The Inepro USB (Universal Serial Bus) card reader consists of a
USB interface controller board with a proximity card reader. The
controller board is programmed with software to read out the UID
(Unique ID) of the proximity card. By default the card reader reads
out the CSN (Card Serial Number) of the proximity card.
Please note that the firmware version programmed in the controller
board is depending on the proximity card technology and, if
needed, customized read out of the UID of the user card.
When a user card is presented to the reader the host device
receives the data as a keyboard input in hex format.
The Inepro USB Card Reader has an unique vendor and a
application ID. The vendor ID of Inepro = 0x1DA6, the application
ID = 0x0110. For each Inepro USB Card Reader the same
vendor/application ID is used (regardless of the used Inepro USB
card reader). At the connection procedure the software version of
the Inepro USB Card Reader is send to the host device.
Supported Proximity Card Technologies
The Inepro USB Card Reader supports the following proximity card
technologies:
·Mifare ISO 1443A
·Mifare Desfire ISO 1443A
·Legic Prime
·Legic Advant ISO 1443A
·Legic Advant ISO 15693
USB Communication
The Inepro USB card readers supports the USB 2.0 protocol as a
Human Interface Device (HID).

II
Inepro USB Reader Component List
Part

Inepro USB Reader Component List
Version 3.0.2 - 4
Inepro USB Card Reader Component List
The Inepro USB card reader comes in four version, the desktop
and the MFP version in the colours grey and red. The MFP version
is meant to be mounted on the side of an MFP machine, the
desktop version for use on a flat service or installment inside the
MFP.
Inepro Desktop USB Card Reader (Grey) Kit Content 276001
(or Red 276003)

5 - USB Card Reader (Desktop & MFP)
The Inepro Desktop USB Card Reader Kit consist of the following
items:
1. Desktop USB Card Reader Kit
-1x Multi ISO Reader Desktop (Grey 276001, Red 276003)
-2x Double-sided adhesive tape (for attachment of the USB
controller to the MFD (Multi Functional Device))
-1x Manual Leaflet (P551211)
-1x Serial Stickers (P551360)
-2x Cable Duct (PS8650)

Inepro USB Reader Component List
Version 3.0.2 - 6
Inepro MFP USB Card Reader (Grey) Kit Content 276000
(or Red 276002)
The Inepro MFP USB Card Reader Kit consist of the following
items:
2. MFP USB Card Reader Kit
-1x Multi ISO Reader MFP (Grey 276000, Red 276002)
-2x Cable Duct (PS8650)
-1x Manual Leaflet (P551211)
-1x Serial Stickers (P551360)
-1x Bottom Inlay Mounting Cover (Grey PS08818, Red )

III
Operation
Part

Operation
Version 3.0.2 - 8
Operation
Connect the reader
Connect the reader to a free USB port.
Inner operation of the Inepro USB reader
The card number that is read by the Inepro USB Card Reader is a
hex decimal format. This hex decimal number is divided into two
and after that the keyboard representation code of the number
shall be send by the USB interface controller. After the last
character an <enter> keystroke code is send.
The software driver that runs in the host will convert the code to the
ASCII character of the keystroke code.
When the card is removed, only a single <enter> keystroke code is
send.
For example:
·Read value: 0x12345678 (hex decimal number)
·Send keystroke data:
<0x1E><0x1F><0x20><0x21><0x22><0x23><0x24><0x25><0x
58>
·Conversion to ASCII characters by the HID host driver:
<1><2><3><4><5><6><7><8><enter>

IV
Software Test
Part

Software Test
Version 3.0.2 - 10
Software Test
Testing with the Inepro Test Tool:
The Inepro USB Card Reader can be tested with a PC or laptop.
Connect the reader to the USB port of the PC or laptop.
Start the Inepro Test Tool. This will show in the display which
software version is currently used in the Inepro USB Card Reader
and it will display the card ID when a card is presented to the
reader.

11 - USB Card Reader (Desktop & MFP)
Test with Windows Device Management:
1. On a PC or laptop without Inepro Test Tool you can also check
the version that is in the Inepro USB Card Reader .
2. Connect the Inepro USB Card Reader to the PC or laptop.
3. Go to “Configuration screen -> System -> Device Management
-> Human Interface Devices”. One of the available HID-USB
devices is the IP Card Reader set.
4. On the main page there is a field “location” and here you will find
the software version of the Inepro USB Card Reader .

Software Test
Version 3.0.2 - 12
Test with the Windows Calculator:
1. Connect to Inepro USB Card Reader to the USB PC or laptop.
2. Start the Calculator application on Windows, set de calculator
under 'View' in on 'Scientific'.
3. Set the number system to hex decimal ('Hex').
4. Present a card to the Inepro USB card reader.
5. Set the number system to decimal ('Dec') to read out the
decimal value of this number. This is the card number.

V
Hardware Test
Part

Hardware Test
Version 3.0.2 - 14
Hardware Test
Physical test Inepro USB card reader
1. Remove the top cover of the USB controller
2. Connect the Inepro USB Card Reader to the USB port of a
computer.
3. Check the indicator LED's to see if the board is operating as it
should.
LED's
On the USB interface board are a number of LED’s. Each of the
LED's has a label, explaining their use. See the table below.
Label
Function
Standby / OK
Busy
Not OK
<undefined>
<undefined>
<undefined>
<undefined>
<undefined>
Connection
Connection /
transmission
Burnscontinuously
Burnscontinuously
Off
On / Off
On / Power
Burnscontinuously
Flashes
Off

15 - USB Card Reader (Desktop & MFP)
