USER MANUAL
Three phases Modular UPS Solutions:
30 kVA to 300 kVA HV
For 30 kVA modules

2
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
Table of Contents
1. Safety ...............................................................................................................................3
1.1 Important Safety Instructions.....................................................................................3
1.2 CE conformity............................................................................................................3
1.3 Installation information ..............................................................................................4
1.4 Maintenance .............................................................................................................4
1.5 Recycling the used battery .........................................................................................4
2. Installation ........................................................................................................................5
2.1 Initial Inspection .......................................................................................................5
2.2 Installation Environment ............................................................................................5
2.3 Unpacking.................................................................................................................6
2.4 Moving the Cabinet....................................................................................................8
2.5 Types of UPS Cabinet.................................................................................................9
2.6 Exterior................................................................................................................... 10
2.7 Internal Mechanisms................................................................................................ 14
2.8 Control Panel........................................................................................................... 19
2.9 Introduction of Modules ........................................................................................... 21
2.10 Power Cable .......................................................................................................... 27
2.11 Wiring................................................................................................................... 28
2.12 Power Module Installation ...................................................................................... 31
2.13 Battery Module Installation..................................................................................... 33
3. Operation Mode and UPS Operation .................................................................................. 34
3.1 Block diagram of UPS .............................................................................................. 34
3.2 Operation Mode....................................................................................................... 36
3.3 UPS Operation......................................................................................................... 43
4. Control Panel and Display Description................................................................................ 54
4.1 Introduction ............................................................................................................ 54
4.2 Screen Description................................................................................................... 55
4.3 Alarm List ............................................................................................................... 79
4.4 History Record......................................................................................................... 81
5. Interface and Communication ........................................................................................... 83
5.1 Dry Contact Port...................................................................................................... 83
5.2 Extra Comm. Slot .................................................................................................... 85
5.3 Local Communication Ports –RS232 & USB............................................................... 85
5.4 SNMP Slot ............................................................................................................... 85
6. Troubleshooting ............................................................................................................... 86
7. Service ............................................................................................................................ 89
7.1 Replacement Procedures Of Power Module ................................................................ 89
7.2 Replacement Procedures Of STS Module ................................................................... 89
7.3 Replacement Procedures Of Battery Module .............................................................. 89
7.4 Replacement Procedures Of Air Filter ........................................................................ 90
8. Specifications .................................................................................................................. 91
9. UPS Installation for Parallel Rack System ........................................................................... 92
9.1 Input and Output Wiring .......................................................................................... 92
9.2Parallel Board Setting and Power Module ................................................................... 93
9.3 Parallel Function Setting........................................................................................... 94
9.4Parallel Cable Connection.......................................................................................... 95
9.5Parallel System Turn On Procedure............................................................................ 95

3
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
1. Safety
1.1 Important Safety Instructions
This UPS contains LETHAL VOLTAGES. All repairs and service must be performed by AUTHORIZED
SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS inside the UPS.
WARNING:
The UPS designed for commercial and industrial purpose, it is forbidden to apply for any life
sustainment and support.
The UPS system contains its own energy source. The output terminals may carry live voltage
even when UPS is disconnected to an AC source.
To reduce the risk of fire or electrical shock, UPS installation has to be in a controlled room
where temperature and humidity are monitored. Ambient temperature must not exceed 40°C.
The system is only for indoor use.
Ensure all power is disconnected before installation or service.
Service and maintenance should be performed by qualified personnel only.
1.2 CE conformity
WARNING: This is a product for commercial and industrial application in the second environment
- installation restrictions or additional measures may be needed to prevent disturbances.
This logo means that the 220V/230V/240V HV product answers to the EMC and LVD
standards (regarding to the regulation associated with the electric equipment voltage and
the electromagnetic fields).
This is a category C3 UPS product. This category includes UPS with an output current exceeding 16
A and intended for use in the second environment. Such UPS are suitable for use in commercial or
industrial installations having a minimum boundary of 30 m from other buildings classified as first
environment (HV versions only).
WARNING:
An UPS belongs to the electronic and electrical equipment category. At the end of its
useful life it must be disposed of separately and in an appropriate manner.
This symbol is also affixed to the batteries supplied with this device, which means they
too have to be taken to the appropriate place at the end of their useful life.
Contact your local recycling or hazardous waste centre for information on proper disposal
of the used battery.
Before working on this circuit
-Isolate Uninterruptible Power System (UPS)
-Then check for Hazardous Voltage between
all terminals including the protective earth.
Risk of Voltage Backfeed
The isolation device must be able to carry the UPS input current.

4
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
1.3 Installation information
WARNING:
Installation must be performed by qualified personnel only.
The cabinets must be installed on a level floor suitable for computer or electronic equipment.
The UPS cabinet is heavy. If unloading instructions are not closely followed, cabinet may
cause serious injury.
Do not tilt the cabinets more than 10 degree.
Before applying electrical power to the UPS, make sure the Ground conductor is properly
installed.
Installation and Wiring must be performed in accordance with the local electrical laws and
regulations.
The disconnection device should be chosen based on the input current and should break line
and neutral conductors - four poles for three phases.
1.4 Maintenance
WARNING:
Only qualified service personnel should perform the battery installation.
The following PRECAUTIONS should be observed
(1.) Remove watches, rings, or other metal objects.
(2.) Use tools with insulated handles.
(3.) Wear rubber gloves and boots.
(4.) Do not lay tools or metal parts on top of batteries or battery cabinets.
(5.) Disconnect the charging source prior to connecting or disconnecting terminal.
(6.) Check if the battery is inadvertently grounded. If it is, remove the source of grounding.
Contacting with any part of the ground might result in electrical shock. The likelihood of
such shock can be prevented if such grounds are removed during installation and
maintenance.
UPS is designed to supply power even when disconnected from the utility power. After
disconnect the utility and DC power, authorized service personnel should attempt internal
access to the UPS.
Do not disconnect the batteries while the UPS is in Battery mode.
Disconnect the charging source prior to connecting or disconnecting terminals.
Batteries can result in a risk of electrical shock or burn from high short circuit current.
When replacing batteries, use the same number of sealed, lead-acid batteries.
Do not open or mutilate the battery. Release electrolyte is harmful to the skin and eyes, and
may be toxic.
1.5 Recycling the used battery
WARNING:
Do not dispose of the battery in a fire. Battery may explode. Proper disposal of battery is
required. Refer to your local codes for disposal requirements.
Do not open or mutilate the battery. Released electrolyte is harmful to the skin and eyes. It
may be toxic.
Do not discard the UPS or the UPS batteries in the trash. This product contains sealed,
lead-acid batteries and must be disposed properly. For more information, contact your local
recycling/reuse or hazardous waste center.
Do not discard waste electrical or electronic equipment (WEEE) in the trash. For proper
disposal, contact your local recycling/reuse or hazardous waste center.

5
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2. Installation
2.1 Initial Inspection
1. Visually examine if there is any damage inside and outside of packages in the process of the
transportation. If any damage, report it to the carrier immediately.
2. Verify the product label and confirm the consistency of the equipment.
3. If the equipment needs to be returned, carefully repack the equipment by using the originally
packing material that came with.
2.2 Installation Environment
1. The UPS is designed for indoor use only and should be located in a clean environment with
adequate ventilation to keep the environmental parameters within the required specification.
2. Make sure that transportation routes (e.g. corridor, door gate, elevator, etc.) and installation
area can accommodate and bear the weight of the UPS, the external battery cabinet and
handling equipment.
3. The UPS uses forced convection cooling by internal fans. Cooling air enters the module
through ventilation grills located at the front of the cabinet and exhausted through grills
located in the rear part of the cabinet. Please do not block the ventilation holes.
4. Ensure that the installation area is spacious for maintenance and ventilation.
5. Keep the temperature of installation area around 30°C and humidity within 90%. The highest
operating altitude is 1000 meters above sea level.
6. If necessary, install a system of room extractor fans to avoid formation of room temperature.
Air filters are necessary if the UPS is operated in a dusty environment.
7. It is recommended that you parallel the external battery cabinets to the UPS. The following
instructions of clearances are suggested:
Keep a clearance of 100cm from the top of the UPS for maintenance, wiring and
ventilation.
Keep a clearance of 100cm from the back of the UPS and the external battery cabinets for
ventilation.
Keep a clearance of 150cm from the front of the UPS and the external battery cabinets
for maintenance and ventilation.
8. For safety concerns, we suggest that you shall:
Equip with CO2 or dry powder fire extinguishers near the installation area.
Install the UPS in an area where the walls, floors and ceilings were constructed by
fireproof materials.
9. Do not allow unauthorized personnel to enter the installation area. Assign specific personnel
to keep the UPS key.

6
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.3 Unpacking
Before installation, please inspect the unit. Make sure that nothing inside the package is damaged.
Please keep the original package in a safe place for future use. S versions means without
batteries space.
Voltage
3 x 380V + N
3 x 400V + N
3 x 415V + N
1. Use a forklift to move the product to installed area. Refer to Figure 2-1. Please make sure the
bearing capacity of forklift is sufficient.
2. Please follow the orders in Figure 2-2 to remove carton and foams.
Figure 2-1

7
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
Figure 2-2
3. Put a ramp in the front of the cabinet and insert small wood into groove. Then, remove two
side panels. Refer to Figure 2-3.
Figure 2-3
4. Remove 4 fixing cabinet plates and loosen leveling feet by rotating them counterclockwise.
Then, move the cabinet from the pallet. Refer to Figure 2-4.
5. To fix the cabinet in position, simply rotate leveling feet clockwise. Refer to Figure 2-5.

8
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
Figure 2-4
Figure 2-5
2.4 Moving the Cabinet
The UPS is fixed on the pallet with 4 fixing cabinet plates. When removing it, pay attention to
the movement of the casters to avoid accidents.
The cabinet can be pushed forward or backward only. Pushing it sideward is not allowed.
When pushing the cabinet, pay attention not to overturn it as the gravity center is high.
1. If you need to move the UPS over a long distance, please use appropriate equipment like a
forklift. Do not use the UPS casters to move over a long distance.
2. After the UPS has been removed from the pallet to ground, we suggest that at least three
people move the UPS to the installation area. One person holds a lateral side of the UPS with
hands, another holds the other lateral side of the UPS with hands, and the other person pushes
the UPS either from the front side or from the back side to the installation area and avoid
tipping the UPS.
3. The casters are designed to move on level ground. Do not move the UPS on an uneven surface.
This might cause damage to the casters. Toppling the UPS could also damage the unit.
4. Ensure that the weight of UPS is within the designated bearing capacity of any handling
equipment.
5. At the bottom of the UPS, the four casters help you to move the UPS to a designated area.
Before you move the UPS, please turn the four leveling feet counterclockwise to raise them off
the ground. This protects the leveling feet from damage when moving the UPS. Refer to Figure
2-6.
Figure 2-6

9
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.5 Types of UPS Cabinet
There are two series of UPS cabinets, standard and extended for different requirements.
The standard cabinets have the battery modules inside and they can work as a stand-alone UPS or
be connected to battery externally.
The extended cabinets don’t have the battery module compartments. The battery has to be
connected externally.
Please consider the external battery space and wiring gauge for installation.
Mod5T
90/30
Mod5T
120/30
Mod5T
120/30 S
Mod5T
180/30 S
Mod5T
210/30 S
Mod5T
300/30 S
Cabinet
Height
30U
42U
30U
30U
42U
42U
Switch
Unit
1
1
1
1
1
1
STS
1
1
1
1
1
1
Max.
Power
Module
3
4
4
6
8*
10
Battery
Module
12
20
N/A
N/A
N/A
N/A
*Max power 210 kVA / Configuration 7+1

10
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.6 Exterior
In the front of the UPS, there are control interface (LCD Panel) and door lock.
The side panels are lockable. The casters at the bottom of the UPS cabinet can be used to move
over short distances. There are four leveling feet to fix and stabilize the UPS cabinet on the ground.
Refer to Figure 2-7.
Inside the cabinet, there are Breakers, STS Module, Power Module slots and Battery module slots
(Battery Module Slots is only for standard series). All wiring terminal blocks are located in the back
of cabinet.
Figure 2-7 Exterior

11
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.6.1 Mechanical Data
Dimensions
UPS cabinet
Width
Depth
Height
30U
600mm
1100m
1475mm
42U
600mm
1100m
2010mm
Figure 2-8 Dimensions

12
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.6.2 Front View
Unlock and open the front door and you will see the Main Breaker (Q1), Maintenance Breaker (Q2),
Output Breaker (Q3), STS Module, Power Module slots and Battery Module slots (Battery Module
Slots is only for standard series).
The cabinet of 300K Model has Maintenance Bypass Switch Only.
Mod5T 120/30 (42U) Mod5T 210/30 S (42U) Mod5T 300/30 S (42U)
1. Switch Unit
2. STS Module
3. Power Module
4. Battery Module

13
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.6.3 Rear View
Unlock and open the rear door and you will see the rear panel of UPS. There is a Battery Breaker
for internal battery modules in the standard series, but there is not any in the extended series (S
versions).
Mod5T 120/30 (42U)
Mod5T 210/30 S (42U) Mod5T 300/30 S (42U)
Figure 2-10 Rear View

14
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.7 Internal Mechanisms
2.7.1.1 Breakers
After opening the front door, there are three breakers, Main Breaker (Q1), Maintenance Breaker
(Q2) and Output Breaker (Q3).
For the standard series, there is a battery breaker for internal battery modules. You can see it
when you open the rear door.
Mod5T 120/30 (42U) front
Mod5T 210/30 S (42U) front
Figure 2-11 Front Breakers

15
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
Mod5T 90/30 (30U) Rear
Mod5T 120/30 (42U) Rear
Figure 2-12 Rear Breaker

16
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.7.1.2 Maintenance Bypass Switch
After opening the front door, there is one Maintenance Bypass Switch in the 300K cabinet.
Figure 2-12.1 Maintenance Bypass Switch

17
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.7.2 Wiring Terminal Blocks
Open the UPS’s back doors and you will see the wiring terminal block. For UPS cabinet wiring,
please refer to Figure 2-13.
No.
Item
Function
Description

Output Block
Connects the critical loads
Includes R, S, T and Neutral
terminals.

Bypass Input Block
Connects bypass AC source
Includes R, S, T and Neutral
terminals.

Main Input Block
Connects main AC source
Includes R, S, T and Neutral
terminals.

For UPS Grounding
For UPS grounding
Includes one grounding terminal.

Battery Input Block
Connects an external battery
cabinet
Includes
Positive (+), Negative (-) and
Neutral (N) terminals.
Figure 2-13 Mod5T 90/30 (30U) Terminal Blocks






18
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
Figure 2-14 Mod5T 120/30 (42U) Terminal Blocks
Figure 2-15 Mod5T 210/30 S (42U) Terminal Blocks











19
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.8 Control Panel
2.8.1 LCD Display
Through the graphic LCD display, the user can easily understand the operation mode of UPS. In
addition, the measurement, parameters, versions of firmware and warnings can be browsed in the
friendly interface. For detailed information, please refer to Charter 4.
Figure 2-16 Control Panel
2.8.2 LED Indicators
LED
Color
Status
Definition
INPUT
Green
On
Input source is normal.
Flashing
Input source is abnormal (out of limit).
Off
No input source
BYPASS
Yellow
On
Load on Bypass.
Flashing
Input source is abnormal (out of limit).
Off
Bypass not operating.
INVERTER
Green
On
Load on inverters.
Off
Inverters not operating.
BATTERY
Red
On
Load on Battery.
Flashing
Low battery
Off
Battery converter is normal and battery is charging.
ALARM
Red
On
UPS fault.
Flashing
UPS alarm.
Off
Normal.

20
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –04 17 AA 59 201 06
2.8.3 Function Keys
Control Key
Description
Esc
When it is in Main screen, you can enter menu by pressing ESC
key.
Return to previous screen, when screen is not in Main screen.
Return to previous value in the same row, so you can change it.
For example, when changing 4-digit password, press “Esc” to
allow cursor back to previous digit.
(Up) (Left)
Key for menu page navigation or digit modification.
(Down) (Right)
Key for menu page navigation or digit modification.
Enter
Confirmation of commands, or cursor displacement.
Home
Return to Main screen.
Power On/Off
Turn on UPS or turn off UPS.
