User Manual
Please read the sections “Important notice” and “Warnings” at the end of this document
V 1.0
www.infineon.com/eval-audio-ma2304dns-b
www.infineon.com/eval-audio-ma2304pns-b
2023-07-14
UM_2307_PL88_2307_020213
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
About this document
Scope and purpose
This document describes the use and operation of the EVAL_AUDIO_MA2304xNS_B evaluation kit (EVK). The
MA2304xNS EVK is an evaluation and demonstration kit for MA2304DNS and MA2304PNS proprietary multilevel
amplifiers.
Intended audience
Audio amplifier design engineers.
Attention: Please read this user manual before operating the board. When powering up the board, make
sure to follow the instructions in the “MA2304xNS start-up sequence” section.
Stuck or in need of help?
Support for Infineon’s class D audio portfolio can be found quickly and easily by visiting the Class D Audio
Amplifier IC Forum or community.infineon.com. The community forum features members of the audio
applications team who are ready to provide timely support, helping you get your designs done quickly, reliably
and right the first time.
Safety precautions
Note: Please note the following warning regarding hazards associated with development systems.
Table 1 Safety precautions
Caution: The evaluation or reference board contains parts and assemblies sensitive to
electrostatic discharge (ESD). Electrostatic control precautions are required when
installing, testing, servicing or repairing the assembly. Component damage may result
if ESD control procedures are not followed. If you are not familiar with ESD control
procedures, refer to the applicable ESD protection handbooks and guidelines.

User Manual 2 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Table of contents
Table of contents
About this document....................................................................................................................... 1
Stuck or in need of help? ................................................................................................................. 1
Safety precautions.......................................................................................................................... 1
Table of contents............................................................................................................................ 2
1Overview............................................................................................................................... 3
1.1Board features and audio performance .................................................................................................3
1.2 EVK device type .......................................................................................................................................3
2Setup guide ........................................................................................................................... 4
2.1 EVK connections and interfaces .............................................................................................................5
2.1.1 EVAL_AUDIO_MA2304xNS_B board...................................................................................................5
2.1.2 Interface boards.................................................................................................................................6
2.1.3 Optional heatsink...............................................................................................................................7
2.1.4 EVK headers and connectors.............................................................................................................7
2.2 Notes on the digital I/O breakout header...............................................................................................9
3Operating the demonstration board........................................................................................10
3.1 Recommended operating conditions...................................................................................................10
3.2 Toggle switches.....................................................................................................................................10
3.3 Speaker load..........................................................................................................................................10
3.4 MERUS™ audio amplifier configurator .................................................................................................11
3.5 MA2304xNS start-up sequence .............................................................................................................11
4Measurement methods ..........................................................................................................12
5Schematic ............................................................................................................................14
5.1 Main page...............................................................................................................................................14
5.2 Amp page...............................................................................................................................................15
5.3 Power page............................................................................................................................................16
5.4 MCU page...............................................................................................................................................17
6PCB layout............................................................................................................................18
7Bill of materials.....................................................................................................................21
Revision history.............................................................................................................................25
Disclaimer.....................................................................................................................................26

User Manual 3 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Overview
1Overview
The demonstration board EVAL_AUDIO_MA2304xNS_B is an evaluation and demonstration board for MERUS™
audio’s MA2304DNS and MA2304PNS amplifiers.
It contains digital input/output (I/O) and a variety of output and setup/selection features. It also contains one
onboard buck power supply generator (1.8 V/3.3 V selectable) so only one external power supply (PVDD) is
necessary.
The board can be used to evaluate or demonstrate key features/advantages of the MERUS™ technology:
•Energy efficiency
−Power losses at typical audio listening levels
−Idle power loss
•Adaptive power management system
•No output filter components
−Solution cost and size reduction
•Audio performance
−THD performance and audio quality
1.1 Board features and audio performance
•Number of audio channels 2 (BTL) or 1 (PBTL)
•Audio input format Digital (I2S, LJF, RJF or TDM)
•Typical supply voltage 18 V (PVDD)
•Output noise level 52 µVRMS (high audio performance mode)
•Dynamic range 106 dB (high audio performance mode)
•Idle consumption at PVDD = 18 V 52 mW (low power consumption mode)
•Efficiency
−1 W, 8 ΩMore than 79 percent
−Full-scale, 8 ΩMore than 90 percent
Note: Idle consumption is the sum of output stage (PVDD) current, VDD and VDD_IO supply current. As all
the supplies are tied to PVDD, the efficiency of the buck converter should be considered when
measuring idle current consumption directly from PVDD. Features on the EVK make it possible to
break the input and output of the buck converters for these purposes (see Table 3). Please refer to
the MA2304xNS device datasheet for exact current figures.
1.2 EVK device type
The type of device –MA2304DNS/MA2304PNS –is printed on the top of the EVK, and is also stated on the serial
number label on the bottom side of the EVK PCB.

User Manual 4 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Setup guide
2Setup guide
The following is included in the MA2304xNS evaluation kit:
•EVAL_AUDIO_MA2304xNS_B board
•I2S interface boards: analog in, S/PDIF coax and S/PDIF optical
•Micro-USB cable
•22 µH power inductor
Additional equipment required for operation and evaluation:
•10 to 20 V DC power supply capable of driving 6 A (BTL) or 12 A (PBTL)
•Loudspeaker and speaker wires, as shown in Figure 1
In addition, for datasheet spec testing, as shown in Figure 1:
•2 to 8 Ωresistor load
•Audio analyzer with class D measurement filter
OR
Figure 1 Setup for “speaker test” or “datasheet spec test”
SPK
SPK+
SPK-
SPK+
SPK-
22µH
 
Filter
Audio
Analyzer

User Manual 5 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Setup guide
2.1 EVK connections and interfaces
The MA2304xNS EVK includes the main EVAL_AUDIO_MA2304xNS_B board and three interface boards.
2.1.1 EVAL_AUDIO_MA2304xNS_B board
The board features MA2304xNS silicon, digital I/O headers, enable and mute switches, speaker terminals,
power supply terminal blocks, and a USB port.
Figure 2 EVAL_AUDIO_MA230xxNS_B board (top view)

User Manual 6 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Setup guide
2.1.2 Interface boards
Three interface boards are included: analog in, S/PDIF coax and S/PDIF optical. These are plugged in to the J1
digital I/O breakout header for simple evaluation.
Figure 3 Interface boards
There is no need to configure the MA2304xNS when using these interface boards, as its digital audio output
format matches the MA2304xNS defaults.
Note that the interface boards are not compatible with a 1.8 V supply. When using the onboard buck converter,
ensure that the MA2304xNS board’s VDD_SEL jumper is configured for 3.3 V (pins 1 and 2).
Interface board input/output specifications are provided in Table 2.
Table 2 Interface board I/O specifications
Interface board
Input
Output
Analog in1
3.5 mm (1/8 in.) stereo TRS jack
2.1 VRMS full-scale
I2S, 24-bit serial audio at 3.3 V
SCK = 64 x WCK
WCK = 48 kHz
S/PDIF coax
RCA jack
0.2 V minimum, 5 V tolerant
32 to 96 kHz support
I2S, 24-bit serial audio at 3.3 V
SCK = 64 x WCK
WCK = 32 to 96 kHz
S/PDIF optical
Optical input jack
32 to 96 kHz support
I2S, 24-bit serial audio at 3.3 V
SCK = 64 x WCK
WCK = 32 to 96 kHz
1Noise measurements and other specs will show degraded performance when using the analog in interface board.

User Manual 7 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Setup guide
2.1.3 Optional heatsink
EVAL_AUDIO_MA2304xNS_B boards include holes for an optional heatsink. When high continuous output
power is required, it is recommended to use a heatsink. Recommended parts are Wakefield-Vette 960-31-28-D-
AB-0. Thermal conductivity material may be 3M Electronic Specialty 5519-155x210.
Figure 4 Recommended optional heatsink for continuous output power evaluation
2.1.4 EVK headers and connectors
The following table provides a description of each jumper, header, switch and test point. Defaults are shown in
the “Comment”column.
Table 3 EVK headers and connectors
Name
Description
Comment
J1
Digital I/O breakout header. Refer to Section 2.2 for details.
I/O pins. Do not jumper.
J2
Interface board connector
I/O pins. Do not jumper.
J_MSEL
Selects amplifier output mode between PBTL (L) and BTL (H)
Default:
BTL (pins 1 and 2)
JI2C_ADD
These headers select the I2C slave address (see Table 4)
Default:
I2C address 0b0100000
AD1: Low (pins 4 and 6)
AD0: Low (pins 3 and 5)
SW_ENABLE
Controls the amplifier’s ENABLE pin. Sets the amplifier into
enabled state when set to on.
Default:
Off
SW_MUTE
Controls the amplifier’s NMUTE pin. Mutes the amplifier when
set to mute.
Default:
Mute
J_CH0A
OUT0A speaker connection
CH0 positive speaker
output terminal
J_CH0B
OUT0B speaker connection
CH0 negative speaker
output terminal
J_CH1A
OUT1A speaker connection
CH1 positive speaker
output terminal
J_CH1B
OUT1B speaker connection
CH1 negative speaker
output terminal

User Manual 8 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Setup guide
Name
Description
Comment
J_OUT0
OUT0 speaker connector
Pin 1: OUT0B
Pin 2: GND
Pin 3: OUT0A
J_OUT1
OUT1 speaker connector
Pin 1: OUT1A
Pin 2: GND
Pin 3: OUT1B
J_ADC
AUX_ADC input header
Pin 1: ADC input
Pin 2: GND
J_VDDSEL
Sets the onboard buck converter output as:
3.3 V (pins 1 and 2)
1.8 V (pins 2 and 3)
Default:
3.3 V (pins 1 and 2)
J_VDD_SW
Provides the option to measure PVDD current into the buck
converter
Default:
Jumpered
J_VDD_ON
Provides the option to measure the buck converter output
current
Default:
Jumpered
J_SCL
Provides the option to isolate I2C_SCL from the MCU
Default:
Jumpered
J_SDA
Provides the option to isolate I2C_SDA from the MCU
Default:
Jumpered
J_I2S_SCK
Provides the option to isolate I2S_SCK from the MCU
Default:
Removed
J_I2S_WC
Provides the option to isolate I2S_WC from the MCU
Default:
Removed
J_I2S_DO
Provides the option to isolate I2S_DO from the MCU
Default:
Removed
J_I2S_DI
Provides the option to isolate I2S_DI from the MCU
Default:
Removed
J11
SWD/JTAG header for the onboard MCU
J_USB008
For future use
TP_OUT0A
Direct connection to device output node OUT0A
Output measurement
pin
TP_OUT0B
Direct connection to device output node OUT0B
Output measurement
pin
TP_OUT1A
Direct connection to device output node OUT1A
Output measurement
pin
TP_OUT1B
Direct connection to device output node OUT1B
Output measurement
pin
TP_GND
TP_GND2
Ground test points
MH1
MH2
Ground-connected mounting holes

User Manual 9 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Setup guide
Name
Description
Comment
MH3
MH4
Table 4 I2C address decoding (JI2C_ADD)
I2C device address
AD1
AD0
7-bit I2C address
0x20
L
L
0b0100000
0x21
L
H
0b0100001
0x22
H
L
0b0100010
0x23
H
H
0b0100011
2.2 Notes on the digital I/O breakout header
The digital I/O breakout header (J1) provides access to audio and control signals (I2S and I2C, respectively) as
well as several MA2304xNS GPIO pins and the onboard VDD supply (3.3 or 1.8 V). The J1 header is meant for use
with the interface boards, and/or external connections (external I2S, MCU, etc.) for measurements and
debugging. The J2 header contains exactly the same signals as J1 but can be used for monitoring the I/O digital
signals.
The MA2304xNS acts as an I2S slave, accepting SCK (bit clock) and WC (word clock) as inputs, with SCK = 64 x WC
as default.
Table 5 Digital I/O breakout header
Pin
Signal
Signal
Pin
20
GND
/AMP_ERR
19
18
GND
/AMP_CLIP
17
16
GND
I2S_DO
15
14
GND
I2S_WC
13
12
GND
I2S_SCK
11
10
GND
I2S_DI
9
8
GND
I2C_SDA
7
6
GND
I2C_SCL
5
4
GND
/AMP_MUTE
3
2
3.3V
AMP_ENABLE
1

User Manual 10 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Operating the demonstration board
3Operating the demonstration board
3.1 Recommended operating conditions
Table 6 Recommended operating conditions
Parameter
Minimum
Nominal
Maximum
Unit
PVDD
10
18
20
V
Output peak current (BTL)
Output peak current (PBTL)
6.0
12.0
A
A
3.2 Toggle switches
The board has two MA2304xNS-related toggle switches, as shown in Table 7. The toggle switches have the
following functions:
Table 7 Switch function
Switch
Function
SW_ENABLE
Off/enable (default set to “off”)
SW_MUTE
Mute/unmute (default set to “mute”)
3.3 Speaker load
The demonstration board is configured as a filterless amplifier. This means that no LC filter is placed between
the amplifier outputs and the load. In normal use the amplifier relies on the inherent inductance of the
loudspeaker, so no extra inductance is needed.
Inductors for use in series with power resistors are included with the demonstration board. These can be used
when making any measurements without a real loudspeaker as the load, and having no external low-pass filter
(LPF) in front of the audio analyzer input section.
Please note that many audio measurement analyzers do not perform correctly when connected directly to a
filterless amplifier output. Please refer to Section 4 for more information on measurement methods.

User Manual 11 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Operating the demonstration board
3.4 MERUS™ audio amplifier configurator
The demonstration board is used with PC graphical user interface (GUI) software to control the MA2304xNS
device.
The MA2304xNS can play audio by default without configuration, but to take advantage of the many features
the chip offers it is necessary to configure the device.
Refer to the MERUS™ audio amplifier configurator user manual for details on how to install and use this
software.
Figure 5 MA2304DNS GUI main window
3.5 MA2304xNS start-up sequence
Follow this (recommended) sequence to start the board:
1. Make sure toggle buttons are in “off” and “mute” positions.
2. Connect all cables (speakers/load, USB and power) to the EVK.
3. Connect an external I2S digital audio source to the EVK digital I/O header (J1). The EVK default I/O voltage is
3.3 V.
4. Turn on the PVDD power supply.
5. Make sure the I2S clocks are present before enabling the amplifier.
6. Start board by setting the SW_ENABLE toggle switch to the “on” position.
7. Start playing sound by setting the SW_MUTE toggle switch to the “unmute” position.
Mute and turn off the PVDD power supply when finished.

User Manual 12 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Measurement methods
4Measurement methods
Setting up a reliable measurement configuration for the MA2304DNS or the MA2304PNS takes a little more
effort than for linear amplifiers, and even “regular” switching amplifiers. This is mainly because the MA2304xNS
is a filterless amplifier, which means it does not require an external (usually expensive and bulky) LC filter to
remove switching residuals. The filterless application is enabled by the MERUS™ audio multilevel technique,
which ensures the switching residual is orders lower compared to “regular” switching amplifiers. For more
information on the multilevel switching technique, please refer to the datasheet.
To obtain reliable measurement results, the MA2304xNS devices require a separate external LPF in front of the
input stage of the audio analyzer. Most audio analyzers are bandwidth-limited at their input stage, which
means they cannot follow the rapid changes of the amplifier’s output stage. This can result in inaccurate and
high THD+N measurements.
Figure 6 shows the recommended measurement setup. The setup shows a LPF stage (AUX-0025) in front of the
audio analyzer (APx525 with the serial interface I/O option installed). In this case the measurement setup has
been built around Audio Precision hardware, but this can also be some other audio analyzer hardware. Please
note that it is recommended to use a balanced input measurement configuration.
22µH
 
Audio Analyzer
ChA IN
ChB IN
Audio Precision APx525
Analog Input External Class-D Filter
ChA IN
ChB IN
ChA OUT
ChB OUT
Audio Precision AUX-0025
Digital Serial
Bit Clock
Frame Clock
Data Out
I2S_SCK
I2S_WS
I2S_DI
22µH
 
OUT+
OUT-
OUT+
OUT-
BTL Ch1
BTL Ch0
Serial I/O
MA2304xNS
Device Under Test (DUT)
Figure 6 Recommended audio measurement setup

User Manual 13 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Measurement methods
Figure 7 shows an example measurement setup using an 8 Ω/22 µH load, similar to the setup shown in Figure 6.
Figure 7 Audio measurement setup example
Figure 8 shows an example dynamic range measurement performed with the previous measurement setup.
Figure 8 Dynamic range measurement example

User Manual 14 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Schematic
5Schematic
5.1 Main page
Figure 9 Main page
















 
 
 
 

 
 

  
    
    



  

 
 

   
   
 
 







 


 

 








 
 



 



 

 
 






   








 








 
 










User Manual 15 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Schematic
5.2 Amp page
Figure 10 Amp page
















 
 
 
 

 
 

   
  
    



  

 
 

   
    
 



 












 

 








  
 
 
 
   
 
 
 
 
 
 

  


  



  


  




  
  






  
 



   
 






  



  
  
  





  
  
  




  

   




 

  


  
 




 

  



   

   

 


  

 
 
 



  
  
  



  
  

 



 




  


 


 
 
  

 

  
 
 


  



  





  

  
 

 



    
  

 


  

  


  


  


  


  


  
  


  
  

 


  


  





 

 

  










 






 



 


 

User Manual 16 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Schematic
5.3 Power page
Figure 11 Power page
















 
 
 
 

 
 

   
 
    



  

 
 

   
    
 


  


  


 
  


  






  


  





 
 


 

  

  

 
  
  


  






 
 







 
 
 
 



 
  





  


   
   






 


User Manual 17 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
Schematic
5.4 MCU page
Figure 12 MCU page
















 
 
 
 

 
 

  
 
    



  

 
 

   
    
 

 





































































 
 
 
 
 
 
 
   
 
 
 
 
 
   
 
 
 
 
 
 
   
 
 
 
 
 
 
   
 
 
 
 
 
 
   
 
 
 
 
 
 
   
 
 






























 






   
 
 
 
 






 
 












  
 
 
 

 
 
  


  










  
  


 
 


 



  


  




 
 
 
 
 













 
 

 

 





 


  

  



  



  











 



 

  




  


  

  
 

  



 

  


  



 

  


  




  


  



  


  


  


  


  


  



  



  



 

  
 



  

   

 

 









 
  
 












 

  


 
 
 
 





User Manual 18 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
PCB layout
6PCB layout
Figure 13 PCB layout (top x-ray view)
Figure 14 PCB layout (top layer)

User Manual 19 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
PCB layout
Figure 15 PCB layout (layer 1)
Figure 16 PCB layout (layer 2)

User Manual 20 V 1.0
2023-07-14
User manual for MA evaluation boards
EVAL_AUDIO_MA2304DNS_B and EVAL_AUDIO_MA2304PNS_B
PCB layout
Figure 17 PCB layout (bottom layer)
Figure 18 PCB layout (bottom x-ray view, mirrored)
