Iluminarc Ilumipod Inground Tri-12 IP User manual

Ilumipod Inground
Tri-12 IP
Quick Reference Guide

Ilumipod Inground Tri-12 IP
2
What is
Included
•One Ilumipod Inground Tri-12 IP
•Concrete installation sleeve •One Warranty Card •One Quick Reference Guide
About this
Guide
The Ilumipod Inground Tri-12 IP Quick Reference Guide (QRG) only
contains the product
’s connection and mounting information as well as the
menu options and the DMX values.
This QRG does not replace the
product’s user manual. You must download the user manual
from the
ILUMINARC® Web site (www.iluminarc.com) to learn about the
disclaimers, safety notes, programming modes and technical information.
Product at a
Glance
Use on Dimmer
x
Auto Programs
x
Outdoor Use P
Auto-ranging power
supply
P
Sound Activated
x
Replaceable Fuse
x
DMX
P
User Serviceable x
Master/Slave
x
Duty Cycle
x
Features
•Remote addressable DMX-512 LED inground wash light
•Operating modes:
1-channel: Dimmer
3-channel: RGB control
4-channel: RGB, dimmer
6-channel: RGB per module
7-channel: RGB, dimmer, macro, strobe, dimming speed
•Blackout/static/dimmer/strobe/pulse
•IP67 ingress protection
•High power 3 W (1,050 mA) tri-color LEDs
•IP67 stainless steel gland nuts for cable entry
•Adjustable module angle
•Cast aluminum and stainless steel housing
•Impact resistant glass lens cover (drive-over rated)
• Polished stainless steel mounting ring
Options
•Ilumicode compatible
•ILUMICON compatible
•Installed (non-changeable) optical system:
15
°
lenses P/N: 11012001

Ilumipod Inground Tri-12 IP
3
Installation
Notes
The Ilumipod Inground Tri-12 IP consists of
two parts, the fixture housing
and the concrete installation sleeve
. The fixture housing is IP67 rated, but
the
sleeve is not. Please pay close attention to the installation instructions
for the concrete installation sleeve regarding leveling and drainage.
You will have to run the AC power and signal cables into the concrete
installation sleeve and the fixture’s hou
sing. Do not use the fixture’s
junction box to extend the power or signal cables
to other units because it
may compromise the IP rating of the junction box. Instead, use individual
cables from the fixture to the corresponding distribution boxes.
Always kee
p the power cables away from the signal cables by running them
in different conduits and using separated distribution boxes.
Installation
Sleeve
Orientation
Orient the installation
sleeve to allow the signal
cable to enter the sleeve
using one of
the four cable
inlets and the power cable
to use the opposite inlet
, as
seen in the figure
. This
will reduce the stress to
the signal and power
cables when installing the
fixture, while keeping
them separated.
Installation
Sleeve Setup
When setting up the installation sleeve, make sure that any water that may
have entered it can drain out of the sleeve on its own. Locate the
installation
sleeve above the normal drainage level so the fixture
does not become
submerged in more than 1 m of water (IP67) during heavy rain.
In addition, make sure that the installation sleeve allows the stainless steel
collar to be leveled and flushed with the ground
surface to distribute the
load uniformly over the fixture’s surface.
Installation Sleeve
Drainage
The Ilumipod Inground Tri-12 IP can support a distributed load of up to
3,000 kg (6,614 lbs) when properly installed.

Ilumipod Inground Tri-12 IP
4
Beam Angle
Adjustment
The Ilumipod Inground Tri-12 IP has two LED modules. You can adjust the
angle of each of these modules to spread or narrow the fixture’s beam. To
do so, follow these steps:
•Loosen the ¼ turn Allen bolts on the stainless steel collar.
•Lift the fixture from the installation sleeve, making sure not to stretch
the power and signal cables.
•Loosen the six nuts that hold the collar to the housing, except two
adjacent ones.
•
Wait a few seconds for the seal to expand. This lowers the possibility of
damaging the seal.
•Complete the removal of the two remaining nuts.
•Remove the stainless steel collar.
•Carefully, lift and remove the protective glass and seal. Make sure not
to reverse the glass.
•Using only your hands, push on the sides of each module to adjust its
angle, as shown in the figure below.
•Replace the glass and seal.
•Replace the stainless steel collar, making sure to allow the Allen screws
to show and that the glass is flushed with the collar.
•Replace all six nuts and adjust them manually until they touch the
housing.
•Tighten the nuts uniformly by alternating between opposite nuts.
•
Reattach the fixture to the installation sleeve.

Ilumipod Inground Tri-12 IP
5
AC Power
This product has an auto-
ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
Junction
Box
This fixture has an IP67 rated junction box where the power and signal
cables come into the unit. The cables access the junction box through
individual (signal and power) IP67 rated stainless steel gland nuts.
Make sure that the junction seal is clean befo
re placing the cover back on.
In addition, tighten the gland nuts and the junction cover
to prevent water
from entering the junction box and cause a short.
The figure below shows the connections in the junction box.
Power
Wiring
To provide AC power to this fixture, you must run a single STJW rated, 3-
conductor cable (AWG18/3, 6~8 mm external diameter) from the power
distribution box into the installation sleeve and the fixture’s junction box.
Make sure to s
trip the end of the AC
power
cable that will connect to the
junction box as indicated in the figure
on the right.
Power Cable Table
Connection Wire (US) Wire (Europe)
AC Live
Black
Brown
AC Neutral White Blue
AC Ground
Green/Yellow
Green/Yellow
Signal
Wiring
To provide signal to this fixture, you must run a single, IP67 rated DMX
signal cable (shielded, 2-conductor, AWG24/2
, 6.5 mm external diameter)
from the signal distribution box into the installation sleeve and the fixture’s
junction box. The signal cable
must match or exceed the electrical
characteristics of the Belden® 9841 cable for EIA RS-485 applications.
VERY IMPORTANT
Make sure to use power and signal cables with the indicated outer diameters
to ensure that the corresponding gland nut makes full contact with the
cable’s external insulation. This is required to ensure watertightness once
fully adjusted.

Ilumipod Inground Tri-12 IP
6
Power
Distribution
You must connect the bare-ended power cable from the fixture to a
power
distribution box. If you choose to bury the power distribution boxes
, make
sure that they are IP67 rated.
Power Distribution
Box Wiring
Signal
Distribution
You must connect the bare-ended signal cable from the fixture to a signal
distribution box.
If you choose to bury the signal distribution boxes, make
sure that they are IP67 rated.
Signal Distribution
Box Wiring

Ilumipod Inground Tri-12 IP
7
DMX
Controller
The Ilumipod Inground Tri-12 IP
can work with a standard DMX
controller. The channel assignments will depend on the chosen personality
(see Menu Options
) and the DMX address assigned to each fixture (see
Settings).
The figure below illustrates how to connect the DMX controller to the
Ilumipod Inground Tri-12 IP fixture(s).
DMX Controller
Connection
ILUMICON
The Ilumipod Inground Tri-12 IP can also work with the ILUMICON
controller instead of a standard DMX controller. Please refer to the
ILUMICON user manual to learn how to use it with this fixture.
The figure below illustrates how to connect the ILUMICON controller to
the Ilumipod Inground Tri-12 IP fixture(s).
ILUMICON
Controller
Connection

Ilumipod Inground Tri-12 IP
8
Settings
The Ilumipod Inground Tri-12 IP
uses the Ilumicode unit for configuration
purposes.
Ilumicode
Connection
The diagram below shows how to connect the Ilumicode to this product.
Note that this connection will control multiple fixtures at the same time,
all having the same DMX address. To assign individual DMX addresses to
each fixture, you must connect the Ilumicode unit to each fixture,
individually.
Ilumicode
Connection
Diagram
ILUMINARC® suggests you to connect no more than 20 fixtures in this
mode and to keep the total distance to less than
60 m (197 ft). Otherwise,
you might need to use an optically isolated signal amplifier.
Ilumicode
Description
Button Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently
selected value into the selected function
<UP>
Navigates upwards through the menu list and increases the
numeric value when in a function
<DOWN>
Navigates downwards through the menu list and decreases the
numeric value when in a function

Ilumipod Inground Tri-12 IP
9
Menu
Options
1ST Level 2nd Level 3rd Level Instructions
DMX 001~512 N/A Sets the DMX starting address
PERSON
ARC 1
N/A
3-channel: RGB control
ARC 1 + D 4-channel: RGB + dimmer (D)
ARC FULL 7-channel: RGB, D, macro, strobe,
speed
REMOTE The fixture operates with
ILUMICON
SOLID 1-channel: D
SPECIAL 1 6-channel: RGB per module
CALIB
WHITE
1~11
RED
000~255
Defines the White color
temperature used in
Macros
GREEN
RGBTOW
(1) Defines the white color
used in RGBTOW (2)
BLUE
DIMMER
OFF
N/A
The dimmer works in linear mode
DIM 1~4 The dimmer works in non-linear mode, from fast (DIM1) to slow
(DIM4).
STATIC
RED
000~255 Combines RGB values to form a
static color
GREEN
BLUE
STRB 00~20 Sets the strobe frequency (0~20 Hz)
SETTINGS
COLOR
OFF When RGB = 255, output is
maximum
RGBTOW
(2) When RGB = 255, output is the one
defined in RGBTOW (1)
UC When RGB = 255, output matches
older models of the same fixture
RESET NO
YES

Ilumipod Inground Tri-12 IP
10
DMX Values
ARC FULL
Channel
Function
Value
Setting
1
Dimmer
000 ó255
0~100%
2
Red
000 ó255
0~100%
3
Green
000 ó255
0~100%
4
Blue
000 ó255
0~100%
5 Color Macro + White
Balance
000 ó010
011 ó030
031 ó050
051 ó070
071 ó090
091 ó110
111 ó130
131 ó150
151 ó170
171 ó200
201 ó205
206 ó210
211 ó215
216 ó220
221 ó225
226 ó230
231 ó235
236 ó240
241 ó245
246 ó250
251 ó255
No Function
Red 100% - Green Up - Blue 0%
Red Down - Green 100% - Blue 0%
Red 0% - Green 100% - Blue Up
Red 0% - Green Down - Blue 100%
Red Up - Green 0% - Blue 100%
Red 100% - Green 0% - Blue Down
Red 100% - Green Up - Blue Up
Red Down - Green Down - Blue 100%
Red 100% - Green 100% - Blue 100% - White 100%
White 1: 3,200 K
White 2: 3,400 K
White 3: 4,200 K
White 4: 4,900 K
White 5: 5,600 K
White 6: 5,900 K
White 7: 6,500 K
White 8: 7,200 K
White 9: 8,000 K
White 10: 8,500 K
White 12: 10,000 K
6 Strobe
000 ó004
005 ó255
No Function
0~20 Hz
7 Dimming Speed
000 ó009
010 ó029
030 ó069
070 ó129
130 ó189
190 ó255
Dimmer is set by Ilumicode
OFF (Dimmer is linear)
DIM1 (Fastest dimmer curve)
DIM2
DIM3
DIM4 (Slowest dimmer curve)

Ilumipod Inground Tri-12 IP
11
SPECIAL 1
Channel
Function
Value
Percent/Setting
1
Module 1 Red
000 ó255
0~100%
2
Module 1 Green
000 ó255
0~100%
3
Module 1 Blue
000 ó255
0~100%
4
Module 2 Red
000 ó255
0~100%
5
Module 2 Green
000 ó255
0~100%
6
Module 2 Blue
000 ó255
0~100%
ARC 1
Channel
Function
Value
Percent/Setting
1
Red
000 ó255
0~100%
2
Green
000 ó255
0~100%
3
Blue
000 ó255
0~100%
ARC 1 + D
Channel
Function
Value
Percent/Setting
1
Dimmer
000 ó255
0~100%
2
Red
000 ó255
0~100%
3
Green
000 ó255
0~100%
4
Blue
000 ó255
0~100%
SOLID
Channel
Function
Value
Percent/Setting
1
Dimmer
000 ó255
0~100%

Ilumipod Inground Tri-12 IP
12
Contact Us
World Headquarters
ILUMINARC®
General Information
Address:5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
United Kingdom and Ireland
ILUMINARC®
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
Technical Support
Email: [e-mail]
World Wide Web
www.iluminarc.com
World Wide Web
www.iluminarc.com
Ilumipod Inground Tri-12 IP QRG – Rev. 02
© Copyright 2014 ILUMINARC®
All rights reserved.
Printed in the P. R. C.
