10 . Avoid using front and rear washing functions excessively or for long periods of time as
such overuse may increase the possibility of washing away desirable resident bacteria and
causing an imbalance of bacteria in your body. If you are pregnant, are being treated for a
gynecological condition, develop excessive irritation in the area of use, or if you have
questions, please speak to your doctor before beginning or continuing use of the product.
GCW-1220-W-08110表紙-4.indd4GCW-1220-W-08110表紙-4.indd4 2011/07/1210:50:572011/07/1210:50:57

This product provides features to enhance personal toilet hygiene and comfort. This product features
include a posterior wash, a bidet, a warm air dryer, and a seat heater, as well as controls for these
functions.
This product consists of a body (with heated toilet seat, toilet seat lid, warm water tank, and power cord),
hardware to mount the body on a toilet and connect it to the toilet water supply and this installation and
use manual.
This product is equipped with the following features:
posterior wash with water flow strength controls
bidet with water flow strength controls
warm air dryer with air temperature controls
seat heater with heat level control
wash and bidet water temperature control
seat and water temperature indicators
wash and bidet nozzle self-cleaning
stop button for the wash, bidet, and dryer
•
•
•
•
•
•
•
•
5
2. Product description
Note:
When carrying the product, take care not to inadvertently bump or drop it.
This product has been already inspected using tap water. A small amount of water may be
detected when installing the unit; this should not be a cause for concern.
•
•
GCW-1220-W-08110.indd5GCW-1220-W-08110.indd5 2011/07/1211:12:122011/07/1211:12:12

6
3. Installing this product
Installation requirements
Product carton contents
Body
Packing
(2 mm) thick
Junction fitting
Manual set
Clip
Clip
Water supply hose
(95 cm long)
Mounting bolt
Bushing
Slide plate
(This plate attaches to the body.)
Washer
Remove the parts from the product carton and make sure all the parts in the parts list (below) are
present. Inspect the parts carefully to make sure they are in good condition.
If any part is damaged or missing, do not install this product. Contact the nearest sales outlet for the
part(s) you need.
This product carton should contain the following parts:
Body (with heated toilet seat, toilet seat lid and power cord)
Slide plate
Manual set
Mounting bolts, washers, and bushings (2 pieces each)
Junction fitting (with a packing)
Body water supply hose (with 2 clips)
•
•
•
•
•
•
Before installing this product, ensure that each of the following installation requirements is met.
Batteries (2) Wood screw Plastic anchor
Bracket
Remote control unit
*Remote control unit and bracket are
packed in the box of the parts.
For remote control unit
GCW-1220-W-08110.indd6GCW-1220-W-08110.indd6 2011/07/1211:12:122011/07/1211:12:12

7
A ground fault circuit interrupter must be installed in the circuit that supplies power to this product.
Ground fault circuit interrupter
Power supply
Grounding
Installation location
Water supply
220V
Checking the toilet room
The dimensions required for mounting this product on a
toilet are as shown in the figure below. Check to make
sure there is sufficient space inside the toilet room and
that there are no obstructions in the way.
DANGER:Improper use of the grounding plug can result in a risk of electric hazard.
Use only the tap water line to supply water to this product. There is danger of ground water or other
water that is not tap water causing trouble with this product.
The tap water pressure must be 0.06 to 0.74 MPa (0.6 to 7.5 kgf/cm2).
This product is for use on a nominal 220 V circuit. Use a 220 V, 50 Hz power supply. The maximum
power consumption is 305 W. Electrical wiring must be installed that meets these conditions. The plug
outlet shall be placed in accessible location after installation.
This product must be grounded. In the event of an electrical short circuit, grounding reduces the risk
of electric hazard by providing an escape wire for the electric current. The power cord has a grounding
wire and a three-blade grounding plug (shown below). Do not use an adapter with the product's power
plug, or use any other method to connect the plug to an improperly configured outlet.
The outlet to which the product is connected must be 220 V, 50 Hz, with a minimum electrical rating of 3
A. The outlet must be properly installed and grounded, and have a three-slot outlet (shown below).
If it is necessary to use an extension cord, use only a three wire extension cord that has a three-blade
grounding plug. The extension cord must be rated for at least 220 V, 50 Hz, 3 A.
This product is manufactured for family or personal use. In order to avoid damage to the electronic
components, prevent the body of this product from getting wet by drops or splashes of water. In
extremely humid conditions, please provide adequate ventilation by operating an exhaust fan or opening
a window (or door).
Unit : cm
3 or more
3 or more
20.7
21.9
120 or more 40 or more
55.8
42.6
GCW-1220-W-08110.indd7GCW-1220-W-08110.indd7 2011/07/1211:12:122011/07/1211:12:12

47 cm or more
8
Checking the toilet
1. Measure the size of the toilet.
Depending on the toilet, it may not be possible to mount
this product on it.
Make sure the toilet's dimensions are as shown in the
figure at right.
14 to 15.7 cm
39 cm or less
2. In the case of a toilet with a corner
mounted tank, decide which is more
satisfactory, (1) or (2).
In the case of a corner mounted tank type toilet, it is
possible to mount this product if the dimensions A and B
meet the conditions in either (1) or (2) below.
(1) A: 17 cm or more
(2) A: 13 cm or more and
B: 17 cm or more
(3) A': 17 cm or more
(4) A': 13 cm or more and
B: 17 cm or more
If the measured dimensions satisfy neither (1) or (2),
(3) or (4), take measures such as raising the position
of the tank. (Please consult with the store where you
purchased this product.)
3. Conditions for use of this product's water
supply hose (packed with this product)
The length of the water supply hose shipped with this
product is 95 cm, but a length within 80 cm from the
junction fitting to the body's water supply socket is
appropriate. (See the figure at right.)
80 cm or less
φ1.5 cm or more
AA' B
5 cm or more
GCW-1220-W-08110.indd8GCW-1220-W-08110.indd8 2011/07/1211:12:132011/07/1211:12:13

9
Names of parts
Overall view
Indicator panel
Strainer
* The strainer removes impurities and foreign matter in the
tap water. (See page 31.)
Strainer
Power save lamp
Power lamp
Water shutoff valve
Toilet bowl
Toilet seat
Nozzle (for bidet)
Toilet seat lid
Nozzle (for posterior)
Tank water supply pipe
Water supply hose
Power plug
Tank
Marking label
Strainer
(See below.)
Junction fitting
Body
Occupied seat sensor
Caution label
Deodorizer
cartridge cover
Deodorizer
cartridge
<Bottom of body>
Remote control unit
(See page 10.)
GCW-1220-W-08110.indd9GCW-1220-W-08110.indd9 2011/07/1211:12:142011/07/1211:12:14

10
Body locking plate
Body locking plate
Body
Lock lever
Operation panel
Use when drying wet parts.
(See page 25.)
DRY
Warm water tank drain plug
* Remove the warm water tank drain plug when draining the
water from the warm water tank. (See page 37.)
Warm water tank drain plug
<Bottom of body>
Stops posterior washing,
bidet washing, and drying
operations.
STOP
Adjusts the toilet seat
temperature. (See page 22.)
SEAT TEMP.
Use for bidet washing.
BIDET
Adjusts the water
temperature. (See page 22.)
WATER TEMP.
Use for posterior washing.
SHOWER
Pressing the stop switch
for 2 seconds or longer
turns the power on or off.
(See page 22.)
POWER
Pressing the toilet seat
switch and warm water
switch together for 2
seconds or longer turns off
the power to the toilet seat
heater and warm water
heater. (See page 26.)
POWER SAVE Adjusts the spray strength
during posterior and bidet
washing. (See page 23.)
STRENGTH
(See pages 33 and 34.)
Alternates spray strength
between strong and weak.
MASSAGE
GCW-1220-W-08110.indd10GCW-1220-W-08110.indd10 2011/07/1211:12:152011/07/1211:12:15

Installation
11
1. Installation of branch fitting
Branch fitting
Installation
diagram
Close the water shutoff valve
for the toilet very tightly with a
flathead screwdriver (or the valve
handle, if available) and shut off
the water supply.
(1) Close the water shutoff valve.
(2) Remove the existing water supply pipe.
1) Loosen the cap nut at the tank.
A small amount of water
may spill from the pipe
when loosening the cap
nut. If this is a concern,
please place a rag
underneath to catch
the spilled water before
loosening the nut.
2) Loosen the cap nut at the water shutoff valve and
remove the water supply pipe.
Packing
(color: black,
thickness: 2 mm)
Water shutoff valve
Water shutoff valve
Close
CAUTION
•Close the water shutoff valve before performing any
operations.
*If you perform operations without closing the valve,
you may experience water leaks.
Tank Cap nut
Supply pipe
Loosen
Supply pipe
Loosen Water shutoff valve
CAUTION
•Do not apply unnecessary force
on the water shutoff valve or water
supply pipe.
*Doing so may break the
connections and cause water leaks.
(3) Attach the
branch fitting.
Set the gasket seat
packing (color:
black, thickness: 2
mm) in the branch
fitting and attach
the fitting to the
water shutoff valve.
Water shutoff
valve
Branch fitting
(1) Shorten the water supply pipe.
1) Mark the end of the water supply
pipe (on the side without the
guard) for a cutting position which
is suitable for attachment to the
branch fitting and then increase
that amount by an additional
10 to 15 mm for some insertion
allowance.
2) Cut the water supply pipe at the
position determined above with a
pipe cutter.
CAUTION
•Please verify the orientation and the installation
sequence for each part.
*If you attach the parts in an incorrect sequence or
inappropriately, it may cause water leaks.
Tank
Installation diagram
Ball tap
(or ball valve)
Gasket packing
(color: blue,
thickness: 2 mm)
Cap nut
Guard area
Supply pipe
Branch fitting
Water supply from the wall
Cap nut
Split compression
ring
Slip washer
Insertion tolerance
(10 to 15 mm)
Cap nut Gasket packing
(color: blue,
thickness: 2 mm)
Ball tap
(or ball
valve)
Guard
area
Tank
Supply pipe
Branch fitting
Water supply from the floor
CAUTION
•Please do not cut the guard area of the supply pipe.
•Use a pipe cutter when shortening the supply pipe. Please connect the shortened pipe only after cleaning the cutting burrs by rinsing it with water or
some other method.
•If the water shutoff valve can move vertically 5 mm or more, first please securely affix the stop valve.
*This may cause water leaks.
Pipe cutter
Add 10 to 15
mm for insert
allowance.
Gasket packing
(color: black,
thickness: 4 mm)
2. Installation of water supply pipe
GCW-1220-W-08110.indd11GCW-1220-W-08110.indd11 2011/07/1211:12:162011/07/1211:12:16

12
3. Installation of water supply hose to the shower
toilet (at the shower toilet body) 1)
Remove the protective cover
from the end of the water supply
hose, and pull out the cap from the
water supply connection socket.
2) Connect the water supply hose
for the shower toilet into the water
supply connection socket.
(2) Attach the water supply pipe.
1) Place the cap nut for the tank and branch fitting, split
compression ring, slip washer, and packing (color: black,
thickness: 4 mm) on the shortened water supply pipe and
insert the pipe into the branch fitting. (Please see the
above installation diagram of the water supply pipe.)
2) Place the gasket packing (color: blue, thickness: 2 mm)
between the ball tap and the supply pipe, and attach the
supply pipe to the tank with the cap nut.
3) The cap nut for the branch fitting should be finger-
tightened as much as possible, and then, additionally
tighten it with a wrench for another 3/4 to one full turn. Do
not over-tighten the nut.
(Tightening torque: 10 to 15 Nm ( 8-11 ft-lbs) or 100 to
150 KgF/cm)
While tightening the nut with a wrench, place a spanner
(monkey wrench) around the hexagonal area of the
branch fitting to hold it firmly, and then tighten the cap nut.
Branch fitting
Supply pipe
Hose connection socket
CAUTION
•
Tighten the cap nut
while securely grasping
the ball tap to prevent it
from turning.
*If the ball tap is rotated
out of position, the float
ball may make contact with the inside wall of the tank
and cause a water stoppage failure.
•Please be careful not to break or damage the hose
connection.
*Doing so may cause water leaks.
•Please firmly connect the water supply pipe.
*If the cap nut is not sufficiently tightened, it may
cause water leaks.
3) Insert the attachment clip onto the
water supply hose to attach it to
the shower toilet and water supply
connection socket.
*The attachment clip can be attached in
any direction.
CAUTION
•
Please firmly insert the clip.
*If the clip is not firmly
inserted, it may cause
water leaks.
4) Bend the clip end and firmly clip
together both the feeding hose for
the shower toilet and the feeding
socket. After you install the clip,
twist it in both directions to verify
that it is firmly attached.
Water supply connection socket
Protective cover
Water supply
hose for the seat O-ring
CAUTION
•Please be careful not to damage the O-ring.
*If the O-ring is damaged, it may cause water leaks.
Clip
Clip
Bend here
Water supply
socket
Clip
O-ring
Installation diagram
Water supply hose for shower toilet
Water supply
socket
CAUTION
•Please insert the clip
until you feel a click
from the clip edge.
*If not firmly inserted,
it may cause water
leaks.
•
When removing the clip, hold
the clip with your fingers, set
the flathead screwdriver and
push the clip downward to
remove it as shown in the
figure below.
Flathead
screwdriver
GCW-1220-W-08110.indd12GCW-1220-W-08110.indd12 2011/07/1211:12:172011/07/1211:12:17

13
4. Installation of the shower toilet (1) Remove the existing
seat.
1) Remove the nuts from the
seat mounting bolts, the
slip washers, and rounded
packing.
2) Raise the seat and remove
it by lifting the seat mounting
bolts.
Seat mounting bolts
References
•
Some toilet seats may require different methods
of removal that differ from our explanation.
• The removed toilet seat should be stored in your
home in case you remove the shower seat.
1) Insert the bushings into
the seat mounting holes. 2) Insert the mounting
brackets into the slide
plate and attach the slide
plate with the mounting
bolts on the seat.
(2) Attach the slide plate onto the seat.
1) Place the shower toilet on the toilet and align the ▽
mark on the slide plate with the △mark on the rear
section of the shower toilet.
2) Slightly raise the front side of the shower toilet, slide it
until the slide plate is fully inserted, and then press the
locking lever to secure the shower toilet.
(3) Attach the shower toilet.
CAUTION
•When use of the slide plate is not
necessary, please retain the slide
using the attaching screw included in
the installation kit to prevent it from
moving or becoming lost.
Rounded packing
Existing seat
Slip washer
Nut
Loosen
Bushings
Seat mounting holes
Mounting bolts for the toilet
Mounting brackets
Slide plate
1
2
Slide plate
Shower toilet
*For the attachment lacations of
the mounting brackets, please see
"Checking the toilet seat."
Caution
•When installing the shower
toilet, make sure to use the parts
provided in the installation kit.
Installation diagram
Toilet seat mounting guide holes
Shower toilet
Slide plate
Bushing
Mounting brackets
Seat mounting bolts
Slide plate
Attaching screw
GCW-1220-W-08110.indd13GCW-1220-W-08110.indd13 2011/07/1211:12:182011/07/1211:12:18

14
5. Attachment of the water supply hose for the shower
toilet (at the branch fitting)
(1) Remove the
protective covers
from the ends of
the water supply
hose and insert
the hose into the
branch fitting.
Installation diagram
Water supply hose
for the shower toilet
CAUTION
•Please be careful not to damage the O-ring.
*If the O-ring is damaged, it may cause water leaks.
•Please firmly insert the clip.
*If the clip is not firmly inserted, it may cause water leaks.
•Please insert the clip until you feel a click from the clip edge.
*If not firmly inserted, it may cause water leaks.
(2) Attach the clip in the same manner as
it is attached on the shower toilet, and
then attempt to twist the clip from side
to side to make sure that it is firmly
attached.
(1) Turn the water shutoff valve
counterclockwise to open the supply
of water to the tank and shower toilet.
(2) Operate the flush handle attached on
the tank and check each joint to see if
there are any water leaks.
* If water is leaking, further tighten the
connections, or re-install the shower toilet.
(3) Confirm that the water flow stops after
the tank is filled with water.
*If the tank does not fill with water, or the
water flow does not stop, please check
whether the ball tap and float ball are
functioning.
O-ring Branch
fitting
Clip
6. Confirming water flow
O-ring
Branch fitting
Protective
covers
Water supply hose
Clip
Clip
Bend here
Branch fitting
Water shutoff valve
Turn counterclockwise.
Example of water supply from the floor
CAUTION
• When water supply into the tank does not stop, or the
tank does not fill at all, please check if the float ball is
making contact with the inside wall of the tank.
• If so, please reposition it using the following procedure:
(1)Loosen the inside nut on the side of the tank and
vertically straighten the ball tap.
(2)
While holding the ball tap with your hand, tighten the nut.
• Please do not remove the strainer while the water shutoff valve is open.
• Doing so may cause water leaks from the strainer area.
Branch fitting area
Water supply socket area
•
When removing the clip, hold
the clip with your fingers, set
the flathead screwdriver and
push the clip downward to
remove it as shown in the
figure below.
Flathead
screwdriver
GCW-1220-W-08110.indd14GCW-1220-W-08110.indd14 2011/07/1211:12:192011/07/1211:12:19

15
8. Mounting the remote control
7. Positioning the remote control unit
Battery
Back cover
Bracket
Wood screw
6 mm dia.
Plastic anchor
Wood screw
Bracket
Bracket
Remote
control unit
Plastic anchor
φ6mm
33 mm
Bracket
Wood screw
(1) Open the back cover of the remote control
unit and insert the batteries (two AA size
batteries).
(2) Place the remote control unit in the position
you would like it to be in, sit down on the toilet
seat and press the stop switch.
(1) Place the bracket on the wall depending on the
wall material as follows, then mount it in the
desired mounting position.
• If mounted in plywood paneling 5 mm or
greater in thickness:
Fasten the bracket to the wall with the wood
screws.
• If mounted either in plywood paneling 5
mm or less in thickness or in gypsum
board:
A) In plywood paneling, drill holes with a
diameter of 6 mm; in gypsum board, drill
holes with a diameter of 5 mm.
B) Using a hammer, gently drive the plastic
anchors into the holes.
C) Fasten the bracket securely to the
anchors using wood screws. As you
tighten the screws, they are hard to turn at
first, then gradually get easier to turn, and
then are hard to turn again.
(2) Align the remote control unit with the bracket
and then push it down onto the bracket.
CAUTION
•
Install the batteries with the positive and negative poles facing the
correct direction in accordance with the marks on the remote control unit
case.
• Do not use old and new batteries together.
• Use the batteries in the pack.
CAUTION
•
Water will spray from the nozzle if the Shower or Bidet switch is pressed,
so exercise caution.
• Check to make sure there is enough space above the remote controller to
mount or remove the controller at its mounting position.
• After you make sure the power lamp blinking, pull the power plug out of the
receptacle at once.
GCW-1220-W-08110.indd15GCW-1220-W-08110.indd15 2011/07/1211:12:202011/07/1211:12:20

16
CAUTION
When removing the strainer, be sure
to close the water shutoff valve. When
attaching the strainer, firmly tighten it until
the end of the strainer is hidden in the body.
* Water will leak from the strainer.
Strainer
End
Used to dry the parts
that became wet during
washing.
DRY
Stops posterior washing,
bidet washing, and drying
operations.
STOP
Adjusts the heated toilet
seat temperature.
SEAT TEMP.
Adjusts the temperature of
the shower and bidet water.
WATER TEMP.
Flushes the toilet
automatically when you
rise from the toilet seat.
POWER
Saves power by lowering
the toilet seat temperature.
POWER SAVE
Adjusts the spray strength
during posterior and bidet
washing.
STRENGTH
Repeats washing
strength weak-strong
cycle.
MASSAGE
Trial operation (Follow the procedure below after installation work is completed.)
Confirm that the power lamp on the body is lit.
1. Insert the power plug in the outlet.
220V
Power plug
(2) Perform the same check with the bidet spray
function.
(1) Check the shower washing operation.
1) With your forearm resting on the toilet
seat, press the SHOWER button.
The shower automatically stops in two
minutes after the switch is turned on.
2) When the nozzle extends, cover the tip
of the nozzle with your hand to catch the
spray when the shower begins spraying.
3) Press the STOP button to stop the shower
spray.
*Since there is an occupied seat sensor, the
product’s shower, bidet and deodorizing functions
will not operate if you don't touch the seat.
Roll up your sleeve and
bring your bare arm in direct
contact with the toilet seat.
2.Check the shower and bidet spray.
Warning
Please make certain to
securely attach the ground wire.
*If not connected, there is the
risk of electric shock in case of a
failure.
*If there is no ground terminal
on the electrical outlet, please
consult an electrician.
GCW-1220-W-08110.indd16GCW-1220-W-08110.indd16 2011/07/1211:12:202011/07/1211:12:20

17
(1) Turn the water shutoff valve to the right to close it.
As the water shutoff valve is pre-adjusted, remember the
original position (how much it is turned).
(2) Remove the strainer on the left side of the body.
Place a wash bowl or similar underneath the strainer.
(3) Clean the strainer.
(4) Firmly tighten the strainer.
(5) Turn the water shutoff valve to the original position to open it.
(1) Turn the water shutoff valve to the right to stop water supply to
the tank.
(For cold area drain type, operate the indoor drain plug.)
(2) Press the flush lever on the tank to drain water from the tank.
(3) Remove the power plug from the outlet.
(4) Drain water from the hot water tank and the water supply hose
connected to the body.
1) Pull the lock lever on the right side of the body and slide the
body forward to remove it from the toilet bowl.
2) Remove the strainer on the left side of the body. Place a wash
bowl or similar underneath the strainer.
3) Tilt the body to the left to drain water from the water supply
hose through the strainer hole.
4) After water drainage, firmly attach the strainer.
5) Turn the drain plug on the bottom of the body to the left
(counterclockwise) 90 degrees to loosen it.
6) Tilt the body forward, pull out the drain plug and drain water
from the hot water tank completely.
7) After water drainage, push and turn the drain plug to the right
(clockwise) 90 degrees to tighten it.
8) Place the body on the toilet bowl, and engage the ▽mark on
the mounting plate with the convex part at the lower rear of the
body.
9) Slide the body backward and push the lock lever to secure the
body.
Strainer
Water Shutoff
Valve
Turn
clockwise.
Turn
clockwise.
Strainer
Lock Lever
Drain Plug
Loosen
▽mark of the Fixing Plate
Convex part of the
back of the body
3. If flushing begins to weaken,or if the shower spray
seems to be getting weaker, clean the strainers.
4. If freezing weather is anticipated before handing the
product to the customer, drain the water.
GCW-1220-W-08110.indd17GCW-1220-W-08110.indd17 2011/07/1211:12:212011/07/1211:12:21

18
For care of plastic parts, do not use any
cleansers which are not safe to use on
toilet seats. (Do not use toilet bowl cleaner,
household cleaner, bleach, benzene, paint
thinner, polishing powder, or cresol.)
Do not open or close either the toilet seat lid
or the toilet seat with great force. Doing so
could crack or otherwise damage it, causing
an electrical hazard.
Do not forcefully pull on the nozzle or turn it.
Doing so could damage it.
Do not cover the warm air outlet or insert a
foreign object into it. Doing so could cause
product failure.
Do not climb or seat on top of the toilet seat
lid or body. Doing so could damage it.
Do not lean against the toilet seat lid during use.
Doing so could damage it.
Observe these precautions to prevent possible injury or damage.
Safety precautions
Do not pull the power plug out of the wall
outlet by pulling on the power cord. This could
damage the power plug or power cord and
cause an electrical hazard.
4. Using this product
GCW-1220-W-08110.indd18GCW-1220-W-08110.indd18 2011/07/1211:12:222011/07/1211:12:22

19
Do not place a stove or heater close to
the body. Doing so could cause product
discoloration or failure.
If there is risk of water lines freezing,
implement the freeze prevention methods to
prevent damage. (See page 35.)
Do not apply unnecessary force to the body
water supply hose. Doing so could damage it
and cause water to leak.
Do not urinate on the nozzle. Doing so could
cause nozzle damage or failure.
In a thunderstorm, do not touch the power plug.
Doing so could cause an electrical hazard.
Do not expose this product to the direct
rays of the sun. Plastic parts could become
discolored by the sunlight.
If you are using this product for a long period of
time, set the seat temperature switch
on "Off".
For the following persons, be sure to set the
seat temperature switch on "Off" when they are
using this product.
(Children, elderly persons, persons who are
sick, persons who cannot adjust the temperature
themselves, persons with weak skin, persons
who are taking medicines that make them
drowsy, such as sleeping medications, deeply
intoxicated persons, or persons who are
extremely fatigued.)
* If this product is being used for a long
period of time with the seat temperature switch
on any setting other than "Off", there is
danger of low temperature burns.
About Low Temperature Burns
A burn occurs when the skin has been
exposed to high temperatures. However, a low
temperature burn may occur when the skin
has been in contact with an object at relatively
low temperature (about 40ºC). Susceptibility
to burns also depends on an individual’s skin
sensitivity and other factors.
GCW-1220-W-08110.indd19GCW-1220-W-08110.indd19 2011/07/1211:12:232011/07/1211:12:23

20
A toilet seat cover or toilet seat lid cover can
cause the occupied seat sensor to either remain
on continuously or not go on at all, leading to
faulty operation. In this event, remove the cover.
While this product is still new, there may be a
slight odor when using the drying function. As
the toilet is used, the odor will disappear.
To prevent the toilet seat and toilet seat lid
from slamming down, a damping mechanism is
provided to lower them gradually. If the toilet seat
or toilet seat lid is closed roughly or too forcefully,
this product could be damaged or fail.
Sit back fully on the toilet seat and arrange your
clothing so it does not get wet when using the
wash or bidet functions.
This product is constructed to use the tap water
pressure to extend the nozzles and spray water
from them. Where the tap water pressure is
extremely low, the nozzles may not spray water
at all with the spray strength at the weakest
setting. In this case, turn the STRENGTH dial
clockwise. (See page 23.)
• The capacity of the warm water tank is 0.88 L.
Water temperature gradually drops when the
wash or bidet is used. If the water drops below
a comfortable temperature, press the stop
button and wait about 3 minutes for the water to
reheat.
• The water temperature range is preset to the
following temperatures:
Low: Approx. 36 °C,
Medium: Approx. 38 °C,
High: Approx. 40 °C.
It takes approximately 10 minutes to heat
cold water (at about 5 °C) to the appropriate
temperature (about 38 °C). Occupied seat sensor
This product is equipped with an occupied seat
sensor that prevents the water from spraying
and the dryer from operating if nobody is sitting
on the toilet seat. This prevents activation if the
wash, bidet, or dry button is pressed when the
toilet seat is unoccupied.
• You are leaning forward or sitting on the front of
the seat.
Sit back fully on the toilet seat, or change the
way you sit on the toilet.
• You are wearing clothing that is black, napped,
or otherwise inhibits light reflection.
Cover the sensor with your hand or arrange
your clothing so that your skin is sensed by the
sensor.
• Dirt or water is on the sensor.
Remove the dirt or water from the sensor.
The occupied seat sensor uses light reflection
to function and may not operate in the following
cases:
This product may interfere with radio or
television reception. In this case, move the radio
or television away from this product until the
interference ceases.
Before and after washing and when the water
temperature adjustment button is pressed, etc.,
water is sprayed out around the nozzle, but this
is necessary due to this product's construction
and is not a sign of breakdown.
If water sprays under any other circumstances,
or sprays constantly, close the water shutoff
valve and remove the power plug from the
wall outlet. Then, contact the store where you
purchased this product.
Other references
GCW-1220-W-08110.indd20GCW-1220-W-08110.indd20 2011/07/1211:12:242011/07/1211:12:24
