 IP
Optic RGBWA product to
a power line with the
proper voltage and
frequency, as per the
specifications in this
manual or on the
product’s sticker.
The listed
current rating
indicates the
maximum current draw
during normal operation.
If you choose to
bury the power or
signal distribution
boxes, make sure that
they are IP67 rated or
greater.
AC Power
The Ilumipanel 90 IP Optic RGBWA has an auto-ranging power supply that works with an
input voltage range of 100~240 VAC, 50/60 Hz.
Make sure you are connecting this product to the proper voltage, as per the specifications in this
manual or on the product’s sticker.
Power Consumption
To determine the power requirements for the Ilumipanel 90 IP Optic RGBWA, refer to
the label affixed to the side of the product or refer to the Technical Specifications chart
in this manual.
The listed current rating indicates the maximum current draw during normal operation.
AC Plug
The Ilumipanel 90 IP Optic RGBWA comes with an un-terminated power input cord
for hardwiring during installation. Use the table and illustration below to wire a plug.
Connection Wire (US) Screw Color (US) Wire (Europe) IP67 Pin
AC Live Black Yellow or Brass Brown 1
AC Neutral White Silver or Gray Blue 2
AC Ground Green/Yellow Green Green/Yellow 3
Power Wiring
You can connect the bare-ended IP67 rated AC power cable from the product to an
IP67 rated power connector or IP67 rated junction box.
If using junction boxes, make sure to use IP67 rated conduit for surface installations.

Operation
8 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
The units must
be linked using
DMX cable in a
daisy chain (serial)
fashion. To comply with
the EIA-485 standard, no
more than 32 units should
be connected on one
daisy chain without using
a DMX optically-isolated
splitter. Doing otherwise
may result in deterioration
of the digital DMX signal.
USITT
recommends
limiting the total
length of the DMX cable
(from the first
unit/controller to the last
unit) to 300 ~ 455 m (985
~ 1,500 ft).
Disconnect the
product from the
AC power before
opening it.
The signal cable
must match or
exceed the
electrical characteristics
of the Belden® 9841
cable for EIA RS-485
applications. You may
also use CAT5, 5e, or
CAT6 LAN cable.
DMX Linking
You may link the Ilumipanel 90 IP Optic RGBWA to a DMX controller using a standard DMX
serial connection or W-DMX™. If using other DMX units compatible with the Ilumipanel 90
IP Optic RGBWA, you can control each product individually with a single DMX controller.
DMX Modes
The Ilumipanel 90 IP Optic RGBWA uses the standard DMX data connection for
ARC1, ARC1+D, ARC2, ARC2+D, ARC3, ARC3+D, ARC FULL, REMOTE,
SOLID, and SPECIAL 2.
Refer to the Introduction chapter for a brief description of these modes and the
Operation chapter to learn how to configure the Ilumipanel 90 IP Optic RGBWA to
work in these modes.
The DMX Values section will give you detailed information regarding the above-
mentioned DMX modes. The highest possible starting address for each DMX mode
are as follows:
DMX Mode DMX Address DMX Mode DMX Address DMX Mode DMX Address
ARC FULL 506
A
RC3 508 SOLID 512
ARC1 510
A
RC3+D 507 SPECIAL2 504
ARC1+D 509
A
RC3+S 506
Signal Wiring
To provide signal for any of the Ilumipanel 90 IP Optic 15/30 RGBWA, you can
connect the bare-ended IP67 rated signal cable from the product to two IP67 rated
signal connectors (DMX In and DMX Out) or use an IP67 rated junction box. In this
case, make sure to use IP67 rated conduit.
Protocol Connectivity
The Ilumipanel 90 IP Optic RGBWA uses USITT DMX 512 Protocol. The procedure
below illustrates the recommended connection method.

Operation
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 9
If you have not
configured the
DMX starting
address and DMX
mode for each product,
they will all use their
default values. This
means that all products
will operate in unison.
Controllers
The products in the Ilumipanel 90 IP Optic RGBWA can operate with a standard DMX
controller, the ILUMICON controller, or the Ilumicode addresser. The sections below will show
you how to connect these products to the corresponding controllers.
The instructions to operate these products with each of the above controllers are in the
Operation chapter of this manual. You may also choose to connect these controllers via W-
DMX™.
Refer to the W-DMX™ transmitter instructions provided with your transmitter and the W-
DMX™ Calibration section of this manual to use this method.
DMX Controller
The Ilumipanel 90 IP Optic RGBWA products can work with a standard DMX
controller. The channel assignments will depend on the chosen personality (see the
corresponding Menu Map section) and the DMX address assigned to each product (see
the Programming section).
The following figure illustrates how to connect the DMX controller to the Ilumipanel
90 IP Optic RGBWA products.

Operation
10 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
To assign
individual DMX
addresses to each
product, you must
connect the Ilumicode
addresser to each product,
individually.
The Ilumicode will
not work via
wireless. You
must hardwire the
ilumicode directly to the
Ilumipanel 90 IP Optic
RGBWA when
programming the product.
ILUMINARC®
suggests that you
connect no more than 20
products together at one
time with this controller and
keep the total distance to
less than 60 m (197 ft).
Otherwise, you might need
to use an optically isolated
signal amplifier.
ILUMICON
The Ilumipanel 90 IP Optic RGBWA can also work with the ILUMICON controller
instead of a standard DMX controller. Please refer to the ILUMICON User Manual to
learn how to use this controller with the Ilumipanel 90 IP Optic RGBWA products. The
following figure illustrates how to connect the ILUMICON controller to the Ilumipanel
90 IP Optic RGBWA.
Ilumicode
The Ilumicode addresser (version 2.2 or higher) is required to program the settings on
the Ilumipanel 90 IP Optic RGBWA. The following diagram shows how to connect the
Ilumicode addresser to this product.
This connection will control multiple products at the same time. In addition, all
connected products will be assigned to the same DMX address
Important: The Ilumicode must be used to configure this product. The Ilumicode
can be purchased separately through your Iluminarc sales representative.

Operation
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 11
The Ilumicode
Addresser is
required to send
DMX addressing and
personality information to
the fixture.
Once W-DMX
has been
enabled, you
cannot use the Ilumicode
to make changes to the
Ilumipanel 90 IP Optic
RGBWA. Changes made
via the Ilumicode should be
done prior to enabling W-
DMX. The W-DMX takes
priority control over the
wired DMX cables.
W-DMX™ Calibration
You can run the Ilumipanel 90 IP Optic RGBWA without DMX cabling using the W-DMX™
option. This product can operate in W-DMX mode up to 300 m (900 feet) from the W-DMX
transmitter. For wireless operation, the W-DMX receiver in the Ilumipanel 90 IP Optic RGBWA
must be paired with the W-DMX transmitter. Use the following instructions to operate.
1. Using the Ilumicode, set the personality and the DMX address to the Ilumipanel 90 IP Optic
RGBWA. (Refer to the programming section of the Operation chapter of the User Manual.)
2. Disconnect power and the Ilumicode from the product.
3. Open the cover next to the W-DMX™ Antenna by unscrewing the 6 Allen Screws using a
3mm angled Allen Key.
4. Reconnect power to product.
5. Press and hold the W-DMX™ button until the Green LED stops flashing.
6. Disconnect power to the product for approximately 10 seconds.
7. Reconnect power to product.
8. Locate the product by using the W-DMX™ transmitter. (Refer to the W-DMX™ transmitter
instructions provided with your transmitter.)
9. Upon locating the product wirelessly, close the cover.
10. Tighten the Allen Screws uniformly by alternating between opposite screws to insure a tight
seal.



Operation
12 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
4. Operation
When you scroll
through the
menu options,
you will see
many of them that do not
correspond with the menu
map. Skip them, as they
do not work with the
RGBWA only output
products.
Ilumicode
The Ilumipanel 90 IP Optic RGBWA needs the Ilumicode addresser to change its configuration.
Ilumicode Panel Description
Control Options
You can set the Ilumipanel 90 IP Optic RGBWA start address in the 001~512 DMX range. This
allows for the control of up to 51 products in the 10-channel Special 1 personality.
Programming
Carry out all the programming procedures indicated below from the control panel. Refer to the
Menu Map section to learn how the menu options relate to each other.
Use <ENTER> and <MENU> to change levels in the Menu Map. This is equivalent to move
right and left respectively. Use <UP> and <DOWN> to move vertically within the Menu Map
options.
DMX Personality
1. Go to PERS and select any DMX personality.
2. Make sure to rearrange the DMX addresses of all products in the current DMX
universe to avoid address overlapping.
DMX Starting Address
1. Go to DMX.
2. Select a starting DMX address (001~512).
Button Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the
currently selected value into the selected function
<UP> Navigates upwards through the menu list and increases
the numeric value when in a function
<DOWN> Navigates downwards through the menu list and
decreases the numeric value when in a function
<POWER> Turns the unit on. The unit will turn off automatically
after 30 seconds of inactivity.

Operation
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 13
DIM1 is the
fastest dimmer
curve and DIM4
is the slowest.
Static Colors
1. Go to STATIC.
2. Select a color or effect (Red, Green, Blue, White, Amber or Strobe).
3. Select a color value (000~255) or a strobe frequency (0~20).
Dimmer
1. Go to DIMMER.
2. Select a dimmer curve (OFF or DIM1~4).
Procedure:
DIMMER Description
OFF Dimmer curve is linear with fader
DIM1 Non-linear (fastest)
DIM2 Non-linear (fast)
DIM3 Non-linear (slow)
DIM4 Non-linear (slowest)
Color
1. Go to SETTINGS > COLOR.
2. Select the color method (OFF, RGB TO W, UC).
Procedure:
OFF
When the RGB faders are all set to “255”, the output is maximum.
RGB TO W
When the RGB faders are all set to “255”, the output is the selected White color (see
Whites Setting).
UC
When the RGB faders are all set to “255”, the output matches the same color output of
previous versions of this product.
Whites Setting
1. Go to CALIB.
2. Select a white color (WHITE 1~11) or RGB TO W.
3. Select an RGB color (Red, Green, or Blue).
4. Configure the color value (0~255).
5. Repeat steps 3 and 4 for the other RGB colors to obtain a white color.
6. Repeat steps 2 to 5 for the other white colors.
Reset to Factory Settings
1. Go to SETTINGS > RESET.
2. Select an option (YES/NO).

Operation
14 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
Menu Map
Main Level Programming Levels Description
DMX 001~512 N/A Sets the DMX starting address
PERSON
ARC 1
N/A
3-channel: RGB control
ARC 1 + D 4-channel: RGB control + dimmer
ARC 2 4-channel: RGBW control
ARC 2 + D 5-channel: RGBW control + dimmer
ARC 3 5-channel: RGBWA control
ARC 3 + D 6-channel: RGBWA control + dimmer
ARC FULL 7-channel: RGB control, dimmer, color macro, strobe,
dimmer speed
REMOTE Allows using the ILUMICON unit
SOLID 1-channel: dimmer
SPECIAL 2 9-channel: RGBWA control, dimmer, color macro, strobe,
dimmer speed
CALIB
WHITE (1~11) RED
GREN
BLUE
COOL
WARM
AMBE
0~255
Determines the white balance for the color macros
RGBTOW Determines the white balance when RGBTOW is active
DIMMER
OFF
N/A
Dimmer work in linear mode
DIM 1
Dimmer works in non-linear mode, from fast to slow.
DIM 2
DIM 3
DIM 4
STATIC
RED
0~255 Configures the static color and effect
GREN
BLUE
COOL
WARM
AMBR
STRB
SETTINGS COLOR
OFF Maximum output, unbalanced white
RGBTOW White output is as per CALIB > RGBTOW settings
UC
Output matches that of product’s previous versions
RESET NO/YES
Resets unit to factory default settings

Operation
Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10 15
DMX Values
ARC FULL
Channel Function Value Percent/Setting
1 Dimmer 000 255 0~100%
2 Red 000 255 0~100%
3 Green 000 255 0~100%
4 Blue 000 255 0~100%
5 Color Macros
000 010
011 035
036 060
061 085
086 110
111 135
136 160
161 185
186 210
211 215
216 220
221 225
226 230
231 235
236 240
241 245
246 250
251 255
No function
R: 100% G: Up B: 0%
R: Down G: 100% B: 0%
R: 0% G: 100% B: Up
R: 0% G: Down B: 100%
R: Up G: 0% B: 100%
R: 100% G: 0% B: Down
R: 100% G: Up B: Up
R: Down G: Down B: 100%
White 1: 3,200 K
White 2: 3,400 K
White 3: 4,200 K
White 4: 4,900 K
White 5: 5,600 K
White 6: 5,900 K
White 7: 6,500 K
White 8: 7,200 K
White 9: 8,000 K
6 Strobe 000 005
006 255 No function Slow~Fast
7 Dimmer Speed
000 009
010 069
070 129
130 189
190 255
Off
Speed 1 (Fastest)
Speed 2
Speed 3
Speed 4 (Slowest)
ARC 1
Channel Function Value Percent/Setting
1 Red 000 255 0~100%
2 Green 000 255 0~100%
3 Blue 000 255 0~100%
ARC 1 + D
Channel Function Value Percent/Setting
1 Dimmer 000 255 0~100%
2 Red 000 255 0~100%
3 Green 000 255 0~100%
4 Blue 000 255 0~100%

Operation
16 Ilumipanel 90 IP Optic RGBWA User Manual Rev. 10
ARC 2 + D
Channel Function Value Percent/Setting
1 Dimmer 000 255 0~100%
2 Red 000 255 0~100%
3 Green 000 255 0~100%
4 Blue 000 255 0~100%
5 White 000 255 0~100%
ARC 3
Channel Function Value Percent/Setting
1 Red 000 255 0~100%
2 Green 000 255 0~100%
3 Blue 000 255 0~100%
4 White 000 255 0~100%
5 Amber 000 255 0~100%
ARC 3 + D
Channel Function Value Percent/Setting
1 Dimmer 000 255 0~100%
2 Red 000 255 0~100%
3 Green 000 255 0~100%
4 Blue 000 255 0~100%
5 White 000 255 0~100%
6 Amber 000 255 0~100%
SOLID
Channel Function Value Percent/Setting
1 Dimmer 000 255 0~100%
