Inepro Reader Bracket for MFP User manual

Reader Bracket for MFP Assembly - EN
© 2021 inepro
Congratulations on your selection of the Inepro Reader Bracket for MFP Assembly. We
are certain you will be pleased with your purchase of one of the flexibele solutions of the
market.
We want to help you get the best result from your Reader Bracket for MFP Assembly.
This manual contains information on how to do that; please read it carefully. Due to
continuous product improvements this manual is subject to changes without notice.
We strongly recommend you read the license agreement to fully understand its
coverage and your responsibilities of ownership.
Your Inepro dealer is dedicated to your satisfaction and will be pleased to answer your
questions and your concerns.
Best wishes,
inepro.

Reader Bracket for MFP Assembly
All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical,
including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the
publisher.
Products that are referred to in this document may be either trademarks and/or registered trademarks of the respective owners. The
publisher and the author make no claim to these trademarks.
While every precaution has been taken in the preparation of this document, the publisher and the author assume no responsibility for
errors or omissions, or for damages resulting from the use of information contained in this document or from the use of programs
and source code that may accompany it. In no event shall the publisher and the author be liable for any loss of profit or any other
commercial damage caused or alleged to have been caused directly or indirectly by this document.
Revision number R 8. This revision of the manual can be applied to products with version 7.6 or higher.
Publisher
inepro
Managing Editor
K. de Graaf
Technical Editors
Koos de Graaf
Cover Design
H. Wagenaar
K. de Graaf
Team Coordinator
R. Groen
Production
inepro

Table of Contents
Bracket Assembly Instructions 1

ATTENTION!!
Read this manual carefully before installing the Reader Bracket for MFP Assembly!
Guarentee
No guarantee can be given if safety regulations are not followed.
Changes and/or modifications
Changes and/or modfications whch have not been approved by the responsible party can void
the user's authorty to operate the equitement.
Security
Always disconnect the power supply before handling anything inside the device.
For Indoor Use Only
FCC Federal Communications Commission - US
This device may only be used indoors.
This device is complies with part 15 of the FCC rules, operation is subject to two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, includng interference that may cause undesired operation.
CE Conformité Europeéne (Conform European Norm)
This device is in conformity with the EMC directive and low-voltage directive.
Conformité d’Industrie Canada
Appareil concernés:
Spider
Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux appareils
radio exempts de licence.
L’exploitation est autorisée aux deux conditions
suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le
fonctionnement.
Confirm Canada Industries
Relevant Devices:
Spider
This device complies with Industry Canada’s
licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of
the device.
RCM Regulatory Compliance Mark
This deviceis in conformity with Australian law.
End of life directives
Inepro is paying a lot of attention to environmentally-friendly production. Your new device contain materials which can be recycled
and reused. At the end of its life specialised companies can dismantle the discarded device to recycle the reusable materials and to
minimise the amount of materials to be disposed of. Please observe the local regulations regarding the disposal of packaging
materials, exhausted batteriesand old requipment.
Directives

inepro.com
Bracket Assembly Instructions
Pondweg 7 | 2153 PK, Nieuw-Vennep | The Netherlands | [phone] | [e-mail] |
Bracket Assembly Instructions
This document contains the assembly instructions and outer dimensions of the MFP Reader Bracket.
The bracket can be used for both the SCR Reader and the Spider Reader.
1. Clean Area
The bracket is 119mm deep, 58mm high and 66mm wide.
Determine the area where you want to attach the reader and the cable ducts. Clean those area's
keeping the following in mind.
§ Surface preparation is the key to success in applying double sided tapes.
§ While we are using an aggressive adhesive that is well-suited to your application, the double sided
tape wouldn’t perform like it should if the surface is not prepared correctly.
§ For a majority of surfaces that you commonly encounter, a good scrub with a mixture of isopropyl
alcohol (IPA) and water in equal proportions will do the job of preparing it for applying double
sided tape. The alcohol helps dissolve light grease and water clears away the dust and dirt. The
only care you need to take is to keep the surface dry and clear and not touch it with your bare
hands, as finger oils and other contaminants might affect it.

inepro.com
Bracket Assembly Instructions
Pondweg 7 | 2153 PK, Nieuw-Vennep | The Netherlands | [phone] | [e-mail] |
2. Attach Bracket Base
2a. Take off the protective foil from the foam adhesive at the back of the bracket base.
2b. Feed the cable trough the bracket base (it might be connected to your reader already).
2c. Carefully align the bracket and attach it to the MFP.
2d. Keep pressure on the bracket base for 1 minute.

inepro.com
Bracket Assembly Instructions
Pondweg 7 | 2153 PK, Nieuw-Vennep | The Netherlands | [phone] | [e-mail] |
3. Attach Reader to Bracket Base and slide cover on
3a. Place the double-sided tape precisely on the serial sticker at the bottom of the reader.
3b. Use the alignment pins on the bracket base and the alignment holes to align the reader and place
it on the bracket.
3c. Finally slide the bracket cover on the bracket base. It should click and be sturdy.

inepro.com
Bracket Assembly Instructions
Pondweg 7 | 2153 PK, Nieuw-Vennep | The Netherlands | [phone] | [e-mail] |
4. (optionally) Use cable ducts (like PS08651 Cable Duct PTM) to guide the cable to the
back
4a. Remove the protective foil from the adhesive at the back of the cable duct.
4b. Carefully guide the cable to the back with the cable ducts.
